Description
Industrial CMOS camera, 5 Megapixels
The Guppy PRO F-503B/C is an industrial CMOS camera with 5 Megapixel resolution. It is
equipped with an Aptina sensor and runs 13 fps at full resolution.
●
Aptina MT9P031 CMOS sensor
●
Trigger
❍
Edge mode, programmable trigger delay
●
Options
❍
Various IR cut/pass filters
❍
White medical housing
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-503bc.html 1
Specifications
Guppy PRO F-503
Interface IEEE 1394b - 800 Mb/s, 1 port
Resolution 2588 x 1940
Sensor Aptina MT9P031
Sensor type CMOS Progressive
Sensor size Type 1/2.5
Cell size 2.2 µm
Lens mount C-Mount
Max frame rate at full resolution 13 fps
A/D 12 bit
Output
Bit depth 8-12 bit
Mono modes 8/12/16
Color modes YUV 411/422
Raw modes 8/12/16
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 1/3
Operating conditions/Dimensions
Operating temperature +5 °C ... +45 °C
Power requirements (DC) 8 V - 36 V
Power consumption (12 V) <3.5 W
Mass 80 g
Body Dimensions
(L x W x H in mm)
Regulations CE, FCC Class B, RoHS
44.8 x 29 x 29 mm incl. connectors
Download technical drawing (click here)
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-503bc.html 2
Smart features
●
AOI (separate AOI for auto features)
●
Programmable LUT, gamma
●
Debayering, color correction
●
Gain
❍
Auto/manual
❍
Manual gain control: 0 - 18.06 dB
●
Exposure
❍
Auto/manual
❍
Exposure time: 20 µs - 22.3 s
●
Binning, up to 4 x 4 mono and color
●
Low noise binning
●
Sub-Sampling (b/w)
●
Defect pixel correction
●
Image mirror H+V (F-503C only horizontal)
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-503bc.html 3
Applications
Thanks to the CMOS sensor and 5 Megapixel resolution, the Guppy PRO F-503 is an industrial
CMOS camera with a high performance and a very attractive price.
Applications:
●
Industrial inspection with high resolution
●
Robotics
●
Logistics
●
Pharmaceutical industry
●
Multimedia
●
ITS/Traffic monitoring
●
... and more
