MICRO CONTROLS INC.

ADVANCED

Manual #: 940-0D043

GENERAL INFORMATION

Important User Information

The products and application data described in this manual are useful in a wide variety of different applications. Therefore, the user and others responsible for applying these products described herein are responsible for determining the acceptabilit y f or e ach applic at ion . While efforts have been made to provide accurate infor mation within this manual, AMCI assumes no responsibility for the application or the completeness of the information contained herein.

UNDER NO CIRCUMSTANCES WILL ADVANCED MICRO CONTROLS, INC. BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES OR LOSSES, INCLUDING INDIRECT OR CONSEQUENTIAL DAM AGES OR LOSSES, ARISING FROM THE USE OF ANY INFORMATION CONTAINED WITHIN THIS MANUAL, OR THE USE OF ANY PRODUCTS OR SERVICES REFERENCED HEREIN.

No patent liability is assumed by AMCI, with respect to use of information, circuits, equipment, or software described in this manual.

in part, for your personal use, provided that this copyright notice is included. You may distribute copies of this complete manual in electronic format provided that they are unaltered from the version posted by Advanced Micro Controls Inc. on our official website: www.amci.com. You may incorporate portio ns of this documents in other literature for your own personal use provided that you include the notice “Portions of this document copyright 2018 by Advanced Micro Controls Inc.” You may not alter the contents of this document or charge a fee for reproducing or distributing it.

Standard Warranty

ADVANCED MICRO CONTROLS, INC. warrants that all equipment manufactured by it will be free from defects, under normal use, in materials and workmanship for a period of [18] months. Within this warranty period, AMCI shall, at its option, repair or replace, free of charge, any equipment covered by this warranty which is returned, shipping charges prepaid, within eighteen months from date of invoice, and which upon examination proves to be defective in material or workmanship and not caused by accident, misuse, neglect, alteration, improper installation or improper testing.

The provisions of the "STANDARD WARRANTY" are the sole obligations of AMCI and excludes all other warranties expressed or implied. In no event shall AMCI be liable for incidental or consequential damages or for delay in performance of this warranty.

Returns Policy

All equipment being returned to AMCI for repair or replacement, regardless of warranty status, must have a Return Merchandise Authorization number issued by AMCI. Call (860) 585-1254 with th e model number and serial number (if applicable) along with a description of the problem during regular business hours, Monday through Friday , 8AM - 5PM Eastern. An "RMA" number will be issued. Equipment must be shipped to AMCI with transportation charges prepaid. Title and risk of loss or damage remains with the customer until shipment is received by AMCI.

24 Hour Technical Support Number

24 Hour technical support is available on this product. If you have internet access, start at www.amci.com. Product documentation and FAQ’s are available on the site that answer most common questions.

If you require additional technical support, call (860) 583-1254. Your call will be answered by the factory during regular business hours, Monday through Friday, 8AM - 5PM Eastern. During non-business hours an automated system will ask you to enter the telephone number you can be reached at. Please remember to include your area code. The system will page an engineer on call. Please have your product model number and a description of the problem ready before you call.

Waste Electrical and Electronic Equipment (WEEE)

At the end of life, this equipment should be collected separately from any unsorted municipal waste.

ADVANCED MICRO CONTROLS INC.

General Information

Important User Information ..................... 2

Standard Warranty ................................... 2

Returns Policy .......................................... 2

24 Hour Technical Support Number ........ 2

WEEE Statement ..................................... 2

About This Manual

Audience .................................................. 5

Navigating this Manual ............................ 5

Manual Conventions ................................ 5

Trademarks and Other Legal Stuff .......... 5

Revision Record ....................................... 5

Where to Go From Here .......................... 6

Reference 1: The Absolute Digital

DuraCoder

Absolute Digital DuraCoder Overview ... 7

Absolute Digital DuraCoder 

Diagnostics .................................. 7

Part Numbering System ........................... 8

Description of Outputs ............................. 8

Output Codecs ............................... 8

Output Update Control .................. 8

Output Electrical Configurations ... 9

Status LED ............................................... 9

Normal Operation 

(Test Pin open) ............................ 9

Test Mode 

(Test Pin grounded) ..................... 9

Electrical Specifications .......................... 10

Environmental Specifications .................. 10

Mechanical Specifications ....................... 10

Task 1: Installation

Flange Mount Outline Drawings .............. 11

End Connector .............................. 11

Side Connector .............................. 11

Alternate Shafts ............................. 12

Shaft Loading ................................ 12

Servo Mount Outline Drawings ............... 13

End Connector .............................. 13

Side Connector .............................. 13

Alternate Shafts ............................. 14

Shaft Loading ................................ 14

Blind Shaft Mount Outline Drawings ...... 15

End Connector .............................. 15

Side Connector .............................. 16

Available Shaft Diameters ............ 16



Shaft Loading ................................ 16

5/8" Shaft Outline Drawings .................... 17

End Connector .............................. 17

Side Connector .............................. 18

Shaft Loading ................................ 19

Connector Pinout ...................................... 19

Task 2: Diagnostics

Output States ............................................ 21

Over Voltage and 

Under Voltage Detection ....................... 21

Error Output ............................................. 22

Test Input ................................................. 22

Normal Operation 

(Test Pin Open) ........................... 22

Test Mode 

(Test Pin Tied to GND) .............. 23

Testing Sourcing Output DuraCoders ...... 23

High True Output Units ................ 23

Low True Output Units ................. 23

Testing Sinking Output DuraCoders ........ 24

High True Output Units ................ 24

Low True Output Units ................. 24

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

TABLE OF CONTENTS

Notes

Absolute Digital DuraCoder User’s Manual

ADVANCED MICRO CONTROLS INC.

Read this chapter to learn how to navigate through this manual and familiarize yourself with the conventions used in it. The last section of this chapter highl ights the manual’s remaining chapters and their target audience.

Audience

This manual explains the installation and operation of AMCI’s absolute digital output DuraCoders. It is written for the engineer responsible for incorporating the Absolute Digital DuraCoder into a design as well as the engineer or technician responsible for its actual installation. If there are any unanswered questions after read ing this manual, call the factory. An applications engineer will be available to assist you.

Navigating this Manual

This manual is designed to be used in both printed and on-line forms. Its on-line form is a PDF document, which requires Adobe Acrobat Reader version 7.0+ to open it. You are allowed add notes and annotations as well as select and copy sections for use in other documents. If you decide to print out this manual, all sections contain an even number of pages which allows you to easily print out a single chapter on a duplex (two-sided ) printer.

Manual Conventions

Three icons are used to highlight important information in the manual:

NOTES highlight important concepts, decisions you must make, or the implications of those

decisions.

ABOUT THIS MANUAL

CAUTIONS tell you when equipment may be damaged if the procedure is not followed

properly.

WARNINGS tell you when people may be hurt or equipment may be damaged if the pro-

cedure is not followed properly.

The following table shows the text formatting conventions:

Format Description

Normal Font Font used throughout this manual.

Emphasis Font Font used the first time a new term is introduced.

Cross Reference

HTML Reference

When viewing the PDF version of the manual, clicking on the cross reference text jumps you to referenced section.

When viewing the PDF version of the manual, clicking on the HTML reference text will open your default web browser to the referenced web page.

Trademarks and Other Legal Stuff

The AMCI logo is a trademark, and “DuraCoder” is a registered trademark of Advanced Micro Controls Inc. “Adobe” and “acrobat” are registered trademarks of Adobe Systems Incorporated.

All other trademarks contained herein are the property of their respective holders.

Revision Record

This manual, 940-0D043 is the fourth release of the manual. It adds information on the new diagnostic capabilities and the alterations to the connector pinout. It was first released October 31th, 2018.

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

ABOUT THIS MANUAL

Where to Go From Here

The table below gives a brief description of the content of each chapter to help you find the information you need to assist you in your job.

CHP

NUM.

Reference

Task 1 Installation

Task 2 Diagnostics

Chapter Title Chapter Description

The Absolute Digital

DuraCoder

Intended for anyone new to the Absolute Digital DuraCoder, this chapter gives a basic overview of the unit. The chapter also explains the Absolute Digital DuraCoder part numbering system.

This chapter is intended for the engineer or technician responsible for installing and wiring the Absolute Digital DuraCoder. Information in this chapter includes mechanical drawings, installation guidelines and connector pinout.

This chapter explains the diagnostics available on the latest revision of the absolute digital DuraCoders. A status LED has been added on the rear cover of the revised DuraCoders.

ADVANCED MICRO CONTROLS INC.

REFERENCE 1

Figure R1.1 An Absolute Digital DuraCoder

THE ABSOLUTE DIGITAL DURACODER

Absolute Digital DuraCoder Overview

DuraCoders are designed as direct replacements for optical encoders. Instead of being designed around a disk and optics, a DuraCoder uses a resolver as its primary shaft position sensor. Constructed in a manner similar to high precision motors, resolvers are absolute, single turn position sensors that are unsurpassed in terms of ruggedness and reliability. The resolver is an analog device whose outputs vary sinusodially as the shaft is rotated. If you are interested in learning more about resolvers, read the article on our website at: https://www.amci.com/indus-

trial-automation-resources/plc-automation-tutorials/whatresolver/.

The resolver’s analog signals are decoded into a 12 bit position value by electronics incorporated into the DuraCoder. This 12 bit (4096 count), absolute position value is available as a paral lel digital output. Several different output codes and voltage level outputs are available.

In addition to the actual position outputs, the Absolute Digital DuraCoders also offer two inputs that control the outputs. The Latch Input is used to control when the position values update and the Direction Input controls the direction of rotation needed to produce increasing counts.

The Absolute Digital DuraCoder is available in a variety of industry standard size 25 optical encoder packages. A flange mount unit with a 3/8" shaft and a side connector is shown in figure R1.1. Servo mount and end connect units are also available. If your application requires you to mount the DuraCoder to a motor, a blind shaft mounting option is available as well. Finally, a face mount unit with a 5/8 inch shaft is available for applications that may be exposed to high shaft loads.

Outline drawings of all of the packing options is available in the Outline Drawings section of the Installation chapter, starting on page 11.

Absolute Digital DuraCoder Diagnostics

Starting in August of 2018, Absolute Digital DuraCoders include additional diagnostic features.

 Fault Output - This output is active during normal operation and goes inactive when one or more of the

following conditions exists:

1) Over temperature of the output drivers

2) Output shorted to ground

3) Output shorted to Vdc

4) Open connection or wire.

 Test Input - Used to test the outputs of the unit. This single input can be used to force all of the outputs

into their active or inactive states. A full explanation of the uses of this pin can be found in Task 2,

Diagnostics starting on page 21.

 Status LED - Located on the back of the unit, this LED shows the status of the unit under normal oper-

ating conditions, and the status of the outputs when used with the Test Pin.



20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

THE ABSOLUTE DIGITAL DURACODER

HOUSING

F = Square Flange S = 2.5" Dia. Servo Mount H = 63mm Blind Shaft Mount

BEARING SEAL

B = Nitrile (standard) V = Viton

SHAFT DIA.

Standard Shaft

Blind Shaft Hole

1 = 0.375" Dia. 2 = 10mm Dia. 3 = 0.250" Dia. 5 = 0.625" Dia.

1 = 0.375" Dia 2 = 10mm Dia. 4 = 0.500" Dia 6 = 12mm Dia.

Flange Mount Only

Housing = 'F'

OUTPUT CONFIG.

High True Outputs

B = Current Sink, 24Vdc m a x.

F = Current Source, 24Vdc max. G = Current Sink, 24Vdc max. H = Current Sink with 10 K pullup



Low True Outputs

E = End

DURACODER TYPE

A = Absolute Parallel, Level Update B = Absolute Parallel, Edge Update

1 = 1,024 Count, Gray Code 2 = 1,024 Count, Binary 3 = 4,096 Count, Gray Code 4 = 4,096 Count, Binary 5 = 360 Count, BCD 6 = 1,000 Count, BCD

B0002 to B4 09 6 Factory Se t , Binary D0002 to D1000 Factory Se t , BCD G0002 to G4096 Factory Set, Gray Code

Figure R1.3 Level Sensitive Update

DATA

LATCH

CONTROL

325 µS

Part Numbering System

DC25

Description of Outputs

Output Codecs

The Absolute Digital DuraCoder can output its data in 12 bit Natural Binary , 12 bit Gray Code, or 12 bit BCD formats. In Natural Binary and Gray Code formats, the maximum output value is 4,095. For BCD format, the maximum output value is 999.

–

OUTPUT CODING

Figure R1.2 Part Numbering System

CONNECTOR

S = Side

A = Curr ent Sour ce, 24V dc max.

C = Current Si n k with 10 K pullup

to DuraCoder Input Voltage.

Output Update Control

Position data updates are controlled by a single pin named Latch Control and the type of control is set when the DuraCoder is ordered. Two types of position update control are available.

In new installations, the sole advantage of Gray Code over Natural Binary is that only one bit changes per count. This allows you to easily check the validity of the position data. This one bit change holds true only if your number of counts per turn is a power of two. (2, 4, 8, ... 4,096) If your number of counts per turn is not set to a power of two, the transition between your maximum count and zero will result in two or more bits changing in the data.

 Level Sensitive (Part # starts: DC25?-??A) – The

position data updates every 325 microseconds while the Latch Control pin is at a Logic 1 voltage or the pin is left open. The position data will freeze within 25 microseconds of this pin being driven to a Logic 0 voltage. The position data will begin to update within 325 microseconds once it is released from the Logic 0 voltage level. If the Latch Control pin is at a Logic 0 on power up, all outputs will be in their zero state until the first positive transition. Position data will not be valid until this transition.

25 µS

BITS

ADVANCED MICRO CONTROLS INC.

Description of Outputs (continued)

Figure R1.4 Edge Sensitive Update

DATA

LATCH

CONTROL

325 µS 325 µS

Status LED

Figure R1.5 Status LED Location

Output Update Control (continued)

 Edge Sensitive (Part # starts: DC25?-??B) –

Logic 0  1 or 1  0 transition on the Latch Control input will update the outputs within 325 microsec onds. The output will then freeze until another valid transition. Transitions must be a minimum of 325 microseconds apart. (1.5 kHz at a 50% duty cycle maximum.) On power up, all of the outputs will be in their zero state until the first valid transition occurs. Position data will not be valid until this transition.

Output Electrical Configurations

Three different electrical configurations are available for the outputs.

 Open Collector Sourcing  Open Collector Sinking  Open Collector Sinking with a 10K resistor to +Vin

Full characteristics for the output are available in the Electrical Specifications section on the following page. Outputs can be ordered as a High True Output or a Low True Output. The table below shows the states.

THE ABSOLUTE DIGITAL DURACODER

BITS

Open Collector Source Output Conducts to VIN High-Impedance High-Impedance Conducts to VIN

Open Collector Sink Output High-Impedance Conducts to GND Conducts to GND High-Impedance

Sink Output w/ 10 K Pullup

Status LED

As shown in figure R1.5, the Status LED is located on the back of the unit.

Normal Operation (Test Pin open)

 Steady Green - The encoder is operating normally without a fault.  Steady Red - One or more of the following fault conditions exists:

1) Over temperature of the output drivers

2) Output shorted to ground

3) Output shorted to Vdc

4) Open connection or wire.

Test Mode (Test Pin grounded)

 OFF - The output are acting normally.

High True Low True

Logic 1 Logic 0 Logic 1 Logic 0

High-Impedance

Pulled to VIN

through 10 K

Figure R0.1 Output States

Conducts to GND Conducts to GND

High-Impedance

through 10 K

Pulled to VIN

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

 ON - A fault condition exists on one or more of the outputs. See Task

Diagnostics starting on page 21 for information on diagnosing the

2, error condition.

THE ABSOLUTE DIGITAL DURACODER

Electrical Specifications

Operating Voltage

10.8 Vdc to 26.4Vdc (12 to 24 Vdc nominal)

Power Requirements

1.2 W max. (50mA @ 24Vdc)  All outputs in their inactive state.

Position Resolution

2 to 4,096 counts with Gray Code or Natural Binary out-

put format.

2 to 1,000 counts with BCD output format

Position Update Control

Latch Control pin on connector that is factory set to

either Level control or Edge control.

With Level control, the outputs update continuously

while pin is at a logic 1 or open circuit. Outputs freeze when input tied to DC Return.

With Edge control, outputs update within 325 microsec-

onds of a transition from logic 0 to logic 1 or logic 1 to logic 0. Transitions must occur at a minimum of 325 microseconds apart. (1.5KHz at 50% duty cycle)

Logic Level Input Voltages

Logic 0: 0 Vdc to 0.8 Vdc. Logic 1: 2 Vdc to Operating Voltage.

Inputs have pull up resistors, so  leaving them disconnected will act  as a logic “1”

Position Update Time

325 microseconds when using Level update control and

the Latch Control pin has been at a logic 1 or open circuit for a minimum of 325 microseconds

Max. Output Settling Time

325 microseconds. Occurs on either transition when

using Edge control or when Latch Control pin changes from Logic 0 to Logic 1 state when using Level control.

Direction of Increasing Counts

Default CCW looking at shaft Can be set to CW increasing by shorting pin R to DC

Return.

Output Types

Open Collector Sourcing, Open Collector Sinking, and

Sinking with 10 K

On State Current

500 mA per output without damage.

On State Resistance

0.75  max. (0.03 Vdc drop across driver at 40 mA)

Leakage Current

5 microamps maximum

 pull-up resistor.

Environmental Specifications

Operating Temperature

-40°F to +185°F (-40°C to +85°C)

Shock

50g, 11 millisecond duration

Vibration

20g, 5 to 2000Hz

Enclosure Rating

IP67

Approximate Weight

2.0 lbs. (0.91 Kg) 0.625" shafts

1.4 lbs. (0.65 Kg) All other shafts

Mechanical Specifications

Package Style

2.5 inch aluminum housing with flange, servo, or blind shaft mounting

Connector Location

Side or End

Housing

Powder coated aluminum

Shaft

0.250", 0.375", 0.625", or 10mm

Blind Shaft with 0.375", 0.500", 10mm or 12 mm hole

Max. Starting Torque @ 25°C

2.0 oz-in: 0.250", 0.375", and 10mm shafts

6.0 oz-in: All blind shafts

6.0 oz-in: 0.625" shaft

Moment of Inertia (oz-in-sec2)

6.00 X 10-4: 0.250", 0.375", and 10mm shafts

7.00 X 10-4: All blind shafts

8.50 X 10-4: 0.625" shaft

Max. Operating Speed

6000 RPM

Max. Shaft Loading (0.625" shaft)

Axial: 50 lbs. (222 N) Radial: 100 lbs. (445 N) As specified max. loads, bearing life is 2X109 revolu-

tions min.

Max. Shaft Loading (All other shafts)

Axial: 20 lbs. (89 N) Radial: 40 lbs. (178 N) As specified max. loads, bearing life is 2X109 

revolutions minimum.

ADVANCED MICRO CONTROLS INC.

INSTALLATION

DC25

Absolute Digital

Output Flange Mount End Connector

(67.3)

(6.35)

(26.21)

( ) = Dimensions in mill imeter s

(31.75)

MS3112E-14-19P

DC25

Output Flange Mount Side Connector

(67.3)

(26.21)

max.

(35.6)

dia.

Connector

Flange Mount Outline Drawings

End Connector

TASK 1

Side Connector

( ) = Dimensions in millimeters

Figure T1.1 Flange Mount, End Connect Outline Drawing

(31.75)

(22.86)

(26.21)

Connector

MS3112E-14-19P

Absolute Digital

(6.35)

2.50"

(63.5)

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

Figure T1.2 Flange Mount, Side Connect Outline Drawing

INSTALLATION

Figure T1.3 Flange Mount Alternate Shafts

0.2497"

0.2492"

(6.330)

(6.342)

1/4" Shaft

(Shaft Option 3)

10mm Shaft

(Shaft Option 2)

0.900"

0.850"

(21.59)

0.3934"

0.3931"

(9.985)

(9.993)

(22.86)

0.900"

0.850"

(21.59)

(22.86)

() = Dimensions in mm

Flange Mount Outline Drawings (continued)

Alternate Shafts

Shaft Loading

Limit shaft loading to the following values. These values statistically yield an L10 life of 2X109 revolutions. (L10 life is a rating which means that statistically, only 10% of the bearings will have failed after 2X10 olutions.) Shaft loading has an exponential effect on bearing life. The bearings will statistically last longer if you can limit shaft loading below the given values. Consider using the 5/8" shaft DuraCoder from AMCI if your shaft loading is expected to be greater than the values given below. Outline drawings for the 5/8" shaft DuraCoders start on page

17.

rev-

Radial Load Axial Load

40 lbs. (178 N) 20 lbs. (88 N)

Table T1.1 Flange Mount Shaft Loading

ADVANCED MICRO CONTROLS INC.

Servo Mount Outline Drawings

DC25

Absolute Digital Output Servo Mount End Connector

#8-32 UNC- 2B. 0.18" min depth. Six places, 60° apart on a 1.875" B.C.

(4.6)

(47.63)

(58.64)

(22.86)

(31.75)

Connector

(35.6)

dia.

Connector

Output Servo Mount Side Connector

(7.62)

(58.6)

#8-32 UNC-2B.

0.18" min. depth. Six places, 60° apart on 1.875" B.C.

(4.6)

(47.62)

(22.86)

(7.62)

(31.75)

End Connector

( ) = Dimensions in millimeters

INSTALLATION

MS3112E-14-19P

Side Connector

( ) = Dimensions in millimeters

Figure T1.4 Servo Mount, End Connect Outline Drawing

MS3112E-14-19P

DC25

Absolute Digital

2.50"

(63.5)

Figure T1.5 Servo Mount, Side Connect Outline Drawing

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

INSTALLATION

Figure T1.6 Servo Mount Alternate Shafts

0.2497"

0.2492"

(6.330)

(6.342)

1/4" Shaft

(Shaft Option 3)

10mm Shaft

(Shaft Option 2)

0.900"

0.850"

(21.59)

0.3934"

0.3931"

(9.985)

(9.993)

(22.86)

0.900"

0.850"

(21.59)

(22.86)

() = Dimensions in mm

Servo Mount Outline Drawings (continued)

Alternate Shafts

Shaft Loading

17.

rev-

Radial Load Axial Load

40 lbs. (178 N) 20 lbs. (88 N)

Table T1.2 Servo Mount Shaft Loading

ADVANCED MICRO CONTROLS INC.

Blind Shaft Mount Outline Drawings

(28.58)

2.72" (69.0)

0.067" radius on 2.48" B.C.

(1.70)

(63.0)

(17.0)

(20.0)

SEE

CHART

Customer Side

2.48" B.C.

(63.0)

(16.5)

1.10" depth

(27.9)

(63.5)

VIEW A

3 places,

120° apart

Shaft Leng th

0.59" min.

1.10" max.

(15)

(27.9)

SEE

CHART

VIEW A

Output

End Connector

(114)

Shaft Seal

Connector

End Connector

( ) = Dimens ions in mi llimeters

2.50" Dia.

INSTALLATION

0.55" max.

(14.0)

Total clearance of 4.5" needed for removal of matin

DC25

Absolute Digital

Blind Shaft Mount

4.09" (103.9)

0.65" Clearance

connector.

MS3112E-14-19P

Figure T1.7 Blind Shaft Mount, End Connect Outline Drawing

4-40 Thru Tap

0.75"

(19.0)

0.14"

(3.6)

Nominal Hole

Diameters Available

English Metric

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

INSTALLATION

(28.58)

2.72" (69.0)

0.067" radius on 2.48" B.C.

(1.70)

(63.0)

(17.0)

(20.0)

SEE

CHART

Customer Side

2.48" B.C.

(63.0)

(16.5)

1.10" depth

(27.9)

2.50" Dia.

(63.5)

3 places,

120° apart

Shaft Length

0.59" min.

1.10" max.

(15)

(27.9)

SEE

CHART

VIEW A

Output

End Connector

Shaft Seal

(35.6)

Connector

max.

1.05" max. Total clearance of 5.1" needed for removal of mating connector.

(26.7)

(130)

2.30"

(58.4)

Blind Shaft Mount Outline Drawings (continued)

Side Connector

( ) = Dimensions in millimeters

1.40" sq.

MS3112E-14-19P

DC25

Absolute Digital

Blind Shaft Mount

4.09" (103.9)

Available Shaft Diameters

The diameter of the drive shaft must be specified when ordering a blind shaft DuraCoder. Available options are given in the table below. Other diameter options may have become available after the release of this man ual. Please check our website, www.amci.com, if you do not see the shaft diameter that fits your application.

Figure T1.8 Blind Shaft Mount, Side Connect Outline Drawing

VIEW A

0.75"

(19.0)

4-40 Thru Tap

Nominal Hole Diameters

English Metric

0.375" 10 mm

0.500" 12 mm

0.14"

0.65" Clearance

Nominal Hole

Diameters Available

English Metric

(3.6)

Table T1.3 Available Blind Shaft Diameters

Shaft Loading

The load that the Analog DuraCoder presents to your input shaft, which is equal to the load presented to the DuraCoder by your input shaft, is difficult to calculate and is dependent on the accuracy of the mounting. The flexible metal mounting bracket will be able to absorb most of the radial loading forces, but accurate mount ing of the DuraCoder is still important.

ADVANCED MICRO CONTROLS INC.

5/8" Shaft Outline Drawings

INCLUDED KEY

KEYWAY

0.1895"

0.1885"

(4.788)

0.108"

0.106"

(2.69)

)

depth. Six Places. for removal of mating connector.

Deep

See Keyway

Specifications

0.750"

(19.05)

1.500"

(38.10)

0.470"

(11.95)

See Note 1

1.032"

(26.21)

0.94"

(23.9)

(36.8)

(3.18)

1.500"

1.499"

(38.07)

(38.10)

diameter

See Note 2

0.6247"

0.6237"

(15.842)

(15.867)

0.188"

0.187"

(4.75)

See Note 3

(14.0)

DC25

Absolute Digital Output 5/8" Shaft Flange Mount End Connector

( ) = Dimensions in millimeters

dia.

typ.

1.00"

(25.4)

1.032"

(26.21)

End Connector

INSTALLATION

0.125"

MS3112E-14-19P Connector

2.50"

(63.5)

0.55" max.

NOTES:

1) Integral Shaft Seal. 2

1/4-20 UNC-2B 0.50" (12.7) minimum

3) Total clearance of 4.5" (114) needed

Figure T1.9 5/8" Shaft, Face Mount, End Connect Outline Drawing

KEYWAY SPECIFICATIONS

Sq.

1.00"

(25.4)

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

INSTALLATION

max.

1.37" max. See Note 3

(34.8)

NOTES:

1) Integral Shaft Seal. depth. Six Places. for removal of mating connector.

(12.7)

(127)

See Keyway

Specifications

0.750"

(19.05)

1.500"

(38.10)

(11.95)

1.032"

(26.21)

0.94"

(3.18)

1.500"

1.499"

(38.07)

(38.10)

0.6247"

0.6237"

(15.842)

(15.867)

Output 5/8" Shaft Flange Mount Side Connector

MS3112E-14-19P

Connector

typ.

1.032" typ.

(26.21)

See Note 2

(35.6)

INCLUDED KEY

KEYWAY

0.1895"

0.1885"

(4.788)

0.108"

0.106"

(2.69)

(4.75)

dia.

5/8" Shaft Outline Drawings (continued)

Side Connector

1.40" sq.

See Note 1

0.470"

(23.9)

0.125"

DC25

Absolute Digital

(36.8)

diameter

( ) = Dimensions in millimeters

2) 1/4-20 UNC-2B 0.50" minimum

3) Total clearance of 5.0" needed

2.50"

(63.5)

KEYWAY SPECIFICATIONS

Figure T1.10 Flange Mount, Side Connect Outline Drawing

1.00"

(25.4)

ADVANCED MICRO CONTROLS INC.

0.188"

0.187"

Sq.

1.00"

Deep

(25.4)

5/8" Shaft Outline Drawings (continued)

V R DU

Figure T1.11 Connector Pinout

Function

Gray

Code

Natural

Binary

BCD

(8421)

AG(0) 2

B G(1) 2

CG(2) 2

D G(3) 2

EG(4) 2

F G(5) 2

GG(6) 2

H G(7) 2

JG(8) 2

100

K G(9) 2

200

L G(10) 2

400

M G(11) 2

800 N Error Output P Test Input R Direction Control Input S Case GND T DC Return U Latch Control Input V +DC Input

Shaft Loading

Radial Load Axial Load

100 lbs. (445 N) 50 lbs. (222 N)

Table T1.4 Flange Mount Shaft Loading

Connector Pinout

Figure T1.11 shows the pin designations on the MS3112E-14-19P connector. AMCI sells a straight mating connector under the AMCI part number: MS-19.

AMCI does not supply factory made cables for the Absolute Digital DuraCoder because of the many possible configurations.

Pins A-M: Position Output – These pins output the absolute position value.

Pin A is the least significant bit.

INSTALLATION

rev-

Pin N: Error Output – The output state of this pin is active dur-

ing normal operation. It switches to its inactive state when there is a fault condition. The four detectable fault conditions are:

 Output driver over -temp erature  Output shorted to ground  Output shorted to Vdc  Open wire or connections

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

These faults are latched. Once they occur, the DuraCoder will report the error until it is cleared. There are two methods to clear the error.

1)Cycle power to the DuraCoder

2)Pull the Test input low for a minimum of 10 milliseconds and release it.

If the fault condition no longer exists, the Error output will return to its active and the Status LED on the back of the unit will change from red to green.

See table T2.2, Output Voltage States, found on page 21 for the output voltage levels when the output is active or inactive.

Pin P: Test Input – This pin is used to test the outputs of the

DuraCoder and clear fault conditions. This pin should be left open for normal operation. Connecting this pin to GND will place the DuraCoder in test mode. The use of this pin is fully described in Task

Prior to the August 2018 release of the Absolute Digital DuraCoder, the “N” and “P” pins were “No Connection” pins.

2, Diagnostics, starting on page 21.

INSTALLATION

Connector Pinout

Pin R: Direction Control – This pin controls which direction the shaft must rotate to increment the position

data. With this pin open circuit, position data increases with CCW rotation, looking at the shaft. Connecting this pin to Pin T, (DC Return), forces the position to increase with CW rotation, looking at the shaft.

If you want CW increasing counts, you must connect pins R and T at the connector or at the end of a short extension cable. Do not run a long cable pair from these pins and connect these pins at the other end of the cable. This may allow noise to be injected into the Direction Con trol pin that will affect the position count.

Pin S: Case GND – This pin should be used to tie the body of the DuraCoder to chassis ground at the



DuraCoder if the unit is not grounded through its mounting. This pin is not to be used as the power supply return. The power supply must be wired to pins T (DC Return) and V (+DC Input).

Pin T : DC Return – This pin must be connected the power supply return. The power supply must be wired to

pins T (DC Return) and V (+DC Input). This pin cannot be used to tie the body of the DuraCoder to chassis ground.

Pin U: Latch Control – The Latch Control input is fully described in the section Output Update Control,

found on page 8. Briefly here, there are two types of position data update control:



Level Sensitive:

The outputs update every 325 microseconds when the pin is open circuit or at a logic 1 voltage level. The outputs will freeze within 25 microseconds when a logic 0 voltage is applied. Wh en the input transitions between a logic 0 and a logic 1, the outputs will take approximately 325 microseconds before they begin to update.



Edge Sensitive:

The outputs update within 325 microseconds of a 01 or 10 transition on the input. The outputs then freeze until another valid transition. T r ansitions must be at least 325 micro seconds apart, which yields a maximum frequency of 1.5KHz with a 50% duty cycle. All of the outputs will be at a logic 0 state on power up until the first valid transition occurs.

Pin V: +DC Input – This pin must be connected to the high side of the power supply. The power supply must

be wired to pins T (DC Return) and V (+DC Input).

ADVANCED MICRO CONTROLS INC.

This chapter is specifically for the latest revision of the Absolute Digital DuraCoders that contain additional diagnostic features. These instructions only apply to units with a status LED on the rear cover.

Output States

The Absolute Digital DuraCoder offers both sinking and sourcing outputs. Therefore, these diagnostic instructions list the outputs as being in their active state or inactive state. (Conducting current, or not conduct ing current.) T able T2.1 below shows the expected output voltages when an output is in its two states. Refer to

Part Numbering System, found on page 8 if you need to determine the type of outputs your DuraCoder has.

TASK 2

DIAGNOSTICS

High True Outputs

(Output Config A,B,C)

Logic 1

DC)

Logic 0

(GND)

Low True Outputs

(Output Config F, G, H)

Logic 1

(GND)

Logic 0

(VDC)

Open Collector Source (A or F) Active Inactive Inactive Active

Open Collector Sink Output (B or G) Inactive Active Active Inactive

Sink Output w/ 10 K Pullup (C or H) Inactive Active Active Inactive

Table T2.1 Output Logic States

Active Inactive

Open Collector Source

(Output Type A or F)

Open Collector Sink Output

(Output Type B or G)

Conducting. Output voltage equals

the input voltage to the DuraCoder.

Conducting. Output is at ground

potential. (0 Vdc)

Not Conducting. Output typically

pulled to Ground through an

external resistor.

Not Conducting. Output typically

pulled to an external voltage

through an external resistor.

Not Conducting. Output pulled to

Sink Output w/ 10 K Pullup

(Output Type C or H)

Conducting. Output is at ground

potential. (0 Vdc)

the DuraCoder’s power supply

voltage through the internal

10 Kresistor.

Table T2.2 Output Voltage States

Over Voltage and Under Voltage Detection

The output driver IC on the DuraCoder has the ability to detect over voltage and under voltage conditions on the power supply and turn off the drivers if either condition occurs. This leaves the outputs in a known state instead of an uncertain state based on the power supply levels. However, this is a feature of the driver IC itself, and does not indicate to the DuraCoder that it is in this state.

Therefore, if the outputs are in their inactive state but the DuraCoder does not give any fault indication, check the power supply voltage and verify that it is within its acceptable range of

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

10.8 Vdc to 26.4Vdc.

DIAGNOSTICS

Module Common

(V) +Vdc

(Pin Number)

(T) DC Return

12 to

24 Vdc

12 to

24 Vdc

DuraCoder

(N) Error Out

Error Output

The Error output is the same driver type as the position outputs, with an internal pull-up or pull-down resistor. Therefore, the “high” voltage is equal to the voltage that powers the DuraCoder.

The output can sink or source a maximum of 500 milliamperes. It is designed to drive a typical PLC DC input. Figure

T2.1 below shows how to wire the output to a typical DC inpu

(V) +Vdc

Input

Module Common

For sinking output units, the output is low during normal operation. For sourci ng output units, the output is high for normal operations. The output switches to its inactive state when one of the following conditions occurs:

 Over temperature fault on the output driver IC.  One or more outputs shorted to ground.  One or more outputs shorted to the input voltage of the DuraCoder.  One or more outputs with an open connection or broken wire.

These faults are latched. Once they occur , the DuraCoder will report the error until it is cleared. There are two methods to clear the error.

1) Cycle power to the DuraCoder

2) Pull the Test input (Pin P) low for a minimum of 10 milliseconds and release it.

If the fault condition no longer exists, the Error output will return to its active state and the Status LED on the back of the unit will change from red to green.

Test Inp ut

The Test input is a DC input with an internal pull-up resistor to the supply voltage of the DuraCoder. When the Test input is pulled low for a minimum of 325 microseconds, the DuraCoder is placed in test mode. The unit remains in test mode while the Test input is low. Once the Test input is released, the DuraCoder will return to its normal mode of operation within 325 microseconds.

Input

Figure T2.1 Error Output Wiring

Normal Operation (Test Pin Open)

During normal operation, the Status LED is in one of three states:

Status LED State Description

OFF

Green

Red

No power to the DuraCoder.

Operating normally

A fault condition exists. See the

errors.

If there are no faults, the state of the outputs is determined by the DuraCoder shaft position. If there is an overtemperature fault, all of the outputs are forced into their inactive state. For all other fault conditions, the state of the unaffected outputs is determined by the DuraCoder shaft position.

Error Output

Table T2.3 Output Voltage States

ADVANCED MICRO CONTROLS INC.

section above for a list of detectable

Test Input (continued)

Test Mode (Test Pin Tied to GND)

In T est mode, all of the outputs are forced into their active or inactive states. This is accomplished by pulling the Test input low for a minimum of 325 milliseconds. The DuraCoder remembers the last state the outputs were forced into. Once the T est input is released for a minimum of 325 milliseconds and pulled low again, the outputs will switch to their other test state. When the Test input is released for a minimum of 325 millisec onds, the unit exits Test Mode, and the outputs begin to output position data again.

Testing Sourcing Output DuraCoders

A pull down resistor or equivalent load is required when testing sourcing outputs. If this load is not present, a voltmeter may read that the output is active when it is in its inactive, high impedance, state due to leakage current through the output.

High True Output Units

High True output units have the output at 0 Vdc for a logic “0” and +Vdc for a logic “1”.

 If the Test Pin in pulled low when power is applied to the unit, all outputs are set to 0 Vdc. The drivers

are not conducting and this is considered a logic “0”.

1) If the Test Pin is high or open during power up, the first time it is pulled low for greater than 325 milliseconds, all outputs are set to the +Vdc voltage. The drivers are conducting and this is considered a logic “1”. If the output voltage is at 0 Vdc, you have a short to ground or a wiring error.

2) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

3) Pulling the Test Input low for greater than 325 milliseconds will place the unit back into test mode. All of the outputs are now set to 0 Vdc. The drivers are not conducting and this is considered a logic “0”. If the output voltage is at +Vdc, you have a short to +Vdc or a wiring error.

4) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

Repeating steps 1 through 4 will force the outputs to alternate between their logic “1” and “0” states.

DIAGNOSTICS

Low True Output Units

Low True output units have the output at 0 Vdc for a logic “1” and +Vdc for a logic “0”.

 If the Test Pin in pulled low when power is applied to the unit, all outputs are set to the +Vdc voltage.

The drivers are conducting and this is considered a logic “0”.

1) If the Test Pin is high or open during power up, the first time it is pulled low for greater than 325 milliseconds, all outputs are set to 0 Vdc. The drivers are not conducting and this is considered a logic “1”. If the output voltage is at +Vdc, you have a short to +Vdc or a wiring error.

2) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

3) Pulling the Test Input low for greater than 325 milliseconds will place the unit back into test mode. All of the outputs are now set to the +Vdc voltage. The drivers are conducting and this is considered a logic “0”. If the output voltage is at 0 Vdc, you have a short to ground or a wiring error.

4) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

Repeating steps 1 through 4 will force the outputs to alternate between their logic “1” and “0” states.

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

DIAGNOSTICS

Testing Sinking Output DuraCoders

If the unit does not have internal pull up resistors, external pull up resistors or equivalent loads are required when testing sinking outputs. If this load is not present, a voltmeter may read that the output is active when it is in its inactive, high impedance, state due to leakage current through the output.

When the unit has internal pull up resistors, the voltage on the outputs will be equal to +Vdc. When external pull up resistors are used, the pull up voltage on those resistors does not have to be the same as +Vdc. For example, the DuraCoder can be powered by 24 Vdc, while the pull up resistors have 12 Vdc, or 5 Vdc, as their supply voltage. For simplicity in the explanations that follow, “+Vdc” will be used to describe the voltage on the pull up resistors.

High True Output Units

High True output units have the output at 0 Vdc for a logic “0” and +Vdc for a logic “1”.

 If the Test Pin in pulled low when power is applied to the unit, all outputs are set to 0 Vdc. The drivers

are conducting and this is considered a logic “0”.

1) If the Test Pin is high or open during power up, the first time it is pulled low for greater than 325 milliseconds, all outputs are set to the +Vdc voltage. The drivers are not conducting and this is considered a logic “1”. If the output voltage is at 0 Vdc, you have a short to ground or a wiring error.

2) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

3) Pulling the Test Input low for greater than 325 milliseconds will place the unit back into test mode. All of the outputs are now set to 0 Vdc. The drivers are conducting and this is considered a logic “0”. If the output voltage is at +Vdc, you have a short to +Vdc or a wiring error.

4) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

Repeating steps 1 through 4 will force the outputs to alternate between their logic “1” and “0” states.

Low True Output Units

Low True output units have the output at 0 Vdc for a logic “1” and +Vdc for a logic “0”.

 If the Test Pin in pulled low when power is applied to the unit, all outputs are set to the +Vdc voltage.

The drivers are not conducting and this is considered a logic “0”.

1) If the Test Pin is high or open during power up, the first time it is pulled low for greater than 325 milliseconds, all outputs are set to 0 Vdc. The drivers are conducting and this is considered a logic “1”. If the output voltage is at +Vdc, you have a short to +Vdc or a wiring error.

2) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

3) Pulling the Test Input low for greater than 325 milliseconds will place the unit back into test mode. All of the outputs are now set to the +Vdc voltage. The drivers are not conducting and this is considered a logic “0”. If the output voltage is at 0 Vdc, you have a short to ground or a wiring error.

4) Releasing the Test Input for more than 325 milliseconds will take the unit out of test mode and back to normal operation.

Repeating steps 1 through 4 will force the outputs to alternate between their logic “1” and “0” states.

ADVANCED MICRO CONTROLS INC.

Notes

DIAGNOSTICS

20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786 Tel: (860) 585-1254 Fax: (860) 584-1973 http://www.amci.com

LEADERS IN ADVANCED CONTROL PRODUCTS

ADV ANC ED MIC RO CONTROLS INC.

20 GEAR DRIVE, TERRYVILLE, CT 06786 T: (860) 585-1254 F: (860) 584-1973

www.amci.com

AMCI DC25 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

GENERAL INFORMATION

Important User Information

Standard Warranty

Returns Policy

24 Hour Technical Support Number

Waste Electrical and Electronic Equipment (WEEE)

TABLE OF CONTENTS

Audience

Navigating this Manual

Manual Conventions

ABOUT THIS MANUAL

Trademarks and Other Legal Stuff

Revision Record

Where to Go From Here

THE ABSOLUTE DIGITAL DURACODER

Absolute Digital DuraCoder Overview

Absolute Digital DuraCoder Diagnostics

Part Numbering System

Description of Outputs

Output Codecs

Output Update Control

Status LED

Output Electrical Configurations

Normal Operation (Test Pin open)

Test Mode (Test Pin grounded)

Electrical Specifications

Environmental Specifications

Mechanical Specifications

INSTALLATION

Flange Mount Outline Drawings

End Connector

Side Connector

Alternate Shafts

Shaft Loading

Servo Mount Outline Drawings

End Connector

Side Connector

Alternate Shafts

Shaft Loading

Blind Shaft Mount Outline Drawings

End Connector

Side Connector

Available Shaft Diameters

Shaft Loading

5/8" Shaft Outline Drawings

End Connector

Side Connector

Shaft Loading

Connector Pinout

Output States

DIAGNOSTICS

Over Voltage and Under Voltage Detection

Error Output

Test Inp ut

Normal Operation (Test Pin Open)

Test Mode (Test Pin Tied to GND)

Testing Sourcing Output DuraCoders

High True Output Units

Low True Output Units

Testing Sinking Output DuraCoders

High True Output Units

Low True Output Units
