Alphacool Eisblock XPX Aurora Edge Plexi Black User Manual

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

What is it?

Alphacool Eisblock XPX Aurora Edge Plexi Black

Highlights

The new Alphacool Eisblock XPX Aurora Edge CPU water cooler offers fantastic performance thanks to
the patented ramp design as well as boasting excellent quality. The new Aurora design in combination
with the addressable digital RGB illumination offers many possibilities for outstanding illumination of the
CPU water block.

- Transparent plexi top

- Nickel-plated copper cooling block

- Digital RGB illumination

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Technical data GPU cooler

W x T x H 70 x 70 x 32,5 mm

Net weight 407 g

Max working temperature 60 °C

Material cooler nickel plated copper

Material bottom part brass

Material top Plexi

Threads 2 x G1/4“

Power supply Digital RGB 3-Pin 5V

Pressure tested 1,5 bar

Certificates CE, FC, ROHS

Scope of delivery

1 pcs. CPU cooler
1 pcs. Thermal paste
1 pcs. digital – RGB adapter cable
4 pcs. springs
4 pcs. M4 nuts

1 pcs. Set INTEL 2066 / 2011 brackets
4 pcs. INTEL 2066 / 2011 bolts

1 pcs. Set INTEL 3647 Narrow brackets
4 pcs. INTEL 3647 screws

1 pcs. Set AMD TR 4 / SP 3 brackets

4 pcs. AMD TR 4 / SP 3 bolts

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Other data

Article number Alphacool 12948

EAN Code 4250197129480

PU Box 1

Dimensions PU B x T x H 21,5 x 13 x 4 cm

Weight 686 g

Customs code 84195080900

Product pics download

https://www.alphacool.com/
download/1016828_Alphacool_Eisblock_XPX_Aurora_Edge-

Plexi_Black_Digital_RGB.zip

Article text

The new Alphacool Eisblock XPX Aurora Edge CPU water cooler offers fantastic performance thanks to
the patented ramp design as well as boasting excellent quality. The new Aurora design in combination
with the addressable digital RGB illumination offers many possibilities for outstanding illumination of the
CPU water block.

Performance in abundance!

Alphacool already developed and patented new flow technology for the first Alphacool Eisblock XPX se­ries. The so-called "ramp system" ensures an even flow of water inside the cooler and sits in front of the
diffuser plate. This ensures that the water is pressed evenly through the diffuser plate, which in turn push­es the water evenly over the cooling base. The cooling channels on the CPU cooler base has also been
enlarged to a proud 34 x 32 mm to accommodate the ever-growing CPU DIEs. This is especially true for
multi-core processors with 4, 6, 8 or even 12 and more CPU cores. So that the heat from the CPU can
be transferred to the water as quickly as possible. 81 cooling fins can be found on the cooling plate to en­sure maximum heat diffusion. The fin structure has been reduced to just 0.2 mm in order to create the

largest possible surface area in the smallest possible space.

And the lighting?

All new Eisblock XPX Aurora Edge CPU waterblocks come with addressable digital RGB lighting. The
aRGB LEDs are integrated directly into the CPU water cooler and run once around the entire cooling
block. With up to 15 digital RGB LEDs the entire CPU block is evenly and intensively lit. Of course, the
brightness can be controlled by an appropriate controller. And as with all aRGB LED products all known

Manual PDF

https://www.alphacool.com/download/Eisblock-XPX-Aurora_Manual.pdf

Version: 17.09.2019

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

effects can be created. From simple colour changes to wave effects and rainbow lighting, everything is
possible. Of course, the Alphacool Eisblock Aurora coolers can also be connected and controlled via

mainboards using the standard 3-pin 5V connector. The cable also has an integrated Y-adapter. This

makes it easy to connect further Alphacool Aurora products in series without having to order separate Y­adapters. Extension cables may be needed if you want to connect the products in series, depending on the
size of the case.

Is installation difficult?

Mounting the XPX Aurora Edge Eisblock cooler is simple. The backplate is simply attached to the main­board from behind. The mounting frame for the AMD or Intel socket is clamped to the cooler and the
corresponding mounting screws are pre-attached to this frame. Next, you simply apply thermal paste and
you attach the cooler using the screws.

Please note: Remove the protective foil on the cooler base before use!

Unique Aurora Design

The Alphacool Eisblock Aurora Edge has been significantly changed in some points to its predecessor, the
Eisblock XPX. The lower part of the cooler is completely made of brass and no longer of plexiglass or
transparent nylon. This changes the overall feel and quality of the cooler. Not only is it heavier in the
hand, but it is also much more stable than the usual Plexi CPU water coolers. In order to stand out visual­ly from the normal Eisblock XPX Aurora CPU water cooler, the bottom of the cooler was kept com­pletely in black. This emphasizes the visual effect of the water flow. The corners of the CPU cooler are
more angular, which makes the cooler stand out from the normal Aurora Plexi Eisblock.
