K-KC4Z - Kona
INSTRUCTION MANUAL
07.10
KK008
● Model Number
Please keep this manual and product code number for future reference
and to order replacement parts if necessary.
● General Instructions
- Read this manual carefully and completely before
proceeding.
- It is recommended that you wear safety glasses at all
times during the installation.
● Installation over Ceramic Tiles
- Silicone should be used to seal the gap where the
ceramic tiles meet the
- If your shower door is to be installed over ceramic tiles,
the tiles should lay completely under the wall jamb.
panel.
● Notice
- Caulking: no sealant is required inside the shower.
- All models are equipped with transparent sealing
gaskets.
● Care for your Frameless Shower Door
- Never use scouring powder pads or sharp instruments on
metal pieces or glass panels.
An occasional wiping down with a mild soap diluted
in water is all that is needed to keep the panels and
aluminum parts looking new.
- We recommend wiping the glass panels with a squeegee
after each use.
without notice.
2
PARTS LISTING
NOTE
11 910
1
2
XX REFERS TO THE MATERIAL FINISH
11- Bright Chrome
12- Bright Brass
25- Brushed Nickel
29- Oil Rubbed Bronze
3
4
5
6
ITEM PARTS QTY
7
1 WALL JAMB 2
2 EXPANDER 2
3 FIXED PANEL 2
4 SET OF HANDLES 2
5 DOOR SIDE GASKET 4
6 DOOR PANEL ASSEMBLY 2
7 BOTTOM TRACK 2
8 SIDE GASKET WALL JAMB SIDE 2
9 TOP TRACK 2
10 MAGNETIC DOOR GASKET 2
11 GLASS SUPPORT 8
3
PROVIDED HARDWARE
4
11a 11b
11
5
12 13 14
16
8
1715
10
18
19a
ITEM HARDWARE QTY
19
19b
20
4 SET OF HANDLES 2
5 SIDE GASKET 4
8 SIDE GASKET WALL JAMB SIDE 4
10 MAGNETIC DOOR GASKET 1
11 GLASS SUPPORT 8
12 BOTTOM SLIDER SHIM 4
13 WALL PLUG 8
14 SCREW (M4 x 8) 8
15 SCREW CAP 8
16 SCREW (M4 x 35) 12
17 SCREW (M4 x 8) 8
18 EXPANDER CAP 2
19 CONNECTOR 2
20 WALL JAMB CAP
4
3. INSTALLEZ LE PANNEAU
TOOLS AND MATERIALS REQUIRED
8
3. INSTALL THE FIXED PANEL.
/
*
SCREWDRIVERS
*
If the shower panels are to be assembled on ceramic tiles, use a 1/4˝ drill bit for ceramic tiles.
DRILL
1/4˝& 1/8˝ DRILL BITS
SILICONE
WOODEN BLOCK
2˝
1/2˝
6˝
PENCIL
CUTTING PLIER
TAPE MEASURE
MALLET
LEVEL
5
CENTER AND INSTALL THE WALLJAMB
1
1A
MODEL MIN (in / cm) MAX (in / cm)
32 31 1/4” (79cm) 32” (81cm)
36 34 1/4” (87cm) 35” (89cm)
42
40 3/8”
(102.5cm)
41 1/8” (104cm)
1B
Refer to the limits given (Min/Max),position and center
1A.
the wall jambs (#1) on the shower threshold.
1B.
Trace outer edge of wall jambs.
1
6
MOUNT THE WALL JAMBS.
2
Reposition one of the wall jambs (#1) on the shower
2A.
threshold.
Mark drilling location.
.B2
2C.
With a 1/4” drill bit, drill 4 holes.
Insert 4 wall plugs (#13) and put in each a drop of
2D.
silicone.
2B
2C
1
2A
1
2E.
Secure the wall jamb (#1) using the 1 3/8” screws
(#16).
2F.
Repeat the same step for the other wall jamb.
2D
2E
7
3
BUILD TWO HALVES-FRAMES.
3
Mount on the each expander (#2) the two track (#7 & #9)
3A.
to form two halves-frames.
9
2
7
BUILD THE FRAME.
4
4A.
Use the connectors(#19a) to close the frame and add
the cover (#19b).
19b
2
7
19a
19b
19a
19a
19b
8
MOUNT THE FRAME.
5
Insert the frame into the installed wall jambs.
5A.
1
5A
1
5A
5B.
Position and center the frame onto threshold of shower
base.
5B
9
INSTALL THE FIXED PANEL.
6
INTERIOR
SHOWER SIDE
6A.
9
11b
3
3
11b
INTERIOR
SHOWER SIDE
3
11b
6A
11a
7
11b
11b
INTERIOR
SHOWER SIDE
11a
6B
3 3
10
DOOR INSTALLATION
7
INTERIOR
SHOWER SIDE
7A
INTERIOR
SHOWER SIDE
7a.
Install the rollers on the door panel so
that the rollers point towards the outside
of the shower. The hole of the handle
must always be on the opening side of
the door.
7b.
Install the bottom sliders on the door
panel while placing the hooks towards
the outside of the shower. Place the
bottom slider shims on the hooks.
Shims
7B
INTERIOR
SHOWER SIDE
11
DOOR INSTALLATION
7
6
6
7C
1010
6
7D
10
6
6
7C
12
6
7C.
Insert door panels(# 6) into the top track (#9) and
add magnetic dor gasket (# 10).
7D.
Insert door panels(# 6) into the bottom track (#7)
pushing down the guide and add bottom slider shim
(# 12).
9
7D
7
12
VERTICAL ADJUSTMENT.
8
8A 8C
INTERIOR
SHOWER SIDE
8B
INTERIOR
SHOWER SIDE
3
3
5
INTERIOR
SHOWER SIDE
10
8E
8D
6
5
8
INTERIOR
SHOWER SIDE
8
8A.
Loosen the nut with a hex nut driver 5/16
’’
Vertical adjustment(verify if the magnetic gasket meetproperly).
8C.
Tighten the nut. Close the cover.
8D.
& door panels.
Insert side gasket wall jamb side (#8) using a
8E.
mallet and a small wood block.
13
UNITY FIXATION.
89
9A. Level and adjust unit.
Fasten frame with screw 3/8’’ (#14) and add screw
9B.
cap (#15).
9A
9A
9A
14
15
INTERIOR
SHOWER SIDE
2
9B
15
2
14
INTERIOR
SHOWER SIDE
14
FINISHING TOUCHES.
10
10A.
Insert expander caps (#18).
18
20
10A
1
18
20
1
18
20
1
7
7
HOURS
10B.
Silicone exterior the bottom track (#7) and along
the wall jambs (#1).
10B
15
