No. d'article: 168029
Numéro de fabricant: ALL-WCL1200AC
ALLNET ALL-WCL1200AC / 1200Mbit Wireless Client
EAN CODE
4038816168023
HIGHLIGHTS
Support wide voltage DC5-15V power supply, two-stage automatic overvoltage protection;
Suppot both 2.4G and 5G band;
RF power: 2.4G--14.5dBm, 5G 19dBm/23dBm Adjustable;
Support WiFi transmission protocols such as 802.11ac and 802.11n;
WiFi transmission rate: 300Mbps (2.4G) + 900Mbps (5G);
Point-to-point barrier-free maximum transmission distance: 300 meters (802.11A);
Support connecting more than 20pcs WiFi terminal at the same time;
Adopt temperature compensated auto frequency control technology (TAFC), WiFi signal is more stable
and not easy to drop;
Original creation VDNS virtual domain configuration technology to solve the user’s trouble of
configuration;
Built-in heat sink with convection cooling holes on both sides of the housing for more efficient heat
dissipation;
WiFi intelligent bridge function, wireless to wired, wired to wireless intelligent switching;
Support manually close SSID broadcast, manually close WiFi hardware;
Support WEB management, English configuration interface;
Support SSA signal strength detection and reporting function to realize WiFi mobile positioning;
Working environment temperature: -40 ° C to 55 ° C;
Support IP layer transparent transmission and MAC layer transparent transmission two bridge modes to
meet various bridge applications:
IP layer transparent transmission (factory default), transparent transmission of IP layer data, can meet
most of the bridge applications;
MAC layer transparently transmits all data above the MAC layer (link layer) and the MAC layer, including
IP layer data;
ALLNET GmbH - Maistraße 2 - 82110 Germering - sales@allnet.de - 089 / 894 222 22
Sous réserve d'erreurs et d'omissions.
Côté 1/3
Numéro de fabricant: ALL-WCL1200AC
MAC transparent transmission can solve some special applications for MAC layer encryption, such as
GoPro camera, Cisco AP, Hikvision monitoring system, etc.
Application-Szenarios:
Technical Details:
Protocol Standards IEEE 802.11ac, IEEE 802.11a;
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b;
Transmission rate 2.4GHz band: 300Mbps
No. d'article: 168029
5GHz band: 900Mbps
External interface A USB/DC power cable;
A set of 10/100m adaptive Ethernet cable
Button Reset button (long press 5 seconds, then release, the
device will automatically restore the factory )
LED Status instruction:
Ethernet port status light (Yellow);
2.4G WiFi connection status light (Blue);
5G WiFi connection status light (Green);
Antenna Built-in 2pcs Smart omnidirectional 2.4G Antennas,
1.5dbi;
Built-in 2pcs Smart omnidirectional 5G Antennas,
1.5dbi;
Product size 94mm x 45mm x 15mm(L x W x H)
Item weight 72g
ALLNET GmbH - Maistraße 2 - 82110 Germering - sales@allnet.de - 089 / 894 222 22
Sous réserve d'erreurs et d'omissions.
