Allnet ALL1685BUNDEL User guide

Powerline Network

Instant Networks for Internet Access…and More!

Solution for SOHO, SMALL OFFICE AND HOME OFFICE

Encryption Management Utility

User Guide

for

ETHERNET BRIDGE ALL1685

© 2

Index

1. Introduction...................................................................... 3

1.1. Installation............................................................................................................................. 3

1.2. Run the Utility....................................................................................................................... 4

2. How to use.......................................................................5

2.1. Main Frame........................................................................................................................... 5

2.2. Privacy Frame.......................................................................................................................9

2.3. Diagnostics Frame............................................................................................................... 10

2.4. About Frame ....................................................................................................................... 12

© 2

1. Introduction

The ALLNET Configuration Utility enables the user to find HomePlug devices on the
Powerline networks, measures data rate performance, ensures privacy and performs
diagnostics by setting user defined secure Powerline networks.

1.1. Installation

First step, you need to verify that there is no other Powerline Encryption Management
Utility installed on your computer before installing this utility. If there is another utility
installed, please uninstall it and restart your computer.

Second step, please insert setup CD-ROM into the computer’s CD-ROM drive. Run
the “Setup.exe” to install the Utility. The CD will launch an installation screen shown in
Figure 1. Click the “Next” button to continue and follow the instruction to complete the
installation.

Figure 1: Installation Screen

© 2

1.2. Run the Utility

After installed the utility, please run the utility from Start / All Programs or double-click
the utility icon on the desktop. Figure 2 is the main frame screen of the configuration utility.
This screen shows a HomePlug 1.0 device connected as a local device and another three
devices as remote devices.

Figure 3 is the main screen that High Speed device connected locally.

Figure 2: Main Screen with HomePlug 1.0 device Local

Figure 3: Main Screen with High Speed device Local
