components
Chaise Assembly
B
item description qty
A Seat 1
B Back 1
C Back Legs 2
D Front Legs 2
Please note: actual product may
look dierent than illustration.
A
C
D
hardware
Please note: you will need a wrench to
(H1) x 11
1 1/4" flat washer
We guarantee our upholstered furniture against defects in construction for a period of one (1) year. When a structural defect is brought to our
attention, we will repair or replace it at our option at no charge to the customer (inculdes parts and labor, not transportation costs). Fabric
wearability for upholstered furniture is not covered by the warranty. Vacuum for regular cleaning.
PLEASE DISPOSE OF PLASTIC BAG(S) AND CARTON(S) RESPONSIBLY.
(H2) x 7
5/16" nut
complete this assembly.
limited warranty
1
step 1
Chaise Assembly
1.1
Place (B) back face down on a flat surface and
peel back velcro flap.
Insert (C) back legs onto bolts and attach using
(H1) washers and (H2) nuts. Make sure notch
of (C) back legs are flush with the bottom of (B)
back. Tighten with wrench.
Replace velcro flap.
step 2
2.1
Turn (B) back over. Fit (A) seat onto bolts of
(B) back, aligning sides and bottoms of both
pieces.
2.2
Attach (A) seat to (B) back using (H1) washers
and (H2) nuts.
Tighten with wrench.
2
step 3
Chaise Assembly
3.1
Remove plastic caps from (D) front legs, and attach to (A) seat using one
(H1) washer per leg.
Once legs are secure, turn the chaise upright to check if level.
If the item is not level, unscrew the shortest leg and add an additional (H1)
washer.
Repeat as needed.
Please note: you may have extra (H1) washers depending on how many you use
to level the chaise.
