Allied Telesis AR442S, AR440S, AR441S, AR415S, AR450S User Manual
AR400 Series Router
Installation and Safety Guide
AR415S
AR440S
AR441S
AR442S
AR450S
AR400 Series Router
Installation and Safety Guide
AR415S
AR440S
AR441S
AR442S
AR450S
2 AR400 Series Router
AR400 Series Installation and Safety Guide
Document Number 613-000313 Rev D.
Copyright © 2004-2011 Allied Telesis Inc. All rights reserved. No part of this
publication may be reproduced without prior written permission from Allied
Telesis, Inc.
Allied Telesis, Inc. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The
information provided herein is subject to change without notice. In no event
shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or
consequential damages whatsoever, including but not limited to lost profits,
arising out of or related to this manual or the information contained herein,
even if Allied Telesis has been advised of, known, or should have known, the
possibility of such damages.
All company names, logos, and product designs that are trademarks or
registered trademarks are the property of their respective owners.
613-000313 Rev D
Installation and Safety Guide 3
Table of Contents
Models Covered By This Guide ........................................................................................... 4
Package Contents .................................................................................................................... 4
AR415S Router ........................................................................................................................ 6
Installing the AR415S .......................................................................................................6
Configuring the AR415S .................................................................................................9
Connecting Data Cables to AR415S ......................................................................... 13
System LEDs on AR415S ............................................................................................. 14
AR440S, AR441S, AR442S Routers .................................................................................. 15
Installing the AR440S, AR441S, AR442S .................................................................. 15
Configuring the AR440S, AR441S, AR442S ............................................................ 19
Connecting Data Cables to AR440S, AR441S, AR442S ....................................... 25
System LEDs on AR440S, AR441S, AR442S ........................................................... 26
AR450S Router ...................................................................................................................... 27
Installing the AR450S .................................................................................................... 27
Configuring the AR450S .............................................................................................. 29
Connecting Data Cables to the AR450S ................................................................. 33
System LEDs on the AR450S ...................................................................................... 34
Default Configuration on AR440S, AR441S, AR442S ................................................... 35
Documentation and Tools CD-ROM ................................................................................ 36
Connection to mains voltage supply ................................................................................. 37
Telecommunications Interfaces .......................................................................................... 37
Safety ........................................................................................................................................ 39
Sicherheit ................................................................................................................................. 40
Sikkerhed ................................................................................................................................. 41
Veiligheid .................................................................................................................................. 42
Sécurité .................................................................................................................................... 43
Turvallisuus .............................................................................................................................. 44
Norme di Sicurezza ............................................................................................................... 45
Sikkerhet .................................................................................................................................. 46
Segurança ................................................................................................................................. 47
Seguridad ................................................................................................................................. 48
Säkerhet ................................................................................................................................... 49
US Federal Communications Commission (FCC) ......................................................... 50
Canadian Department of Communications ..................................................................... 51
Emission Compliance Statements ...................................................................................... 52
613-000313 Rev D
4 AR400 Series Router
Models Covered By This Guide
This Installation and Safety Guide includes information on these models:
■ AR415S
■ AR440S
■ AR441S
■ AR442S
■ AR450S
You can download updates to this document from
www.alliedtelesis.com/support/documentation/
Package Contents
Before beginning any installation, please check the package contents. Contact your
authorised Allied Telesis distributor or reseller if any items are damaged or missing.
AR415S
■ one AR400 Series router
■ one AC power cord
■ one power cord retaining clip
■ one serial cable for connecting the router to a terminal or PC
■ two UTP network cables
■ one 19 inch rack-mount kit
■ one AR400 Series Router Installation and Safety Guide
■ one AR400 Series Router Documentation and Tools CD-ROM (includes the
complete AR400 Series Document Set and utilities)
■ one warranty card
613-000313 Rev D
Installation and Safety Guide 5
AR440S, AR441S and AR442S
■ one AR400 Series router
■ one AC power cord
■ one power cord retaining clip
■ one serial null modem cable for connecting the router to a terminal or PC
■ two UTP network cables
■ one DSL cable
AR440S: two in Australia and New Zealand
■ one 19 inch rack-mount kit
■ one AR400 Series Router Installation and Safety Guide
■ one AR400 Series Router Documentation and Tools CD-ROM (includes the complete
AR400 Series Document Set and utilities)
■ one warranty card
AR450S
■ one AR400 Series router
■ one AC power cord
■ one power cord retaining clip
■ one serial null modem cable for connecting the router to a terminal or PC
■ two UTP network cables
■ one 19 inch rack-mount kit
■ one AR400 Series Router Installation and Safety Guide
■ one AR400 Series Router Documentation and Tools CD-ROM (includes the complete
AR400 Series Document Set and utilities)
■ one warranty card
To install your router, see:
■ “AR415S Router” on page 6
■ “AR440S, AR441S, AR442S Routers” on page 15.
■ “AR450S Router” on page 27
613-000313 Rev D
6 AR400 Series Router
AR415S Router
This section describes how to install the AR415S router.
■ “Installing the AR415S” below
■ “Configuring the AR415S” on page 9
■ “Connecting Data Cables to AR415S” on page 13
■ “System LEDs on AR415S” on page 14
For corresponding information about installing an AR440S, AR441S or AR442S, see
“AR440S, AR441S, AR442S Routers” on page 15.
For corresponding information about installing an AR450S, see “AR450S Router” on
page 27.
Installing the AR415S
Selecting a Site
You can install the router:
■ on a level surface such as a desktop or bench
■ in a standard 19-inch rack, using the rack-mount kit supplied with the router
When you install the router, choose a site that:
■ allows adequate airflow around the router and its vents
■ is free of dust and moisture
■ will maintain an ambient temperature in the range 0 ºC to 40 ºC
ºF to 104 ºF)
(32
■ will maintain a humidity in the range 5% to 80% non-condensing
■ has a reliable and earthed (grounded) power supply, preferably dedicated and
filtered
■ does not expose cabling to sources of electrical noise such as radio transmitters,
broadband amplifiers, power lines, electric motors, and fluorescent fixtures
■ allows easy access to the router’s power and cable connections
Before Installing the Router
■ Read the safety information “Safety” on page 39.
■ Unpack the router. Verify the package contents. If any items are damaged or
missing, contact your sales representative.
613-000313 Rev D
Installation and Safety Guide 7
Installing an Optional PIC
If you purchased an optional PIC, install it now by following the Port Interface Card
Quick Install Guide. The PIC Quick Install Guide can be found with the PIC, on the
Documentation and Tools CD-ROM, or can be downloaded from
www.alliedtelesis.com/support/documentation/
Installing the Router in a Rack
1. Gather additional items. You will need:
• the rack-mount kit (in your router package, or ordered from your authorised
Allied Telesis distributor or reseller)
• a Phillips #1 screwdriver
• screws and cage nuts to attach the brackets to your rack
2. Check the rack.
Ensure that the rack is safely secured and that it will not tip over. Devices in a
rack should be installed starting at the bottom, with the heavier devices near the
bottom of the rack.
Ensure the rack has sufficient space for the router and its associated cables. The
router is 1U high.
3. Unscrew the feet from the router.
4. Connect the handles to the brackets.
Screw the handles to the wider side of each bracket, using the supplied screws
(see figure below).
5. Connect the brackets to the router.
Screw the brackets to the sides of the router, using the supplied screws (see
figure below). The router can be front or rear mounted.
Rmount
613-000313 Rev D
8 AR400 Series Router
6. Mount the router in the rack.
Use appropriate rack mounting screws (not supplied).
Applying Power to the Router
1. Check the supply voltage and the router’s rated voltage.
AR400 Series routers are fitted with a universal mains power supply that will
function over the range 100 VAC to 240 VAC and 50 Hz to 60 Hz.
For continued protection against the risk of fire and shock hazard, replace fuses
only with the same type and rating.
Warning The specific power supply requirements for a particular model are
clearly displayed on the rear or underside of the router. If the supply is outside
the accepted range for the router, the router may not operate or damage to
the router may result.
2. Fit the power cord retaining clip to the AC power inlet on the router’s rear panel.
3. Connect the provided power cord to the AC power inlet and clip it in place.
Switch the router’s power switch to the ON position. The Power LED lights
continuously and the System LED lights briefly. The Port LEDs also light briefly.
The router is supplied with an approved power cord that incorporates a
moulded plug. It must only be used with the power cord supplied.
If the LEDs fail to light, the most likely cause is that the router is not receiving
power. Check that:
■ the power supply outlet’s switch (if any), and the router’s power switch, are in
the ON position
■ the power cable is securely plugged in
■ the power supply is operational
613-000313 Rev D
Installation and Safety Guide 9
Configuring the AR415S
You can configure the router via the command line interface (CLI) or the graphical
user interface (GUI). First use the CLI to assign an IP address to the router, then use
the CLI or the GUI to complete the configuration.
■ “Using the CLI to configure the AR415S” below
■ “Using the GUI to configure the AR415S” on page 11
Using the CLI to configure the AR415S
This section describes how to access the router’s command line interface (CLI)
using a terminal or PC connected to the router’s console port.
1. Initiate router start-up.
Using the terminal cable supplied, connect a VT100-compatible terminal, or the
COM port of a PC running a terminal emulation program such as Windows
Hyper Terminal, to the Console RS-232 (ASYN0) port on the router’s rear
panel.
Set the communication parameters on your terminal or terminal emulation
program to:
• Baud rate: 9600
• Data bits: 8
•Parity: None
• Stop bits: 1
• Flow control: Hardware
See the AR400 Series Router Hardware Reference for more information on
configuring emulation software.
613-000313 Rev D
10 AR400 Series Router
2. Log in and set the password.
The login prompt appears on the terminal or PC. If the login prompt does not
appear, press [Enter] two or three times.
When the router boots for the first time it automatically creates an account
with manager privileges. The account has the user name “manager” and the
password is “friend”. Passwords are case sensitive.
At the login prompt, enter the user name and password.
Login: manager
Password: friend
The router’s command prompt appears and you can now configure the router
using the command line interface.
Warning Change the password as soon as possible. Leaving the manager
account with the default password is a serious security risk. Make sure you
remember the new password as there is no way to retrieve it if it is lost.
Use the following command to change the account password:
set password
3. Configure the router.
See the AR400 Series Router Software Reference for more information on router
start-up and configuration procedures (including a list of message definitions). To
continue configuring the router using the CLI, use the commands in the
Software Reference.
To display a list of help topics, enter:
help
To display help on a specific topic, enter:
help topic
Alternatively, type a question mark (?) at the end of a partially completed
command to see a list of valid options.
4. Save the configuration.
Save your configuration to a new file by using the command:
create config=filename.cfg
Then set the router to load this file when it restarts by using the command:
set config=filename.cfg
We recommend leaving the boot.cfg file unchanged, in case you need to revert
to the original default configuration.
To continue configuring the router using the GUI, see the following section.
613-000313 Rev D
Installation and Safety Guide 11
PC
router
switch ports
straight-through cable
POWER
ETH0
ASYN0
SWITCH PORTS
PIC BAY
31
42
POWER
100-240 VAC
50/60 Hz
2.1 A
ON
OFF
PC
router
switch ports
hub or layer 2
switch
3421
10BASE-T/100BASE-TX SWITCH PORTS
POWER
ON
OFF
POWER
ETH0
ASYN0
SWITCH PORTS
PIC BAY
31
42
POWER
100-240 VAC
50/60 Hz
2.1 A
ON
OFF
Using the GUI to configure the AR415S
This section describes how to access the GUI via a switch port in VLAN1 on the
AR415S router, when the PC and the router are in the same subnet, in order to
configure the router. The router’s switch ports all belong to VLAN1 by default.
The GUI requires a PC and web browser. Supported browsers are Internet Explorer
5.0 or later and Netscape 6.2.2 or later, with JavaScript enabled. If you are using a
toolbar or plug-in on your browser to block pop-ups, disable it while using the GUI.
The GUI displays detailed configuration options and information in pop-up windows.
1. Connect the PC to a router switch port.
The PC can be connected either directly or through your LAN.
To connect the PC directly to the router, use a straight-through Ethernet cable
to connect an Ethernet card on the PC to any one of the router’s switch ports.
Note the PC’s IP address and mask.
To connect via a LAN, use an Ethernet cable to connect the router’s switch
port(s) to the device(s) on the LAN. Select the LAN PC from which you wish to
configure the router. The PC should be in the same subnet as the part of the
LAN that contains the router (for example, the PC could be connected to a hub
or Layer 2 switch that is directly connected to one of the router’s switch ports).
Note the PC’s IP address and mask.
2. Access the CLI on the router.
613-000313 Rev D
Follow the instructions in the previous section “Using the CLI to configure the
AR415S” on page 9.
12 AR400 Series Router
3. Enable IP.
In the CLI, enter the command:
enable ip
4. Assign an IP address to VLAN1.
Assign the VLAN1 interface an IP address in the subnet that the PC uses, using
the command:
add ip interface=vlan1 ip=ipaddress mask=mask
5. Browse to the GUI.
If you access the Internet through a proxy server, set your browser to bypass
the proxy for the IP address you assigned to the VLAN1 interface.
Point your web browser at the IP address of the VLAN interface.
6. Log in and set the password.
At the log in prompt, enter the log in name and password. Passwords are case
sensitive.
User Name: manager
Password: friend
The system status page appears and you can now use the GUI to configure the
router.
Important To ensure configuration settings are saved correctly, use the GUI
menus and buttons to navigate, not your browser’s buttons.
Caution As a security precaution, change the password as soon as
possible.
To change the password, select Management > Users from the sidebar menu.
Select the Manager account and click Modify.
7. Configure the router.
Use the GUI to continue configuring your router. To access context-sensitive
help in the GUI, click on the Help button [Help]. The Help button is located at
the top of the sidebar menu or on any popup page.
613-000313 Rev D
Installation and Safety Guide 13
Connecting Data Cables to AR415S
Connecting the router to your network:
1. Connect to the LAN
If you have not already done so, use straight-through Ethernet patch cables to
connect the device(s) on your private network (LAN) to the router’s switch
port(s). By default, all switch ports are members of VLAN1.
2. Connect to the WAN.
Caution If you intend to use a firewall, configure it before you activate
the WAN link.
Once initial configuration is complete, connect the router to the WAN:
• Connect a PIC port to a WAN connection. See the Port Interface Card Quick
Install Guide and Hardware Reference.
• Use an Ethernet patch cable to connect the router’s Ethernet WAN (ETH0)
port to the Ethernet port of a WAN device (such as a modem).
613-000313 Rev D
14 AR400 Series Router
System LEDs on AR415S
The LEDs described in the following table show the operational status and port
activity for the AR415S router.
LED State Function
PWR Green The router is receiving power and the power
switch is ON.
SYS Amber Lit briefly during router start up, or the router is
malfunctioning.
Off Normal operation.
PIC 0 Green A port interface card (PIC) is correctly installed
and has been detected by the router.
Off No PIC is installed, or the router has not
recognised the PIC.
Full Green The link is in full-duplex mode.
Off The link is in half-duplex mode.
L/A
100M
Green A link has been established.
Flashing Data is being transmitted.
Off There is no link.
Green The link is at 100 Mbps speed.
Off The link is at 10 Mbps speed.
613-000313 Rev D
Installation and Safety Guide 15
AR440S, AR441S, AR442S Routers
This section describes how to install the AR440S, AR441S and AR442S routers.
■ “Installing the AR440S, AR441S, AR442S” below
■ “Configuring the AR440S, AR441S, AR442S” on page 19
■ “Connecting Data Cables to AR440S, AR441S, AR442S” on page 25
■ “System LEDs on AR440S, AR441S, AR442S” on page 26
For corresponding information about installing an AR415S, see “AR415S Router” on
page 6.
For corresponding information about installing an AR450S, see “AR450S Router” on
page 27.
Installing the AR440S, AR441S, AR442S
Selecting a Site
You can install the router:
■ on a level surface such as a desktop or bench
■ in a standard 19-inch rack, using the rack-mount kit supplied with the router
■ on a firm wall, using a wall-mount kit ordered from your authorised Allied
Telesis distributor or reseller
When you install the router, choose a site that:
■ allows adequate airflow around the router and its vents
■ is free of dust and moisture
■ will maintain an ambient temperature in the range 0 ºC to 50 ºC
ºF to 122 ºF)
(32
■ will maintain a humidity in the range 5% to 80% non-condensing
■ has a reliable and earthed (grounded) power supply, preferably dedicated and
filtered
■ does not expose cabling to sources of electrical noise such as radio transmitters,
broadband amplifiers, power lines, electric motors, and fluorescent fixtures
■ allows easy access to the router’s power and cable connections
Before Installing the Router
■ Read the safety information “Safety” on page 39.
■ Unpack the router. Verify the package contents. If any items are damaged or
missing, contact your sales representative.
613-000313 Rev D
16 AR400 Series Router
Installing an Optional PIC
If you purchased an optional PIC, install it now by following the Port Interface Card
Quick Install Guide. The PIC Quick Install Guide can be found with the PIC, on the
Documentation and Tools CD-ROM, or can be downloaded from
www.alliedtelesis.com/support/documentation/
Installing the Router in a Rack
1. Gather additional items. You will need:
• the rack-mount kit (in your router package, or ordered from your authorised
Allied Telesis distributor or reseller)
• a Phillips #1 screwdriver
• screws and cage nuts to attach the brackets to your rack
2. Check the rack.
Ensure that the rack is safely secured and that it will not tip over. Devices in a
rack should be installed starting at the bottom, with the heavier devices near the
bottom of the rack.
Ensure the rack has sufficient space for the router and its associated cables. The
router is 1U high.
3. Unscrew the feet from the router.
4. Connect the handles to the brackets.
Screw the handles to the wider side of each bracket, using the supplied screws
(see figure below).
5. Connect the brackets to the router.
Screw the brackets to the sides of the router, using the supplied screws (see
figure below). The router can be front or rear mounted.
613-000313 Rev D
Loading...
