Alcatel Idol Mini User Manual

Note:

Your phone is a unibody device, so the back cover and battery are not
removable.
Your phone only supports micro-SIM cards. Do not attempt to insert other SIM
card types like mini and nano cards, otherwise you may damage your phone.
If your phone experiences an unexpected system crash, try to press and hold
the Power key for a while until the power-on animation appears.

Table of Contents

Safety and use ............................................................................4

General information ...............................................................11

1 Your mobile .......................................................................12

1.1 Keys and connectors ................................................................................ 12

1.2 Getting started ..........................................................................................15

1.3 Home screen ..............................................................................................18

1.4 Applications and widgets list ..................................................................28

2 Text input ........................................................................... 29

2.1 Using the Onscreen Keyboard ...............................................................29

2.2 Text editing .................................................................................................31

3 Phone call, Call log and Contacts .................................... 32

3.1 Phone ...........................................................................................................32

3.2 Call log .........................................................................................................41

3.3 People .......................................................................................................... 42

4 Messaging, Email ...............................................................49

4.1 Messaging .................................................................................................... 49

4.2 Gmail/Email .................................................................................................56

4.3 Hangouts .....................................................................................................62

5 Calendar & Alarm clock & Calculator ............................65

5.1 Calendar ......................................................................................................65

5.2 Time ............................................................................................................. 67

5.3 Calculator ....................................................................................................68

6 Getting connected ............................................................70

6.1 Connecting to the Internet .................................................................... 70

6.2 Browser .......................................................................................................73

6.3 Connecting to Bluetooth devices..........................................................81

6.4 Connecting to a computer .....................................................................82

6.5 Sharing your phone's mobile data connection ...................................84

6.6 Connecting to virtual private networks ..............................................85

7 Google Play Store .............................................................87

7.1 Locate the item you want to download and install ..........................87

7.2 Download and install ................................................................................ 88

7.3 Manage your downloads .......................................................................... 90

8 Multimedia applications ...................................................92

8.1 Camera ........................................................................................................92

8.2 Gallery ......................................................................................................... 95

8.3 YouTube .......................................................................................................97

8.4 Music ............................................................................................................98

8.5 Video Player ..............................................................................................100

9 Google Maps ....................................................................101

9.1 Get My Location .....................................................................................101

9.2 Search for a location ..............................................................................102

9.3 Save a location .........................................................................................102

9.4 Get driving, public transportation or walking directions...............104

9.5 Arrangement of Layers ..........................................................................105

1 2

10 Others ..............................................................................106

10.1 File Manager .............................................................................................106

10.2 Sound Recorder ......................................................................................106

10.3 Radio ..........................................................................................................107

10.4 Setup Wizard ...........................................................................................108

10.5 Alcatel Help ............................................................................................ 109

10.6 Other applications ..................................................................................109

11 Settings ............................................................................110

11.1 Wireless & networks .............................................................................110

11.2 Device ........................................................................................................113

11.3 Personal .....................................................................................................116

11.4 Accounts ...................................................................................................122

11.5 System ........................................................................................................122

12 Making the most of your phone ....................................130

12.1 OVER-THE-AIR SOFTWARE UPDATE CAPABLE Upgrade ........130

13 LIMITED WARRANTY ...................................................131

14 Accessories .....................................................................133

15 Troubleshooting ..............................................................134

16 Specifications ................................................................... 140

This product meets applicable national SAR limits
of 1.6 W/kg. The specific maximum SAR values can
be found in the RADIOWAVES section of this user
guide.

When carrying the product or using it while worn

www.sar-tick.com

on your body, either use an approved accessory
such as a holster or otherwise maintain a distance
of 1.0 cm from the body to ensure compliance with
RF exposure requirements. Note that the product
may be transmitting even if you are not making a
phone call.

3 4

Safety and use ..............................

We recommend that you read this chapter carefully before using your mobile phone.
The manufacturer disclaims any liability for damage, which may result as a consequence
of improper use or use contrary to the instructions contained herein.

• TRAFFIC SAFETY:

Given that studies show that using a mobile phone while driving a vehicle constitutes
a real risk, even when the hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their mobile phone when the vehicle is not parked.
Check the laws and regulations on the use of wireless mobile phones and their
accessories in the areas where you drive. Always obey them. The use of these devices
may be prohibited or restricted in certain areas.

When driving, do not use your mobile phone and headphone to listen to music or to
the radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your mobile phone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or
airbags. To ensure that there is no problem:

- do not place your mobile phone on top of the dashboard or within an airbag
deployment area,

- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from mobile phone RF energy.

• CONDITIONS OF USE:

You are advised to switch off the mobile phone from time to time to optimize its
performance.
Remember to abide by local authority rules of mobile phone use on aircrafts.
Operational Warnings: Obey all posted signs when using mobile devices in public
areas.
Follow Instructions to Avoid Interference Problems: Turn off your mobile device in
any location where posted notices instruct you to do so. In an aircraft, turn off your
mobile device whenever instructed to do so by airline staff. If your mobile device
offers an airplane mode or similar feature, consult airline staff about using it in flight.
Switch the mobile phone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, mobile phones can
interfere with other electrical or electronic devices, or equipment using radio frequency.
Switch the mobile phone off when you are near gas or flammable liquids. Strictly obey
all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in
any potentially explosive atmosphere.
When the mobile phone is switched on, it should be kept at least 15 cm from any

medical device such as a pacemaker, a hearing aid or insulin pump. In particular when
using the mobile phone you should hold it against the ear on the opposite side to
the device, if any.
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your
implantable medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding your mobile phone to
your ear. Also move the handset away from your ear while using the “hands-free”
option because the amplified volume might cause hearing damage.
It is recommended to have proper supervision while small children use your mobile
phone.
Please note that your phone is a unibody device, the back cover and battery are
not removable. Do not attempt to disassemble your phone. If you disassemble your
phone the warranty will not apply. Disassembling the phone may also damage the
battery, and may cause leakage of substances that could create an allergic reaction.
Always handle your mobile phone with care and keep it in a clean and dust-free place.
Do not allow your mobile phone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The
manufacturer’s recommended operating temperature range is -10°C (14°F) to +55°C
(131°F) (the max value depends on device, materials and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s display may be impaired,
though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is damaged, cracked or broken
to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your mobile phone
model. TCT Mobile Limited and its affiliates disclaim any liability for damage caused
by the use of other chargers or batteries.
Your mobile phone should not be disposed of in a municipal waste. Please check local
regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing
lights, or when playing video games. These seizures or blackouts may occur even if
a person never had a previous seizure or blackout. If you have experienced seizures
or blackouts, or if you have a family history of such occurrences, please consult your
doctor before playing video games on your mobile phone or enabling a flashing-

5 6

lights feature on your mobile phone. Parents should monitor their children’s use of
video games or other features that incorporate flashing lights on the mobile phones.
All persons should discontinue use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms, please take
the following safety precautions:

- Play at the farthest distance possible from the screen.

When you play games on your mobile phone, you may experience occasional discomfort
in your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders:

- Take a minimum of a 15-minute break every hour of game playing.

- If your hands, wrists, or arms become tired or sore while playing, stop and rest
for several hours before playing again.

- If you continue to have sore hands, wrists, or arms during or after playing, stop the
game and see a doctor.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume
levels for long periods. Exercise caution when holding your device
near your ear while the loudspeaker is in use.

• PRIVACY:

Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding
taking photographs and recording sounds with your mobile phone. Pursuant to such
laws and regulations, it may be strictly forbidden to take photographs and/or to
record the voices of other people or any of their personal attributes, and reproduce
or distribute them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained,
if necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
mobile phone (including the operator) disclaim any liability which may result from
the improper use of the mobile phone.

• BATTERY AND ACCESSORIES:

Please note your phone is a unibody device, the back cover and battery are not
removable. Observe the following precautions:

- Do not attempt to open the back cover,

- Do not attempt to eject, replace and open battery,

- Do not punctuate the back cover of your phone,

- Do not burn or dispose of your phone in household rubbish or store it at
temperature above 60°C.

Phone and battery as a unibody device must be disposed of in accordance with locally
applicable environmental regulations.

This symbol on your telephone, the battery and the accessories means that
these products must be taken to collection points at the end of their life:

- Municipal waste disposal centers with specific bins for these items of
equipment

- Collection bins at points of sale.

They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.

In European Union countries:

These collection points are accessible free of charge. All products with this sign must
be brought to these collection points.

In non European Union jurisdictions:

Items of equipment with this symbol are not be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead they
are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

• CHARGERS

Home A.C./ Travel chargers will operate within the temperature range of: 0°C (32°F)
to 40°C (104°F).
The chargers designed for your mobile phone meet with the standard for safety
of information technology equipment and office equipment use. Due to different
applicable electrical specifications, a charger you purchased in one jurisdiction may
not work in another jurisdiction. They should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5 V, 550 mA
Battery: Lithium 1700 mAh

• RADIO WAVES:

THIS MOBILE PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio-frequency (RF)
energy. These limits are part of comprehensive guidelines and establish permitted

levels of RF energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. These guidelines include a substantial safety
margin designed to ensure the safety of all persons, regardless of age and health.
The exposure standard for mobile phones employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such
as the Federal Communications Commission of the US Government (FCC), or by
Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are
conducted using standard operating positions with the mobile phone transmitting at
its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual
SAR level of the mobile phone while operating can be well below the maximum
value. This is because the mobile phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the lower the power
output of the mobile phone. Before a mobile phone model is available for sale to
the public, compliance with national regulations and standards must be shown.
The highest SAR value for this model mobile phone when tested is

0.94 W/Kg for use at the ear and 1.29 W/Kg for use close to the body.
While there may be differences between the SAR levels of various mobile phones and at
various positions, they all meet the government requirement for RF exposure. For body­worn operation, the mobile phone meets FCC RF exposure guidelines provided that it
is used with a non-metallic accessory with the handset at least 1.0 cm from the body.
Use of other accessories may not ensure compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular Telecommunications &
Internet Association (CTIA) Web site: http://www.phonefacts.net
The World Health Organization (WHO) considers that present scientific information
does not indicate the need for any special precautions for use of mobile phones. If
individuals are concerned, they might choose to limit their own or their children’s
RF exposure by limiting the length of calls, or using “hands-free” devices to keep
mobile phones away from the head and body. (fact sheet n°193). Additional WHO
information about electromagnetic fields and public health are available on the
following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference to radio or television reception, which can be determined by turning the

7 8

equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

- Consult the dealer or an experienced radio/ TV technician for help.

Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service (e.g.
FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received, including interference that may

cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other
than against your ear. In such circumstances the device will be compliant with
the guidelines when used with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any metal and that it
positions the mobile phone at least 1.0 cm away from the body.

• LICENCES

microSD Logo is a trademark.

The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by TCT Mobile
Limited and its affiliates is under license. Other trademarks and
trade names are those of their respective owners.

ONETOUCH 6012A Bluetooth QD ID B021282

The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.

Google, the Google logo, Android, the Android logo, Google

The Android robot is reproduced or modified from work created and shared
by Google and used according to terms described in the Creative Commons 3.0
Attribution License (the text will show when you touch and hold Google legal in
Settings\About phone\Legal information)
You have purchased a product which uses the open source (http://opensource.
org/) programs mtd, msdosfs, netfilter/iptables and initrd in object code and other
open source programs licensed under the GNU General Public License and Apache
License.
We will provide you with a complete copy of the corresponding source codes upon
request within a period of three years from the distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/projects/alcatel/
files/. The provision of the source code is free of charge from internet.

Search TM, Google MapsTM, Gmail TM, YouTube, Google Play
Store, Google Latitude TM and Hangouts

TM

are trademarks of

Google Inc.

(1)

.

(1)

It may not available according to the countries.

9 10

Hearing Aid Compatibility

Your mobile phone is rated: «For Hearing Aid», to assist hearing device users in
finding mobile phones that may be compatible with their hearing devices.
This device is HAC M3 compatible. Reference ANSI C63.19-2007
For more information please visit our website http://www.alcatelonetouch.com

FCC ID: RAD390

General information ...................

• Website: www.alcatelonetouch.com

• Facebook: http://www.facebook.com/ALCATELONETOUCHCanada

• Twitter: http://www.twitter.com/alcatel1touch

• Hot Line Number: In Canada, call 888-841-5371 for technical support.

On our Internet site, you will find our FAQ (Frequently Asked Questions) section.
You can also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.com

Your telephone is a transceiver that operates on GSM in quad-band with
(850/900/1800/1900) MHz or UMTS in triple-band with (850/1900/2100) MHz.

Protection against theft

Your mobile phone is identified by an IMEI (mobile phone serial number) shown on
the packaging label and in the product’s memory. We recommend that you note
the number the first time you use your mobile phone by entering *#06# and keep
it in a safe place. It may be requested by the police or your operator if your mobile
phone is stolen.

Disclaimer

There may be certain differences between the user manual description and the
mobile phone’s operation, depending on the software release of your mobile phone
or specific operator services.

TCT Mobile shall not be held legally responsible for such differences, if any, nor for
their potential consequences, which responsibility shall be borne by the operator

exclusively.

(1)

Contact your network operator to check service availability.

(1)

11 12

Your mobile ..........................

1

1.1 Keys and connectors

Power key

Headset connector

Front camera

Charging LED indicator

Touch screen

Back key

Home key

micro-USB/

Charger connector

Option key

Flashlight

Camera

SIM slot

Volume up

Volume down

microSD card slot

Option key

• Touch: To use as Menu key, touch to access Wallpaper,

Manage applications and Settings.

• Touch and hold: Open a list of thumbnail images of apps you've

worked with recently. Touch a thumbnail image to open an
app. Swipe it upwards or downwards to remove a thumbnail
from the list.

Home key

• While on any application or screen, touch to return to the

Home screen.

Back key

• Touch to go back to the previous screen, or to close a dialog

box, options menu, the Notification panel, etc.

Power key

• Press: Lock the screen/Light up the screen.

• Press and hold: Show the pop-up menu to select from Power

off/Restart/Airplane mode/Quick start.

Press and hold: Power on.

• Press to mute the ringtone when there’s an incoming call.

• Press and hold for more than 7 seconds to restart the phone

if the system has frozen.

• Press and hold the Power and Volume down keys to

capture a screenshot.

• Press and hold the Power and Volume up keys in power off

mode to restore factory settings.

Volume Keys

• In call mode, adjusts the earpiece or headset volume.

• In Music/Video/Streaming mode, adjusts the media volume.

• In general mode, adjusts the ring tone volume.

• Mutes the ringtone of an incoming call.

• Press to light up the screen when it dims during a call.

• In Camera mode, when used as the capture key, allows you

to take a photo.

13 14

1.2 Getting started

1.2.1 Set-up

Inserting or removing the SIM card and microSD card

You must insert your SIM card to make phone calls. Please power off
your phone before inserting or removing the SIM card and microSD card.

Your phone only support micro-SIM card. Please contact your network
operator if you do not have a micro-SIM card.

To install, take off micro-SIM card protector, insert the micro-SIM card
into the slot with chip facing downward, and then cover the slot.

To remove the card, open micro-SIM card protector, gently press it out,
and then cover the slot.

Steps for removing and installing microSD card are the same with steps
for micro-SIM card.

Charging the battery

Connect the battery charger to your phone and outlet respectively.

• When using your telephone for the first time, charge the battery fully

(approximately 5 hours).

You are advised to fully charge the battery (
indicated by an on-screen percentage reading while the phone is powered
off. The percentage increases as the phone is charged.

If the battery is very low, there will be no indication that power is

being received until the charge is sufficient to show the charging
status bar. To reduce power consumption and energy waste,
once the battery is fully charged, disconnect your charger from
the plug; switch off Wi-Fi, GPS, Bluetooth or background-running
applications when not in use; reduce the backlight time, etc.

). The charge status is

1.2.2 Power on your phone

Hold down the Power key until the phone powers on, unlock your phone
(Slide, PIN, Password, Pattern, Face unlock or Voice unlock) if necessary
and confirm. The Home screen will then be displayed.

If you do not know your PIN code or if you have forgotten it, contact your
network operator. Do not leave your PIN code with your phone. Store
this information in a safe place when not in use.

15 16

Set up your phone for the first time

Once you have powered on your phone for the first time, you should set
the following options:

• Touch Get started..., then select the phone's language.

• Select your input keyboard, then touch Next.

• Select the SIM which you want to use, then touch Next.

• Set your date and timezone, you can also choose Automatic time zone,

then touch Next.

• Setup your Google account: Touch Set up now. If you have a

Google account, touch Yes to sign in, then enter your user name and
password. If you forget your password, you can go to http://www.
google.com/ to retrieve it. If you don’t own a Google account, you are
prompted to create one by touching Get an account. Touch Not now
to skip to the next step.

• Touch Next, then the Setup complete screen displays, touch Finish

to confirm.

If you power on your phone with no SIM card inserted, you can connect
to a Wi-Fi network to sign into your Google account and use some
features.

1.2.3 Power off your phone

Hold down the Power key from the Home screen, select Power off.

1.3 Home screen

You can bring all the items (applications, shortcuts, folders and widgets)
that you use most frequently to your Home screen for quick access. Touch
the Home key to switch to the Home screen.

Favorite applications tray

• Touch to enter the application

• Touch and hold to move or change applications

Application tab

• Touch to open the main menu

The Home screen is provided in an extended format to allow more space
for adding applications, shortcuts etc. Slide the Home screen horizontally
left and right to get a complete view of the Home screen. The white
short line at the lower part of the screen indicates which screen you are
viewing.

1.3.1 Using the touchscreen

(1)

Touch

To access an application, touch it with your finger.

(1)

Depends on software version.

17 18

Touch and Hold

Touch and hold the Home screen to access the available options for
setting the wallpaper.

Drag

Place your finger on any item to drag it to another location.

Status icons

GPRS connected

GPRS in use Roaming

EDGE connected No SIM card inserted

EDGE in use Vibrate mode

Receiving location data
from GPS

Slide/Swipe

Slide the screen to scroll up and down the applications, web pages… at
your convenience.

Flick

Similar to swiping, but flicking makes it move quicker.

Pinch/Spread

Place the fingers of one hand on the screen surface and draw them apart
or together to scale an element on the screen.

Rotate

Automatically change the screen orientation from portrait to landscape by
turning the phone sideways to have a better view.

1.3.2 Status bar

From the status bar, you can view both phone status and notification
information.

19 20

3G connected Ringer is silenced

3G in use

HSPA 4G connected Battery is very low

HSPA 4G in use Battery is low

Connected to a Wi-Fi
network

Bluetooth is on Battery is full

Connected to a Bluetooth
device

Airplane mode Headset connected

Alarm is set No signal (gray)

GPS is on Signal strength (blue)

Phone microphone is
muted

Battery is partially drained

Battery is charging

Notification icons

New text or multimedia
message

Problem with SMS or MMS
delivery

New Hangouts message Call forwarding is on

New voicemail Uploading data

Upcoming event Downloading data

Data is synchronizing Download finished

Missed call

Call on hold

Notification panel

Touch and drag down the Status bar to open the Notification panel.
Touch and drag up to close it. From the Notification panel, you can open
items and other reminders indicated by notification icons or view wireless
service information.

Touch to access Quick setting bar

Song is playing Select input method

Screenshot error

USB tethering is on

Portable Wi-Fi hotspot
is on

Screenshot captured System update available

Carrier data use threshold
approaching or exceeded

Call in progress

An open Wi-Fi network is
available

Phone is connected via USB
cable

Radio is on

Connected to VPN

21 22

Touch one notification and slide it sideways to delete it.

Touch the
notifications will remain).

Touch

icon to clear all event–based notifications (other ongoing

and then the Settings icon to access Settings.

Quick setting bar

• Touch icons to enable/disable functions or to

change modes

1.3.3 Search bar

(1)

The phone provides a Search function which can be used to locate
information within applications, the phone or the web.





 Search by text

• Slide the Home screen to the right, and then the search bar will

appear.

• Enter the text/phrase you want to search for.

• Touch

on the keyboard if you want to search on the web.

 Search by voice

• Touch

from the Search bar to display a dialog screen.

• Speak the word/phrase you want to search for. A list of search results

will display for you to select from.

1.3.4 Lock/Unlock your screen

To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password.

To create a screen unlock pattern (refer to section "Screen lock" for
detailed settings)

• Drag down the Notification panel and touch

icon to enter Settings, then touch Security\Set up screen lock\
Pattern.

• Draw your own pattern.

Draw your unlock pattern

Touch to confirm by drawing pattern again

To create a screen unlock PIN/Password

• Touch Settings\Security\Set up screen lock\PIN or Password.

• Set your PIN or password.

To lock phone screen

Press the Power key once to lock the screen.

and then the Settings

(1)

Depends on software version.

23 24

To unlock phone screen

Press the Power key once to light up the screen, draw the unlock pattern
you have created or enter your PIN or password to unlock the screen.

If you have chosen Slide as the screen lock, touch and drag the
downwards to unlock the screen.

icon

Reposition

Touch and hold the item to be repositioned to activate Move mode, drag
the item to the desired position and then release. You can move items
both on the Home screen and the Favorite tray. Hold the icon on the left
or right edge of the screen to drag the item to another Home screen.

Remove

Touch and hold the item to be removed to activate Move mode, drag
the item up to the top of Remove icon, and release after the item turns
red.

Create folders

To improve the organization of items (shortcuts or applications) on the
Home screen and the Favorite tray, you can add them to a folder by
stacking one item on top of another. To rename a folder, open it, touch
the folder’s title bar and input the new name.

1.3.5 Personalize your Home screen

Add

Touch the Application tab
to activate Move mode, and drag the item to your preferred Home
screen.

While adding an application to a Home screen, drag it to the top of
the App info icon to view its detailed information. If the application is
already downloaded, drag it to the top of the Uninstall icon to uninstall
it directly.

, touch and hold an application or a widget

25 26

Wallpaper customization

Touch and hold an empty area, a popup window named Choose
wallpaper from will appear, offering a range of options. Gallery includes

pictures you have taken, cropped or downloaded. Live wallpapers
includes a scrolling list of animated wallpapers. Video wallpaper includes
preset videos in the phone; and videos stored in your SD card and camera.
Wallpapers includes all preset wallpapers in the phone. Slide left and
right to locate a desired image, touch Set wallpaper to confirm.

1.3.6 Application tab

Touch on the Home screen to enter the applications and widgets
list.

To return to the Home screen, touch the Home key.

Consult recently-used applications

To consult recently-used applications, you can touch and hold the Option
key. Touch a thumbnail in the window to open the related application.
Touch one thumbnail and slide it upwards or downwards to delete it.
You can also touch and hold the app and touch Remove from list to
delete it.

1.3.7 Volume adjustment

Using the Volume key

Press the Volume key to adjust the volume. To activate vibrate mode,
press the Volume down key until the phone vibrates. Press the Volume

down key once more to activate silent mode.

Using Settings menu

Drag down the Notification panel and touch

to enter Settings, then touch Sound. You can set the volumes of

ringtones, notifications, system sounds etc. to your preference.

and then the Settings icon

1.4 Applications and widgets list

This list contains all pre-embedded and newly installed applications and
widgets.

To access the list, touch

To return to the Home screen, touch the Home key or the Back key.

Slide left and right to view all applications and widgets. Touch APPS,
DOWNLOADED or WIDGETS to access the category directly.

Touch the

icon to access the Google Play Store.

from the Home screen.

27 28

Text input ..............................

2

2.1 Using the Onscreen Keyboard

Onscreen Keyboard settings
Touch the Application tab from the Home screen, select Settings\

Language & input, touch the Settings icon
keyboard or Swype. Settings are available for your selection from the

displayed series.

Adjust the Onscreen Keyboard orientation

Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can also adjust it by changing the settings (on the
application list, touch Settings\Display\Orientation).

2.1.1 Android keyboard

Touch to enter text or numbers.

on the right of Android

2.1.2 Swype keyboard

Swype lets you enter a word with one continuous motion: just drag your
finger over the letters in the word.

• Place your finger on the key with the first letter of the word and drag

your finger to each subsequent letter without lifting your finger off the
screen.

• Continue until you have finished the word. Lift your finger after the last

letter.

• If Swype cannot clearly determine your word, the word choice window

opens. Select an alternative word from the list.

Touch to enter text or numbers.

Touch and hold to enter multiple choices
mode.

Touch to switch "abc/Abc/ABC" input mode.

Touch to switch between "abc/Abc" mode; touch
& hold to switch between "abc/ABC" mode.

Touch & hold, then select to enter symbols/
emoticons.

Touch & hold to show input options; when Wi-Fi or data connection is
on, touch to enter voice input.

Touch to switch between symbol and numeric keyboard.

29 30

• Touch to switch back to last chosen word.

• Touch and hold to change input language.

Touch to enter numbers, symbols, etc.

Touch and hold for Swype settings and additional information.

2.2 Text editing

You can edit the text you have entered.

• Touch and hold or double-tap within the text you would like to edit.

• Drag the tabs to change the highlighted selection.

• The following options will appear: Select all

and Paste .

• Touch the icon

You can also insert new text

• Touch where you want to type, or touch and hold a blank space, the

cursor will blink and the tabs will show. Drag the tab to move the
cursor.

• If you have selected any text, touch the tab to show PASTE icon which

allows you to paste any text you have previously copied.

to confirm.

, Cut , Copy

Phone call, Call log

3

and Contacts .........................

3.1 Phone ...........................................................

3.1.1 Placing a call

The user can easily start a call using the Phone application. Touch the
Application tab from the Home screen and select Phone.

People

Call log

Touch and hold to access voicemail.

Slide to access Call log and People.

Touch to get more options.

Touch to hide/show the dial pad.

Enter the desired number from the keyboard directly or select a contact
from People or Call log by sliding or touching tabs, then touch Call to
place the call.

The number you entered can be saved to People by touching
selecting Add to Contacts.

If you make a mistake, you can delete the incorrect digits by touching

To hang up a call, touch End.

and

.

31 32

International call

To dial an international call, touch and hold
the international country prefix followed by the full phone number and
finally touch Call.

Emergency call

If your phone has network coverage, dial the emergency number and
touch Call to make an emergency call. This works even without a SIM
card and without typing the PIN code.

to enter "+", then enter

3.1.2 Answering or rejecting a call

When you receive a call, touch .

• Slide to the right to answer;

• Slide to the left to reject;

• Slide upwards to reject the call by sending a preset message.

To mute the ringtone volume of an incoming call, press the Volume
up/down key or turn the phone face down if Turn over to mute is
activated. To activate, touch Settings\Gestures\Turn over to mute.

3.1.3 Calling your voicemail

Your voicemail is provided by your network to avoid missing calls. It works
like an answering machine that you can consult at any time.

To access your voicemail, touch and hold

To set your voicemail number, touch

Voicemail.

If you receive a voicemail, a voicemail icon
Open the Notification panel and touch New Voicemail to hear it.

on the Phone tab.

and touch Settings\Voice call\

appears on the Status bar.

3.1.4 During a call

To adjust the volume during a call, press the Volume up/down key.

33 34

Touch to hold the current call. Touch this icon again to
retrieve the call.

Touch to display Dialpad.

Touch to end the current call.

Touch to mute the current call. Touch this icon again to
unmute the call.

Touch to activate the speaker during the current call. Touch
this icon again to deactivate the speaker.

and select Start recording to record.

Touch

To avoid accidental touchscreen operations during a call, the
screen will be locked automatically when you put the cellphone
close to your ear; it will be unlocked when the cellphone is taken
away from your ear.

3.1.5 Managing multiple calls

With this phone you can handle multiple calls at the same time.

Swap calls

When you accept two calls, you can now switch between two lines. The
current call is put on hold and you can join the other call.

Conference calls

To set up a conference call:

• Place a call to the first participant of the conference call.

• Touch

and select Add call.

• Enter the phone number of the person you want to add to the conference

and touch Call. You can also add participants from Contacts or Call
log.

• Touch the

• During a conference call, touch

privately to one of the participants. Touch End to drop the participant
from the conference, touch to talk privately to the participant and
hold the other participants.

• Touch End to end the conference call and disconnect all callers.

(1)

icon to start a conference call.

to drop a participant or to talk

(1)

Depending on your network operator.

35 36

3.1.6 Call settings

Touch and select Settings from the Dial screen. The following options
are available:

Voice call

• Voicemail

Voicemail service Opens a dialog box where you can select your

carrier’s voicemail service or another service.

Voicemail settings If you are using your carrier’s voicemail service,

this opens a dialog box where you can enter the
phone number to use for listening to and managing
your voicemail. You can enter a comma (,) to
insert a pause into the number — for example, to
add a password after the phone number.

• IP prefix number

Enter prefix number Edit prefix number for IP dialling.

• Call forwarding

Touch to configure how your calls are forwarded when you are busy,
unanswered or unreachable.

• Call barring

You can activate or deactivate call barring for outgoing and incoming calls.
The various options are:

All outgoing calls All outgoing calls are barred.

International
outgoing call

International
except home

All incoming calls All incoming calls are barred.

Incoming calls in
roaming

Cancel all Deactivate all call barring.

Change barring
password

• Additional settings

Caller ID Opens a dialog box where you can set whether

Call waiting Mark the check box to notify you of a new

Call waiting status Check the call waiting status of your phone.

Outgoing international calls are barred.

Outgoing international calls except those to your
country of subscription are barred.

Incoming calls are barred when you are abroad.

Change the original barring password for activating
call barring.

your phone number is displayed when making
calls.

incoming call.

37 38

Video call

• Local video

replacement

• Display

peer video

• Peer video

replacement

• Enable back

camera

(1)

You can choose a picture from your collection to
display when the Camera is unreachable.

Mark the checkbox to display a picture for replacing
peer-to-peer when it is unavailable.

Set a picture to display when peer video is
unavailable.

Mark the checkbox to turn on back camera during
a video call.

• Bigger peer video Touch to enable a bigger view of peer.

• Auto drop back Mark the checkbox to enable automatic switch

back to voice call.

• Outgoing

Touch to display local video when you place a call.

video call

• Incoming

video call

Touch to display local video when receiving an
incoming call.

• Call forwarding Touch to configure how your calls are forwarded

when you are busy, unanswered or unreachable.

• Call barring Enter to cancel types of video calls and change

barring password.

• Additional

settings

Caller ID Open a dialog box where you can

set whether your phone number is
displayed when making calls.

Call waiting Mark the check box to notify you

of a new incoming call.

Call waiting
status

Touch to view call waiting status
if available.

Other settings

• Fixed Dialing Numbers

Fixed Dialing Number (FDN) is a SIM service mode, where outgoing calls
are restricted to a set of phone numbers. These numbers are added to the
FDN list. The most common practical application of FDN is for parents to
restrict the phone numbers which their children can dial.

For security reasons, you’ll be prompted to enable FDN by entering SIM
PIN2 which is usually acquired from your service provider or SIM maker.

• Minute reminder

Mark the checkbox to enable minute reminder at 50s of every minute
during a call.

• Vibrate reminder

Mark the checkbox to enable vibration when the call is connected.

• Turn over to mute

Mark the checkbox to mute incoming calls by turning the phone over.

• Power key ends call

Mark the checkbox to end a call by pressing the Power key.

• Dual mic noise reduction

Mark the checkbox to turn on dual mic for noise reduction.

• Quick responses

Touch to edit quick responses which will be used when you reject a call
with messages.

(1)

Depending on your model.

39 40

• TTY mode

TTY mode can be used by people who are deaf, have poor hearing or
speech impairments.

After connecting the cell phone and a TTY machine, the machine will
convert incoming speech to text for the person using the TTY and
converts outgoing text from the TTY machine to spoken voice for the
person on the other end of the conversation.

• International dialling assist

Mark the checkbox to activate.

3.2 Call log

You can access your call memory by touching from the Dial screen.
Touch on the right side of the contact/number to place a call directly.
There are three kinds of calls in Call log:

Incoming calls (blue arrows)

Outgoing calls (green arrows)

Missed calls (red arrows)

Touch a contact or number to view information or further operations.

You can view detailed information of a call, launch a new call or send
messages to a contact or number, or add numbers to People (only
available for unsaved phone numbers), etc.

Touch the photo

To clear the entire call memory, touch

to open the Quick Contact panel.

and Delete.

3.3 People ..........................................................

The People app enables quick and easy access to the people you want
to reach.

You can view and create contacts on your phone and synchronize these
with your Gmail contacts or other applications on the web or on your
phone.

3.3.1 Consult your contacts

To access the People app, touch the Application tab on the Home screen,
then select People.

Touch to view your favorite contacts.

Touch to view your contact groups.

Touch icon to open Quick Contact panel.

Touch to view the contact’s detailed information.

Touch to add a new contact.

Touch to search in People.

41 42

Touch

The following actions are enabled:

• Delete contact Select and delete unwanted contacts.

• Contacts to display Choose contacts to display.

• Import/Export Import or export contacts between phone, SIM

• Accounts Manage the synchronization settings for different

• Settings Access contact display settings.

• Share visible

contacts

to display contacts list option menu.

card, and microSD card, or share contacts.

accounts.

Share contacts with others by sending the
contact's vCard to them via Bluetooth, Email,
SMS, etc.

3.3.2 Managing contact groups

The contact group helps you to improve the organization of your contacts.
You can add, remove and view groups in the Contact group screen.

Touch the
the
have added accounts to your phone, touch the icon to view groups
in accounts.

icon to view local groups. To create a new group, touch

icon , enter the new name and touch DONE to confirm. If you

3.3.3 Adding a contact

Touch the icon in the contact list to create a new contact.

You are required to enter the contact's name and other contact
information. By scrolling up and down the screen, you can move from one
field to another easily.

Touch to save

Touch to select a picture for the contact

Touch to add a new label

Touch to unfold the other predefined labels of
this category

If you want to add more information, touch Add another field to add
a new category.

When finished, touch DONE to save.

To exit without saving, you can touch CANCEL.

Add to/remove from Favourites

To add a contact to favourites, you can touch a contact to view details
then touch

To remove a contact from favourites, touch

Only phone contacts can be added to favourites.

to add the contact to favourites.

on contact details screen.

43 44

3.3.4 Editing your contacts

To edit contact information, touch in the contact details screen, then
touch Edit. When finished, touch DONE.

Change a contact’s default phone number

The default phone number (the number which has priority when making
a call or sending a message) will always be displayed under the contact
name.

To change the default phone number, touch and hold the number you
want to set as the default number from the contact's details screen, then
select Set default. A

This choice is only available when the contact has more than one
number.

Set the ringtone for a contact

On the contact's detail screen, touch to display the list options menu,
touch Set ringtone.

Delete a contact

To delete a contact, touch
(details) screen.

On the contacts list screen, touch
the contact(s) you want to remove and touch to confirm. Touch
Select all and then to delete all contacts.

The contact you have deleted will also be removed from other

applications on the phone or web the next time you synchronize
your phone.

appears after the number.

and touch Delete from the contact

and then Delete contact, select

3.3.5 Communicating with your contacts

From the contacts details screen, you can communicate with your contacts
by making a call or exchanging messages.

To launch a call, touch the

To send a message, touch the

Use Quick contact for Android

Touch a contact’s picture to open Quick Contact for Android, then you
can touch the number or the

The icons available on the Quick Contact panel depend on the information
you have for the contact and the applications/accounts on your phone.

icon on the right side of the number.

icon on the right side of the number.

icon for the way you want to connect.

45 46

3.3.6 Contacts importing, exporting and sharing

This phone enables you to import contacts from a SIM card/microSD card
and export contacts to a microSD card which can then be used to back
up your information.

From the Contacts screen, touch
Import/Export, then choose to import/export contacts from/to SIM
card, Phone, SD card, Phone storage, Accounts, etc.

To import/export a single contact from/to a SIM card, choose an account
and target SIM card(s), select the contact you want to import/export, and

to confirm.

touch

To import/export all contacts from/to a SIM card, choose an account and
target SIM card(s), touch Select all and touch

You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.

Touch a contact you want to share, touch
contact details screen, then select the application to perform this action.

to open the options menu, touch

to confirm.

and Share from the

3.3.7 Displaying contacts

You can configure which group of contacts, for each account, you want
to display in the Contacts list. Touch and then Contacts to display
from the contacts list screen, then you can choose which contacts to
display.

By touching
or Family name, as well as View contact names as Given name first or
Family name first.

and then Settings, you can Sort list by Given name

3.3.8 Joining/Separating contacts

To avoid duplication, you can add any new contact information to existing
contacts in a single action.

Touch the contact which you want to add information to, touch
then Edit, then touch in the edit screen and touch Join.

Then, you will be required to select the contact whose information you
want to join with the first contact. The information from the second
contact is added to the first one, and the second contact will no longer be
displayed in the Contacts list.

To separate contact information, touch the contact whose information
you want to separate, touch
edit screen and touch Separate, touch OK to confirm.

and then Edit, then touch in the

and

3.3.9 Synchronizing contacts in multiple accounts

Contacts, data or other information can be synchronized from multiple
accounts, depending on the applications installed on your phone.

To add an account, touch
then touch Add account.

You are required to select the kind of account you are adding, like Google,
Corporate, etc.

As with other account set-ups, you need to enter detailed information, like
username, password, etc.

You can remove an account and all associated information from the
phone. Open the Settings screen, touch the account you want to delete,
touch

Sync

You can synchronize an account on the Accounts screen. Touch an
account in the list, then touch

and then select Remove account, then confirm.

on the Quick setting bar to get to Settings,

and select Sync now.

47 48

Messaging, Email ..................

4

For saved contacts, touch the photo to open the Quick Contact

panel to communicate with the contact. For unsaved contacts,
touch the photo to add the number to your Contacts.

4.1 Messaging.....................................................

You can create, edit and receive SMS and MMS with this mobile phone.

To access this feature, touch the Application tab from the Home screen,
then select Messaging.

All messages you receive or send out can only be saved in the
phone's memory. To consult messages stored in the SIM card,
touch

messages (SMS)\Manage SIM messages.

4.1.1 Writing a message

On the message list screen, touch the new message icon to write text/
multimedia messages.

from the Messaging screen, then touch Settings\Text

• Touch to view the whole message thread

• Touch & hold message threads to delete

messages or to add shortcut

Touch to create a new message

Touch to search in all messages

Sending a text message

Enter the mobile phone number of the recipient on the Type person's
name or number bar or touch
text message bar to enter the text of the message. When finished, touch

to send the text message.

An SMS of more than 160 characters will be charged as several

SMS. Specific (accented) letters will increase the size of the SMS,
which may cause multiple SMS to be sent to your recipient.

Sending a multimedia message

MMS enables you to send video clips, images, photos, animations, slides
and sounds to other compatible mobiles and e-mail addresses.

An SMS will be converted to MMS automatically when media files (image,
video, audio, slides, etc.) are attached or subject or email addresses are
added.

To send a multimedia message, enter the recipient's phone number in the
Type person's name or number bar, touch the Type text message
bar to enter the text of the message. Touch
touch Add subject to insert a subject, and touch to attach a picture,
video, audio and so on.

When finished, touch

to send the multimedia message.

to add recipients, touch the Type

to open the option menu,

49 50

Attachment options:

• Capture picture Access the Camera to capture a new picture for

• Pictures Access the Gallery or File manager to select a

• Capture video Access the Camcorder to record a new video for

• Videos Access the Gallery or File manager to select a

• Record Audio Enter the voice message recorder to record a

• Audio Access a selection of audio files for attaching.

• Contact Access People to select one or more contact(s)

• Calendar Access Calendar to select one or more event(s)

• Slideshow Enter the Edit slide show screen, touch Add

attaching.

picture as an attachment.

attaching.

video as an attachment.

voice message for attaching.

to attach.

to attach.

slide to create a new slide, and touch a currently
existing slide to edit it (see following picture).
Touch
duration setting, adding music, etc.

to get more options, like slide

Touch to go to previous or next slide
Touch to preview current slide

Touch to edit the title of this slide

4.1.2 Manage messages

When a new message comes, a icon will appear on the status bar
as notification. Drag down the status bar to open the Notification panel,
touch the new message to open it. You can also access Messaging and
touch the new message to open it.

Messages are displayed in conversational order.

To reply to a message, touch the current message to enter the message­composing screen, enter the text, then touch

Touch and hold a message in the message details screen, the following
options will be available:

• Copy This option is only available for SMS. Touch to copy

current message content and paste it to the Type
text message bar of the new message you are
going to compose.

• Forward Touch to forward the message to another recipient.

• Delete message Delete the current message.

.

51 52

• Lock/Unlock

message

• View message

details

• Select text Touch to select the message text to copy, cut,

• Save message to

SIM card

Touch to lock/unlock the message so it can't/can
be deleted if you reach the maximum number of
stored messages.

Touch to view details of the message.

add to dictionary, etc.

This option displays when the message is an SMS.
Touch to save the message to the SIM card.

4.1.3 Adjust message settings

In the message list screen, touch and select Settings.

Text messages (SMS)

• Delivery reports Mark to request a delivery report for each text

• Manage SIM

messages

• Edit quick text Touch to add or edit message templates.

• SMS service center Touch to view or edit your SMS service center.

• Validity period Touch to select your SMS validity period.

• SMS storage

location

• Alphabet

management

message you send.

Touch to view or manage messages on your SIM
card.

Touch to choose either phone or SIM card for
storing messages.

Touch to select auto format, super compact or
precise mode.

Multimedia messages (MMS)

• Group messaging Mark the checkbox to send a single message to

• Delivery reports Select to request a delivery report for each

• Read reports Select to request a report on whether each recipient

• Send read report Select to request a report on whether the multimedia

• Auto-retrieve Select to download full MMS message (including

• Roaming auto-

retrieve

• Creation mode Touch to set MMS creation mode when composing

• Maximum

message size

• Priority Set MMS priority as High, Normal or Low.

Notifications

• Notifications Select to display message notifications in status bar.

• Mute Select to mute phone notifications when receiving

• Select ringtone Touch to select a ringtone as a new message

multiple recipients.

multimedia message you send.

has read a multimedia message sent by you.

message has been sent out.

message body and attachment) automatically to
your phone. Otherwise, download only the MMS
message header.

Select to download full MMS message (including
message body and attachment) automatically
when roaming. Otherwise, download only the
MMS message header to avoid extra charges.

messages.

Select to edit the message size limit, but it should
not be more than 300KB.

a new message.

notification tone.

53 54

General

• Chat wallpaper Touch to select wallpaper for message

• Message font size Touch to select message font size.

• Show email

address

• Delete old

messages

• Text message limit Touch to set the number of text messages to be

• Multimedia

message limit

• Cell Broadcast Touch to enable or disable cell broadcast service

• Enable WAP

PUSH

• Auto-Launch SL Mark the checkbox to automatically launch Service

• Enable userpin

message

background.

Mark the checkbox to include email address in
contact results.

Select to delete old messages when maximum
number of stored messages is reached.

saved per conversation.

Touch to set the number of multimedia messages
to be saved per conversation.

or to choose its language and channel.

Mark the checkbox to enable reception of WAP
PUSH.

Loading (SL) messages when received.

Mark the checkbox to enable reception of
omacp messages with userpin.

4.2 Gmail/Email

The first time you set up your phone, you can select to use an existing
Gmail account or to create a new Email account.

4.2.1 Gmail ...................................................................

As Google's web-based email service, Gmail is configured when you first
set up your phone. Gmail on your phone can be automatically synchronized
with your Gmail account on the web. Unlike other kinds of email account,
each message and its replies in Gmail are grouped in your inbox as a single
conversation; all emails are organized by labels instead of folders.

To access Gmail

From the Home screen, touch the Application tab to enter the applications
list, then touch Gmail.

Gmail displays messages and conversations from one single Gmail account
at a time, if you own more than one account, you can add an account by
touching
ADD ACCOUNT. When finished, you can switch to another by touching
the account name from Inbox screen, then select the account you want to
view.

To create and send emails

• Touch the

• Enter recipient(s)’s email address in the To field, and if necessary,

touch
the message.

and selecting Settings from the Inbox screen, then touch

icon from the Inbox screen.

and select Add Cc/Bcc to add a copy or a blind copy to

55 56

• Enter the subject and the content of the message.

• Touch

attachment.

• Finally, touch the

• If you do not want to send the mail out right away, you can touch

and then Save draft or touch the Back key to save a copy. To view the
draft, touch your account name to display all labels, then select Drafts.

If you do not want to send or save the mail, you can touch
touch Discard.

To add a signature to emails, touch
inbox screen, choose an account, then touch Signature.

To receive and read your emails

When a new email arrives, you will be notified by a ringtone or vibration,
and a

Touch and drag down the Status bar to display the Notification panel,
touch the new email to view it. Or you can also access the Gmail Inbox
label and touch the new mail to read it.

You can search for an email by sender, recipient, subject, etc.

• Touch the

• Enter the keyword you want to search for in the search box and touch

and select Attach picture or Attach video to add an

icon to send.

and then

and then touch Settings from the

icon will appear on the Status bar.

icon from the Inbox screen.

on the software keyboard.

To reply or forward emails

• Reply

• Reply all

• Forward

Managing Gmails by Labels

To conveniently manage conversations and messages, you can organize
them using a Label.

To label a conversation when reading a conversation’s messages, touch

and Change labels to assign a label for the conversation.

To view conversations by labels when viewing your inbox or another
conversation list, touch your account name, then touch a label to view a
list of conversations within that label.

To manage labels, touch
select Manage labels.

When viewing an email, touch
mail.

Touch

and select Reply all to send messages to

all people in a mail loop.

Touch

and select Forward to forward the

received mail to other people.

and Settings, then touch your account and

to reply to this

57 58

Touch and hold a message thread to display the following
options:

•

•

/

•

•

• Add star/

Remove star

• Mark as (not)

important

• Mute To mute the entire conversation. When muted,

• Report spam To report the email message/conversation as spam.

• Report phishing To report the email message/conversation as phishing.

Touch to archive the email message.

Touch to delete the email message.

Touch to mark an email message as read or unread.

Touch to open further options, like: Move to, Add

star, Mark as (not) important, Mute, Report
spam, etc.

To assign a star or remove the star from the
conversation. You can also add or delete a star mark
by touching the
message thread.

To Mark the email as important or not important.

new mails related to this conversation will not be
displayed in the Inbox, but archived.

or icons at the end of each

Gmail settings

To manage Gmail settings, touch
screen.

General settings

• Archive & delete

actions

• Swipe to archive Mark the checkbox to swipe left or right

• Sender image Mark the checkbox to display a photo

• Reply all Touch to mark the checkbox to make this

• Auto-fit messages Touch to mark the checkbox to zoom in/

• Auto-advance Touch to select which screen to show after

• Message actions Touch to show/hide message actions.

• Confirm before

deleting

• Confirm before

archiving

• Confirm before

sending

Touch to Show archive only, Show delete
only or to Show archive & delete.

when viewing conversations.

beside the name in the conversation list.

default response to messages.

out of the message, so that it fits on the
screen.

you delete or archive a conversation.

Mark the checkbox to request confirmation
before deleting emails.

Mark the checkbox to request confirmation
before archiving emails.

Mark the checkbox to request confirmation
before sending emails.

and select Settings in the Inbox

59 60

After touching an account, the following settings will appear:

• Inbox type To set this box as the default one.

• Notifications Mark the checkbox to activate notification when

• Inbox sound &

vibrate

• Signature To add a signature text to the end of each mail

• Sync Gmail Mark the checkbox to turn on/off Gmail sync.

• Days of mail to

sync

• Manage labels Touch to open the Label screen, where you can

• Download

attachments

a new email arrives.

Touch to set Ringtone or vibration for Gmail
notifications.

you send.

Touch to set the duration in days for mail sync.

manage synchronization and notifications.

Mark the checkbox to auto download attachments
to recent messages via Wi-Fi.

4.2.2 Email ....................................................................

Besides your Gmail account, you can also set-up external POP3 or IMAP
email accounts in your phone.

To access this function, touch the Application tab from the Home screen,
then select Email.

An email wizard will guide you through the steps to set-up an email
account.

• Enter the email address and password of the account you want to set-up.

• Touch Next. If the account you entered is not provided by your service

provider in the phone, you will be prompted to go to the email account
settings screen to enter settings manually. Alternatively, you can touch
Manual setup to directly enter the incoming and outgoing settings for
the email account you are setting up.

• Enter the account name and display name in outgoing emails.

• To add another email account, you can touch

finally touch ADD ACCOUNT on the right of the title to create the
account.

To create and send emails

• Touch the

• Enter recipient(s) email address(es) in the To field.

• If necessary, touch

carbon copy to the message.

• Enter the subject and the content of the message.

• Touch

• Finally, touch

• If you do not want to send the mail right away, you can touch

Save draft or touch the Back key to save a copy.

icon from the Inbox screen.

and touch Add Cc/Bcc to add a copy or a blind

, touch Attach file to add an attachment.

to send.

and Settings, and

and

4.3 Hangouts .....................................................

Google's instant messaging service, Hangouts, lets you communicate with
your friends whenever they are connected to this service.

To access this feature and sign in, touch the Application tab from the
Home screen, then touch Hangouts. All friends added by using Hangouts
from the web or phone will be displayed in your friends list.

To sign out, touch
touch Settings\Sign out.

from the Friends list screen to display options, then

61 62

4.3.1 Chatting with your friends

To start a chat, touch the name of a friend in your Friends list, then type
your message and finally touch .

You can invite other friends to join in a group chat by touching
selecting Add people on the group chat screen and then selecting the
friend you want to add.

and

4.3.2 To add a new friend

From the Friends list, touch the icon to add a new friend. Type the
name, email or number of the friend you want to add, and then touch
Message or Video call to start a chat.

A notification of this invitation will be received by the friend. By touching
the invitation, the friend can select Decline or Reply in response.

4.3.3 To manage your friends

Besides adding new friends to your friends list, touching and selecting
People & options from your Chatting screen will make the following
actions available:

•

• Rename Touch to rename Hangout.

• Notifications Mark the checkbox to be notified of new

• Leave Touch to leave Hangout.

•

Touch to add the person to a new group
Hangout.

messages.

Touch to add the person to your circles of Friends,

Family, Acquaintances or Following.

4.3.4 Settings

A series of settings are available for your selection by touching from
the Friends list screen.

• Hangout requests Touch to view hangout requests which you

• Snooze

notifications

• Archived

Hangouts

• Settings Touch to open further personal settings for every

• Send feedback Touch to send your feedback for Hangouts.

• Help Touch to view Hangouts help through your

receive when someone sends you a message or
invites you to a video call for the first time.

Touch and select how long you'd like to go
without receiving Hangouts notifications. This
setting will temporarily disable notifications about
new messages and video calls.

Touch to display all archived Hangouts that have
been prevented from displaying in the Hangouts
list. To unarchive a Hangout, touch and hold it
until

appears, touch and select Unarchive.

Hangout you have.

selected app.

63 64

Calendar & Alarm clock &

5

Calculator ..............................

5.1 Calendar ......................................................

Use the Calendar to keep track of important meetings, appointments,
etc.

To access this function, touch the Application tab from the Home screen,
then touch Calendar.

5.1.1 Multimode view

You can display the Calendar in daily, weekly, monthly, or agenda view.

To change your Calendar view, touch the date title to open a drop-down
menu for your options. Touch the

Agenda view

icon to return to Today's view.

Day view

Week view

Month view

5.1.2 To create new events

You can add new events from any Calendar view.

• Touch the

• Fill in all required information for this new event. If it is a whole-day

event, you can select All day.

• When finished, touch DONE from the top of the screen.

To quickly create an event from the Day or Week view screen, touch and
hold an empty spot or an event to open the Option menu, then touch
New event to edit the event details. Or you can also touch an empty spot
until it turns orange, then tap again to enter a new event editing screen.

icon to access the new event edit screen.

5.1.3 To delete or edit an event

To share, delete or edit an event, touch the event to enter the details
screen, touch the icon to share the event with other people by
Bluetooth, Email and messaging, etc., touch the icon to edit the event,
and touch the

icon to delete.

5.1.4 Event reminder

If a reminder is set for an event, the upcoming event icon will appear on
the Status bar as a notification when the reminder time arrives.

Touch and drag down the status bar to open the Notification panel, touch
the event name to view the Calendar notification list.

Touch Snooze to turn off all event reminders for 5 minutes.

Touch the Back key to keep the reminders pending in the status bar and
the Notification panel.

In Agenda, Day or Week
view touch an event to view
its details.

Touch a day in Month
view to open that day's
events.

65 66

Important options activated by touching
screen:

• Refresh To refresh the calendar.

• Search To search in the calendar.

• Calendars to display To show or hide, remove or add calendars.

• Clear events To clear events in the calendar.

• Go to Select to go to a specific date.

• Settings To set a series of Calendar settings.

from the Calendar main

5.2 Time .............................................................

Your mobile phone has a built-in clock.

To access this function, touch the Application tab from the Home screen,
then touch Time.

Touch

5.2.1 To set an alarm

From the Time screen, touch to enter the Alarm screen, touch
to add a new alarm. The following options will appear:

• Label Touch to set a name for the alarm.

• Repeat Touch to select days when you want the alarm

• Volume Slide to adjust the volume for the alarm

• Vibrate Select to activate vibration.

• Ringtone Touch to select a ringtone for the alarm.

• Time Scroll up or down to select the time for your

Alarm to add or set an alarm.

to work.

ringtone.

alarm.

When finished, touch OK to confirm.

Touch and hold an already existing alarm and touch Delete alarm to
delete the selected alarm.

5.2.2 To adjust alarm settings

Touch the Menu icon from the Alarm screen. The following options
will be available:

• Alarm in silent

mode

• Snooze duration Touch to set temporary turn off time of an

• Auto-silence Touch to set the duration of alarms.

• Volume buttons Touch to set side Volume up/down key

• Turn over to

activate

Select to play alarm with sound or vibration even
when the phone is in Silent mode.

alarm.

behaviors when alarm sounds: None, Snooze
or Dismiss.

Touch Turn over to activate to choose
the status Snooze or Dismiss. Touch the

switch to turn on/off snoozing or

to dismiss the alarm by turning over the phone.

5.3 Calculator ....................................................

With the Calculator, you can solve many mathematical problems.

To access this function, touch the Application tab from the Home screen,
then touch Calculator.

There are two panels available: Basic calculator and Scientific calculator.

67 68

To switch between panels, touch
option menu and touch Scientific calculator; or under auto rotation
mode, rotate screen automatically to switch between Basic calculator and
Scientific calculator.

Basic calculator Scientific calculator

Enter a number and the arithmetic operation to be performed, enter the
second number, then touch "=" to display the result. Touch
digits one by one, touch to delete all at one time.

When some numbers or operations have been entered, touch and hold
the enter bar to open a menu offering further operations:

• Cut To cut selected text.

• Copy To copy selected text.

(1)

• Paste

To paste what you have previously copied to the

entering bar.

from the basic panel to open the

to delete

(1)

Getting connected ................

6

To connect to the internet with this phone, you can use GPRS/EDGE/3G
/4G networks or Wi-Fi, whichever is most convenient.

6.1 Connecting to the Internet

6.1.1 GPRS/EDGE/3G/4G

You can touch on the Quick setting bar to connect to the network.

To check the network connection you are using, touch the Application tab
on the Home screen, then touch Settings\More...\Mobile networks\

Access Point Names or Network operators.

To create a new access point

A new GPRS/EDGE/3G/4G network connection can be added to your
phone with the following steps:

• Touch

• Touch More...\Mobile networks\Access Point Names

• Then touch

• Enter the required APN information.

• When finished, touch

on the Quick setting bar to get to Settings.

and select New APN.

and Save.

(1)

Option will not appear unless copy or cut operation has been made.

69 70

To activate/deactivate Data roaming

When roaming, you can decide to connect/disconnect a data service.

• Touch

• Touch SIM management\Roaming\Data roaming.

• Mark/Unmark the checkbox to activate or deactivate data roaming.

• When Data roaming is deactivated, you can still perform data exchange

with a Wi-Fi connection (refer to "6.1.2 Wi-Fi").

on the Quick setting bar to get to Settings.

6.1.2 Wi-Fi

Using Wi-Fi, you can connect to the Internet when your phone is within
range of a wireless network. Wi-Fi can be used on your phone even
without a SIM card inserted.

To turn Wi-Fi on and connect to a wireless network

• Touch

• Touch the

• Touch Wi-Fi, the detailed information of detected Wi-Fi networks is

displayed in the Wi-Fi networks section.

• Touch a Wi-Fi network to connect with. If the network you selected

is secured, you are required to enter a password or other credentials
(contact your network operator for details). When finished, touch
Connect.

on the Quick setting bar to get to Settings.

switch beside Wi-Fi to turn on/off Wi-Fi.

To activate notification when a new network is detected

When Wi-Fi is on and the network notification is activated, the Wi-Fi icon
will appear on the status bar whenever the phone detects an available
wireless network within range. The following steps activate the notification
function when Wi-Fi is on:

• Touch

• Touch Wi-Fi, then

• Mark/Unmark the Network notification checkbox to activate/

deactivate this function.

To add a Wi-Fi network

When Wi-Fi is on, you may add new Wi-Fi networks according to your
preference.

• Touch

• Touch Wi-Fi, and then touch

• Enter the name of the network and any required network information.

• Touch Save.

When successfully connected, your phone will be connected automatically
the next time you are within range of this network.

To forget a Wi-Fi network

The following steps prevent automatic connections to networks which you
no longer wish to use.

• Turn on Wi-Fi, if it’s not already on.

• In the Wi-Fi screen, touch and hold the name of the saved network.

• Touch Forget network in the dialog that opens.

on the Quick setting bar to get to Settings.

and select Advanced.

on the Quick setting bar to get to Settings.

.

71 72

6.2 Browser........................................................

Using the Browser, you can enjoy surfing the Web.

To access this function, touch the Application tab from the Home screen,
then touch Browser.

To go to a web page

On the Browser screen, touch the URL bar at the top and enter the
address of the web page.

Touch to delete all contents

Touch to search and go to this address

Touch to go the suggested website

Touch to input the suggested address

The URL bar will hide after a few seconds. To show the URL bar, you
can touch and slide down the screen.

To set a homepage

• Touch

Settings\General\Set home page.

• Choose a page or most visited website as your homepage.

• If you choose Other, enter the URL of the website you want to set as

your homepage, touch OK to confirm.

from the Browser screen to display the option menu, touch

6.2.1 Viewing web pages

After opening a website, you can navigate on web pages by sliding your
finger on the screen in any direction to locate the information you want
to view.

To zoom in/out of a web page

Pinch/Spread your finger on the screen to zoom out/in of the web page.

To quickly zoom into a section of a web page, double-tap on the section
you want to view. To return to normal zoom level, double-tap again.

To find text on a web page

• Touch

• Enter the text or phrase you want to find.

• The first word with matching characters will be highlighted on the

screen, and subsequent matches will be boxed.

• Touch the up or down arrow to switch to the previous or next matching

items.

• When finished, you can touch

bar.

Further operations for the text on a web page

You can copy, share or search the text on a web page:

• Touch and hold the text to highlight it.

• Move the two selecting tabs in orange to locate the text. Or touch

SELECT ALL to select all words in this web page.

• Touch

Web Search.

• When finished, touch

from the web page screen, then touch Find on page.

or the Back key to close the search

to show further options, including Copy, Share, Find and

or the Back key to deactivate the mode.

73 74

To open new window/switch between windows

Multiple windows can be opened at the same time for your convenience.

• Touch

• Slide up and down to view all windows, touch one to view it.

• Touch

• Touch

any trace.

• To close a window, touch

it sideways.

Other options:

• Refresh To refresh the current page.

• Stop To stop opening the current page.

• Home page To get back to the homepage you set.

• Save to

bookmarks

• Close To close all tabs and exit.

• Save for offline

reading

• Share page To share the current page with your friends via various

• Find on page To input contents you want to find on the current

• Request

desktop site

• Bookmarks/

History

• Settings To access a series of Browser settings.

• Version To see the version of your browser.

to open all windows' thumbnails.

to open a new window.

and select New incognito tab to open a window without

on the window you want to close or slide

To add the current website page as a bookmark.

To save the web page for offline reading. You can find
it by touching
HISTORY\SAVED PAGES.

ways, like Message, Email, Bluetooth, etc.

page.
To enable/disable computer versions of websites.

To see your bookmarks and browsing history.

and then touching BOOKMARKS\

6.2.2 Manage links, history, downloads

To manage a link, phone number or address displayed on a web
page

• Link Touch the link to open the web page.

Touch and hold the link to open options for further
operation, like opening in new window, saving link,
copying link URL, etc.

• Phone number Touch to call the phone number.

• Address Touch to open Google Maps and locate the address.

To view Browser history

• Touch

• Touch Bookmarks/History.

• Touch the HISTORY tab to view browser history.

• Touch SAVED PAGES to view the pages you saved.

To download a web application/view your downloads

Before downloading a web application, you need to enable your phone to
install web applications (touch the Application tab from the Home screen,
touch Settings\Security, mark checkbox of Unknown sources, finally
touch OK to confirm).

To download an item, touch the item or the link you want to download.

To cancel a download, touch the downloaded item from the Notification
panel, touch and hold the item to be deleted, and touch

To view items you have downloaded, touch the Application tab, then
touch DOWNLOADED.

from the Browser screen.

to confirm.

75 76

Manage bookmarks

To bookmark a web page

• Open the web page you want to bookmark.

• Touch

screen, touch the star beside the URL.

• Enter the name and the location if needed and touch OK to confirm.

To open a bookmark

• Touch

enter the Bookmarks screen.

• Touch the bookmark you want to open.

• You can also touch and hold to display the options screen, then touch

Open or Open in new window.

Touch and hold a bookmark in the bookmark list to view
additional options:

• Edit bookmark Touch to edit information of the bookmark.

• Add shortcut to

Home

• Share link To share the bookmark.

• Copy link URL To copy the bookmark link.

• Delete bookmark Touch to delete the bookmark.

• Set as homepage To set this page as the homepage.

and touch Save to bookmarks, or from the History

and touch Bookmarks/History, or touch the icon to

To add a bookmark shortcut to the Home
screen.

6.2.3 Settings

A series of settings are available for your adjustment. To access the
Browser settings, touch from the Browser screen, and touch

Settings.

General

• Set home page Touch to set your homepage.

• Form auto-fill Mark the checkbox to fill out web forms with a

• Auto-fill text Touch to set up text to auto-fill in web forms.

Privacy & security

• Clear cache Touch to clear locally cached content and

• Clear history Touch to clear the browser history.

• Show security

warnings

• Accept cookies Mark to allow sites to save and read cookie data.

• Clear all cookie

data

• Remember form

data

• Clear form data Touch to clear all saved form data.

• Enable location Mark to allow sites to request access to your

• Clear location

access

single touch.

databases.

Mark to show a warning if there is a problem with
a site’s security.

Touch to clear all browser cookies.

Mark to remember data in forms for later use.

location.

Touch to clear location access for all websites.

77 78

• Remember

passwords

• Clear passwords Touch to clear all saved passwords.

• Enable notificationsTouch to select notification type.

• Clear notification Touch to clear notification access to all websites.

Accessibility

• Force enable zoom Mark to control a website's zoom as you prefer.

• Text scaling Slide to change the size of the text display.

• Zoom on double-

tap

• Minimum font size Slide to change the minimum font size.

• Font Touch to select fonts.

• Inverted rendering Mark to display pages in invert color.

• Contrast Slide to change pages' contrast. It is grey, unless

Advanced

• Set search engine Touch to select a search engine.

• Open in

background

• Enable JavaScript Mark to enable JavaScript.

• Multiple tabs per

app

Mark to save usernames and passwords for
websites.

Slide to change the magnification level when
double-tapping the page.

you mark Inverted rendering.

Mark to open new windows behind the current
one.

Mark to allow one app to use multiple tabs.

• Enable plug-ins Touch to enable plug-ins.

• Website settings Touch to view advanced settings for individual

• Default zoom Touch to select the magnification level by

• Open pages

in overview

• Auto-fit pages Mark to format web pages to fit the screen.

• Block pop-up

windows

• Text encoding Touch to select the character-encoding standard.

• Reset to default Touch to clear all browser data and to reset all

Bandwidth management

• Search result

preloading

• Web page

preloading

• Load images Mark to display images on web pages.

Labs

• Quick controls Mark to enable quick controls.

• Full screen Mark to use the full screen mode.

websites.

default.

Mark the checkbox to open web pages zoomed
out, in an overview.

Mark the checkbox to prevent pop-up windows.

settings to default.

Touch to enable/disable browser to preload
search results in the background.

Touch to enable/disable browser to preload the
linked web pages in the background.

79 80

6.3 Connecting to Bluetooth devices

(1)

Bluetooth is a short-range wireless communication technology that you
can use to exchange data, or connect to other Bluetooth devices for
various uses.

To access this function, touch

on the Quick setting bar to get to
Settings, then touch Bluetooth. Your device and other available ones
will show on the screen.

To turn on Bluetooth

• Touch

• Touch

on the Quick setting bar to get to Settings.

to activate/deactivate this function.

To make your phone more recognizable, you can change your phone name
which is visible to others.

• Touch

on the Quick setting bar to get to Settings.

• Touch Bluetooth.

• Touch

and select Rename phone.

• Enter a name, and touch Rename to confirm.

To make device visible

• Touch

on the Quick setting bar to get to Settings.

• Touch Bluetooth.

• Touch your device to make it visible or invisible.

• Touch

and select Visibility timeout to select the visible time.

To pair/connect your phone with a Bluetooth device

To exchange data with another device, you need to turn Bluetooth on
and pair your phone with the Bluetooth device with which you want to
exchange data.

• Touch

on the Quick setting bar to get to Settings.

• Touch Bluetooth.

• Touch SEARCH FOR DEVICES.

• Touch a Bluetooth device you want to be paired with in the list.

• A dialog will popup, touch Pair to confirm.

• If the pairing is successful, your phone will connect with the device.

To disconnect/unpair from a Bluetooth device

• Touch the Settings icon

beside the device you want to unpair.

• Touch Unpair to confirm.

6.4 Connecting to a computer

With the USB cable, you can transfer media files and other files between
micro SD card/internal storage and a computer.

Before using MTP or PTP, first mark USB debugging.

• To access this function, touch Settings\About phone, then touch

Build number 7 times. Then touch Settings\Developer options\
USB debugging.

(1)

You are recommended to use ALCATEL ONETOUCH Bluetooth headsets,

which have been tested and proved compatible with your phone. You can go
to www.alcatelonetouch.com for more information about the ALCATEL ONE
TOUCH Bluetooth headset.

81 82

To connect/disconnect your phone to/from the computer:

• Use the USB cable that came with your phone to connect the phone to

a USB port on your computer. You will receive a notification that the
USB is connected.

• If you use mass storage, open the Notification panel and touch USB

connected, then touch Mount in the dialog that opens to confirm that
you want to transfer files.

• If you use MTP or PTP, your phone will be automatically connected.

To disconnect (from mass storage):

• Unmount the microSD card on your computer.

• Open the Notification panel and touch Turn off.

For Windows XP or lower operating systems, you should
download and install Windows Media Player 11 on your computer
from the following link: http://windows.microsoft.com/en-CA/
windows/download-windows-media-player.

To locate the data you have transferred or downloaded to the
internal storage:

• Touch the Application tab from the Home screen to open the

applications list.

• Touch File Manager.

All data you have downloaded is stored in File Manager, where you can
view media files (videos, photos, music and others), rename files, install
applications on your phone, etc.

To format a microSD card

• Touch

• Touch Storage.

• Touch Format SD card, a popup message appears to warn you that

formatting the microSD card will erase its contents.

• Touch

on the Quick setting bar to get to Settings.

to confirm.

6.5 Sharing your phone's mobile data connection

You can share your phone's mobile data connection with a single
computer via a USB cable (USB tethering) or with up to eight devices at
once by turning your phone into a portable Wi-Fi hotspot.

The functions below may incur additional network charges from
your network operator. Extra fees may also be charged in roaming
areas.

To share your phone's data connection via USB

Use the USB cable that came along with your phone to connect the phone
to a USB port on your computer.

• Drag down the Notification panel and touch

to access Settings.

• Touch More...\Tethering & portable hotspot.

• Mark\unmark the checkbox of USB tethering to activate/deactivate

this function.

To share your phone's data connection as a portable Wi-Fi
hotspot

• Drag down the Notification panel and touch

to access Settings.

• Touch More...\Tethering & portable hotspot.

• Touch the switch

this function.

beside Wi-Fi hotspot to activate/deactivate

then the Settings icon

then the Settings icon

83 84

To rename or secure your portable hotspot

When Portable Wi-Fi hotspot is activated, you can change the name of
your phone's Wi-Fi network (SSID) and secure its Wi-Fi network.

• Drag down the Notification panel and touch

to access Settings. Drag down the Notification panel and touch then

the Settings icon to access Settings.

• Touch More...\Tethering & portable hotspot\Wi-Fi hotspot.

• Touch Set up Wi-Fi hotspot to change the network SSID or set your

network security.

• Touch Save.

then the Settings icon

6.6 Connecting to virtual private networks

Virtual private networks (VPNs) allow you to connect to the resources
inside a secured local network from outside that network. VPNs are
commonly deployed by corporations, schools, and other institutions so
that their users can access local network resources when not inside that
network, or when connected to a wireless network.

To add a VPN

• Touch

• Touch More...\VPN settings and then touch

• In the screen that opens, follow the instructions from your network

administrator to configure each component of the VPN settings.

• Touch Save.

The VPN is added to the list on the VPN settings screen.

on the Quick setting bar to get to Settings.

.

Before adding a VPN, you should set a lock screen pattern, PIN
code or password for your phone.

To connect/disconnect to a VPN

To connect to a VPN:

• Touch on the Quick setting bar to get to Settings.

• Touch More...\VPN settings.

• VPNs you have added are listed; touch the VPN you want to connect

with.

• In the dialog that opens, enter any requested credentials and touch

Connect.

To disconnect:

• Open the Notification panel and touch the resulting notification for VPN

disconnection.

To edit/delete a VPN

To edit a VPN:

• Touch

• Touch More...\VPN settings.

• VPNs you have added are listed; touch & hold the VPN you want to

edit.

• Touch Edit profile.

• After finishing, touch Save.

To delete:

• Touch and hold the VPN you want to delete, in the dialog that opens,

touch Delete profile.

on the Quick setting bar to get to Settings.

85 86

Google Play Store

7

Google Play Store is an online software store, where you can download
and install applications and games to your Android powered phone.

To open Google Play Store:

• Touch the Application tab from the Home screen, then touch Play Store.

• For the first time you access Google Play Store, a screen with terms of

service pops up for your attention, touch Accept to continue.

Touch
for more information on this function.

and then select Help to enter the Google Play Store help page

(1)

........

7.1 Locate the item you want to download

and install

Google Play Store home page provides several ways to find applications. It
showcases applications and games in categorized listings.

Touch the top right corner and select My apps to see all your downloads.

Touch to search in Play Store

Slide left and right to see all categories

Touch a category to browse its contents. You can also select a
subcategory if there is one. Within each category you can select to view
items sorted by Top paid, Top free, Top grossing, etc

7.2 Download and install

To download and install:

• Navigate to the item you want to download, and enter the details screen

from which you can read its description, overall rating or comments,
view developer’s information, etc.

• Touch INSTALL to preview the functions and data the application can

access on your phone if you install it.

• Touch ACCEPT to download.

• The progress of the download will show on the details screen, touch

STOP to stop downloading the item. You can also access this screen
through the Notification panel.

• After download and installation have finished, you will see a notification

icon

on the status bar.

Be especially cautious with applications that have access to many

functions or to a significant amount of your data. Once you accept,
you are responsible for the results of using this item on your
phone.

(1)

Depending on your country and operator.

87 88

To open the application you have downloaded:

• On the Google Play Store Apps screen, touch the top right corner and

select My apps.

• Touch the installed application in the list, then touch OPEN.

To buy an application

(1)

On Google Play Store, some applications are labelled as free, while
some of them are to be paid for before downloading and installing.

• Touch the application you want to buy.

• Touch the price to preview the functions and data the application can

access on your phone if you install it.

• Touch Continue to confirm.

• When making your first purchase, you are required to input your

credit card information and to log into the Google payment and billing
service.

• If your account has multiple credit card accounts, select one to

proceed.

• Select the Terms of service link and read the document. When finished,

touch the Back key.

• Mark the checkbox if you agree with the terms of service.

• Touch Buy now at the bottom of the screen.

When finished, Android downloads the application.

To request a refund

If you are not satisfied with the application, you can ask for a refund within
15 minutes of the purchase. Your credit card will not be charged and the
application will be removed. If you change your mind, you can install the
application again, but you will not be able to request a refund.

• Touch the top right corner and touch My apps from the Google Play

Store Apps screen.

• Touch the application that you want to uninstall and refund.

• Touch REFUND to uninstall the application and receive a refund. If the

button becomes UNINSTALL, your trial period has expired.

• In the survey form, select the answer that best matches your reason,

and touch OK.

7.3 Manage your downloads

After you have downloaded and installed an application, the following
further operations are available for your selection.

View

On the Google Play Store Apps screen, touch the top right corner and
touch My apps.

Uninstall

On the Google Play Store Apps screen, touch the top right corner and
touch My apps. Touch the application you want to uninstall to enter the
details screen, touch UNINSTALL, and finally touch OK to confirm.

Refund

On the Google Play Store Apps screen, touch the top right corner and
touch My apps. Touch the application you want to uninstall for a refund,
touch REFUND, and finally touch OK to confirm.

(1)

Google Paid applications may not be available to users in some countries.

89 90

Update notification

On the Google Play Store Apps screen, touch the top right corner and
touch Settings\Notifications to enable update notification.

Auto update

To auto update all installed applications, touch the top right corner from
the My apps screen, and then touch Settings\Auto-update apps to
enable this function.

To auto update one specific application, touch the top right corner and
mark the checkbox of Auto-update from the app details screen.

Multimedia applications

8

8.1 Camera ........................................................

Your mobile phone is fitted with a Camera for taking photos and shooting
videos.

Before using the Camera, please be sure to open the protective lens cover
to avoid it affecting your picture quality.

Rate and review

Open the details screen for an application, touch the stars
besides Rate & review to award and input comments, touch OK to
confirm.

Flag

You can report an inappropriate application to Google Play Store by
flagging it. Open the details screen for the application, scroll to the bottom
and touch Flag as inappropriate, enter the reason and finally touch
Submit.

91 92

Touch to switch between front/back camera.
Touch to show settings.

Touch to select flash modes.

Touch the screen to set focus. Double-tap or
pinch two or more fingers together or spread
them apart to zoom in/out.

Slide to view pictures or videos you have taken.

Slide to switch between camera and camcorder.

Touch to take a picture.

To take a picture

The screen acts as the viewfinder. First position the object or landscape in
the viewfinder, touch the screen to focus if necessary, touch the
to take the picture which will then be automatically saved.

To shoot a video

First position the object or landscape in the viewfinder, and touch the
icon to start recording. Touch to pause recording, touch again or
press the Back key to save the video.

Further operations when viewing a picture/video you have taken

• Touch the icons below the screen to share and edit the photo or video

you have taken.

• Touch the photo icon to access the Gallery.

icon

8.1.1 Settings in framing mode

Before taking a photo/shooting a video, touch the icon to adjust a
number of settings in framing mode.

Back camera shooting mode

• HDR Touch to activate high-dynamic range.

• Panorama Touch to switch to panorama mode.

• Night Touch to switch to night mode.

• Full screen Touch to turn on/off the full screen view.

• Tap shooting Touch to turn on/off tap shooting function.

• Shutter sound Touch to turn on/off shutter sound.

• Picture size Touch to select picture size.

• Timer Touch to select pause duration before capturing

pictures.

Front camera shooting mode

Switch to front camera, touch
following options will display for you to choose from:

• Expression (4-shot) Touch to turn on expression (4-shot) function:

• Tap shooting Touch to turn on/off tap shooting function.

• Shutter sound Touch to turn on/off shutter sound.

• Timer Touch to turn off or set duration of timer while

Camcorder settings

• Video quality Touch to set Video quality.

once four photos taken, the phone will
automatically synthesize and save them as one
picture.

shooting.

to access camera settings and the

93 94

8.2 Gallery ..........................................................

The Gallery acts as a media player for you to view photos and playback
videos. In addition, a set of further operations to pictures and videos are
available for your choice.

To access this function, touch the Application tab from the Home screen,
then touch Gallery.

Touch to open camera.

Touch to stitch and edit pictures.

Touch to select categories: Albums, Locations,
Times.

Touch the album to view more pictures.

Slide left or right to view more albums.

To view a picture/play a video

Pictures and videos are displayed by albums in the Gallery.

• Touch an album and all pictures or videos will display on the screen.

• Touch the picture/video directly to view or play it.

• Slide left/right to view previous or next pictures/videos.

Working with pictures

You can work with pictures by editing them, sharing them with friends,
setting them as a contact photo or wallpaper, etc.

Touch
you to choose from.

 Touch to go back to the picture display screen.
 Touch to undo the previous modification.
 Touch to redo the previous modification.
 Touch to save the modified picture.

Batch operation

The Gallery provides a multi-select function, so that you can work with
pictures/videos in batches.

Open the main Gallery window or an album, touch
album or Select item to activate batch operation mode (you can also
touch and hold one album/picture), then touch albums/pictures you want
to work on. Touch the
selected ones.

from the full-screen picture view. More options will display for



icon to delete selected ones. Touch to share







and select Select

95 96

8.3 YouTube ......................................................

YouTube is an online video-sharing service where the user can download,
share and view videos. It supports a streaming function that allows you
to start watching videos almost as soon as they begin downloading from
the Internet.

To access this function, touch the Application tab from the Home screen,
then touch YouTube.

As an online video service, your phone must have a network

connection to access YouTube.

All videos in YouTube are grouped into several categories, like Most
Popular, Most Discussed, Featured Videos, etc.

Touch to search for a video

Touch to play the video and to show more
information

By touching from the YouTube screen, you can set General settings
and Search settings for YouTube. For details about these features, please

visit the YouTube website: www.YouTube.com

8.3.1 Watch videos

Touch a video to play it. In the Playing screen, you can view information
and video comments, and also browse links to related videos. You can also
rate, share, label as favorite, create a new playlist, etc. from this screen.

To exit the video playing screen, touch the Back key to return to the
video list.

8.4 Music ............................................................

Using this menu, you can play music files stored on the microSD card
in your phone. Music files can be downloaded from a computer to the
microSD card using a USB cable.

To access this function, touch the Application tab from the Home screen,
then touch Music.

You will find four categories in which all songs are classified: Artists,
Albums, Songs and Playlists. Slide left and right to view all. Touch
and touch Shuffle all to shuffle all songs.

97 98

8.4.1 Playing music

Touch a song or touch Play from the drop-down menu to play the song.







 Touch to play the current playlist in shuffle mode (tracks are played in

random order).

 Touch to skip to the previous track in the album, playlist, or shuffle.
 Touch to pause/resume playback.
 Touch to skip to the next track in the album, playlist, or shuffle.
 Touch to select repeat mode: Repeating all songs, Repeating current

song, or Repeat is off.

 Touch to show the displayed song.

While playing songs with Music, the operation of pause, play or

skip is still available even if the screen is locked.

Adjust sound effects

Touch
and adjust sound effects.

and touch Sound effects from the playing screen to enable







8.4.2 Working with playlists

Playlists allow you to conveniently organize all songs stored in the SD
card.

You can create a new playlist, add a song to the list, and delete or rename
a playlist.

To create a playlist

Touch Recently added from the Playlists screen, touch
touch Save as playlist, enter the name and finally touch Save.

To delete a playlist

Touch and hold a playlist to show the menu, then touch Delete.

To rename a playlist

Touch and hold a playlist to show the menu, then touch Rename. When
finished, touch Save to confirm.

and then

8.5 Video Player ................................................

To access this function, touch the Application tab from the Home screen,
then touch Video player.

Video player is a small built-in video player that lists all your videos.

Touch an item from the list to play. While playing, touch a point on the
timeline to jump to and play from.

99 100

Google Maps

9

(1)

................

9.1 Get My Location

9.1.1 Choose a data source to decide My Location

Touch on the Quick setting bar to get to Settings, touch Location
access.

Mark the checkbox of Access to my location, then the
beside GPS satellites will be automatically on to set GPS as the My location
data source.

Alternatively, mark the checkbox of Google's location service to set
Wi-Fi and/or mobile networks as My Location data source.

9.1.2 Open Google Maps and view My Location

Touch the Application tab from the Home screen, then touch Maps.

Touch the

The map will then center on a blue dot. Your actual position is at the blue dot.

icon on the map to view My Location.

Switch

To move the map, drag the map with your finger.

To zoom in and out of a map, pinch or spread your fingers, or you can also
zoom in by double-tapping a location on screen.

9.2 Search for a location

While viewing a map, touch the search icon to activate the search
function.

In the search box, enter an address, a city or a local business.

Touch the search icon to search, and in a while your search results will
appear on the map as red dots. You can touch one to show a label.

Touch to show more information.

Slide left or right to view more search results.

9.3 Save a location

Just like bookmarking a web address on the Internet, you can star any
position on the map for later use.

(1)

It may vary depending on the app version of Maps.

101 102

9.3.1 How to star (or unstar) a location

Touch a location on a map.

Touch the address rectangle which then opens.

Touch
location.)

to save the location. (Or touch to cancel the saving of that

9.3.2 View a list of saved items

Touch to view nearby saved places. Touch View all to view a list of
saved places.

Touch a location in the list to view it.

9.4 Get driving, public transportation or walking

directions

9.4.1 Get suggested routes for your trip

Touch the icon on the Maps screen.

• Touch the enter bar to edit your start point by entering an address or

selecting a saved item.

• Do the same for your end point.

• To reverse directions, touch

• Then select a transport mode: driving by car, using public transportation,

or walking directions.

.

103 104

9.4.2 Preview suggested routes and decide on a route

more preferable or feasible to you

You can preview each turn in your route in Navigation, Satellite, and
other views.

• Touch Start to preview your selected route.

• Touch

When selecting a more preferable or feasible route, distance and time
will be the two most important factors for your evaluation. Distance and
estimated time will be displayed at the bottom of the directions screen.

to open Route preview, Step-by-step list, Mute/Unmute
voice guidance, or Satellite view. Touch the Back key to return to
the previous view.

9.4.3 Search for locations along your route

Please refer to "9.2 Search for a location" for detailed information.

9.5 Arrangement of Layers

Layers allow you to view locations and additional information overlaid
on the map. You can add multiple layers or remove only certain layers
so you control exactly what information you want visible on the map at
one time.

10

Others .................................

10.1 File Manager ................................................

To access this function, touch the Application tab from the Home screen,
then touch File Manager.

File Manager works with both SD card and phone storage.

File Manager displays all data stored on both microSD card and phone

storage, including applications, media files such as videos, pictures or
audios you have captured; other data transferred via Bluetooth, USB
cable, etc.

When you download an application from a PC to your microSD card,
you can locate the application on File Manager, then touch it to install it
in your phone.

File Manager allows you to perform and be really efficient with the
following common operations: create a (sub) folder, open a folder/file,
view, rename, move, copy, delete, play, share, etc.

10.2 Sound Recorder ..........................................

To access this function, touch the Application tab from the Home screen,
then touch Sound Recorder.

Sound Recorder allows you to record voice/sound for seconds/hours.

105 106

10.3 Radio ............................................................

Your phone is equipped with a radio
traditional radio with saved channels or with parallel visual information
related to the radio program on the display if you tune to stations that
offer a visual radio service.

To access this function, touch the Application tab from the Home screen,
then touch Radio.

To use it, you must plug in your headset, which works as an
antenna connected with your phone.

Touch to go to previous saved channel
Touch to decrease 0.1MHz

Touch and hold to search and go to the nearest
lower frequency channel

Touch to increase 0.1MHz

Touch to go to next saved channel

Touch to add the current station to favorites

Touch to play/stop

Touch to open and view the saved channels list

(1)

. You can use the application as a

Available options:

• Save channel Save the current tuned station to the channels list.

• Audio mode Listen to the radio using the loudspeaker or

headset.

• Delete Delete the channel.

• Enter frequency Enter the frequency manually.

• Search Search for all available stations automatically.

• RDS settings Touch to select channel information and alternative

frequency.

• Record FM Record the current channel.

• Exit Turn off the radio.

10.4 Setup Wizard .............................................

To access this function, touch the Application tab from the Home screen,
then touch Setup Wizard.

Setup Wizard helps set up your phone in multiple ways: language, input
method, mobile data connection, account setup and synchronization,
system update, etc. This will also be performed the first time you power
on your phone.

(1)

The quality of the radio depends on the coverage of the radio station in that

particular area.

107 108

10.5 Alcatel Help ................................................

To access this function, touch the Application tab from the Home screen,
then touch Alcatel Help.

Alcatel Help provides help when you have questions or need assistance
when using the phone.

10.6 Other applications

The previous applications in this section are preinstalled on your phone.
To read a brief introduction of the preinstalled 3rd party applications,
please refer to the leaflet provided with the phone. You can also download
thousands of 3rd party applications by going to Android Market on your
phone.

(1)

..........................................

11

Drag down the Notification panel and touch then the Settings icon
to access Settings.

Settings .........................

11.1 Wireless & networks

11.1.1 Wi-Fi

Using Wi-Fi you can now surf the Internet without using your SIM card
whenever you are in range of a wireless network. The only thing you
have to do is to enter the Wi-Fi screen and configure an access point to
connect your phone to the wireless network.

For detailed instructions on using Wi-Fi, please refer to "6.1.2 Wi-Fi".

11.1.2 Bluetooth

Bluetooth allows your phone to exchange data (videos, images, music, etc.)
within a small range with another Bluetooth supported device (phone,
computer, printer, headset, car kit, etc.).

For more information on Bluetooth, please refer to "6.3 Connecting to

Bluetooth devices".

11.1.3 Call settings

For detailed instructions on call settings, please refer to "3.1.6 Call
settings".

(1)

Application availability depends on country and operator.

109 110

11.1.4 Data usage

To enable/disable mobile data, touch the switch.

By marking the checkbox of Set mobile data limit, you can then drag
the limit line and the warning line according to your preferred limits. Your
mobile data connection will be disabled when the specified limit is reached.
You can also choose a data usage cycle to view the statistics and related
applications of your phone's data use.

Touch

, and you can view more settings related to your data usage.

Data usage is measured by your phone, and your carrier may
count differently. Please consider using a conservative limit.

For more information on VPN, please refer to "6.6 Connecting to

virtual private networks".

11.1.7 Tethering & portable hotspot

This function allows you to share your phone's mobile data connection
via USB or as a portable Wi-Fi access point (Please refer to "6.5 Sharing

your phone's mobile data connection").

11.1.8 Mobile networks

• Data connection

Touch to turn on/off data connection.

11.1.5 Airplane mode

Through More...\Airplane mode you can simultaneously disable all
wireless connections including Wi-Fi, Bluetooth and more.

You can also open Airplane mode by touching AIRPLANE MODE on
the Quick setting bar or in phone options when you press the Power key.

11.1.6 VPN settings

A mobile virtual private network (mobile VPN or mVPN) provides mobile
devices with access to network resources and software applications on
their home network, when they connect via other wireless or wired
networks. Mobile VPNs are used in environments where workers need to
keep application sessions open at all times, throughout the working day,
as the user connects via various wireless networks, encounters gaps in
coverage, or suspends-and-resumes their device to preserve battery life. A
conventional VPN cannot survive such events because the network tunnel
is disrupted, causing applications to disconnect, time out, fail, or even the
computing device itself to crash.

111 112

• 3G service

Touch to Enable 3G service or to select Network mode.

• Preferences

Touch to view/edit/delete preferences.

• Access Point Names

You can select your preferred network with this menu.

• Network operators

You can select a network operator.

11.1.9 USB Internet

Touch to share your PC internet via a USB cable when connected to PC.

11.2 Device

11.2.1 Gestures

Mark the checkbox or touch to enable the following gestures: Turn over
to mute, Turn over to activate, Shake to switch music.

11.2.2 Sound

Use the Sound settings to configure ringtones for different events and
environments.

VOLUME

• Vibrate Marking the check box makes your phone vibrate

• Silent mode Marking the check box silences all sounds except

• Ringtone,

notifications

• Music, video,

games and other
media

• Alarms Slide to adjust the alarm volume.

CALL RINGTONE & VIBRATE

• Phone ringtone Touch to select your default incoming call

• Crescendo ringing Mark the check box to enable crescendo ringing.

• Default notification Touch to select your default notification ringtone.

when receiving incoming calls.

media & alarms.
Slide to adjust the volume of ringtones, notifications

and system sounds.

Slide to adjust the volume of music, video, games,
etc.

ringtone.

SYSTEM

• Dial pad touch

tones

• Audible selection Mark the check box to enable sounds when

• Screen lock sound Mark the check box to enable sounds to play

• Haptic feedback Mark the check box to activate vibration

• Power on ringtone Touch to set your default power on ringtone.

• Shut down

ringtone

Mark the check box to enable tones when using
the dial pad.

making screen selections.

when locking and unlocking the screen.

when pressing soft keys and with certain UI
interactions.

Touch to set your default power off ringtone.

11.2.3 Display

• Lock screen

notifications

• Wallpaper Touch to set the wallpaper.

• Orientation Mark the checkbox to select whether or not the

• Automatic

brightness

• Screen module Touch to adjust the screen module.

• Font size Touch to set the font size.

• Sleep Touch to set the screen timeout.

Mark the checkbox to show notifications on the
lock screen.

screen rotates automatically.

Touch to adjust the brightness of the screen.

113 114

11.2.4 Status bar

Touch the switch to reveal all 3rd party application notifications
which will then be shown on the top left of the status bar.

You can also touch some app icons to deactivate their notifications in the
status bar.

11.2.5 Storage

Use these settings to manage your microSD card by monitoring the total
and available space on your phone and your microSD card.

If a warning message comes up saying that phone memory is

limited, you are required to free up space by deleting some
unwanted applications, downloaded files, etc.

11.3 Personal

11.3.1 Location access

Use GPS satellites

Check to use your phone’s global positioning system (GPS) satellite
receiver to pinpoint your location within an accuracy as close as several
meters ("street level"). The process of accessing the GPS satellite and
setting your phone's precise location for the first time will require up to
5 minutes. You will need to stand in a place with a clear view of the sky
and avoid moving. After this, GPS will only need 20-40 seconds to identify
your precise location.

11.3.2 Security

11.2.6 Battery management

In the battery screen you can view battery usage data since you last
connected the phone to a power source. The screen also shows your
battery status and how long it has been used since last charging. Touch
one category to reveal its specific power consumption.

You can adjust power use by adjusting screen brightness or screen timeout
in the Display screen.

11.2.7 Applications

You use the Applications settings to view details about the applications
installed on your phone, to manage their data and force them to stop, and
to set whether you want to permit installation of applications that you
obtain from websites and emails.

115 116

Set up screen lock

• None Touch to disable screen unlock security.

• Slide Touch to enable slide unlock mode.

• Face unlock Touch to unlock your phone's screen by looking at it.

• Voice unlock Touch to unlock your phone's screen by speaking to it.

• Pattern Touch to unlock your phone's screen by drawing a

pattern.

• PIN Touch to unlock your phone's screen with a numeric

PIN.

• Password Touch to unlock your phone's screen with a password.

Owner info

Touch to input owner information which will display on the lock screen.

Lock screen G-sensor

Mark the checkbox to lock the screen G-sensor.

Find Me Back

Turn on the
privacy in case of theft or loss.

Encrypt phone

You can encrypt your accounts, settings, downloaded apps and their data,
media and other files by touching Encrypt phone.

Set up SIM card lock

Choose a SIM card you want to configure.

Mark the checkbox of Lock SIM card to lock the SIM card with a PIN
code.

Touch Change SIM PIN to change the PIN code.

Make passwords visible

Mark the checkbox to show passwords as you type.

switch to activate this function. It will protect your

Trusted credentials

Touch to display trusted CA certificates.

Install from SD card

Touch to install encrypted certificates from the microSD card.

Clear credentials

Touch to remove all credentials.

11.3.3 Language & input

Use the Language & input settings to select the language for the text on
your phone and for configuring the onscreen keyboard. You can also
configure voice input settings and the pointer speed.

Language

Touch to select the language and the region you want.

Device administrators

Touch to view or deactivate device administrators.

Unknown sources

Mark the checkbox to permit installation of applications that you obtain
from websites, emails, or other locations other than Android Market.

To protect your phone and personal data, download applications only
from trusted sources, such as Android Market.

Verify apps

Mark the checkbox to prevent or warn you before installing apps which
might cause harm.

117 118

Spell checker

Mark the checkbox to enable the system to show suggested words.

Personal dictionary

Touch to open a list of the words you’ve added to the dictionary. Touch a
word to edit or delete it. Touch the add button (+) to add a word.

Default

Touch to select a default input method. Touch the Settings icon
the right of selected input method, a series of settings are available for
your selection.

on

Swype

• Select Input Method

Touch to select method as English or Swype.

• How to Swype

Touch to view how to use Swype.

• Personal dictionary

Touch to add and keep new words into dictionary.

• Preferences

Audio feedback

Mark the checkbox to turn on sounds when tying.

Vibrate on keypress

Mark the checkbox to vibrate when keypressing.

Show tips

Mark the checkbox to turn on helpful tips from Swype.

Auto-spacing

Mark the checkbox to automatically insert spaces between words.

Auto-capitalization

Mark the checkbox to automatically capitalize the first letter in a sentence.

Show complete trace

Mark the checkbox to display the complete Swype path.

Word suggestion

Mark the checkbox to suggest words during typing.

Speed vs. accuracy

Select how quickly Swype responds to input.

Reset Swype’s dictionary

Delete all the words you’ve added to Swype’s dictionary.

Version

View the version of Swype.

• Language Options

Select input language such as French, English, Spanish, etc.

Voice search

Touch to view settings about voice search, such as Language, Speech
output, etc.

Text-to-speech output

• Preferred engine

Touch to choose a preferred text-to-speech engine, touch the Settings

to show more choices for each engine.

icon

• Speech rate

Touch to open a dialog where you can select how quickly you want the
synthesizer to speak.

• Listen to an example

Touch to play a brief sample of the speech synthesizer, using your current
settings.

Pointer speed

Touch to open a dialog where you can change the pointer speed. Touch
OK to confirm.

119 120

11.3.4 Backup and reset

Back up my data

Mark the checkbox to back up your phone’s settings and other application
data to Google servers, with your Google account. If you replace your
phone, the settings and data you’ve backed up are restored onto the new
phone the first time you sign in with your Google account. If you mark this
option, a wide variety of settings and data are backed up, including your
Wi-Fi passwords, bookmarks, a list of the applications you’ve installed, the
words you’ve added to the dictionary used by the onscreen keyboard,
and most of the settings configured within the Settings application. If you
unmark this option, settings are no longer backed up, and any existing
backups are deleted from Google servers.

Back up account

Touch to back up your account.

Automatic restore

Mark the checkbox to restore your backed up settings or other data when
you reinstall an application.

DRM reset

Touch to delete all DRM licenses.

Factory data reset

Phone reset will erase all of your personal data from the internal phone
storage, including information about your Google account, any other
accounts, your system and application settings, and any downloaded
applications. Resetting the phone does not erase any system software
updates you’ve downloaded or any files on your microSD card. If you
reset the phone in this way, you’re prompted to re-enter the same kind of
information as when you first started Android.

When you are unable to power on your phone, there is another way to
perform a factory data reset by using hardware keys. Press the Volume

up key and the Power key simultaneously until the screen lights up.

11.4 Accounts

Use these settings to add, remove, and manage your email and other
supported accounts. You can also use them to control details of the ways
applications send, receive, and synchronize data; if this is according to
their own schedules; and whether all applications can synchronize user
data automatically.

11.4.1 Add account

Touch to add an account for a selected app.

11.5 System

11.5.1 Date & time

Use Date & Time settings to customize your preferences for how date
and time are displayed.

121 122

Automatic date & time

Touch to select Use network/GPS provided time or Off.

Mark the checkbox to use network-provided time or use GPS provided
time.

Automatic time zone

Mark the checkbox to use the network-provided time zone. Or unmark
to set all values manually.

Set date

Touch to open a dialog where you can manually set the phone’s date.

Set time

Touch to open a dialog where you can manually set the phone’s time.

Select time zone

Touch to open a dialog where you can set the phone’s time zone.

Use 24-hour format

Mark the checkbox to display the time using 24-hour clock format.

Select date format

Touch to open a dialog where you can select the format for displaying
dates.

NTP sever

Touch to select NTP server for time auto update settings.

11.5.2 Schedule power on/off

Touch to preset the power on/off time and repeat mode.

11.5.3 Accessibility

Accessibility settings can be used to configure any accessibility plug-ins you
have installed on your phone.

TalkBack

Touch to turn on/off TalkBack.

Magnification gestures

Touch to turn on/off and to activate/deactivate the zoom in/out function
by triple-tapping the screen.

Power button ends call

Mark the checkbox to end a call by pressing Power key during the call.

Speak passwords

Mark the checkbox to speak passwords while typing.

Accessibility shortcut

Touch to turn on/off to enable/disable accessibility features.

Touch & hold delay

Touch to adjust the duration of touch and hold delay. This function enables
your phone to differentiate between touch and touch & hold, which may
avoid incorrect operations.

Enhance web accessibility

Touch to open a dialog which asks you to install scripts from Google which
make their web content more accessible. Touch Allow to confirm.

123 124

11.5.4 Developer options

To access this function, touch Settings\About phone, then touch Build
number 7 times. Now Developer options is available.

The Development screen contains settings that are useful for developing
Android applications. For full information, including documentation of the
Android applications and development tools, see the Android developer
website (http://developer.android.com).

Allow mock locations

Mark the checkbox to permit a development tool on a computer to
control where the phone believes it is located, rather than using the
phone’s own internal tools for this purpose.

Select debug app

Touch to select debug app.

Desktop backup password

Touch to set/change/remove desktop full backup password.

Stay awake

Mark the checkbox to prevent the screen from dimming and locking when
the phone is connected to a charger or to a USB device that provides
power. Don’t use this setting with a static image on the phone for long
periods of time, or the screen may be marked with that image.

Protect SD card

Mark the checkbox to select that apps must request permission to read
your SD card.

USB debugging

Mark the checkbox to permit debugging tools on a computer to
communicate with your phone via a USB connection.

Power menu bug report

Mark the checkbox to include the option of submitting a bug report in
the power menu.

125 126

Wait for debugger

Mark the checkbox to wait for a debugger to attach before executing.

Verify apps over USB

Mark the checkbox to check apps over USB.

Show touches

Mark the checkbox to show visual feedback for touches.

Pointer location

Mark the checkbox to show current touch data.

Show layout bounds

Mark the checkbox to show clip bounds, margins, etc.

Show GPU view updates

Mark the checkbox to show GPU view updates.

Show HW layers updates

Mark the checkbox to show hardware layers updates.

Show GPU overdraw

Mark the checkbox to show GPU overdraw.

Show CPU usage

Mark the checkbox to show current CPU usage.

Show surface updates

Mark the checkbox to show surface updates.

Window animation scale

Touch to adjust the animation scale for your window.

Transition animation scale

Touch to adjust the animation scale while performing a transition.

Animation duration scale

Touch to adjust the animation duration scale.

Disable HW overlays

Mark the checkbox to select to always use GPU for screen compositing.

Force GPU rendering

Mark the checkbox to enforce the use of 2D hardware acceleration in
applications.

Force 4x MSAA

Mark the checkbox to enable 4x MSAA.

Strict mode enabled

Mark the checkbox to enable strict mode. Once enabled, the screen will
flash when applications do long operations on the main thread.

Profile GPU rendering

Mark the checkbox to use 2D hardware acceleration in applications.

Enable OpenGL traces

Touch to adjust OpenGL traces.

Enable traces

Touch to adjust traces.

Don't keep activities

Mark the checkbox to destroy all activities as soon as you leave.

Background process limit

Touch to change the limit for background processes.

Show all ANRs

Mark the checkbox to show "Application Not Responding" dialogs for
background applications.

127 128

11.5.5 Quick start

Mark the checkbox to activate Quick start to shorten boot time. You can
also enable this function in phone options when pressing the Power key.

11.5.6 Regulatory & Safety

Touch to view information of the product model, manufacture name, IMEI
number and some certification logos or text.

12

Making the most of your

phone ..................................

You can download software upgrades for free from the website (www.
alcatelonetouch.com).

11.5.7 About phone

This contains information on items ranging from legal information, model
number, firmware version, baseband version, kernel version, build number
etc. related to the following:

System updates

Touch to check for system updates.

System updates (storage)

Touch to check for system udpates (storage).

Status

This contains Battery status, Battery level, My phone number, Network,
Signal strength, etc.

Legal information

Touch to view legal information.

You can learn more information about the phone such as its model
number, firmware version, baseband version, kernel version and build
number.

129 130

12.1 OVER-THE-AIR SOFTWARE UPDATE

CAPABLE Upgrade

Using the OVER-THE-AIR SOFTWARE UPDATE CAPABLE Upgrade tool
you can update your phone's software.

To access System Updates, please open the Notification panel and

and then , then press About phone\System updates. Or

touch
you can directly touch and access Settings\About phone\System
updates. Touch Check for updates, and the phone will search for
the latest software. If you want to update the system, please touch the
Download button, after it's done please touch Install to complete the
upgrade. Now your phone's software will be the latest version.

You should turn on data connection before searching for updates. Settings
for auto-check intervals and reminders about upgrades are also available
once you restart the phone.

If you have chosen auto-check, when the system discovers the new
version, the icon
access the System Updates directly.

During OVER-THE-AIR SOFTWARE UPDATE CAPABLE

downloading or updating, to avoid errors in locating the correct
update packages, do not change your default storage location.

will appear in the status bar. Touch the notification to

13

TCT Mobile (US), Inc. warrants to the original retail purchaser of this
wireless device that should this product or part thereof during normal
consumer usage and condition be proven to be defective in material or
workmanship that results in product failure within the first twelve (12)
months from the date of purchase as shown on your original sales receipt
from an authorized sales agent. Such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the company’s option without charge for parts
or labor directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box items are
also warranted against defects and workmanship that results in product
failure within the first twelve (12) months period from the date of purchase
as shown on your original sales receipt. Such defect(s) will be repaired or
replaced (with new or rebuilt parts) at the company’s option without charge
for parts or labor directly related to the defect(s).
The limited warranty for your wireless device will be voided if any of the
following conditions occur:

• Non-compliance with the instructions for use or installation, or with

technical and safety standards applicable in the geographical area where
your phone is used;

• Connection to any equipment not supplied or not recommended by TCT

Mobile (US), Inc.;

• Modification or repair performed by individuals not authorized by TCT

Mobile (US), Inc. or its affiliates;

• Changes to the device operating system by the user or third party

applications;

• Acts of god such as inclement weather, lightning, power surges, fire,

humidity, infiltration of liquids or foods, chemical products, crash, high
voltage, corrosion, oxidation;

LIMITED WARRANTY ....

• Removal or altering of the wireless device’s event labels or serial numbers

(IMEI);

• Damage from exposure to water or other liquids, moisture, humidity,

excessive temperatures or extreme environmental conditions, sand,
excess dust and any condition outside the operating guidelines;

• Defects in appearance, cosmetic, decorative or structural items such as

framing and non-operative parts;

• Damage as result of physical abuse regardless of cause.

• Rooted devices.

There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided
by your jurisdiction. In no event shall TCT Mobile (US), Inc. or any of its
affiliates be liable for incidental or consequential damages of any nature
whatsoever, including but not limited to commercial loss, to the full extent
those damages can be disclaimed by law. Some states do not allow the
exclusion or limitation of incidental or consequential damages, or limitation
of the duration of implied warranties, so the preceding limitations or
exclusions may not apply to you.

131 132

14

The latest generation of ALCATEL ONETOUCH mobile phones offers
a built-in handsfree feature that allows you to use the telephone from a
distance, placed on a table for example. For those who prefer to keep
their conversations confidential, an earpiece is also available known as
the headset.

1. Charger

2. USB cable

3. Stereo headset

Accessories .......................

Only use your telephone with the ALCATEL ONETOUCH

accessories in your box.

15

Before contacting the service center, you are advised to follow the
instructions below:

• You are advised to fully charge ( ) the battery for optimal operation.

• Avoid storing large amounts of data in your phone as this may affect its

performance.

• Use Factory data reset and the Mobile Upgrade tool to perform

phone formatting or software upgrading (to reset factory data, hold
down the Power key and the Volume up key at the same time under
power off mode). ALL User phone data: contacts, photos, messages,
files, and downloaded applications will be lost permanently. It is
strongly advised to fully backup the phone data and profile before doing
formatting and upgrading.

and carry out the following checks:

My phone is frozen or cannot be switched on

• Check the battery power level, charge for at least 20 minutes.

• Press and hold the Power key for more than 7 seconds to try to restart.

• If it still does not work, please reset the phone using the Power key and

the Volume up key.

• If it still does not work, please use Factory data reset to reset the phone

or OVER-THE-AIR SOFTWARE UPDATE CAPABLE/Mobile Upgrade
to upgrade software.

My phone has not responded for several minutes

• Restart your phone by pressing and holding the Power key.

• If it still does not work, please use Factory data reset to reset the phone

or OVER-THE-AIR SOFTWARE UPDATE CAPABLE/Mobile Upgrade
to upgrade software.

Troubleshooting ................

133 134

My phone turns off by itself

• Check that your screen is locked when you are not using your phone,

and make sure the Power key is not accidentally pressed while the
screen is unlocked.

• Check the battery charge level.

• If it still does not work, please use Factory data reset to reset the phone

or OVER-THE-AIR SOFTWARE UPDATE CAPABLE/Mobile Upgrade
to upgrade software.

My phone cannot charge properly

• Make sure you are using an ALCATEL ONETOUCH charger from the

box.

• Make sure that your battery is not completely discharged; if the battery

power is empty for a long time, it may take around 20 minutes to display
the battery charger indicator on the screen.

• Make sure charging is carried out under normal conditions (0°C (32°F)

to +40°C (104°F)).

• When abroad, check that the voltage input is compatible.

My phone cannot connect to a network or "No service" is
displayed

• Try connecting in another location.

• Verify the network coverage with your operator.

• Check with your operator that your SIM card is valid.

• Try selecting the available network(s) manually (see "11.1.8 Mobile

networks").

• Try connecting at a later time if the network is overloaded.

My phone cannot connect to the Internet

• Check that the IMEI number (press *#06#) is the same as the one

printed on your warranty card or box.

• Make sure that the internet access service of your SIM card is available.

• Check your phone's internet connection settings.

• Make sure you are in a place with network coverage.

• Try connecting at a later time or another location.

Invalid SIM card

• Make sure the SIM card has been correctly inserted (see "Inserting or

removing the SIM card").

• Make sure the chip on your SIM card is not damaged or scratched.

• Make sure the service of your SIM card is available.

Unable to make outgoing calls

• Make sure you have dialled a valid number and have touched Call.

• For international calls, check the country and area codes.

• Make sure your phone is connected to a network, and the network is

not overloaded or unavailable.

• Check your subscription status with your operator (credit, SIM card

valid, etc.).

• Make sure you have not barred outgoing calls.

• Make sure that your phone is not in airplane mode.

Unable to receive incoming calls

• Make sure your phone is switched on and connected to a network

(check for overloaded or unavailable network).

• Check your subscription status with your operator (credit, SIM card

valid, etc.).

• Make sure you have not forwarded incoming calls.

• Make sure that you have not barred certain calls.

• Make sure that your phone is not in airplane mode.

The caller’s name/number does not appear when a call is
received

• Check that you have subscribed to this service with your operator.

• Your caller has concealed his/her name or number.

I cannot find my contacts

• Make sure your SIM card is not broken.

• Make sure your SIM card is inserted properly.

• Import all contacts stored in SIM card to phone.

135 136

The sound quality of the calls is poor

• You can adjust the volume during a call by pressing the Volume Up/

Down key.

• Check the network strength

• Make sure that the receiver, connector or speaker on your phone is

clean.

I am unable to use the features described in the manual

• Check with your operator to make sure that your subscription includes

this service.

• Make sure this feature does not require an ALCATEL ONETOUCH

accessory.

When I select a number from my contacts, the number cannot
be dialled

• Make sure that you have correctly recorded the number in your file.

• Make sure that you have selected the country prefix when calling a

foreign country.

I am unable to add a contact in my contacts

• Make sure that your SIM card contacts are not full; delete some files or

save the files in the phone contacts (i.e. your professional or personal
directories).

My callers are unable to leave messages on my voicemail

• Contact your network operator to check service availability.

I cannot access my voicemail

• Make sure your operator’s voicemail number is correctly entered in

"Voicemail number".

• Try later if the network is busy.

.

I am unable to send and receive MMS

• Check your phone memory availability as it might be full.

• Contact your network operator to check service availability and check

MMS parameters (see "4.1.3 Adjust message settings").

• Verify the server center number or your MMS profile with your

operator.

• The server center may be swamped, try again later.

SIM card PIN locked

• Contact your network operator to obtain the PUK code (Personal

Unblocking Key).

I am unable to connect my phone to my computer

• Check that your USB driver is installed properly.

• Open the Notification panel to check if the Android Manager Agent has

been activated.

• Check that you have marked the checkbox of USB debugging.

• Check that your computer meets the requirements for ALCATEL ONE

TOUCH Android Manager installation.

• Make sure that you’re using the right cable from the box.

I am unable to download new files

• Make sure there is sufficient phone memory for your download.

• Select the internal SD card as the location to store downloaded files.

• Check your subscription status with your operator.

The phone cannot be detected by others via Bluetooth

• Make sure that Bluetooth is turned on and your phone is visible to other

users (see "6.3 Connecting to Bluetooth devices").

• Make sure that the two phones are within Bluetooth’s detection range.

137 138

How to make your battery last longer

• Make sure you follow the complete charge time (minimum 2.5 hours).

• After a partial charge, the battery level indicator may not be exact. Wait

for at least 20 minutes after removing the charger to obtain an exact
indication.

• Adjust the brightness of the screen as appropriate

• Extend the email auto-check interval for as long as possible.

• Update news and weather information on manual demand, or increase

their auto-check interval.

• Exit background-running applications if they are not being used for a

long time.

• Deactivate Bluetooth, Wi-Fi, or GPS when not in use.

The phone will become warm following prolonged calls, game
playing, internet surfing or running other complex applications.

• This heating is a normal consequence of the CPU handling excessive

data. Ending the above actions will make your phone return to normal
temperatures.

16

Processor MTK6572

Platform Android™ 4.2

Memory ROM: 4 GB/8 GB

Dimensions
(LxWxT)

Weight 96g with battery

Display 4.3", IPS, FWVGA

Network UMTS:

GPS Assisted GPS/Internal GPS antenna

Connectivity • Bluetooth V4.0/A2DP

Camera • 5.0 megapixel back camera

Specifications

RAM: 512 MB

127.1 x 62 x 7.95 mm

850/1900/2100 MHz

GSM/GPRS/EDGE:

Quad-band 850/900/1800/1900 MHz

(Band frequency and data speed are operator
dependent.)

• Wi-Fi IEEE 802.11 b/g/n

• 3.5 mm audio jack

• Micro-USB

• 0.3 megapixel front camera

139 140

Audio supported

AAC, AAC+, MP3, MP4, Midi

formats

Video supported

MPEG-4, H.263, H.264

formats

(1)

Battery

• 1700 mAh, Polymer Lithium-Ion battery

Special Features • G-sensor

• Light Sensor

• Proximity Sensor

Note: Specifications are subject to change without prior notice.

ALCATEL is a trademark of Alcatel-Lucent

and is used under license by

TCT Mobile Limited.

(1)

© Copyright 2014 TCT Mobile Limited

All rights reserved

TCT Mobile Limited reserves

the right to alter material

or technical specification

without prior notice.

All "Signature" ringtones embedded in this phone have been composed,
arranged and mixed by NU TROPIC (Amar Kabouche).

(1)

The original battery has undergone rigorous safety inspections to meet

qualification standards, the use of non-original batteries may be dangerous.

141 142

English - CJA17U101AAA
