Amana ARS2606BB, ARS2606BC, ARS2606BW Specification Sheet
Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Side by Side 26 Cubic Foot Models: |
Fax Document Number: 1138 / 011015 |
Models |
ARS2606B |
|
|
General |
|
Style |
Freestanding |
Free-O-Frost™ Operation |
Yes |
Magna-Seal™ Door Gaskets |
Yes |
Seamless Food Liners |
Yes |
Total Refrigerator Capacity (cu.ft.) |
25.6 |
Fresh Food Capacity (cu.ft.) |
15.9 |
Freezer Capacity (cu.ft.) |
9.7 |
Total Refrigerator Shelf Area (sq.ft.) |
25.4 |
Fresh Food Shelf Area (sq.ft.) |
16.6 |
Freezer Shelf Area (sq.ft.) |
8.8 |
Colors |
|
White |
ARS2606BW |
Bisque |
ARS2606BC |
Black |
ARS2606BB |
Energy Index |
|
% Below Current Standard |
0 |
Energy Label Value @ $.0842 KWH |
55 |
KWH per Year, Using FTC Method |
657 |
Energy Star® Compliant |
--- |
Exterior Features |
|
Handle Color & Type with Extension |
CC/Grab |
Rounded Door Edge |
Yes |
Toe Grille Color |
CC |
Top & Bottom Hinge Cover Color |
CC |
Textured Steel Exterior |
Yes |
Adjustable Front & Rear Rollers |
Yes |
SofSound™ Package |
Yes |
Fresh Food Interior |
|
Two Covered Upper & One Lower Light |
Yes |
Temp-Assure® Controls |
Yes |
Clean ‘n clear® Water Filter |
--- |
Adjustable Full-Width Glass Shelves (#) |
2 |
Spillsaver™ |
2 |
EasyGlide™ |
1 |
Adj. Split Spillsaver™ SideGlide™ Shelves |
2 |
Adjustable Beverage Organizer™ |
Slide-Out |
Clear Adjustable Humidity Controlled |
|
Snack Drawer |
Yes |
Spillsaver™ Glass Top Shelf |
Yes |
Large Clear Garden Fresh™ Humidity |
|
Controlled Crisper (#) |
Yes |
Drawer Glides |
--- |
Spillsaver™ Glass Top Crisper Shelf |
Yes |
Clear Temperature Controlled Dual Drawer |
Yes |
Drawer Glides |
--- |
CC - Color Coordinated |
|
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice. Doc. 1138, Page 1 of 3
Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Models |
ARS2606B |
|
|
Fresh Food Door |
|
Clear Adjustable Dairy Center |
Yes |
Large Temperature Controlled Beverage |
|
Chiller™ |
Yes/French Door |
Adjustable Clear Gallon Door Buckets (#) |
1 |
Adj. Clear Gallon Tilt-Out Door Buckets (#) |
2 |
Gallon Door Storage (#) |
8 |
Deepfreeze Interior |
|
OneCovered Upper Light |
Yes |
Quick Chill™ Zone |
--- |
Stationary Full-Width Wire Shelves (#) |
3 |
Glide-Out Wire Freezer Baskets (#) |
2 |
Hanging Wire Shelf |
Yes |
Flex Action Ice Cube Trays |
2 |
Ice Storage Bin |
Yes |
Deepfreeze Door |
|
Adjustable Door Bucket (#) |
2 |
Stationary Door Bucket (#) |
1 |
Adjustable Tilt-Out Door Buckets (#) |
3 |
Feature Accessory Package |
|
Accessory Coupon Value |
$10.00 |
Gallon Bucket Grip Pads |
3 |
Sales Accessories |
Available by calling 1/877-232-6771 or by visiting ww.amana.com |
FreshNest™ Egg Bucket |
Yes |
Gallon Bucket Grip Pads |
Yes |
Temperature Controlled Beverage Chiller™ |
Yes |
MiniChiller™ |
Yes |
KidZone™ Door Storage |
Yes |
Ice Maker Kit |
IC10S |
External Water Filter Kit |
WF60 |
Trim & Panel Kit |
Contact Frigo Designs at 1/800-836-8746 |
|
Warranty applies only when product is |
Warranty |
repaired by an authorized Amana servicer |
Entire Unit |
Full 1 year - parts, labor and travel |
Sealed System |
Full 5 years - parts, labor and travel |
Food Compartment Liner |
Full 5 years – parts, labor and travel in lieu of replacement |
Approvals |
|
U.L. & C.S.A. |
Yes |
Electrical Information |
|
115 V, 60 Hz, 15 Amp |
Yes |
Installation Specification (in Inches) |
|
Top/Back Air Clearance |
1/2 |
Kitchen Cabinet Opening |
36 |
Door Opening Outside of Cabinet |
1/4 |
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice. Doc. 1138, Page 2 of 3
