ALR-10223-SHMAA
MADE IN MALAYSIA
1
C
8 x 1.1/4" Pan Head Screw
6
STEP 1
STEP 2
STEP 3
STEP 4
M6x 40mm JCBC Bolt
M6x70mm JCBC Bolt
M6x13mm Lock Washer
M6.5x16.5mm Flat Washer
M4 x 2.1/2" Allen Key
Assembly Glue
8 x 1" Wood Screw
6
2
6
8
8
1
1
NO Parts List
Q'TY
Chair Back
Box Seat
Hardseat
Left Front Leg
Right Front Leg
1
1
1
1
1
Left Side Stretcher
Right Side Stretcher
Front Stretcher
1
1
1
A
B
C
D
E
F
G
H
NO Hardware List
Q'TY
1
2
3
4
5
6
7
8
B
A
E
D
G
H
F
2
8
5
5
5
7
7
7
6
6
6
4
4
3
Do not fully tighten the bolt
Do not fully tighten the bolt
Levelling solution: Loosen each bolt in the seat box (front legs, back
corner blocks and back apron) to the point where it can be turned
Chair/Stool back and seat frame are well connected. Sit in the
Chair/Stool,but do not lean against the Chair/Stool back. Gently sway
back and forth, left and right. Carefully turn the Chair/Stool upside
down, and tighten each bolt. The Chair/Stool will now be levelled.
Important Note
Do not use power tool for assembly.
All bolt must fasten either by wrench or Allen Key.
LADDERBACK BARSTOOL WITH HARDSEAT
