USER’S MANUAL
Products Features
Button Introduce
z Button Introduce
1. Power button:long press for 3 seconds is for turn on/off，short press for wake up screen;
2.Earphoneφ:3.5mm earphone port
3.USB card/OTG port for U disk/mouse/keyboard
4.DC in:2.5MM DC12V 2A charging port
5.HDMI:HDMI out put
6.TF card:TF expand card port
7.Camera；
8.Reset:short press for reset ；
一．Use preparation
z Connecting to your PC
Startup your PC, and connect the product to your PC with the provided USB Cable for USB charge or file
transfer. The product will show connected and you can copy/delete files within the player through PC.
Notice: Do not play music or video while connected with PC. Please be aware that we claim
no responsibility for damage caused by this improper operation.
z Turn on
Under power on mode, long press "Power button" for 3 seconds，the system will enter android
power-on status bar,and about 100s later enter the system menu,the screen is locked,hold
to drag up to the green point position,the device will unlock automatically,just as the following picture
lock tap
shows:
Connect the device with PC,the system will turn on the device automatically(it only supply
power and don't charge).
Power saving & screen-lock：turn on the device and short press“POWER” button to enter SLEEP power
saving mode,at this time,the screen become black screen, and also enter screen lock mode.Press “POWER”
button again ,the system resume bright screen within 1s.
Note:
1.Under power saving mode, the original operations such as music,video etc will not pause and will
continuously work ,it only clock the screen to be at the status of black screen.
2.When the system hangs up,press "power switch" button for 10s so that the device resume
to turn off, and press "power switch" again,it will turn on.
z Power off
Under the power-on status ,long press "power button" for 3s, power-off menu will show,select "OK" to turn off the
player.
【Notice】When power is not enough,the device will continuously give an alarm ,it will automatically power off if
no charging;if don't turn it on,please check the power status,try to turn it on within 5 minutes to 10 minutes
after it is charging if power is out of use.
z Using TF expansion card
1、Connect the player with your PC, it will appear 2 Removable Disk, the first one is build-in flash
memory, the other one is TF card. The second Removable Disk will not be opened if you did not plug a TF
expansion card to the player.
Notice:the player only supports TF kind of expansion card (maximum memory:32GB).
2、Plug expansion card
To Plug: Insert the expansion card as the indication near the card slot. Once the player identifies the
expansion card, Files stored in the card memory can be played.
To Unplug: Press the expansion card slightly and remove it.
z Charging the battery
1、For best results, let it charge for about 5 to 6 hours during the first use, to confirm the full power
and then use it.
2、Insert MINI 5IN USB port of the adaptor into the device USB port，the other end of the adaptor is inserted
into DC port,then the device turn on automatically,the battery capacity will read as the green scrolling icon
shows when charging, the charger should not be plugged out until power is fully charged. The indicator light
becomes blue,the battery icon's green bar
When the power exhausts out,wait for a minute and turn the device on.
Notice:
1.if you want the special charger with 5V--2A,contact the distributor in the local.
2.Don't use 9V charger, or we are not responsible if the device is damaged to lead by the usage of 9V
charger.
will stop.
z Main user interface （menu icons definition）
icon Function introduction icon Function introduction
Any interface and click it
will return to main menu
The system has identify
new device
Battery icon showing the
remaining power
Operation introduction
二．
Menu of Recent operation
To show the time of current
Return button
system
Function module menu
1.Wifi Setting
a. WIFI on setting：click module menu icon ，enter module menu list,click "setting" to enter
the setting menu,click "wireless & networks" to enter,select "Wi-Fi" ：
b. WIFI setting and network connecting: Click "Wi-Fi setting”to enter and the system
will automatically find WIFI network name.
2.USB-HOST function
a. Reading U Disk function :
Insert U disk into HOST/OTG port,click "explorer" ,click "USB" ,enter the file
list of U disk as follows:
b.External 3G USB Dongle：
Insert 3G
HOST port ,and wait minutes after appear the 3G icon and could to connect the Internet.
USB-DONGLE card through OTG cable, end into Dongle ,and end into USB/OTG
3.APK Installer
U19GT support the applications from android platform,most apps can be downloaded from the
Internet,then copy Into Interal Memory or T-Flash to install.
• Click APK Installer“
”，Pop-up APK installer menu：Installer、Manager、Exit.
•
Installer ：click installer,enter Apk installer menu.
Internal Memory and SD Card is separately flash memory and T-Flash card memory;
Enter and choose the app you want in the right column and click "install".
• Manage ：click "mange",enter the menu.
- Launch：launch the software
- Export：export the software to T-Flash card
- Uninstall：uninstall the software
- Cancel：cancel the operation
4．Explorer
In main menu ,click the explore icon to enter the manager interface,click "SD Card"、"Internal
Memory" and "U Disk",enter the sub file list,you can add,copy,paste,delete .long press the file
or file folder,choose "last","next",or "last level" to find the related position and click "edit"
and choose "paste" to the related position in the coming box.
5.Record
In main menu,click the record icon to enter，click record button to start recording.click
the stop button
notice whether this record will be used or given up,you can choose it manually.
Play the record：select audio play button to play the record,first choose the record file in the
explore,then click "play"
to stop recording.click to play the record.The system automatically
6.IE explore
When wifi is connecting,click IE explore in the main menu and enter to IE menu,click the
website address column and input the website address to view ：
7.Update fireware
Upgrade before the machine and computer connection, on the computer open upgrade tool "RKBatchTool.
Exe" execution file, pop-up window, click " " open img firmware. Then click on the "switch", select the
"repair" into the firmware upgrade state, and upgrade tool current information prompt "repair finish" said firmware
upgrade was successful, after the success of the upgrade to the machine back into the system, and after connect
with computer, the computer can exit.
【Notice】:
upgrade system will removed all local data, before the upgrade ,please backup important information .
After the upgrade for the first time when boot disk partition, the software pre-installed on such action, will
be slow, please kindly wait a moment, the second time into the system speed is normal.
三．Technology specification
Hardware configuration
Main Frequency 1.0GHz
CPU Cortex-A9 Single Core
Inner memory
512M DDR3
7 inch 1024*600 screen
Screen
Multi-touch Capacitive screen （5PIN touch)
Memory 8GB
WiFi WiFi 802.11b/g/n
Volume
Built-in Speaker
Expansion card Micro SD card，support maximum 32GB Micro SD（TF）
Battery 3.7V \2500mA/h
Data port High speed USB 2.0 ，support OTG function
Operation system
Operation
system Google Android 4.1
Camera
Front 0.3 Mega Pixels
Function feature
Mobile memory It can be used as movable hardware Disk
Audio MP3、WMA、OGG、APE、FLAC、AAC、WAV
Support H.264,VP8,RV,WMV,AVS,MPEG4 etc 1080P video output、
Video
YouTubeYouTube、720P、HTML5 、Flash10.1
Picture Support JPG、BMP、PNG etc.
2D/3D graphic process unit ，support OpenGL ES 2.0/1.1 and Open
VG1.1
Others
View internet,Chat online ,E-mail,E-Book,Explore
Clock,Alarm clock,Calculator,Record
Audio mode Normal,Popular,Rock,Classical,Bass,Jazz,User-defined
Language Multi-language(optional)
Repeated mode Single song once、single repeated、all once、demo
Record Support microphone,support3GPP record format
Technology specification
Battery usage
time Audio playing time：about 10 hours；video play time:about 4 hours
Website view time:about 3 hours
SNR ≥95db
【Note】：
The picture on the manual is only for reference.There is no notice if the
specification,button operation and appearance are exchanged. Hope you can understand.
Declaration
Pls backup the own data when you operate it.The company is not responsible for the loss and
damage of data caused by wrongly operating hardware,software,product repair,battery
replacement or other unforeseen circumstances. Meanwhile,we can not control the user’s
misunderstand of using the manual, so the company is not responsible for the accidental damage,and
not responsible for the third part claims caused by using the products.
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receive r .
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
