ALLIED Vision Technologies Guppy F-036 User Manual

Description

Ultra-compact, inexpensive high contrast VGA camera with HDR mode

The Guppy F-036B/C is an ultra-compact, inexpensive VGA camera for applications with high
contrasts. It is equipped with a CMOS sensor by Micron/Aptina which supports the HDR mode
(High Dynamic Range mode). At full resolution, it runs at up to 58 fps. Higher frame rates can
be reached by a smaller AOI.

●

Mircron/Aptina MT9V022 CMOS sensor

●

Trigger

❍

Edge mode, programmable trigger delay

●

Options

❍

Various IR cut/pass filters

❍

CS-Mount, M12-Mount adapter (M12 only for sensors < 1/2)

❍

White medical housing

http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy/f-036bc.html 1

Specifications

Guppy F-036

Interface IEEE 1394a - 400 Mb/s, 1 port
Resolution 752 x 480
Sensor Micron/Aptina MT9V022
Sensor type CMOS Progressive
Sensor size Type 1/3
Cell size 6 µm
Lens mount C
Max frame rate at full resolution 64 fps
A/D 10 bit

Output
Bit depth 8 bit
Mono modes Mono8
Color modes YUV n/a
Color modes RGB n/a
Raw modes Raw8

General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 3 outputs
RS-232 1

Operating conditions/Dimensions
Power requirements (DC) 8 V - 36 V
Power consumption (12 V) <2 W
Mass 50 g
Body Dimensions

(L x W x H in mm)
Regulations CE, FCC Class B, RoHS

48.2 x 30 x 30 mm incl. connectors

Download Guppy technical drawing (click here)

http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy/f-036bc.html 2

Smart features

●

Programmable LUT

●

Gain

❍

Auto/manual

❍

Manual gain control: 0 - 12 dB

●

Exposure

❍

Exposure time: 179 µs - 979 ms

●

Image mirror

●

Binning (b/w)

●

HDR mode (High Dynamic Range mode)

http://www.alliedvisiontec.com/emea/products/cameras/firewire/guppy/f-036bc.html 3

Applications

The CMOS sensor of the Guppy F-036B/B has no blooming and supports the HDR (High
Dynamic Range) mode. For this reason, this FireWire camera is made for applications with
intense illumination and high contrasts.

●

Surveillance and Security

●

Inspection and Control

●

Robotics

●

ITS/Traffic monitoring

●

Applications with high contrasts
