Key Features
Performance
• Layer 2 and 3 switching and routing at
wire-speed
• Full IPv4 routing
• IPv6 routing option
• Built from a 168Gbps switch fabric yielding
71.4 Million packets per second performance
(x900-24X)
• Provides up to 256K IPv4 route entries
• Supports full 4096 VLANs
• Supports 4096 Layer 3 interfaces
• VLAN double tagging
• Private VLANs, providing security and port
isolation of multiple customers using the
same VLAN
• Supports 10KB Jumbo frame size for data
center and server aggregation applications
• Gigabit SFP ports will support any
combination of 10/100/1000BASE-T,
100BASE-X, or 1000BASE-X SFPs
• Extensive wire-speed traffic classification for
ACLs and QoS
• Advanced routing protocols OSPF, BGP-4, RIP,
RIPv2, RIPng,PIM-SM.
• DHCP Option 82
• Wire-speed multicasting
Reliability and Future Proofing
• 60Gbps expansion bays support a choice of
modules, including 1x 10GbE, 12 x 1GbE
(SFP), 12 x 1GbE (RJ45), and stacking, for
port flexibility and application versatility
• 1RU form factor, high port density and
front-to-back cooling, ideal for high density
rack and wiring closet installations
• For the x900-24X: Eliminates the need for
redundant power supplies by providing
power supplies that are hot-swappable and
load-sharing
• Full environmental monitoring of PSUs, fans,
temperature and internal voltages, with
SNMP traps to alert network managers in
case of any failure
Quality of Service
• Policy based QoS features
• Highly configurable traffic classification
• Buffered multiple packet remarking options
at egress on all ports, and on each of 8
egress queues per port
• Two-rate three-color (green, yellow, red)
bandwidth metering
• Low switching latency essential for Voice over IP
(VoIP) and real-time streaming media applications
Resiliency
• Stack multiple units with the XEM-STK
2
• STP, RSTP, MSTP (802.1s)
• Port trunking (802.3ad LACP)
• VRRP
• EPSR
Management
• Out of band 10/100/1000 Ethernet
management port and asynchronous
management port, both on the front panel
for ease of access
• An SD memory card socket on the front
panel, allowing software release files,
configurations and other files to be stored for
backup and distribution to other switches
• Port mirroring
• SSH and SNMPv3 for secure management
• 802.1x support
• RMON (4 groups)
1
NEBS (Network Equipment Building System) is a series
of safety and conformance standards applied to
telecommunications equipment in North America.
2
AlliedWare Plus software release 5.2.1 supports
stacking of 2 x900-24X units. Support for more than 2
x900-24X units and the x900-12XT/S will be in a
future release.
Allied Telesis www.alliedtelesis.com
Datasheet | Switches
X900-12X AND 24X SERIES
Advanced Gigabit Layer 3+ Expandable Switches
Datasheet | Switches
x900-24XT
2 x 60Gbps expansion bays
24 x 10/100/1000BASE-T (RJ-45) copper ports
x900-24XT-N
NEBS Compliant
1
2 x 60Gbps expansion bays
24 x 10/100/1000BASE-T (RJ-45) copper ports
x900-24XS
2 x 60Gbps expansion bays
24 x 100/1000BASE-X SFP ports
x900-12XT/S
1 x 60Gbps expansion bay
12 x combo ports (10/100/1000BASE-T
copper or SFP)
Unmatched Flexibility
The x900 Layer 3+ switches have high-speed
60Gbps expansion bays which provide a high level
of port flexibility and application versatility
unmatched by any other 1RU Gigabit Ethernet
switch on the market.The expansion modules can
be used in a variety of configurations to provide
tailored solutions that meet wide-ranging physical
networking requirements.
10GbE expansion modules and hot-swappable
XFPs provide high-speed, high-capacity fiber
uplinks, with the option of either 10Gbps or
20Gbps uplink capacity to the network core.
Resiliency can be achieved by using 10GbE
modules and MSTP (802.1s) for fast failover on link
failure.This is suitable for wiring closet aggregation
of gigabit to the desktop links and aggregating
gigabit uplinks from other network switches.
Ethernet Protected Switched Rings (EPSR) and
10 GbE modules allow several x900-24X
switches to form a protected ring with sub
50ms failover. This feature is perfect for high
performance at the core of enterprise or
provider access networks.
Continued on next page
NEBS
COMPLIANT
AlliedWare Plus
OPERATING SYSTEM
TM
Allied Telesis www.alliedtelesis.com
X900-12X AND 24X SERIES
| Advanced Gigabit Layer 3+ Expandable Switches
Combined with one or two 12-port
10/100/1000BASE-T (RJ-45) copper expansion
modules, the x900 is ideal for gigabit to the
desktop or gigabit aggregation applications.The
12 x 100/1000BASE-X (SFP) expansion
modules offer variable port options, designed
for aggregating mixed copper and fiber links in
server farms and data center applications.
x900 Layer 3+ switches provide maximum
Gigabit Ethernet port density in a compact
1RU chassis.Their high degree of flexibility
future-proofs your investment against changes
in network infrastructure, topologies, and
physical link requirements.
Reliability
Dual hot-swappable AC or -48V DC loadsharing power supplies packaged in the
x900-24X 1RU rack mount chassis, provide the
ultimate in space saving, reliability and resiliency.
These features, combined with front-to-back
cooling, make the x900 series perfect for the
high-density rack environment where space is at
a premium.
Policy-Based Quality of Service
Comprehensive, low latency Quality of Service
(QoS) features operating at wire-speed provide
flow-based traffic management with full
classification, prioritization, traffic shaping and
min/max bandwidth profiles.The x900 QoS
features are ideal for service providers wanting
to ensure maximum availability of premium
voice, video and data services, and at the same
time manage customer service level
agreements. For enterprise customers, the x900
QoS features protect productivity by
guaranteeing performance of business-critical
applications (including VoIP services), and help
to restore and maintain responsiveness of
enterprise applications in the workplace.
Performance
The x900-24X is a powerful Layer 3+ switch
with a 168Gbps switching fabric, achieving wirespeed switching and routing performance with a
forwarding rate of 71.4Mpps. It can support up
to two wire-speed 10GbE ports for high
performance, high capacity network applications.
The x900-12XT/S is a powerful Layer 3+ switch
with a 84Gbps switching fabric, achieving wirespeed switching and routing performance with a
forwarding rate of 35.7Mpps. It supports a
10GbE port for high performance, high capacity
network applications.
Hardware Performance
Up to 256K IPv4 routes
Up to 16K MAC addresses maximum
Up to 4K layer 2 multicast groups
Up to 1K layer 3 IPv4 multicast groups
4K VLANs
512MB SDRAM
Separate packet buffer memory
64MB Flash Memory
Switching Fabric
• x900-24X 168Gbps
• x900-12XT/S 84Gbps
Forwarding Rate:
• x900-24X 71.4Mpps
3
• x900-12XT/S 35.7Mpps
4
Reliability
MTBF
x900-24X
With 1 PSU and 1 fan module: 93,700 hours
With 2 PSUs: 249,400 hours
(calculated using Telcordia SR-332 (Issue 1, May
2001) at 25°C ambient operating temperature)
x900-12XT/S
MTBF 103,000 hours
Power Characteristics
AC Voltage: 100 to 240V (+/-10% auto ranging)
Frequency: 47 to 63Hz
DC Voltage: 40 to 60V
Power Consumption
x900-24X
With 1 PSU and 1 fan module:
110 Watts (375 BTU/hr)
With 2 PSUs and 2 XEM-1XP modules:
191 Watts (652 BTU/hr)
x900-12XT/S
With 1 XEM-12: 104 Watts (355 BTU/hr)
With no XEM: 68 Watts (232 BTU/hr)
Environmental Specifications
Operating Temperature Range:
0°C to 40°C (32°F to 104°F)
Derated by 1°C per 305 Meters (1000ft)
Storage Temperature Range:
-25°C to 70°C (-13°F to 158°F)
Operating Relative Humidity Range:
5% to 80% non-condensing
Storage Relative Humidity Range:
5% to 95% non-condensing
Altitude:
3,050 Meters maximum (10,000ft)
Physical Dimensions
Height: 44.5mm (1.75")
Width: 440mm (16.7")
Depth: x900-24X: 440mm (16.7")
5
x900-12XT/S: 350mm (13.2")
5
Mounting: 19" rack mountable, 1RU form-factor
Weights
x900-24X:
With 1 PSU and 1 fan module:
7.3kg (16.1lbs), and 8.8kg (19.4lbs) packaged.
With 2 PSUs and 2 XEM-1XP
modules:
9.3kg (20.5lbs), and 10.8kg
(23.8lbs) packaged
x900-12XT/S:
No XEM: 5.3kg (11.6lbs), and 7.9kg (17.3lbs)
packaged
With XEM-1XP fitted: 6.0kg (13.2lbs), and 8.6kg
(18.9lbs) packaged
AT-PWR01 (AC or DC):
1.0kg, and packaged 1.8kg (3.9lbs)
(AC) or 1.5kg (3.3lbs) (DC)
AT-FAN01:
0.6kg (1.3lbs), and 1.4kg (3.1lbs) packaged
Electrical Approvals and Compliances
EMC: EN55022 class A, FCC class A,VCCI
class A
Immunity: EN55024, EN61000-3 levels 2
(Harmonics), and 3 (Flicker)
– AC models only
NEBS: GR63, GR1089 level 3
x900-24XT-N and XEM-12S.
Safety
Standards: UL60950-1, CAN/CSA-C22.2 No.
60950-1-03, EN60950-1,
EN60825-1, AS/NZS 60950.1
Certification: UL, cUL,TUV
Restrictions on Hazardous Substances
(RoHS) Compliance
EU RoHS Compliant
Country of Origin
Singapore
3
With two 12 x 1GbE expansion modules
(SFP or RJ45) installed.
4
With one 12 x 1GbE expansion modules
(SFP or RJ45) installed.
5
This depth measurement excludes the PSU handles.
