Part No.: 155351
Vendor Part No.: ALL-MC115PVDSL2
ALLNET ALL-MC115PVDSL2 / VDSL2 100 Mbit Mini
Modem Master/Sl
EAN CODE
4038816155351
Highlights:
VDSL2 modem can be set as either master or slave
Simple 2-wire connection for point-to-point connection
Up to 100 Mbps symmetrical for up to 1km (cable dependent)
supports data packets up to 1536 bytes
2x RJ45 10/100 Mbps Ethernet with PoE according to IEEE802.3af/at
With the ALL-MC115P-VDSL2 modem ALLNET launches a pure VDSL2 Single Port Bridge on the market, which
meets the basic requirement of a high-performance point-to-point connection by means of a 2-wire connection typically an old telephone connection - with all the advantages of a VDSL2 connection. The modem has both
RJ11 sockets and clamping sockets for the pure wire connection. The additional possibility of grounding the
devices (with the ALL95100 lightning protection) provides the necessary protection against lightning strikes in the
application area. Two 10/100Mbps ports with PoE IEEE802.3af/at connect the modem to the network or PoEenabled devices such as telephones / surveillance cameras etc. .
The ALL-MC115P-VDSL2 can be configured quickly and easily via the dip-switch as either a master or slave
modem. Numerous LEDs are mounted on the front of the device for visual indication of operating states and
connections.
Technical Details:
Element Specifications
Standards: IEEE802.3, IEEE802.3u Ethernet
G993.2 VDSL2
VDSL2 Line Code: Discrete multitone (DMT) modulation
ALLNET GmbH - Maistraße 2 - 82110 Germering - sales@allnet.de - 089 / 894 222 22
Errors and technical changes that serve the interests of progress or development of the product, are reserved.
Page 1/4
Part No.: 155351
Vendor Part No.: ALL-MC115PVDSL2
VDSL2 Transmission Mode: Packet Transfer Mode (PTM) / DMT Encoding
Interfaces: 2 x RJ-45 10/100Mbps auto-negotiation Ethernet port
PoE IEEE802.3af/at PoE Output
1 x RJ-11/Terminal Block connector for VDSL2 line port
1 x DIP Switch for Master/Slave Modus and INP and
Interleave Mode selectable
Power DC 48V via AC switching Adapter (48v/1,875A PSU)
Power Output: 30W maximum (power injector)
LED Indicators: LAN:Act/Link, PoE
VDSL2: Act/Link, Line Mode: CO/CPE
Housing: Metal
Dimensions: 137 x 100 x 27 mm
Gewicht: 465 Gramm
Weight: 460g
Environment: Temperature: 0 ~ 50 °C (Operating)
Humidity: 10% ~ 90% (non condensing)
Marks: CE, ROHS
Package content: 1x ALL-MC115P-VDLS2 Modem
1x external PSU
1x QIG
