Altech Toggle Handle Motor Disconnect Switch Catalog Page
1L1
50.5 mm 71 mm
74 mm
Toggle Handle Motor Disconnect Switch
The KUE series only
requires an additional
co
ver plate (see
below) which makes
the switch IP20 touch
proof.
Catalog Number
No. of Poles
General Purpose Current
Maximum Voltage
Motor FLA @ 480V AC
Motor FLA @ 600V AC
Horsepower Rating /HP
110-120V AC
200V AC
208V AC
220-240V AC
265V AC
277V AC
380-415V AC
440-480V AC
550-600V AC
Short Circuit Withstand Rating
at 600 Vwith Max. Fuse
Size/Class:
K5
RK5
RK1
J
KUE325
3
25A
600V AC
17.5A
11A
1 Phase 3 Phase
12
25
25
37.5
3 7.5
37.5
510
7.5 15
510
10kA
50A
50A
80A
80A
KUE340
3
40A
600V AC
28A
18A
1 Phase 3 Phase
23
37.5
37.5
510
5 10
510
7.5 15
10 20
7.5 15
10kA
50A
50A
80A
80A
KUE363
3
60A
600V AC
34A
27A
1 Phase 3 Phase
35
510
510
510
5 10
7.5 10
10 20
15 25
15 25
10kA
60A
60A (80A@480V AC)
100A
100A
Terminal Size Acceptability
(Cu Conductors only, 75°C)
Terminal Torque
Dimensions
(to convert to inches
multiply by 0.03937)
Weight
Suitable Accessories
Cover Plate
Cat. No. K/KUE K/KUE Y R/KUE R/KUE Y
Color Grey Yellow Grey Yellow
Shape Rectangular Rectangular Circular Circular
14-8AWG
16 lb. in.
0.172Kg (0.379lb.)
14-8AWG
16 lb. in.
0.172Kg (0.379lb.)
12-4AWG
16 lb. in.
0.172Kg (0.379lb.)
10
