Alcatel OT-C820A User Manual

displayed, the vibrator is activated and there is no

ringtone. If the

icon is displayed, the phone neither rings nor vibrates.

ringtone. If the

icon is displayed, the phone neither rings nor vibrates.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 1

English - T5000562 AAAA 01

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 1

Introduction ................................

T&A Mobile phones would like to thank you for purchasing this mobile.

Power music player/video player

•With playlist, lyrics display and equalizer

•Full screen video playback

•Watch the show on 2.0” TFT screen

Unlimited video recording

• Shoot video clips as long as you want (1)

USB mass storage

Simply a USB key.

Webcam

The best companion for PC instant messaging.

Bluetooth

•Bluetooth 2.0

•A2DP profile (Bluetooth stereo)

Table of contents ........................

Safety and use ......................................................................			5
General information..........................................................			10
1.	Your mobile ..................................................................		12
	1.1	Keys ......................................................................................................	13
	1.2	Main screen icons ..............................................................................	15
2.	Getting started ............................................................		17
	2.1	Set-up....................................................................................................	17
	2.2	Power on your phone ......................................................................	19
	2.3	Power off your phone ......................................................................	20
3.	Calls ..............................................................................		21
	3.1	Making a call........................................................................................	21
	3.2	Calling your voicemail ......................................................................	21
	3.3	Receiving a call ..................................................................................	22
	3.4	During the call....................................................................................	23
	3.5	Conference calls ................................................................................	24
	3.6	Line switching ....................................................................................	25
4.	Menu..............................................................................		26
5.	Call log ..........................................................................		28
	5.1	Call memory ......................................................................................	28
	5.2	My numbers ........................................................................................	28
	5.3	Billing ....................................................................................................	29
	5.4	Call settings ........................................................................................	29
6.	Directory ......................................................................		32
	6.1	Consulting your directory ..............................................................	32
	6.2	Creating a file......................................................................................	34
	6.3	Available options................................................................................	34

(1)Depending on battery and free memory.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 3

7. Messages ......................................................................		36
7.1	Messages:Text/Multimedia message ..............................................	36
7.2	Voice message ....................................................................................	39
7.3	Photo message....................................................................................	39
7.4	Video message....................................................................................	39
7.5	Voicemail..............................................................................................	39
7.6	Settings ................................................................................................	39

8. My settings....................................................................		41
8.1	Ringtones ............................................................................................	41
8.2	Color ....................................................................................................	42
8.3	Slider settings......................................................................................	42
8.4	Theme ..................................................................................................	43
8.5	Antenna off mode..............................................................................	43
8.6	Equalizer ..............................................................................................	43
8.7	Display ..................................................................................................	44
8.8	Clock ....................................................................................................	45
8.9	Keys ......................................................................................................	45
8.10	More settings ......................................................................................	46

9. Tools ..............................................................................		49
9.1	Bluetooth™ ........................................................................................	49
9.2	Organizer ............................................................................................	50
9.3	Alarm ....................................................................................................	51
9.4	Calculator ............................................................................................	51
9.5	Converter............................................................................................	52
9.6	Memory status....................................................................................	52
9.7	Voice memo ........................................................................................	53

10. My shortcuts ................................................................		54
11. WAP ..............................................................................		55
11.1	Homepage............................................................................................	55
11.2	Bookmarks ..........................................................................................	55
11.3	Recent pages ......................................................................................	55
11.4	Go to URL ..........................................................................................	55
11.5	Profiles..................................................................................................	55
		3

12. Media album ................................................................		57
12.1	My audios ............................................................................................	57
12.2	My images ............................................................................................	58
12.3	My videos ............................................................................................	58
12.4	My creations........................................................................................	58
12.5	Unknown files ....................................................................................	58
12.6	Memory card ......................................................................................	59
12.7	Managing audios, images, videos and creations ..........................	60
12.8	Formats and compatibility ..............................................................	61
12.9	Memory status....................................................................................	61
13. Photo & Video ..............................................................		62
13.1	Access ..................................................................................................	62
13.2	Photo ....................................................................................................	62
13.3	Video ....................................................................................................	64
14. Music player..................................................................		67
14.1	Music player ........................................................................................	67
14.2	Settings ................................................................................................	68
14.3	Playing with lyrics ..............................................................................	68
15. Games & Applications ................................................		69
15.1	Launch an application........................................................................	69
15.2	Java settings ........................................................................................	69
15.3	Java downloading................................................................................	69
16. Making the most of your mobile................................		71
16.1	PC suite................................................................................................	71
17. Latin input mode/Character table ............................		72
18. Telephone warranty ....................................................		76
19. Accessories ..................................................................		78
20. Troubleshooting ..........................................................		79

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 5

Safety and use ............................

We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.

• TRAFFIC SAFETY:

Given that studies show that using a cellphone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their cellphone when the vehicle is not parked.

When driving, do not use your phone and headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas.

When switched on, your phone emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags.To ensure that there is no problem:

-do not place your phone on top of the dashboard or within an airbag deployment area,

-check with your car dealer or the car manufacturer to make sure that the car’s electronic devices are shielded from cellphone RF energy.

• CONDITIONS OF USE:

You are advised to switch off the telephone from time to time to optimize its performance. Switch the phone off before boarding an aircraft to avoid prosecution.

Switch the phone off when you are in health care facilities, except in designated areas.As with many other types of equipment now in regular use, cellphones can interfere with other electrical or electronic devices, or equipment using radio frequency.

Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive atmosphere.

When the phone is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump. In particular when using the phone you should hold it against the ear on the opposite side to the device, if any.

To avoid hearing impairment, pick up the call before holding your phone to your ear.Also move the handset away from your ear while using the “hands-free” option because the amplified volume might cause hearing damage.

Do not let small children use your cellphone without supervision.

When replacing the cover please note that your phone may contain substances that could create an allergic reaction.

Always handle your phone with care and keep it in a clean and dust-free place.

Do not allow your phone to be exposed to adverse weather or environmental conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.).The manufacturer’s recommended operating temperature range is -10°C to +55°C (the max value depends on product i.e. if paint or not) Over 55°C the legibility of the phone’s display may be impaired, though this is temporary and not serious.

Do not open or attempt to repair your cellphone yourself. Do not drop, throw or try to bend your cellphone.

Do not paint it.

Use only batteries, battery chargers, and accessories which are recommended by T & A Mobile Phones Limited and its affiliates and are compatible with your phone model (see Accessories List£¨chapter 78).T&A Mobile Phones Limited and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries.

Your phone should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products.

Remember to make back-up copies or keep a written record of all important information stored in your phone.

Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games.These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone. Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:

-Do not play or use a flashing-lights feature if you are tired or need sleep.

-Take a minimum of a 15minute break hourly.

-Play in a room in which all lights are on.

-Play at the farthest distance possible from the screen.

When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders:

-Take a minimum of a 15 minute-break every hour of game playing.

-If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.

- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see a doctor.

Prolonged exposure to music at full volume on the music player may damage the listener's hearing. Set your phone volume safely. Use only headphones recommended by T & A Mobile Phones Limited and its affiliates.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 7

• PRIVACY:

Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding taking photographs and recording sounds with your mobile telephone. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and reproduce or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorization be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your cellphone (including the operator) disclaim any liability which may result from the improper use of the cellphone.

• BATTERY:

Before removing the battery from your phone, please make sure that the phone is switched off. Observe the following precautions for battery use:

- Do not attempt to open the battery (due to the risk of toxic fumes and burns). - Do not puncture, disassemble or cause a short-circuit in a battery,

-Do not burn or dispose of a used battery in the garbage or store it at temperatures above 60 °C.

Batteries must be disposed of in accordance with locally applicable environmental regulations. Only use the battery for the purpose for which it was designed. Never use damaged batteries or those not recommended by T&A Mobile Phones Limited and/or its affiliates.

This symbol on your telephone, the battery and the accessories means that these products must be taken to collection points at the end of their life:

- Municipal waste disposal centres with specific bins for these items of equipment

- Collection bins at points of sale.

They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.

In European Union countries:

These collection points are accessible free of charge. All products with this sign must be brought to these collection points.

In non European Union jurisdictions:

Items of equipment with this symbol are not be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled.

• CHARGERS

Mains powered chargers will operate within the temperature range of: 0°C to 40°C.

The chargers designed for your cellphone meet with the standard for safety of information technology equipment and office equipment use.

Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction.

They should be used for this purpose only.

Characteristics of power supply (depending on the country):

Travel charger:

Input : 100-240 V, 50/60 Hz, 0.15 A

Output : 5 V, 400mA

Battery: Lithium 700 mAh

• RADIO WAVES:

THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your cellphone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies.These guidelines include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health.

The exposure standard for cellphones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating positions with the cellphone transmitting at its highest certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified power level, the actual SAR level of the cellphone while operating can be well below the maximum value.This is because the cellphone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the cellphone Before a cellphone model is available for sale to the public, compliance with national regulations and standards must be shown.

The highest SAR value for this model cellphone when tested for use at the ear is 0.79 W/Kg and for use close to the body is 0.96 W/Kg.While there may be differences between the SAR levels of various cellphones and at various positions, they all meet the government requirement for RF exposure. For body-worn operation, the cellphone meets FCC RF exposure guidelines provided that it is used with a non-metallic accessory with the handset at least 2 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 9

The World Health Organization (WHO) considers that present scientific information does not indicate the need for any special precautions for use of cellphones. If individuals are concerned, they might choose to limit their own or their children's RF exposure by limiting the length of calls, or using "hands-free" devices to keep cellphones away from the head and body. (fact sheet n°193).Additional WHO information about electromagnetic fields and public health are available on the following website: http://www.who.int/peh-emf.

Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid touching it or degrading it.

• LICENCES

Obigo®	is a registered trademark of Obigo AB.
	microSD Logo is a trademark.
	The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
	use of such marks by T&A Mobile Phones Limited and its affiliates is under license.
	Other trademarks and trade names are those of their respective owners.
	T9 Text Input is licensed under			one or more of the following: U.S. Pat. Nos.
	5,187,480,	5,818,437,	5,945,928,	5,953,541,	6,011,554,	6,286,064,	6,307,548,
®	6,307,549, and 6,636,162, 6,646,573; European Pat. Nos. 0					842 463 (96927260.8),
	6,307,549, and 6,636,162, 6,646,573; European Pat. Nos. 0					842 463 (96927260.8),

1 010 057 (98903671.0), 1 018 069 (98950708.2); and additional patents are pending worldwide.

Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

General information ..................

•Website: www.tctmobile.com

•Hot Line Number: see “T&A Mobile Phones Services” leaflet or go to our Internet site.

On our Internet site, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have.

An electronic version of this user guide is available in English and other languages according to availability on our server: www.tctmobile.com

Your telephone is a transceiver that operates on GSM networks with 850, 1800 and 1900 MHz bands.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 11

Protection against theft (1)

Your cellphone is identified by an IMEI (phone serial number) shown on the packaging label and in the product’s memory.We recommend that you note the number the first time you use your telephone by entering *#06# and keep it in a safe place. It may be requested by the police or your operator if your telephone is stolen. This number allows your cellphone to be blocked preventing a third person from using it, even with a different SIM card.

Disclaimer

There may be certain differences between the user manual description and the phone’s operation, depending on the software release of your telephone or specific operator services.

February 2007

(1)Check the availability of this service with your operator.

1 Your mobile ..........................

Volume +/-

Camera key

Play/Pause

Left softkey

Pick up/Send call

Call memory

Voicemail

Navigation key (1): Menu/Confirm an option Messages Directory Media Album Volume

Right softkey

Switch on/

Switch off

End call

Vibrator

(1)Depending on your network operator.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 13

1.1Keys

Navigation key

Confirm an option (press the middle of the key)

Pick up

Send a call

Access call memory (Redial) (short keypress)

Switch on/Switch off the telephone (long keypress) End call

Return to the main screen

Left softkey

Right softkey

Access your voicemail (long keypress)

In Edit mode:

-Short keypress: change input methods

-Switch from T9 predictive mode to Normal mode

-Long keypress: access the Symbols table

From main screen

-Short keypress: #

-Long keypress: activate/deactivate the vibrator In edit mode:

-Short keypress: (space)

-Long keypress: add a word

Short keypress: Play/pause

Long keypress: go to the Music player screen and play the current song.

(in the playing mode) Short keypress: previous/next song

Side keys:

Camera key

Volume up (Zoom in)

Volume down (Zoom out)

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 15

1.2Main screen icons (1)

Battery charge level

Vibrate alert: your phone vibrates, but neither rings nor beeps except for the alarms (see page 42).

Bluetooth status (Blue - Activated).

Bluetooth status (Connected to an audio device).

Headset connected.

Keypad locked.

Call forwarding activated: your calls are forwarded (see page 30).

Alarm clock programmed (see page 51).

Level of network reception.

Voicemail message arrived.

Unanswered calls.

WAP alerts (2).

Roaming.

(1)The icons and illustrations in this guide are provided for informational purposes only.

(2)Depending on your network operator.

Memory card scanning in progress.

Memory card scanning completed.

Double line (1): indicates the selected line.

GPRS active.

Music player active.

USB cable connected.

Reception of a message in progress.

Sending a message.

Silence mode: your phone neither rings, beeps nor vibrates except for the alarms (see page 42).

Message unread

Message list is full: your terminal cannot accept any new messages.You must access the message list and delete at least one message on your SIM card.

Preferred tariff areas (1).

Antenna off mode.

A2DP connected.

(1)Contact your network operator to check service availability.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 17

2 Getting started ....................

2.1Set-up

Inserting and removing the SIM card (1)

You must insert your SIM card to make phone calls.

Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted.

To remove the card, press it and slide it out.

Installing the battery

Removing the battery

Insert and click the battery into	Unclip the cover, then remove
place, then close the telephone	the battery.
cover.

(1)Check with your network operator to make sure that your SIM card is 3V compatible. The old 5 Volt cards can no longer be used. Please contact your operator.

Charging the battery

Connect the battery charger

•The charging may take about 20 minutes to start if the battery is flat.

•Be careful not to force the plug into the socket.

•Make sure the battery is correctly inserted before connecting the charger.

•The mains socket must be near to the phone and easily accessible (avoid electric extension cables).

•When using your telephone for the first time, charge the battery fully

(approximately 3 hours). You are advised to fully charge the battery ().

The charge is complete when the animation stops. Only use Alcatel chargers.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 19

Remove the back cover

2.2Power on your phone

Hold down the key until the telephone powers on, type in your PIN code if necessary and then confirm with the key.The main screen is displayed.

If you don’t know your PIN code or if you have forgotten it, contact your network operator. Do not leave your PIN code near your telephone and store your card in a safe place when not in use.

If cell broadcast messages are displayed, use the key to browse through them in full or press the right softkey to return to the main screen.

While the phone is searching for a network, “Searching/Emergency” will be displayed.

In the power on screen, you also have access to "Media album", "Photo&Video" and "Music player" functions even if no SIM card inside.

2.3Power off your phone

Hold down the key from the main screen.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 21

3 Calls....................................

3.1Making a call

Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey.

To hang up the call, press the key.

To enter characters “+”,“W” (for tonewait) or “P” (used to store a number with extension number), hold down the key (the following characters will scroll by: 0, +, P,W).

Making an emergency call

If your phone is covered by the network, dial 112 and press the key to make an emergency call (or any other number provided by your operator).This works even without a SIM card and without typing the PIN code or unlocking the keypad.

3.2Calling your voicemail (1)

Your voicemail is provided by your network to avoid missing calls. It works like an answering machine that you can consult at any time.To access your voicemail, hold down the key.

(1)Contact your network operator to check service availability.

If the access number for your operator’s voicemail service does not work, dial the number that you were given.To change this number at a later date, refer to “My numbers” (see page 28).

To use your voicemail service from abroad, contact your network operator before leaving.

3.3Receiving a call

When you receive an incoming call, press the key to talk and then hang up using the key.

The caller’s number is displayed if it is transmitted by the network (contact your network operator to check service availability).

Muting the ringtone

Press the right softkey once while the telephone is ringing.Answer the call by pressing the key.

Rejecting a call

Press the key once or the right softkey twice.

K7S_UM_USA_25-10-07 25/10/07 9:30 Page 23

3.4During the call

Available functions

During a call, you can use your directory, your diary, short messages, etc. without losing your correspondent by pressing the key.

Call on hold

Ongoing call

Handsfree

WARNING: move the handset away from your ear while using the “handsfree” option because the amplified volume might cause hearing damage.
