Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Amana Over the Range Microwaves:
Models ACO1520A ACO1840A ACO1860A
Fax Document Number: 2018 / 011023
General
Interior Capacity 1.5 1.8 1.8
Wattage 950 1000 1000
Touchmatic® Control System Yes Yes Yes
12.75 Inch Turntable Yes --- -- Recessed Turntable 13 Inch --- Yes – On/Off Yes – On/Off
Interior Oven Light Yes Yes Yes
3 Program Levels Including Defrost Yes Yes Yes
10 Variable Power Levels Yes Yes Yes
Auto Defrost, 3 Options Yes - Meat, Poultry & Fish
Timed Defrost Yes Yes Yes
Rapid Defrost (1 pound) --- Yes Yes
Favorite Recipe Pad --- Yes Yes
3 Sensor Cook Options
3 Sensor Reheat Options
3 Sensor Vegetable
4 Auto Cook Options
4 Auto Reheat Options
Popcorn Pad Yes Yes Yes, Sensor
Potato Pad Yes Yes Yes, Sensor
Pizza Yes Yes Yes, Sensor
Beverage Yes Yes -- Frozen Entrée Yes --- -- More/Less Time Pad --- Yes Yes
Easy Cook™ Yes Yes Yes
Hold Warm Yes Yes Yes
Help Pad --- Yes Yes
Complete Reminder Yes Yes Yes
Clock/Timer AM/PM Yes Yes Yes
Scrolling 7 Digit Display Yes Yes Yes
5 Control Set Up Options
CFM’s Low/High 110 / 220 215 / 300 215 / 300
Exterior Cooktop Light Low/High (# of) Yes – (1) Yes – (2) Yes – (2)
Cooktop Light Timer --- Yes Yes
Recirculating Charcoal Filter Included Yes Yes Yes
Bi Level Wire Rack --- Yes Yes
Child Lock Out Yes Yes Yes
UL Listed Yes Yes Yes
Installation Instruction Manual Available on Fax Document #2096
--- --- Frozen Entree,
Casserole, Rice
--- --- Casserole,
Dinner Plate,
Soup/Sauce
--- --- Fresh, Frozen,
Canned
Fresh Vegetable,
Frozen Vegetable,
Rice, Casserole
Dinner Plate,
Soup/Sauce,
Casserole, Roll/Muffin
Sound On/Off, Clock Display On/Off, Scroll Speed Adjustment
Weight in Pounds or Kilograms & Demo Mode
Fresh Vegetable,
Frozen Vegetable,
Rice, Casserole
Dinner Plate,
Soup/Sauce,
Casserole, Roll/Muffin
---
---
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice.
1 of 3
Doc 2018, Page
Page 2
Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Models ACO1520A ACO1840A ACO1860A
Colors
Black ACO1520AB ACO1840AB ACO1860AB
White ACO1520AW ACO1840AW ACO1860AW
Bisque --- ACO1840AC ACO1860AC
Stainless Steel --- --- ACO1860AS
Warranty
Entire Appliance Full 1 year – parts, labor and travel
Magnetron Tube
Electrical
Electrical Requirements 120 VAC, 60 Hz, 13 Amp
KW 1.50 KW
Oven Interior Dimensions - Door Closed
(in Inches)
Height - w/Turntable in Place
(if applicable)
Width 19 7/8 22 1/16
Depth 14 5/32 14 7/16
Warranty applies only when product is repaired by an
authorized Amana servicer.
Full 2-5 years – parts, labor and travel
8 15/16
9 7/8
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice.
2 of 3
Doc 2018, Page
Page 3
Amana Product Information by Fax / Internet
800-843-0304 / http://www.amana.com
Models ACO1520A ACO1840A ACO1860A
Exterior Dimensions (in Inches)
Height - Front 15 3/4
Height – Rear 16 7/16
Width 29 15/16
Depth - Oven Door Closed with Handle 16 31/32
Clearance - Oven Door 23 3/8 25
Cut-Out Dimensions (in Inches)
Height 30
Width 30 (minimum)
Top Edge from Cooking Surface 30 (minimum)
Top Edge from Floor 66 (minimum)
Maximum Cooking Surface Width 36
Approximate Shipping Weight (lbs.) 68
OPTIONAL ACCESSORIES
Replacement Recirculating Charcoal
Filter Kit (for duct-free installation)
MVHRK4
MVHRK3
* Units are designed to be installed with standard 12” deep cabinets
** Please refer to current installation instructions for all installation information
Grounded O utlet
(inside upper cabinet)
30" min. cabinet
opening width
30" min. clearance from bottom
of cabinet to cooking surface
or countertop
(Use templates included
with installation instructions)
Maximum gas or electric
cooking product widt h of
36 inches.
Power Suppl y Co rd Hole
Amana’s ongoing commitment to quality products may mean a change in product specifications without notice.
3 of 3
