Alcatel V607A User Guide

607_UM_USA_30-12-08 30/12/08 12:28 Page 1
Table of contents ........................
Introduction ........................................................................1
Safety and use ......................................................................5
General information..........................................................10
1. Your cellphone ............................................................12
1.1 Keys ......................................................................................................13
2. Getting started ............................................................17
2.1 Set-up....................................................................................................17
2.2 Power on your phone ......................................................................19
2.3 Power off your phone ......................................................................20
3. Calls ..............................................................................21
3.1 Making a call........................................................................................21
3.3 Receiving a call ..................................................................................22
3.4 During the call....................................................................................23
3.6 Line switching (ALS)..........................................................................25
4. Menu..............................................................................26
5. Call register..................................................................28
5.1 Call memory ......................................................................................28
5.2 My numbers ........................................................................................28
5.3 Billing ....................................................................................................29
5.4 Call settings ........................................................................................29
6. Directory ......................................................................32
6.1 Consulting your directory ..............................................................32
6.2 Creating a file......................................................................................33
6.3 Available options................................................................................34
2
Introduction ................................
TCT Mobile Limited would like to thank you for purchasing this cellphone.
Power music player/video player
• With playlist, lyrics display and equalizer
• Full screen video playback
• Watch the show on 1.8” TFT screen
Unlimited video recording
• Shoot video clips as long as you want
(1)
USB mass storage
Simply a USB key.
Webcam
The best companion for PC messenger.
1
(1)
Depending on battery and free memory.
607_UM_USA_30-12-08 30/12/08 12:28 Page 1
12. Media album ................................................................53
12.1 My audio ..............................................................................................53
12.2 My images ............................................................................................54
12.3 My videos ............................................................................................54
12.4 My creations........................................................................................54
12.5 Unknown files ....................................................................................54
12.6 Memory card ......................................................................................55
12.7 Managing audio, images, videos and creations ............................56
12.8 Formats and compatibility ..............................................................57
12.9 Memory status....................................................................................57
13. Camera & Video ..........................................................58
13.1 Access ..................................................................................................58
13.2 Camera ................................................................................................58
13.3 Video ....................................................................................................60
14. Music ............................................................................63
14.1 Music ....................................................................................................63
14.2 Settings ................................................................................................64
14.3 Playing with lyrics ..............................................................................64
15. Games ..........................................................................65
16. Making the most of your cellphone ..........................66
16.1 PC suite................................................................................................66
17. Latin input mode/character table ..............................67
18. Telephone warranty ....................................................71
19. Accessories ..................................................................73
20. Troubleshooting ..........................................................74
4
7. Messages ......................................................................35
7.1 Messages:Text/Multimedia message ..............................................35
7.2 Voice message ....................................................................................37
7.3 Photo message....................................................................................37
7.4 Video message....................................................................................37
7.5 Voicemail ..............................................................................................37
7.6 Settings ................................................................................................37
8. My settings....................................................................39
8.1 Ringtones ............................................................................................39
8.2 Color ....................................................................................................40
8.3 Clamshell..............................................................................................40
8.4 Theme ..................................................................................................41
8.5 Antenna off mode..............................................................................41
8.6 Equalizer ..............................................................................................41
8.7 Display..................................................................................................42
8.8 Clock ....................................................................................................43
8.9 Keys ......................................................................................................43
8.10 More settings ......................................................................................44
9. Tools ..............................................................................47
9.1 Organizer ............................................................................................47
9.2 Alarm ....................................................................................................47
9.3 Calculator ............................................................................................47
9.4 Converter............................................................................................48
9.5 Memory status....................................................................................48
9.6 Voice memo ........................................................................................49
10. My shortcuts ................................................................50
11. WAP..............................................................................51
11.1 Homepage............................................................................................51
11.2 Bookmarks ..........................................................................................51
11.3 Recent pages ......................................................................................51
11.4 Go to URL ..........................................................................................51
11.5 Profiles..................................................................................................51
3
607_UM_USA_30-12-08 30/12/08 12:28 Page 3
Over 55°C the legibility of the phone’s display may be impaired, though this is temporary and not serious. Emergency call numbers may not be reachable on all cellular networks. You should never rely only on your phone for emergency calls. Do not open, dismantle or attempt to repair your cellphone yourself. Do not drop, throw or try to bend your cellphone. Do not paint it. Use only batteries, battery chargers, and accessories which are recommended by TCT Mobile Limited and its affiliates and are compatible with your phone model (see Accessories List page 73). TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries. Your phone should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products. Remember to make back-up copies or keep a written record of all important information stored in your phone. Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games.These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone. Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15 minute break hourly.
- Play in a well lit room.
- Play at the farthest distance possible from the screen.
- If your hands, wrists,or arms become tired or sore while playing, stop and rest for several hours before playing again.
- If you continue to have sore hands,wrists, or arms during or after playing, stop the game and see a doctor.
When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders,neck, or other parts of your body. Follow the instructions to avoid problems such as tendonitis, carpal tunnel syndrome, or other musculoskeletal disorders.
Prolonged exposure to music at full volume on the music player may damage the listener's hearing.
Set your phone volume safely. Use only headphones recommended by TCT Mobile Limited and its affiliates.
6
Safety and use ............................
We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Recent studies show that using a cellphone while driving a vehicle constitutes a real risk,even when the hands-free kit is used (headset...), drivers are requested to refrain from using their cellphone when the vehicle is not parked.
Check the laws and regulations on the use of wireless telephones and their accessories in the areas where you drive.The use of these devices may be prohibited or restricted in certain areas.Do not use your phone's stereo or music feature with a headphone. When driving, do not use your phone and headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas. When switched on, your phone emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its performance. Switch the phone off before boarding an aircraft. Switch the phone off when you are in health care facilities,except in designated areas. As with many other types of equipment now in regular use, cellphones can interfere with other electrical or electronic devices, or equipment using radio frequency. Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive atmosphere. When the phone is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump. In particular when using the phone you should hold it against the ear on the opposite side to the device, if any. To avoid hearing impairment, pick up the call before holding your phone to your ear.Also move the handset away from your ear while using the “hands-free” option because the amplified volume might cause hearing damage. Do not let small children use your cellphone without supervision. When replacing the cover please note that your phone may contain substances that could create an allergic reaction. Always handle your phone with care and keep it in a clean and dust-free place. Do not allow your phone to be exposed to adverse weather or environmental conditions (moisture, humidity, rain, infiltration of liquids, dust,sea air, etc.).The manufacturer’s recommended operating temperature range is -10°C to +55°C (the max value depends on product ie. housing or paint).
5
607_UM_USA_30-12-08 30/12/08 12:28 Page 5
Characteristics of power supply (depending on the country):
110 V charger (used in Mexico / USA): Input: 100-240 V, 50/60 Hz, 0.15 A Output: 5 V(5,V), 400mA Battery: Lithium 3.7V/750 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your cellphone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies.These guidelines include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health. The exposure standard for cellphones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating positions with the cellphone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the cellphone while operating can be well below the maximum value.This is because the cellphone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the cellphone. Before a cellphone model is available for sale to the public, compliance with national regulations and standards must be shown. The highest SAR value for this model cellphone when tested for use at the ear is 0.743 W/Kg and for use close to the body is 1.21 W/Kg. While there may be differences between the SAR levels of various cellphones and at various positions, they all meet the government requirement for RF exposure. For body-worn operation, the cellphone meets FCC RF exposure guidelines provided that it is used with a non-metallic accessory with the handset at least 1.5 cm from the body.Use of other accessories may not ensure compliance with FCC RF exposure guidelines. The World Health Organization (WHO) considers that present scientific information does not indicate the need for any special precautions for use of cellphones.If individuals are concerned, they might choose to limit their own or their children's RF exposure by limiting the length of calls, or using "hands-free" devices to keep cellphones away from the head and body. (fact sheet n°193). Additional WHO information about electromagnetic fields and public health are available on the following website: http://www.who.int/peh-emf.
8
• PRIVACY:
Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your cellphone regarding taking photographs and recording sounds with your cellphone. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and reproduce or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorization be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your cellphone (including the operator) disclaim any liability which may result from the improper use of the cellphone.
• BATTERY:
Before removing the battery from your phone, please make sure that the phone is switched off. Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at temperatures above 60 °C.
Batteries must be disposed of in accordance with locally applicable environmental regulations.Only use the battery for the purpose for which it was designed. Never use damaged batteries or those not recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your cellphone, the battery and the accessories means that these products must be taken to collection points at the end of their life:
- Municipal waste disposal centers with specific bins for these items of equipment
- Collection bins at points of sale. They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities;instead they are to be taken to collection points for them to be recycled. In the United Stares you may learn more about CTIA’s Recycling Program at www.recyclewirelessphones.com CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
• HOME POWERED CHARGERS:
Home powered chargers will operate within the temperature range of: 0°C to 40°C.The chargers designed for your cellphone meet with the standard for safety of information technology equipment and office equipment use. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction.They should be used for this purpose only.
7
607_UM_USA_30-12-08 30/12/08 12:28 Page 7
General information ..................
• Website: www.alcatel-mobilephones.com
• Hot Line Number: see “TCT Mobile Services” leaflet or go to our
Internet site.
On our Internet site, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other languages according to availability on our server: www.alcatel­mobilephones.com
Your cellphone is a transceiver that operates on GSM networks with 850, 1900 MHz bands.
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity for your cellphone can be obtained through our website: www.alcatel-mobilephones.com.
10
NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid touching it or degrading it.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548, 6,307,549, and 6,636,162, 6,646,573; European Pat. Nos. 0 842 463 (96927260.8), 1 010 057 (98903671.0), 1 018 069 (98950708.2);and additional patents are pending worldwide.
9
607_UM_USA_30-12-08 30/12/08 12:28 Page 9
®
12
Protection against theft
(1)
Your cellphone is identified by an IMEI (phone serial number) shown on the packaging label and in the product’s memory. We recommend that you note the number the first time you use your cellphone by entering * # 0 6 # and keep it in a safe place. It may be requested by the police or your operator if your cellphone is stolen.This number allows your cellphone to be blocked preventing a third person from using it, even with a different SIM card.
Disclaimer
There may be certain differences between the user manual description and the phone’s operation, depending on the software release of your cellphone or specific operator services.
11
(1)
Depending on your network operator.
(1)
Contact your network operator to check service availability.
1
Your cellphone ......................
Voicemail
Switch on/ Switch off End call
Left softkey
Right softkey
Answer Call/Send
Call
Call memory
Navigation key
(1)
: Menu/Confirm an option Messages Directory Media Album Volume
Vibrator
Camera key
Forward key Play/Pause key Backward key
607_UM_USA_30-12-08 30/12/08 12:28 Page 11
From main screen
- Short keypress: #
- Long keypress: activate/deactivate the vibrator In edit mode:
- Short keypress: (space)
- Long keypress: add a word
Camera key Short keypress: take a photo Long keypress: go to the Music player screen and play the recent song.
Short keypress: Play/pause Long keypress: go to the Music player screen and play the recent song.
(in the playing mode) Short keypress: previous/next song Long keypress: backward/forward
When there is an incoming event, the music keys are flashing.
14
1.1 Keys
Navigation key Confirm an option (press the middle of the key)
Answer Call Send Call Access call memory (Redial) (short keypress)
Switch on/Switch off the cellphone (long keypress) End call Return to the main screen
Left softkey
Right softkey
Access your voicemail (long keypress)
In Edit mode:
- Short keypress: change input methods
- Switch from T9 predictive mode to Normal mode
- Long keypress: access the Symbols table
13
607_UM_USA_30-12-08 30/12/08 12:28 Page 13
Level of network reception.
USB cable connected.
Receiving a message in progress.
Sending a message.
Silence mode: your phone is in silent mode. Ringer and vibrator
are silenced except for alarm (see page 40).
Message unread
Message list is full: your messages are full. You must delete at
least 1 old message to receive a new message.
Preferred tariff areas
(1)
.
Antenna off mode.
16
(1)
Contact your network operator to check service availability.
1.2 Main screen icons
(1)
Battery charge level.
Vibrate alert: your phone is in vibrate mode. Ringer is silenced
except for alarm (see page 40).
Headset connected.
Call forwarding activated: your calls are forwarded (see page
30).
Alarm clock programmed (see page 47).
Voicemail message received.
Unanswered calls.
WAP alerts
(2)
.
Roaming.
Memory card scanning in progress.
Memory card scanning completed.
Line switching
(2)
: indicates the selected line.
GPRS active.
Music player active.
15
(1)
The icons and illustrations in this guide are provided for informational purposes only.
(2)
Depending on your network operator.
607_UM_USA_30-12-08 30/12/08 12:28 Page 15
18
Connect the battery charger
• Charging may take about 20 minutes to start if the battery is dead.
• Be careful not to force the plug into the socket.
• Make sure the battery is correctly inserted before connecting the
charger.
• The power outlet must be near the phone to avoid using extension
cords when charging.
• When using your cellphone for the first time, charge the battery fully
(approximately 3 hours).
The charge is complete when the animation stops. Only use Alcatel chargers.
Charging the battery
2
Getting started ....................
2.1 Set-up
Inserting and removing the SIM card
(1)
You must insert your SIM card to make phone calls.
17
Installing and removing the battery
Insert and click the battery into place, then close the cellphone cover.
Unclip the cover, then remove the battery.
(1)
Check with your network operator to make sure that your SIM card is 3V compatible. The old 5 Volt cards can no longer be used. Please contact your operator.
Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press it and slide it out.
607_UM_USA_30-12-08 30/12/08 12:28 Page 17
While the phone is searching for a network, “Searching/Emergency” will be displayed.
In the power on screen, you also have access to "Media album", "Camera & Video" and "Music" functions even if your SIM card is not inserted.
2.3 Power off your phone
Hold down the key from the main screen.
20
Removing the back cover
19
2.2 Power on your phone
Hold down the key until the cellphone powers on, type in your PIN code if necessary and then confirm with the key. The main screen is displayed.
If you don’t know your PIN code or if you have forgotten it, contact your network operator. Do not leave your PIN code near your cellphone and store your card in a safe place when not in use.
If messages are displayed,use the key to browse through them in full or press the right softkey to return to the main screen.
607_UM_USA_30-12-08 30/12/08 12:28 Page 19
If the access number for your operator’s voicemail service does not work, dial the number that you were given.To change this number at a later date, refer to “My Numbers” (see page 28).
To use your voicemail service from abroad,contact your network operator before leaving.
3.3 Receiving a call
When you receive an incoming call,press the key to talk and then hang up using the key.
If the icon is displayed, the vibrator is activated and there is no ringtone. If the icon is displayed, the phone neither rings nor vibrates.
If the flip is open
- To answer a call, press the key.
If the flip is closed
- To answer a call, open the flip (if clamshell open answer option is activated, see page 40).
The caller’s number is displayed if it is transmitted by the network (contact your network operator to check service availability).
22
3
Calls ......................................
3.1 Making a call
Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey.
To hang up the call, press the key.
To enter characters “+”, “W” (for tonewait) or “P” (used to store a number with extension number), hold down the key (the following characters will scroll by: 0, +, P, W).
Making an emergency call
If your phone is covered by the network, dial 911 and press the key to make an emergency call (or any other number provided by your operator).This works even without a SIM card and without typing the PIN code or unlocking the keypad.
3.2 Calling your voicemail
(1)
Your voicemail is an optional feature offered by your provider to accept voice messages if you are unable to answer a call. It works like an answering machine that you can consult at any time. To access your voicemail, hold down the key.
21
(1)
Contact your network operator to check service availability.
607_UM_USA_30-12-08 30/12/08 12:28 Page 21
Loading...
+ 28 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
