Page 1
NIGHT-LITE
GR-SERIES LIQUID-COOLED
Model Kubota Diesel CAT D ie sel
Engine Make Kubota CAT
Engine Model D100 5 C 1.1
Estimated Engine Prime Power (kW) 6
Fuel Capacity (g al [L]) 63 (238)
HP @ 1800 RPM 11. 6 13.8
Emission Tier Tier 4 Final
LED Wat tage 350
Light Output Per Lamp (Lumens) - 350W LED 51,122
Lumens Total - 350W LED 204,488
Engine Cooling Liquid-Cooled
Oper ating Time (Hrs) 350W LED 214 195
Esti mated LED Life (Hrs) 50,000
Outlets
Max Width (in) 98
Transport Width (in) 50.5
Max Height (in) 276
Transport Height (in) 98.5
Tongue Out Length (in) 106.5
Tongue Up Length (in) 86.25
Operating Temperatures -40°F* / 120°F
Shipping Weight (lbs [kg]) (No Fuel) 1,355 (615)
Net Weight - Dry (lbs [kg]) 1,310 (5 94)
Net Weight - Wet (lbs [kg]) 1,750 (7 94)
Number of Units on 48' Flatbed 18
Number of Units on 53' Flatbed 20
Single 120V/20A Duplex GFCI
Single 120V/30A RV
Single 240V/30A 4 Prong Twistlock
™
* Arctic Package Required for -40°F
Page 2
OPTIONS
Available Options at Launch Kubota Diesel CAT D ie sel
Arct ic Package (immersion heater and HD ba ttery)
250W Lights
LED Diffuser Panels
Custom Paint
Telematics (customer supplied, factory lead time)
Galv Tower
Electric Winch
Reversible Coupler 2.5" Lunette Ring (no Bulldog)
Bulldog Hitch (no reversible coupler)
Night-Lite™ GR-Series Liquid-Cooled
www.allmand.com
BRIGGS & ST RATTON
POST OFFICE BOX 702
MILWAUKEE, WI 53201 USA
Copy right ©2021.
All rights reserved.
