Alphacool Eisblock XPX Aurora PRO Plexi Black User Manual

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

What is it?

Alphacool Eisblock XPX Aurora PRO Plexi Black

Highlights

With the Alphacool XPX Aurora Pro Eisblock, Alphacool offers a CPU water cooler specially designed
for processors with particularly large processor cores. These currently include the AMD Threadripper
models and processors from Intel for the LGA 2066 socket and the LGA 3647 server socket in narrow
ILM design.

- Transparent plexi top

- Nickel-plated copper cooling block

- Digital RGB illumination

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Technical data GPU cooler

W x T x H 79 x 63,8 x 31 mm

Net weight 545 g

Max working temperature 60 °C

Material cooler nickel plated copper

Material bottom part brass

Material top Plexi

Threads 2 x G1/4“

Power supply Digital RGB 3-Pin 5V

Pressure tested 1,5 bar

Certificates CE, FC, ROHS

Scope of delivery

1 pcs. CPU cooler
1 pcs. Thermal paste
1 pcs. digital – RGB adapter cable
4 pcs. springs
4 pcs. M4 nuts

1 pcs. Set INTEL 2066 / 2011 brackets
4 pcs. INTEL 2066 / 2011 bolts

1 pcs. Set INTEL 3647 Narrow brackets
4 pcs. INTEL 3647 screws

1 pcs. Set AMD TR 4 / SP 3 brackets

4 pcs. AMD TR 4 / SP 3 bolts

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Other data

Article number Alphacool 12950

EAN Code 4250197129503

PU Box 1

Dimensions PU B x T x H 21,5 x 12,7 x 4 cm

Weight 815 g

Customs code 84195080900

Product pics download

https://www.alphacool.com/
download/1016829_Alphacool_Eisblock_XPX_Aurora_PRO-

Plexi_Black_Digital_RGB.zip

Article text

With the Alphacool XPX Aurora Pro Eisblock, Alphacool offers a CPU water cooler specially designed
for processors with particularly large processor cores. These currently include the AMD Threadripper
models and processors from Intel for the LGA 2066 socket and the LGA 3647 server socket in narrow
ILM design. As a CPU cooler from the Aurora Design line, the CPU cooler naturally offers integrated digi-

tal aRGB lighting.

Extremely powerful

The cooler base has been specially optimized for the large processor cores. With an area of 42 x 58.6
mm and 147 cooling fins the cooling area has been significantly increased. As a comparison, an Alphacool
XPX Aurora Eisblock has 81 cooling fins to completely cover the processor core of a normal CPU. Both
coolers use the same fin type with a thickness of only 0.2 mm. This clearly shows how far Alphacool has
gone to offer the best possible performance. The entire cooler base is of course made of nickel-plated
copper and not aluminium. This is due to the increased thermal conductivity of copper. It is almost twice
as high as that of aluminium.

How is the CPU cooler illuminated?

As with all new Eisblock CPU water coolers, Alphacool relies on an integrated aRGB solution. An alumin­ium frame is flush with the CPU cooler. Of course, the aluminium does not come into contact with the
water. The LED frame contains up to 14 addressable digital RGB LEDs. This is more than enough to illu­minate the entire cooler even and brightly. The intensity of the illumination can of course be controlled
by an appropriate controller. Due to the use of digital RGB LEDs, all known effects can be created, be-

Manual PDF

https://www.alphacool.com/download/Eisblock-XPX-Aurora­Pro_Manual.pdf

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

cause each LED can be controlled separately with the right controller. The Alphacool Eisblock Aurora
Pro cooler can also be connected and controlled via the 3-pin 5V connector on any compatible main-

board. The cable also has an integrated Y-adapter. This makes it easy to connect further Alphacool Auro-

ra products in series without having to order separate Y-adapters. Only additional extension cables may
be needed if you want to connect the products in series.

Is the assembly difficult?

Installation is child's play. Remove the protective film from the base of the cooler, apply some of the en­closed thermal paste to the CPU and then attach the cooler to the board. Depending on the base, the
mounting screws are either screwed on before or after mounting. No tools are necessary for the assem­bly. Alphacool uses knurled screws, which allow a quick and easy assembly.

Finally Plexi!

The Alphacool Eisblock XPX Aurora Pro is the technical brother of the Eisblock XPX Pro 1U cooler,
which was developed especially for the use in server housings. During the development the functionality
had a much higher priority than the design, which was kept practical and discreet. The Eisblock XPX Au­rora Pro has been optically adapted to the Aurora products and now offers the same design features as
you are used to from the Aurora series. This allows you to perfectly match your entire system to each
other optically and you don't have to make any compromises. Thanks to the plexiglass look, you can see
the water flow beautifully. On the Plexi there is a black frame embedded with a very discreet Alphacool
logo in one corner.
