Alpha VI644S10, VI644S12 Specsheet

Product Specification Sheet APS864 - Rev. 11/2013

VI644S V.I.P.™ Series Stainless Steel Economy Style Lobby PanelsVI644S V.I.P.™ Series Stainless Steel Economy Style Lobby Panels

387 CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone] CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone]

Web: www.canalalarm.comWeb: www.canalalarm.com

Copyright © 1998-2 017 Alpha Communication s® - All Righ ts Reserved.

Due to c ontinuo us product i mprovement, all col ors, sizes, materials, finishes and sp ecifications are subject to change witho ut not ice.

VI644 S06

6 Butto n Su rfa ce Pa n el

Architects' And Engineers'Architects' And Engineers'

SpecificationsSpecifications

The entry panel unit(s) shall be Alpha
Communications® VI644S V.I.P.™ series,
or approved equal. Panel(s) shall be
surface mount t ype. Panel(s) shall include
a 45-ohm mylar loudspeaker. Panel(s)
shall have solid-metal push-buttons,
matc hing stainless steel resident name
holder slots, and mesh speaker grille to
protect the speaker components. Panel
shall be made of a single sheet of 16
gauge high carbon stainless steel.

Surface VI644S panels shall be made with

1.375" (35mm) side return bends and
open in the bac k. A 'Star'
head sc rewdriver tip shall be provided
with eac h panel for installation / removal
and maintenance of t he name holders.

VI644S V.I.P.™ Series Economy Stainless Steel Lobby PanelsVI644S V.I.P.™ Series Economy Stainless Steel Lobby Panels

The Alpha Communicat ions® VI644S V.I.P.™ series surface mount Stainless Steel (Vandal-
Resistant) lobby panels are rugged, good-looking panels for indoor or outdoor use, and are
our lowest c ost St ainless Steel panels, with matching stainless steel name holders, made in
stoc k c onfigurations, for 2 to 12 push buttons.

Made of heavy 16 gauge high-c arbon stainless steel, the VI644S series is made to take
abuse. VI644S panels are made in 'stoc k' sizes, and are available in several surface mount
styles. These surfac e VI644S panels are made with 1.375" (35mm) side return bends and
are open in the back, and include a 'C' type galvanized st eel wall mounting bracket.

All VI644S panels feature solid metal push-butt ons and matc hing stainless steel resident
name holder slots. T he use of 'Star' head sc rews makes it nearly impossible to tamper with
the panel without t he use of the spec ial screwdriver tool.

All VI644S surface panels are a c ompact 4.25" wide (108mm) and are available in
2,3,4,6,8,10 or 12 button versions. Models with 2 thru 8 push butt ons are 13.00" high
(331mm) and model with 10 or 12 buttons are 16.00" high (407mm). Because of the low­cost 'st ock' nature of these panels, t hey are not available in cust om sizes or configurations,
with c ustom engraving, building name/address engraving or alphabetical directories. For
cust om configurations or special Stainless Steel panel requirements, we suggest our VI402
(custom) V.I.P.™ series panels.

FeaturesFeatures

Our LOWEST COST St oc ked Surface Stainless St eel Panels!
Heavy 16 Gauge High-Carbon Stainless Steel Fac eplate
Solid Metal Pushbuttons with Permanent Engravings
Panels are available in several Surface Mount c onfigurations
Rugged, Good-Looking and Vandal-Resistant
Works with a variety of apartment intercom stations
Tamper-Resistant 'Star' Head Sc rews Used

SpecificationsSpecifications

Dimensions:

WIDTH: Surfac e; 4.25" (108mm).
HEIGHT : 2 t hru 8 push buttons 13.00" (331mm), 10 or 12 push
buttons 16.00"h (407mm).

Construction: Heavy 16 Gauge High- Carbon Stainless Steel fac eplate.

Tool Required:

'Star' head sc rewdriver tip required for panel
installation/removal, and name holder maintenance, included
with eac h VI644 V.I.P.™ panel ordered.
