Publication 1788-IN054A-EN-P - September 2002
Installation Instructions
EtherNet/IP Daughtercard
Catalog Number 1788-ENBT
Use this document as a guide to install the EtherNet/IP daughtercard. This
document covers only the hardware installation; refer to the FlexLogix System User
Manual, publication 1794-UM001, for information about configuring the
daughtercard.
This table lists the contents of the document and where to find specific information.
For information about See page
Important User Information 2
About the EtherNet/IP Daughtercard 4
Required Software 4
Related Publications 4
Identifying Daughtercard Components 4
Install the Daughtercard 5
Connect the Daughtercard to the Network 5
Apply Host Power 6
Daughtercard System Performance 6
Interpret the LED Status Indicators 7
Where to Find Information on Configuring the Daughtercard 9
Hazardous Location Information 10
Specifications 11
4
EtherNet/IP Daughtercard
Publication 1788-IN054A-EN-P - September 2002
About the EtherNet/IP Daughtercard
The network daughtercard architecture defines a common
hardware and software interface that several different
network interface cards will support. This lets products that
have been designed to support the network daughtercard
option support several different Rockwell Automation
networks.
You can install the 1788-ENBT EtherNet/IP daughtercard in any host device that
supports the daughtercard.
(1)
Required Software
Use RSLogix 5000 programming software V11 or later to configure a
FlexLogix/DriveLogix system for use with the EtherNet/IP daughtercard.
Related Publications
Identifying Daughtercard Components
(1)
The host device must provide suitable power source per the restrictions in the specifications table on
page 11.
Publication Title Publication Number
EtherNet/IP System Overview ENET-SO001
EtherNet/IP Media Planning and Installation Manual ENET-IN001
EtherNet/IP Performance and Application Guide ENET-AP001
FlexLogix System User Manual 1794-UM001
EtherNet/IP Daughtercard User Manual 1788-UM054
31447-M
MSN
S
LNK
U%
E
N
E
T
module status LED network status LED
link status LED utilization percent LEDRJ45 cable connector
EtherNet/IP Daughtercard
11
Publication 1788-IN054A-EN-P - September 2002
Specifications
Characteristic Value
Power Requirements
5V dc @ 465mA
(1)
Power Consumption
Thermal Dissipation
5 V dc, 2.33W
8.0 BTU/hr
Isolation Voltage Tested to withstand 500V ac for 60 seconds
Ethernet Conductors
Wiring
Category
802.3 compliant - twisted pair
2
(2)
Ethernet Connector RJ45 Category 5
Emissions CISPR 11: Group 1, Class A (with appropriate enclosure)
ESD Immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity IEC 61000-4-4:
±2kV at 5kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
±2kV line-earth (CM) on communications ports
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Enclosure Type Rating None (open-style)
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
This product is suitable for application in equipment that is rated 0 to 60
o
C
(32 to 140
o
F) maximum. It is acceptable for the ambient slot temperature
immediately surrounding this product to reach 85oC (185oF) maximum.
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock):
–40 to 85°C (–40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat):
5 to 95% non-condensing
Shock IEC60068-2-27 (Test Ea, Unpackaged Shock):
Operating 30g
Non-operating 50g
Publication 1788-IN054A-EN-P - September 2002 PN 957678-55
© 2002 Rockwell Automation. Printed in the U.S.A.
Allen-Bradley, FlexLogix, and DriveLogix are trademarks of Rockwell Automation, Inc.
RSLogix is a trademark of Rockwell Software, Inc.
Vibration IEC60068-2-6 (Test Fc, Operating):
5g @ 10-500Hz
Weight 0.1 kg (0.2 lb.)
Certifications:
(when product is marked)
c-UR-us UL Recognized Component Industrial Control Equipment for
Class I, Division 2 Group A,B,C,D Hazardous
Locations, certified for US and Canada.
CE
(3)
European Union 89/336/EEC EMC Directive, compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial
Requirements
EN 61000-6-2; Industrial Immunity
C-Tick
(3)
Australian Radiocommunications Act, compliant with:
AS/NZS 2064; Industrial Emissions
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications.
(1)
To comply with UL restrictions, this equipment must be powered from a source compliant with the following: Class 2 or
Limited Voltage/Current, as defined in UL 508 Seventeenth Edition Section 32.
(2)
For information on conductor routing refer to publications 1770-4.1, Industrial Automation Wiring and Grounding Guidelines,
and ENET-IN001, EtherNet/IP Media Planning and Installation Manual.
(3)
See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other certification details.
