Alphacool Eisbaer TPV Extension Set User Manual

Version: 22.06.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

What is it?

Alphacool Eisbaer TPV Extension Set

(Hose and Connectors)

Highlights

The Alphacool Eisbaer TPV Extension Set offers the easiest way to connect the expandable AIO systems
from Alphacool with other components. The Extension Set is compatible with all Alphacool AIO systems
for processors and graphics cards.

- Completely pre-assembled

- TPV hose

- with Eisbaer Ready quick coupling

Version: 22.06.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Technical data hose

Material Thermoplastic vulcanizates, EPDM/PP

Outside diameter/inside diameter 12,7 x 7,6 mm

Colour Matt black

Length 30 cm

Working temperature -50 to 155 °C

Hardness 35 Shore-A to 50 Shore-D

Certificates CE, FC, ROHS

Scope of delivery

Alphacool Eisbaer TPV Extension Set 90° - male

Alphacool Eisbaer TPV Extension Set 90° - female

Technical data quick connector

Diameter x height 20 x 104 mm

Bore diameter 6 mm

For tube size 12,7 / 6,7 mm

Net weigth 27 g

Max working temperature 60° C

Type of quick release connector Screw In

Material Nylon

Technical data

Net weight 125 g

Technical data fitting

Dimensions (L xD) 24 x 18 mm

For hose size 12,7 / 6,7 mm

Thread G1/4“

Thread length 5,5 mm

Material Brass

Version: 22.06.2020

We assume no responsibility for any typing errors.

Alphacool International GmbH, Marienberger Strasse 1, 38122 Braunschweig Tel: [phone] Supportmail: [e-mail]

Other data

Article number Alphacool 12982

EAN Code 4250197129824

PU Box 1

Dimensions PU B x T x H 40 x 9,6 x 3,3 cm

Weight 200 g

Customs code 84199085900

Product pics download

https://www.alphacool.com/download/1019315_pics.zip

Article text

The Alphacool Eisbaer TPV Extension Set offers the easiest way to connect the expandable AIO systems
from Alphacool with other components. The Extension Set is compatible with all Alphacool AIO systems
for processors and graphics cards.

The 12.7/7.6 mm TPV hose is 30 cm long and has a straight Alphacool TPV connection with G¼" thread
at one end. At the other end there is a quick-release coupling with a male or female connection. The safe­ty quick-release fasteners use a twist lock. This means that unintentional opening of the quick release fas­tener is almost impossible.

If you want to use the Extension Set to extend an Alphacool AIO solution with another product, you
must pay attention to where you use the male and female connectors. The hose with the Male quick con­nector should always be mounted at the water outlet. The piece of hose with the female quick release
fastener is used at the water inlet.
