Description
FireWire camera - ICX445 CCD
The Guppy PRO F-125B/C is a FireWire camera (1394b) with the sensitive ICX445 CCD sensor
and an ultra-compact housing. At full resolution, it runs 31 fps.
●
Sony ICX445 EXview HAD CCD sensor
●
Trigger
❍
Programmable, trigger level control, single trigger, bulk trigger, programmable trigger
delay
●
Options
❍
Various IR cut/pass filters
❍
White medical housing
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-125bc.html 1
Specifications
Guppy PRO F-125
Interface IEEE 1394b - 800 Mb/s, 1 port
Resolution 1292 x 964
Sensor Sony ICX445
Sensor type CCD Progressive
Sensor size Type 1/3
Cell size 3.75 µm
Lens mount C-Mount
Max frame rate at full resolution 31 fps
A/D 14 bit
Output
Bit depth 8-14 bit
Mono modes 8/12/16
Color modes YUV 411/422
Color modes RGB RGB8
Raw modes 8/12/16
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 1/3
Operating conditions/Dimensions
Operating temperature +5 °C ... +45 °C
Power requirements (DC) 8 V - 36 V
Power consumption (12 V) <3.5 W
Mass 80 g
Body Dimensions
(L x W x H in mm)
Regulations CE, FCC Class B, RoHS
44.8 x 29 x 29 mm incl. connectors
Download technical drawing (click here)
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-125bc.html 2
Smart features
●
AOI (separate AOI for auto features)
●
Programmable LUT, gamma
●
Debayering, color correction
●
Gain
❍
Auto/manual
❍
Manual gain control: 0 - 24.4 dB
●
Exposure
❍
Auto/manual
❍
Exposure time: 39 µs - 67 s
●
Binning (2 x 2 b/w)
●
Sub-Sampling (2 x 2 b/w)
http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy-pro/f-125bc.html 3
Applications
This FireWire camera is equipped with a sensitive ExView HAD CCD sensor. With its
ultra-compact housing, the Guppy PRO F-125B/C can easily be integrated into your
application.
Typical applications:
●
Machine vision
●
Robotics
●
Logistics
●
Security and Surveillance
●
Healthcare
●
Ophthalmology
●
Pharmaceutical industry
●
Food inspection
●
Motion analysis
●
ITS/Traffic monitoring
