Page 1
mension
ASSEMBLY INSTRUCTIONS
Cube Size : 39”x18.6”x11.6” NW: 30.8 LBS
DINING CHAIR WITH PLAIN WOOD SEAT
Description
Di
: DINING CHAIR WITH PLAIN WOOD SEAT
: W. 17" 3 x D.19.9" x H. 37"
GW: 39.6 LBS
- 1 -
Page 2
BEFORE ASSEMBLY
NOT INCLUDED
Hardware bag
location
Thank you for purchasing this quality product. This product has been designed for easy assembly and long lasting use. Please
take the time to read and follow the assembly instructions carefully.
Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment.
Please separate, identify, and count all parts and metal hardware. Compare with part list to be sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call for us.
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being
scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQUIRED
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you
have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A
C-R
Chair back 1
B
Seat Frame
1
D
U Stretcher 1
1
C-L
DINING CHAIR WITH PLAIN WOOD SEAT
Front Leg
1
- 2 -
Page 3
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you
have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
Bolt
1
3
5
(M6x60mm)
Lock Washer
(Ф6.5x9)
Allen Key
(4mm)
4
10
1
2
4
6
Bolt
(M6x50mm)
Flat Washer
(Ф6.5x19)
Screw
(M4x40mm)
6
10
2
STEP 1
Attach front legs (C-L) and (C-R) to the seat frame by bolts (1), washers (3) and (4) and slightly tighten
with Allen Key (5).
Then attach the U stretchers (D) to two front legs by the screw (6) using Philip driver as shown below:
C-R
C-L
D
B
DINING CHAIR WITH PLAIN WOOD SEAT
- 3 -
Page 4
STEP 2
Attach the seat frame and U stretchers (D) from step 1 to the chair back (A) by using bolts (2) and
washers (3) and (4) then slightly tighten it with Allen Key (5) as shown below:
Note: DO NOT fully tighten any of the bolts, until the chair is assembled.
5
2
3
4
X2
STEP 3
Put the chair on a flat level surface to make sure the chair is level and then tighten the all bolts.
DINING CHAIR WITH PLAIN WOOD SEAT
- 4 -
