AMD AN9 32X User Manual
g
g
AN9 32X
Introduction
Motherboard
AMD Socket AM2
User’s Manual
Hardware Setup
BIOS Setup Driver & Utility CD Appendix
AMD Socket AM2
ATX Motherboard
NB: NVIDIA C51XE
SB: NVIDIA MCP55PXE
2GHz HT
Dual DDR2 800 DIMM Slots
NVIDIA SLI Technology
Dual PCI-E X16 Slots
Dual GbE LAN
IEEE 1394a
About this Manual:
This user’s manual contains all the information you may
need for settin
manual of PDF format (readable by Adobe Reader), place
the “Driver & Utility CD” into the CD-ROM drive in your
system. The auto-run screen will appear, click the
“Manual” tab to enter its submenu. If not, browse the
root directory of the CD-ROM via the File Mana
double click the “AUTORUN” file.
up this motherboard. To read the user’s
er, and
8x SATA 3Gb/s with RAID
ABIT Guru™ Technology
ABIT Silent OTES™ Technology
7.1 Channel HD Audio
AN9 32X
User’s Manual
English, 1
June, 2006
st
Edition
Copyright and Warranty Notice
The information in this document is subject to change without notice and does not represent a
commitment on part of the vendor, who assumes no liability or responsibility for any errors that may
appear in this manual.
No warranty or representation, either expressed or implied, is made with respect to the quality,
accuracy or fitness for any particular part of this document. In no event shall the manufacturer be
liable for direct, indirect, special, incidental or consequential damages arising from any defect or
error in this manual or product.
Product names appearing in this manual are for identification purpose only and trademarks and
product names or brand names appearing in this document are the property of their respective
owners.
This document contains materials protected under International Copyright Laws. All rights reserved.
No part of this manual may be reproduced, transmitted or transcribed without the expressed written
permission of the manufacturer and authors of this manual.
If you do not properly set the motherboard settings, causing the motherboard to malfunction or fail,
we cannot guarantee any responsibility.
ii AN9 32X
Contents
Introduction
1. Introduction..................................................................... 1-1
1.1 Features & Specifications .............................................................1-1
1.2 Motherboard Layout.....................................................................1-3
2. Hardware Setup ............................................................... 2-1
2.1 Choosing a Computer Chassis.......................................................2-1
2.2 Installing Motherboard .................................................................2-1
2.3 Checking Jumper Settings ............................................................2-2
2.3.1 CMOS Memory Clearing Header and Backup Battery ..............2-3
2.3.2 Wake-up Headers................................................................2-5
2.4 Connecting Chassis Components...................................................2-6
2.4.1 ATX Power Connectors ........................................................2-6
2.4.2 Front Panel Switches & Indicators Headers............................2-7
2.4.3 FAN Power Connectors ........................................................2-8
2.5 Installing Hardware......................................................................2-9
2.5.1 CPU Socket AM2 .................................................................2-9
2.5.2 DDR2 Memory Slots ..........................................................2-11
2.5.3 PCI Express X16 Add-on Slots (Install Graphics Card) ..........2-12
2.5.4 AudioMAX Connection Slot ................................................. 2-14
2.6 Connecting Peripheral Devices .................................................... 2-17
2.6.1 Floppy and IDE Disk Drive Connectors ................................ 2-17
2.6.2 Serial ATA Connectors ....................................................... 2-18
2.6.3 Additional USB 2.0 Port Headers......................................... 2-19
2.6.4 Additional IEEE1394 Port Headers ......................................2-19
2.6.5 PCI Express X1 Add-on Slots .............................................. 2-20
2.6.6 PCI Add-on Slot ................................................................2-20
2.6.7 GURU Panel Connection Header ......................................... 2-21
2.7 Onboard Status Display..............................................................2-22
2.7.1 POST Code Displayer.........................................................2-22
2.7.2 Power Source Indicators .................................................... 2-23
2.8 Connecting I/O Devices.............................................................. 2-24
Hardware Setup
BIOS Setup Driver & Utility CD Appendix
3. BIOS Setup....................................................................... 3-1
3.1 µGuru™ Utility..............................................................................3-2
3.1.1 OC Guru .............................................................................3-2
3.1.2 ABIT EQ .............................................................................3-4
3.2 Standard CMOS Features............................................................ 3-10
AN9 32X iii
3.3 Advanced BIOS Features ............................................................3-13
3.4 Advanced Chipset Features......................................................... 3-15
3.5 Integrated Peripherals................................................................ 3-17
3.6 Power Management Setup.......................................................... 3-21
3.7 PnP/PCI Configurations ..............................................................3-24
3.8 Load Fail-Safe Defaults ..............................................................3-26
3.9 Load Optimized Defaults ............................................................3-26
3.10 Set Password........................................................................... 3-26
3.11 Save & Exit Setup ....................................................................3-26
3.12 Exit Without Saving.................................................................. 3-26
4. Driver & Utility CD............................................................ 4-1
4.1 nVidia nForce Chipset Driver......................................................... 4-2
4.2 Realtek HD Audio Driver...............................................................4-3
4.3 Silicon Image 3132 RAID Driver....................................................4-4
4.4 Cool’n’Quiet Driver.......................................................................4-5
4.5 USB 2.0 Driver.............................................................................4-7
4.6 ABIT µGuru Utility........................................................................4-7
4.7 NVRaid Floppy Disk......................................................................4-8
5. Appendix .......................................................................... 5-1
5.1 POST Code Definitions .................................................................5-1
5.1.1 AWARD POST Code Definitions.............................................5-1
5.1.2 AC2005 POST Code Definitions.............................................5-4
5.2 Troubleshooting (How to Get Technical Support?)..........................5-5
5.2.1 Q & A.................................................................................5-5
5.2.2 Technical Support Form ......................................................5-8
5.2.3 UNIVERSAL ABIT Contact Information ..................................5-9
iv AN9 32X
1. Introduction
Introduction
1.1 Features & Specifications
CPU
• Supports Socket 940 AM2 Processor with 2GHz system bus using Hyper-Transport™
Technology
• Supports AMD CPU Cool ‘n’ Quiet Technology
Chipset
• Northbridge: NVIDIA®C51XE Chipset
• Southbridge: NVIDIA
Memory
• Four 240-pin DIMM slots
• Supports Dual Channel DDR2 800 Un-buffered ECC/Non-ECC memory
• Supports maximum memory capacity up to 8GB
ABIT Engineered
• ABIT Guru™ Technology
• ABIT Silent OTES
NVIDIA SLI Technology
• Two PCI-Express X16 slots support NVIDIA Scalable Link Interface
SATA 3Gb/s RAID
• Supports 6 ports NV SATA 3Gb/s RAID 0/1/0+1/5/JBOD
2nd SATA 3Gb/s RAID
• 1x Internal SATA 3Gb/s port
• 1x External SATA 3Gb/s port
Dual GbE LAN
• Dual NVIDIA® Gigabit Ethernet
IEEE 1394
• Supports 2 Ports IEEE 1394a at 400Mb/s transfer rate
Audio
• ABIT AudioMAX HD 7.1 CH
• Supports auto jack sensing and optical S/PDIF In/Out
Expansion Slots
• 2x PCI Express x16 slots
• 2x PCI Express x1 slots
• 1x PCI slot
®
MCP55PXE Chipset
™
Technology
AN9 32X 1-1
• 1x AudioMAX slot
Internal I/O Connectors
• 1x Floppy port
• 1x UDMA 133/100/66/33 connector
• 7x SATA connectors
• 3x USB 2.0 headers
• 2x IEEE1394a headers
Rear Panel I/O
• Silent OTES™
• 1x eSATA connector
• 1x PS/2 Keyboard connector
• 1x PS/2 Mouse connector
• 2x RJ-45 Gigabit LAN ports
• 4x USB 2.0 ports
RoHS Compliancy
• 100% Lead-free process and RoHS compliancy
Miscellaneous
• ATX form factor (305mm x 245mm)
※ Specifications and information contained herein are subject to change without
notice.
1-2 AN9 32X
1.2 Motherboard Layout
Introduction
AN9 32X 1-3
1-4 AN9 32X
2. Hardware Setup
In this chapter we will elaborate all the information you need upon installing this motherboard
to your computer system.
※ Always power off the computer and unplug the AC power cord before adding or
removing any peripheral or component. Failing to so may cause severe damage
to your motherboard and/or peripherals. Plug in the AC power cord only after
you have carefully checked everything.
2.1 Choosing a Computer Chassis
• This motherboard carries an ATX form factor of 305 x 245 mm. Choose a chassis big
enough to install this motherboard.
• As some features for this motherboard are implemented by cabling connectors on the
motherboard to indicators and switches or buttons on the chassis, make sure your chassis
supports all the features required.
• If there is possibility of adopting some more hard drives, make sure your chassis has
sufficient power and space for them.
• Most chassis have alternatives for I/O shield located at the rear panel. Make sure the I/O
shield of the chassis matches the I/O port configuration of this motherboard. You can find
an I/O shield specifically designed for this motherboard in its package.
2.2 Installing Motherboard
Hardware Setup
Most computer chassis have a base with
many mounting holes to allow the
motherboard to be securely attached, and at
the same time, protected the system from
short circuits. There are two ways to attach
the motherboard to the chassis base:
1. with studs,
2. or with spacers
In principle, the best way to attach the board
is with studs. Only if you are unable to do
this should you attach the board with spacers.
Line up the holes on the board with the mounting holes on the chassis. If the holes line up and
there are screw holes, you can attach the board with studs. If the holes line up and there are
only slots, you can only attach with spacers. Take the tip of the spacers and insert them into
the slots. After doing this to all the slots, you can slide the board into position aligned with slots.
After the board has been positioned, check to make sure everything is OK before putting the
chassis back on.
AN9 32X 2-1
r
To install this motherboard:
1. Locate all the screw holes on
the motherboard and the
chassis base.
2. Place all the studs or spacers
needed on the chassis base
and have them tightened.
3. Face the motherboard’s I/O
ports toward the chassis’s rear
panel.
4. Line up all the motherboard’s
screw holes with those studs o
spacers on the chassis.
5. Install the motherboard with
screws and have them
tightened.
※ To prevent shorting the PCB circuit, please REMOVE the metal studs or spacers if
they are already fastened on the chassis base and are without mounting-holes
on the motherboard to align with.
Face the chassis’s rear panel.
2.3 Checking Jumper Settings
For a 2-pin jumper, plug the jumper cap on both pins will make it CLOSE (SHORT). Remove the
jumper cap, or plug it on either pin (reserved for future use) will leave it at OPEN position.
SHORT OPEN OPEN
For 3-pin jumper, pin 1~2 or pin 2~3 can be shorted by plugging the jumper cap in.
Pin 1~2 SHORT Pin 2~3 SHORT
2-2 AN9 32X
2.3.1 CMOS Memory Clearing Header and Backup Battery
The time to clear the CMOS memory occurs when (a) the CMOS data becomes corrupted, (b)
you forgot the supervisor or user password preset in the BIOS menu, (c) you are unable to
boot-up the system because the CPU ratio/clock was incorrectly set in the BIOS menu.
This header uses a jumper cap to clear the CMOS memory and have it reconfigured to the
default values stored in BIOS.
• Pins 1 and 2 shorted (default): Normal operation.
• Pins 2 and 3 shorted: Clear CMOS memory.
To clear the CMOS memory and load in the default values:
1. Power off the system and disconnect with AC power source.
2. Set pin 2 and pin 3 shorted by the jumper cap. Wait for a few seconds. Set the jumper cap
back to its default settings --- pin 1 and pin 2 shorted.
3. Power on the system.
4. For incorrect CPU ratio/clock settings in the BIOS, press <Del> key to enter the BIOS setup
menu right after powering on system.
5. Set the CPU operating speed back to its default or an appropriate value.
6. Save and exit the BIOS setup menu.
Hardware Setup
AN9 32X 2-3
CMOS Backup Battery:
An onboard battery saves the CMOS memory to keep the BIOS information stays on even after
disconnected your system with power source. Nevertheless, this backup battery exhausts after
some five years. Once the error message like “CMOS BATTERY HAS FAILED” or “CMOS
checksum error” displays on monitor, this backup battery is no longer functional and has to
be renewed.
To renew the backup battery:
1. Power off the system and disconnect with AC power source.
2. Remove the exhausted battery.
3. Insert a new CR2032 or equivalent battery. Pay attention to its polarity. The “+” side is its
positive polarity.
4. Connect AC power source and power on the system.
5. Enter the BIOS setup menu. Reconfigure the setup parameters if necessary.
CAUTION:
※ Danger of explosion may arise if the battery is incorrectly renewed.
※ Renew only with the same or equivalent type recommended by the battery
manufacturer.
※ Dispose of used batteries according to the battery manufacturer’s instructions.
2-4 AN9 32X
2.3.2 Wake-up Headers
These headers use a jumper cap to enable/disable the wake-up function.
Hardware Setup
• PS2-PWR1:
Pin 1-2 shorted (Default): Disable wake-up function support at Keyboard/Mouse port.
Pin 2-3 shorted: Enable wake-up function support at Keyboard/Mouse port.
• USB-PWR1:
Pin 1-2 shorted (Default): Disable wake-up function support at USB1 port.
Pin 2-3 shorted: Enable wake-up function support at USB1 port.
• USB-PWR2:
Pin 1-2 shorted (Default): Disable wake-up function support at USB2 port.
Pin 2-3 shorted: Enable wake-up function support at USB2 port
• FP-PWR1:
Pin 1-2 shorted (Default): Disable wake-up function support at FP-USB1 port.
Pin 2-3 shorted: Enable wake-up function support at FP-USB1 port.
• FP-PWR2:
Pin 1-2 shorted (Default): Disable wake-up function support at FP-USB2 port.
Pin 2-3 shorted: Enable wake-up function support at FP-USB2 port
• FP-PWR3:
Pin 1-2 shorted (Default): Disable wake-up function support at FP-USB3 port.
Pin 2-3 shorted: Enable wake-up function support at FP-USB3 port
AN9 32X 2-5
2.4 Connecting Chassis Components
2.4.1 ATX Power Connectors
These connectors provide the connection from an ATX power supply. As the plugs from the
power supply fit in only one orientation, find the correct one and push firmly down into these
connectors.
ATX 24-Pin Power Connector:
The power supply with 20-pin or 24-pin cables can both be connected to this 24-pin connector.
Connect from pin-1 for either type. However, a 20-pin power supply may cause the system
unstable or even unbootable for the sake of insufficient electricity. A minimum power of 300W
or higher is recommended.
ATX 12V 4-Pin Power Connector:
This connector supplies power to CPU. The system will not start without connecting power to
this one.
Auxiliary 12V Power Connector:
This connector provides an auxiliary power source for devices added on PCI
Express slots.
2-6 AN9 32X
2.4.2 Front Panel Switches & Indicators Headers
This header is used for connecting switches and LED indicators on the chassis front panel.
Watch the power LED pin position and orientation. The mark “+” align to the pin in the figure
below stands for positive polarity for the LED connection. Please pay attention when connecting
these headers. A wrong orientation will only cause the LED not lighting, but a wrong connection
of the switches could cause system malfunction.
• HLED (Pin 1, 3):
Connects to the HDD LED cable of chassis front panel.
• RST (Pin 5, 7):
Connects to the Reset Switch cable of chassis front panel.
• SPKR (Pin 13, 15, 17, 19):
Connects to the System Speaker cable of chassis.
• SLED (Pin 2, 4):
Connects to the Suspend LED cable (if there is one) of chassis front panel.
• PWR (Pin 6, 8):
Connects to the Power Switch cable of chassis front panel.
• PLED (Pin 16, 18, 20):
Connects to the Power LED cable of chassis front panel.
Hardware Setup
AN9 32X 2-7
2.4.3 FAN Power Connectors
These connectors each provide power to the cooling fans installed in your system.
• CPUFAN1: CPU Fan Power Connector
• SYSFAN1: System Fan Power Connector
• AUXFAN1~4: Auxiliary Fan Power Connector
※ These fan connectors are not jumpers. DO NOT place jumper caps on these
connectors.
2-8 AN9 32X
2.5 Installing Hardware
※ DO NOT scratch the motherboard when installing hardware. An accidentally
scratch of a tiny surface-mount component may seriously damage the
motherboard.
2.5.1 CPU Socket AM2
※ DO NOT touch or bend the delicate pins on the CPU whenever you are holding it.
The installation procedures vary with different types of CPU fan-and-heatsink assembly. The
one shown here is served for DEMO only. For detailed information on how to install the one
you bought, refer to its installation guidelines.
1. Pull out the socket lever away from the
socket and fully lift it up over 90-degree
angle.
Locate and align the triangle mark with
both the CPU and the socket body.
Vertically place the CPU with its pin-side
down into the socket.
Be careful to insert the CPU into the
socket. The CPU only fits in one
orientation with the socket. DO NOT
force the CPU into the socket.
2. After placing the CPU into position, push
the socket lever down into its locked
position to secure the CPU. The lever
clicks when it’s locked into position.
3. The heatsink for CPU may have thermal
interface material attached to its
bottom. If not, applying a few squeeze
of thermal paste to the CPU die will help
to increase the contact.
Hardware Setup
AN9 32X 2-9
g
4. Place the heatsink and fan assembly
onto the retention frame. Match the
heatsink clip with the socket
mounting-lug. Hook the spring clip to
the mounting-lug.
5. On the other side, push the retention
clip straight down to lock into the plastic
lug on the retention frame.
6. Connect the CPU cooling fan power
cable to the CPUFAN1 connector on this
motherboard.
※ The “CPUFAN1” connector MUST be
connected with coolin
fan, no
matter a 3-Pin or 4-Pin CPU Fan.
※ The motherboard in this illustration is served for DEMO only, may not be the
same type or model as the one described in this user’s manual.
※ A higher fan speed will be helpful for better airflow and heat-dissipation.
Nevertheless, stay alert to touch any heatsink since the high temperature
generated by the working system is still possible.
2-10 AN9 32X
2.5.2 DDR2 Memory Slots
This motherboard provides four 240-pin DIMM slots for Dual Channel DDR2 800 memory
modules with memory expansion size up to 8GB.
To reach the performance of Dual Channel DDR2, the following rules must be obeyed:
• For a 2-DIMM dual-channel installation:
Populate DIMM modules of the same type and size on slots [DIMM1]+[DIMM2], or slots
[DIMM3]+[DIMM4].
• For a 4-DIMM dual-channel installation:
Populate 2 DIMM modules of the same type and size on slots [DIMM1]+[DIMM2], and
another 2 DIMM modules of the same type and size on slots [DIMM3]+[DIMM4].
※ [DIMM1] and [DIMM2] slots are made of the same color.
[DIMM3] and [DIMM4] are made of another same color.
Usually there is no hardware or BIOS setup required after adding or removing memory modules,
but you will have to clear the CMOS memory first if any memory module related problem
occurs.
Hardware Setup
AN9 32X 2-11
To install system memory:
1. Power off the computer and unplug the AC power cord before installing or removing
memory modules.
2. Locate the DIMM slot on the board.
3. Hold two edges of the DIMM module
carefully, keep away from touching its
connectors.
4. Align the notch key on the module with
the rib on the slot.
5. Firmly press the module into the slots
until the ejector tabs at both sides of the slot automatically snap into the mounting notch.
Do not force the DIMM module in with extra force as the DIMM module only fits in one
direction.
6. To remove the DIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the DIMM module.
※ Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.
2.5.3 PCI Express X16 Add-on Slots (Install Graphics Card)
These slots support the connections of graphics cards that comply with PCI Express
specifications. This motherboard provides dual PCI-Express X16 slots for one or two graphics
cards installation:
One PCIE graphics card installation (Normal Mode):
Insert your PCIE graphics card into [PCIEXP1]
slot.
2-12 AN9 32X
Two PCIE graphics cards installation (SLI Mode):
To install two SLI-ready graphics cards under SLI Mode, you will need to:
• Prepare two identical NVIDIA certified, SLI-ready PCI Express x16 graphics cards (the same
model from the same manufacturer).
• Make sure the graphics card driver supports the NVIDIA SLI technology. Download the
latest driver form NVIDIA website (www.nvidia.com
• Make sure your power supply unit is sufficient to provide the minimum power required.
※ The following illustration is served for DEMO only. All the devices, including the
motherboard, the graphics cards, the SLI Bridge Connector, or the SLI bracket,
may not be exactly the same type, shape, or model as the one you bought.
1. Insert two identical SLI-ready graphics
cards into both PCIEXP1 and PCIEXP2
slots.
※ The NVIDIA SLI technology
currently supports the Windows XP
operating system only.
).
Hardware Setup
2. Bridge connecting two graphics cards
with the “SLI Connector Card” (fit in
both direction).
Insert and secure the SLI supporting
bracket.
AN9 32X 2-13
2.5.4 AudioMAX Connection Slot
This slot provides the audio input/output connection over the rear I/O part through an add-on
daughter-card. Find your “AudioMAX” daughter-card and its driver in the motherboard
package.
• S/PDIF Out: This connector provides an S/PDIF-Out connection through optical fiber to
digital multimedia devices.
• S/PDIF In: This connector provides an S/PDIF-In connection through optical fiber to
digital multimedia devices.
Line-In: Connects to the line out from external audio sources.
• Mic-In: Connects to the plug from external microphone.
• Line-Out: Connects to the front left and front right channel in the 7.1-channel or regular
2-channel audio system.
• Cen/Sub: Connects to the center and subwoofer channel in the 7.1-channel audio system.
• R.L./R.R. (Rear Left / Rear Right): Connects to the rear left and rear right channel in
the 7.1-channel audio system.
• S.L./S.R. (Surround Left / Surround Right): Connects to the surround left and
surround right channel in the 7.1-channel audio system.
• CD1: This connector connects to the audio output of internal CD-ROM
drive or add-on card.
2-14 AN9 32X
• FP-AUDIO1: This header provides the connection to audio connector
at front panel.
This header provides the front panel connection for HD (High Definition)
Audio, yet for AC’97 Audio CODEC connection, you must carefully check the
pin assignment before connecting from the front panel module. An incorrect
connection may cause malfunction or even damage the motherboard.
※ Please do not connect the
“Ground” cable or “USB VCC”
cable from the front panel
module to the Pin 4 “AVCC”
of this header.
Driver Configuration for AC’97
audio connection:
The audio driver is originally
configured to support HD Audio. For
AC’97 audio connection, you may:
1. Right-click the “Realtek HD Audio Manager”
in system tray.
icon
Pin Assignment
Pin
(HD AUDIO)
1 MIC2 L 1 MIC In
2 AGND 2 GND
3 MIC2 R 3 MIC Power
4 AVCC 4 NC
5 FRO-R 5 Line Out (R)
6 MIC2_JD 6 NC
7 F_IO_SEN 7 NC
9 FRO-L 9 Line Out (L)
10 LINE2_JD 10 NC
Pin
Pin Assignment
(AC’97 AUDIO)
Hardware Setup
2. Click “Audio I/O” tab, and then click
“Connector Settings”.
AN9 32X 2-15
Loading...
