Alcatel 6070O, 6055B User Manual

Note:

This is a shared user manual for Alcatel IDOL 4 (6055B) and Alcatel IDOL 4S (6070O).

Table of Contents

Safety and use �� 4

General information ��17

1 Your mobile ��19

1.1 Keys and connectors .........................................................................19

1.2 Getting started ...................................................................................25

1.3 Home screen .......................................................................................26

2 Boom Key ��34

3 Text input ��35

3.1 Using the Onscreen Keyboard ........................................................35

3.2 Text editing ..........................................................................................36

4 Call, Call log and Contacts ��37

4.1 Call ........................................................................................................37

4.2 Call log .................................................................................................43

4.3 Contacts ...............................................................................................44

5 Messaging and Email ��50

5.1 Messaging ............................................................................................50

5.2 Email .....................................................................................................55

6 Calendar & Time & Calculator ��57

6.1 Calendar ...............................................................................................57

6.2 Clock ....................................................................................................59

6.3 Calculator .............................................................................................62

1

7 Getting connected ��63

7.1 Connecting to the Internet..............................................................63

7.2 Browser ................................................................................................65

7.3 Connecting to Bluetooth devices ..................................................71

7.4 Connecting to a computer...............................................................73

7.5 Sharing your phone's cellular data connection ...........................73

7.6 Connecting to virtual private networks ........................................74

7.7 Connecting with devices through NFC ........................................76

8 Multimedia applications ��77

8.1 Camera/Camcorder ...........................................................................77

8.2 Gallery ..................................................................................................80

8.3 Music ....................................................................................................83

9 Others��84

9.1 Files .......................................................................................................84

9.2 Sound Recorder ..................................................................................84

9.3 Compass ..............................................................................................85

9.4 Boost ....................................................................................................85

9.5 Radio .....................................................................................................85

9.6 Xender File Transfer ..........................................................................87

9.7 Waves MaxxAudio .............................................................................87

9.8 Other applications .............................................................................87

10 Google applications ��88

10.1 Chrome ................................................................................................88

10.2 Gmail .....................................................................................................88

10.3 Maps .....................................................................................................88

10.4 YouTube ................................................................................................ 89

10.5 Play Store .............................................................................................89

10.6 Drive .....................................................................................................89

10.7 Play Music ...........................................................................................89

10.8 Play Movies & TV...............................................................................90

10.9 Hangouts .............................................................................................90

10.10 Photos ..................................................................................................90

10.11 Keep ......................................................................................................90

2

11 Settings ��91

11.1 Wireless & networks .........................................................................91

11.2 Device ..................................................................................................94

11.3 Personal ...............................................................................................99

11.4 System ............................................................................................... 103

12 VR goggles �� 107

12.1 Getting started ......................................................................... ....... 107

12.2 Troubleshooting ...............................................................................112

12.3 Safety information .......................................................................... 113

13 Making the most of your phone �� 114

13.1 Smart Suite ......................................................................... .............. 114

13.2 Upgrade ............................................................................................ 115

14 Accessories �� 117

15 Warranty �� 118

16 Troubleshooting �� 120

17 Specifications (Alcatel IDOL 4)�� 127

18 Specifications (Alcatel IDOL 4S) �� 129

This product meets applicable national SAR limits of 1.6 W/ kg. The specific maximum SAR values can be found on page 8 of this user guide.

When carrying the product or using it while worn on your body, either use an approved accessory such as a holster

www.sar-ck.com

or otherwise maintain a distance of 15 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

3

Safety and use ��

We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.

• TRAFFIC SAFETY:

Given that studies show that using a mobile phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset��), drivers are requested to refrain from using their mobile when the vehicle is not parked�

When driving, do not use your phone and headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas.

When switched on, your phone emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:

- do not place your phone on top of the dashboard or within an airbag deployment area,

- check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from mobile phone RF energy.

• CONDITIONS OF USE:

You are advised to switch off the telephone from time to time to optimize its performance.

Switch the phone off before boarding an aircraft. Switch the phone off when you are in health care facilities, except in designated

areas. As with many other types of equipment now in regular use, mobile telephones can interfere with other electrical or electronic devices, or equipment using radio frequency.

Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive atmosphere.

When the phone is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular, when using the phone, you should hold it against the ear on the opposite side to the device, if any.

4

To avoid hearing impairment, pick up the call before holding your phone to your ear. Also, move the handset away from your ear while using the "hands-free" mode because the amplified volume might cause hearing damage.

Do not let children use the phone and/or play with the telephone and accessories without supervision.

If your phone has a removable cover, note that your phone may contain substances that could create an allergic reaction.

If your phone is a unibody device, the back cover and battery are not removable. If you disassemble your phone the warranty will not apply. Disassembling the phone may damage the battery, and may cause leakage of substances that could create an allergic reaction.

Always handle your phone with care and keep it in a clean and dust-free place. Do not allow your phone to be exposed to adverse weather or environmental

conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The manufacturer’s recommended operating temperature range is -10°C to +40°C

(1)

At over 40°C the legibility of the phone’s display may be impaired, though this is temporary and not serious.

Emergency call numbers may not be reachable on all cellular networks. You should never rely only on your phone for emergency calls.

Do not open, dismantle or attempt to repair your mobile phone yourself. Do not drop, throw or bend your mobile phone. Do not use the phone if the glass made screen is damaged, cracked or broken

to avoid any injury. Do not paint it. Use only batteries, battery chargers, and accessories which are recommended by

TCL Communication Ltd. and its affiliates and are compatible with your phone model. TCL Communication Ltd. and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries.

Remember to make back-up copies or keep a written record of all important information stored on your phone.

Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone.

.

(1)

For Alcatel IDOL 4: -20°C to +40°C

5

Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:

- Do not play or use a flashing-lights feature if you are tired or need sleep.

- Take a minimum of a 15-minute break hourly.

- Play in a room in which all lights are on.

- Play at the farthest distance possible from the screen.

- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.

- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see a doctor.

When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

• PRIVACY:

Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding taking photographs and recording sounds with your mobile telephone� Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy� It is the user's sole responsibility to ensure that prior authorization is obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your mobile phone (including the carrier) disclaim any liability which may result from the improper use of the mobile phone�

6

• BATTERY:

Following air regulation, the battery of your product is not charged. Please charge it first.

Please note your phone is a unibody device, the back cover and battery are not removable. Observe the following precautions:

- Do not attempt to open the back cover,

- Do not attempt to eject, replace and open battery,

- Do not punctuate the back cover of your phone,

- Do not burn or dispose of your phone in household rubbish or store it at a temperature above 60°C.

Phone and battery as a unibody device must be disposed of in accordance with locally applicable environmental regulations.

- Collection bins at points of sale.

They will then be recycled, preventing substances being disposed of in the environment so that their components can be reused.

In European Union countries:

These collection points are accessible free of charge. All products with this sign must be brought to these collection points.

In non-European Union jurisdictions:

Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead, they are to be taken to collection points for them to be recycled.

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

This symbol on your telephone, the battery, and the accessories means that these products must be taken to collection points at the end of their life:

- Municipal waste disposal centers with specific bins for these items of equipment

• CHARGERS

Home A.C./ Travel chargers will operate within the temperature range of: 0°C (32°F) to 40°C (104°F).

The chargers designed for your mobile phone meet with the standard for safety of information technology equipment and office equipment use. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be used for this purpose only.

7

Characteristics of power supply (depending on the country): Travel charger: Input: 100-240 V, 50/60 Hz, 500 mA Output: 5 V, 2A Battery: Lithium 2610 mAh

(1)

(2)

• RADIO WAVES:

THIS MOBILE PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. These guidelines include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of measurement known as the Specific Absorption Rate or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating positions with the mobile phone transmitting at its highest certified power level in all tested frequency bands.

This device complies with SAR for general population /uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods and procedures specified in IEEE1528.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: 2ACCJA015 or 2ACCJA017 for Alcatel IDOL 4 and FCC ID: 2ACCJN008 for Alcatel IDOL 4S.

(1)

For Alcatel IDOL 4S: 5 V, 2A; 9V, 1.67A

(2)

For Alcatel IDOL 4S: 3000 mAh

8

Although the SAR is determined at the highest certified power level, the actual SAR level of the mobile phone while operating can be well below the maximum value. This is because the mobile phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the mobile phone. Before a mobile phone model is available for sale to the public, compliance with national regulations and standards must be shown.

The highest SAR value for this model mobile phone when tested is 1.19 W/Kg for use at the ear and 1.12 W/Kg for use close to the body.

(1)

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirements.

SAR compliance for body-worn operation is based on a separation distance of

(2)

15 mm

between the unit and the human body. Carry this device at least 15

(2)

away from your body to ensure RF exposure level compliant or lower to the

mm reported level. To support body-worn operation, choose the belt clips or holsters, which do not contain metallic components, to maintain a separation of 15 mm between this device and your body.

(2)

RF exposure compliance with any body-worn accessory, which contains metal, was not tested and certified, and use such body-worn accessory should be avoided.

Additional information on SAR can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site: http://www.ctia.org/

The World Health Organization (WHO) considers that present scientific information does not indicate the need for any special precautions for use of mobile phones. If individuals are concerned, they might choose to limit their own or their children’s RF exposure by limiting the length of calls, or using “handsfree” devices to keep mobile phones away from the head and body. Additional WHO information about electromagnetic fields and public health are available on the following website: http://www.who.int/peh-emf.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

(1)

For Alcatel IDOL 4S: 1.16 W/kg for use at the ear and 1.16 W/kg for use

close to the body.

(2)

For Alcatel IDOL 4S: 10 mm

9

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/ TV technician for help. Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment. For the receiver devices associated with the operation of a licensed radio service

(e.g. FM broadcast), they bear the following statement: This device complies with Part 15 of the FCC Rules and Industry Canada license-

exempt RSS standard(s). The operation is subject to the condition that this device does not cause harmful interference.

For other devices, they bear the following statement: This device complies with Part 15 of the FCC Rules and Industry Canada license-

exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received, including interference that

may cause undesired operation. Your mobile phone is equipped with a built-in antenna. For optimal operation,

you should avoid touching it or degrading it. Please note by using the device some of your personal data may be shared with

the main device. It is under your own responsibility to protect your own personal data, not to share it with any unauthorized devices or third party devices connected to yours. For products with Wi-Fi features, only connect to trusted Wi-Fi networks. Also, when using your product as a hotspot (where available), use network security. These precautions will help prevent unauthorized access to your device. Your product can store personal information in various locations including a SIM card, memory card, and built-in memory. Be sure to remove or clear all personal information before you recycle, return, or give away your product. Choose your apps and updates carefully, and install from trusted sources only. Some apps can impact your product’s performance and/or have access to private information including account details, call data, location details and network resources.

10

Note that any data shared with TCL Communication Ltd. is stored in accordance with applicable data protection legislation. For these purposes, TCL Communication Ltd. implements and maintains appropriate technical and organizational measures to protect all personal data, for example against unauthorized or unlawful processing and accidental loss or destruction of or damage to such personal data whereby the measures shall provide a level of security that is appropriate having regard to

(i) the technical possibilities available, (ii) the costs for implementing the measures, (iii) the risks involved with the processing of the personal data, and (iv) the sensitivity of the personal data processed. You can access, review and edit your personal information at any time by logging

into your user account, visiting your user profile or by contacting us directly. Should you require us to edit or delete your personal data, we may ask you to provide us with evidence of your identity before we can act on your request.

• LICENSES

microSD Logo is a trademark.

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TCL Communication Ltd. and its affiliates are under license. Other trademarks and trade names are those of their respective owners.

Alcatel 6055B Bluetooth Declaration ID D030257 Alcatel 6070O Bluetooth Declaration ID D029817

The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.

Google, the Google logo, Android, the Android logo, Google

TM

, Google MapsTM, GmailTM, YouTube, Google Play Store,

Search Google LatitudeTM and Hangouts

TM

are trademarks of Google Inc.

11

The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License (the text will show when you long press Google legal in Settings\About phone\Legal information).

(1)

You have purchased a product which uses the open-source (http://opensource. org/) programs mtd, msdosfs, netfilter/iptables and initrd in object code and other open source programs licensed under the GNU General Public License and Apache License.

We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the distribution of the product by TCL.

You may download the source codes from http://sourceforge.net/projects/ alcatel/files/. The provision of the source code is free of charge from the internet.

Hearing Aid Compatibility

Your mobile phone is rated: «For Hearing Aid», to assist hearing device users in finding mobile phones that may be compatible with their hearing devices.

This device is HAC M4/T4 compatible. Reference ANSI C63.19-2011 Your phone meets the M4/T4 level rating. For more information please visit our website http://www.alcatelonetouch.us

(1)

May not be available in all countries.

12

General information ��

•Website: www.alcatelonetouch.us

•Facebook: facebook.com/alcatel

•Twitter: twitter.com/alcatel

•Instagram: instagram.com/actalel

•Hot Line Number: In the United States, call 855-368-0829 for

technical support.

•Manufacturer: TCL Communication Ltd.

•Address: Flat/RM 1910-12A, Block 3, China HongKong City, 33

Canton Road, Tsimshatsui, Kowloon, Hong Kong.

•Electronic labeling path: Touch Settings\Regulatory & safety or press

*#07#, you can find more information about labeling

•How to obtain Support: In United States please call, (855) 368-0829

or go to www.alcatelonetouch.us for technical support. In Canada please call, (855) 844-6058 or go to www.alcatelonetouch.us for technical support.

On our website, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have.

An electronic version of this user guide is available in English and other languages according to availability on our server:

www�alcatelonetouch�us

Your telephone is a transceiver that operates on GSM in quad-band (850/900/1800/1900 MHz), UMTS in quad-band (850/900/1900/2100 MHz or 850/900/1700/1900/2100), or LTE (B2/3/4/7/13/17/28 or B2/3/4/5/7/12/17/27/28)

(2)

.

(1)

.

(1)

It depends on countries.

(2)

For Alcatel IDOL 4S: GSM 850/900/1800/1900, WCDMA

850/1700/1900/2100, or LTE FDD B2/4/5/7/12/17

13

This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The entire copy of the Declaration

of Conformity for your telephone can be obtained through our website:

www.

alcatelonetouch.us.

Protection against theft

Your telephone is identified by an IMEI (phone serial number) shown on the packaging label and in the phone’s memory� We recommend that you note the number the first time you use your telephone by entering * # 0 6 # and keep it in a safe place� It may be requested by the police or your carrier if your telephone is stolen� This number allows your mobile telephone to be blocked preventing a third person from using it, even with a different SIM card�

(1)

Disclaimer

There may be certain differences between the user manual description and the phone’s operation, depending on the software release of your telephone or specific carrier services.

TCL Communication shall not be held legally responsible for such differences if any, nor for their potential consequences, which responsibility shall be borne by the carrier exclusively.

(1)

Contact your network carrier to check service availability.

14

Your mobile ��

1

1�1 Keys and connectors

Alcatel IDOL 4:

Headset connector

Microphone

Speaker

LED indicator/

Front flashlight

Speaker

Sensor

Front camera

Touch screen

Boom Key

Back key

Overview key

Home key

Bottom microphone

Micro-USB connector

15

Camera Flash/Flashlight

Camera

Volume key

Boom key

SIM card slot/

microSD card

slot

Power key

NFC antenna

16

Alcatel IDOL 4S:

Headset connector

Microphone

Speaker

Sensor

Speaker

Bottom microphone

LED indicator

Front camera Front flashlight

Touch screen

Boom Key

Back key

Overview key Home key

Micro-USB connector

17

Camera Flash/Flashlight

Camera

Volume key

Boom key

Power key

SIM card slot/microSD card slot

FCC ID:2ACCJN008

18

Boom Key

Boom Key settings are available at: Settings\Boom Key. If Boom Key is enabled,

•From Home screen, press the key to show weather effect.

•Press the key to instantly take a photo when your phone

is locked.

•Press and hold the key to take burst shot when your phone is locked.

•Press the key to trigger audio effect when a song or movie is played.

•Press the key to enhance voice quality during a call.

•Press the key from Gallery Moments to create a photo

collage.

•Press the key to trigger special effect such as sequence change when a movie is played.

•You can also customize the Boom Key function. For example, enable screenshot taking or application running by pressing the Boom Key when the screen is locked.

•When phone is locked (display off):

- press to screen-on;

- double press to instant shot (800ms);

- long press to continuously shot.

Overview key

•Touch to switch between individual app activities and documents.

Home key

•From any application or screen, touch to return to the Home screen.

•Long press to turn on Google Now. You can get help such as getting directions and restaurant information based on the content detected on the screen.

19

Back key

•Touch to go back to the previous screen, or close a dialog box, options menu, the notification panel, etc.

Power key

•Press: Lock the screen/Light up the screen.

•Press and hold: Show the popup menu to select from

Power off/Restart/Aeroplane mode.

•Press and hold the Power key and Volume up key to reset.

•Press and hold the Power key and Volume down key to

make a screenshot.

•Press and hold the Power key for at least 10 seconds to force reboot.

Volume Keys

•In call mode, adjusts the earpiece or headset volume.

•In Music/Video/Streaming mode, adjusts the media

volume.

•In general mode, adjusts the ringtone volume.

•Mutes the ringtone of an incoming call.

•In camera preview mode, press Volume up or down key to

take a photo or press and hold to make burst shoot.

20

1�2 Getting started

1�2�1 Set up

Inserting or removing the SIM/microSD card

You must insert your SIM card to make phone calls. You do not need to power off your phone before inserting or removing the SIM card as this phone supports hot swap.

Your phone only supports nano-SIM cards. Do not attempt to insert other SIM types like mini and micro cards; otherwise, this may cause damage to your phone.

Charging the battery

You are advised to fully charge the battery ( indicated by a percentage displayed on the screen while the phone is powered off. The percentage increases as the phone is charged.

To reduce power consumption and energy waste when the battery is fully charged, disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc.

1�2�2 Power on your phone

Hold down the Power key until the phone powers on, unlock your phone (Swipe, PIN, Password or Pattern) if necessary and confirm. The Home screen is displayed.

If you do not know your PIN code or forget it, contact your network carrier. Be sure to keep your PIN code well.

). Charging status is

21

1�2�3 Power off your phone

Hold down the Power key until options appear, select Power off.

1�3 Home screen

You can bring all the items (applications, shortcuts, folders and widgets) you love or use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen.

Status bar

•Status/Notification indicators

•Touch and drag down to

open the notification panel.

Search bar

•Touch  to enter text search screen.

•Touch  to enter voice search screen.

Touch an icon to open an application, folder, etc.

Favorite tray applications

•Touch to enter the application.

•Long press to move or remove applications.

Touch to enter the applications list.

The Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen horizontally left and right to get a complete view.

Reversible screen

The phone supports the reversible function. From the Home screen, touch Reversible. Switch the toggle to enable the function.

to open the applications list, then touch Settings\Display\

22

1�3�1 Using the touchscreen

Touch

To access an application, touch it with your finger.

Long press

To enter the available options for an item, long press the item. For example, select a contact in Contacts, long press this contact, an options list will appear.

Drag

Place your finger on the screen to drag an object to another location.

Slide/Swipe

Slide the screen to scroll up and down the applications, images, and web pages. You can slide the screen horizontally too.

The device also supports one finger zooming in the Camera and Gallery functions. Double touch the screen to zoom in/out.

Flick

Similar to swiping, but flicking makes it move quicker.

Pinch/Spread

Place two fingers on the screen surface and draw them apart or together to scale an element on the screen.

23

Rotate

Automatically change the screen orientation from portrait to landscape by turning the phone sideways to have a better screen view.

1�3�2 Status bar

From the status bar, you can view both phone status (on the right side) and notification information (on the left side).

Drag down the status bar to view notifications and drag again to enter the quick settings panel.

Touch and drag up to close it. When there are notifications, you can touch them to access notifications.

Notification panel

When there are notifications, touch and drag down the Status bar to open the Notification panel to read more detailed information.

Touch to switch to the quick settings panel.

Touch to clear all event–based notifications (other ongoing notifications will remain).

24

Quick settings panel

Touch and drag down the Notification panel or touch Quick settings panel. You can enable or disable functions or change modes by touching the icons. Touch the Quick settings panel.

Touch to enter user screen to edit and save owner's name, phone number, and other information.

Touch to customize your Quick settings panel. Touch to access Settings, where you can

set more items.

icon to customize your

to open the

1�3�3 Search bar

The phone provides a Search function which can be used to locate information within applications, the phone or the web.

25

 Search by text

• Touch the Search bar from the Home screen.

•Enter the text/phrase you want to search for.

•Touch the

 Search by voice

•Touch

•Speak the word/phrase you want to search for. A list of search

results will display for you to select from.

icon on the keyboard if you want to search on the web.

from the Search bar to display a dialog screen.

1�3�4 Lock/Unlock your screen

To protect your phone and privacy, you can lock the phone screen by choosing slide or creating a pattern, PIN or password, etc.

To create a screen unlock pattern

•From the Home screen, touch

touch Settings\Lock screen\Screen lock\Pattern.

•Draw your own pattern.

to open the applications list, then

26

To lock phone screen

Press the Power key once to lock the screen.

To unlock the phone screen

Press the Power key once to light up the screen, slide to draw the unlock pattern you have created or enter your PIN or password, etc. to unlock the screen.

If you have chosen Swipe as the screen lock, you can press the Power key to light up the screen, then swipe up to unlock the screen, swipe the camera icon left to enter Camera or swipe the Voice search icon right to enter Voice search.

Double touch to enter the detailed screen

Swipe up to unlock the screen

Swipe right to

enter Voice search

Swipe left to enter Camera

1�3�5 Personalize your Home screen

Add

You can long press a folder, an application or a widget to activate the Move mode, and drag the item to your preferred Home screen.

27

Reposition

Long press the item to be repositioned to activate the Move mode, drag the item to the desired position and then release. You can move items both on the Home screen and the Favorite tray. Hold the icon on the left or right edge of the screen to drag the item to another Home screen.

Remove

Long press the item to be removed to activate the Move mode, drag the item up to the top of the X icon, and release after the item turns red.

Create folders

To improve the organization of items (shortcuts or applications) on the Home screen and the Favorite tray, you can add them to a folder by stacking one item on top of another. To rename a folder, open it and touch the folder’s title bar to input the new name.

Wallpaper customization

Long press the empty area in the Home screen, then touch

WALLPAPERS to customize wallpaper.

1�3�6 Widgets and recently-used applications

Consult widgets

Long press the empty area in the Home screen, then touch WIDGETS to display all widgets.

Touch the selected widget and slide it to move to your preferred screen.

28

Consult recently-used applications

To consult recently-used applications, touch the Overview key. Touch a thumbnail in the window to open the application.

Touch one thumbnail and slide it right/left or touch X to close the application.

Touch applications.

at the bottom of the screen to close all the running

1�3�7 Volume adjustment

Using the volume key

Press the Volume key to adjust the volume. To activate the vibrate mode, press the Volume down key until the phone vibrates.

Using the settings menu

From the Home screen, touch touch Settings\Sound & notification\Sound to set the volume of media, ringtone, alarm, etc. to your preference.

to open the applications list, then

29

Boom Key ��

2

Boom Key settings are available at: Settings\Boom Key.

If Boom Key is enabled,

•From Home screen, press the key to show weather effect.

•Press the key to instantly take a photo when your phone is locked.

•Press and hold the key to take burst shot when your phone is locked.

•Press the key to trigger audio effect when a song or movie is played.

•Press the key to enhance voice quality during a call.

•Press the key from Gallery Moments to create a photo collage.

•Press the key to trigger special effect such as sequence change when

a movie is played.

•You can also customize the Boom Key function. For example, enable screenshot taking or application running by pressing the Boom Key when the screen is locked.

•When phone is locked (display off):

- press to screen-on;

- double press to instant shot (800ms);

- long press to continuously shot.

30

Text input ��

3

3�1 Using the Onscreen Keyboard

Onscreen Keyboard settings

Touch Settings\Language & input, touch the keyboard you want to set up and a series of settings will become available.

Adjust the Onscreen Keyboard orientation

Turn the phone sideways or upright to adjust the onscreen keyboard orientation. You can adjust it by changing the settings (Touch Settings\ Display\Auto-rotate screen). Also your phone screen is reversible.

(Touch Settings\Display\Reversible).

3�1�1 Android keyboard

Touch to enter text or numbers.

Touch to switch

between "abc/Abc"

Long press to switch to

"abc/ABC" mode.

between symbol and

numeric keyboard.

mode;

Touch to switch

Long press to select symbols.

Long press to show input options.

31

3�2 Text editing

You can edit the texts you entered.

•Long press or double touch within the texts you want to edit.

•Drag the tabs to change the checked texts.

•The following options will show: SELECT ALL, CUT, COPY and

SHARE.

You can also insert new texts if preferred

•Touch where you want to type, or long press the blank, the cursor will blink and the tab will show. Drag the tab to move the cursor.

•If you have cut or copied any text, touch the tab to show the PASTE icon which allows you to complete pasting immediately.

32

Call, Call log and Contacts ��

4

4�1 Call ��

4�1�1 Making a call

You can launch a call by using Call. Touch the icon on the Home screen to access the Call application.

Touch to

call the

previewed

number.

Touch to enter the contact details screen. You can choose to edit, delete, share the contact, or send a message to the contact.

Slide to access the RECENTS and CONTACTS.

Touch to display keyboard.

Display the suggested number(s).

Long press to access voicemail.

33

Enter the desired number from the keyboard and touch the call or select a contact from CONTACTS or RECENTS by sliding or touching tabs, then to make the call.

The number you entered can be saved to Contacts by touching and then touching Create new contact.

If you make a mistake, you can delete the incorrect digits by touching

.

To hang up a call, touch

International call

To dial an international call, long press international country prefix followed by the full phone number and touch

.

Emergency call

If your phone has network coverage, dial the emergency number and touch card and without typing the PIN code.

to make an emergency call. This works even without a SIM

.

to enter “+”, then enter the

to place

34

4�1�2 Answering or rejecting a call

When you receive a call:

•Slide the

message.

To mute the ringtone volume of an incoming call, press the Volume

up/down key, or turn the phone over (when the Settings\Gestures\ Turn over to mute option is activated).

icon to the right to answer;

icon to the left to reject;

icon upwards to reject the call by sending a preset

For your convenience, your phone features a unique Reversible UI, which ensures functionality, including normal call, even the phone is held in reverse (upside-down) position.

35

4�1�3 Reversible call functionality

Your phone features a unique Reversible UI, which ensures complete functionality. When this feature is enabled through the Settings\ Display\Reversible menu, it allows normal calls to be made or received even when the phone is held upside down. The reversed UI will appear upright and normal, even if the phone is upside down.

When in the reversed position, the phone UI will appear upright and normal. The phone will function normally in all respects as it relates to interacting with the display, except that the power and volume keys will be on the opposite sides of their normal position. Also, take care to remember that the camera lenses (front and back) will be toward the lower edge of the device when in the reversed orientation. Please note that while a call is connected (user has selected Answer or Send), the UI will be fixed for the duration of the call. To disable the Reversible feature, go to the Settings\Display setting menu and disable Reversible.

36

Always make a visual inspection of the proper UI orientation when making or receiving a call to avoid placing the incorrect end of the phone to your ear. During an active call, if the phone must be taken away from your ear (eg, switching hands or to the other ear) please use caution not to use the phone in an orientation opposite that of which was used to originally make or answer the call. Doing so could cause unwanted, albeit brief, exposure to additional RF to the user. Only the active receiver (speaker) serving as the «top» of the device will function during the call so holding the device inadvertently in the opposite orientation will result in not being able to hear the other caller from the receiver against the ear. The user just needs to rotate the device back to the correct position to continue the call. Use of third-party auto-answer type features is also not recommended.

4�1�4 Calling your voicemail

Your voicemail is provided by your network to avoid missing calls. It works like an answering machine that you can consult at any time.

To access your voicemail, long press

To set your voicemail number: Long press NUMBER\Voicemail\Setup\Voicemail number.

If you receive a voicemail, a voicemail icon bar. Open the Notification panel and touch New voicemail.

.

, then touch ADD

appears on the Status

37

4�1�5 During a call

To adjust the volume during a call, press the Volume up/down key.

Touch to end the current call.

Touch to activate the speaker during the current call. Touch this icon again to deactivate the speaker.

Touch to mute the current call. Touch this icon again to unmute the call.

Touch to display the Dial pad.

Touch to hold the current call. Touch this icon again to retrieve the call.

Touch to add a call.

To avoid accidental operation of the touchscreen during a call, the screen will be locked automatically when you put the cellphone close to your ear; and it will be unlocked when the cellphone is taken away from your ear.

38

4�1�6 Managing multiple calls

With this phone you can handle multiple calls at the same time.

Swap calls

When you accept two calls, touch the

icon, you can now switch between two lines. The current call will be put on hold and you are able to join the other call.

Conference calls

(1)

You can set up a conference call as follows.

•Place a call to the first participant of the conference call.

•Touch the icon

•Then touch the icon

.

and then touch the icon to start the

conference.

•Touch to end the conference call and disconnect all callers.

4�1�7 Call settings

Touch from the Call screen, then touch Settings. The following options are available:

Display options

• Sort by: Touch to sort the list by the first name or last name.

• Name format: Touch to choose whether to display first name first,

or last name first.

Sounds and vibrate

Touch to set incoming call ringtone, and mark the checkbox to enable dial pad tones or vibrate for calls.

(1)

Depending on your network carrier.

39

Quick response

Touch to edit quick response.

Calling accounts

• Dual call settings: select SIM 1 or SIM 2 to set under options.

- Voicemail Service: Opens a dialog box where you can select your carrier’s

voicemail service or another service. Setup: If you are using your carrier’s voicemail service, this opens

a dialog box where you can enter the phone number to use for listening to and managing your voicemail. You can enter a comma (,) to insert a pause into the number — for example, to add a password after the phone number.

Sound: Touch to set the sound when a new voicemail arrives. Vibrate: Mark the checkbox to enable vibration when a new

voicemail arrives.

- Fixed Dialing Numbers

Fixed dialing number (FDN) is a SIM service mode, where outgoing calls are restricted to a set of phone numbers. These numbers are added to the FDN list. The most common practical application of FDN is for parents to restrict the phone numbers to which their children can dial. For security reasons, you’ll be prompted to enable FDN by entering SIM PIN2 which is usually acquired from your service provider or SIM maker.

- Vibration reminder

Touch the switch

to enable vibrate when call connects.

- Service Dialing Numbers

You can place a call from the SDN list.

(1)

Only for Alcatel IDOL 4S

40

- Turn on video calling Mark the checkbox to enable video calling.

- GSM call settings Call forwarding: Touch to configure how your calls are forwarded

when you are busy, unanswered or unreachable. Additional settings: Touch Caller ID to use default carrier settings

to display your number in outgoing calls. Mark the Call waiting check box to notify you of new incoming calls during a call.

Call barring: Touch to configure Call barring settings. Mark the checkbox to activate the call barring for outgoing and incoming calls.

Accessibility

Switch the toggle to enable hearing aids.

4�2 Call log

You can access your call memory by touching RECENTS tab from the Call screen to view Missed calls, Outgoing calls and Incoming calls.

Touch a contact or number to view information or further operations, you can launch a new call, send SMS to the contact or number, view detailed information of the call, or clear the call.

Touch View full call history to view all call log, touch log to clear the entire call memory.

and Clear call

41

4�3 Contacts ��

Contacts enables quick and easy access to the contact you want to

reach.

You can view and create contacts on your phone and synchronize these with your Gmail contacts or other applications on the web or on your phone.

4�3�1 Consult your Contacts

To see your contacts, touch from the Home screen, then select Contacts.

Touch to view

your favorites.

Long press to select

the current contact

or all contacts to

delete.

Touch to search in

Contacts

Touch to open Quick Contact panel.

Touch to add new contact.

Delete a contact

To delete a contact, long press the contact you want to delete, the icon will turn to

, then touch and confirm to delete. Touch

to select all contacts, then touch and confirm to delete all contacts.

42

The contact you have deleted will also be removed from other applications on the phone or web the next time you synchronize your phone.

Touch are enabled:

to display the contacts list option menu, following actions

•Contacts to display

•Merge contacts

•Import/Export

•Blocked contacts

•Accounts

•Settings

Choose contacts to display.

Select duplicate contacts to merge.

Import or export contacts between phone, SIM card, microSD card and phone storage.

Touch to view your blocked contacts. You can also unblock them.

Manage the synchronization settings for different accounts.

Touch to change the display of the sort list and contact names.

4�3�2 Adding a contact

Touch in the contact list to create a new contact.

You are required to enter the contact's name and other contact information. By scrolling up and down the screen, you can move from one field to another.

43

Touch to save.

Touch to select Phone, account, or SIM card.

Touch to add detailed name information. Touch to add organization.

Touch to select a picture or take a photo for the contact.

Touch to add a number.

When finished, touch to save.

To exit without saving, you can touch

and then touch Discard

changes.

Add to/remove from Favorites

(1)

To add a contact to favorites, you can touch a contact to view details then touch to add the contact to favorites (the star will turn white).

To remove a contact from favorites, touch the white star

on the

contact details screen.

4�3�3 Editing your contacts

To edit contact information, touch in the contact details screen to edit.

When finished, touch

to save.

(1)

Only phone contacts can be added to Favorites.

44

4�3�4 Use Quick contact for Android

Touch a contact to open Quick contact for Android, then you can touch or the number to make a call, touch to send a message.

The icons available on the Quick contact panel depend on the information you have for the contact and the applications and accounts on your phone.

4�3�5 Importing, exporting and sharing contacts

This phone enables you to import or export contacts between your phone, SIM card and phone storage.

From the Contacts screen, touch

Import/Export, then select Import/from SIM card, from SD storage, from phone, Export/to SIM card, to SD storage, to phone storage or Share visible contacts.

You can share a single contact or contacts with others by sending the contact's vCard to them via Bluetooth, Gmail, etc.

to open the options menu, touch

45

Touch a contact you want to share, touch the

icon and Share from

the contact details screen. Select the number you want to share and touch the

icon, and then select the application to perform this

action.

4�3�6 Displaying contacts

You can configure which list of contacts, for each account, you want to display in the Contacts list. Touch from contacts list screen, then you can choose which contacts to display.

Touch

and Settings to sort the list by the given name or family

name, as well as viewing contact names by given/family name first.

4�3�7 Joining/Separating contacts

To avoid duplication, you can add any new contact information to existing contacts in a single action.

Touch the contact which you want to add information to, touch enter edit contact screen, then touch again and touch Join.

At this time, you are required to select the contact whose information you want to join with the first contact. The information from the second contact is added to the first one, and the second contact will no longer be displayed in the Contacts list.

To separate contact information, touch the contact whose information you want to separate, touch touch again and touch Separate, touch OK to confirm.

and touch Contacts to display

(1)

to

to enter edit contact screen, then

(1)

Only applicable for phone contacts.

46

4�3�8 Accounts

Contacts, data or other information can be synchronized from multiple accounts, depending on the applications installed on your phone.

To add an account, touch

Accounts\ Add account, or from the home screen, touch then Settings\Accounts\Add account.

You are required to select the kind of account you are adding, like Google, Corporate, etc.

As with other account setup, you need to enter detailed information, like username, password, etc.

You can remove an account to delete it and all associated information from the phone. Touch the account you want to delete, touch select Remove account, then confirm.

Turn on/off the auto-sync

In the Accounts screen, touch checkbox. When activated, all changes to information on the phone or online will be automatically synchronized with each other.

from the contacts list and touch

and

and mark the Auto-sync data

47

Messaging and Email ��

5

5�1 Messaging ��

You can create, edit and receive SMS and MMS with this phone.

To send a message, touch

Messaging.

5�1�1 Write message

On the message list screen, touch the new message icon to write text/multimedia messages.

For saved contacts, touch the photo to open the Quick contact panel to communicate with the contact. For unsaved contacts, touch the photo to add the number to your Contacts�

from the Home screen then select

•Touch to view the whole message thread.

•Long press to activate delete mode.

Touch to create a new message.

48

Sending a text message

Enter the mobile phone number of the recipient in the To bar or touch

to add recipients. Touch the Send message bar to enter the text of

the message. Touch the touch to send the text message.

An SMS message of more than 160 characters will be charged as several SMS. A counter will be on the right of the text box to remind you how many characters are allowed to be entered in one message.

Specific letters (accented) will also increase the size of the SMS, this may cause multiple SMS to be sent to your recipient.

Sending a multimedia message

MMS enables you to send video clips, images, photos, animations, slides and sounds to other compatible mobiles and e-mail addresses.

An SMS will be converted to MMS automatically when media files (image, video, audio, slides, etc.) are attached or subject or email addresses are added.

To send a multimedia message, enter the recipient's phone number in the To bar and touch the Send message bar to enter the text of the message. Touch insert a subject. Touch the and so on.

When finished, touch

to open the options menu, touch Add subject to

icon to insert emoticons. When finished,

icon to attach a picture, video, audio

to send the multimedia message.

5�1�2 Manage messages

When receiving a message, an icon will appear on the status bar as a notification. Drag down the status bar to open the Notification panel, touch the new message to open and read it. You can also access the Messaging application and touch the message to open it.

Messages are displayed in conversational order.

49

Touch a message to enter the message composing screen:

•Touch

if the number has been saved;

•To reply to a message, enter the text, or touch contact etc., after edit then touch

•Long press a message to show the following icons: copy text , forward , view details , delete etc., touch to save the message to SIM card.

to call the number;

to save the number to contacts or view the contact details

to insert quick text,

.

5�1�3 Adjust message settings

You can adjust a range of message settings. From the Messaging application screen, touch and touch Settings.

GENERAL

•SMS enable

•Quick text

Storage

•Delete old messages

•Text message limit

•Multimedia

message limit

Touch to change your default SMS app.

Touch to edit quick response text.

Select to delete old messages when the maximum number of stored messages is reached.

Touch to set the maximum number of text messages to be saved per conversation.

Touch to set the maximum number of multimedia messages to be saved per conversation.

50

Notifications

•Notifications

•Select ringtone

•Vibrate

WAP message settings

•WAP message enable

Select to display message notifications in the status bar.

Touch to select a ringtone as a new message notification tone.

Select to have phone vibrate as a notification when receiving a new message.

Touch to enable receipt of push messages from network.

51

Cell Broadcast settings

•Cell broadcast

•Select CB ringtone

•Enable CB LED

indicator

•Enable light up screen

•Vibrate

•Cell broadcast

settings

•Emergency alerts

Mark the checkbox to enable receipt of cell broadcast messages.

Touch to select CB ringtone when receiving cell broadcast messages.

Mark the checkbox to enable CB LED indicator.

Mark the checkbox to light up the screen when receiving new cell broadcast.

Select to have phone vibrate as a notification when receiving a new message.

Touch to select channels and configure languages.

Touch to enter emergency alert settings, including whether to show threats and alert tones.

52

ADVANCED

Text message (SMS) settings

•Delivery reports

•Manage SIM

messages

•SMS Service Center

•Validity period

•Alphabet

management

•SMS signature

Multimedia message (MMS) settings

•Delivery reports

•Read reports

•Auto-retrieve

Select to request a delivery report for each text message you send.

Touch to manage text messages stored on your SIM card.

Touch to edit or view the service center number.

Touch to select the validity period, during which the network provider will continue to try to send the message.

Touch to select the Alphabet mode.

Mark the checkbox to add the signature to the messages you sent.

Select to request a delivery report for each multimedia message you send.

Select to request a report on whether each recipient has read a multimedia message sent by you.

Select to download the full MMS message (including message body and attachment) automatically to your phone. Otherwise, download only the MMS message header.

53

•Roaming autoretrieve

•Creation mode

•Maximum message

size

•Priority

Select to download the full MMS message (including message body and attachment) automatically when roaming. Otherwise, download only the MMS message header to avoid extra charges.

Select to change creation mode.

Select to input the maximum message size.

Touch to set the priority.

5�2 Email ��

The first time you set up your phone, you can select to use an existing Email or to create a new Email account.

You can also set up external POP3 or IMAP email accounts in your phone.

To set up your email account, touch select Email.

An email wizard will guide you through the steps to set up an email account.

•Enter the email address and password of the account you want to set up.

•Touch Next. If the account you entered is not provided by your service provider in the phone, you will be prompted to go to the email account settings screen to enter settings manually. Alternatively, you can touch Manual setup to directly enter the incoming and outgoing settings for the email account you are setting up.

•Enter the account name and display name in outgoing emails.

from the Home screen, then

54

•To add another email account, you can touch the icon upper left corner and select Settings. And then touch Add account.

To create and send emails

•Touch the icon

•Enter recipient(s) email address(es) in the To field.

•If necessary, touch Cc/Bcc to add a copy or a blind carbon copy to

the message.

•Enter the subject and the content of the message.

•Touch

•If you do not want to send the mail right away, you can touch

Save draft or touch the Back key to save a copy.

•Touch

If you do not want to send or save the email, you can touch then select Discard.

To add a signature to your emails, touch choose the account where you want to create or modify the signature, touch Signature to edit.

from the Inbox screen.

to add an attachment.

to send.

and select Settings, then

on the

and

55

Calendar & Time &

6

Calculator ��

(1)

6�1 Calendar ��

Use the Calendar to keep track of important meetings, appointments, etc.

To view the calendar and create events, touch screen, then touch Calendar.

6�1�1 Multimode view

You can display the Calendar by Schedule, Day, 3-day, Week, or Month.

Schedule view

Day view

3-day view

from the Home

Week view

Month view

(1)

The icon will vary with date.

56

6�1�2 To create new events

You can add new events from any Calendar view.

•Touch

•Fill in all required information for this new event. If it is a whole-day

event, you can select All-day.

•Invite guests to the event. Enter the email addresses of the guests you want to invite with commas to separate. The guests will receive an invitation from Calendar and Email.

•When finished, touch S AVE from the top of the screen.

To quickly create an event from the Week view screens, touch an empty spot to select a target area which will then turn the icon to create the new event.

to access a new event edit screen.

, and touch

6�1�3 To delete or edit an event

To delete or edit an event, touch the event to enter its details screen, touch the

icon to edit the event, and touch DELETE to delete.

6�1�4 Event reminder

If a reminder is set for an event, the upcoming event icon will appear on the Status bar as a notification when the reminder time arrives.

Touch and drag down the status bar to open the notification panel, touch an event name to view the Calendar notification list.

Touch the Back key to keep the reminders pending in the status bar and the notification panel.

57

6�2 Clock ��

Your mobile phone has a built-in clock.

To view the current time, touch

Clock.

6�2�1 World clock

To view the world clock, touch on the Time screen.

Touch the

icon to add a time zone.

6�2�2 Alarm

From the Time screen, touch to enter the Alarm screen.

Touch the switch

Touch

•Time

•Repeat

•Ringtone

•Vibrate

•Label

Touch a currently existing alarm to enter the alarm editing screen.

Touch

to add a new alarm, the following options will appear:

then touch to delete the selected alarm.

to enable the alarm.

Touch to set the alarm time.

Touch to select the days when you want the alarm to work.

Touch to select a ringtone for the alarm.

Select to activate vibration.

Touch to set a name for the alarm.

from the Home screen, then touch

58

6�2�3 Countdown

From the Time screen, touch to enter the Countdown screen.

•Enter the time. The time should be typed in second, minute and hour number sequence.

•Touch

•Touch the

•Touch

icon to activate Countdown.

icon to set the countdown time in panel.

icon to deactivate Countdown.

icon to delete current countdown label.

6�2�4 Timer

From the Time screen, touch to enter the Timer screen.

•Touch

to activate the timer.

to show a list of records according to the updated time.

•Touch

to halt the total and lap times. These will only restart after

is touched.

to delete the record.

to share.

6�2�5 Adjust Clock settings

Touch the icon and then Settings, the following options can now be adjusted:

59

•Style

•Automatic home

clock

•Home time zone

•Change Date &

time

•Silence after

•Snooze length

•Alarm volume

•Gradually increase

volume

•Volume buttons Touch to set side Volume up/down key

•Start week on

•Timer ringtone

Touch to set the clock style to Analogue or Digital.

Mark the checkbox to enable the function when traveling in an area where the time is different, add a clock for home.

Touch to set Home time zone.

Touch to enable automatic data & time, or change time manually.

Touch to set a temporary turn off time for an alarm.

Touch to set the duration of alarms.

Touch to set alarm volume.

Touch to select the duration after which the alarm volume increases, or disable this function.

behaviors when alarm sounds: None, Snooze or Dismiss.

Touch to choose the start of a week.

Touch to select the timer ringtone.

60

6�3 Calculator ��

With the Calculator, you can solve many mathematical problems.

To use the calculator, touch Calculator.

There are two panels available: Basic panel and Advanced panel.

To switch between panels, turn the device to the landscape mode from the basic panel or swipe left to open the Advanced panel

Enter a number and the arithmetic operation to be performed, enter the second number, then touch “=” to display the result. Touch to delete digits one by one, long press

from the Home screen, then touch

(1)

.

to delete all at one time.

(1)

If Settings\Display\Auto-rotate screen is enabled, this item will display.

61

Getting connected ��

7

To connect to the internet with this phone, you can use GPRS/ EDGE/3G/4G networks or Wi-Fi, whichever is most convenient.

7�1 Connecting to the Internet

7�1�1 GPRS/EDGE/3G/4G

The first time you turn on your phone with your SIM card inserted, it will automatically configure your network service: GPRS, EDGE , 3G or 4G.

To check the network connection you are using, touch Settings\More\

Cellular networks\Access Point Names or Network operators.

To create a new access point

A new GPRS/EDGE/3G/4G network connection can be added to your phone with the following steps:

•Touch Settings\More\Cellular networks\Access Point Names.

•Then touch the

•When finished, touch the

To activate/deactivate Data roaming

When roaming, you can decide to connect/disconnect to a data service.

•Touch Settings\More\Cellular networks.

•Switch the toggle to activate data roaming.

•When Data roaming is disabled, you can still perform data exchange

with a Wi-Fi connection (refer to “7�1�2 Wi-Fi”).

icon to enter the required APN information.

key and touch Save.

62

To set preferred network mode

•Touch Settings\More\Cellular networks\Preferred network mode.

7�1�2 Wi-Fi

Using Wi-Fi, you can connect to the Internet when your phone is within range of a wireless network. Wi-Fi can be used on your phone even without a SIM card inserted.

To turn Wi-Fi on and connect to a wireless network

•Touch Settings\Wi-Fi.

•Touch the switch

•Once Wi-Fi is on, the detailed information of detected Wi-Fi

networks is displayed.

•Touch a Wi-Fi network to connect to it. If the network you selected is secured, you are required to enter a password or other credentials (you may contact the network carrier for details). When finished, touch Connect.

To activate notification when a new network is detected

When Wi-Fi is on and the network notification is activated, the Wi-Fi icon will appear on the status bar whenever the phone detects an available wireless network within range. The following steps activate the notification function when Wi-Fi is on:

•Touch Settings.

•Touch Wi-Fi, then touch the

screen.

•Switch to toggle beside Network notification to activate/deactivate this function.

to turn on/off Wi-Fi.

icon and Advanced from the Wi-Fi

63

To add a Wi-Fi network

When Wi-Fi is on, you may add new Wi-Fi networks according to your preference.

•Touch Settings.

•Touch Wi-Fi, then touch the

icon and Add network from the

Wi-Fi screen.

•Enter the name of the network and any required network information.

•Touch SAVE.

To forget a Wi-Fi network

The following steps prevent automatic connections to networks which you no longer wish to use.

•Turn on Wi-Fi, if it’s not already on.

•In the Wi-Fi screen, touch the name of the saved network.

•Touch FORGET in the dialog that opens.

7�2 Browser

(1)

��

Using the Browser, you can enjoy surfing the Web.

To surf the web, touch

from the Home screen, then touch Browser.

To go to a web page

On the Browser screen, touch the URL bar at the top, enter the address of the web page, then confirm.

(1)

Only for Alcatel IDOL 4

64

Touch to search and go to this address Touch to delete all contents Touch to go to the suggested web site

To set a homepage

•Touch the

icon from Browser screen to display option menu, touch

Settings\Homepage.

•Choose a page or most visited website as your homepage.

•If you choose Other, enter the URL of the website you want to set

as your homepage, touch OK to confirm.

Viewing web pages

When opening a website, you can navigate on web pages by sliding your finger on the screen in any direction to locate the information you want to view.

65

To find text on a web page

•Touch the touch Find on page.

•Enter the text or phrase you want to find.

•The first word with matching characters will be highlighted on the

screen, and subsequent matches will be boxed.

•Touch the up or down arrow to switch to the previous or next matching items.

•When finished, you can touch the Back key to close the search bar.

Further operations for the text on a web page

You can copy, share or search the text from a web page:

•Long press the text to highlight the text.

•Move two tabs to select the text.

•Touch the

on the page or the web.

•When finished, touch the Back key to deactivate the mode.

To open new window/switch between windows

Multiple windows can be opened at the same time for your convenience.

•Touch

•Slide up and down to view all windows, touch one to view it.

•Touch

•To close a window, touch

slide it sideways.

icon from Browser screen to display option menu, and

icon to show further actions, including share and search

to open all windows' thumbnails.

to open a new window.

icon and to open a window without any trace.

on the window you want to close or

66

Other options:

•

•Bookmarks

•

To refresh the current page.

To forward the pages you have opened.

To see the bookmarks and browsing history.

To add the current website page as a bookmark.

•History

•Share page

•Find on page

•Request desktop

site

•Save for offline reading

•Exit

By touching the icon on the left of the URL, you can view more information about the current page.

To view your browsing history.

To share the current page with your friends in various ways, e.g. via Messaging, Email, Bluetooth, etc.

To input contents you want to find on the current page.

To enable/disable computer version websites.

To save the web page for offline reading. You can find it by touching the Menu key, then Bookmarks\SAVED PAGES.

To close all tabs and exit.

67

7�2�1 Manage links, history, downloads

To manage a link, phone number or address displayed on a web page

•Link

•Phone number

•Address

To download a web application/view your downloads

Before downloading a web application, you need to enable your phone to install web applications (Touch Settings\Security, enable the Unknown sources by switching the toggle).

To download an item, touch the item or the link you want to download.

To cancel a download, touch the downloaded item from the Notification panel, select the item to be canceled, and touch

To view items you have downloaded, touch application Downloads.

Touch the link to open the web page.

Long press the link to open options for further operation, like open in new window, save link, share link, copy link, etc.

Touch to call the phone number.

Touch to open Google Maps and locate the address.

to confirm.

, then touch the

7�2�2 Manage bookmarks

To bookmark a web page

•Open the web page you want to bookmark.

•Touch the

•Enter the name and the location if needed and touch OK to confirm.

icon and .

68

To open a bookmark

•Touch the

•Touch the bookmark you want to open.

•You can also long press to display the options screen, then touch

Open or Open in new tab.

To edit a bookmark

•Touch the

•Long press the bookmark you want to edit.

•Touch Edit bookmark, and enter your changes.

•When finished, touch OK to confirm.

Long press a bookmark in the bookmark list to view these additional options:

•Add shortcut to home

•Share link

•Copy link URL

•Delete bookmark

•Set as homepage

icon and Bookmarks.

To add a bookmark shortcut to the Home screen.

To share the bookmark.

To copy the bookmark link.

To delete a bookmark.

To set this page as the homepage.

69

7�2�3 Settings

A series of settings are available for your adjustment. To access Browser settings, touch the

Settings.

General

•Homepage

•Set search engine

•Form auto-fill

•Auto-fill text

Advanced

•Privacy & Security

•Accessibility

•Reset to default

from the Browser screen, and touch

Touch to set homepage.

Touch to choose your search engine in the phone.

Switch the toggle to fill out web forms with a single touch.

Touch to set up text to auto-fill in web forms.

Touch to update the settings related to privacy and security such as whether to remember your passwords, enabling "Do not track" mode, and application permissions.

Touch to adjust the text size.

Touch to restore Browser to default settings.

7�3 Connecting to Bluetooth devices

(1)

Bluetooth is a short-range wireless communication technology that you can use to exchange data, or connect to other Bluetooth devices for various uses.

(1)

You are recommended to use Alcatel Bluetooth headsets, which have

been tested and proved compatible with your phone. You can go to www.alcatelonetouch.us for more information about the Alcatel Bluetooth headset.

70

To exchange data, touch Settings\Bluetooth, your device and other available ones will show on the screen.

To turn on Bluetooth

•Touch Settings.

•Touch

To make your phone more recognizable, you can change your phone's name which is visible to others.

•Touch Settings\Bluetooth.

•Touch the

•Enter a name, and touch RENAME to confirm.

To pair/connect your phone with a Bluetooth device

To exchange data with another device, you need to turn Bluetooth on and pair your phone with the Bluetooth device with which you want to exchange data.

•Touch Settings\Bluetooth.

•Touch

•Touch a Bluetooth device you want to be paired with in the list.

•A dialog will pop up, touch PAIR to confirm.

•If the pairing is successful, your phone connects to the device.

To disconnect/unpair from a Bluetooth device

•Touch the Settings icon

•Touch FORGET to confirm.

to activate/deactivate this function.

icon and Rename this device.

and Refresh.

beside the device you want to unpair.

71

7�4 Connecting to a computer

With the USB cable, you can transfer media files and other files between your internal storage and a computer.

To connect your phone to the computer

Use the USB cable that came with your phone to connect the phone to a USB port on your computer. You will receive a notification that the USB is connected.

Open the Notification panel and select USB for file transfer.

Before using MTP, make sure that the driver (Windows Media Player 11 or higher version) has been installed.

To locate the data you have transferred or downloaded in internal storage, touch Files. All data you have downloaded is stored in Files, where you can view media files (videos, photos, music and others), rename files, install applications into your phone, etc.

7�5 Sharing your phone's cellular data connection

You can share your phone's cellular data connection with a single computer via a USB cable (USB tethering) or with up to eight devices at once by turning your phone into a portable Wi-Fi hotspot.

The functions below may incur additional network charges from your network carrier. Extra fees may also be charged in roaming areas.

To share your phone's data connection via USB

Use the USB cable that come with your phone to connect the phone to a USB port on your computer.

•Touch Settings\More\Tethering & portable hotspot.

•Touch the switch beside USB tethering to activate/deactivate this

function.

72

To share your phone's data connection as a portable Wi-Fi hotspot

•Touch Settings\More\Tethering & portable hotspot.

•Touch the switch beside Portable Wi-Fi hotspot to activate/

deactivate this function.

To rename or secure your portable hotspot

When a Portable Wi-Fi hotspot is activated, you can change the name of your phone's Wi-Fi network (SSID) and secure its Wi-Fi network.

•Touch Settings\More\Tethering & portable hotspot�

•Touch Set up Wi-Fi hotspot to change the network SSID or set your

network security.

•Touch SAVE.

To play media files on device with Wi-Fi Display feature

You can share your phone’s data such as music and video file with your TV by enabling the Wi-Fi display.

•Touch Settings\Display\Wi-Fi Display.

•To use Wi-Fi display, you must turn on WI-FI.

7�6 Connecting to virtual private networks

Virtual private networks (VPNs) allow you to connect to the resources inside a secured local network from outside that network. VPNs are commonly deployed by corporations, schools, and other institutions so that their users can access local network resources when not inside that network, or when connected to a wireless network.

To add a VPN

•Touch Settings\More\VPN and then touch

•In the screen that opens, follow the instructions from your network

administrator to configure each component of the VPN settings.

•Touch SAVE.

73

.

The VPN is added to the list on the VPN settings screen.

Before adding a VPN, you should set a PIN code or password for your phone.

To connect/disconnect VPN

To connect to a VPN:

•Touch Settings\More\VPN.

•VPNs you have added are listed; touch the VPN you want to connect

with.

•In the dialog that opens, enter any requested credentials and touch

CONNECT.

To disconnect:

•Open the Notification panel and touch the notification for the VPN disconnection.

To edit/delete a VPN

To edit a VPN:

•Touch Settings\More\VPN.

•VPNs you have added are listed; touch the

you want to edit.

•After editing, touch SAVE.

To delete:

•Touch the FORGET.

icon beside the VPN you want to delete, then touch

icon beside the VPN

74

7�7 Connecting with devices through NFC

NFC, short for Near Field Communication, is a short-range high frequency wireless communication technology which enables the exchange of data between devices over about a 10 centimeter (around 4 inches) distance.

NFC devices can be used in contactless payment systems, similar to those currently used in credit cards and electronic ticket smartcards, and allow mobile payment to replace or supplement these systems. NFC can also be used in social networking situations, such as sharing contacts, photos, videos or files, and entering multiplayer mobile games.

To enable NFC function:

•Drag down notification panel and touch

•Touch More and switch on the toggle for NFC to turn on NFC

function. Or drag down notification panel and touch the NFC icon to turn it on.

Alcatel IDOL 4:

to access Settings.

75

Multimedia applications ��

8

8�1 Camera/Camcorder ��

Your mobile phone is fitted with a Camera and a Camcorder for taking photos and shooting videos.

Before using the Camera or Camcorder, be sure to remove the protective lens cover to avoid it affecting your picture quality.

To take a photo or video, touch touch Camera.

from the Home screen and then

Touch to

update settings

Touch the screen

to set a focus

Pinch/spread two

fingers together

to zoom in/out

Touch to view the

photos or videos

you have taken

Touch to take a picture

To take a picture

The screen acts as the viewfinder. First, position the object or landscape in the viewfinder, touch the screen to focus if necessary and touch the saved.

icon to take the picture which will be automatically

76

Touch to switch between front/back camera

Touch to select flash mode

Slide left or right to change the camera mode to Manual, Pano, Auto, etc.

Touch to switch to Video mode

To shoot a video

Switch Camera mode to Video mode. First, position the object or landscape in the viewfinder and touch the Touch the saved.

Further operations when viewing a picture/video you have taken

•Slide left or right to view the photos or videos you have taken.

•Touch the

photo or video.

•Touch the

icon to stop recording. The video will be automatically

icon then Gmail, Bluetooth, MMS, etc to share the

icon or slide down to return to Camera.

icon to start recording.

8�1�1 Modes and settings

Before taking a photo, slide left or right to change the camera mode.

Back camera shooting mode

•AUTO

•PANO

•MANUAL

•SLO-MO

Auto mode is turned on.

Touch to turn on panorama function. Touch the shutter button to start taking panoramic photo and move the phone towards your capture direction and overlap the two lines. Once the slots are filled, the photo will be automatically saved. If the slots are not fully filled, touch the shutter button again to save the photo.

Touch to manually set ISO, shutter speed, focal length, or white balance as your wish.

Touch to start recording slow motion videos.

77

•MICRO-VIDEO

Settings

Touch


•Size

•Grid

•Attention sound/

Video

•Back camera video

•EIS

to set under options:

seeker

Press and hold to start recording a micro video.

Touch to select picture size.

Switch the toggle to enable/disable grid view. It divides the screen into equal parts and helps you take better photos by making it simple to align compositional elements to the grid, such as the horizon or buildings to the lines in the grid.

Switch the toggle to enable/disable the sound.

Touch to select the video recording quality.

Switch the toggle to enable the Electronic Image Stabilization (EIS) feature. It helps reduce blurring associated with the motion of a camera during exposure.

78

General

•Storage

•GPS tagging

•Shutter sound

•Anti Banding

•Reset to factory

settings

Touch to choose the phone or SD card to save photos.

Switch the toggle to activate/deactivate the function of tagging photos and videos with your location. This option is available when GPS location services and wireless network are switched on.

Switch the toggle to enable/disable shutter sound when taking a photo.

Touch to adjust camera settings to avoid banding.

Touch and confirm to reset the camera settings.

8�2 Gallery ��

Gallery acts as a media player for you to view photos and play videos. In addition, a set of further operations to pictures and videos are available for your choice.

To view the photos you have taken, touch then touch Gallery.

from the Home screen,

79

Touch to select the items shown in Gallery.

Touch to select photos for further operation.

Touch to access your albums.

To view a picture/play a video Pictures and videos are displayed by albums in the Gallery.

•Touch an album. All pictures or videos will spread across the screen.

•Touch the picture/video to view or play it.

•Slide left/right to view previous or next pictures/videos.

80

Working with pictures

You can touch one album, then slide left or right to view the pictures.

Touch a picture you want to work on, touch the selected one. Touch to share selected ones.

Touch the

Touch

Batch operation

The Gallery provides a multi-select function, so that you can work with pictures/videos in batches.

Open the main Gallery window or an album, touch item to activate batch operation mode (you can also touch and hold one album/picture), then touch videos/pictures you want to work on.

Touch the files.

icon to set them as contact ID or wallpaper, etc.

to access more options.

icon to delete selected files. Touch to share selected

icon to delete a

and touch Select

81

8�3 Music ��

Using this application, you can play music files stored in your phone. Music files can be downloaded from your computer to the phone using a USB cable.

To play a music file, touch

Music.

8�3�1 Playing music

Touch a song to play it.

 Touch to access the menu.

 Touch to change the song display

 Touch to search for a song

 Touch to access more functions

 Touch to play or pause

 Touch to play the next song

While playing songs with Music, the operation of pause, play or skip is still available even if the screen is locked.

from the Home screen, then touch









82

9

Others ��

9�1 Files ��

To manage the files in your phone, touch from the Home screen, then touch Files.

Files works with both external SD card and internal storage.

Files displays all data stored on the phone, including applications,

media files downloaded from Google Play Store, YouTube or other locations; videos, pictures or audios you have captured; other data transferred via Bluetooth, USB cable, etc.

When you download an application from PC to phone, you can locate the application using Files, then touch it to install it in your phone.

Files allows you to perform and is really efficient with the following common operations: create (sub) folder, open folder/file, view, rename, move, copy, delete, play, share, etc.

9�2 Sound Recorder ��

To record voice, touch from the Home screen, then touch Sound Recorder.

Sound Recorder allows you to record voice/sound for seconds/hours.

83

9�3 Compass ��

Wave your phone in a figure 8 motion to have your detailed location.

9�4 Boost

(1)

��

Boost provides you with the phone storage and battery status, and its performance. You can manage and optimize your phone by using this application.

9�5 Radio ��

Your phone is equipped with a radio

(2)

with RDS use the application as a traditional radio with saved channels or with visual information related to the radio program displayed if you turn to stations that offer Visual Radio service.

To listen to a radio program, touch touch Radio.

To use it, you must plug in your headset, which works as an antenna connected with your phone.

(1)

Only for Alcatel IDOL 4.

(1)

The quality of the radio depends on the coverage of the radio station in

that particular area.

(3)

Depending on your network carrier and market.

84

(3)

functionality. You can

from the Home screen, then

Touch to enable/disable

the loudspeaker.

Touch to decrease 0.1MHz.

Long press to search and

go to the nearest lower

frequency channel.

Touch to go to previous

saved channel.

Touch to play/stop.

Available options:

Touch to open and view the saved channels list.

Touch to add the current station to favorites.

Drag to change current frequency.

Touch to increase 0.1MHz. Long press to search and go to the nearest higher frequency channel.

Touch to go to next saved channel.

•Save channel

•Edit name

•Scan channels

•Delete

•Enter frequency

•Exit

Save the current station to the channel list.

Edit the channel name.

Touch to search for channels.

Delete the channel.

Enter the frequency manually to turn to the channel.

Turn off the radio.

85

9�6 Xender File Transfer

(1)

��

By using Xender, you can transfer the files in your phone to any other devices including PC/MAC and Android/iOS/Windows phones.

9�7 Waves MaxxAudio ��

Touch to set the sound effect for music and movies.

9�8 Other applications

(2)

��

The previous applications in this section are preinstalled on your phone. To read a brief introduction of the preinstalled 3rd party applications, refer to the leaflet provided with the phone. You can also download thousands of 3rd party applications by going to Google Play Store on your phone.

(1)

Only for Alcatel IDOL 4.

(2)

Application availability depends on country and carrier.

86

10

Google apps are preinstalled on your phone to improve work efficiency and help you enjoy life.

This manual briefly introduces the apps. For detailed features and user guides, refer to related websites or the introduction provided in the apps.

You are recommended to register with a Google account to enjoy all the functions.

Google applications ��

10�1 Chrome

A web browser with which you can surf the Internet.

Your bookmarks, browsing history, and settings across all devices with the browser installed can be synchronized with your Google account.

10�2 Gmail

As the Google's web-based email service, Gmail is configured when you first set up your phone. With this application, you can receive and send mails, manage mails by labels, and archive mails, etc. Mails can be automatically synchronized with your Gmail account.

10�3 Maps

Google Maps offers satellite imagery, street maps, 360° panoramic views of streets, real-time traffic conditions, and route planning for traveling by foot, car, or public transportation. By using this application, you can get your own location, search for a place, and get suggested route planning for your trips.

87

10�4 YouTube

YouTube is an online video-sharing application where users can upload, view, and share videos. Available content includes video clips, TV clips, music videos, and other content such as video blogging, short original videos, and educational videos. It supports a streaming function that allows you to start watching videos almost as soon as they begin downloading from the Internet.

10�5 Play Store

Serves as the official app store for the Android operating system, allowing users to browse and download applications and games. Applications are either free of charge or at a cost.

In Play Store, search for the app you need, download it and then follow the installation guide to install the app. You can also uninstall, update an app, and manage your downloads.

10�6 Drive

A file storage and synchronization service created by Google, which allows users to store files in the cloud, share and edit files.

Files in Drive are well kept and you can reach your files from any device by logging in to your Google account. Files or folders can be shared privately with particular users having a Google account.

10�7 Play Music

A music streaming service and online music locker operated by Google.

You can upload and listen to a large number of songs for free. In addition to offering music streaming for Internet-connected devices, the Google Play Music app allows music to be stored and listened to offline. Songs purchased through the Play Music are automatically added to the user's account.

88

10�8 Play Movies & TV

Movies and television shows can be viewed online via Google Play Movies & TV. You can also download movies and TV shows for offline viewing. Some content is only available for rental or purchase.

10�9 Hangouts

Google Hangouts is a communication platform developed by Google which includes instant messaging, video chat, SMS, and VOIP features. You should add a friend and then start chatting. All friends added via Hangouts from the Web or device will be displayed in your friend list.

10�10 Photos

Google Photos stores and backs up your photos and videos. It also automatically analyzes photos and organizes them into groups, so that you can quickly locate the photos you need.

10�11 Keep

A note taking application developed by Google.

You can insert images, lists, and record voice in your notes, and set time or location-based reminders for notes. Google Keep allows you to categorize notes by labels, and notes are searchable based on their color, whether they have reminders, audio, images, or are lists.

89

11

To go to Settings, touch from the Home screen, then touch

Settings.

Settings ��

11�1 Wireless & networks

11�1�1 Wi-Fi

Using Wi-Fi you can now surf the Internet without using your SIM card whenever you are in range of a wireless network. The only thing you have to do is to enter the Wi-Fi screen and configure an access point to connect your phone to the wireless network.

For detailed instructions on using Wi-Fi, refer to “7�1�2 Wi-Fi”.

11�1�2 Bluetooth

Bluetooth allows your phone to exchange data (videos, images, music, etc.) within a small range with another Bluetooth supported device (phone, computer, printer, headset, car kit, etc.).

For more information on Bluetooth, refer to “7�3 Connecting to

Bluetooth devices”.

11�1�3 SIM cards

Touch to choose SIM 1 or SIM 2 for connecting to the network, making calls and sending SMS messages.

(1)

Only for Alcatel IDOL 4S

90

11�1�4 Data usage

Cellular data

If you do not need to transmit data on cellular networks, turn off cellular data to avoid incurring significant charges for data use on local carrier cellular networks, particularly if you do not have a cellular data agreement.

Set cellular data limit

By enabling Set cellular data limit, your cellular data connection will be disabled when the specified limit is reached. You can also choose a data usage cycle to view the statistics and applications related to the data use of your phone.

Data usage is measured by your phone, and your carrier may count differently.

11�1�5 More\Aeroplane mode

Touch the switch of Aeroplane mode to simultaneously disable all wireless connections including Wi-Fi, Bluetooth and more.

11�1�6 More\NFC

Touch the switch to enable and disable NFC.

The function allows data exchange when the phone touches another device.

11�1�7 More\Android Beam

Android beam can be activated only when NFC is on.

The function allows to transmit app content via NFC.

91

11�1�8 More\Tethering & portable hotspot

This function allows you to share your phone's cellular data connection via USB or as a portable Wi-Fi access point (refer to “7�5 Sharing your

phone's cellular data connection”).

11�1�9 More\VPN

A mobile virtual private network (mobile VPN or mVPN) provides mobile devices with access to network resources and software applications on their home network when they connect via other wireless or wired networks. Mobile VPNs are used in environments where workers need to keep application sessions open at all times, throughout the working day, as the user connects via various wireless networks, encounters gaps in coverage, or suspends-and-resumes their devices to preserve battery life. A conventional VPN can't survive such events because the network tunnel is disrupted, causing applications to disconnect, time out, fail, or even the computing device itself to crash.

For more information on VPN, refer to “7�6 Connecting to virtual

private networks”.

11�1�10 More\Cellular networks

Data roaming

If you don’t need to transmit data on other carriers’ cellular networks, disable Data roaming to avoid incurring significant roaming charges.

Preferred network mode

You can set your preferred network mode, such as GSM/WCDMA, LTE etc.

Enhanced 4G LTE mode

Touch to improve the communication quality.

92

Show roaming reminder

Touch to select whether to show a reminder under roaming mode.

Access Point Names

You can select your preferred network with this menu.

Network carriers

You can select a network carrier.

11�1�11 Mobile plan

Touch to set the mobile plan.

11�1�12 Emergency alerts

Touch to enter emergency alerts settings, include whether to show threats and alert Tone.

11�2 Device

11�2�1 Gestures

The following gestures can be used for quick operations:

(1)

•Touchless UI

•Glove mode

Approach the screen with your finger to show the effect.

(1)

Enable glove mode then you can touch on the screen with thin gloves.

•Turn over to mute

•Double tap screen

Switch the toggle to mute ringtones of incoming calls by turning the phone over. Switch the toggle to enable the function that allows you to turn the screen on or off by a double tap.

(1)

•Black screen gesture

(1)

Only for Alcatel IDOL 4S

Enable the black screen gesture, draw a letter on

(1)

the black screen to quickly access an application.

93

11�2�2 Display

In this menu, you can adjust your screen brightness, wallpaper, font size, color temperature of your screen, etc.

Press Power key twice for Camera

If enabled, you can quickly access Camera by double pressing the Power key without unlocking your phone.

Reversible

If activated, you can answer a call even if your phone is held upside down.

Matrix FlipCase

If enabled,

•The cover will light up to show the time and weather when you press the power key or double touch the screen area.

•Swipe left/right to play the previous/next song or channel when the music player or radio is on.

•The cover will show the name or phone number of an incoming call. You can swipe left/right to reject/answer the call, or swipe down to end a call.

•The cover reminds you of the event details.

Auto-launch VR

If activated, the VR launcher starts automatically when VR headset is plugged in, so that you can enjoy 3D images and movies with VR glasses.

(1)

It depends on countries. For detailed instructions, see “12 VR goggles”.

94

11�2�3 Lock screen

Func shortcuts

Touch to customize the application shortcuts displayed on your lock screen.

WallShuffle

If this function is enabled, different wallpapers will be displayed on your lock screen each time you press the power key to unlock your phone.

Screen lock

Touch to set your screen unlock method. For example, you can unlock your phone by sliding the screen, entering a password, or drawing a pattern, etc.

Make pattern visible

This option only displays when you select Pattern to unlock your phone. Touch

Automatically lock

Touch to select the duration to lock the phone after the screen is off.

Lock screen message

Touch to input owner information which will display on the locked screen.

to make pattern visible.

11�2�4 Sound & notification

Touch to adjust call and notification ringtones, music, and other audio settings.

95

•Sound

•Headset mode

•Also vibrate for

calls

•MaxxAudio

•Do Not Disturb

•Phone ringtone

•Default notification

ringtone

•Mute power on & off ringtone

•Other sounds

•Pulse notification

light

•When device is locked

•App notifications

•Notification access

Set volume for media, ringtone, and alarms.

Mark the checkbox to enable headset mode. Ringtones will only be heard from the headset if it is plugged in.

Switch the toggle to enable vibration for incoming calls.

Touch to set the sound effect for music and movies.

Touch to allow alarms, reminders, calls, etc. when Do not disturb mode is enabled.

Touch to set your incoming call ringtone.

Touch to set the default sound for notifications.

Touch to enable/disable the power on & off ringtone.

Touch to set dial pad tones, screen locking sounds, touch sounds and vibrate on touch.

Touch to enable light reminding when there is a notification.

You can configure whether to show all notification content or don't show notification at all when your device is locked.

Touch to block or set priority for app notifications.

Touch to view the notification listeners.

96

11�2�5 Boom Key

If Boom Key is enabled,

•From Home screen, press the key to show weather effect.

•Press the key to instantly take a photo when your phone is locked.

•Press and hold the key to take burst shot when your phone is locked.

•Press the key to trigger audio effect when a song or movie is played.

•Press the key to enhance voice quality during a call.

•Press the key from Gallery Moments to create a photo collage.

•Press the key to trigger special effect such as sequence change when

a movie is played.

•You can also customize the Boom Key function. For example, enable screenshot taking or application running by pressing the Boom Key when the screen is unlocked.

•When phone is locked (display off):

- press to screen-on;

- double press to instant shot (800ms);

- long press to continuously shot.

11�2�6 Apps

Touch to view details about the applications installed on your phone, to manage their data usage and force them to stop.

In the App permissions menu of an application, you can grant permissions for the app, such as allowing the app to access your Camera, Contacts, Location, etc.

In the Notification menu, you can configure whether to block the notifications from this app, hide sensitive content, etc.

11�2�7 Storage & USB

Use these settings to monitor the total and available space on your phone.

97

11�2�8 Battery

Touch any category in the battery management screen to view its power consumption.

You can adjust power use via the screen brightness or screen timeout settings in the Display screen.

11�2�9 Memory

Touch to view the total memory and the memory used by applications.

11�2�10 Users

Touch to add an account for this phone.

11�3 Personal

11�3�1 Location

On

Touch the and cellular networks to determine your approximate location, for use in Google Maps, when you search, and so on. When you select this option, you’re asked whether you consent to share your location anonymously with Google’s location service.

Mode

Touch to select High accuracy, Battery saving or Device only mode.

• High accuracy: Use GPS, Wi-Fi and cellular network to determine location.

• Battery saving: Use Wi-Fi to determine location.

• Device only: Use GPS to determine location.

switch to enable the use of information from Wi-Fi

98

Recent location requests

This list shows the recent location requests.

11�3�2 Security

Encrypt phone

Requires a numeric PIN, pattern, or password to decrypt your phone each time you power it on.

Prevent mis-operation

Switch the toggle to prevent mis-operation in double touch unlock mode.

Set up SIM card lock

•Switch the toggle of Lock SIM card to lock the SIM card with a PIN code.

•Touch Change SIM PIN to change the PIN code.

Make passwords visible

Switch the toggle to show passwords as you type.

Device administrators

Touch to view or deactivate device administrators.

Unknown sources

Switch the toggle to permit installation of applications that you obtain from websites, emails, or other locations other than Google Play Store.

To protect your phone and personal data, download applications only from trusted sources, such as Google Play Store.

(1)

Only for Alcatel IDOL 4S

99

Alcatel 6070O, 6055B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
