User’s Manual
For
11N Wireless Lan Card
Model Number : WMP-N12
Revision: 1.0
Alpha Networks Proprietary and Confidential Information
1
Test Utility Installation:
Hardware: RT3052 RGMII INIC test fixture, with gigabit Ethernet port computer
Software: RT3x5x MII V1.0.1.0
1. Insert WMPN12 to RT3052 RGMII INIC test fixture, connect the test fixture to computer with
Ethernet cable
2. Use RT3x5x MII V1.0.1.0, make sure the computer has installed the wincap.exe
3. Select GIGABIT INIC
4. Use QA tool control WMPN12
Alpha Networks Proprietary and Confidential Information
2
1.1 Document
This document is to specify the product requirements for 802.11n Draft 2.0 Intelligent NIC Card. This iNIC Card
is based on Ralink RT3052 single chipset that complied with complied with IEEE 802.11n Draft 2.0, IEEE 802.11
b/g standard from 2.4~2.5GHz. It can be used to provide up to 54Mbps for IEEE 802.11g , 11Mbps for IEEE
802.11b and 300Mbps for IEEE 802.11n to connect your wireless LAN.
1.2 Product Features
y RT3052 , single chip , 2T2R , MA/BBP/RF
y A WLAN intelligent NIC solution to a host SOC platform
y High performance 384 MHz MIPS24Kec CPU inside to Ethernet PHY and Gigabit Ethernet MAC
y 300Mbps PHY data rate for longer range and better throughput
y Compatible with IEEE 802.11g high rate standard to provide wireless 54Mbps data rate
y Compatible with IEEE 802.11b high rate standard to provide wireless 11Mbps data rate
y Compatible with IEEE 802.11n draft standard to provide wireless 300Mbps data rate
y Operation at 2.4 ~ 2.5GHz frequency band to meet worldwide regulations
y Dynamic date rate scaling at 6, 9, 12, 18, 24, 36, 48, 54Mbps for IEEE 802.11a and IEEE 802.11g
y Dynamic date rate scaling at 1, 2, 5.5, and 11Mbps for IEEE 802.11b
y Dynamic date rate of IEEE 802.11n scaling from MCS – 0 to MCS –15 as shown in Appendix I
y Supports wireless data encryption with 64/128 bit WEP for security
y Support WPA and WPA2 enhanced security
y Support QoS – WMM , WMM power save
y Support RGMii signals transmission
y Drivers support Linux 2.6
Alpha Networks Proprietary and Confidential Information
3
2.0 Requirements
The following sections identify the detailed requirements of the 802.11n Draft 2.0 mPCI .
2.2 General Requirements
2.2.1 IEEE 802.11b Section
# Feature Detailed Description
2.2.2.1 Standard
2.2.2.2 Radio and
Modulation
Schemes
2.2.2.3 Operating
Frequency
2.2.2.4 Channel Numbers
2.2.2.5 Data Rate
2.2.2.6 Media Access
Protocol
2.2.2.7 Transmitter Output
Power
2.2.2.8 Receiver Sensitivity
IEEE 802.11b
y
DQPSK, DBPSK, DSSS, and CCK
y
2400 ~ 2483.5MHz ISM band
y
11 channels for United States/ TAIWAN
y
13 channels for Europe Countries
14 channels for Japan
11, 5.5, 2, and 1Mbps
y
CSMA/CA with ACK
y
Typical RF Output Power (Tolerance +-2dB) at each RF chain, Data
y
Rate and at room Temp. 25degree C
18±2dBm at 1,2,5.5,11Mbps
y
Typical Sensitivity at Which Frame (1000-byte PDUs) Error Rate =
y
8%
–88 dBm at 1Mbps
y
–88 dBm at 2Mbps
y
–88 dBm at 5.5Mbps
y
–86 dBm for 11Mbps
y
2.2.2 IEEE 802.11g Section
# Feature Detailed Description
2.2.3.1 Standard
2.2.3.2 Radio and
Modulation Type
2.2.3.3 Operating Frequency
2.2.3.4 Channel Numbers
2.2.3.5 Data Rate
2.2.3.6 Media Access
Protocol
2.2.3.7 Transmitter Output
Power
2.2.3.8 Receiver Sensitivity
Alpha Networks Proprietary and Confidential Information
IEEE 802.11g
y
BPSK, QPSK, 16QAM, 64QAM with OFDM
y
2400 ~ 2483.5MHz ISM band
y
11 channels for United States/ TAIWAN
y
13 channels for Europe Countries
13 channels for Japan
6,9,12,18,24,36,48,54Mbps
y
CSMA/CA with ACK
y
Typical RF Output Power (tolerance +-2dB) at each RF chain, Data
y
Rate and at room Temp. 25degree C
18±2dBm at 6~18 Mbps
y
17±2dBm at 36 and 24Mbps
y
15±2dBm at 54 and 48 Mbps
y
Typical Sensitivity at Which Frame (1000-byte PDUs) Error Rate =
y
10%
–87 dBm at 6Mbps
y
4
# Feature Detailed Description
–86 dBm at 9Mbps
y
–84 dBm at 12Mbps
y
–82 dBm at 18Mbps
y
–79 dBm at 24Mbps
y
–75 dBm at 36Mbps
y
–71 dBm at 48Mbps
y
–70 dBm at 54Mbps
y
2.2.3 IEEE 802.11n Section for 2.4G Band
# Feature Detailed Description
2.2.4.1 Standard
2.2.4.2 Radio and
IEEE 802.11n
y
BPSK, QPSK, 16QAM, 64QAM with OFDM
y
Modulation Type
2.2.4.3 Operating Frequency
2.2.4.4 Data Rate
2.2.4.5 Media Access
2400 ~ 2483.5MHz ISM band
y
From MCS – 0 to MCS –15 as shown in Appendix I
y
CSMA/CA with ACK
y
Protocol
2.2.4.6 Transmitter Output
Power
Typical RF Output Power (tolerance +-2dB) at each RF chain, Data
y
Rate and at room Temp. 25degree C
HT 20
y 17±
y 17±
y 16±
y 14±
2 dBm at MCS 0,1
2 dBm at MCS 2,3
2 dBm at MCS 4,5
2 dBm at MCS 6,7
HT 40
y 15±
y 15±
y 14±
y 12±
2.2.4.7 Receiver Sensitivity
y
2 dBm at MCS 0,1
2 dBm at MCS 2,3
2 dBm at MCS 4,5
2 dBm at MCS 6,7
Typical Sensitivity at Which Frame (1000-byte PDUs) Error Rate =
10%
HT20
–85 dBm at MCS 0
y
–82 dBm at MCS 1
y
–80 dBm at MCS 2
y
–77 dBm at MCS 3
y
–74 dBm at MCS 4
y
–70 dBm at MCS 5
y
–68 dBm at MCS 6
y
–66 dBm at MCS 7
y
HT40
–82 dBm at MCS 0
y
–79 dBm at MCS 1
y
–77 dBm at MCS 2
y
–74 dBm at MCS 3
y
–71 dBm at MCS 4
y
–67 dBm at MCS 5
y
–65 dBm at MCS 6
y
–63 dBm at MCS 7
y
2.3 General Section
# Feature Detailed Description
2.3.1.1 Antenna Connector
Three UFL antenna connectors
y
Alpha Networks Proprietary and Confidential Information
5
2.3.1.2 Operating Voltage
2.31.3 Current
Consumption
2.3.1.4 Form Factor and
Interface
2.3.1.5 LED
3.3VDC +/- 10%
y
450 mA at continuous transmit mode (2 Tx chains on )
y
250 mA at continuous receive mode (2 Rx chains on )
y
PCI-E form factor
y
External LED function supported
y
2.4 Software Requirements
The Configuration Software supports Linux2.6. This configuration software includes the following functions:
y Information
Information allows you to monitor network status.
y Configuration
Configuration allows you to configure parameters for wireless networking.
y Security
Supports enhanced security WEP, 802.1x, WPA and WPA2.
2.4.1 Information
# Feature Detailed Description
2.4.1.1 General
Information
2.4.1.2 Current Link
Information
2.4.1.3 Site survey
General Information shows the name of Wireless
y
Adapter, Adapter MAC Address, Regulatory Domain,
Firmware Version, and Utility Version.
Current Link Information shows the Current Setting
y
ESSID, Channel Number, Associated BSSID, Network
Type, Security Status, Link Status, Transmit Speed,
Signal Strength, and Link Quality.
To search the neighboring access points and display the
y
information of all access points.
2.4.2 Configuration
# Feature Detailed Description
2.4.2.1 ESS ID
2.4.2.2 Network Type
2.4.2.3 Power Save
2.4.2.4 RTS Threshold
2.4.2.5 Fragment
Threshold
2.4.2.6 Transmission Speed
2.4.2.7 Roaming
2.4.3 Security
# Feature Detailed Description
2.4.3.1 Encryption y RC4 encryption algorithm
Alpha Networks Proprietary and Confidential Information
Input an SSID number if the roaming feature is enabled
y
Supports for ASCII printable characters.
y
Ad-hoc Mode and 802.11 Ad-hoc Mode for network
y
configurations that do not have any access points
Infrastructure Mode for network configurations with
y
access points
Extend the battery life of clients by allowing the client
y
to sleep for short periods of time while the Access Point
buffers the messages.
Set the number of bytes used for fragmentation
y
boundary for messages
Set the number of bytes used for RTS/CTS boundary
y
This indicates the communication rates. Select
y
appropriate transmission speed to match your wireless
LAN settings
Support Automatic or Manual Rescan to associate with
y
access point.
y Support 64-bit and 128-bit WEP encryption
6
# Feature Detailed Description
y Support open system (OSA) and shared key
authentication (SKA)
2.4.3.2 WEP Management y Four WEP keys can be selected
y STA with WEP off will never associate any AP with
WEP enabled
y WEP Key Format: Option for Hex format
2.4.3.3 802.1x
2.4.3.4 WPA/WPA2
Support EAP-TLS, EAP-TTLS, and EAP-PEAP
y
Support WPA/WPA2-PSK and WPA/WPA2-EAP
y
Support Cipher Mode AES and TKIP
y
2.5 Mechanical Requirements
# Feature Detailed Description
2.5.1 Length y 72mm(max)
2.5.2 Width y 48mm (+-0.25)
2.5.3 Height y 4.7mm (+-0.1)
2.6 Compatibility Requirements
This device passes the following compatibility requirements.
# Feature Detailed Description
2.6.1 Wi-Fi
2.6.2 WHQL
2.6.3 Physical Layer and
Functionality
Meet Wi-Fi certification for IEEE 802.11b/g/n product
y
Meet applicable WHQL certification requirements
y
Meet ALPHA Engineering Test Plan and Test Report
y
2.7 Requirements of Reliability, Maintainability and Quality
# Feature Detailed Description
2.7.1 MTBF
2.7.2 Maintainability
2.7.3 Quality
Mean Time Between Failure > 30,000 hours
y
There is no scheduled preventive maintenance required
y
The product quality is followed-up by ALPHA factory
y
quality control system
2.8 Environmental Requirements
# Feature Detailed Description
2.8.1 Operating
Temperature
Conditions
2.8.2 Non-Operating
Temperature
Conditions
2.8.3 Operating
Humidity
conditions
2.8.4 Non-Operating
Humidity
Conditions
Alpha Networks Proprietary and Confidential Information
y The product is capable of continuous reliable operation
when operating in ambient temperature of 0℃ to +40℃.
Neither subassemblies is damaged nor the operational
y
performance is degraded when restored to the operating
temperature after exposing to storage temperature in the
range of -40 ℃ to +70℃.
The product is capable of continuous reliable operation
y
when subjected to relative humidity in the range of 10%
and 90% non-condensing.
The product is not damaged nor the performance is
y
degraded after exposure to relative humidity ranging
from 5% to 95% non-condensing
7
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware
programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for
testing their end-product for any additional compliance requirements required with this module installed (for example, digital device
emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with
another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In
these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining
a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained
between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: RRKWMPN12A1”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in
the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Alpha Networks Proprietary and Confidential Information
8
以下警語適用台灣地區
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更
原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無
干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本產品內含射頻模組：ID 編
號」
Alpha Networks Proprietary and Confidential Information
9
Loading...
