DATE: TYPE:
NAME:
PROJECT:
Solid state
This five-blade 54” ceiling fan features a white opal shade. A remote with batteries
is included. This fan has a dual mount system to offer greater flexibility when
installing. The 17W dimmable, 3000K LED module provides energy- and costsavings benefits to the homeowner.
• 54” indoor ceiling fan features five blades and an LED light source, offering both form and
function with energy- and cost-savings benefits
• The light kit contains a white opal shade and contains a 17W dimmable 3000K LED module
with 90CRI and 1400 lumens
• Features Graphite blades and a Graphite finish
• A hand held remote control with fan speed control and full range light dimming is included
and comes with a convenient wall bracket for storage
• Remote control may be replaced by a wall control
• This five-blade fan features a dual mount system to offer greater flexibility when
installing
• The fan can be installed on a flat or sloped ceiling
• Indoor ceiling fan ideal for use in great rooms, living rooms, bedrooms and bonus rooms
• Ideal for Contemporary interiors
• Reversible motor for year round comfort allows you to choose either a down draft (summer)
or an up draft (winter)
• As a general rule of thumb, lighting experts suggest this fan is ideal in a room size that
ranges from 226- to 400-square feet
• UL dry location listed for indoor use
• A 3/4” x 6” downrod is included. Longer accessory downrods can be ordered separately
• High Speed Energy Information: Airflow— 5242 cfm, Energy consumption— 65 watts
(excluding lights), Airflow efficiency— 80 cfm/watt
• Limited Lifetime Warranty
Category: Ceiling Fans
Finish: Brushed Nickel (Plated)
Construction: Steel construction
Glass: Diffuser
Diameter: 54”
Height: 16”
$
$
3
Cost Range of Similar Models (19” – 84”)
• Based on 12 cents per kWh and 6.4 hours use per day
• Your cost depends on rates and use
• Energy Use: 42 Watts
All estimates based on typical use, excluding lights
Estimated
Yearly Energy Cost
12
Airflow
3678
Cubic Feet Per Minute
• The higher the airflow, the
$
34
more air the fan will move
• Airflow Efficiency: 87 Cubic
Feet Per Minute Per Watt
ftc.gov/energy
MOUNTING ELECTRICAL LAMPING ADDITIONAL INFORMATION
Ceiling mounted
Mounting strap for outlet box
included
Canopy covers a standard 4”
octagonal recessed outlet box
5.875” W., 2.25” ht., 5.875”
depth
Pre-wired
80” of wire supplied
120 V
Quantity:
One 18w max. LED(included)
LED base
UL Dry location listed
Limited Lifetime warranty
Meets California Title 24 JA8-
2016
