Alfa FXALLE-LGIA-T, FXALLE-LROA-T, FXALLE-LGIA, FXALLE-LROA Specification Sheet

ALLEGRO

CARATTERISTICHE TECNICHE - TECHNICAL DETAILS

LEGNA - WOOD

conforme a UNI 10474 e EN 13229

UNI 10474 and EN 13229 compliant

YELLOW

FXALLE-LGIA-T

ANTIQUE RED

FXALLE-LROA-T

Peso

Weight

Area piano forno

Oven oor area

Dim. piano forno

Oven oor dim.

Minuti per scaldare

Heating time (min)

N° pizze alla volta

Pizza capacity

Infornata di pane

Bread capacity

Temperatura massima

Max oven temperature

Consumo medio

Average fuel consumption

170 kg

375 lbs

0.7 m2

7.43 ft2

100 x 70 cm

39.3 x 27.5 in

20

5

5 kg

11 lbs

500°C

1000°F

5 kg/h

11 lbs/h

Materiali utilizzati

Used material

Tipo di refrattario

Type of refractory

Combustibile consigliato

Recommended fuel

Carica nominale

Rated charge

Tiraggio minimo

Minimum ue draught

Flusso volumetrico fumi

Flue smokes mass ow

Emissioni CO al 13% O

CO emission at 13% O

Temperatura fumi

Smoke temperature

www.alfaforni.com

lamiera ferro. acciaio inox. bra ceramica

iron sheet. stainless steel. ceramic ber

Tavella silico-alluminoso

Alumina silicate bricks

Ciocchi diam. Max 5 cm. potature

Max 1.9 In diam. logs. trimmings

8.3 kg/h

18.3 Lbs/h

11 Pa

49.6 g/s

2

2

0.35% 4444 mg/Nm

387°C

728°F

3

MISURE - DIMENSIONS

F

L L

G

D

O

P

H

S S

Q

R

A

118.3 cm

A

46.6 in

84.8 cm

B

E

C

N

M

⌀

V

Q

T

B

Z

U

W

33 in

149 cm

C

58.7 in

64.7 cm

D

25.5 in

18 cm

E

7.1 in

84.3 cm

F

33.2 in

58 cm

G

22.6 in

19.5 cm

H

7.6 in

50.15 cm

L

19.7 in

23.55 cm

M

9.3 in

60.45 cm

N

23.8 in

DIMENSIONE IMBALLO

PACKAGING

Larghezza

Width

Profondiftà

125 cm

48.7 in

Depth

109 cm

42.5 in

O

P

Q

R

S

T

U

V

W

Z

69.45 cm

23.8 in

32.55 cm

12.8 in

59.15 cm

23.3 in

96 cm

37.8 in

11.5 cm

4.4 in

75 cm

29.5 in

2.9 cm

1.1 in

6.9 cm

2.7 in

17.2 cm

6.7 in

102 cm

40.2 in

Altezza

Height

79 cm

30.8 in

Descrizione

Description

Comignolo

Chimney cap

Canna fumaria

Chimney

Sportello

Door

Flangia

Flange

Carter esterno Giallo

External shell Yellow

Carter esterno Rosso

External shell Red

Termometro

Thermometer

Mattoni 30x20 cm

Red bricks

Mattoni 40x20 cm

Red bricks

30x20 cm

40x20 cm

Gasbeton

Piedini

Feet (n.4)

Logo Alfa (v1.0)

PARTI DI RICAMBIO - SPARE PARTS

Codice

Code

S6PZ_01_025

A

TI180_750_SAT

B

S6PZ_01_021

G

H

I

SCRT-01-029-RO

I

J

K

K

L

SETPIE-M10X20

M

D14PLAC-ALFA

N

SML_03_0182

SCRT-01-029-GI

YT63-135

RRA3020

RRA4020

FCGSB602515

G

J

N

A

B

H

I

www.alfaforni.com

K

M

L
