Label Picture Description QTY
A
Left Armrest
(with Legs)
1
B
Right Armrest
(with Legs)
1
C
Backrest
(with Legs)
1
Caution : You must read this before you proceed
Club Chair
Page 1 OF 7
D Seat Panel 1
E
Front Panel
(with Legs)
1
F Left Front Foot Clip 1
G Right Front Foot Clip 1
H Left Back Foot Clip 1
I Right Back Foot Clip 1
M Seat Cushion 1
Q Rubber Hammer 1
Before
Beginning
Assembly:
Page 2 OF 7
Overview
This Club Chair has multiple parts and may require up to 30 minutes to assemble. To give you
an overview of the Club Chair parts, the above picture is to help you put the various parts into
perspective. Please read through the instructions below to familiarise yourself with the parts and
steps before assembly.
Step 1
Open the carton and place all parts on a clean, non-marring surface.
Place the Seat Panel(D) facedown on the clean, non-marring surface.
Insert Front Panel(E) into Seat Panel(D) using the interlocking joints and secure with Rubber
Hammer(Q).
Left Armrest (A)
Seat Cushion (M)
Backrest (C)
Front Panel (E)
Front Facing
Right Armrest (B)
Seat Panel (D)
Right Front Foot Clip (G)
Left Front Foot Clip (F)
Left Back Foot Clip (H)
Front of Seat
Board(D)
Back of Seat
Board(D)
Page 3 OF 7
Turn the assembly onto it's side as shown.
Insert the Clasps on the Left Armrest(A) into the Pear-shaped Clasp mounting positions on the
Front Panel(E), Seat Panel(D), and Backrest(C).
Insert the 8 Clasps of Front Panel(E), Seat Panel(D), and Backrest(C) into Pear-Shaped Clasp
mounting positions of Left Armrest(A).
Step 2
Place the Backrest(C) upright and align Seat Panel(D) as shown above.
There are four Pear-shaped Clasp mounting positions on the Backrest(C), and four Clasps on
the Seat Panel(D).
Insert the four Clasps into four mounting positions and push down to button up the Clasps with
the Rubber Hammer(Q).
Step 3
Pear-shaped Clasp
Mounting Position
Clasp
Clasp
Pear-shaped Clasp
Mounting Position
Page 4 OF 7
Step 4
Button up the Clasps with the Rubber Hammer(Q) from left to right as shown above.
Step 5
With the help of an adult partner, turn the assembly over as shown above.
Repeat the same process from Steps 3 - 4 with the Right Armrest(B).
Page 5 OF 7
Attach the Left Front Foot Clip(F), Right Front Foot Clip(G), Left Back Foot Clip(H), Right Back
Foot Clip(I) to the feet of the Club Chair using the Rubber Hammer(Q) as shown above.
Step 7
With the help of your adult partner, stand the Club Chair up on a Lever surface, to check for
wobbles.
If there are wobbles, use the Rubber Hammer(Q) to ensure all parts are properly secured.
Step 8
Place the Cushion(M) on the seat.
Your Club Chair is ready for use.
This Club Chair can only be used on a flat, level surface.
Step 6
Page 6 OF 7
Page 7 OF 7
