14” Digital Photo Frame
Instructional Manual
aluratek.com
mnl M10127 Copyright © 2011 Aluratek, Inc. All Rights Reserved.
ADMPF114F
Table of Contents
Frame Close-up ......................................................................................................
Remote Control Close-up .......................................................................................
Package Contents ..................................................................................................
Getting Started .......................................................................................................
Operating Instructions
Set-Up ....................................................................................................................
Selecting Which Media to View ..........................................................................
Viewing Photos ..................................................................................................
Adjust Speed of Slideshow ................................................................................
Adjust the Slide Transition Effect .......................................................................
Listen to Music ...................................................................................................
Music Play Mode ................................................................................................
View Videos .......................................................................................................
Video Play Mode ................................................................................................
Copy Files Between Memory Cards / Internal Memory .....................................
Delete Files From Memory Cards / Internal Memory .........................................
Change the Display Language ...........................................................................
04
05
06
06
07
07
08
09
10
11
12
13
14
15
16
17
Table of Contents
Set the Date and Time .......................................................................................
Set the Alarm .....................................................................................................
Setup Power On / Off Timer ...............................................................................
Display Mode Setup ...........................................................................................
Color Setup ........................................................................................................
Technical Support ...................................................................................................
Radio and TV Interference Statement ....................................................................
Warranty .................................................................................................................
18
19
20
21
22
23
24
25
Frame Close-Up
Menu Buttons
Speakers
14” LCD Screen
Quality Glossy Black Frame
4
LED
SD / SDHC Card Slot
USB 2.0 Ports
Power Button
Power Adapter Port
Frame Stand
Remote Control Close-Up
1. Power On / Off
2. SlideShow
3. Enter
4. Up, Down, Left, Right Arrows - Use arrow keys
to navigate your way throught various menus
5. Exit - Returns to the previous menu
6. Zoom
7. OSD - On Screen Display
8. View
9. Aspect Ratio - 16:9 / 4:3
10. Music
11. StepShow - Advance to next photo
12. Rotate
13. Volume + / Volume -
14. Menu - Takes you to the main menu
9
MUSIC
SLIDE
SHOW
16:9/4:3
STEP
SHOW
10
11
1
2
3
4
5
6
7
8
ENTER
EXIT
ZOOM OSD
MENU
VIEW
ROTATE
VOL+
VOL-
12
13
14
5
Package Contents
Your order has been carefully packaged and inspected. The following should be included in
your package. Please inspect the contents of the package to ensure that you have received
all items and that nothing has been damaged. If you discover a problem, please contact us
immediately for assistance.
• Digital Photo Frame
• Remote Control
• USB 2.0 Cable
• Power Adapter
• Instructional Manual
• Warranty / Registration Card
Getting Started
• Remove the protective lm covering the LCD.
• Remove the plastic insulator from the battery on the remote control.
6
Operating Instructions
Set-Up
STEP 1: Plug the power adapter in then turn the power switch on.
STEP 2: Please insert your memory card (SD / SDHC) at this time. You may also insert a
USB thumb / ash drive into the on-board USB 2.0 port which will be detected automatically. Slideshow will start automatically when the card is inserted. (The slideshow will start
from the internal memory if no memory card is detected)
Note: You must disconnect the USB cable from your computer after transferring. You will not be able to scroll
with the remote while the USB connection is established.
Selecting Which Media to View
Press the “Menu” button until you can view the media you have inserted into your picture
frame or the included memory in the main menu.
To create a custom slideshow with pictures in a particular order, please copy one picture
at a time to the memory card as the order is determined by the time stamp of the le
when it is copied.
7
Operating Instructions
Viewing Photos
1. Select the “Photo” icon on the screen.
2. Select the photo you desire by using the up and down keys on your remote control.
3. Once you have selected your photo press “Enter”.
4. You may zoom in on your photos by pressing the “Zoom” button on the remote. You
may also reposition the photo using the up, down, left and right buttons on the remote
once you zoom in for detailed viewing. You may also rotate the picture by pressing the
“Rotate” button on the remote.
5. You can also press the “OSD” button for more viewing options.
8
Operating Instructions
You may adjust your photo viewing options settings including: Speed interval for slideshow,
and multiple slide transition options by entering the “Setup” menu from the main menu.
Adjust Speed of Slideshow
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Slideshow Time”.
3. Use the left or right key to select the time interval from 3sec to 1hour then press “Enter”.
4. Press “Menu” to return to the main menu.
9
Operating Instructions
Adjust the Slide Transition Effect
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Slideshow Mode”.
3. Use the left or right key to select your desired slide transition effect then press “Enter”.
4. Press “Menu” to return to the main menu.
10
Operating Instructions
Listen to Music
1. Select the “Music” icon on the screen.
2. A list of MP3 les stored on your media will appear on the screen. Use the up and
down keys on the remote control to select the desired song then press “Enter”. You
can press the “ ” to pause / play.
3. The next song will play automatically on the song list. You may also select another
song using the up and down keys on your remote control.
11
Operating Instructions
Music Play Mode
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Music Repeat Mode”.
3. Use the left or right key to select “Repeat One”, “Repeat All” or “Repeat Off” then
press “Enter”.
4. Press “Menu” to return to the main menu.
12
Operating Instructions
View Videos
1. Select the “Movie” icon on the screen.
2. A list of video les stored on your media will appear on the screen. Use the up and
down keys on the remote control to select the desired video then press “Enter”. You
can press the “ ” to pause / play.
3. You may zoom in on the video by pressing the “Zoom” button on the remote.
4. The next video will play automatically on the list. You may also select another video
using the up and down keys on your remote control.
13
Operating Instructions
Video Play Mode
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Movie Repeat Mode”.
3. Use the left or right key to select “Repeat One”, “Repeat All” or “Repeat Off” then
press “Enter”.
4. Press “Menu” to return to the main menu.
14
Operating Instructions
Copy Files Between Memory Cards / Internal Memory
1. Select the “File” icon on the screen.
2. Select the photo you want to copy using the up and down keys on your remote control
and press the “ ” key. You will see a next to the le name
3. Press the “OSD” button.
4. Select “Copy” and press “Enter” on the remote.
5. Select the memory card or internal memory that you want to copy to and press the “ ” key.
6. Press the “Enter” key to start copy
7. Press the “Enter” key when you see “Finish” to exit.
15
Operating Instructions
Delete Files From Memory Cards / Internal Memory
1. Select the “File” icon on the screen.
2. Select the photo you want to delete using the up and down keys on your remote control
and press the “ ” key. You will see a next to the le name.
3. Press the “OSD” button.
4. Select “Delete” and press “Enter” on the remote.
5. Select the “check mark” and press the “Enter” key to delete the le.
6. Press the “Enter” key when you see “Finished” to exit.
16
Operating Instructions
Change the Display Language
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Language”.
3. Use the left or right key to select the desired language then press “Enter”.
4. Press “Menu” to return to the main menu.
17
Operating Instructions
Set the Date and Time
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Time”.
3. Use the left or right key to select what you want to change and use the up or down key
to change to the correct value then press “Enter”.
4. Press “Menu” to return to the main menu.
18
Operating Instructions
Set the Alarm
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Alarm”.
3. Use the left or right key to select what you want to change and use the up or down key
to change to the correct value then press “Enter”. The 1st number is the hour follow by
the minute. The next item is ring tone selection, Ring1/Ring2. The last item is the alarm
status “off”, “once”, “every”.
4. Press “Menu” to return to the main menu.
19
Operating Instructions
Setup Power On / Off Timer
1. Select “Setup” from the main menu and press “Enter” on the remote control.
2. Scroll to “Auto Power On” or “Auto Power Off” and press the “ ” button on the
remote control.
3. Use the up or down key to set the time in 24H format.
4. Use the up or down key to select “On” and press “Enter”.
20
Operating Instructions
Display Mode Setup
1. Select “Setup” and press “Enter” from the main menu.
2. Use the up or down key to select “Display Mode”.
3. Use the left or right key to select “Cinema”, “Crop”, and “Stretch” then press “Enter”.
4. Press “Menu” to return to the main menu.
21
Operating Instructions
Color Setup
1. Select “Setup” from the main menu and press “Enter” on the remote control.
2. Scroll to the desired option “Brightness”, “Contrast”, or “Saturation” and press the
“ ” or “ ” button on the remote control to select the desired level.
22
Technical Support
If you need further assistance, please contact Aluratek support department prior to returning
this device.
E-mail: support@aluratek.com
Web: www.aluratek.com/support
Local (Tustin, CA): 714-586-8730
Toll free: 1-866-580-1978
23
Radio and TV Interference Statement
WARNING!!! This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by whatever measures may be required to
correct the interference.
24
Warranty
Aluratek warrants this product against defect in material or workmanship for 120 Days from the
date of purchase.
This warranty becomes invalid if the factory-supplied serial number or “warranty void” sticker has
been removed or altered on the product.
This warranty does not cover:
A) Cosmetic damage or damage due to acts of God
B) Accident, misuse, abuse, negligence or modication of any part of the product.
C) Damage due to improper operation or maintenance, connection to improper equipment,
or attempted repair by anyone other than Aluratek.
D) Products sold AS IS or WITH FAULTS.
IN NO EVENT SHALL ALURATEK’S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT
FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING
FROM THE USE OF THE PRODUCT, IT’S ACCOMPANYING SOFTWARE, OR IT’S DOCUMENTATION.
Aluratek makes no warranty or representation, expressed, implied, or statutory, with respect to it’s
products, contents or use of this documentation and all accompanying software, and specically
disclaims it’s quality, performance, merchantability, or tness for any particular purpose. Aluratek
reserves the right to revise or update it’s product, software or documentation without obligation to
notify any individual or entity.
25
aluratek.com
Aluratek, Inc. 14831 Myford Rd. Tustin, CA 92780 sales@aluratek.com 714.586.8730 • ofce 714.586.8789 • fax
Loading...
