Alpha TE903, TE903NP Specsheet

Product Specification Sheet APS585 - Rev. 07/2013

TE903/TE903NP Surface Mount Telephone Entry Master StationsTE903/TE903NP Surface Mount Telephone Entry Master Stations

387 CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone] CANAL STREET • NEW YORK • NY • 10013-1615 • Phone: [phone] • Fax: [phone]

Web: www.canalalarm.comWeb: www.canalalarm.com

Copyright © 1998-2 017 Alpha Communication s® - All Right s Reserved.

Lexan is a registered trademark of G.E. Corp

Due to c ontinuo us product i mprovement, all col ors, sizes, materials, finishes and sp ecifications are subject to change witho ut not ice.

TE903 (standard 'Dialer' type)

TE903NP (No-Phone-Bill' type)

Architects' And Engineers'Architects' And Engineers'

SpecificationsSpecifications

Alpha Communicat ions® surface mount
Series Telephone Entry System is a
complete automatic call and entry
cont rol system. The syst em operates on
a standard dedicated telephone line and
110 VAC with 16 VAC t ransformer.

All faceplates shall be c onstructed of 16
gauge stainless steel and shall include a
zinc die-cast marine quality keypad,
speaker/microphone, postal release
option, and an RJ Plug Connect or. The
TEK-Entry Modular Series allows for 1 ­750 apartment c apac ity (with 7/10/11
digit dialing capabilities).

Both the TE903 and TE903NP models
shall include an integral 100 name
directory with a Lexan®
Window, although more than 100 names
may be possible if a smaller font is used.

NOTE: See installation/use manual
for certain restrictions when using
the TE903 and/or TE903NP
unit(s) outdoors.

Stainless Steel Faceplate Telephone Entry SystemsStainless Steel Faceplate Telephone Entry Systems

Alpha Communicat ions® Stainless St eel Fac eplate Telephone Entry Syst ems are designed for
easy operation and are available in models with a number capacity of 1 - 750 units (7
digits/10 digits/11 digits). Units c an be used as st andard 'dialer' type or 'nophone-bill type (with
additional equipment). Both models are standard in an open- voice (loudspeaking) configuration.

FeaturesFeatures

Can be used with either rotary or touch-t one service
Memory retention during power failure (EEPROM)
Vandal/weather resistant c onstruction (St ainless Steel)
Keyless entry c ode
Door timer c ut- off - Voice mail compatible
Built-in Weigand interfac e t o c ard ac cess system
Postal Lock Release provision
Multiple entrance capability (add only additional lobby panels up to 20 entrance stations)
Secondary relay output
Lexan® Polycarbonate Directory Window

SpecificationsSpecifications

Dimensions:

11.0"W x 16.0"H x 3.65"D
(280mm x 407mm x 93mm)

Construction:

16 gauge stainless st eel fac eplate with Black painted enclosure and
Rain Hood

Power Required: 110 VAC for SS106 Transformer(s)

Mounting:

Surface (standard) - may be Flush mounted with optional model TR903
Stainless Steel Flush Trim frame

Typical System ComponentsTypical System Components

TE903

Telephone Entry Master (stainless steel with Black painted enc losure and rain hood
with built-in 100 name directory

TE903NP

Same as TE903 Master but also includes the 'No Phone Bill' software required for
that application. This master requires additional 'No Phone Bill' components.

SS106

Transformer (1 required to power the TE903 or TE903NP. A separate t ransformer is
required to power the door opener).
