Allen-Bradley 1732E-OB16M12DR, 1732E-16CFGM12R, 1732E-IB16M12SOEDR, 1732E-8X8M12DR, 1732E-OB16M12R Installation Instructions Manual

Installation Instructions

1732E ArmorBlock 2 Port Ethernet Module

Catalog Numbers 1732E-IB16M12R, 1732E-OB16M12R,
1732E-IB16M12DR, 1732E-OB16M12DR, 1732E-16CFGM12R,
1732E-IB16M12SOEDR, 1732E-8X8M12DR

Topic Page

Important User Information 2

Environment and Enclosure 3

Prevent Electrostatic Discharge 3

About the ArmorBlock 2 Port Ethernet Module 4

Catalog Number Explanation 5

Install the Module 5

Set the Network Address 6

Mount the Module 7

Product Dimensions 7

Connect the I/O, Network and Auxiliary Cables to the ArmorBlock Module 8

Interpret LED Indicators 13

Specifications 15

2 1732E ArmorBlock 2 Port Ethernet Module

Important User Information

Solid state equipment has operational characteristics differing from those of electromechanical
equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls
(publication SGI-1.1 available from your local Rockwell Automation sales office or online at

http://literature.rockwellautomation.com

equipment and hard-wired electromechanical devices. Because of this difference, and also because of
the wide variety of uses for solid state equipment, all persons responsible for applying this equipment
must satisfy themselves that each intended application of this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the
many variables and requirements associated with any particular installation, Rockwell Automation, Inc.
cannot assume responsibility or liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.

) describes some important differences between solid state

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

WARNING

IMPORTANT

ATTENTION

SHOCK HAZARD

Identifies information about practices or circumstances that can cause an
explosion in a hazardous environment, which may lead to personal injury or death,
property damage, or economic loss.

Identifies information that is critical for successful application and understanding
of the product.

Identifies information about practices or circumstances that can lead to personal
injury or death, property damage, or economic loss. Attentions help you to identify
a hazard, avoid a hazard, and recognize the consequences.

Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that dangerous voltage may be present.

BURN HAZARD

Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that surfaces may reach dangerous temperatures.

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 3

Environment and Enclosure

Follow these guidelines for environment and enclosure information for this
equipment.

ATTENTION

This equipment is intended for use in overvoltage Category II applications (as
defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according
to IEC/CISPR 11. Without appropriate precautions, there may be difficulties
with electromagnetic compatibility in residential and other environments due
to conducted and radiated disturbances.
This equipment is supplied as enclosed equipment. It should not require
additional system enclosure when used in locations consistent with the
enclosure type ratings stated in the Specifications section of this publication.
Subsequent sections of this publication may contain additional information
regarding specific enclosure type ratings, beyond what this product provides,
that are required to comply with certain product safety certifications.
In addition to this publication, see:

• Industrial Automation Wiring and Grounding Guidelines, Rockwell

Automation publication 1770-4.1
requirements.

• NEMA Standards 250 and IEC 60529, as applicable, for explanations of

the degrees of protection provided by different types of enclosure.

, for additional installation

Prevent Electrostatic Discharge

Follow these guidelines when you handle this equipment.

ATTENTION

This equipment is sensitive to electrostatic discharge that can cause internal
damage and affect normal operation. Follow these guidelines when you
handle this equipment.

• Touch a grounded object to discharge potential static.

• Wear an approved grounding wrist strap.

• Do not touch connectors or pins on component boards.

• Do not touch circuit components inside the equipment.

• Use a static-safe workstation if available.

• Store the equipment in appropriate static-safe packaging when not in

use.

Publication

1732E-IN004A-EN-E - November 2009

4 1732E ArmorBlock 2 Port Ethernet Module

About the ArmorBlock 2 Port Ethernet Module

The EtherNet/IP ArmorBlock is a 24V DC I/O module that communicates
via EtherNet/IP. The sealed IP65, IP67 and IP69K housing of these modules
requires no enclosure. Note that environmental requirements other than IP65,
IP67 and IP69K may require an additional appropriate enclosure. I/O
connectors are sealed M12 style.

EtherNet/IP networks use advanced network technology, for example,
producer/consumer communication, to increase network functionality and
throughput.

EtherNet/IP ArmorBlock 16-Point I/O Module

Status LEDs

EtherNet/IP D-Code
M12 connector

LINK 1 LINK 2

Functional Earth

EtherNet/IP D-Code
M12 connector

(1)

M12 I/O connectors M12 I/O connectors

Auxiliary power

Node address
switches

Protective Earth

(2)

44945

(1)

Functional Earth grounds the I/O block’s EtherNet/IP communication circuitry which is designed to

mitigate the effect of noise on the network. Refer to EtherNet/IP Connectors on page 9 for
connections.

(2)

Protective Earth is provided for the grounding of field devices and is internally connected to each Pin 5 of

the M12 I/O connectors. Refer to I/O Connectors on page 8 for connections.

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 5

Catalog Number Explanation

Refer to the table for a description of the modules’ catalog numbers.

Cat. No. Description Network

Connector

1732E-IB16M12R 16 Channel 24V DC Digital Input Dual-Port

Ethernet Module

1732E-OB16M12R 16 Channel 24V DC Digital Output Dual-Port

Ethernet Module

1732E-16CFGM12R 16 Channel 24V DC Configurable Digital I/O

Dual-Port Ethernet Module

1732E-IB16M12DR Diagnostic 16 Channel 24V DC Digital Input

Dual-Port Ethernet Module

1732E-OB16M12DR Diagnostic 16 Channel 24V DC Digital Output

Dual-Port Ethernet Module

1732E-8X8M12DR Diagnostic 8-Input/8-Output 24V DC Digital I/O

Dual-Port Ethernet Module

1732E-IB16M12SOEDR Diagnostic Sequence of Events 16 Channel 24V

DC Digital Input Dual-Port Ethernet Module

Dual D-Code
M12

Dual D-Code
M12

Dual D-Code
M12

Dual D-Code
M12

Auxiliary
Power

Single 4-pin
mini

Single 4-pin
mini

Single 4-pin
mini

Single 4-pin
mini

Install the Module

Refer to the following sections to install your module.

• Set the Network Address

• Mount the Module

• Connect the I/O, Network and Auxiliary cables to the ArmorBlock

Module

Publication

1732E-IN004A-EN-E - November 2009

6 1732E ArmorBlock 2 Port Ethernet Module

Set the Network Address

The I/O block ships with the rotary switches set to 999 and DHCP enabled.
To change the network address, you can do one of the following:

• adjust the switches on the front of the module.

• use a Dynamic Host Configuration Protocol (DHCP) server, such as

Rockwell Automation BootP/DHCP.

• retrieve the IP address from nonvolatile memory.

The I/O block reads the switches first to determine if the switches are set to a
valid number. Set the network address by adjusting the 3 switches on the front
of the module (refer to the illustration on page 6). Use a small blade
screwdriver to rotate the switches. Line up the small notch on the switch with
the number setting you wish to use. Valid settings range from 001...254.

Network Address Example

This example shows
the network address
set at 63.

44233

When the switches are set to a valid number, the I/O block’s IP address is

192.168.1.xxx (where xxx represents the number set on the switches). The
I/O block’s subnet mask is 255.255.255.0 and the gateway address is set to

0.0.0.0. When the I/O block uses the network address set on the switches, the
I/O block does not have a host name assigned to it or use any Domain Name
Server.

If the switches are set to an invalid number (for example, 000 or a value
greater than 254 excluding 888), the I/O block checks to see if DHCP is
enabled. If DHCP is enabled, the I/O block asks for an address from a
DHCP server. The DHCP server also assigns other Transport Control
Protocol (TCP) parameters.

If DHCP is not enabled, the I/O block uses the IP address (along with other
TCP configurable parameters) stored in nonvolatile memory.

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 7

Mount the Module

Two sets of mounting holes are used to mount the module directly to a panel
or machine. Mounting holes accommodate #8 (M4) pan head screws. The
torque specification is 1.13 Nm (10 in-lb).

Product Dimensions

Refer to the mounting dimensions illustration to help you mount the modules.

179 mm
(7.05 in.)

169 mm
(6.64 in.)

65 mm
(2.56 in.)

LINK 1 LINK 2

43.25 mm
(1.70 in.)

26.5 mm
(1.04 in.)

Front view

Publication

Side view

44946

1732E-IN004A-EN-E - November 2009

8 1732E ArmorBlock 2 Port Ethernet Module

Mount the Module in High Vibration Areas

If you mount the module in an area that is subject to shock or vibration, we
recommend you use a flat and a lock washer to mount the module. Mount the
flat and the lock washer as shown in the mounting illustration. Torque the
mounting screws to 1.13 Nm (10 in-lb).

High Vibration Area Mounting

Lock washer

Flat washer

44766

Connect the I/O, Network and Auxiliary Cables to the ArmorBlock Module

The ArmorBlock EtherNet/IP family has 5-pin micro-style connectors. We
provide caps to cover the unused connectors on your module. Connect the
quick-disconnect cord sets you selected for your module to the appropriate
ports.

I/O Connectors

Refer to the pinout diagrams for the I/O connectors.

Micro-style 5-Pin Input Female Connector

(View into connector)

1 2

5

4

3

44807

Pin 1 Sensor source voltage
Pin 2 Input B
Pin 3 Return
Pin 4 Input A
Pin 5 PE

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 9

Micro-style 5-Pin Output Female Connector

(View into connector)

1 2

Pin 1 Not used
Pin 2 Output B

5

4

3

44807

Pin 3 Return
Pin 4 Output A
Pin 5 PE

Self-configuring Connector

(View into connector)

1 2

5

4

3

44807

Pin 1 Sensor source voltage
Pin 2 Input or output B
Pin 3 Return
Pin 4 Input or output A
Pin 5 PE

EtherNet/IP Connectors

Refer to the pinout diagrams for the network connectors.

D-Code M12 Network Female Connector

(View into connector)
Pin 1 M12_Tx+
Pin 2 M12_Rx+
Pin 3 M12_Tx­Pin 4 M12_Rx­Pin 5 Connector shell shield FE

IMPORTANT

4

31

2

5

44808

Use the 1585D–M4DC–H: Polyamide small body unshielded or the
1585D–M4DC–SH: Zinc die-cast large body shielded mating connectors
for the D-Code M12 female network connector.

Publication

1732E-IN004A-EN-E - November 2009

10 1732E ArmorBlock 2 Port Ethernet Module

IMPORTANT

Use two twisted pair CAT5E UTP or STP cables.

D-Code

M12 Pin

1 White-Orange TX+ 1
2 White-Green RX+ 3
3 Orange TX- 2
4 Green RX- 6

Wire Color Signal 8-way Modular

RJ45 Pin

The 1732E-16CFGM12R self-configuring module contains both input and
output functionality.

• If an I/O point is to be an output, dedicate that point as an output

with a wired load and energize it through a control program.

• Energized outputs show an associated active input that can be used as

a feedback mechanism to make certain that the output is on.

• If an I/O point is to be an input, wire the input device as normal and

leave the associated output de-energized at all times.

ATTENTION

Make sure all connectors and caps are securely tightened to properly seal the
connections against leaks and maintain IP enclosure type requirements.

I/O Self-configure Circuitry

Turn output on

From PLC

Output scan list

Input scan list

To PLC

Input is on
(Or output is on)

Output
circuit

Input
circuit

Sensor or
actuator

Connector pin

43601

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 11

Refer to the illustration for configuration operations.

Configure Operations

EtherNet/IP D-Code
M12 connector

Module/network
status LED indicators

Eight M12 I/O
connectors

I/O status LED
indicators

Auxiliary power

LINK 1 LINK 2

EtherNet/IP D-Code
M12 connector

Network address switches

44945

Refer to On-Machine Connectivity Catalog, publication M116-CA001, for
Rockwell Automation cable and cord set offerings or use the configuration
tools available at

www.ab.com/e-tools/.

Publication

1732E-IN004A-EN-E - November 2009

12 1732E ArmorBlock 2 Port Ethernet Module

Auxiliary Power Cable

Attach the mini-style 4-pin connector to the mini-style 4-pin receptacle as
shown below.

Mini-style 4-Pin Input Male Receptacle

(View into receptacle)

4 2

3 1

44809

Auxiliary Power is based on a 4-pin connector system and is used to provide
24V DC power to I/O modules and other devices. Running separate power to
these devices is most typically used for I/O devices with output connections

Pin 1 Output power+
Pin 2 Sensor/MDL power+
Pin 3 Sensor/MDL power­Pin 4 Output power-

to prevent power supply interruption due to switching of outputs. However,
some devices require separate auxiliary power to power them regardless of the
presence of outputs.

Depending on the devices used, it may be possible to provide power through
only one pair of the four available pins, and in this case the other available pair
may be used for single channel E-stop through the use of special E-stop drop
or power T-ports and shorting plugs. Allen-Bradley E-stop T-ports and
shorting plugs are red in color for easy identification.

ATTENTION

To comply with the CE Low Voltage Directive (LVD), this equipment and all
connected I/O must be powered from a source compliant with the following:
Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 13

Interpret LED Indicators

This module has the following indicators:

• Network, Module, and Link status indicators for EtherNet/IP

• Auxiliary Power indicator

• Individual I/O status indicators for inputs and outputs

Link

status

indicator

Module

status

indicator

I/O status
indicators

LINK 1 LINK 2

Link
status
indicator

Network
status
indicator

I/O status
indicators

Auxiliary power
status indicator

Indicator Status for Modules

Status Description

Module status Off No power applied to device.

Flashing red/green Device is in self-test.

Green Device operating normally.

Flashing red Recoverable fault.

Red Unrecoverable fault – may require device

replacement.

Publication

44945

1732E-IN004A-EN-E - November 2009

14 1732E ArmorBlock 2 Port Ethernet Module

Indicator Status for Modules

Status Description

Network status Off The device is not initialized or the module does not

have an IP address.

Flashing green The device has no CIP connections.

The device has an IP address, but no CIP connections
are established.

Green The device is online, has an IP address, and CIP

connections are established.

Flashing red One or more connections have timed out.

Red The module has detected that its IP address is

already in use.

Flashing red/green The module is performing a powerup self-test.

Network link status Off No link established.

Green Link established on indicated port at 100 Mbps.

Flashing green Link activity present on indicated port at 100 Mbps.

Yellow Link established on indicated port at 10 Mbps.

Flashing yellow Link activity present on indicated port at 10 Mbps.

Auxiliary status Off No auxiliary power to device or input not valid.

Green Auxiliary power applied to device.

(1)

Digital output status

Digital input status

(1)

Off Output not energized.

Yellow Output energized.

Red Output shorted.

Flashing red Output open load.

Off No valid input.

Yellow Valid input.

Red Sensor source voltage shorted.

Flashing red Sensor source open wire.

(1)

Only diagnostic modules 1732E-*DR have red I/O status LEDs.

IMPORTANT

The Module Status LED indicator will flash red and green for a maximum
30 s while the module completes its POST (Power-On Self Test).

Publication

1732E-IN004A-EN-E - November 2009

1732E ArmorBlock 2 Port Ethernet Module 15

Specifications

ArmorBlock 2 Port Ethernet Module Input – 1732E-8X8M12DR, 1732E-IB16M12R,
1732E-IB16M12DR, 1732E-IB16M12SOEDR, 1732E-16CFGM12R

Attributes Value

Number of inputs 8 – 1732E-8X8M12DR

16 – all other modules

Input type Sink, 24V DC

Voltage, off-state input, max 5V DC

Voltage, on-state input, max 30V DC

Voltage, on-state input, nom 24V DC

Voltage, on-state input, min 11V DC

Current, off-state input, max 1.5 mA @ 5V DC

Current, on-state input, max 5 mA @ 30V DC

Voltage, sensor source, max 30V DC

Voltage, sensor source, min 10V DC
Input delay time

ON to OFF
OFF to ON

Isolation voltage 50V (continuous), Basic Insulation Type, Inputs and Sensor Power to

0…16000 μs

Network
No isolation between individual Inputs or between Network channels
Type tested at 707V DC for 60s

ArmorBlock 2 Port Ethernet Module Output – 1732E-8X8M12DR,
1732E-OB16M12R, 1732E-OB16M12DR, 1732E-16CFGM12R

Attributes Value

Number of outputs 8 – 1732E-8X8M12DR

16 – all other modules

Output type Source, 24V DC

Voltage drop, on-state output,
max

Voltage off-peak blocking, min 30V DC

Voltage, on-state output, max 30V DC

0.5V DC

Publication

1732E-IN004A-EN-E - November 2009

16 1732E ArmorBlock 2 Port Ethernet Module

ArmorBlock 2 Port Ethernet Module Output – 1732E-8X8M12DR,
1732E-OB16M12R, 1732E-OB16M12DR, 1732E-16CFGM12R

Attributes Value

Voltage, on-state output, min 11V DC

Voltage, on-state output, nom 24V DC
Current on-state output, max 2 A – 1732E-OB16M12R

0.5 A – all other modules

Current per module, max 4.0 A – 1732E-8X8M12DR

8.0 A – all other modules

Leakage current, off-state
output, max

Surge current per output, max 4.8 A for 10 ms, repeatable every 2 s – 1732E-OB16M12R

Isolation voltage 50V (continuous), Basic Insulation Type, Outputs and Output Power to

Pilot duty rating DC-14

50 μA

1.2 A for 10 ms, repeatable every 2 s – all other modules

Network
No isolation between individual Outputs or between Outputs and
Output power or between Network channels
Type tested at 707V DC for 60s

General Specifications

Attributes Value

Voltage, auxiliary power, max 30V DC

Voltage, auxiliary power, min 12V DC
Current, Ethernet system power, max

(pins 2, 3 sensor source/module power)

0.4 A – 1732E-OB16M12R, 1732E-OB16M12DR

0.8 A – 1732E-8X8M12DR

1.2 A – 1732E-IB16M12R, 1732E-IB16M12DR,
1732E-IB16M12SOEDR, 1732E-16CFGM12R

Current, auxiliary power, max per output module
(pins 2, 3 sensor source/module power plus
pins 1, 4 for output loads)

Current, sensor source, per input, max 50 mA

Current, sensor source, per connector, max 100 mA
Communication rate EtherNet/IP

Publication

1732E-IN004A-EN-E - November 2009

4 A – 1732E-8X8M12DR
8 A – all other modules

10/100 Mbps
Full or half-duplex
100 meter per segment

1732E ArmorBlock 2 Port Ethernet Module 17

General Specifications

Attributes Value

LED indicators Module Status - red/green

Network Status - red/green
Link Status - green/yellow
Auxiliary Power - green
I/O LED - yellow
I/O LED - yellow/red – 1732E-*DR modules only

Dimensions (HxWxD), approx. 179 x 65 x 43.25 mm (7.05 x 2.56 x 1.70 in.)

Weight, approx. 0.34 kg (0.75 lb)

Enclosure type rating Meets IP65/66/67/69K (when marked)

Wiring category

(1)

Use this Conductor Category information for planning conductor routing. Refer to publication 1770-4.1,
Industrial Automation Wiring and Grounding Guidelines.

(1)

1 - on signal ports
1 - on power ports
1 - on communications ports

Environmental Specifications

Attribute Value

Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),

IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):

-20…60 °C (-4…140 °F)

Temperature, storage IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),

IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating Thermal Shock):

-40…85 °C (-40…185 °F)

Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):

5…95% non-condensing

Vibration IEC60068-2-6 (Test Fc, Operating):

Shock, operating IEC60068-2-27 (Test Ea, Unpackaged Shock):

Shock, non-operating IEC60068-2-27 (Test Ea, Unpackaged Shock):

Emissions CISPR 11:

5 g @ 10…500 Hz

30 g

50 g

Group 1, Class A

Publication

1732E-IN004A-EN-E - November 2009

18 1732E ArmorBlock 2 Port Ethernet Module

Environmental Specifications

Attribute Value

ESD immunity IEC 61000-4-2:

6 kV contact discharges
8 kV air discharges

Radiated RF immunity IEC 61000-4-3:

10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 Mhz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 Mhz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz

EFT/B immunity IEC 61000-4-4:

±4 kV @ 5 kHz on power ports
±3 kV @ 5 kHz on signal ports
±3 kV @ 5 kHz on communications ports

Surge transient immunity IEC 61000-4-5:

±1 kV line-line(DM) and ±2 kV line-earth(CM) on power ports
±1 kV line-line(DM) and ±2 kV line-earth(CM) on signal ports
±2 kV line-earth(CM) on communications ports

Conducted RF immunity IEC 61000-4-6:

10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz

Certifications

Certification (when
product is marked)

c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See

CE European Union 2004/108/EC EMC Directive, compliant with:

C-Tick Australian Radiocommunications Act, compliant with:

EtherNet/IP ODVA conformance tested to Ethernet/IP specifications.

(1)

See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates,
and other certification details.

Value

(1)

UL File E322657.

EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)

AS/NZS CISPR 11; Industrial Emissions

Publication

1732E-IN004A-EN-E - November 2009

Notes:

1732E ArmorBlock 2 Port Ethernet Module 19

Publication

1732E-IN004A-EN-E - November 2009

Rockwell Automation Support

Rockwell Automation provides technical information on the Web to assist you in using
its products. At http://support.rockwellautomation.com

, you can find technical
manuals, a knowledge base of FAQs, technical and application notes, sample code and
links to software service packs, and a MySupport feature that you can customize to
make the best use of these tools.

For an additional level of technical phone support for installation, configuration, and
troubleshooting, we offer TechConnect support programs. For more information,
contact your local distributor or Rockwell Automation representative, or visit

http://support.rockwellautomation.com

.

Installation Assistance

If you experience a problem within the first 24 hours of installation, please review the
information that's contained in this manual. You can also contact a special Customer
Support number for initial help in getting your product up and running.

United States 1.440.646.3434

Monday – Friday, 8 a.m. – 5 p.m. EST

Outside United States Please contact your local Rockwell Automation representative for any

technical support issues.

New Product Satisfaction Return

Rockwell Automation tests all of its products to ensure that they are fully operational
when shipped from the manufacturing facility. However, if your product is not
functioning and needs to be returned, follow these procedures.

United States Contact your distributor. You must provide a Customer Support case number

(see phone number above to obtain one) to your distributor in order to
complete the return process.

Outside United States Please contact your local Rockwell Automation representative for the return

procedure.

Allen-Bradley, Rockwell Automation, ArmorBlock and TechConnect are trademarks of Rockwell Automation, Inc.

Trademarks not belonging to Rockwell Automation are property of their respective companies.

Publication 1732E-IN004A-EN-E - November 2009

Copyright © 2009 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
