Qu Mixer MIDI Protocol V1.9+ 1 CD 13/03/2017 iss.1
Qu Mixer MIDI Protocol - Firmware V1.9+ March 2017
This protocol is for use with the Qu-16, Qu-24, Qu-32, Qu-Pac and Qu-SB loaded with firmware version
V1.9 or later.
Note Firmware V1.9 added new MIDI messages for:
Remote shutdown command added.
Note For firmware V1.5 onwards the MIDI channel numbers and NRPN ID previously used by Mute
Groups were re-allocated to the added DCA Groups to be consistent with other Allen & Heath mixers.
Mute Groups channel numbers were changed and are as detailed in this specification.
Qu transmits MIDI messages when its controls are operated. It also responds to parameter changes it
receives via MIDI, for example from a computer or an external MIDI controller.
MIDI communicates via:
USB – Rear panel USB B port for direct connection to Apple Mac computers running OSX 10.6 or later.
This is the recommended connection for DAW control.
Note USB MIDI is supported natively by Apple Mac computers so no driver is needed. A driver for
Windows computers can be downloaded from the Allen & Heath web site.
TCP – Rear panel network port for use with a computer, a touch panel or other remote controller with
configurable MIDI over a TCP/IP port.
Note TCP MIDI requires a driver for the data to be seen as a MIDI port. An Allen & Heath TCP MIDI driver
for Apple Mac computers can be downloaded from the iLive Software web page. A driver is not available
for Windows computers.
Note Qu currently allows only one TCP MIDI connection at a time over its Network port.
The following Qu functions can be controlled via MIDI:
Mutes
Faders and Pan
Mix and FX sends - Level, Pan, Assign, Pre/Post
Matrix sends (not Qu-16) – Level, Pan, Assign, Pre/Post
Audio Groups (not Qu-16) – Assign, (plus Level, Pan, Pre/Post if in Mix mode)
Mute Groups – Assign, Master Mute
DCA Groups – Assign, Master Level, Master Mute
PAFL select
Input Channel source
Preamp (local and dSNAKE) – Gain, Pad, 48V
Insert In/Out
Input Channel processing – Trim, Polarity, Gate, PEQ, Compressor, Delay
Mix processing - PEQ, GEQ, Compressor, Delay
Group and Matrix processing – PEQ, GEQ, Compressor, Delay (not Qu-16)
Channel Names
Scene Recall
FX Tap Tempo
MMC Transport Control
Remote Shutdown
Qu Mixer MIDI Protocol V1.9+ 2 CD 13/03/2017 iss.1
DAW Control for Mac computers:
MIDI fader strips can be assigned to the Custom Layer to work with a DAW (Digital Audio Workstation).
These send/receive CC and note on/off messages using a different MIDI channel to that used for the Qu
functions described above. The MIDI fader strip sends/receives messages relating to:
Fader position
Mute key / indicator
Sel key / indicator
PAFL key /indicator
DAW Bank Up/Down
You can work directly with these messages or use the Allen & Heath DAW Control driver to convert them
into either of the following popular protocols:
HUI
Mackie Control
Note DAW Control is available for Mac computers only. A driver for Windows computers is not available.
Go to the Allen & Heath web site to download the DAW Control driver for Mac and for further information in
the DAW Control Setup Notes.
Reference
Refer to the table at the end of this document for value listings.
All MIDI message numbers shown in blue in this document are Hexadecimal
Key Blue Hexadecimal number, eg, F0
Green Variable referred to in table or note, eg, VA = parameter value
Red NRPN ID number for parameter type, eg. Polarity = 6A
Orange NRPN Index to specify a second value, eg, VX
MIDI channel number N (see table)
MIDI channel 1 to 16 = 0 to F
Qu functions use MIDI channel = N
MIDI strips (DAW controls) use MIDI channel = N+1
Channel numbers CH (see table)
FX Send 1 to 4 = 00 to 03
FX Return 1 to 4 = 08 to 0B
DCA Groups 1 to 4 = 10 to 13 Note Introduced in V1.5 firmware
Input 1 to 32 = 20 to 3F
Stereo Channels = 40 to 42
Mute Groups 1 to 4 = 50 to 53 Note This is a change introduced in V1.5 firmware
Group 1-2 to 7-8 = 68 to 6B (not Qu-16)
Mix 1 to 10 = 60 to 66
Main LR = 67
Matrix 1-2, 3-4 = 6C , 6D (not Qu-16)
Active Sensing
Qu supports MIDI Active Sensing over its TCP/IP Ethernet connection to detect connection
status. Qu will send an initial Active Sense byte (FE) once an Ethernet connection is established,
and then once every 300ms or so during any period of inactivity.
Qu also responds to Active Sense If it receives an Active Sense byte it will expect to receive
regular MIDI data from that point onwards (either valid control data, or more Active Sense bytes
during any period of inactivity). If it does not receive any data for 12 seconds, it will close the
Ethernet connection.
Qu Mixer MIDI Protocol V1.9+ 3 CD 13/03/2017 iss.1
DAW control
MIDI strips assigned to the Custom Layer can provide DAW control.
DAW messages can be translated into HUI or Mackie Control protocol using the Allen & Heath
DAW Control driver which can be downloaded from the Allen & Heath web site.
Note DAW Control is available for Mac computers only. A driver for Windows computers is not
available.
DAW messages use a different MIDI channel to other Qu MIDI messages:
Qu MIDI channel = N
DAW MIDI channel = N+1
MIDI strip controls send and respond to the following messages:
Strip Fader
Control Change message:
B(N+1), FD, VA
Where FD = Strip fader 00 to 1F (see table)
VA = Fader min to max position = 00 to 7F
Strip keys
The strip keys use NOTE ON followed by NOTE OFF messages.
Pressing keys send messages.
Key LED indicators respond to received messages.
9(N+1), KY, 7F, 9 (N+1), KY, 00
Where KY = Mute Strip 1-32 = 00 to 1F (see table)
Sel Strip 1-32 = 20 to 3F
PAFL Strip 1-32 = 40 to 5F
Bank Up/Down
Qu SoftKeys can be assigned as DAW Bank Up or Bank Down keys.
These use NOTE ON followed by NOTE OFF messages which are converted by DAW Control to
become the Bank Up/Down control.
Bank Up 9(N+1), 7E, 7F, 9(N+1), 7E, 00
Bank Down 9(N+1), 7F, 7F, 9(N+1), 7F, 00
MMC (Transport Control)
Sysex message F0, 7F, 7F, 06, TC, F7
Where TC transport control:
01 = Stop
02 = Play
04 = Fast Forward
05 = Rewind
06 = Record Strobe
09 = Pause
Qu Mixer MIDI Protocol V1.9+ 4 CD 13/03/2017 iss.1
Mute control
Mute on NOTE ON with velocity > or = 40 followed by NOTE OFF
9N, CH, 7F, 8N, CH, 00
Mute off NOTE ON with velocity < 40 followed by NOTE OFF
9N, CH, 3F, 8N, CH, 00
Received Mute messages
Velocity 00 and NOTE OFF messages are ignored
Velocity 01 to 3F = Mute off
Velocity 40 to 7F = Mute on
NRPN Parameter control
Qu mixer parameters are transmitted and received as MIDI NRPN (Non-Registered Parameter
Number) messages. The MSB (most significant byte) selects the mixer channel (CH), and the
LSB (least significant byte) selects the parameter number (ID). The data entry MSB sets the
parameter value (VA) and LSB sets the index value for its range (VX) where needed.
(NRPN MSB) (NRPN LSB) (Data MSB) (Data LSB)
BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, VX
Group Mode BN, 63, CH, BN, 62, 5E, BN, 06, VA BN, 26, 00
Where VA Group mode = 00, Mix mode = 01
Note This is unidirectional – Sent from mixer but not received
Fader BN, 63, CH, BN, 62, 17, BN, 06, VA BN, 26, 07
Where VA –inf to +10dB = 00 to 7F, 0dB = 6B (see table)
Pan BN, 63, CH, BN, 62, 16, BN, 06, VA BN, 26, VX
Where VA Full Left = 00 to Centre = 25 to Full Right = 4A
VX 04 , 05, 06, 07 = Mix 5-6, 7-8, 9-10, LR
VX 08 , 09, 0A, 0B = Grp 1-2, 3-4, 5-6, 7-8 (in Mix mode)
VX 0C, 0D = MTX1-2, 3-4 (not Qu-16)
LR Assign BN, 63, CH, BN, 62, 18, BN, 06, VA BN, 26, 07
Where VA Off = 00, On = 01
Mix Assign BN, 63, CH, BN, 62, 55, BN, 06, VA BN, 26, VX
Where VA Off = 00, On = 01
VX 00 to 0B = Mix1 to 9-10, LR
VX 10 to 13 = FX send 1-4 (Qu-16 FX1,2 only)
VX 08 , 09,0A, 0B, 0C, 0D = Grp1-2 to 7-8, MTX1-2 to 3-4
Mute Grp Assign BN, 63, CH, BN, 62, 5C, BN, 06, VA BN, 26, 07
Where VA Off Mute Grp 1-4 = 00 to 03,
On Mute Grp 1-4 = 40 to 43
Qu Mixer MIDI Protocol V1.9+ 5 CD 13/03/2017 iss.1
DCA Grp Assign BN, 63, CH, BN, 62, 40, BN, 06, VA BN, 26, 07
Where VA Off Mute Grp 1-4 = 00 to 03,
On Mute Grp 1-4 = 40 to 43
Mix Pre/Post BN, 63, CH, BN, 62, 50, BN, 06, VA BN, 26, VX
Where VA Post = 00, Pre = 01
VX 00 to 06 = Mix1 to 9-10
VX 08 to 0B = Grp1-2 to 7-8 (in Mix mode)
VX 10 to 13 = FX send 1-4 (Qu-16 FX1,2 only)
VX 0C, 0D = MTX1-2, 3-4 (not Qu-16)
Send Level BN, 63, CH, BN, 62, 20, BN, 06, VA BN, 26, VX
Where VA –inf to +10dB = 00 to 7F (see table)
VX 00 to 06 = Mix1 to 9-10
VX 08 to 0B = Grp1-2 to 7-8 (in Mix mode)
VX 10 to 13 = FX send 1-4 (Qu-16 FX1,2 only)
VX 0C, 0D = MTX1-2, 3-4 (not Qu-16)
PAFL select BN, 63, CH, BN, 62, 51, BN, 06, VA BN, 26, 07
Where VA Off = 00, On = 01
Ch USB Source Switches between channel current Preamp and current USB source
BN, 63, CH, BN, 62, 12, BN, 06, VA BN, 26, 00
Where VA Off (Preamp) = 00, On (USB) = 01
Ch Preamp Source Switches between mixer rear panel and remote AR rack input source
BN, 63, CH, BN, 62, 57, BN, 06, VA BN, 26, 00
Where VA Off (Local) = 00, On (dSNAKE) = 01
dSNAKE Patch BN, 63, CH, BN, 62, 5D, BN, 06, VA BN, 26, 00
Where VA = dSNAKE input socket index 00 to 27
Note This is unidirectional – Sent from mixer but not received
Local Preamp Applies to rear panel local inputs only
BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, 07
Where
Gain ID = 19 VA Gain -5dB to +60dB = 00 to 7F (see table)
48V PP ID = 69 VA Off = 00, On = 01
dSNAKE Preamp Applies to remote AR rack inputs only
BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, VX
Where
Gain ID = 58 VA Gain +5dB to +60dB = 00 to 7F (see table)
Pad ID = 59 VA Out = 00, In = 01
48V PP ID = 5A VA Off = 00, On = 01
VX = dSNAKE socket index (00 to 27) (dSNAKE input patch)
Qu Mixer MIDI Protocol V1.9+ 6 CD 13/03/2017 iss.1
Digital Trim Applies to USB source to channel only
BN, 63, CH, BN, 62, 52, BN, 06, VA BN, 26, 07
Where VA Trim -24 to +24dB = 00 to 7F 0dB = 40
Stereo Trim Applies to local ST1, ST2 and ST3 inputs only
BN, 63, CH, BN, 62, 54, BN, 06, VA BN, 26, 07
Where VA Trim -24 to +24dB = 00 to 7F 0dB = 40
Polarity BN, 63, CH, BN, 62, 6A, BN, 06, VA BN, 26, 07
Where VA Off (normal) = 00, On (reversed) = 01
Insert In/Out BN, 63, CH, BN, 62, 6B, BN, 06, VA BN, 26, 07
Where VA Out = 00, In = 01
PEQ BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, 07
Where
LF Gain ID = 01 VA -12 to +12dB = 00 to 7F 0dB = 40
LF Freq ID = 02 VA 20Hz to 20 kHz = 00 to 7F
LF Width ID = 03 VA 1.5 to 1/9 Oct = 00 to 7F
LF Type ID = 04 VA Bell = 00, Shelf = 06
LM Gain ID = 05 VA -12 to +12dB = 00 to 7F 0dB = 40
LM Freq ID = 06 VA 20Hz to 20 kHz = 00 to 7F
LM Width ID = 07 VA 1.5 to 1/9 Oct = 00 to 7F
HM Gain ID = 09 VA -12 to +12dB = 00 to 7F 0dB = 40
HM Freq ID = 0A VA 20Hz to 20 kHz = 00 to 7F
HM Width ID = 0B VA 1.5 to 1/9 Oct = 00 to 7F
HF Gain ID = 0D VA -12 to +12dB = 00 to 7F 0dB = 40
HF Freq ID = 0E VA 20Hz to 20 kHz = 00 to 7F
HF Width ID = 0F VA 1.5 to 1/9 Oct = 00 to 7F
HF Type ID = 10 VA Bell = 00, Shelf = 06
PEQ In/Out BN, 63, CH, BN, 62, 11, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
HPF Freq BN, 63, CH, BN, 62, 13, BN, 06, VA BN, 26, 07
Where VA 20Hz to 20kHz = 00 to 7F
HPF In/Out BN, 63, CH, BN, 62, 14, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
GEQ Gain BN, 63, CH, BN, 62, 70, BN, 06, VA BN, 26, VX
Where VA Gain -12 to +12dB = 00 to 7F
VX 00 to 1B = Each of 28 bands (see table)
GEQ In/Out BN, 63, CH, BN, 62, 71, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
Qu Mixer MIDI Protocol V1.9+ 7 CD 13/03/2017 iss.1
Gate BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, 07
Where
Attack ID = 41 VA 50us to 300ms = 00 to 7F
Release ID = 42 VA 10ms to 1s = 00 to 7F
Hold ID = 43 VA 10ms to 5s = 00 to 7F
Threshold ID = 44 VA -72 to +18dB = 00 to 7F
Depth ID = 45 VA 0 to 60dB = 00 to 7F
Gate In/Out BN, 63, CH, BN, 62, 46, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
Comp BN, 63, CH, BN, 62, ID, BN, 06, VA BN, 26, 07
Where
Type ID = 61 VA 4 types = 00, 01, 02, 03
Attack ID = 62 VA 300us to 300ms = 00 to 7F
Release ID = 63 VA 100ms to 2s = 00 to 7F
Knee ID = 64 VA Hard knee = 00, Soft knee = 01
Ratio ID = 65 VA 1:1 to inf = 00 to 7F, 2.6:1 = 50
Threshold ID = 66 VA -46 to +18dB = 00 to 7F
Gain ID = 67 VA 0 +18dB = 00 to 7F
Comp In/Out BN, 63, CH, BN, 62, 68, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
Delay Time BN, 63, CH, BN, 62, 6C, BN, 06, VA BN, 26, 07
Where VA Input 0 to 85ms = 00 to 40 (linear)
VA Mix 0 to 170ms = 00 to 7F (linear)
VA Group 0 to 170ms = 00 to 7F (linear)
VA Matrix 0 to 170ms = 00 to 7F (linear)
Delay In/Out BN, 63, CH, BN, 62, 6D, BN, 06, VA BN, 26, 00
Where VA Out = 00, In = 01
Remote Shutdown
Remote Shutdown BN, 63, 00 BN, 62, 5F BN, 06, 00 BN, 26, 00
Note: The QU mixer will require a hard power reset to switch on the mixer.
Qu Mixer MIDI Protocol V1.9+ 8 CD 13/03/2017 iss.1
FX Parameter Control
Delay FX Time To set delay time. Can be used for Tap Tempo.
Can use one or two NRPN messages:
Use MSB message only for course time value resolution.
Use LSB followed by MSB message for fine resolution.
LSB: BN, 63, CH, BN, 62, 49, BN, 06, VAf BN, 26, VX
MSB: BN, 63, CH, BN, 62, 48, BN, 06, VAc BN, 26, VX
Where VAf Fine resolution time value = 00 to 7F
VAc Course resolution time value = 00 to 7F
VX Delay parameter 05 = Left tap
07 = Right tap
(See table for examples of time value)
Delay FX Link To link or unlink the Left and Right tap time.
BN, 63, CH, BN, 62, 48, BN, 06, VA BN, 26, 06
Where VA Off (unlinked) = 00
On (linked) = 7F
Scene Recall
Qu uses Bank Select and Program Change messages for Scene recall. Only Bank 1 is used.
Transmitted Scene message
Qu transmits this message when a Scene is recalled using the touch screen or a SoftKey:
(Bank1 MSB) (Bank1 LSB) Recall Scene
BN, 00, 00, BN, 20, 00, CN, SS
Where SS = Scene1 to 100 = 00 to 63 (see table)
Received Scene message
Qu responds to the following message if Bank1 is currently selected:
Recall Scene
CN, SS
Where SS = Scene1 to 100 = 00 to 63 (see table)
To set Bank1
Qu will ignore Scene change messages if the Bank is not set to 1.
(Bank1 MSB) (Bank1 LSB)
BN, 00, 00, BN, 20, 00
Qu Mixer MIDI Protocol V1.9+ 9 CD 13/03/2017 iss.1
Device Connection
Note Qu currently allows only one TCP MIDI connection at a time over its Network port.
TCP Client Configuration
Clients should be configured to use TCP port 51325
Active Sensing
Qu supports MIDI Active Sensing over its TCP/IP Ethernet connection to detect connection
status. Qu will send an initial Active Sense byte (FE) once an Ethernet connection is established,
and then once every 300ms or so during any period of inactivity.
Qu also responds to Active Sense If it receives an Active Sense byte it will expect to receive
regular MIDI data from that point onwards (either valid control data, or more Active Sense bytes
during any period of inactivity). If it does not receive any data for 12 seconds, it will close the
Ethernet connection.
Qu uses Sysex messages to communicate much of its data.
Sysex Header Sysex Header
A&H ID Qu mixer Major/Minor version MIDI channel
F0, 00, 00, 1A, 50, 11, 01, 00, 0N
Get System State
An external controller such as an iPad running the Qu-Pad app can use MIDI Sysex messages to
request and receive the current parameter state of the Qu mixer.
Note On request, the mixer MIDI channel ( N ) is not known therefore an ‘All Call’ Sysex Header
is sent. The reply returns the MIDI channel number. This number should be used in subsequent
messages.
REQUEST: Sysex Header (All Call), 10 <iPadFlag>, F7
Where Sysex Header (All Call) = F0, 00, 00, 1A, 50, 11, 01, 00, 7F
And <iPadFlag> = 1 identifies the incoming connection as Qu-pad.
REPLY: Sysex Header, 11, < BoxID > , < Version > , F7
Where < BoxID > identifies the outgoing connection Qu mixer model
Where: 1 = Qu-16
2 = Qu-24
3 = Qu-32
4 = Qu-Pac
< Version > = <Major>,<Minor> = Qu firmware version (7bit data)
Subsequent push of NRPN messages to update current state.
Subsequent End Sync Response:
Sysex Header, 14, F7
If <iPadFlag> is set in the initial request the Qu mixer will expect to receive an Active Sense byte
within 5 seconds. If not, it will close the Ethernet connection. This is how the lost communication
mechanism is enforced for Qu-Pad.
Qu Mixer MIDI Protocol V1.9+ 10 CD 13/03/2017 iss.1
Channel Naming
Get Name from Qu
REQUEST: Sysex Header, 01, CH, F7
REPLY: Sysex Header, 02, CH, <Name>, F7
Where < Name > = string of hex ascii characters
Set Name Sysex Header, 03, CH, <Name>, F7
Where < Name > = string of hex ascii characters
Get Meter Data
An external controller such as an iPad running the Qu-Pad app can use MIDI Sysex messages to
request and receive the current meter data from the Qu mixer.
REQUEST:
Sysex Header, 12, < MeterOnOff > , F7
REPLY:
Sysex Header, 13, < MeterData > , F7
Where < MeterData> = Push of all meter data (Described below).
Where < MeterOnOff> = 0 (meters Off), 1 (meters On)
Meter values are signed dB values, coded as fixed point 7Q8 offset 8000 format, stored as
unsigned 16 bit numbers, (transmitted in “7-bit-ized” format in the Sysex).
Encoding of meter data:
The 8-bit file data needs to be converted to 7-bit form, with the result that every 7 bytes of file
data translates to 8 bytes in the MIDI stream.
For each group of 7 bytes of file data, the top bit from each is used to construct an eighth byte,
which is sent first. For example:
AAAAaaaa BBBBbbbb CCCCcccc DDDDdddd EEEEeeee FFFFffff GGGGgggg
becomes :
0ABCDEFG 0AAAaaaa 0BBBbbbb 0CCCcccc 0DDDdddd 0EEEeeee 0FFFffff 0GGGgggg
The final group may have less than 7 bytes, and is coded as follows (example with 2 bytes in the
final group):
0AB00000 0AAAaaaa 0BBBbbbb
Example: 7-bit-ized binary 00100000 01111100 00000000
Unpacks to 8-bit-ized binary 01111100 10000000
Equivalent to hexadecimal 7C80
Remove the offset: (int16_t) 7C80 – (int16_t) 8000 = FC80
Float and scale: (float) FC80 / 256.0f = -3.5dB
Qu Mixer MIDI Protocol V1.9+ 11 CD 13/03/2017 iss.1
Transmission of meter data:
The meter data is transmitted in blocks of data in the following order:
Qu-16 Qu-24 Qu-32, Qu-Pac
16 Mono Input blocks 24 Mono Input blocks 24 Mono Input blocks (CH1-24)
80 unused meters 3 Stereo Input blocks 3 Stereo Input blocks
3 Stereo Input blocks 180 unused meters 20 unused meters
20 unused meters 4 Mono Mix blocks 8 Mono Input blocks (CH25-32)
4 Mono Mix blocks 4 Stereo Mix blocks 4 Mono Mix blocks
4 Stereo Mix blocks 2 Stereo Group blocks 4 Stereo Mix blocks
1 Stereo Monitor block 2 Stereo Matrix blocks 4 Stereo Group blocks
4 Stereo FX blocks 1 Stereo Monitor block 2 Stereo Matrix blocks
4 Stereo FX blocks 1 Stereo Monitor block
4 Stereo FX blocks
Note Stereo Mix blocks include Mix 5-6, 7-8, 9-10, LR
The meter blocks transmit the following meter data:
Mono Input block
Post Preamp
Post PEQ
Post Compressor
Post Delay
Gate Side Chain
Compressor Side Chain
Direct Out
Gate Gain reduction
Compressor Gain Reduction
Ducker Gain Reduction
Stereo Input block
Post Preamp L
Post PEQ L
Post Compressor L
Post Delay L
Gate Side Chain L
Compressor Side Chain L
Direct Out L
Gate Gain reduction L
Compressor Gain Reduction L
Ducker Gain Reduction L
Post Preamp R
Post PEQ R
Post Compressor R
Post Delay R
Gate Side Chain R
Compressor Side Chain R
Direct Out R
Gate Gain reduction R
Compressor Gain Reduction R
Ducker Gain Reduction R
Mono Mix block
TB/SigGen
Pre-Insert
Post-PEQ
Post-GEQ
Post Compressor
Post Fader
Post insert
Compressor Side Chain
Compressor Gain Reduction
Ducker Gain Reduction
Stereo Mix / Group / Matrix block
TB/SigGen L
Pre-Insert L
Post PEQ L
Post GEQ L
Post Compressor L
Post Fader L
Post Insert L
Compressor Side Chain L
Compressor Gain Reduction L
Ducker Gain Reduction L
TB/SigGen R
Pre-Insert R
Post PEQ R
Post GEQ R
Post Compressor R
Post Fader R
Post Insert R
Compressor Side Chain R
Compressor Gain Reduction R
Ducker Gain Reduction R
Qu Mixer MIDI Protocol V1.9+ 12 CD 13/03/2017 iss.1
Stereo Monitor block
PAFL L
PAFL R
PAFL Mono sum
Talkback
Signal Generator
Main Pre Fader L
Main Pre Fader R
Main Post Fader L
Main Post Fader R
Main Mono Sum Pre Fader
Main Mono Sum Post Fader
USB A Record Out L
USB A Record Out R
3 Unused Meters
RTA 31 bands L
RTA 31 bands R
Stereo FX block
Send L (at FX device input)
Send R ( “ )
Send Mono sum
Pre PEQ L
Pre PEQ R
Tap Tempo L
Tap Tempo R
Post PEQ L
Post PEQ R
9 unused meters
Qu Mixer MIDI Protocol V1.9+ 13 CD 13/03/2017 iss.1
MIDI channel Scene number Input Channel Local Gain value GEQ Bands
N N +1 SS SS CH 19 VA 70 VX
Qu Hex DAW Hex Scene Hex Scene Hex CH Hex dB Hex Freq Hex
31.5Hz 00
1 0 2 1 1 00 65 40 1 20 +60 7F 40Hz 01
2 1 3 2 2 01 66 41 2 21 +50 6B 50Hz 02
3 2 4 3 3 02 67 42 3 22 +40 57 63Hz 03
4 3 5 4 4 03 68 43 4 23 +30 44 80Hz 04
5 4 6 5 5 04 69 44 5 24 +20 30 100Hz 05
6 5 7 6 6 05 70 45 6 25 +10 1D 125Hz 06
7 6 8 7 7 06 71 46 7 26 +5 13 160Hz 07
8 7 9 8 8 07 72 47 8 27 0 0A 200Hz 08
9 8 10 9 9 08 73 48 9 28 -5 00 250Hz 09
10 9 11 0A 10 09 74 49 10 29 315Hz 0A
11 A 12 0B 11 0A 75 4A 11 2A dSNAKE Gain value 400Hz 0B
12 B 13 0C 12 0B 76 4B 12 2B 58 VA 500Hz 0C
13 C 14 0D 13 0C 77 4C 13 2C dB Hex 630Hz 0D
14 D 15 0E 14 0D 78 4D 14 2D 800Hz 0E
15 E 16 0F 15 0E 79 4E 15 2E +60 7F 1kHz 0F
16 F 1 00 16 0F 80 4F 16 2F +50 67 1k25 10
17 10 81 50 17 30 +40 50 1k6 11
18 11 82 51 18 31 +35 45 2kHz 12
19 12 83 52 19 32 +30 39 2k5 13
20 13 84 53 20 33 +25 2E 3k15 14
MIDI Strip Mute Sel PAFL 21 14 85 54 21 34 +20 22 4kHz 15
MS KY 22 15 86 55 22 35 +10 0B 5kHz 16
Strip Hex Strip Hex Hex Hex 23 16 87 56 23 36 +5 00 6k3 17
24 17 88 57 24 37 8kHz 18
1 00 1 00 20 40 25 18 89 58 25 38 Fader/Send value 10kHz 19
2 01 2 01 21 41 26 19 90 59 26 39 VA 12k5 1A
3 02 3 02 22 42 27 1A 91 5A 27 3A dBu Hex 16kHz 1B
4 03 4 03 23 43 28 1B 92 5B 28 3B
5 04 5 04 24 44 29 1C 93 5C 29 3C +10 7F
6 05 6 05 25 45 30 1D 94 5D 30 3D +5 74
7 06 7 06 26 46 31 1E 95 5E 31 3E 0 6B Delay FX time
8 07 8 07 27 47 32 1F 96 5F 32 3F -5 61 VAc VAf
9 08 9 08 28 48 33 20 97 60 ST1 40 -10 57 Time Hex Hex
10 09 10 09 29 49 34 21 98 61 ST2 41 -15 4D
11 0A 11 0A 2A 4A 35 22 99 62 ST3 42 -20 43 5ms 00 00
12 0B 12 0B 2B 4B 36 23 100 63 -25 39 100ms 44 31
13 0C 13 0C 2C 4C 37 24 FX Ret CH -30 2F 200ms 54 22
14 0D 14 0D 2D 4D 38 25 CH Hex -35 25 400ms 63 77
15 0E 15 0E 2E 4E 39 26 -40 1B 800ms 73 68
16 0F 16 0F 2F 4F 40 27 1 08 -45 11
1.36sec
7F 7F
17 10 17 10 30 50 41 28 2 09 -inf 00
18 11 18 11 31 51 42 29 3 0A Compressor Type
19 12 19 12 32 52 43 2A 4 0B 61 VA
20 13 20 13 33 53 44 2B
Type
Hex
21 14 21 14 34 54 45 2C
FX Send
CH VX
Manual Peak
00
22 15 22 15 35 55 46 2D CH Hex Hex
Manual RMS
01
23 16 23 16 36 56 47 2E Auto Slow Opto 02
24 17 24 17 37 57 48 2F 1 00 10 Auto Punchbag 03
25 18 25 18 38 58 49 30 2 01 11
26 19 26 19 39 59 50 31 3 02 12
27 1A 27 1A 3A 5A 51 32 4 03 13
28 1B 28 1B 3B 5B 52 33
29 1C 29 1C 3C 5C 53 34 Mix CH VX
30 1D 30 1D 3D 5D 54 35 Mix Hex Hex
31 1E 31 1E 3E 5E 55 36 Mute Group Mute Grp Assign
32 1F 32 1F 3F 5F 56 37 1 60 00 CH VA
57 38 2 61 01 MG Hex MG off on
58 39 3 62 02
59 3A 4 63 03 1 50 1 00 40
60 3B 5-6 64 04 2 51 2 01 41
61 3C 7-8 65 05 3 52 3 02 42
62 3D 9 -10 66 06 4 53 4 03 43
63 3E LR 67 07
64 3F DCA Group DCA Grp Assign
Grp1-2 68 08 CH VA
Grp3-4 69 09 MG Hex MG off on
Grp5-6 6A 0A
Grp7-8 6B 0B 1 10 1 00 40
MTX1-2 6C 0C 2 11 2 01 41
MTX3-4 6D 0D 3 12 3 02 42
4 13 4 03 43
DAW
Loading...
