CE Warnung:
Dies ist ein Class A Produkt und könnte im häuslichen Gebrauch indifferenten
verursachen. Der Benutzer muss dementsprechende Maßnahmen treffen.
Einleitung:
Dieser PoE Splitter verfügt für einen Gigabit Datenport und einen Gigabit Daten +
PoE Port, welcher bis zu 48Volt zur Stromversorgung verwendet. Dieser Splitter ist
IEE802.3af kompatibel. Alle Cat 5/e Kabel (oder höher) können direkt mit dem Input
und Output Port verwendet werden.
Verpackungsinhalt:
Bevor Sie das Gerät verwenden, überprüfen Sie bitte den Verpackungsinhalt:
• 1x ALL0489 PoE Splitter
• 1x Netzteil für die Stromversorgung mit einem Kabel
• 1x Benutzerhandbuch

Daten:
• 1x Dateninput Port (IEEE802.3 10BaseT, IEE802.3u 100BaseTX und IEE 802.3ab
1000BaseT kompatibel)
•1x Daten + PoE Output Port. (IEE802.3af und IEEE802.3at kompatibel)
• Plug and Play
• Der Daten + PoE Port hat eine Erkennung für die Maximal bereit gestellte
Spannung um Endgeräte vor Überspannung zu schützen.
Vorderseite:
LED Status Description
On PoE Power is on. Power
Off PoE Power is off.
On PD Link on PD
Off No Link
Inbetriebnahme:
Verbinden Sie ein Kabel Ihres vorhandenen PoE Switches (Netzwerk) mit dem
Power + Data In Port. Verbinden Sie Ihr Endgerät mit einem Cat 5/e (oder höher)
Kabel mit dem Data Out Port. Verwenden Sie das mitgelieferte Adapterkabel um Ihr
Endgerät mit Strom zu versorgen.
Technische Details:
IEEE 802.3af
IEEE 802.3at
IEEE 802.3
Standards
Features
LED Indicators
Power Input DC 48V
Power Output
10BaseT
IEEE 802.3u
100BaseTX
IEEE 802.3ab
1000BaseT
Number of Ports:
1 x Input (data only)
Port
1 x Output (data +
power) Port
Power and PD
Link
48V/DC at Full 30
W Output
Power
Consumption
Dimensions
Weight 0.19 kg
Operating
Temperature
Storage
Temperature
Humidity
Certifications FCC Class A, CE
Supported
35 Watts (Max)
102 × 75 × 23 mm
(L x W x H)
0 to 50
-20 to 85
10 to 90% RH
(non-condensing)

EC – Declaration of conformity
This equipment conforms with the requirements of the Council Directive R&TTE
1999/5/EC on the approximation of the laws of the member states relating to Radio and
Telecommunication Terminal Equipment and the mutual recognition of their conformity.
The safety advice in the documentation accompanying the products shall be obeyed. The
conformity to the above directive is indicated by the CE sign on the device.
The ALL0489 PoE Splitter conforms to the European Directives 1989/336/EEC.
This equipment meets the following conformance standards:
EN 55022:2006+A1:2007: Class A
IEC 61000-3-2:2005+A1:2008+A2:2009
IEC 61000-3-3:2008
EN 55024:1998+A1:2001+A2:2003
IEC61000-4-2:2008 IEC 61000-4-3:2006+A1:2007
IEC61000-4-4:2004 IEC61000-4-5:2005
IEC 61000-4-6:2008 IEC 61000-4-8:1993+A1:2000
IEC 61000-4-11:2004
This equipment is intended to be operated in all countries.
This declaration is made by
ALLNET Computersysteme GmbH
Maistraße 2
82110 Germering
Germany
and can be downloaded from http://www.allnet.de/ce-certificates/
