Portable
Air Conditioners
Experience portable comfort wherever you are with
the Amana 10,000 BTU portable air conditioner.
Designed for cooling and dehumidifying a room up
to 300 square feet, this Amana unit with features
on-board electronic controls with 3 speeds and a
24-hour timer, plus a handy remote control with
LCD display. With easy-rolling caster wheels you
can conveniently move the unit from room to room,
providing cool air when and where you need it most.
MODEL
PERFORMANCE
BTUs (Cooling) 10,000 10,000 10,000
Control Type Easy Touch Easy Touch Easy Touch
EER 8.87 8.87 8.87
Color White/Black Gold/Black Silver/Grey
Cooling Range (Sq. Ft.) 300-450 300-450 300-450
Dehumidification (Pts. /Hr.) 4.97 4.97 4.97
Air Flow (CFM): High / Med / Low 230 / 212 / 188 230 / 212 / 188 230 / 212 / 188
Noise Level (dBA): High / Med / Low 56 / 55 / 54 56 / 55 / 54 56 / 55 / 54
Refrigerant Type R410A R410A R410A
ELECTRICAL RATINGS
Voltage (V) / Frequency (Hz) 115 V / 60 Hz 115 V / 60 Hz 115 V / 60 Hz
Cooling Amps 10.1 10.1 1 0.1
Cooling Watts 1160 W 1160 W 1160 W
FEATURES
Control Type Digital Digital Digital
Auto Cool Yes Yes Ye s
Remote Control Ye s Yes Yes
Adjustable Thermostat Yes Yes Ye s
Programmable Timer (Hrs.) Yes Yes Ye s
Number of Cooling Speeds 3 3 3
Fan Only Option Ye s Ye s Yes
Air Direction Multi Multi Multi
Auto Swing Louvers Yes Yes Ye s
Sleep Mode Yes Yes Ye s
Reusable Filter Yes Yes Ye s
Room Temperature Display Yes Yes Ye s
DIMENSIONS / WEIGHT
Product Dimensions (in.) 14.2 x 16.9 x 28.7 14.2 x 16.9 x 28.7 14.2 x 16.9 x 28.7
Product Weight (lb.) 54.01 54.01 54.01
Shipping Dimensions (in.) 15.9 x 19.1 x 34.8 15.9 x 19.1 x 34.8 15.9 x 19.1 x 34.8
Shipping Weight (lb.) 65.04 65.04 65.04
UPC Code
AMAP101AB-2 AMAP101AD-2 AMAP101AW-2
92487082362 92487062379 92487062386
24-Hour On/O Timer
Programmable 24-hour on/o timer cools
on your schedule
Sleep Mode
Sleep mode gradually increases the room
temperature after being activated
Features:
• Electronic touch controls
• Wireless remote control
• Auto Swing option via remote
• Dehumidification
• Sleep mode
• Temperature display on the unit
• 24-hour on/o timer
• Cooling and Fan Only functions
• Reusable air filter
• Window kit & Exhaust hose
included
WARRANTY: 1-year full system, parts and labor.
