Amana DCF3315AC, DCF3315AW Specification Sheet
Amana Product Information by Fax / Internet |
|
|
® |
||
|
|
|
|
||
800-843-0304 / http://www.amana.com |
|
|
|
|
|
Amana Freestanding Gas Self-Cleaning Range: |
|
Fax Document Number: 4024 / 030703 |
|||
Models |
|
DCF3305B |
|
DCF3315A |
|
|
|
|
|
|
|
General |
|
|
|
|
|
4.0 Cu.Ft. Porcelain Self-Cleaning Oven |
|
Yes |
|
Yes |
|
Electronic Range Control |
|
Yes |
|
Yes |
|
Delay Bake & Delay Self-Clean |
|
Yes |
|
Yes |
|
One Piece Porcelain Backguard |
|
Yes |
|
Yes |
|
Upswept Cooktop Design |
|
Yes |
|
Yes |
|
Die-Cast Sealed Burners |
|
Yes |
|
Yes |
|
Heavy Steel Porcelain Burner Grates (4) |
|
Yes |
|
Yes |
|
Burner Bowls |
|
--- |
|
--- |
|
Bar Broiling System |
|
Yes |
|
Yes |
|
Porcelain Broiler Pan & Grid |
|
Yes |
|
Yes |
|
2 Oven Racks with 5 Positions |
|
Yes |
|
Yes |
|
Removable Counter-Balanced Glass Oven |
|
|
|
|
|
Door w/Window |
|
Yes |
|
Yes |
|
Manual Interior Oven Light |
|
Yes |
|
Yes |
|
Removable Full-Width Storage Drawer, |
|
|
|
|
|
Glides on Rollers |
|
Yes |
|
Yes |
|
Self-Clean Latch |
|
Manual |
|
Auto |
|
Towel Bar Door Handle |
|
Yes |
|
Yes |
|
Programmable Bake Temp. Offset |
|
Yes |
|
Yes |
|
Control Lockout |
|
Yes |
|
Yes |
|
12 Hour Shut-Off with Override |
|
Yes |
|
Yes |
|
Agency Approvals |
|
|
|
|
|
UL Listed |
|
Yes |
|
Yes |
|
AGA & CGA Approved |
|
Yes |
|
Yes |
|
Colors |
|
|
|
|
|
Bisque-on-Black |
|
DCF3305BK |
|
--- |
|
White-on-Black |
|
DCF3305BT |
|
--- |
|
Bisque |
|
--- |
|
DCF3315AC |
|
White |
|
--- |
|
DCF3315AW |
|
Burners (BTU’s - Nat./LP) |
|
|
|
|
|
Right Front |
|
12,000 / 8,500 |
|
12,000 / 8,500 |
|
Left Front, Left Rear, Right Rear |
|
9,200 / 8,000 |
|
9,200 / 8,000 |
|
Oven (BTU’s - Nat./LP) |
|
|
|
|
|
Bake |
|
18,000 / 18,000 |
|
18,000 / 18,000 |
|
Broil |
|
13,000 / 14,000 |
|
13,000 / 14,000 |
|
Electrical |
|
|
|
|
|
Electrical Requirements |
|
120 VAC, 60 Hz, 3-wire, Single Phase, 15 Amps |
|||
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice. Doc. 4024, Page 1 of 3
Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Models |
DCF3305B |
DCF3315A |
|
|
|
|
Warranty applies only when product is |
|
Warranty |
repaired by an authorized Amana servicer. |
|
|
Full 1 year – parts, labor and travel |
|
Entire Appliance |
Limited 5 years on gas surface burners – parts only |
|
Oven Interior Dimensions - Door Closed |
|
|
(in Inches) |
|
|
Height |
16 1/2 |
16 1/2 |
Width |
23 |
23 |
Depth |
18 1/8 |
18 1/8 |
Exterior Dimensions (in Inches) |
|
|
Height Overall |
46 3/4 |
46 3/4 |
Height of Cooktop |
36 |
36 |
Width |
29 7/8 |
29 7/8 |
Depth Oven Door Closed w/Handle |
28 1/8 |
28 1/8 |
Depth w/o Door Handle |
26 1/8 |
26 1/8 |
Oven Door Clearance |
21 |
21 |
Approximate Shipping Weight (lbs.) |
166 |
166 |
Minimum Clearances to Combustible Surfaces |
|
|
|
|
This range can be installed flush against right and left base |
|
|
|
|
cabinets, and rear vertical wall. The dimensions provided |
B |
|
|
|
are to be measured from the range itself, and not the |
|
|
|
|
installation cutout for the range. |
|
|
|
|
A - Minimum of 30 inches between top of cooking surface and |
C |
|
|
|
bottom of an unprotected wood or metal cabinet. |
A |
|
|
D |
Or |
|
|
||
E |
|
|
|
|
A - Minimum of 24 inches between cooking surface and |
|
|
|
|
protected wood or metal cabinet above range. Cabinet |
|
|
|
|
bottom must be protected by at least 1/4 inch thick millboard |
|
|
|
|
with not less than No. 28 MSG sheet steel, .015 inch thick |
|
|
|
|
stainless steel, .024 inch thick aluminum, or .020 inch thick |
|
|
|
|
|
|
|
|
|
copper. |
|
|
F |
|
B - Minimum of 30 inches of protected cabinets above the |
|
|
|
|
|
|
|
|
|
range. |
|
|
|
|
C - Minimum of 18 inches between top of countertop and |
|
|
|
|
bottom of an unprotected wood or metal cabinet. |
|
|
|
|
D - Maximum depth of 13 inches for overcounter cabinets. |
|
|
|
|
E - Minimum of 3 inches to a vertical right or left side wall |
|
G |
||
extending above cooking surface. |
|
|||
F - Maximum depth of 25 inches. |
|
|
|
|
G - Maximum of 36 inch cabinet height. |
|
|
|
|
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice. Doc. 4024, Page 2 of 3
