User Manual
Cute
Page 2
CCoonntteenntt
1. Precautions
2. Product Introduction
1） Features
2） Specification
3） Button Illustration
4） Terminal Illustration
5） Remote Control Illustration
3. Connecting Illustration
1） How to assemble and disassemble the stand
2） Battery Installation
3） Connecting Illustration
4. Operating Instruction
1） Turn on the Digital Photo Frame
2） Photo Operating Instruction
3） Music Operating Instruction
4） Calendar Operating Instruction
5） File Manager Operating Instruction
6） Medium Browser
7） Setup
5. Troubleshooting
Precautions
Warnings
Please read this manual carefully before operating and reserve it for future reference.
It will be helpful to you if you encounter any operating problem.
¾ Do not use this device near water or moisture, such as bathtub, washbowl, kitchen sink, laundry tub, in a wet basement,
near a swimming pool, or anywhere else that water or moisture are present.
¾ Clean only with a dry soft cloth; do not use any chemical liquid for cleaning.
¾ To ensure reliable operation of the device and to protect it from overheating, do not block any ventilation openings.
¾ Only use attachments/ accessories specified by the manufacturer.
¾ Do not step on the power cable, plug or adapter to avoid electronic shock.
Page 3
¾ Do not attempt to service this device yourself. Opening or removing covers may expose you to dangerous voltages or
other hazards.
¾ Please take off the power plug from power source in the thunderstorm weather or not in use for a long time.
¾ Do not place the device near any heating appliance like Radiator, Calorifier or Furnace heater.
二 Product Introduction
1. Features
¾ 7” LED display with high definition of 480 x 234.
¾ View digital photo/pictures slideshow in formats of JPG/JPEG.
¾ With high-definition picture decoding technology to show you the professional picture display.
¾ Picture slideshow with many kinds of transition effects, background music supported. (Only available
for the customized products.)
¾ Clock & calendar functions with various theme colors.
¾ With auto-slideshow function when power on to support the commercial demonstration.
¾ 2-in-1 Card reader (SD/MMC) and support USB flash drive.
2. Specifications
Items Parameters/Units
Input voltage (power adapter) AC100V-240V - 50/60Hz
Power input DC5V 1.0A
LCD
Specifications
Panel size / Aspect ratio 7inch 16:9
Effective viewing area
154.08（w）×86.58（H）mm
Resolution 480 x 234 pixel
Brightness 300cd/m²
Contrast 250:1
Available file format
JPG/MP3
(Only available for the customized
products.)
Memory card Supported: SD/MMC/ USB flash drive
Built-in speaker
0.5W 16 Ω
(Only available for the customized
products.)
Audio-out
2Vp-p
(Only available for the customized products.)
Operating temperature -5~45
Device Dimension 203x141x30mm
Weight 300g
3. Button Illustration
1） Power: Power on/off.
Page 4
2） Play: a. Play/Pause – Press briefly for switching play or pause in the multi-media function.
b. OK – Press briefly for entering or confirming the selected option.
3） UP: a. Upward select; b. Previous
4） DOWN: a. Downward select; b. Next
5） LEFT: a. Leftward select; b. back; c. volume decrease.
6） RIGHT: a. Rightward select; b. enter; c. volume increase.
7） Menu: To get back to the up-level menu in the submenu.
8） Indicated Light: The light is in Red when plug in, while light off when unplug and device on.
4. Terminal Illustration
1） Indicator LED: The LED will be in red when plug in and in the standby mode. The LED will be dark
when unplug or power on.
2） DC-IN: DC 5V/1.0A input.
3） USB HOST: For USB flash drive.
4） Card reader: Available for SD/MMC memory cards.
5. Remote Control Illustration
Note: The Remote control is an optional accessory, only available for the customized products.
1） Power: Power on/off.
2） Play: a. Play/Pause – Press briefly for switching play or pause in the multi-media function.
b. OK – Press briefly for entering or confirming the selected option.
3） UP: a. Upward select; b. Previous
4） DOWN: a. Downward select; b. Next
5） LEFT: a. Leftward select; b. back; c. volume decrease.
6） RIGHT: a. Rightward select; b. enter; c. volume increase.
7） Menu: To get back to the up-level menu in the submenu.
8） Slideshow: Switch picture display between “Stretch” & “Normal”.
9） Rotate – It enables you rotate photos.
三 Connecting Illustration
1. How to assemble and disassemble the stand
固定: Fix up; 拆卸: Disassemble
开锁状态(左图): Unlock (Left) ; 锁上状态(右图): Lock (Right)
Refer to the pictures above, assemble the stand’s [ ] into the corresponding hole on the backside of the photo frame and rotate
Page 5
the stand counterclockwise to fix it up. To disassemble the stand, clockwise rotate the stand and take it off.
2. Battery Installation
(左图) Picture 1 Picture 2 Picture 3
1） Please refer to the Picture 1, take out the battery, battery case & protective film follow the
arrow.
2） Remove the protective film. (Picture 2)
3） Insert the battery & battery case to the remote control.
3. Connecting Illustration
¾ 电源适配器接口:DC-IN
¾ 电脑: PC
¾ 文件导入: FILE INPUT
¾ U 盘/硬盘: USB FLASH DRIVE
¾ SD/MMC
四 Operating Instruction
1. Turn on the Digital Photo Frame
1） Power on/off
¾ Power on
When the adapter is plugged, the indicator LED will be on, and then press the [], the device will be power on, and the indicator
LED is off.
¾ Power off
Press [] on the rear panel or remote, the device will be turned off and the indicator LED will be on.
2） OSD Operation
¾ The following picture is the default OSD interface, moving the [][][][] to select function and Enter by [].
¾ Note: Music function is only available for the customized products.
2. Photo Operating Instruction
¾ Please copy your favorite pictures to the memory cards or USB flash drive, and insert in the corresponding slot, the
device will auto-recognize and display the pictures in random.
¾ Press [][] for previous or next picture; press [] to pop out the Setup mean when picture displaying. To adjust the Setup
menu, please refer to the picture below: select the function of by [][] and enter by []. Besides, to adjust the screen
brightness by [][], and exit by [].
3. Music Operating Instruction
Page 6
Note: Music function is only available for the customized products.
¾ Navigate [] [] [] [] on rear panel or remote to select the Music icon in the Main Menu, enter the Music Player by []. If
there is no any memory medium, the function cannot be accessed.
¾ The Music Player will show all the music files in the memory medium by tree-structure and auto-playback. Moving the
[][] to select the music and exit by [].
¾ Note: You could adjust the music playback settings in Setup function, for more details, please refer to the chapter of
Setup.
4. Calendar Operating Instruction
1） Clock & Calendar
¾ Navigate [][][][] on rear panel or remote to select the Calendar icon in the Main Menu, enter by this function by []. The
Calendar interface shows the Date & Time, adjust to preview Month by [][], or Year by [][].
2） Alarm & Date setting
¾ To adjust the Alarm & Date setting by pressing [] in the Calendar interface, moving the [][] to select the option and
adjust the value by [][].
¾
5. File Manager Operating Instruction
¾ Navigate [] [] [] [] on rear panel or remote to select the Browser icon in the Main Menu, enter this function by []. The
Brower shows all the files in the memory mediums. Return to the up-level directory by [], and go to sub-directory by [],
select and open the file by []. At the meanwhile, the preview window at the top left corner will show the picture selected.
6. Medium Browser
¾ Navigate [] [] [] [] on rear panel or remote to select the Medium icon in the Main Menu, enter this function by []. (The
function only could be accessed when the memory medium is available.) The
¾ The usage of the Medium Browser is when both of the SD/MMC card and USB flash drive are inserted to the device, the
system will recognize the SD/MMC card as the default memory medium and display the picture automatically, if you
want to display the picture in the USB flash drive, you should select the USB flash drive as the default memory medium.
And select the memory medium by moving [][], enter by [] and exit by.
7. Setup
¾ Transition: There are many kinds of Transition Effects for option, choosing the option by [][].
¾ Slideshow: There are many kinds of option for your selection, such as 3s, 5s, 7s, 20s and etc. Moving [][] to select the
option.
¾ Music Loop Mode: There are three options of Repeat folder, Repeat song and No repeat for setting.
¾ Language: Only available for English & Chinese, moving [][] to select the option.
¾ Startup Mode: There are many kinds of Startup Mode for optional, such as Slideshow + Music, Function Select,
Calendar, MP3 and Card SEL, moving [][] to select the option.
Page 7
¾ Display Mode: There are Stretch & Normal for optional.
五 Troubleshooting
1. To solve the problem, please follow the instructions.
¾ If malfunction appears, please follow the below instructions.
¾ Try again: If it cannot read media cards or USB flash drive, please reinsert.
¾ Reset: Please re-plug the power adapter, and start the device.
2. Problem & Solution:
Problem Solutions
No display on screen and can not start up Check whether the power is connected well, and whether the device is powered
on. Check whether the battery is low (battery version).
No sound Whether the parameter of volume is set to 0
The picture is dark. Check the setting of brightness is in normal value.
Can not read USB flash drive / Medium cards Check whether USB flash drive/media card is inserted well.
The remote control is invalid
The distance between remote control and the device is too long or the angle is
more than 60ْ. Check whether the remote control is poor contact or the battery is
low.
Picture can not full-screen display The screen ratio of this device is 16:9, if you want full-screen display, pleas
adjust the picture ratio to 16:9 as well.
¾ Note: The LED panel is made up by 561000 pixels with high technology. By chance, there will be some pixel is too high
or too dark, but this situation will not effect the actual Digital Photo Frame function.
Page 8
