Amana AEZ8581ADB10, AEZ8590ADB10 Installation Guide

RV Radiant Cooktop |nsta||ation

iMPORTANT:
Installer: Leave installation instructions with the appliance.

,, Follow the enclosed instructions to avoid countertop laminate damage.
Owner: Keep installation instructions for future reference.
,, Save installation instructions for local electrical inspector's use.
,, Only qualified personnel should install or service this appliance.
,, Read "Safety Instructions" in Use & Care Guide before using this appliance.

{{{{{{{{{{{i

Improper installation, adjustment, alteration, service,
maintenance or use of this appliance can result in serious
injury or property damage.

Warranty is void on equipment installed other than as
recommended by manufacturer.

|rlStFUCtJOnS (Models AEZ8590 & AEZ8581)

Cutout dimensions are critical. Dimensions must be
measured and cut accurately to within _+1/16" (.16 cm) to

insure proper fit.

ratine

data plate

'\

Never use a metal blade to pry off knobs. If a knob cannot be

............easily removed, tuck folds of a dishtowel under the knob skirt

and pull upward with steady, even pressure.

!2.Z cm)

30!'

Do not over-tighten the hold down adjusting screw. Damage
to the glass cooktop will occur if excessive pressure is used.
Secure the unit to the countertop using only the hold down
bracket and adjusting screw provided, do not use any other

means to secure the unit.

foam tape

Do not use the junction box for additional wiring connections.
Do not remove the center terminal ground wire from the unit.

Turn off power supply when making electrical connections.

Cookware retention devices must be installed and used
properly to minimize the potential for spills and burns.
Extreme caution should be exercised when cooking in a

moving boat or vehicle.

adjusting screws

Model AEZ8590

(240 Volt, 13.3 Amps)

Ground

__Red

Black

Model AEZ8581

(120 Volt, 20 Amps)

--White/Neutral

--Ground

-- Black

lVlaytag • 403 West Fourth Street North • P, O, Box 39 • Newton, Iowa 50208
