Alpha Omega Instruments 2520 Specifications

SERIES 2520

Percent Oxygen Analyzer

Product shown with optional ow meter

FEATURES BENEFITS

State-of-the-Art Sensor Technology High Precision Measurements

Light Weight/Compact Design Easy to Carry and Transport

Rapid Speed of Response Senses Oxygen Changes in Seconds

Built-in NICAD Batteries Provides Hours of Continuous Operation

Uses Standard NICAD’s Replacement Batteries Found World-Wide

Minimum Maintenance Low Cost of Ownership

System Description

The Series 2520 Portable Percent Oxygen Analyzer is a light­weight, easy-to-use analyzer that provides accurate and repeatable

percent oxygen measurements in a variety of gases. The rugged
and compact design of the Series 2520 makes it ideal for industrial
applications where spot oxygen measurements need to be made.
The Series 2520 can be congured with one of several measuring
ranges from 0-1% to 0-100% oxygen. The standard Series 2520
Portable Percent Oxygen Analyzer is equipped with a 3-1/2 digit

liquid crystal display, built-in NICAD batteries, and a universal AC
adapter that provides the ability to recharge the NICAD batteries

even while powering the analyzer from the adapter.

Specications

PERFORMANCE

Measurement Ranges:
0-5, 0-10, 0-25, 0-50, and 0-100%
Accuracy: ±1% of full scale
Linearity: ±1% of full scale
Response Time: 90% of full scale in <20 seconds
Sensor Type: Electrochemical
Temperature Compensation: Standard
Operating Temperature Range: 40° to 104°F (5° to 40°C)

Warranty: Two years electronics/1 year sensor

ELECTRICAL

Display: 3-1/2 digit liquid crystal display

The Series 2520 Portable Percent Oxygen Analyzer features an
extended life oxygen sensor with EES (Enhanced Electrolyte Sys­tem) that provides exceptional measurement accuracy and stabil­ity. For applications where carbon dioxide is present in the sample
gas, the EES retards passivation of the sensor anode by allowing
the products of oxidation to dissolve in the electrolyte. In effect, the

sensor is renewed continuously, resulting in an increase in sensor

life. The output from the sensor is temperature compensated.

Power Source: Rechargeable NICAD batteries with universal (90­ 240 VAC) AC adapter

Analog Output: Not available

SAMPLE GAS CHARACTERISTICS

Sample Flow Rate: 1.0 to 2.0 SCFH (0.5 to 1.0 liters/minute)

Sample Gas Pressure Limits: 0.1 to 1.5 psig (0.007 to 0.1 kg/cm2).

CONSTRUCTION

Enclosure: Polycarbonate-rated NEMA 1
Dimensions: 5.8 in. (147.3 mm) Height

6.7 in. (170.2 mm) Width

3.4 in. (86.4 mm) Depth
Note: All dimensions are without optional
equipment

Gas Connections: Quick connect

Weight: <2 pounds (<0.907 kg)
