WPTV244UL Series
CCTV Outdoor Power Supplies
Installation Guide
Models Include:
• WPTV244175UL • WPTV244300UL
- 24VAC @ 7 amp (175VA) - 24VAC @ 12.5 amp (300VA)
or 28VAC @ 6.25 amp (175VA). or 28VAC @ 10 amp (280VA).
- Four (4) Protected Outputs. - Four (4) Protected Outputs.
Rev
. 021
104
Overview:
These outdoor Altronix CCTV Power Supplies provide power via four (4) protected outputs for CCTV Cameras, heaters
and other video accessories. Units are UL Listed UL2044 “
U.S. and Canada for CCTV Equipment.”
Four (4) Output WPTV Reference Chart:
Altronix
Model Number
WPTV244175UL
WPTV244300UL
Output Voltage
24VAC 7 amp
28VAC 6.25 amp
24VAC 12.5 amp
28VAC 10 amp
(I max)
Total Output Current
Number of
Outputs
PTC Protected Outputs
4 3 1 2.5 amp/I max - 1.76 amp
4 3 1 2.5 amp/I max - 2.7 amp
Fuse Protected
(Class 2 power limited)
Outputs
Output Current
(max per output)
PTC Protected/Fused
Main Fuse Ratings
on Board
50/60Hz Input
Current
115VAC
Specifications:
• Surge suppression.
• AC power LED indicator.
• Power ON/OFF switch / circuit-breaker.
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
12"H x 8"W x 6"D
Installation Instructions:
1. Mount unit in desired location. Use hardware supplied and stainless steel fasteners.
2. Turn OFF main switch on all models
3. All units are factory set for 24VAC operation.
For 28VAC operation (for models with 24VAC/28VAC option only), adjust unit prior to mounting and applying
power as follows: Change the wire position so that the black wire [28V] is connected to the terminal marked [P] and
the yellow wire [24V] is connected to the terminal marked [S].
4. Before drilling WP enclosure for wire entry, remove back plate (four (4) screws) with all internal par ts
(Fig. 2A, pg. 5). For suggested wire entry locations refer to (Fig. 1, pg. 4). Use weather tight NEMA 4 rated
connectors, b
5. Place back plate with all internal parts (four (4) screws) back into WP enclosure
6. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 2-3, pgs. 5-6), secure g reen lead
to earth ground. Use 18 AWG or larger for all power connections.
eep po
K
Minimum .25” spacing must be provided. Use separate entries.
7. Measure output voltage before connecting devices. This helps avoid potential damage.
Terminals marked [1P - 4P] are of the same polarity.
UTION:
CA
the output v
8. Connect devices to terminals marked [1P - 1N through 3P - 3N] on board (Figs. 2-3, pgs. 5-6), carefully observing
polarity. Connect high current device to output (4P - 4N).
Turn main switch to the ON (RESET) position
9.
10. Green LED will illuminate when unit is powered.
11. Upon completion of wiring, secure enclosure door with the cam lock (supplied).
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
ushings, and cab
er limited (PTC protected outputs only) wiring separate from non-power limited wiring.
w
Determine the maximum operating voltage of the equipment being powered before adjusting
.
e
oltag
les.
(Figs. 2-3, pgs. 5-6).
igs. 2-3, pgs. 5-6).
(F
(Fig. 2A, pg. 5).
- 2 -
WARNING: This installation should be made by qualified service personnel. Unit should be installed in
accordance with the National Electrical Codes and all local codes. For continued protection against risk
of fire replace all fuses only with the same type and rating (15 amp/250V).
Terminal Identification:
PD4 - Power Distribution Module
1P - 3P AC output, PTC protected, power limited, Class 2 Rated.
1N - 3N AC output, common.
4P AC output, fused, non-power limited.
4N AC output, common.
- 3 -
- 3 -
Right PanelLeft Panel
Suggested Locations
for Wire Entries
Bottom Panel
Suggested Locations
for Wire Entries
Fig. 1
- 4 -
Fig. 2
XFMR
non-power
limited
115VAC Input
50/60 Hz.
Green
Lead
(Ground)
Power
Switch
INPUT
1P 1N 2P 2N
LED
PD4
POWER DISTRIBUTING UNIT
ALTRONIX CORP.
BROOKLYN,NY 11220
MADEIN USA
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
3P 3N 4P 4N
F1 F2 F3 F4
PTC protected outputs
1 through 3.
Power limited,
Class 2 Rated,
2.5 amp max
per output.
Input from
transformer.
1P 1N 2P 2N
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
3P 3N 4P 4N
Non-power
limited, fuse
protected output
(see Reference
Chart).
WPTV244175UL
Fig. 2A
Terminal Blocks for Fig. 2
- 5 -
non-power
limited
115VAC Input
50/60 Hz.
Green
L
ead
(Ground)
P
ower
Switch
I
NPUT
1P 1N 2P 2N
L
ED
PD4
POWER DISTRIBUTING UNIT
ALTRONIX CORP.
BROOKLYN,NY 11220
MADEIN USA
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
3P 3N 4P 4N
F
1 F2 F3 F4
XFMR*
Fig. 3
PTC protected outputs
1 through 3.
Power limited,
Class 2 Rated,
2.5 amp max
per output.
Input from
transformer.
1P 1N 2P 2N
1P, 2P, 3P, 4P = FUSED OUTPUTS
1N, 2N, 3N, 4N = COMMON OUTPUTS
3P 3N 4P 4N
Non-power
limited, fuse
protected output
(see Reference
Chart).
WPTV244300UL
Terminal Blocks for Fig. 3
- 6 -
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated “D
ANGEROUS VOLTAGE” within the products enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION:To reduce the risk of electric shock do not open enclosure. There are
no user serviceable parts inside. Refer servicing to qualified service personnel.
- 7 -
.
5"
7
.4"
8.77"
2"
0
0
10"
6
"
0
0
.75"
.75"
11.25"
12"
8".77"
Enclosure Dimensions
12"H x 8"W x 6"D
Altronix is not responsible for any typographical errors.
Altronix Corp.
140 58th Street, Brooklyn, Ne
web site: www.altronix.com, e-mail: info@altronix.com, Lifetime
II1WPTV244UL Series E05D
York 11220 USA, 718-567-8181, fax: 718-567-9056
w
ar
W
, Made in U.S.A.
ranty
- 8 -
