Washer-Extractor

Refer to Page 4 for Model Numbers

Programming

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

www.comlaundry.com

Part No. F8208801R6

April 2012

NOTE: The WARNING and IMPORTANT

Failure to install, maintain, and/or operate this machine according to the manufacturer's instructions may result in conditions which can produce bodily injury and/or property damage.

W030

WARNING

instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution, and carefulness are factors which cannot be built into these machines. These factors MUST BE supplied by the person(s) installing, maintaining, or operating the machine.

Always contact the distributor, service agent, or the manufacturer about any problems or conditions you do not understand.

Table of Contents

Model Identification ........................................................................... 4

Preliminary Information.................................................................... 5

About the Control.......................... ..... .................................................. 5

Glossary of Terms................................................................................. 5

Power Failure Recovery ....................................................................... 5

Communications................................................................................... 5

Control Identification......................................................................... 6

Select Cycle Pads.................................................................................. 6

Display Identification ......................................................................... 7

Light Emitting Diodes (LEDs)............................................................. 7

Machine Operation............................................................................. 8

Start Up................................................................................................. 8

Door Locking Mode ............................................................................. 8

Stop Mode............................................................................................. 8

Start Mode ............................................................................................ 8

End of Cycle Mode............................................................................... 8

Cycle Sequence..................................................................................... 8

Run Mode ............................................................................................. 8

Signals................................................................................................... 8

Special Features.................................................................................. 9

Programming Control........................................................................... 9

Collecting Audit Information ............................................................... 9

Testing Machine and Control Functions............................................... 9

Rapid Advance Feature......................................................................... 9

Communications Mode......................................................................... 9

Entering the Manual Mode................................................................ 10

How to Enter the Manual Mode ........................................................... 10

Manual Diagnostics.............................................................................. 10

Programming Control........................................................................ 11

What Can Be Programmed? ........................................................ .... ..... 11

Programmable Options Available......................................................... 11

Manual Mode Flowchart....................................................................... 14

Manual Programming Flowchart (1 of 3)............................................. 15

Manual Programming Flowchart (2 of 3)............................................. 16

Manual Programming Flowchart (3 of 3)............................................. 17

Diagnostic Tests Flowchart .................................................................. 18

1. Default Cycle “dCYC” ............................................................... 19

2. Audio Signal “AUd” .............................................................. ..... 20

3. Error Code Programming “Err-” ................................................. 22

4. Cycle Programming “Cy--” ........................................................ 26

5. Number of Balance Retries “bALr” (Variable Frequency

Drives Only) ................................................................................ 30

6. IR Access (On/Off) “IrA” ........................................................... 31

7. Fahrenheit/Celsius “t FC” ........................................................... 31

8. Hot Water Temperature “FH” ..................................................... 32

9. Warm Water Temperature “FHC” .............................................. 32

F8208801

10. Cold Water Temperature “FC” ................................................... 33

11. Cooldown Enable/Temperature “Codn” ..................................... 33

12. Production Test Cycle (On/Off) “PtEn” ..................................... 34

13. Manual Rapid Advance (On/Off) “rAEn” .................................. 34

14. No Cycle Time Display “nCtd” .................................................. 35

15. Programmable Cycle Time Display “PCtd” ............................... 35

16. Slow Drain Detection Adjust “SdAd” ........................................ 36

17. Set Real-Time Clock “rtC-”’ ...................................................... 37

18. Manual Diagnostics (On/Off) “dAEn” ....................................... 38

19. Low Water Level “FLo” ............................................................. 38

20. Medium Water Level “FnEd” ....................................... ..... .... ..... 39

21. High Water Level “FHI” ............................................................. 39

22. Temperature Controlled Fill Enable/Disable “tCF” ................... 40

23. Auto-Water Leak Detection “ALd” ............................................ 41

Collecting Audit Information ............................................................ 42

Manual Reset....................................................................................... 43

Testing Machine and

Electronic Control Functions............................................................. 44

Diagnostic Test Descriptions................................................................ 46

Production Test Cycle.................................................... ....................... 49

Error Codes......................................................................................... 52

Rapid Advance Feature...................................................................... 55

Communications Mode ...................................................................... 56

Infra-red Communications.................................................................... 56

Default Cycles...................................................................................... 57

F8208801

Model Identification

Information in this manual is applicable to these machine models:

UWL035K12 UWL065K2M UWN060K1M UWU045K2L UWL035K1L UWL080K1M UWN065K1L UWU045K2M UWL035K1M UWL100K1M UWN065K1M UWU060K12 UWL045K1L UWL125K1M UWN065K2L UWU060K1L UWL045K1M UWN035K12 UWN065K2M UWU060K1M UWL045K2L UWN035K1L UWN080K1M UWU065K1L UWL045K2M UWN035K1M UWN100K1M UWU065K1M UWL060K12 UWN045K1L UWN125K1M UWU065K2L UWL060K1L UWN045K1M UWU035K12 UWU065K2M UWL060K1M UWN045K2L UWU035K1L UWU080K1M UWL065K1L UWN045K2M UWU035K1M UWU100K1M UWL065K1M UWN060K12 UWU045K1L UWU125K1M UWL065K2L UWN060K1L UWU045K1M

F8208801

Preliminary Information

About the Control

This control is an advanced, programmable computer that lets the owner control most machine features by pressing a sequence of keypads. Refer to Figure 1.

The control allows the owner to program custom cycles, retrieve audit information, run diagnostic tests, and other programmable features. Refer to Programming Control for a list of features. Machines shipped from the factory have a default cycle of Cycle #5 built in. However, the owner can change the default cycle, or any cycle, as needs permit.

IMPORTANT: In the event of a power failure, the control will not have to be reprogrammed. It is designed with a memory system that will remember how it was programmed until the electrical power is restored.

IMPORTANT: It is extremely important that the machine has a good ground connection and that all mech a ni c al and electrical connections to the contr ol are made before applying power to or operating the machine.

Glossary of Terms

The following are a few terms and abbreviations to learn. These are referred to throughout the instructions.

Power Failure Recovery

If a cycle is in progress and the power fails for less than five seconds, the cycle status is saved in memory. When the power recovers, the machine will resume into the previously active cycle.

If the length of the power failure is greater than five seconds, the control will end the cycle and the display will revert back to Start Mode.

Communications

The control may be programmed manually or by infrared communication with an external device.

Infra-red Communications

An external device, such as a PDA, allows the owner to program and retrieve information from the control without touching the keypad. An external device greatly expands the programming options available to the owner. However, it is not required to program and operate the machine. The operation of an external device and the advanced features available are covered separately in the instructions included with the external device software. Contact Alliance Laundry Systems for a list of approved PDAs and o ther external devices.

Display – This term refers to the window area of the

control that displays words and values.

LED (Light Emitting Diode) – This term refers to the

lights next to the keypads and status words of the control.

F8208801

Control Identification

Select Cycle Pads (Refer to Figure 1)

SELECT CYCLE pads are used to select the specific washer cycle. These pads are numbered 0-9 and allow the user to select a cycle other than the default cycle (#5). The SELECT CYCLE keypads are not active after a cycle has been started. Pressing the flashing START pad will confirm the selection and the cycle will begin.

The SELECT CYCLE pads are used in va rious combinations for programming cycles, retrieving audit information, running diagnostic tests, and other operations. These instructions cover the manual programming and data retrieval options.

1 SELECT CYCLE pads 2 Display 3 Four 7-Segment Digits 4 STOP UNLOCK pad 5 START pad 6 LED Light 7 LED Status Lights

PHM1263R

Figure 1

F8208801

Display Identification

Light Emitting Diodes (LEDs) (Refer to Figure 1)

Light Emitting Diodes (LEDs) are used to indicate the chosen cycle, cycle status, when the bleach compartment is dispensing, and door lock information. See below for information on each LED.

WASH LED

Wash LED is lit at the beginning of a wash portion of the cycle and will remain lit until the wash is complete.

RINSE LED

Rinse LED is lit at the beginning of a rinse portion of the cycle and will remain lit until the rinse is complete.

SPIN LED

Spin LED is lit during the Final Spin portion of the cycle.

DOOR LED

Door LED is lit whenever the door is locked.

Four 7-Segment Digits

The 7-Segment Digits are used to display the time remaining in a cycle, error messages and descriptive codes. During diagnostic testing or manual programming of the control, these digits will display descriptive codes and values (as described in Entering the Manual Mode).

F8208801

Machine Operation

Start Up

When power is applied to the machine, the control will display its software version as “S xx” (“xx” is the version number) for one second. If the control was not powered down during a running cycle, it will enter Star t Mode.

Door Locking Mode

The control enters this mode after the START (enter) keypad is pressed in Start Mode. The control stays in Door Locking Mode until it confirms the door is closed and locked.

Stop Mode

The control enters this mode if the user stops the cycle by pressing the STOP keypad. If control does not detect water or cylinder rotation it will enter End Of Cycle Mode.

Start Mode

The control enters this mode when machine is ready for operation. The display will show “CYxx” where “xx” is the cycle number.

After pressing the START keypad, with the door closed and locked, the cycle will begin. The cycle cannot be changed once the cycle has st arte d.

Run Mode

The control enters this mode when a cycle is running. The time remaining appears in the display , the status LED’s are lit and the loading door is locked.

Signals

There are two options when a signal can be used during the machine operation. These two options are listed below:

1. End of Cycle Signal

By default, this signal is turned off. If turned on, the signal sounds for three (3) seconds at the end of a cycle.

2. Signal On Keypad Depression

By default, this signal is turned on and sounds for a quarter of a second each time a keypad is pressed.

NOTE: Refer to Programming Control to program signal options.

End of Cycle Mode

When a cycle is complete, the control will display “00” and will prompt for door unlock by flashing STOP/ UNLOCK LED until the machine door is unlocked and opened. When this event occurs, the display will revert back to Start Mode.

Cycle Sequence

Upon the start of a cycle, the control will display the total cycle time. The appropriate LEDs will light while the machine passes through different cycle steps. The user will not be able to change cycles or water temperature.

F8208801

Special Features

Programming Control

The control allows the machine owner to program the control with the use of the keypad. Cycle options may be programmed, audit information may be viewed and diagnostic tests may be run by pressing combinations of the select cycle keypads.

For details on programming select cycle options, refer to Programming Control.

Collecting Audit Information

The control will store audit information in its memory that can be retrieved by pressing various combinations of Select Cycle keyp a d s . The control will record total machine cycles.

For more information on the audit features, refer to Collecting Audit Information.

NOTE: Additional audit information is retrievable with an external device, using infra-red communications. Refer to the appropriate instruction manual.

Testing Machine and Control Functions

Special diagnostic features built into the control allow the owner to run specific diagnostic tests. By opening and closing the top cover and then pressing various sequences of Select Cycle keypads, the owner may retrieve or perform the following tests:

• Drive Parameter Table Version Number (Design 4 models only)

• Drive Type (Design 4 models only)

For detailed information on running diagnostic tests, refer to Testing Machine and Control Functions.

Rapid Advance Feature

This feature allows the user to quickly advance through active cycles. This feature is useful when tests must be performed immediately on a machine currently in an active cycle. In this case, the user can quickly advance through the cycles to shakeout. At this point, the user can perform the required tests and then return the machine to the point it was interrupted.

For detailed information on using the Rapid Advance feature, refer to Rapid Advance Feature.

Communications Mode

This feature allows the control to communicate with an external device using infra-red communications. This allows the control to be programmed and have its data read without using the keypad.

For more detailed information on using the Communications Mode feature, refer to Communications Mode.

• Front End Control Software Version Number

• Output Board Control Software Version Number

• Output Board Water Level Sensor Trim Value

• Top Cover Opening Test

• Door Switch Input Test

• Door Lock Input Test

• Show Fill Time Test

• Show Drain Time Test

• Temperature Sensor Display Test

• Start Pulse Test

• VFD Balance Input Test

• 24 VAC Switch Input Test

• VFD Drive Fault Input Test

• Frame Balance Switch Input Test

• VFD Balance Weight Test (Design 1 models

only)

• Drive DC Bus Display Test (Design 4 models only)

• Water Purge Test

• Water Leak Detection test

• Drive Software Version Number (Design 4

models only)

F8208801

Entering the Manual Mode

For programming, testing, and retrieving information from the control, it is often necessary to enter the Manual Mode by following the six simple steps below .

How to Enter the Manual Mode

1. If the machine is in an active cycle, rapid advance through the cycle. Refer to the Rapid Advance Feature.

2. Press and hold the #4 keypad and the #1 keypad at the same time.

3. The display will show “rAPd”.

4. Press the #3 ( ) keypad or the #6 ( ) keypad to scroll through the options until the desired option appears in the display.

5. Press the START (enter) keypad.

Manual Mode is broken into three groups: Manual Programming, Manual Rapid Advance and Manual Diagnostics. Manual Programming can only be turned on or off with an external device. Refer to the appropriate instruc tion m anual. Manual Rapid Advance and Ma nua l D iag no sti cs can be turned on and off usi ng an external device or by manual p rogramming (refer to 13 and 15 of Programming Control).

Manual Programming

Manual Programming (Prog) Manual Read Audit (AUdt) Manual Reset (rSEt)

Manual Rapid Advance

Rapid Advance (rAPd)

Manual Diagnostics

Manual Diagnostic Tests (dIAg) If a group is turned off, the display will change from

the selected feature to “oFF” when the START pad is pressed and an audio signal will sound for one (1) second. The display will then return to the selected feature. The features in the group cannot be entered.

By default, all groups are turned “on”. The manual features available in each group are as

follows (the menu displayed on the display in this mode is in parentheses).

F8208801

Programming Control

What Can Be Programmed?

Each description includes instructions on when and why the option might be used and, more importantly,

This feature allows the owner to program cycle information and other features by using the keypads. The control must have the Manual Programming Mode enabled, which is the factory default. This mode can only be turned “oFF” and “on” by using an external device. Refer to this section when programming the control.

This section offers a detailed description of all available programmable options.

how to program the option. For more advanced users, a quick reference list (refer

to Table 1) of the options available throug h the Manual Programming Mode is available. Programming Flowcharts (refer to Figures Figure 2-Figure 6) are located on the following pages.

NOTE: The letters and numbers in the Option Display column of the Programmable Options List are what will be shown in the display when that option is selected.

Programmable Options Available

Option

Number

1“dCYC” Default Cycle “Cy05”* “Cy01”-“Cy30”* 2“AUd” Audio Signal “29”* “0”-“31”* 3“Err-” Errors ——

a. b. c. d. e. f. g.

4“Cy--” Cycle Programming Refer to Cycle Chart for default cycle information

Option

Display

“E FL” Fill Errors “on”“on”/“oFF”

“E dr” Drain Error “on”“on”/“oFF” “E Ub” Unbalance Error Display “on”“on”/“oFF” “E oP” Open Therm ister Error Display “on”“on”/“oFF”

“E SH” Shorted Thermistor Error Display “on”“on”/“oFF”

“E Ht” Heat Error Display (Heater only) “on”“on”/“oFF”

“

LEr-” Water Leak Detection Error — —

“LEr1” Water Leak Detection During a Machine Cycle

(On/Off)

“LEr2” Water Leak Detection Day of Week Enable “127”* “0”-“127”*

“LEr3”*** Number of Cycles Between Water Leak

Detection During a Machine Cycle

“ESd” Slow Drain Detection “oFF”“on”/“oFF”

“AgIt” Cycle Agitate ——

“tyPE” Agitate Type ** “1”-“4”*

“ASPd” Agitate Speed (VFD only) ** “Lo”/“rEg”*

“Segx”

(1-8)

“SgEn” Segment Enable/Disable ** “on”/“oFF”

“FILL” Fill Step ——

“FLEn” Fill Step Enable/Disable ** “

“FLEU” Fill Level ** “HI”/“nEd”/“Lo” or 1-30

Cycle Segment Programming ——

Description Default

Value

“oFF”“on”/“oFF”

“0”“0”-“127”

Table 1 (continued)

Value Range

on”/“oFF”

F8208801

Programming Control

Table 1 (continued)

Option

Number

Option

Display

“tEnP” Fill Temperature ** “CoLd”/“Uarn”/“Hot”or

Description Default

Value

Value Range

35°F-194°F/2°C-90°C

“SUPL” Supply S tep ——

“SUEn” Supply Step Enable/Disable ** “on”/“oFF”

“dISP” Dispenser Options ** Display will show “Sx”

“S1” Supply #1 ** “on”/“oFF”

“S2” Supply #2 ** “on”/“oFF”

“S3” Supply #3 ** “on”/“oFF”

“S4” Supply #4 ** “on”/“oFF”

“SdUr” Supply Duration ** Press START keypad to access

options

“SEC” Seconds ** 0-59

“nIn” Minutes ** 0-9

“AgSt” Agitate Step ——

“AgEn” Agitate Step Enable/Disable ** “on”/“oFF”

“AdUr” Agitate Duratio n (in minutes) ** 1-30 for agitate types 1 or 2;

1-180 for agitate types 3 or 4

“HEAt” Heat in Agitate (if heater is present) ** “oFF”/“1”/“2”**

“drAn” Drain Step —“on”/“oFF”

“SPIn” Spin Step ——

“SPEn” Extract Step Enable/Disable ** “on”/“oFF”

“SSEC” Extract Seconds ** 0-59

“SnIn” Extract Minutes ** Intermediate Extract:

Min. Step Time = 30 seconds, Max. Step Time = 3:59 minutes

Final Extract: Min. Step Time = 30 seconds, Max. Step Time = 9:59 minutes

“SSPd” Extract Speed (VFD only) ** “1”-“3”*

5“bALr” Number of Balance Retries (VFD only) 3 (Design 1

“Cnin”*** Cycle Time in Minutes (If PCtd is enabled) 0 0-255 minutes

1-7

and 2)

1 (Design 4)

6“IrA” IR Access (On/Off) “on”“on”/“oFF” 7“t FC” Fahrenheit/Celsius “FAHr”“FAHr”/“CEL” 8“FH” Hot Water Temperature 140°F (60°C) 35°F-194°F/2°C-90°C 9“FHC” Warm Water Temperature 100°F (38°C) 35°F-194°F/2°C-90°C 10 “FC” Cold Water Temperature 35°F (2°C) 35°F-194°F/2°C-90°C 11 “Codn” Cooldown Enable/Temperature “oFF

”“oFF” or 50°F-160°F/10°C-71°C

12 “PtEn” Production Test Cycle (On/Off) “on”“on”/“oFF” 13 “rAEn” Manual Rapid Advance (On/Off) “on”“on”/“oFF”

Table 1 (continued)

F8208801

Programming Control

Table 1 (continued)

Option

Number

Option

Display

Description Default

Value

Value Range

14 “nCtd” No Cycle Time Display “oFF”“on”/“oFF” 15 “PCtd”*** Programmable Cycle Time Display 0 0 = Disabled / 1 = Enabled 16 “SdAd” Slow Drain Detection Adjust 0 0-255 seconds 17 “rtC-” Real Time Clock ——

a. b. c. d. e. f. g.

“rtC1” Set Real Time Clock Minutes — 00-59

“rtC2” Set Real Time Clock Hours — 00-23

“rtC3” Set Real Time Clock Day — “001” (Sunday)-“007” (Saturday)

“rtC4” Set Real Time Clock Date — 1-31

“rtC5” Set Real Time Clock Month — 1-12

“rtC6” Set Real Time Clock Year — 00 (2000)-99

“rtC7” Daylight Saving Option “on”“on”/“oFF”

18 “dAEn” Manual Diagnostics (On/Off) “on”“on”/“oFF” 19 “FLo” Low Water Level 31-10 20 “FnEd” Medium Water Level 15 11-20 21 “FHI” High Water Level 27 21-30 22 “tCF” Temperature Controlled Fill “oFF”“on”/“oFF” 23 “ALd

a. b. c.

” Auto-Water Leak Detection ——

“ALd1” Auto-Water Leak Detection (On/Off and cycles) “oFF”“oFF”/0-127 (Cycles) “ALd2” Auto-Water Leak Detection Hour 0 0-23 “ALd3” Auto-Water Leak Detection Day of Week “127”* “0”-“127”*

*Refer to programming section for value definition. **Refer to the Operation Manual for default cycle setting information. ***Available on Software Version 2 or later.

Table 1

F8208801

Programming Control

Enter Manual Mode.

Press and hold both #4 keypad and

#1 keypad at the same time.

“rAPd” - Quickly advance through active

cycles.

1. Press START (enter) keypad to begin Rapid Advance cycle and advance through cycle

steps.

“AUdt” - Retrieve audit information for

machine.

1. Press START (enter) keypad.

“CyC” - Total number of machine cycles:

1. Press START (enter) once to read audit.

“rSEt” - Reset the control’s programming data

to factory default.

1. Press START (enter) keypad.

“Prog” - Program cycle information and other

features into the control.

1. Refer to the Manual Programming flowchart.

“dIAg” - Run diagnostic tests on machine

operations.

1. Press START (enter) keypad. Refer to Diagnostic Tests flowchart.

“rCyC” - Total number of rapid advance cycles:

1. Press START (enter) once to read audit.

(Option available on Software Version 2 or later)

PHM148

Manual Mode Flowchart

PHM1485R

Figure 2

F8208801

Manual Programming Flowchart (1 of 3)

PHM148

“AUd” - Program when the signal will sound.

“Err-” - Turn on/off certain errors in control.

“E dr” - Drain Error

“E Ub” - Unbalance Error (VFD only)

“E Sd” - Slow Drain Detection

“FILL” - Program fill step options

“LEr-” - Leak Detection

“E oP” - Open Thermistor Error

(temp sensor only)

“E SH” - Shorted Thermistor Error

(temp sensor only)

“LEr1” - Water Leak Detection During

a Machine Cycle

“LEr2” - Water Leak Detection - Day

of Week

“LEr3” - Number of Cycles Between Water

Leak Detection During a Machine Cycle

“0” - “127”

(Available on Software

Version 2 or later)

“dCYC” - Set the default cycle and

temperature.

“Cy--” - Program aspects for the various

steps in each type of cycle. There are (30)

cycles available for programming.

(continued) (continued)

“SEg1” - Program options for each

segment. There are (8) segments

available for programming

“SgEn” - Segment Enabled/Disabled:

“on” = Enabled

“oFF” = Disabled

“tyPE” - Agitation Type:

1 = 18/3/18

2 = 10/20/10

3 = 3/27/3 4 = 4/56/4

“ASPd” - Agitation Speed (VFD only):

“Lo” = Reduced Speed

“rEg” = Normal Speed

“AgIt” - Program the cycles agitation

action and speed

(continued)

““FLEn” - Fill Step Enable/Disable:

“on” = Enabled

“oFF” = Disabled

“FLEU” - Fill Level:

“HI” = High Level

“nEd” = Medium Level

“Lo” = Low Level

“1-30” = Fill Level

“tEnP” - Fill Temperature:

“CoLd” = Cold

“UArn” = Warm

“Hot” = Hot

(35°F - 194°F [2°C - 90°C])

“E Ht” - Heat Error (heater only)

“E FL” - Fill Error

Programming Control

F8208801

Figure 3

PHM1486R

Programming Control

(continued)

(continued) (continued) (continued)

“SUPL” - Program supply step options

“dISP” Dispenser Options:

Press START (enter) to access options

“SdUr” Supply Duration:

Press START (enter) to access options

“AdUr” - Agitate Duration (min):

“1” - “30” (for agitation types 1 or 2) or

“1” - “180” for agitation types 3 or 4

“AgSt” - Program agitate step options

“drAn” - Enable/disable drain step

“SPIn” - Program extract step options

“Cnin” - Programmable

Cycle Time Display

in Minutes: "0" - "255"

Option available on Software

Version 2 or later

“SUEn” - Supply Step Enable/Disable:

“on” = Enabled

“oFF” = Disabled

“AgEn” - Agitate Step

Enabled/Disabled:

“on” = Enabled

“oFF” = Disabled

“SSEC” - Extract Seconds:

“0” - “59”

“SPEn” - Extract Step

Enabled/Disabled:

“on” = Enabled

“oFF” = Disabled

“HEAt” - Heat in Agitate

(heat present only):

“oFF” = Disabled

“1” = To Target

“2” = Maintain

“S3” -

Supply #3:

“on” = Enabled

“oFF” = Disabled

“S2” -

Supply #2:

“on” = Enabled

“oFF” = Disabled

“S4” - Supply #4:

“on” = Enabled

“oFF” = Disabled

Drain Step:

“on” = Enabled

“oFF” = Disabled

“SEC” - Seconds:

“0” - “59”

“nIn” - Minutes:

“0” - “9”

“S1” -

Supply #1:

“on” = Enabled

“oFF” = Disabled

“SnIn” - Extract Minutes:

“30” - “3.59”: Intermediate Step

“30” - “9:59”: Final Step

“SSPd” Extract Speed (G)

(Design 1 and 2 VFD models only):

1 = Very Low Speed (60)

2 = Low Speed (L - Speed = 100; M - Speed = 120)

3 = Medium Speed

(L - Speed = 100;

M - Speed = 180)

“SSPd” Extract Speed (G) (Design 4 models only)

1 = Very Low Speed (27) 2 = Low Speed (100) 3 = Medium Speed (200) (M-speed only)

Manual Programming Flowchart (2 of 3)

Figure 4

PHM1487R

F8208801

Manual Programming Flowchart (3 of 3)

PHM1488R

(continued)

“IrA” - Enable/disable the ability to read

the control by an external device:

“on” = Enabled

“off” = Disabled.

“t FC” (Temp Sensor only) - Set

temperature shown in Fahrenheit or Celsius.

“FH” (Temp Sensor only) - Set

the temperature of the hot water:

35°F - 194°F / 2°C - 90°C.

“FHC” (Temp Sensor only) - Set the

temperature of the warm water:

35°F - 194°F / 2°C - 90°C.

“FC” (Temp Sensor only) - Set the

temperature of the cold water:

35°F - 194°F / 2°C - 90°C.

“Codn” (Temp Sensor only) - Enable/disable

the cool down water temperature option:

“off” or 50°F - 160°F / 10°C - 71°C.

“PtEn” - Enable/disable access to the

production test cycle:

“on” = Enabled

“off” = Disabled.

“rAEn” - Enable/disable the rapid advance

feature:

“on” = Enabled

“off” = Disabled.

“nCtd” - Enable/disable whether the cycle

time will appear in display:

“on” = Enabled

“off” = Disabled.

“bALr” (VFD only) - Program the number

of times control will retry balancing the

load before moving to extract step: 1-7.

Temperature:

“CEL” = Celsius

“FAHr” = Fahrenheit

“SdAd” - Enable/disable slow drain

detection. When enabled can

increase/decrease the time before a slow

drain error will occur:

0 - 255 seconds

“dAEn” - Enable/disable the manual

diagnostics option:

“on” = Enabled “off” = Disabled.

“FLo” - Program the low water level

during fill and tumble of all cycles:

“1” - “10”

“FnEd” - Program the medium water level

during fill and tumble of all cycles:

“11” - “20”

“FHI” - Program the high water level during

fill and tumble of all cycles:

“21” - “30”

“tCF” (Temp Sensor only) - Enable/disable a

temperature controlled fill:

“on” = Enabled “off” = Disabled.

“ALd-” - Set the time and frequency that the

control automatically checks the water level.

“ALd3” - Auto-Water Leak Detection

Day of Week:

“0” - “127”

“ALd2”” - Auto-Water Leak Detection

Hour:

“0” - “23”

“ALd1” - Auto-Water Leak Detection:

“on”, then “0” - “127”

“oFF”

“rtC1” - Programs minutes:

“0” - “59”

“rtC2” - Programs Hours:

“0” - “23”

“rtC3” - Programs Day of Week:

“1” - “7”

“rtC4” - Programs Date of Month:

“1” - “31”

“rtC6” - Programs Year:

“0” - “99”

“rtC-” - set the control’s internal clock.

“rtC7” - Programs Daylight Saving:

“on” = Enabled

“oFF” = Disabled

“rtC5” - Programs Month:

“1” - “12”

“PCtd” - When enabled, the control

displays the programmed time during

a machine cycle:

“0” = Disabled “1” = Enabled

Option available on Software

Version 2 or later

F8208801

Programming Control

PHM1488R

Figure 5

Programming Control

PHM1489R

“dIAg” - Diagnostic Tests.

1. Press START (enter) keypad.

“d001” - Front End Control

Software Version # Test

“S xx”

“d002” - Output Board Control

Software # Test

“o xx”

“d003” - Output Board Water Level

Sensor Trim Value

“txxx”

“d004” - Top Cover Opening Test

“A oP” or “A CL”

“d017” - VFD Drive Fault Input

Te st

“dFoP” or “dFCL”

Design 1 and 2 Models

“d018” - Frame Balance Switch

Input Test

“FSoP” or “FSCL”

Design 1 and 2 Models

“d019” - VFD Balance Weight Test

“bAL”

Design 1 and 2 Models

“d021” - Water Leak Detection

Te st

“Ld”

“d020” - Water Purge Test

“PUrg”

“d013” - Termperature Sensor

Display Test

“xxxF” or “xxxC”

“d015” - VFD Balance Input Test

“bAoP” or bACL”

Design 1 and 2 Models

“d016” - 24 VAC Switch Input Test

“ACoP” or “ACCL”

Design 1 and 2 Models

“d014” - Start Pulse Test

“Stxx”

“d009” - Door Switch Input Test

“drCL” or “drOP”

“d010” - Door Lock Input Test

“drUL” or “drLo”

“d011” - Show Fill Time Test

“Fxxx”

“d012” - Show Drain Time Test

“dxxx”

“d019” - Drive DC Bus

Display Test

“dCb”

Design 4 Models

“d023” - Custom Drive

Parameter Table Version # Test

“dPxx”

Design 4 Models

“d022” - Custom Drive

Software Version # Test

“drxx”

Design 4 Models

“d024” - Custom Drive

Type Value

“dt x”

Design 4 Models

Diagnostic Tests Flowchart

Figure 6

PHM1489R

F8208801

Programming Control

><>

1. Default Cycle “dCYC”

This option allows the owner to set the default cycle the machine will enter when in the Ready Mode.

How to Program Default Cycle

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. When “dCYC” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current default cycle value.

NOTE: The default cycle can be set from 1 to 30.

4. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current number to the desired number.

5. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “AUd”, will appear in the display.

NOTE: T o program “AUd” (Audio Signal), r efer to option 2 To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><>

2. Audio Signal “AUd”

This option allows the owner to program when the signal will sound.

There are two occasions when a signal may sound during operation. These two occasions are listed below:

1. End of Cycle Signal

By default, the signal is turned off. If turned on, the signal will sound for three (3) seconds at the end of a cycle.

2. Keypad Depression Signal

By default, this signal is turned on and will sound for a quarter of a second. This signal will sound each time a keypad is pressed.

How to Program the Audio Signal

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “AUd” appears in the display.

4. When “AUd” appears in the display press the START (enter) keypad. A number will appear in the display. This number corresponds to the current Audio Signal Programming Value.

5. Locate the desired number in the first column of Table 2 on the following page.

6. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current number until correct.

For Example: A user might wish to have the signal sound only when a keypad is pressed. Entering the number “1” in step 5 would turn off all the options except KEYPAD. In this instance, the signal would sound only when a keypad is pressed.

7. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “Err-”, will appear in the display.

NOTE: To program “Err-” (Errors), refer to .option 3 To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

How to Read Table 2

To determine the correct number required to program the Audio Signal, use the following chart. The Signal Value column contains the number required in step 6. The other columns correspond to individual options.

Each column of options contains a unique combination of the words “on” and “oFF” that indicates if that column’s option is turned on or off when the Signal Value is entered. Select the desired combination of options and enter the number found in the Signal V alue column.

The default value programmed at the factory is 1.

Signal

Value

1* OFF OFF OFF OFF ON

10 OFF ON OFF ON OFF 11 OFF ON OFF ON ON 12 OFF ON ON OFF OFF 13 OFF ON ON OFF ON 14 OFF ON ON ON OFF 15 OFF ON ON ON ON 16 ON OFF O FF OFF OFF 17 ON OFF OFF OFF ON 18 ON OFF OFF ON OFF 19 ON OFF OFF ON ON 20 ON OFF ON OFF OFF 21 ON OFF ON OFF ON 22 ON OFF ON ON OFF 23 ON OFF ON ON ON 24 ON ON OFF OFF OFF 25 ON ON OFF OFF ON 26 ON ON OFF ON OFF 27 ON ON OFF ON ON 28 ON ON ON OFF OFF 29 ON ON ON OFF ON 30 ON ON ON ON OFF 31 ON ON ON ON ON

Start

Mode

(Not

Used)

0 OFF OFF OFF OFF OFF

2OFFOFFOFFON OFF 3OFFOFFOFFON ON 4OFFOFFON OFF OFF 5OFFOFFON OFF ON 6OFFOFFON ON OFF 7OFFOFFON ON ON 8OFFON OFF OFF OFF 9OFFON OFF OFF ON

Remove

Card

(Not

Used)

Coin/

Card

Input

(Not

Used)

End of

Cycle

Pressed

Key

F8208801

*Factory default setting

Table 2

Programming Control

><><><>

3. Error Code Programming “Err-”

This option allows the owner to turn on or turn off certain errors in the control.

How to Program Error Code Programming

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “Err-” appears in the display.

4. When “Err-” appears in the display, press the

START (enter) keypad. Refer to Table 3 for a list of programmable error code parameters.

5. Press the #3 ( ) or the #6 ( ) keypad to select error code.

6. Press the ST ART (enter) keypad when the correct code appears in the display. The current status will appear in the display. “on” = Error Code Enabled “oFF” = Error Code Disabled

7. Press the #3 ( ) or the #6 ( ) keypad to change the status.

8. Press the ST ART (enter) keypad when the correct status appears in the display . The next Error Code Programming option will appear in the display.

NOTE: To program “Cy--” (Cycle Programming), press the #5 (<) keypad, then the #3 ( ) keypad and refer to option 4. To program other options, refer to the appropriate section.

How to Exit Programming Feature

9. Press the #5 (<) keypad until the control returns to Start Mode.

“E FL” Fill Error

“E dr” Drain Error “E Ub” Unbalance Error Display (VFD only) “E oP” Open Thermistor Error Display “E SH” Shorted Thermistor Error Display

“E Ht” Heat Error Display (Heater only)

“LEr-” Leak Detection Error

If water leak detection during a machine cycle is enabled, then, on the enabled day(s) of the week, the control will check for water leaks during running machine cycles. If a leak is detected, the control will display the “ELd” error for one minute after the cycle is completed. It will also light the right-most decimal point on the display. To turn off the right-most decimal point on the display, press the START keypad 3 times (within 5 seconds) anytime after the first fill. The water leak detector diagnostic test can be used to verify the leak.

Water Leak Detection During

“LEr1”

“LEr2”

“LEr3”

“ESd” Slow Drain Detection Determines if

machine is draining slower than normal.

If Slow Drain Detection is enabled, the control will check for slow drain operation during running machine cycles. If a slow drain is detected, the control will display the “ESd” error for one minute after the cycle is completed. It will also light the right-most decimal point on the display. For machines equipped with Software V ersion 2 or later , to turn off the right-most decimal point on the display, press the START keypad 3 times (within 5 seconds) anytime after the first fill.

a Machine Cycle - Determines if water level drops below target level.

Water Leak Detection During Machine Cycle Day of Week Enable (Refer to Figure 3 for Day(s) of the Week Enabled Values)

Number of Cycles Between Water Leak Detection During a Machine Cycle (Option available on Software Version 2 or later.)

Table 3

F8208801

Programming Control

Day(s) of the Week Enabled Values

Day Of Week

Value

SAT FRI THUR WED TUE MON SUN

0 OFF OFF OFF OFF OFF OFF OFF 1 OFF OFF OFF OFF OFF OFF ON 2 OFF OFF OFF OFF OFF ON OFF 3 OFF OFF OFF OFF OFF ON ON 4 OFF OFF OFF OFF ON OFF OFF 5 OFF OFF OFF OFF ON OFF ON 6 OFF OFF OFF OFF ON ON OFF 7 OFF OFF OFF OFF ON ON ON 8OFFOFFOFFON OFF OFF OFF

9OFFOFFOFFON OFF OFF ON 10 OFF OFF OFF ON OFF ON OFF 11 OFF OFF OFF ON OFF ON ON 12 OFF OFF OFF ON ON OFF OFF 13 OFF OFF OFF ON ON OFF ON 14 OFF OFF OFF ON ON ON OFF 15 OFF OFF OFF ON ON ON ON 16 OFF OFF ON OFF OFF OFF OFF 17 OFF OFF ON OFF OFF OFF ON 18 OFF OFF ON OFF OFF ON OFF 19 OFF OFF ON OFF OFF ON ON 20 OFF OFF ON OFF ON OFF OFF 21 OFF OFF ON OFF ON OFF ON 22 OFF OFF ON OFF ON ON OFF 23 OFF OFF ON OFF ON ON ON 24 OFF OFF ON ON OFF OFF OFF 25 OFF OFF ON ON OFF OFF ON 26 OFF OFF ON ON OFF ON OFF 27 OFF OFF

ON ON OFF ON ON 28 OFF OFF ON ON ON OFF OFF 29 OFF OFF ON ON ON OFF ON 30 OFF OFF ON ON ON ON OFF 31 OFF OFF ON ON ON ON ON 32 OFF ON OFF OFF OFF OFF OFF 33 OFF ON OFF OFF OFF OFF ON 34 OFF ON OFF OFF OFF ON OFF 35 36 37 38

OFF ON OFF OFF OFF ON ON OFF ON OFF OFF ON OFF OFF OFF ON OFF OFF ON OFF ON OFF ON OFF OFF ON ON OFF

39 OFF ON OFF OFF ON ON ON

F8208801

Table 4 (continued)

Programming Control

Day Of Week

Value

40 OFF ON OFF ON OFF OFF OFF 41 OFF ON OFF ON OFF OFF ON 42 OFF ON OFF ON OFF ON OFF 43 OFF ON OFF ON OFF ON ON 44 OFF ON OFF ON ON OFF OFF 45 OFF ON OFF ON ON OFF ON 46 OFF ON OFF ON ON ON OFF 47 OFF ON OFF ON ON ON ON 48 OFF ON ON OFF OFF OFF OFF 49 OFF ON ON OFF OFF OFF ON 50 OFF ON ON OFF OFF ON OFF 51 OFF ON ON OFF OFF ON ON 52 OFF ON ON OFF ON OFF OFF 53 OFF ON ON OFF ON OFF ON 54 OFF ON ON OFF ON ON OFF 55 OFF ON ON OFF ON ON ON 56 OFF ON ON ON OFF OFF OFF 57 OFF ON ON ON OFF OFF ON 58 OFF ON ON ON OFF ON OFF 59 OFF ON ON ON OFF 60 OFF ON ON ON ON OFF OFF 61 OFF ON ON ON ON OFF ON 62 OFF ON ON ON ON ON OFF 63 OFF ON ON ON ON ON ON 64 ON OFF OFF OFF OFF OFF OFF 65 ON OFF OFF OFF OFF OFF ON 66 ON OFF OFF OFF OFF ON OFF 67 ON OFF OFF OFF OFF ON ON 68 ON OFF OFF OFF ON OFF OFF 69 ON OFF OFF OFF ON OFF ON 70 ON OFF OFF OFF ON ON OFF 71 ON OFF OFF OFF ON ON ON 72 ON OFF OFF ON OFF OFF OFF 73 ON OFF OFF ON OFF OFF ON 74 ON OFF OFF ON OFF ON OFF 75 ON OFF OFF ON OFF ON ON 76 ON OFF OFF ON ON OFF OFF 77 ON OFF OFF ON ON OFF ON 78 ON OFF OFF ON ON ON OFF 79 ON OFF OFF ON ON ON ON 80 ON OFF ON OFF OFF OFF OFF 81 ON OFF 82 ON OFF ON OFF OFF ON OFF 83 ON OFF ON OFF OFF ON ON

Table 4 (continued)

Day(s) of the Week Enabled Values

SAT FRI THUR WED TUE MON SUN

ON ON

ON OFF OFF OFF ON

Table 4 (continued)

F8208801

Programming Control

Table 4 (continued)

Day(s) of the Week Enabled Values

Day Of Week

Value

SAT FRI THUR WED TUE MON SUN

84 ON OFF ON OFF ON OFF OFF 85 ON OFF ON OFF ON OFF ON 86 ON OFF ON OFF ON ON OFF 87 ON OFF ON OFF ON ON ON 88 ON OFF ON ON OFF OFF OFF 89 ON OFF ON ON OFF OFF ON 90 ON OFF ON ON OFF ON OFF 91 ON OFF ON ON OFF ON ON 92 ON OFF ON ON ON OFF OFF 93 ON OFF ON ON ON OFF ON 94 ON OFF ON ON ON ON OFF 95 ON OFF ON ON ON ON ON 96 ON ON OFF OFF OFF OFF OFF 97 ON ON OFF OFF OFF OFF ON 98 ON ON OFF OFF OFF ON OFF

99 ON ON OFF OFF OFF ON ON 100 ON ON OFF OFF ON OFF OFF 101 ON ON OFF OFF

ON OFF ON 102 ON ON OFF OFF ON ON OFF 103 ON ON OFF OFF ON ON ON 104 ON ON OFF ON OFF OFF OFF 105 ON ON OFF ON OFF OFF ON 106 ON ON OFF ON OFF ON OFF 107 ON ON OFF ON OFF ON ON 108 ON ON OFF ON ON OFF OFF 109 ON ON OFF ON ON OFF ON 110 ON ON OFF ON ON ON OFF

111 ON ON OFF ON ON ON ON 112 ON ON ON OFF OFF OFF OFF 113 ON ON ON OFF OFF OFF ON 114 ON ON ON OFF OFF ON OFF 115 ON ON ON OFF OFF ON ON 116 ON ON ON OFF ON OFF OFF 117 ON ON ON OFF ON OFF ON 118 ON ON ON OFF ON ON OFF 119 ON ON ON OFF ON ON ON 120 ON ON ON ON OFF OFF OFF 121 ON ON ON ON OFF OFF ON 122 ON ON ON ON

OFF ON OFF 123 ON ON ON ON OFF ON ON 124 ON ON ON ON ON OFF OFF 125 ON ON ON ON ON OFF ON 126 ON ON ON ON ON ON OFF 127 ON ON ON ON ON ON ON

F8208801

Table 4

Programming Control

><><><>

><><>

4. Cycle Programming “Cy--”

This option allows the owner to program different aspects for various steps in each type of cycle. There are 30 cycles available for programming.

How to Enter Cycle Programming

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “Cy--” appears in the display. Press the START (enter) keypad and “Cy01” will appear in the display.

4. Press the #3 ( ) or the #6 ( ) keypad to scroll through the 30 cycles to program. Press the START (enter) keypad when the desired cycle appears in the display.

5. The first Cycle Programming option, “Agit”, will appear in the display.

NOTE: To program “Agit” (Cycle Agitate), continue to next option. To program other options, press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

How to Program Cycle Agitate “AgIt”

This option allows the owner to program the cycle’s agitation action and speed. These options apply to the entire cycle.

1. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable Cycle Programming options until “Agit” appears in the display.

2. When “Agit” appears in the display, press the START (enter) keypad. The first Cycle Agitate option will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable options. Refer to Table 5.

4. Press the START (enter) keypad when the desired programmable option appears in the display. The current status will appear in the display. Refer to Table 5.

Final

Spin Step

“tyPE” Agitate Type 1-4

“ASPd” Agitate

5. Press the #3 ( ) or the #6 ( ) keypad to change

Description Status

1 = 18/3/18 Agitation Action 2 = 10/20/10 Agitation Action 3 = 3/27/3 Agitation Action 4 = 4/56/4 Agitation Action

Speed

(VFD only)

Table 5

the current status.

“Lo” = Reduced Speed “rEg” = Normal Speed

6. Press the START (enter) keypad when the desired status appears in the display. The next Cycle Agitate option will appear in the display.

NOTE: To program “SEg1” (Cycle Segment 1) press the #5 (<) keypad and continue to next Cycle Programming option. To program other options, press the #5 (<) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><>

<><

How to Program Cycle Segment “SEg1”

There are eight programmable cycle segments. Within each segment, there are several programmable options.

1. Press the #3 ( ) or the #6 ( ) keypad to scroll through the eight programmable Cycle Segments until the desired segment appears in the display.

2. When the desired segment appears in the display, press the START (enter) keypad. “SgEn” (Segment Enable/Disable) will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll through the Cycle Segment programmable options.

NOTE: If the Segment Enable/Disable is programmed “OFF”, the other Cycle Segment programming options can’t be accessed.

4. Press the START (enter) keypad when the desired Cycle Segment programmable option appears in the display.

Programming Segment Enable/Disable

1. When “SgEn” appears in the display, press the START (enter) keypad. The current Segment Enable/Disable status will appear in the display. “on” = Segment is enabled “oFF” = Segment is disabled

2. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

NOTE: If the Segment Enable/Disable is programmed “oFF”, the other Cycle Segment programming options can’t be accessed.

3. Press the START (enter) keypad when the desired status appears in the display. The next Cycle Segment option, “FILL”, will appear in the display.

NOTE: To program “FILL” (Fill Step), continue to next Cycle Segment option. To program other options, press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

Programming Fill Step

1. When “FILL” appears in the display, press the

START (enter) keypad. The first Fill step programming option will appear in the display .

2. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable Fill step options. Refer to Table 6.

NOTE: Fill Step “FLEn” must be enabled to scroll through all Fill Step options.

3. Press the START (enter) keypad when the desired option appears in the display. The current status will appear in the display. Refer to Table 6.

Fill Step Description Status

“FLEn” Fill Step

Enable/Disable

“FLEU” Fill Level “HI” = high level

“tEnP” Fill Temperature “CoLd” = Cold

(35°F-194°F [2°C-90°C])

Table 6

“on”/”oFF”

“nEd” = medium level

“Lo” = low level

“1-30”

“UArn” = Warm

“Hot” = Hot

4. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

5. Press the START (enter) keypad when the desired status appears in the display. The next Fill step option will appear in the display.

NOTE: To program “SUPL” (Supply Step), continue to next Cycle Segment option. To program other options, press the #3 ( ) or the #6 ( ) keypad the and refer to the appropriate section.

How to Exit Programming Feature

Press the #5(<) keypad until the control returns to Start Mode.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

F8208801

Programming Control

><>

<><

><>

<><

Programming Supply Step

1. When “SUPL” appears in the display, press the

START (enter) keypad. The first Supply step programming option will appear in the display.

2. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable Supply step options. Refer to Table 7.

NOTE: Supply Step “SUEn” must be enabled to scroll through all Supply Step options.

3. Press the START (enter) keypad when the desired option appears in the display. The current status value will appear in the display. Refer to Table 7.

Supply

Step

“SUEn” Supply Step

“dISP” Dispenser Options Press STAR T (enter) to

“S1” Supply #1 “on”/“oFF” “S2” Supply #2 “on”/“oFF” “S3” Supply #3 “on”/“oFF” “S4” Supply #4 “on”/“oFF”

“SdUr” Supply Duration Press START (enter)

“SEC” Seconds 0-59

“nIn” Minutes 0-9

4. Press the #3 ( ) or the #6 ( ) keypad to change the current status/value.

5. Press the START (enter) keypad when the desired status/value appears in the display. The next Supply step option will appear in the display.

NOTE: To program “AgSt” (Agitate Step), continue to next Cycle Segment option. If in the Dispenser Options or Supply Duration programming option, press the #5 (<) keypad first. T o pr ogram other options, press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

Description Status/Value

“on”/“oFF”

Enable/Disable

access options

to access options

Table 7

Programming Agitate Step

1. When “AgSt” appears in the display, press the

START (enter) keypad. The first Agitate step programming option will appear in the display .

2. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable Agitate step options. Refer to Table 8.

NOTE: Agitate Step “AgEn” must be enabled to scroll through all Agitate step options.

3. Press the START (enter) keypad when the desired option appears in the display. The current status/value will appear in the display. Refer to Table 8.

Agitate

Step

“AgEn” Agitate Step

“AdUr” Agitate Duration

“HEAt” Heat in Agitate

Description Status/Value

“on”/“oFF”

Enable/Disable

1-30 Minutes for

(in minutes)

(If heater is present)

Table 8

agitate types 1 or 2

1-180 Minutes for

agitate types 3 or 4

(Refer to Cycle Agitate)

“oFF”, 1 or 2 1 = To Target

2 = Maintain

4. Press the #3 ( ) or the #6 ( ) keypad to change the current status/value.

5. Press the START (enter) keypad when the desired status/value appears in the display. The next Agitate step option will appear in the display.

NOTE: To program “drAn” (Drain S tep), continue to next Cycle Segment option. To program other options, press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Ready Mode.

F8208801

Programming Control

><><>

<><

Programming Drain Step

1. When “drAn” appears in the display, press the

START (enter) keypad. The current status will be displayed.

2. Press the #3 ( ) or the #6 ( ) keypad to change the current status. “on” = Drain step is enabled “oFF” = Drain step is disabled

NOTE: Drain must be enabled to activate Extract step.

3. Press the START (enter) keypad when the desired status appears in the display. The next Cycle Segment option, “SPIn”, will appear in the display.

NOTE: To program “SPIn” (Extract Step), continue to next Cycle Segment option. To program other options press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Ready Mode.

Programming Extract Step

1. When “SPIn” appears in the display, press the START (enter) keypad. The first Extract step programming option will appear in the display.

2. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable Extract step options. Refer to Table 9.

Extract

Step

“SPEn” Extract Step

“SSEC” Extract

“SnIn” Extract

“SSPd” Extract Speed

Description Status/Value

Enable/ Disable

Seconds

Minutes

(G) (Design 1

and 2 VFD

models only)

Extract Speed (G) (Design 4

models only)

“on”/“oFF”

0-59

Intermediate Extract:

Minimum Step Time = 30 seconds Maximum Step Time = 3:59 minutes

Final Extract:

Minimum Step Time = 30 seconds Maximum Step Time = 9:59 minutes

1 = very low speed (60) 2 = low speed

(L-speed = 100; M-speed = 120)

3 = medium speed

(L-speed = 100; M-speed = 180)

1 = very low speed (27)

(L and M-speed)

2 = low speed (100)

(L and M-speed)

3 = medium speed (200)

(M-speed)

Table 9

NOTE: Extract Step “

SPEn” must be enabled to

scroll through all Extract step options.

3. Press the START (enter) keypad when the desired option appears in the display. The current status/value will appear in the display. Refer to Table 9.

F8208801

4. Press the #3 ( ) or the #6 ( ) keypad to change the current status/value.

5. Press the START (enter) keypad when the desired status/value appears in the display.

NOTE: To program “Cnin” (Cycle Time Display), continue to next Cycle Segment option. To program other options press the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

Programming Control

><><><><>

Programming Cycle Time Display

NOTE: This option is not available on Software Version 1.

NOTE: This programmable option (Cnin) will only appear if the Programmable Cycle Time Display option (PCtd) has been enabled.

1. When “Cnin” appears in the display, press the

START (enter) keypad. The current status will be displayed.

2. Press the #3 ( ) or the #6 ( ) keypad to change the current value. The cycle time display can be set from 0 to 255 minutes.

3. Press the START (enter) keypad when the desired value appears in the display.

NOTE: To program another cycle, repeat Cycle Programming steps. To program other options press the the #3 ( ) or the #6 ( ) keypad and refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

5. Number of Balance Retries “bALr” (Variable Frequency Drives Only)

This option allows the owner to program how many times the control will retry balancing the load before moving into Extract step.

How to Program Number of Balance Retries

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad, and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “bALr” appears in the display.

4. When “bALr” appears in the display, press the

START (enter) keypad. The current value will appear in the display.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current value.

NOTE: The number of balance retries can be set from 1-7. Design 1 and 2 default number of balance retries is 3 and Design 4 default number of balance retries is 1.

6. Press the START (enter) keypad when the desired value appears in the display. The next option, “IrA”, will appear in the display.

NOTE: To program “IrA” (IR Access [on/off]), refer to option 6. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><><><>

6. IR Access (On/Off) “IrA”

This option allows the owner to enable or disable allowing the control to be read by an external device.

How to Program the IR Access (On/Off)

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “IrA” appears in the display.

4. When “IrA” appears in the display, press the

START (enter) keypad. The current IR Access status will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “tFC” will appear in the display.

NOTE: To program “t FC” (Fahrenheit/Celsius), refer to option 7. To program other options, refer to the appropriate section.

7. Fahrenheit/Celsius “t FC”

This option allows the owner to set whether the display will be shown in Fahrenheit or Celsius.

How to Program Fahrenheit/Celsius

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “tFC” appears in the display.

4. When “tFC” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number (found below) corresponds to the current Fahrenheit/Celsius setting.

CEL = Celsius FAHr = Fahrenheit

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current number to the desired number.

6. Press the ST ART (enter) keypad when the correct number of degrees appears in the display. The new value is saved and the next option, “FH”, will appear in the display.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

NOTE: To program “FH” (Hot Water Temperature), refer to option 8. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><><><>

8. Hot Water Temperature “FH”

This option allows the owner to program the hot water temperature for models equipped with temperature sensing capabilities.

How to Program Hot Water Temperature

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FH” appears in the display.

4. When “FH” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current Hot Water Temperature value.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current Hot Water Temperature value to the desired Hot Water Temperature value.

NOTE: Hot Water Temperature is selectable between 35° and 194° Fahrenheit (2° and 90° Celsius). Default temperature is 140° Fahrenheit (60° Celsius).

NOTE: Refer to option 7 to select Celsius or Fahrenheit display.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “FHC”, will appear in the display.

NOTE: To program “FHC” (Warm Water Temperature), refer to option 9. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

9. Warm Water Temperature “FHC”

This option allows the owner to program the warm water temperature for models equipped with temperature sensing capabilities.

How to Program Warm Water Temperature

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FHC” appears in the display.

4. When “FHC” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current Warm Water Temperature value.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current Wa rm Water T emperature value to the desired Warm Water Temperature value.

NOTE: Warm Water Temperature is selectable between 35° and 194° Fahrenheit (2° and 90° Celsius). Default temperature is 100° Fahrenheit (38° Celsius).

NOTE: Refer to option 7 to select Celsius or Fahrenheit display.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “FC”, will appear in the display.

NOTE: To program “FC” (Cold Water Temperature), refer to option 10. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><><><>

10. Cold Water Temperature “FC”

This option allows the owner to program the cold water temperature for models equipped with temperature sensing capabilities.

How to Program Cold Water Temperature

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FC” appears in the display.

4. When “FC” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current Cold Water Temperature value.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current Cold Water Temperature value to the desired Cold Water Temperature value.

NOTE: Cold Water Temperature is selectable between 35° and 194° Fahrenheit (2° and 90° Celsius). Default temperature value is 35° Fahrenheit (2° Celsius).

NOTE: Refer to option 7 to select Celsius or Fahrenheit display.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “Codn”, will appear in the display.

NOTE: To program “Codn” (Cooldown Enable/ Temperature), refer to option 11. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

11. Cooldown Enable/Temperature “Codn”

This option allows the owner to enable or disable the Cooldown Water Temperature option. If enabled, the owner can also set the cooldown water temperature.

How to Program Cooldown Enable/ Temperature

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “Codn” appears in the display.

4. When “Codn” appears in the display, press the START (enter) keypad. A number or “off” will appear in the display. The number corresponds to the current Cooldown Water Temperature value, and “oFF” appears when cooldown is disabled.

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

NOTE: Cooldown Water Temperature is selectable between 50° and 160° Fahrenheit (10° and 71° Celsius). Default is off.

6. Press the START (enter) keypad when the desired value appears in the display.

NOTE: Refer to option 7 to select Celsius or Fahrenheit display.

7. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “PtEn”, will appear in the display.

NOTE: T o program “PtEn” (Production Test Cycle [on/off]), refer to option 12. To program other options, refer to the appropriate section.

How to Exit Programming Feature

F8208801

Press the #5 (<) keypad until the control returns to Start Mode.

Programming Control

><><><><><>

12. Production Test Cycle (On/Off) “PtEn”

This option allows the owner to enable or disable access to the production test cycle. Refer to Production Test Cycle section for more information.

How to Program the Production Test Cycle (On/Off)

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “PtEn” appears in the display.

4. When “PtEn” appears in the display, press the

START (enter) keypad. The current Production Test Cycle status will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

13. Manual Rapid Advance (On/Off) “rAEn”

This option allows the owner to enable or disable the rapid advance feature. Refer to Rapid Advance Feature section for more information.

How to Program the Manual Rapid Advance (On/Off)

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “rAEn” appears in the display.

4. When “rAEn” appears in the display, press the

START (enter) keypad. The current Manual Rapid Advance status will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “rAEn”, will appear in the display.

NOTE: To program “rAEn” (Manual Rapid Advance [on/off]), refer to option 13. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “rtc-”, will appear in the display.

NOTE: To program “nCtd” (No Cycle Time Display), refer to option 14. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><><><>

14. No Cycle Time Display “nCtd”

This option allows the owner to enable or disable whether the cycle time will appear in the display.

How to Program in the Cycle Time Display

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCyC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “nCtd” appears in the display.

4. When “nCtd” appears in the display, press the

START (enter) keypad. The current No Cycle Time Display status will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “PCtd” will appear in the display.

NOTE: To program “PCtd” (Programmable Cycle Time Display), refer to option 15 . To program other options, refer to the appropriate section.

15. Programmable Cycle Time Display “PCtd”

NOTE: This option is available on Software Version 2 or later only.

This option allows the owner to display either the normal remaining cycle time or the programmed time during a machine cycle.

How to Program the Programmable Cycle Time Display

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCyC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “PCtd” appears in the display.

4. When “PCtd” appears in the display, press the

START (enter) keypad. The current Programmable Cycle Time Display status will appear in the display. “0” = Option Disabled “1” = Option Enabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “SdAd”, will appear in the display.

NOTE: To program “SdAd” (Slow Drain Detection Adjust), refer to option 16. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><>

16. Slow Drain Detection Adjust “SdAd”

This option allows the owner to increase or decrease the slow drain detection threshold by adding additional seconds to the threshold value. When enabled it increases the time before a Slow Drain Error will occur.

How to Program the Pause/Resume Mode

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “SdAd” appears in the display.

4. When “SdAd” appears in the display, press the

START (enter) keypad. The current Slow Drain Detection Adjust Value will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current value.

6. Press the START (enter) keypad when the desired value appears in the display. The next option, “rtc”, will appear in the display.

NOTE: To program “rtc” (Set Real-Time Clock), refer to option 17. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><>

17. Set Real-Time Clock “rtC-”’

This option allows the owner to set the control’s internal clock to the correct time and date.

How to Program the Time and Date

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “rtC-” appears in the display. Press the START keypad and “rtC1” will appear in the display.

4. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable options. Refer to Figure 10.

“rtC1” Programs Minutes “rtC2” Programs Hours “rtC3” Programs Day of Week “rtC4” Programs Date of Month “rtC5” Programs Month “rtC6” Programs Year “rtC7” Programs Daylight Saving

NOTE: The hours will be displayed in military time. For day of week, Sunday is considered day one (001), Monday is day two (002) and so on. For year, the year 2000 is “00”, the year 2001 is “01” and so on.

If programming Daylight Saving, “rtc7”, “on” enables Daylight Saving Time and “oFF” disables Daylight Saving Time.

7. Press the ST ART (enter) keypad when the correct time or date appears in the display. The next Set Real-Time Clock option will appear in the display.

NOTE: To program “dAEn” (Manual Diagnostics [on/off]), press the #5 (<) keypad and refer to option 18. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

Table 10

5. When the desired option appears in the display, press the START (enter) keypad. The current value will appear in the display.

6. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the minutes, hours, day of week, date of the month, month, year to the correct time or date.

F8208801

Programming Control

><><><><><>

18. Manual Diagnostics (On/Off) “dAEn”

This option allows the owner to enable or disable the manual diagnostics option. Refer to Testing Machine and Electronic Control Functions section for more information.

How to Program the Manual Diagnostics (On/Off)

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “dAEn” appears in the display.

4. When “dAEn” appears in the display, press the

START (enter) keypad. The current Manual Diagnostics status will appear in the display. “on” = Option Enabled “oFF” = Option Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “FLo”, will appear in the display.

NOTE: To program “FLo” (Low Water Level), refer to option 19. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

19. Low Water Level “FLo”

This option allows the owner to program the low water level during fill and tumble of all cycles.

How to Program Low Water Level

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FLo” appears in the display.

4. When “FLo” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current low water level during tumble and fill of all cycles.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current water level to the desired water level.

NOTE: The Low W ater Level value can be set fr om 1 to 10.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “FnEd”, will appear in the display.

NOTE: To program “FnEd” (Medium Water Level), refer to option 20. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><><><>

20. Medium Water Level “FnEd”

This option allows the owner to program the medium water level during fill and tumble of all cycles.

How to Program Medium Water Level

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FnEd” appears in the display.

4. When “FnEd” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current medium water level during tumble and fill of all cycles.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current water level to the desired water level.

21. High Water Level “FHI”

This option allows the owner to program the high water level during fill and tumble of all cycles.

How to Program High Water Level

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “FHI” appears in the display.

4. When “FHI” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number corresponds to the current high water level during tumble and fill of all cycles.

5. Press the #3 ( ) or the #6 ( ) keypad to increase or decrease the current water level to the desired water level.

NOTE: The Medium Wa ter Level value can be set from 11 to 20.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “FHI”, will appear in the display.

NOTE: To program “FHI” (High Water Level), refer to option 21. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Star t Mode.

NOTE: The High Water Level value can be set from 21 to 30.

6. Press the ST ART (enter) keypad when the correct number appears in the display. The next option, “tCF”, will appear in the display.

NOTE: To program “tCF” (Temperature Controlled Fill), refer to option 22. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><>

22. Temperature Controlled Fill Enable/Disable “tCF”

This option allows the owner to enable or disable a Temperature Controlled Fill. When enabled, the control will regulate the temperature of the fill to the temperature programmed in options 8, 9 and 10.

How to Program Temperature Controlled Fill

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCYC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “tCF” appears in the display.

4. When “tCF” appears in the display, press the

START (enter) keypad. A number will appear in the display. This number (found below) corresponds to the current Temperature Controlled Fill status.

“on” = Temperature Controlled Fill Enabled “oFF” = Temperature Controlled Fill Disabled

5. Press the #3 ( ) or the #6 ( ) keypad to change the current status.

6. Press the START (enter) keypad when the desired status appears in the display. The next option, “ALd”, will appear on the display.

NOTE: To program “ALd” (Auto-Water Leak Detection), refer to option 23. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Start Mode.

F8208801

Programming Control

><><><>

23. Auto-Water Leak Detection “ALd”

This option allows the owner to set the time and frequency that the control automatically checks the water level. The owner programs which day(s) of the week and hours of day(s) they want this test to occur. The owner may also program this test to only occur after XX number of machine cycles have been completed since the last time the test was run. In order for this Auto-Water Leak Detection test to occur, the machine’s door must be closed.

How to Program Auto-Water Leak Detection

1. Control must be in Manual Mode. Refer to

Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until

“Prog” appears in the display. Press the START (enter) keypad and “dCyC” will appear in the display.

3. Press the #3 ( ) or the #6 ( ) keypad to scroll

through the programmable options until “ALd-” appears in the display. Press the START keypad and “ALd1” will appear in the display.

5. When the desired option appears in the display, press the START (enter) keypad. The current value will appear in the display.

6. Press the #3 ( ) or the #6 ( ) keypad to enable during cycles, disable, increase or decrease the hours or day.

NOTE: The hours will be displayed in military time. For day, Sunday is considered day one (001), Monday is day two (002) and so on.

7. Press the ST ART (enter) keypad when the correct value appears in the display. The next option, “dCyC” will appear in the display.

NOTE: To program “dCyC” (Default Cycle), refer to option 1. To program other options, refer to the appropriate section.

How to Exit Programming Feature

Press the #5 (<) keypad until the control returns to Ready Mode.

4. Press the #3 ( ) or the #6 ( ) keypad to scroll through the programmable options. Refer to Table 11.

ALd1”

“

“ALd2”

“ALd3”

Auto-Water Leak Detection (“oFF” or “0” through “127” cycles [on] - Number of completed cycles after which this test will occur)

Auto-Water Leak Detection Hour (“0” - “23” - Hour of the day this test will occur)

Auto-Water Leak Detection Day of Week (“0” - “127” - Refer to Table 4)

Table 11

F8208801

Collecting Audit Information

This feature allows the owner to retrieve audit information stored in the machine by pressing a sequence of pads on the control.

How to Enter Audit Feature

1. Control must be in Manual Mode to start. Refer to Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until “AUdt” appears.

3. Press the START (enter) keypad. “CyC” will appear.

How to Read Audit Data

1. Use the #3 ( ) or the #6 ( ) keypad to scroll through various options until the desired option is shown in the display. Refer to the Audit Options List, Table 12, for an explaination of the audit options available.

Audit Options List

# Display Description

“CyC” Total # of machine cycles

“rCyC”* Total # of rapid advance cycles

*Option available on Software Version 2 or later.

Table 12

2. Press the START (enter) keypad once to start the audit count. At this point, the display will show the first four-digit segment of the audit value. If the audit count is 10,000 or higher, press the ST ART (enter) keypad again to view the last four digits of the number.

NOTE: The display can show up to 4 digits at one time. Audit counts 10,000 or higher are separated into two 4-digit segments. Each time the START (enter) keypad is pressed in step 2, the display will show the next 4-digit segment in the audit value. If the value is 9,999 or less, only one 4-digit segment will be shown.

3. Press the START (enter) keypad again. The control will go to the next audit option in the Audit Options List.

4. To select other audit options, repeat steps 1-4.

How to Exit Audit Feature

Press the #5 (<) keypad.

F8208801

Manual Reset

This feature allows the owner to reset the machine control’s programming data to the factory default settings by pressing a sequence of pads on the control. For an explanation of the Factory Default Settings, refer to Table 1.

How to Enter Manual Reset

1. Control must be in Manual Mode to start. Refer to Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until “rSEt” appears.

3. Press the ST AR T (enter) keypad. The control will be blank until the programming is complete. Once the program has been reset, the control will display the next Manual Mode option, “dIAg”.

F8208801

Testing Machine and

><>

Electronic Control Functions

This feature allows the owner to run diagnostic tests on various machine operations without servicing the machine. The following tests are available:

• Front End Control Software Version Number

• Output Board Control Software Version Number

• Output Board Water Level Sensor Trim Value

• Top Cover Opening Test

• Door Switch Input Test

• Door Lock Input Test

• Show Fill Time Test

• Show Drain Time Test

• Temperature Sensor Display Test

• VFD Balance Input Test

• 24 VAC Switch Input Test

• VFD Drive Fault Input Test

• Frame Balance Switch Input Test

• VFD Balance Weight Test (Design 1 and 2

models only)

How to Enter Diagnostic Testing Feature

1. Control must be in Manual Mode. Refer to Entering the Manual Mode.

2. Press the #3 ( ) or the #6 ( ) keypad until “dIAg” appears.

3. Press the START (enter) keypad. Display will change to “d001” indicating the front end control software version number test.

4. Press the #3 ( ) or the #6 ( ) keypad to scroll through the diagnostic test options.

How to Start Tests

To start a diagnostic test, refer to the quick reference chart (Table 13). Press the START (enter) keypad when the desired test number is displayed. For detailed information on each test, read the appropriate description.

How to Exit Diagnostic Testing Feature

Press the #5 (<) keypad. The display will return to the previous mode of operation.

• Water Purge Test

• Water Leak Detection Test

The following are available on Design 4 mod els only:

• Drive Software Version Number

• Drive Parameter Table Version Number

• Drive Type Value

• Drive DC Bus Display Test

F8208801

Testing Machine and Electronic Control Functions

Diagnostic (Testing) Mode – Quick Reference Chart

Test Number Diagnostic Mode Display

“d001” Front End Control Software Version # Test “d002” Output Board Control Software # Test “d003” Output Board Water Level Sensor Trim Value “d004” Top Cover Opening Test “d009” Door Switch Input Test “d010” Door Lock Input Test “d011” Show Fill Time Test “d012” Show Drain Time Test “d013” Temperature Sensor Display Test “d014”Start Pulse Test “d015” VFD Balance Input Test (Design 1 and 2) “d016” 24 VAC Switch Input Test (Design 1 and 2) “d017” VFD Drive Fault Input Test (Design 1 and 2) “d018” Frame Balance Switch Input Test “d019” VFD Balance Weight Test (Design 1 and 2)

Drive DC Bus Display Test (Design 4)

“d020” Water Purge Test “d021” Water Leak Detection Test “d022” Drive Software Version Number (Design 4) “d023” Drive Parameter Table Version Number

(Design 4)

“d024” Drive Type Value (Design 4)

“S xx” “o xx” “txxx” “A oP” or “A CL” “drCL” or “drOP” “drUL” or “drLO” “Fxxx” “dxxx” “xxxF” or “xxxC” “Stxx” “bAoP” or “bACL” “ACoP” or “ACCL” “dFoP” or “dFCL” “FSoP” or “FSCL” “bAL” “dCb” “PUrg” “Ld” “drxx” “dPxx”

“dt x”

Table 13

F8208801

Testing Machine and Electronic Control Functions

Diagnostic Test Descriptions

Front End Control Software Version Number Test

This option displays the front end control software version number. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “S xx” where “xx” is the front end control software version number.

To exit the Front End Control Software Version Number T est, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Output Board Control Software Version Number

This option displays the output board control software version number. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “o xx” where “xx” is the output board control software version number.

To exit the Output Board Control Software Version Number T est, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Output Board Water Level Sensor Trim Value

This option displays the output board water level sensor trim value. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “txxx” where “xxx” is the trim value sent from the output board to the front end control.

Top Cover Opening Test

This option tests the top cover switch. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o en ter, press the START (enter) keypad. Th e display will show “A oP” when the top cover switch is open and “A CL” when the top cover switch is closed.

The top cover switch has to be closed for at least one (1) second and opened for at least a half a second for the display to change. This test will add a count to the top cover opening counter for the audit and save the date/time for every opening of the test.

To exit the Top Cover Opening Test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Door Switch Input Test

This test will display whether the machine door is open or closed.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

To enter, press the START (enter) keypad. If the door is closed, the display will show “drCL”. If the door is open, the display will show “drOP”.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Door Lock Input Test

This test will display whether the door is locked or unlocked.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

To exit the Output Board Water Level Sensor Trim Value, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

F8208801

Testing Machine and Electronic Control Functions

Show Fill Time Test

This test will display the average low level fill time. This average will be calculated by taking the average of the last 10 fill times from the start of the fill until the low level is reached.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “Fxxx”. The “xxx” will be the average fill time in seconds.

To exit the Show Fill Time Test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Show Drain Time Test

This test will display the average drain time. This average will be calculated by taking the average of the last 10 drain times.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “dxxx”. The “xxx” will be the average drain time in seconds.

To exit the Show Drain Time Test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Temperature Sensor Display Test

This test is only available on machines equipped with a temperature sensor. This option displays the temperature sensed at the sensor.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “xxxF” for the temperature in degrees Fahrenheit or “xxxC” for the temperature in degrees Celcius. The display will show “SH” if the sensor is shorted or “oP” if the control senses an open sensor.

VFD Balance Input Test (Design 1 and 2 Models)

This option tests the VFD balance switch. To start test, control must be in the Diagnostic Testing

Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

To enter, press the START (enter) keypad. If the VFD balance switch is open, indicating poor balance, the display will show “bAoP”. If the switch is closed, indicating good balance, the display will show “bACL”.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

24 VAC Switch Input Test (Design 1 and 2 Models)

This option tests the 24 VAC switch. To start test, control must be in the Diagnostic Testing

Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

To enter, press the START (enter) keypad. If the 24 VAC switch is open, the display will show “ACoP”. If the switch is closed, the display will show “ACCL”.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

VFD Drive Fault Input T est (Design 1 and 2 Models)

This option tests the drive fault input. To start test, control must be in the Diagnostic Testing

Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

To enter, press the START (enter) keypad. If the drive fault input is open, the display will show “dFoP”. If the switch is closed, the display will show “dFCL”.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

T o exit the Temperature Sensor Display T est, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

F8208801

Testing Machine and Electronic Control Functions

Frame Balance Switch Input Test

This option tests the frame balance switch. To start test, control must be in the Diagnostic Testing

Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the ST ART (enter) keypad. If the frame balance switch is open, the display will show “FSoP”. If the switch is closed, the display will show “FSCL”.

To exit the test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

VFD Balance Weight Test (Design 1 and 2 Models)

This test is only available on machines equipped with a variable frequency motor drive.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “bAL” and the START keypad LED will flash. Close the door. Press the STAR T (enter) keypad. The door will lock. The motor will turn at distribution speed. The control monitors the VFD balance switch for frequency and displays a corresponding message. Refer to Table 14.

VFD Balance

Switch Frequency

0 Switch is

1 Hz 2 Hz

3 Hz

Description Display

always closed

“CLoS”

“1 H” “2 H” “3 H”

Drive DC Bus Display Test (Design 4

Models)

This test is only available on machines equipped with a custom drive.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o en ter, press the START (enter) keypad. Th e display will show “dCb” and the START keypad LED will flash. Close the door.

Press the START (enter) keypad. The door will lock. The control will turn on the drive and ramp up the motor to distribution speed. The drive’s DC Bus Voltage will display.

Water Purge Test

This option empties all water from the machine. To start test, control must be in the Diagnostic Testing

Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o en ter, press the START (enter) keypad. Th e display will show “PUrg” and the START keypad LED will flash. Close the door. Press the STAR T (enter) keypad. The door will lock. The display will show “FLSH”. The control will energize all water valves and supply outputs while keeping the drain valves open.

The test will end, return to Water Purge Test start prompt, and door will unlock if any keypad is pressed, the door is unlocked or opened, if an end test communication is received or if two minutes has occured since the test began. The control will prevent the door from being unlocked until there is no water in the machine.

Switch is

always open

Table 14

Press the START (enter) keypad to stop the test. The door will not unlock until the basket stops or the coast time has expired.

“oPEn”

F8208801

Testing Machine and Electronic Control Functions

Water Leak Detection Test

This option allows the owner to test for a water leak in the machine.

To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “Ld” and the ST ART keypad LED will flash if the door is closed. Press the START (enter) keypad. The door will lock. The control closes the drain valve, turns the pump off and fills the machine with cold water to low level. The water level is monitored for 2 minutes and the display shows an alternating horizontal segment while the control is monitoring the water level. If the water level is the same after 2 minutes, control will display “PASS”, water will drain, door will unlock and control will return to Ready Mode.

If water level is lower, indicating a leak in the drain, control will display “FAIL”, water will drain, door will unlock and water leak detection error will display as “ELd”.

On Design 4 models, if water level is higher, indicating a leak in the fill valve, control will display “FAIL”, water will drain, door will unlock and water leak detection error will display as “ELF”.

Drive Software Version Number Test (Design 4 models only)

This option displays the custom drive software version number. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “drxx” where “xx” is the custom drive software version number.

To exit the Custom Drive Software Version Number Test, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Drive Parameter Table Version Number (Design 4 models only)

To exit the Custom Drive Parameter Table Version Number T est, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Drive Type Value (Design 4 models only)

This option displays the custom drive type value. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o en ter, press the START (enter) keypad. Th e display will show “dt x” where “x” is the custom drive type value. Refer to Figure 15.

Display Drive Type

“dt 1” 2 HP drive “dt 2” 3 HP drive “dt 3” 5 HP 280V drive “dt 4” 5 HP 480V drive

Table 15

To exit the Custom Drive Type Value, press the #5 (<) keypad. The control will return to the Diagnostic Testing Mode.

Production Test Cycle

To Enter Production Test Cycle

1. Be certain control is in Ready Mode and top cover or coin vault is open.

2. While pressing and holding the #3 keypad with one hand, press the #7 keypad with the other hand.

3. When the control enters the Production Test Cycle, it will first display “Sxx” with the “xx” showing the software version of the front end control.

4. The control will advance through the sequence of test steps whenever any key is pressed. Refer to Table 16 for all tests in the Production Test Cycle.

To Exit Production Test Cycle

This option displays the custom drive parameter table version number. To start test, control must be in the Diagnostic Testing Mode. Refer to How to Enter Diagnostic Testing Feature at the beginning of this section.

T o enter, press the START (enter) keypad. The display will show “dPxx” where “xx” is the custom drive parameter table version number.

F8208801

To exit a test step, power down the machine.

Testing Machine and Electronic Control Functions

Production Test Cycle Quick Reference Chart

Display Test Cycle Step Comments

“Sxx” FEC Control Software

xx is the software version number.

Version

“oxx” Output Board Software

xx is the software version number.

Version

“Ct 3” Co ntrol Type xx is the control type. “oPL” Control Type OPL. “USA” Control Type Domestic “drAn” or “PUnP” Drain Type Drain or Pump. “tEnP” Temp Sensor Step skipped if not Temperature Sensor-equipped. “HEAt” Heater Step skipped if not heater-equipped. “rot” Rotation Sensor Step skipped if not Rotation Sensor-equipped. “LdC” or “LAC” Door Lock Type “LdC” if 24 VDC lock or “LAC” if 240 VAC unlock solenoid. “droP” or “drCL” Door Status Door open or closed. “drUL” or “drLo” Door Lock Status Door will lock. “8.8.8.8.” + all LEDs Display Test All display elements are lit. “PAxx” where xx = 1

Keypad Test step Advance after all keypads are pressed.

through 12 “Axx” Top Cover Switch Test xx is either “CL” for closed or “oP” for open. “Cxxx” or “Pxxx” Machine Type/Size “drxx” Drive Software Version

xx is the drive software version number. Design 4 models only.

Number

“dPxx” Drive Parameter Table

Version Number

“dt x

” Drive Type Value xx is the drive type value. Design 4 models only.

xx is the drive parameter table version number. Design 4 models only.

“HFIL” Hot Fill to Low Level All water outputs turned off when Low Level reached. “CFIL” Cold Fill to Low Level All water outpu ts turned off when Low Level reached. “bFIL” Warm Fill to Low Level All water outputs turned off when Low Level reached. “bFIH” Warm Fill to High Level All water outputs turned off when High Level reached. “S1” Supply #1 “S2” Supply #2 “S3” Supply #3 “S4” Supply #4

Table 16 (continued)

F8208801

Testing Machine and Electronic Control Functions

Table 16 (continued)

Production Test Cycle Quick Reference Chart

Display Test Mode Comments

“oFLo” Warm Fill to Overflow “xxxF” degrees F or

“xxxC” degrees C

Heat water to 110°F or display temperature

xxx is degree temperature. This step skipped if not temp-

sensor-equipped. Heater turned off when temperature reached. depending on the Fahrenheit/Celsius programming parameter

“LoAg” then “ xxx” Reduced Wash Speed Forward

This step skipped on 2 Speed models.

with no agitation action

“ Ag” then “ xxx” Wash Speed Forward with no

agitation action

“ rAg” then “ xxx” Wash Speed Reverse with no

agitation action

“drAI” then “ xxx” Drain Distribution Speed “PUrg” Factory Valve Purge “SP 1” then “ xxx” Extract Speed #1 “very low” This step skipped on 2 Speed models. “SP 2” then “ xxx” Extract Speed #2 “low” This step skipped on 2 Speed models. “SP 3” then “ xxx” Extract Speed #3 “medium” This step skipped on 2 Speed Design 1 and 2 models and

L-Speed Design 4 models. “SPIn” (2 Speed models)

then “

xxx”

This step skipped on VFD models.

“Prdn” End of test Turn Power off

NOTE: On models equipped with a rotation sensor,

xxx” will represent RPM’s and it will alternate

“ with the other display.

Table 16

F8208801

Error Codes

Following is a list of possible error codes for an electronic control. Errors beginning with “EI” refer to external device Infra-red communication errors. All other errors refer to machine errors.

Display Description Cause/Corrective Action

EI01 Transmission Failure Communication failure. Re-aim external device and try again. EI02 Time-out Error Communication failure. Re-aim external device and try again. EI03 Invalid Command Code Communication successful, but the command was not valid

for this machine type, or the control could not perform the command in its current mode of operation. Ensure data is for current machine type and control is in correct mode.

EI04 Expecting Upload Request Communication failure. Re-aim external device and try again. EI05 Invalid or Out-of-Range Data The value in at least one of the programming options is

invalid or out of range. Recheck the programming option’s value and try again.

EI09 CRC-16 Error Communication failure. Re-aim external device and try again. EI0A Framing Error Communication error. Re-aim external device and try again. EI0C Time-out Exceeded Communication error. Re-aim external device and try again. EI0E Encryption Error Communication error. Re-aim external device and try again.

If the problem persists, check that the security code is correct.

EI0F Infra-red Disabled Communication failure or infra-red is disabled. Manually

enable infra-red on control or re-aim external device and try again.

EFL Fill Error Programmed water level not reached within 10 minutes (or

other programmed length of time) in any fill agitate cycle. End cycle. Power down machine to clear.

ESP SPI Communications Error Front End control cannot communicate with output board.

Power down the machine, power up and try again.

EdL Door Lock Error Door does not lock immeadiately upon closing (open and

reclose door) or doesn’t unlock 5 seconds after cycle completion. Power down machine and retry.

Edo Door Open Error Control detects door open. Caused by pulling on door while

locked or about to lock. Correct inoperative door locking system. End cycle. Power down machine to clear.

EUb Unbalance Error Unable to balance load. Redistribute load and run cycle. door Door Open Indicator Door is not closed in Start Mode. If door is closed, check for

improper wiring or faulty door switch.

Table 17 (continued)

F8208801

Error Codes

Display Description Cause/Corrective Action

Edr Drain Alarm Error Machine not drained within 15 minutes (or other programmed

length of time) in any drain step. End cycle. Power down machine to clear.

EHt Heat Alarm Erro r Programmed heat alarm time of 120 minutes or other

programmed length of time is exceeded. Turns off heater output for remainder of cycle.

EoP Open Temperature Sensor Error Control senses temperature less than 0°F (-18°C) in machine

equipped with temperature sensor. Heater and thermistor related operations are disabled.

ESH Shorted Temperature Sensor Error Control senses temperature greater than 220°F (104°C) in

machine equipped with temperature sensor. Heater and thermistor related operations are disabled for remainder of cycle.

Ero Rotation Sensor Error Invalid signal received from Rotation Sensor. Control will

activate coast times to complete cycle.

EFS Frame Balance Switch Error Control detects Frame Balance Switch open. End cycle. Edb Drive Balance Switch Error Control detects VFD Balance Switch input closed at start of

drain step. End cycle. Power down machine to clear.

ELd W ater Leak Detection Error Control senses a drop in water level during diagnostic testing,

power down machine to clear. When error occurs during a cycle, “ELd” is displayed for one minute after opening the door at the end of the cycle. When the error occurs during the test, “ELd” is displayed immediately after the test until the machine is powered down to clear the error.

ESd Slow Drain Error Control shows error after door is open (when cycle is

completed) for one minute, the error information will be logged in audit data.

ELF* Water Leak Detection Error (Fill Valve) Control senses an increase in water level during diagnostic

testing, power down machine to clear. When error occurs during a cycle, “ELF” is displayed for one minute after opening the door at the end of the cycle. When error occurs during a test, “ELF” is displayed immediately after the test until the machine is powered down to clear the error.

*Design 4 models only.

Table 17 (continued)

F8208801

Error Codes

Table 17 (continued)

Display Description Cause/Corrective Action

Ed01* SPI Communication Error Front End control cannot communicate with motor drive.

Power down, verify input power and 6-pin communication connection on drive and Front End control, power up and try again.

Ed02* DC Bus Error The control detects the DC bus is too high. Power down,

verify line voltage is within specification, power up and try again.

Ed03* Tachometer Error The drive detects the tachometer input is damaged during

power up or no tachometer signal is detected after initiating motor output. Power down, verify H3 on drive and tachometer connections on motor, power up and try again.

Ed04* Locked Rotor Error Motor does not reach speed at startup. Power down, verify

motor mounting and look for obstructions, power up and try again.

Ed05* IGBT Overcurrent Error The drive detects an overcurrent shunt condition. Power

down machine for a minimum of two minutes, verify the motor is not shorted phase to phase or phase to ground. Power up and try again. If problem persists, replace drive.

Ed06* Thermal Error The control detects a high IPM temperature. Power down,

verify convection around drive heat sink, power up and try again.

Ed07* No Setup Error The drive receives movement commands without receiving a

setup packet. Power down, power up and try again.

Ed08* Max Over Current Error The drive detects motor output overcurrent condition. Power

down, power up and try again.

Ed09* Current Sensor Error The drive detects a current sensor is not operating properly at

startup. Power down, power up and try again. If problem persists, replace drive.

*Design 4 models only.

Table 17

F8208801

Rapid Advance Feature

The Rapid Advance feature allows the owner to quickly advance through active cycles .

How to Use Rapid Advance

Control must be in an active cycle to use the Rapid Advance feature.

While in the Rapid Advance Mode, pressing the ST AR T (enter) keypad will advance the machine to the next cycle step. The cycle indicator lights will tell which cycle step the machine is in.

For Example: If the machine is in the first fill cycle step, pressing the START (enter) keypad will advance the machine into the Agitate cycle step.

Continue pressing the START (enter) keypad until the cycle is completed.

How to Exit Rapid Advance Feature

1. Advance through the cycles until reaching the Start Mode.

NOTE: The Rapid Advance option must be programmed “on” for Rapid Advance to work. Refer to option 13 in Programming Control.

F8208801

Communications Mode

Infra-red Communications

The Infra-red Communications feature allows the control to communicate with an external device. The control can be programmed and have its data read without using the keypad. It may also be used to start and stop various diagnostic tests.

How to Begin Communications with An External Device

The control will go blank and the display will show “-C-” until the communication is complete. If an error occurs that terminates communication, the display will show “EIXX” (“XX” represents the error code).

NOTE: The Infra-red Communications option must be turned on. Refer to option 6 in Programming Control.

F8208801

Default Cycles

Perm Press

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Wash 1 (Wash - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.) 7 7 2 2 2 2 2 Fill Temperature Hot Hot Warm Warm Warm Warm Warm Fill Level Low Low High High High High High Supply S1, S2 S1, S2 OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Y es Spin (min.) 0000000

Wash 2 (Wash - ON/OFF) OFF OFF ON ON ON ON ON

Time for agitation (min.) 2 2 6 6 7 7 10 Fill Temperature Cold Cold Hot Hot Hot Hot Hot Fill Level Low Low Low Low Low Low Low Supply OFF OFF S1 S1 S1 S1 S1 Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Y es Spin (min.) 0000000

Light

Soil

CY01 CY02 CY03 CY04 CY05 CY06 CY07

18/3/18 Normal

Cotton/Terry

Light

Soil

18/3/18

Normal

Perm Press

Medium Soil

18/3/18 Normal

Cotton/Terry Medium Soil

18/3/18

Normal

Perm Press

Heavy Soil

18/3/18 Normal

Cotton/Terry

Heavy Soil

18/3/18 Normal

Rags Heavy

Soil

18/3/18 Normal

Wash 3 (Wash - ON/OFF) OFF OFF ON ON ON ON ON

Time for agitation (min.) 2 2 6 7 7 7 6 Fill Temperature Cold Cold Hot Hot Hot Hot Hot Fill Level Low Low Low Low Low Low High Supply OFF OFF S2 S2 S2 S2 S2 Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Y es Spin (min.) 0000000

Wash 4 (Wash - ON/OFF) OFF OFF OFF OFF OFF OFF OFF

Time for agitation (min.) 2 2 2 2 2 2 2 Fill Temperature Cold Cold Cold Cold Cold Cold Cold Fill Level Low Low Low Low Low Low Low Supply OFF OFF OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Y es Spin (min.) 0000000

(continued)

F8208801

Default Cycles

(continued)

Perm Press

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Rinse 1 (Rinse - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)2222222 Fill Temperature Warm Warm Hot Hot Hot Hot Hot Fill Level High High Low Low Low Low High Supply OFFOFFOFFOFFOFFOFFOFF Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Rinse 2 (Rinse - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)2222222 Fill Temperature Warm Warm Warm Warm W arm Warm Warm Fill Level High High High High High High High Supply OFFOFFOFFOFFOFFOFFOFF Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 1 (Med.) 1 (Med.) 1 (Med.) 1 (Med.) 1 (Med.) 1 (Med.) 0

Light

Soil

CY01 CY02 CY03 CY04 CY05 CY06 CY07

18/3/18

Normal

Cotton/Terry

Light

Soil

18/3/18 Normal

Perm Press

Medium Soil

18/3/18 Normal

Cotton/Terry Medium Soil

18/3/18 Normal

Perm Press

Heavy

Soil

18/3/18

Normal

Cotton/Terry

Heavy

Soil

18/3/18 Normal

Rags Heavy

Soil

18/3/18 Normal

Rinse 3 (Rinse - ON/OFF) OFF OFF OFF OFF OFF OFF OFF

Time for agitation (min.)2222222 Fill Temperature Cold Cold Cold Cold Cold Cold Cold Fill Level Low Low Low Low Low Low Low Supply OFFOFFOFFOFFOFFOFFOFF Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Rinse 4 (Rinse - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)4445454 Fill Temperature Warm Warm Warm Warm W arm Warm Warm Fill Level Low Low Low Low Low Low Low Supply S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 4 (Med.) 5 (Med.) 4 (Med.) 5 (Med.) 4 (Med.) 5 (Med.) 5 (Med.)

Default Cycle Time (hh:mm:ss)

2-speed 00:29:20 00:30:20 00:41:50 00:43:50 00:42:50 00:44:50 00:44:50

L-speed and

M-speed

(Design 1

and 2)

L and M-

speed

(Design 4)

00:30:50 00:31:50 00:43:20 00:45:20 00:44:20 00:46:20 00:45:35

00:31:02 00:32:02 00:43:02 00:45:02 00:43:02 00:46:02 00:45:02

(continued)

F8208801

Default Cycles

(continued)

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Wash 1 (Wash - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)2622222 Fill Temperature Warm Cold Warm Warm Warm Warm Warm Fill Level High High Low Low Low Low Low Supply OFF S1 OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Wash 2 (Wash - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)12266666 Fill Temperature Hot Cold Hot Hot Hot Hot Hot Fill Level Low High Low Low Low Low Low Supply S1 OFF S1, S2 S1, S2 S1, S2 S1, S2 S1, S2 Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Reclaim

CY08 CY09 CY10 CY11 CY12 CY13 CY14

18/3/18

Normal

Delicates

Cold

10/20/10

Gentle

90C 60C 40C

18/3/18 Normal

Normal

18/3/18

90C Perm

Press

18/3/18 Normal

60C Perm

Press

18/3/18 Normal

Wash 3 (Wash - ON/OFF) ON OFF OFF OFF OFF OFF OFF

Time for agitation (min.)12222222 Fill Temperature Hot Cold Cold Cold Cold Cold Cold Fill Level High Low High High High High High Supply S2 OFF OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Wash 4 (Wash - ON/OFF) OFF OFF OFF OFF OFF OFF O FF

Time for agitation (min.)2222222 Fill Temperature Cold Cold Cold Cold Cold Cold Cold Fill Level Low Low Low Low Low Low Low Supply OFF OFF OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

(continued)

F8208801

Default Cycles

(continued)

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Rinse 1 (Rinse - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)4222222 Fill Temperature Cold Cold Cold Cold Cold Cold Cold Fill Level High High High High High High High Supply OFFOFFOFFOFFOFFOFFOFF Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 0000000

Rinse 2 (Rinse - ON/OFF) ONOFFONONONONON

Time for agitation (min.)2222222 Fill Temperature Warm Cold Cold Cold Cold Cold Cold Fill Level High Low High High High High High Supply OFFOFFOFFOFFOFFOFFOFF Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 1 (Med.) 0 1 (Med.) 1 (Med.) 1 (Med.) 1 (Med.) 1 (Med.)

Reclaim

CY08 CY09 CY10 CY11 CY12 CY13 CY14

18/3/18

Normal

Delicates

Cold

10/20/10

Gentle

90C 60C 40C

18/3/18 Normal

Normal

18/3/18

90C Perm

Press

18/3/18 Normal

60C Perm

Press

18/3/18 Normal

Rinse 3 (Rinse - ON/OFF) OFF OFF OFF OFF OFF OFF OFF

Rinse 4 (Rinse - ON/OFF) ON ON ON ON ON ON ON

Time for agitation (min.)4433333 Fill Temperature Warm Cold Cold Cold Cold Cold Cold Fill Level Low High High High High High High Supply S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 S3, S4 Heat (if enabled) No No No No No No No Drain Yes Yes Yes Yes Yes Yes Yes Spin (min.) 5 (Med.) 3 (Low) 5 (Med.) 5 (Med.) 5 (Med.) 3 (Med.) 3 (Med.)

Default Cycle Time (hh:mm:ss)

2-speed 00:55:50 00:26:20 00:32:20 00:32:20 00:32:20 00:30:20 00:30:20

L-speed and

M-speed

(Design 1

and 2)

L and M-

speed

(Design 4)

00:57:20 00:27:05 00:33:50 00:33:50 00:33:50 00:31:50 00:31:50

00:57:02 00:26:02 00:34:02 00:34:02 00:34:02 00:32:02 00:32:02

(continued)

F8208801

(continued)

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Wash 1 (Wash - ON/OFF) ON ON ON ON OFF

Time for agitation (min.) 2 2 2 2 2 Fill Temperature Warm Warm Warm Cold Cold Fill Level Low Low Low High Low Supply OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Spin (min.) 00000

Wash 2 (Wash - ON/OFF) ON ON ON ON OFF

Time for agitation (min.) 6 6 6 3 2 Fill Temperature Hot Hot Hot Cold Cold Fill Level Low Low Low High Low Supply S1, S2 S1, S2 S1, S2 S1, S2 OFF Heat (if enabled) Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Spin (min.) 00000

40C Perm

Press

CY15 CY16 CY17 CY18 CY19-CY30

18/3/18 Normal

70C Perm

Press

18/3/18 Normal

50C Gentle 30C Gentle Blank

10/20/10

Gentle

10/20/10

Gentle

18/3/18

Normal

Default Cycles

Wash 3 (Wash - ON/OFF) OFF OFF OFF OFF OFF

Time for agitation (min.) 2 2 2 2 2 Fill Temperature Cold Cold Cold Cold Cold Fill Level Low High High Low Low Supply OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Spin (min.) 00000

Wash 4 (Wash - ON/OFF) OFF OFF OFF OFF OFF

Time for agitation (min.) 2 2 2 2 2 Fill Temperature Cold Cold Cold Cold Cold Fill Level Low Low Low Low Low Supply OFF OFF OFF OFF OFF Heat (if enabled) Yes Yes Yes Yes Yes Drain Yes Yes Yes Yes Yes Spin (min.) 00000

(continued)

F8208801

Default Cycles

(continued)

Cycle Stops

Cycle reference (display in Program Mode)

Agitation type

Rinse 1 (Rinse - ON/OFF) ON ON ON ON OFF

Time for agitation (min.)22222 Fill Temperature Cold Cold Cold Cold Cold Fill Level High High High High Low Supply OFF OFF OFF OFF OFF Heat (if enabled) No No No No No Drain Yes Yes Yes Yes Yes Spin (min.) 00000

Rinse 2 (Rinse - ON/OFF) ON ON ON ON OFF

40C Perm

Press

CY15 CY16 CY17 CY18 CY19-CY30

18/3/18 Normal

70C Perm

Press

18/3/18 Normal

50C Gentle 30C Gentle Blank

10/20/10

Gentle

10/20/10

Gentle

18/3/18

Normal

Rinse 3 (Rinse - ON/OFF) OFF OFF OFF OFF OFF

Time for agitation (min.)22222 Fill Temperature Cold Cold Cold Cold Cold Fill Level Low Low Low Low Low Supply OFF OFF OFF OFF OFF Heat (if enabled) No No No No No Drain Yes Yes Yes Yes Yes Spin (min.) 00000

Rinse 4 (Rinse - ON/OFF) ON ON ON ON OFF

Time for agitation (min.)33332 Fill Temperature Cold Cold Cold Cold Cold Fill Level High High High High Low Supply S3, S4 S3, S4 S3, S4 S3, S4 OFF Heat (if enabled) No No No No No Drain Yes Yes Yes Yes Yes Spin (min.) 3 (Med.) 3 (Med.) 3 (Low) 2 (Low) 0

Default Cycle Time (hh:mm:ss)

2-speed 00:30:20 00:30:20 00:30:20 00:26:20 00:00:20

L-speed and

M-speed

(Design 1

and 2)

L and M-

speed

(Design 4)

00:31:50 00:31:50 0 0:31:50 00:27:50 00:00:20

00:32:02 00:32:02 0 0:29:32 00:25:32 00:00:32

F8208801

Alliance Laundry Systems UWU045K2L, UWL035K12, UWL035K1L, UWL035K1M, UWL045K1L Programming Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
