Alcatel 5059D, 5059X User Manual

For more information on how to use the phone, please go to www.alcatel-mobile.com and download the
complete user manual. Moreover, on the website, you can also find answers to frequently asked questions,
upgrade the software via Mobile Upgrade, and so much more.

Note:

This is a user manual for alcatel 1X 5059X, 5059D.

Help

Refer to the following resources to get more FAQ, software, and service
information.

Consulting FAQ

Go to

http://www.alcatel-mobile.com/global-en/support/topFaq.json

Updating your phone’s software

Update through the Updates app on your device.

To download the software update tool onto your PC, go to

http://www.alcatel-mobile.com/global-en/support/softwareUpgrade/list

Finding your serial number or IMEI

You can find your serial number or International Mobile Equipment
Identity (IMEI) on the packaging materials. Or, on the phone, choose

Settings > About phone > Status.

Obtaining warranty service

First follow the advice in this guide. Then check hotlines and repair centres
information through

http://www.alcatel-mobile.com/global-en/support/repairResult

Viewing legal information

On the phone, go to Settings > System > About phone > Legal information.

Using ONETOUCH Cloud

Open User Centre, then touch More info. For an online User Centre
tutorial (may not be available in all areas), go to

http://my.alcatelonetouch.com/personalcloud/loginPage?reqUrl=/
dashboard/index.

Using other alcatel apps

Go to

http://www.alcatel-mobile.com/global-en/apps/appsList

1

Table of Contents

Safety and use ..................................................................... 6

Radio waves ....................................................................... 14

Licences ...............................................................................20

General information ......................................................... 22

1 Your mobile ...................................................... .......... 26

1.1 Keys and connectors ......................................26

1.2 Getting started ................................................29

1.3 Home screen ....................................................31

2 Text input ...................................................................42

2.1 Using the onscreen keyboard ......................42

2.2 Text editing .......................................................44

3 Call, Call log and Contacts .....................................45

3.1 Call .....................................................................45

3.2 Call log ...............................................................51

3.3 Contacts ............................................................52

4 Messaging ..................................................................59

4.1 Write a new message ....................................59

4.2 Manage messages...........................................61

4.3 Adjust message settings ................................63

5 Calendar, Clock, and Calculator ............................64

5.1 Calendar ............................................................64

2

5.2 Clock ..................................................................66

5.3 Calculator ..........................................................69

6 Getting connected ...................................................70

6.1 Connecting to the internet ...........................70

6.2 Connecting to a Bluetooth device .............73

6.3 Connecting to a computer via USB ............75

6.4 Sharing your phone's mobile data

connection ..................................................................75

6.5 Connecting to virtual private networks ....76

7 Multimedia applications .........................................79

7.1 Camera ..............................................................79

7.2 Photos ...............................................................83

8 Others ......................................................................... 85

8.1 File Manager ....................................................85

8.2 Radio ..................................................................86

8.3 Other applications .........................................88

9 Google applications ................................................. 89

9.1 Chrome ..............................................................89

9.2 Gmail ..................................................................89

9.3 Maps ..................................................................90

9.4 YouTube .............................................................90

9.5 Play Store ..........................................................90

9.6 Drive ..................................................................91

9.7 Play Music ........................................................91

3

9.8 Duo ....................................................................91

9.9 Photos ...............................................................92

9.10 .................................................................. Keep92

10 Settings ....................................................................... 93

10.1 Network & connection ..................................93

10.2 Apps & notifications ......................................95

10.3 Battery ...............................................................96

10.4 Smart Manager ................................................96

10.5 Display ...............................................................96

10.6 Sound.................................................................96

10.7 Security & location .........................................96

10.8 Advanced Features .........................................97

10.9 Users & accounts ............................................97

10.10Accessibility ......................................................98

10.11Google ...............................................................98

10.12System ...............................................................98

11 Making the most of your phone ........................ 101

11.1 FOTA Upgrade ..............................................101

12 Accessories ............................................................. 102

13 Warranty .................................................................. 103

14 Troubleshooting ..................................................... 106

15 Specifications ......................................................... 115

4

www.sar-ck.com

PROTECT YOUR HEARING

To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your device near
your ear while the loudspeaker is in use.

This product meets applicable national
SAR limits of 2.0 W/kg. The specific
maximum SAR values can be found on
Radio Waves section of this user guide.

When carrying the product or using it
while worn on your body, either use an
approved accessory such as a holster or
otherwise maintain a distance of 5 mm
from the body to ensure compliance
with RF exposure requirements. Note
that the product may be transmitting
even if you are not making a phone call.

5

Safety and use ...............................

We recommend that you read this chapter carefully
before using your phone. The manufacturer disclaims
any liability for damage, which may result as a
consequence of improper use or use contrary to the
instructions contained herein.

• TRAFFIC SAFETY:

Given that studies show that using a phone while
driving a vehicle constitutes a real risk, even when the
hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their phone when the
vehicle is not parked.

When driving, do not use your phone and headset to
listen to music or to the radio. Using a headset can be
dangerous and forbidden in some areas.

When switched on, your phone emits electromagnetic
waves that can interfere with the vehicle’s electronic
systems such as ABS anti-lock brakes or airbags. To
ensure that there is no problem:

- Do not place your phone on top of the dashboard or
within an airbag deployment area;

- Check with your car dealer or the car manufacturer to
make sure that the dashboard is adequately shielded
from phone RF energy.

6

• CONDITIONS OF USE:

You are advised to switch off the phone from time to
time to optimise its performance.

Switch the phone off before boarding an aircraft.
Switch the phone off when you are in health care

facilities, except in designated areas. As with many
other types of equipment now in regular use, phones
can interfere with other electrical or electronic devices,
or equipment using radio frequency.

Switch the phone off when you are near gas or
flammable liquids. Strictly obey all signs and instructions
posted in a fuel depot, petrol station, or chemical plant,
or in any potentially explosive atmosphere.

When the phone is switched on, it should be kept
at least 15 cm from any medical device such as a
pacemaker, a hearing aid, or an insulin pump, etc.. In
particular when using the phone, you should hold it
against the ear on the opposite side to the device, if
any.

To avoid hearing impairment, pick up the call before
holding your phone to your ear. Also move the phone away
from your ear while using the "hands-free" mode because
the amplified volume might cause hearing damage.

Do not let children use the phone and/or play with the
phone and accessories without supervision.

7

If your phone has a removable cover, note that your
phone may contain substances that could create an
allergic reaction.

If your phone is a unibody device, the back cover and
battery are not removable. If you disassemble your
phone the warranty will not apply. Disassembling the
phone may damage the battery, and may cause leakage
of substances that could create an allergic reaction.

Always handle your phone with care and keep it in a clean
and dust-free place.

Do not allow your phone to be exposed to adverse
weather or environmental conditions (moisture,
humidity, rain, infiltration of liquids, dust, sea air,
etc.). The manufacturer’s recommended operating
temperature range is -10°C (14°F) to +45°C (113°F).

At over 45°C (113°F) the legibility of the phone’s
display may be impaired, though this is temporary and
not serious.

Do not open, dismantle, or attempt to repair your phone
yourself.

Do not drop, throw, or bend your phone.
Do not use the phone if the glass screen is damaged,

cracked, or broken to avoid any injury.
Do not paint it.

8

Use only batteries, battery chargers, and accessories
which are recommended by TCL Communication Ltd.
and its affiliates and are compatible with your phone
model. TCL Communication Ltd. and its affiliates
disclaim any liability for damage caused by the use of
other chargers or batteries.

Remember to make backup copies or keep a written
record of all important information stored on your
phone.

Some people may suffer epileptic seizures or blackouts
when exposed to flashing lights, or when playing video
games. These seizures or blackouts may occur even if a
person never had a previous seizure or blackout. If you
have experienced seizures or blackouts, or if you have a
family history of such occurrences, please consult your
doctor before playing video games on your phone or
enabling a flashing-lights feature on your phone.

Parents should monitor their children’s use of video
games or other features that incorporate flashing
lights on the phones. All persons should discontinue
use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching,
loss of awareness, involuntary movements, or

disorientation. To limit the likelihood of such symptoms,
please take the following safety precautions:

- Do not play or use a flashing-lights feature if you are
tired or need sleep;

9

- Take a minimum of a 15-minute break hourly;

- Play in a room in which all lights are on;

- Play at the farthest distance possible from the screen;

- If your hands, wrists, or arms become tired or sore
while playing, stop and rest for several hours before
playing again;

- If you continue to have sore hands, wrists, or arms
during or after playing, stop the game and see a
doctor.

When you play games on your phone, you may
experience occasional discomfort in your hands, arms,
shoulders, neck, or other parts of your body. Follow the
instructions to avoid problems such as tendinitis, carpal
tunnel syndrome, or other musculoskeletal disorders.

10

• PRIVACY:

Please note that you must respect the laws and
regulations in force in your jurisdiction or other
jurisdiction(s) where you will use your phone regarding
taking photographs and recording sounds with your
phone. Pursuant to such laws and regulations, it may
be strictly forbidden to take photographs and/or to
record the voices of other people or any of their
personal attributes, and reproduce or distribute them,
as this may be considered to be an invasion of privacy.
It is the user's sole responsibility to ensure that prior
authorisation has been obtained, if necessary, in order
to record private or confidential conversations or take
a photograph of another person; the manufacturer, the
seller or vendor of your phone (including the operator)
disclaim any liability which may result from improper
use of the phone.

• BATTERY:

Following air regulation, the battery of your product is
not charged. Please charge it first.

For a non-unibody device:

Observe the following precautions:

- Do not attempt to open the battery (due to the risk of
toxic fumes and burns);

- Do not puncture, disassemble, or cause a short circuit
in a battery;

11

- Do not burn or dispose of a used battery in household
rubbish or store it at temperatures above 60°C
(140°F).

Batteries must be disposed of in accordance with
locally applicable environmental regulations. Only
use the battery for the purpose for which it was
designed. Never use damaged batteries or those not
recommended by TCL Communication Ltd. and/or its
affiliates.

For a non-unibody device with a non-removable
battery:

Observe the following precautions:

- Do not attempt to eject, replace or open the battery;

- Do not puncture, disassemble, or cause a short circuit
in the battery;

- Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F).

Phone and battery must be disposed of in accordance
with locally applicable environmental regulations.

For a unibody device:

Observe the following precautions:

- Do not attempt to open the back cover;

- Do not attempt to eject, replace, or open battery;

- Do not puncture the back cover of your phone;

12

- Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F).

Phone and battery as a unibody device must be disposed
of in accordance with locally applicable environmental
regulations.

This symbol on your phone, the battery, and the
accessories means that these products must be
taken to collection points at the end of their life:

- Municipal waste disposal centres with specific bins for
these items of equipment;

- Collection bins at points of sale.

They will then be recycled, preventing substances
being disposed of in the environment, so that their
components can be reused.

In European Union countries:

These collection points are accessible free of charge.
All products with this sign must be brought to these

collection points.

In non-European Union jurisdictions:

Items of equipment with this symbol are not to be
thrown into ordinary bins if your jurisdiction or your
region has suitable recycling and collection facilities;
instead they are to be taken to collection points for
them to be recycled.

13

CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE
OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.

• CHARGERS:

Mains powered chargers will operate within the
temperature range of: 0°C (32°F) to 40°C (104°F ).

The chargers designed for your phone meet the standard
for safety of information technology equipment and
office equipment use. They are also compliant with the
ecodesign directive 2009/125/EC. Due to different
applicable electrical specifications, a charger you
purchased in one jurisdiction may not work in another
jurisdiction. They should be used for this purpose only.

Radio waves ...................................

Proof of compliance with international standards
(ICNIRP) or with European Directive 2014/53/EU
(RED) is required of all phone models before they can
be put on the market. The protection of the health and
safety for the user and any other person is an essential
requirement of these standards or this directive.

THIS DEVICE MEETS INTERNATIONAL GUIDELINES
FOR EXPOSURE TO RADIO WAVES.

14

Your phone is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure
to radio waves (radio frequency electromagnetic
fields) recommended by international guidelines. The
guidelines were developed by an independent scientific
organisation (ICNIRP) and include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.

The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption Rate,
or SAR. The SAR limit for mobile devices is 2 W/kg.

Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest
certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this
device model are:

5059X/D

Maximum SAR for this model and conditions under

which it was recorded

Head SAR
Body-worn SAR

UMTS 900 + Wi-Fi 0.58 W/kg
LTE Band 3 + Wi-Fi 1.70 W/kg

15

During use, the actual SAR values for this phone are
usually well below the values stated above. This is
because, for purposes of system efficiency and to
minimise interference on the network, the operating
power of your phone is automatically decreased when
full power is not needed for the call. The lower the
power output of the phone, the lower its SAR value.

Body-worn SAR testing has been carried out at a
separation distance of 5 mm. To meet RF exposure
guidelines during body-worn operation, the phone
should be positioned at least this distance away from
the body.

If you are not using an approved accessory ensure that
whatever product is used is free of any metal and that
it positions the phone the indicated distance away from
the body.

Organisations such as the World Health Organisation
and the US Food and Drug Administration have stated
that if people are concerned and want to reduce their
exposure they could use a hands-free device to keep
the phone away from the head and body during phone
calls, or reduce the amount of time spent on the phone.

For more information, you can go to www.alcatelmobile.
com.

Additional information about electromagnetic fields
and public health are available on the following site:
http://www.who.int/peh-emf.

16

Your phone is equipped with a built-in antenna. For
optimal operation, you should avoid touching it or
degrading it.

As mobile devices offer a range of functions, they can
be used in positions other than against your ear. In such
circumstances the phone will be compliant with the
guidelines when used with a headset or USB data cable.
If you are using another accessory ensure that whatever
product is used is free of any metal and that it positions
the phone at least 5 mm away from the body.

17

Please note by using the device some of your personal
data may be shared with the main device. It is under
your own responsibility to protect your own personal
data, not to share with it with any unauthorised devices
or third party devices connected to yours. For products
with Wi-Fi features, only connect to trusted Wi-Fi
networks. Also when using your product as a hotspot
(where available), ensure your network security. These
precautions will help prevent unauthorised access
to your phone. Your product can store personal
information in various locations including a SIM card,
memory card, and built-in memory. Be sure to remove
or clear all personal information before you recycle,
return, or give away your product. Choose your apps
and updates carefully, and install from trusted sources
only. Some apps can impact your product’s performance
and/or have access to private information including
account details, call data, location details, and network
resources.

Note that any data shared with TCL Communication Ltd.
is stored in accordance with applicable data protection
legislation. For these purposes TCL Communication Ltd.
implements and maintains appropriate technical and
organisational measures to protect all personal data, for
example, against unauthorised or unlawful processing
and accidental loss or destruction of or damage to such
personal data whereby the measures shall provide a
level of security that is appropriate having regard to

18

- The technical possibilities available;

- The costs for implementing the measures;

- The risks involved with the processing of the personal
data, and;

- The sensitivity of the personal data processed.

You can access, review, and edit your personal
information at any time by logging into your user
account, visiting your user profile or by contacting us
directly. Should you require us to edit or delete your
personal data, we may ask you to provide us with
evidence of your identity before we can act on your
request.

19

Licences ...........................................

microSD logo is a trademark.

The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by TCL Communication
Ltd. and its affiliates is under licence. Other
trademarks and trade names are those of
their respective owners.

Alcatel 1X 5059X/5059D Bluetooth
Declaration
ID D038401

The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.

This equipment may be operated in all
European countries.

This device may be operated without
restrictions in any EU member state.

Google, the Google logo, Android, the Android
logo, Google Search TM, Google Maps TM,
Gmail TM, YouTube, Google Play Store, Google
Latitude TM, and Hangouts
of Google Inc.

TM

are trademarks

20

The Android robot is reproduced or modified from
work created and shared by Google and used according
to terms described in the Creative Commons 3.0
Attribution License (the text will show when you
touch Google legal in Settings > About phone > Legal
information)

(1)

.

You have purchased a product which uses the open
source (http://opensource.org/) programmes mtd,
msdosfs, netfilter/iptables and initrd in object code and
other open source programs licensed under the GNU
General Public Licence and Apache Licence.

We will provide you with a complete copy of the
corresponding source codes upon request within a
period of three years from the distribution of the
product by TCL Communication Ltd.

You may download the source codes from http://
sourceforge.net/projects/alcatel/files/. The provision
of the source code is free of charge from the internet.

We hereby point out that the end user warranty for
infringement IPR is solely limited to the EU/EEA/
Switzerland.

(1)

May not be available in all countries.

21

If and to the extent that the Product is exported,
taken with, or used by end customer or end user
outside the EU/EEA/Switzerland any responsibility,
warranty or indemnification of manufacturer and its
suppliers in regard to the Product expires (including any
indemnification in regard to infringement IPR).

General information .....................

• Internet address: www.alcatelmobile.com

• Hotline: See the "SERVICES" leaflet that came with

your phone or go to our website.

• Manufacturer: TCL Communication Ltd.

• Address: 5/F, Building 22E, 22 Science Park East

Avenue, Hong Kong Science Park, Shatin, NT, Hong
Kong

• Electronic labeling path: Touch Settings > Regulatory

& safety or press *#07#, you can find more

information about labelling

On our website, you will find our FAQ (Frequently
Asked Questions) section. You can also contact us by
email to ask any questions you may have.

This radio equipment operates with the following
frequency bands and maximum radio-frequency power:

GSM 850/900: 34 dBm

(1)

.

(1)

It depends on countries.

22

GSM 1800/1900: 31 dBm
UMTS 1900/2100: 24 dBm
UMTS 850/900: 24.5 dBm
LTE Band 1/3/7/8/20: 24 dBm
Bluetooth:<3.1 dBm

802.11 bgn:2.4GHz band<18 dBm

• Regulatory information

Hereby, TCL Communication Ltd. declares that the
radio equipment type Alcatel 1X 5059X/5059D is in
compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is
available at the following internet address: http://www.
alcatelmobile.com/EU_doc.

• Additional information

The description of accessories and components,
including software, which allow the radio equipment
to operate as intended, can be obtained in the full text
of the EU declaration of conformity at the following
internet address: http://www.alcatelmobile.com/EU_
doc.

23

Protection against theft

(1)

Your phone is identified by an IMEI (phone serial
number) shown on the packaging label and in the
phone’s memory. We recommend that you note the
number the first time you use your phone by entering
*#06# and keep it in a safe place. It may be requested by
the police or your operator if your phone is stolen. This
number allows your phone to be blocked preventing a
third person from using it, even with a different SIM
card.

Disclaimer

There may be certain differences between the user
manual description and the phone’s operation,
depending on the software release of your phone or
specific operator services.

TCL Communication Ltd. shall not be held legally
responsible for such differences, if any, nor for their
potential consequences, which responsibility shall be
borne by the operator exclusively. This phone may
contain materials, including applications and software
in executable or source code form, which is submitted
by third parties for inclusion in this phone ("Third Party
Materials"). All Third Party Materials in this phone
are provided "as is", without warranty of any kind,
whether express or implied. The purchaser undertakes

(1)

Contact your network operator to check service

availability.

24

that TCL Communication Ltd. has complied with all
quality obligations incumbent upon it as a manufacturer
of mobile devices and phones in complying with
Intellectual Property rights. TCL Communication Ltd.
will at no stage be responsible for the inability or
failure of the Third Party Materials to operate on
this phone or in interaction with any other device.
To the maximum extent permitted by law, TCL
Communication Ltd. disclaims all liability for any claims,
demands, suits or actions, and more specifically –
but not limited to – tort law actions, under any theory
of liability, arising out of the use, by whatever means, or
attempts to use, such Third Party Materials. Moreover,
the present Third Party Materials, which are provided
free of charge by TCL Communication Ltd., may be
subject to paid updates and upgrades in the future; TCL
Communication Ltd. waives any responsibility regarding
such additional costs, which shall be borne exclusively
by the purchaser. TCL Communication Ltd. shall not
be held responsible for the lack of availability of any
application, as its availability depends on the country
and the operator of the purchaser. TCL Communication
Ltd. reserves the right at any time to add or remove
Third Party Materials from its phones without prior
notice; in no event shall TCL Communication Ltd. be
held responsible by the purchaser for any consequences
of such removal.

25

Your mobile .............................

1

1.1 Keys and connectors

Front
camera

P/L
sensor

Front

ashlight

Charging
Led

Volume
up/down

Power key

Back

buon

Recent apps

buon

Home

buon

26

Back camera

Flashlight

Back button

• Touch to go back to the previous screen,
or close a dialog box, options menu, the
Notification panel, etc.

Home button

• From any application or screen, touch to
return to the Home screen.

27

• Long press to turn on Google Now. You
can get help such as getting directions and
restaurant information based on the content
detected on the screen.

Recent Apps button

• Touch to open a card view of applications
you've worked with recently.

Power key

• Press: Lock the screen/Light up the screen.

• Press and hold: Show the popup menu to

select from Power off/Restart/Aeroplane
mode.

• Press and hold the Power key and Volume
down key to take a screenshot.

• Press and hold the Power key for at least 10
seconds to force reboot.

Volume keys

• In call mode, adjusts the call volume.

• In Music/Video/Streaming mode, adjusts the

media volume.

• In general mode, adjusts the ringtone volume.

• Mutes the ringtone of an incoming call.

• In camera preview mode, press Volume up or

down key to take a photo or press and hold to
take a burst shot.

28

1.2 Getting started

1.2.1 Setting up

Inserting or removing the SIM/microSD card

Insert the pin into the hole and pull out the tray

1

Insert or remove your SIM card or microSD card

2

Single-SIM

2

1

Dual-SIM

2

SIM2/

SD

1

29

You must insert your SIM card to make phone calls. You
do not need to power off your phone before inserting
or removing the SIM card as this phone supports hot
swap.

Your phone only supports nano-SIM cards. Do
not attempt to insert other SIM types like mini
and micro cards; otherwise this may cause damage
to your phone.

Charging the battery

You are advised to fully charge the battery ( ). Charging
status is indicated by a percentage displayed on screen.
The percentage increases as the phone is charged.

To reduce power consumption and energy waste
when the battery is fully charged, disconnect your
charger from the plug; switch off Wi-Fi, GPS,
Bluetooth or background-running applications
when not in use; reduce the backlight time, etc.

30

1.2.2 Powering on your phone

Hold down the Power key until the phone powers on,
unlock your phone (Swipe, PIN, Password or Pattern) if
necessary and confirm. The Home screen is displayed.

If you do not know your PIN code or forget it, contact
your network operator. Be sure to keep your PIN code
safe.

1.2.3 Powering off your phone

Press and hold the Power key until options appear, then
select Power off.

1.3 Home screen

You can bring all the items (applications, shortcuts,
folders and widgets) you love or use most frequently
to your Home screen for quick access. Touch the Home
button to switch to the Home screen.

31

2

Status bar

1

1

3

4

5

6

7

• Status/Notification indicators

• Touch and drag down to open the Notification

panel.

Google Search bar

4

• Touch 2 to enter text search screen

• Touch 3 to enter voice search screen

Swipe left or right to view more screens

5

Favorite tray applications

6

• Enter the application.

• Long press to move or remove applications.

Enter the App drawer.

7

32

Reversible screen

The phone supports the reversible function. From
the Home screen, touch to open the App drawer,
then touch Settings > Display > Auto-rotate screen to
enable the function.

1.3.1 Status bar

From the Status bar, you can view both phone status
(on the right side) and notification information (on the
left side).

Drag down the status bar to view notifications and drag
again to enter the Quick settings panel.

Touch and drag up to close it. When there are
notifications, you can touch them to access notifications.

33

Notification panel

When there are notifications, touch and drag down the
Status bar to open the Notification panel to read more
detailed information.

1

2

3

Open the Quick Settings panel

1

Touch and drag down to open the Notification

2

panel.

Clear all notifications (ongoing notifications will

3

remain)

34

Quick Settings panel

Touch and drag down the notification panel to open
the Quick Settings panel. You can enable or disable
functions or change modes by touching the icons.

Open Settings, to view the full list
of settings.

35

1.3.2 Navigation bar

Touch to hide navigation bar.

1

Swipe up to display navigation bar.

2

1

2

1

36

1.3.3 Locking and unlocking your screen

To protect your phone and privacy, you can lock the
phone with a pattern, PIN, password or fingerprint, etc.

To create a screen unlock pattern

• From the Home screen, touch to open the App

drawer, then touch Settings > Security & location >
Screen lock.

• Set your own pattern.

To lock phone screen

Press the Power key once to lock the screen.

To unlock the phone screen

Press the Power key once to light up the screen, slide to
draw the unlock pattern you have created or enter your
PIN, password or fingerprint, etc.

If you have chosen Swipe as the screen lock, you can
press the Power key to light up the screen, then swipe
up to unlock the screen.

37

Swipe up to
unlock the screen

1.3.4 Personalising your Home screen

Add

You can long press a folder, an application or a widget
and drag the item to your preferred Home screen.

Reposition

Long press an item and drag it to the desired position
and then release. You can move items both on the
Home screen and the Favourite tray. Hold the icon on
the left or right edge of the screen to drag the item to
another Home screen.

38

Remove

Long press an item and drag it up to the top of the

Remove icon, then release.

Create folders

To improve the organisation of shortcuts or applications
on the Home screen and the Favourite tray, you can add
them to a folder by stacking one item on top of another.
To rename a folder, open it and touch the folder’s title
bar to input the new name.

Wallpaper customisation

Long press an empty area on the Home screen, then
touch WALLPAPERS to customise wallpaper.

1.3.5 Widgets and recently used applications

Consult widgets

Long press the empty area on the Home screen, then
touch WIDGETS to display all widgets.

Touch the selected widget and slide it to move to your
preferred screen.

Consult recently used applications

To consult recently used applications, touch the Recent
Apps button. Touch a thumbnail in the window to open

the application.

39

Touch one thumbnail and slide it right/left or touch X to
close an application.

Touch at the bottom of the screen to close all the
running applications.

1.3.6 Volume adjustment

Using the volume key

Press the Volume key to adjust the volume. To activate
the vibrate mode, press the Volume down key until the
phone vibrates.

40

Using the settings menu

From the Home screen, touch to open the App
drawer, then touch Settings > Sound to set the volume
for media, ringtones, alarms, etc.

41

Text input ................................ .

2

2.1 Using the onscreen keyboard

Onscreen keyboard settings

Go to Settings > System > Languages & input > Virtual
keyboard, touch the keyboard you want to set up and a

series of settings will become available.

Adjust the onscreen keyboard orientation

Turn the phone sideways or upright to adjust the
onscreen keyboard orientation. You can adjust it by
changing the settings (Touch Settings > Display > Auto-
rotate screen).

42

2.1.1 Gboard

1

3
4

5

Enter text or numbers.

1

Long press to select symbols.

2

Switch between "abc/Abc" mode; Long press to

3

2

switch to "abc/ABC" mode.

Switch to symbol and numeric keyboard.

4

Long press to show input options.

5

43

2.2 Text editing

You can edit the texts you entered.

• Long press or double tap within the texts you want
to edit.

• Drag the tabs to change the selected texts.

• The following options will show: CUT, COPY, SHARE

and SELECT ALL.

You can also insert new texts if preferred

• Touch where you want to type, or long press a blank
space, the cursor will blink and the tab will show.
Drag the tab to move the cursor.

• If you have cut or copied any text, touch the tab to
show PASTE which allows you to paste any text you
have previously copied.

44

Call, Call log and Contacts ...

3

3.1 Call ......................................................

3.1.1 Making a call

To make a call, touch in the Favourites tray.

1

2

5

Call log

1

Contacts

2

View the contact’s detailed information. You can

3

also edit, delete, share the contact, or send a
message to the contact.

3

4

45

Show the dial pad

4

Call the previewed number.

5

Long press to

access voicemail

Enter the desired number from the dial pad and touch

to place the call or select a contact from CONTACTS

or CALL LOG by sliding or touching tabs, then touch
to make the call.

The number you entered can be saved to Contacts by
touching the Create new contact icon or the Add to
a contact icon .

If you make a mistake, you can delete the incorrect
digits by touching .

To hang up a call, touch .

46

International call

To dial an international call, long press to enter “+”,
then enter the international country prefix followed by
the full phone number and touch .

Emergency call

If your phone has network coverage, dial the emergency
number and touch to make an emergency call. This
works even without a SIM card and without typing the
PIN code.

3.1.2 Answering or rejecting a call

47

When you receive a call, a call window will be presented
on top of the screen. Touch DECLINE to dismiss a call
or ANSWER to answer a call. Touch the call window to
open the Phone call screen.

On the Phone call screen:

• Touch to answer the call;

• Touch to reject the call;

• Touch to reject the call by sending a preset

message.

• Touch to set a call back reminder.

3.1.3 Calling your voicemail

Your voicemail is provided by your network to avoid
missing calls. It works like an answering machine that
you can consult at any time.

To access your voicemail, long press .

If you receive a voicemail, appears on the Status bar.
Open the Notification panel and touch New voicemail.

48

3.1.4 During a call

To adjust the volume during a call, press the Volume
key.

End the current call.

Touch once to activate the speaker during the

current call. Touch this icon again to deactivate the
speaker.

Touch once to mute the current call. Touch this icon

again to unmute the call.

Display the dial pad.

Touch once to hold the current call. Touch this icon

again to retrieve the call.

Touch to add another call.

49

Touch to open Contacts options.

To avoid accidental operation of the touchscreen
during a call, the screen will be locked automatically
when you put the phone close to your ear; and it
will be unlocked when the phone is taken away
from your ear.

3.1.5 Managing multiple calls

With this phone you can handle multiple calls at the
same time.

Swap calls

When you accept two calls, touch the contact name or
number to switch between two lines. The current call
will be put on hold and you are able to join the other
call.

Conference calls

(1)

You can set up a conference call as follows.

• Place a call to the first participant of the conference
call.

• Touch to add another call.

• Enter the phone number of the person you want to

add to conference and touch . You can also add
participants from Call log or Contacts.

(1)

Depending on your network operator.

50

• Touch to start the conference.

• Touch to end the conference call and disconnect

all callers.

3.1.6 Call settings

Touch from the Call screen, then touch Settings to
set phone and contacts.

3.2 Call log

You can access your call log by touching from the
Call screen to view missed calls, outgoing calls and
incoming calls.

Touch to view information or further operations, you
can launch a new call, send a message to the contact or
number, view detailed information of the call, or clear
the call.

51

Touch to Delete all history.

3.3 Contacts ............................................

Contacts enables quick and easy access to the contact

you want to reach.

You can view and create contacts on your phone and
synchronise them with your Gmail contacts or other
applications on the web or on your phone.

3.3.1 Consult your Contacts

To see your contacts, touch from the App drawer.

52

1

2

3

4

Display the contacts list option menu

1

Touch to search contacts

2

Open the Quick contact panel

3

Long press to select contact(s) to delete

Add new contact

4

Deleted contacts will also be removed from other
applications on the phone or web the next time
you synchronise your phone.

3.3.2 Adding a contact

Touch in the contact list to create a new contact.

53

You are required to enter the contact's name and other
contact information. By scrolling up and down the
screen, you can move from one field to another.

1

2

3

When finished, touch this icon to save

1

Select a picture or take a photo for the contact

2

Touch to open available labels

3

Add to/Remove from Favourites

(1)

To add a contact to favourites, you can touch a contact
to view details then touch to add the contact to
favourites.

(1)

Only phone contacts and account contacts can be added

to Favourites.

54

To remove a contact from favourites, touch the star
on the contact details screen.

3.3.3 Editing your contacts

To edit contact information, touch in the contact
details screen.

When finished, touch to save.

3.3.4 Use Quick contact for Android

Touch a contact to open Quick contact for Android. You
can then touch or the number to make a call. To send
a message, touch .

55

The icons available on the Quick contact panel depend
on the information you have for the contact and the
applications and accounts on your phone.

3.3.5 Importing, exporting and sharing contacts

This phone enables you to import or export contacts
between your phone, SIM card and phone storage.

From the Contacts screen, touch to open the options
menu. Touch Settings > Import/Export, then select to
import/export contacts from/to your accounts, SIM
card, Phone, internal storage, micro SD card, etc.

You can share a single contact or contacts with others
by sending the contact's vCard to them via Bluetooth,
Gmail, etc.

Touch the contact you want to share, touch and
Share from the contact details screen. Select the
number you want to share, touch , and then select
the application to perform this action.

3.3.6 Displaying contacts

You can configure which list of contacts, for each
account, you want to display in the Contacts list. Touch

and touch Contacts to display from contacts list

screen, then you can choose which contacts to display.

56

Touch and then Settings > Display options to sort
the list by touching First name or Surname, as well as
viewing contact names by touching First name first or

last name first.

3.3.7 Merging/Separating contacts

To avoid duplication, you can add any new contact
information to existing contacts in a single action.

Touch the contact which you want to add information
to, touch to enter the edit contact screen, touch
again and touch Link.

At this time, you are required to select the contact
whose information you want to merge with the first
contact. The information from the second contact is
added to the first one, and the second contact will no
longer be displayed in the Contacts list.

To separate contact information, touch the contact
whose information you want to separate, touch
to enter the edit contact screen, then touch again
and touch View linked contacts, Touch SEPARATE to
confirm.

57

3.3.8 Synchronising contacts in multiple

accounts

Contacts, data or other information can be synchronised
from multiple accounts, depending on the applications
installed on your phone.

To add an account, touch from the contacts list and
touch Settings > Manage accounts, or from the Home
screen, touch , then Settings > Users & accounts >
Add account.

You are required to select the kind of account you are
adding, like Google, Corporate, etc.

As with other account setups, you need to enter
detailed information, like username, password, etc.

You can remove an account and all associated
information from the phone. Touch the account you
want to delete > Touch > Select Remove account >
Confirm.

Auto-sync

On the Accounts screen, touch and mark the Auto­sync data checkbox. When activated, all changes to

information on the phone or online will be automatically
synchronised with each other.

58

Messaging ...........................

4

4.1 Write a new message

You can create, edit and receive SMS and MMS with
this phone.

To access Messaging, touch .

On the message list screen, touch to write text/
multimedia messages.

1

2

More options

1

Send the text message

2

59

Sending a text message

To add recipients, enter the name or phone number of
the recipient. Touch the Type an SMS message bar to
enter the text of the message. When finished, touch
to send the text message.

An SMS message of more than 160 characters will be
charged as several SMS. There is a counter on the right
of the text box to remind you how many characters are
allowed to be entered in one message.

Specific letters (accented) will also increase the
size of the SMS. This may cause multiple SMS to
be sent to your recipient.

Sending a multimedia message

MMS enables you to send video clips, images, photos,
animations, slides and sounds to other compatible
mobiles and email addresses.

An SMS will be converted to MMS automatically when
media files (image, video, audio, etc.) are attached or
subject or email addresses are added.

To send a multimedia message, enter the recipient's
phone number. Touch the Type message bar to enter
the text of the message.

60

Touch to open the options menu. Touch Add subject
to insert a subject. Touch to attach a picture, video,
audio, etc.

When finished, touch to send the multimedia
message.

4.2 Manage messages

When receiving a message, will appear on the Status
bar as a notification. Drag down the Status bar to open
the Notification panel. Touch the new message to
open and read it. You can also access the Messaging
application and touch the message to open it.

Messages are displayed as a conversation.

Touch a message to enter the message composing
screen:

61

• Touch to call the number;

• Touch to save the number to contacts or view the

contact details if the number has been saved;

• To reply to a message, enter the text or touch to
insert quick text, contact, etc. When finished, touch

.

• If you long press a message, the following options will
be available: Copy , Forward , View message
details , Delete , Return , other options menu

, etc.

62

4.3 Adjust message settings

On the message list screen, touch and select
Settings.

• GENERAL

Storage, Notifications, WAP push messages, Cell
Broadcast settings etc. can be set in General settings.

• ADVANCED

Text message (SMS) settings and Multimedia
message (MMS) settings can be set in Advanced

settings.

63

Calendar, Clock, and

5

Calculator .................................

5.1 Calendar .............................................

You can use Calendar to keep track of important
meetings, appointments, etc.

To view the calendar and create events, touch from
the Home screen, then touch Calendar.

5.1.1 Multimode view

You can display the Calendar by Schedule, Day, 3-day,
Week, or Month, touch to select.

5.1.2 To create new events

You can add new events from any Calendar view.

• Touch .

• Fill in all required information for this new event. If it

is a whole-day event, you can select All-day.

• Invite guests to the event. Enter the email addresses
of the guests you want to invite with commas to
separate. The guests will receive an invitation from
Calendar and Email.

64

• When finished, touch SAVE from the top of the
screen.

To quickly create an event from the Week view screens,
touch an empty spot to select a target area which will
then turn , then touch the icon to create the new
event.

5.1.3 To delete or edit an event

To delete or edit an event, touch the event to enter its
details screen. Touch to edit the event, or touch
and then Delete to delete.

5.1.4 Event reminder

If a reminder is set for an event, the upcoming event
icon will appear on the Status bar as a notification
when the reminder time arrives.

Touch and drag down the Status bar to open the
Notification panel and touch an event name to view the
Calendar notification list.

Touch the Back button to keep the reminders pending
in the Status bar and the Notification panel.

65

5.2 Clock ..................................................

Your mobile phone has a built-in clock.

To view the current time, touch from the Home
screen, then touch Clock.

5.2.1 World clock

To view the world clock, touch on the Time screen.

Touch to add a time zone.

5.2.2 Alarm

From the Time screen, touch to enter the ALARM
screen.

Turn on to enable the alarm.

Touch to add a new alarm:

Touch a currently existing alarm to enter the alarm
editing screen.

Touch to delete the selected alarm.

66

5.2.3 Countdown

From the Time screen, touch to enter the TIMER
screen.

• Enter the time. The time should be typed in second,
minute and hour number sequence.

• Touch to start the countdown.

Pause/play

67

5.2.4 STOPWATCH

From the Time screen, touch to enter the
STOPWATCH screen.

• Touch to start the Stopwatch.

• Touch LAP to show a list of records according to the

updated time.

• Touch to halt the total and lap times. These will
only restart after is touched.

• Touch RESET to delete the record.

• Touch SHARE to share.

5.2.5 Adjust Clock settings

Touch and then Settings to access Clock and Alarms
settings.

68

5.3 Calculator .........................................

There are two panels available: Basic panel and
Advanced panel.

To switch between panels, select one of the following
two ways:

• Swipe the basic calculation screen to the left to open
the scientific calculation.

• Turn the phone to the landscape orientation from
the basic panel to open the scientific calculation.
This option is only available if Settings > Display >
Auto-rotate screen is on.

Touch to delete digits one by one, or long press
to delete all at once.

69

Getting connected .................

6

To connect to the internet with this phone, you can use
GPRS/EDGE/3G/4G networks or Wi-Fi, whichever is
most convenient.

6.1 Connecting to the internet

6.1.1 GPRS/EDGE/3G/4G

The first time you turn on your phone with your
SIM card inserted, it will automatically configure your
network service: GPRS, EDGE , 3G or 4G.

If the network is not connected, you can turn on mobile
data in Settings > Network & connection > Data usage.

To check the network connection you are using, touch

Settings > Network & connection > Mobile network >
Access Point Names or Network operators.

To create a new access point

A new GPRS/EDGE/3G/4G network connection can be
added to your phone with the following steps:

• Touch Settings > Network & connection > Mobile
network > Access Point Names.

• Touch and enter the required APN information.

70

• When finished, touch and then Save.

To enable data roaming

• Touch Settings > Network & connection > Mobile
network > Data roaming.

• When data roaming is disabled, you can still perform
data exchange with a Wi-Fi connection (refer to

"6.1.2 Wi-Fi").

To set preferred network mode

• Touch Settings > Network & connection > Mobile
network > Preferred networks.

6.1.2 Wi-Fi

You can connect to the internet when your phone is
within range of a wireless network. Wi-Fi can be used
on your phone even without a SIM card inserted.

To turn Wi-Fi on and connect to a wireless network

• Touch Settings > Network & connection > Wi-Fi.

• Turn on .

• Once Wi-Fi is turned on, detected Wi-Fi networks

are listed.

71

• Touch a Wi-Fi network to connect to it. If the
network you selected is secured, you are required
to enter a password or other credentials (you may
contact the network operator for details). When
finished, touch CONNECT.

To enable notification when a new network is detected

When Wi-Fi is on and the network notification is
activated, the Wi-Fi icon will appear on the Status
bar whenever the phone detects an available wireless
network within range. The following steps activate the
notification function when Wi-Fi is on:

• Touch Settings > Network & connection > Wi-Fi.

• Touch .

• Turn on Network notification .

To add a Wi-Fi network

When Wi-Fi is on, you may add new Wi-Fi networks
according to your preference.

• Touch Settings > Network & connection > Wi-Fi.

• Touch Add network.

• Enter the name of the network and any required

network information.

• Touch SAVE.

72

To forget a Wi-Fi network

The following steps prevent automatic connections to
networks which you no longer wish to use.

• Turn on Wi-Fi, if it’s not already on.

• On the Wi-Fi screen, touch the name of the saved

network.

• Touch FORGET in the dialog that opens.

6.2 Connecting to a Bluetooth device

(1)

Bluetooth is a short-range wireless communication
technology that you can use to exchange data, or
connect to other Bluetooth devices for various uses.

To turn on Bluetooth

• Touch Settings > Network & connection > Bluetooth.

• Turn on Bluetooth .

Your device name and other available devices will
appear on screen.

(1)

You are recommended to use alcatel Bluetooth headsets,

which have been tested and proved compatible with your
phone. You can go to www.alcatelmobile.com for more
information about the alcatel Bluetooth headset.

73

To rename your device

• Touch Settings > Network & connection > Bluetooth.

• Touch Device name.

• Enter a name, and touch RENAME to confirm.

To pair/connect your phone with a Bluetooth device

To exchange data with another device, you need to turn
Bluetooth on and pair your phone with the Bluetooth
device with which you want to exchange data.

• Touch Settings > Network & connection > Bluetooth.

• Touch + Pair new device.

• Touch a Bluetooth device you want to pair your

phone with in the list.

• In the dialog that pops up, touch PAIR to confirm.

• If the pairing is successful, your phone will be

connected to the device.

To disconnect/unpair from a Bluetooth device

• Touch beside the device you want to unpair.

• Touch FORGET to confirm.

74

6.3 Connecting to a computer via USB

With a USB cable, you can transfer media files and
other files between your phone and a computer.

To connect your phone to the computer

Use the USB cable that came with your phone to
connect the phone to a USB port on your computer. You
will receive a notification that the USB is connected.

Open the Notification panel and touch USB for file
transfer, then, in the next dialogue, choose the way in
which you want to transfer files. By default, Charging
is selected.

Before using MTP, make sure that the driver
(Windows Media Player 11 or higher version) has
been installed.

6.4 Sharing your phone's mobile data

connection

You can share your phone's mobile data connection
with a single computer via a USB cable (USB tethering)
or with up to four devices at once via Bluetooth
(Bluetooth tethering) or Wi-Fi (mobile hotspot).

The functions below may incur additional network
charges from your network operator. Extra fees
may also be charged in roaming areas.

75

To share your phone's data connection via USB and
Bluetooth, or as a mobile hotspot

Go to Settings > Network & connection > Hotspot &
tethering to activate these functions.

To rename or secure your mobile hotspot

When mobile hotspot is activated, you can rename
your phone's Wi-Fi network (SSID) and secure its Wi-Fi
network.

• Touch Settings > Network & connection > Hotspot
& tethering > Mobile hotspot.

• Touch Set up mobile hotspot to rename the network
SSID or set your network security.

• Touch SAVE.

6.5 Connecting to virtual private

networks

Virtual private networks (VPNs) allow you to connect
to the resources inside a secured local network from
outside that network. VPNs are commonly deployed
by corporations, schools, and other institutions so
that their users can access local network resources
when not inside that network, or when connected to a
wireless network.

76

To add a VPN

• Touch Settings > Network & connection > VPN and
then touch .

• On the screen that opens, follow your network
administrator's instructions to configure each
component of the VPN settings.

• Touch SAVE.

The VPN is added to the list on the VPN settings screen.

Before adding a VPN, you should set a PIN code
or password for your phone.

To connect/disconnect to/from VPN

To connect to a VPN:

• Touch Settings > Network & connection > VPN.

• The VPNs you have added are listed. Touch the VPN

you want to connect with.

• In the dialog that opens, enter any requested
credentials and touch CONNECT.

To disconnect from a VPN:

• Touch the VPN you want to disconnect from. In the
dialog that opens, touch DISCONNECT.

To edit/delete a VPN

To edit a VPN:

• Touch Settings > Network & connection > VPN.

77

• The VPNs you have added are listed. Touch the
icon next to the VPN you want to edit.

• After editing, touch SAVE.

To delete a VPN:

• Touch the icon next to the selected VPN, then
touch FORGET to delete it.

78

Multimedia applications .......

7

7.1 Camera ..............................................

Your mobile phone is fitted with a camera for taking
photos and videos.

Before using the camera, make sure that you remove
the protective lens cover to avoid it affecting your
picture quality.

To take a photo or video, touch from the Home
screen and then touch Camera.

3

4

5

6

7

1

2

79

Flash mode

1

Touch to turn on/off the camera flash.

Switch between front/back camera

2

Filter button

3

Touch to preview the viewfinder with live filter
applied. Touch any filter to apply filter and return to
the previous screen.

Touch the screen to focus

4

Pinch/spread two fingers together/apart to zoom

5

out/in

View the photos or videos you have taken

6

Take a photo

7

To take a photo

The screen acts as the viewfinder. First, position the
object or landscape in the viewfinder, touch the screen
to focus if necessary and touch to capture. The
photo will be automatically saved. You can also long
press to take burst shots.

80

To take a video

Touch the right part of this icon to change the
camera mode to video, then touch the left part of this
icon to start video recording. You can also touch
the left part of this icon to take a picture during
video recording.

Touch to pause video recording and touch to
continue. Touch to stop recording. The video will be
automatically saved.

Further operations when viewing a picture/video you
have taken

• Slide left or right to view the photos or videos you
have taken.

• Touch , then Gmail/Bluetooth/MMS/etc. to share
the photo or video.

• Touch to return to Camera.

81

7.1.1 Modes and settings

Touch to switch between modes.

• Auto

Auto is the default mode for Camera.

• Pano

Touch to turn on panorama function. Touch the
shutter button to start taking panoramic photo
and move the phone steadily along the direction
indicated by the onscreen line. Once the slots are
filled, the photo will be automatically saved. If the
slots are not fully filled, touch the shutter button
again to save the photo.

• Time-lapse

Capture a series of photos and convert them into a
sped up time-lapse video.

• Social

• Light trace

Settings

• Grid

Turn on to enable grid view. It divides the screen
into equal parts and helps you take better photos
by making it simple to align elements, such as the
horizon or buildings, to the lines in the grid.

82

• Video stabilisation (EIS)

Turn on to enable the Electronic Image
Stabilization (EIS) feature. It helps reduce blurring
associated with the motion of a camera during
exposure.

• Save location information

Turn on to tag photos and videos with your
location. This option is available when the GPS
location service is enabled.

7.2 Photos ...............................................

Photos acts as a media player for you to view photos
and play videos. In addition, a set of further operations
to pictures and videos are available for your choice.

To view the photos you have taken, touch from the
Home screen, then touch Photos.

83

7.2.1 Playing music

Touch a song to play.

4

Search for a song.

1

Access more functions.

2

Play or pause.

3

Access the menu.

4

1

2

3

While playing songs with Music, the operation of
pause, play or skip is still available even if the
screen is locked.

84

8

Others ...................................

8.1 File Manager ....................................

To manage the files in your phone, touch from the
Home screen, then touch File Manager.

File Manager works with both external SD card and
internal storage.

File Manager displays all data stored on the phone,
including applications, media files downloaded from
Google Play Store, YouTube or other locations; videos,
pictures or audios you have captured; other data
transferred via Bluetooth, USB cable, etc.

When you download an application from PC to phone,
you can locate the application using Files, then touch it
to install it in your phone.

85

8.2 Radio ..................................................

Your phone is equipped with a radio

(1)

with RDS

(2)

functionality. You can use the application as a traditional
radio with saved channels or with visual information
related to the radio program displayed if you turn to
stations that offer Visual Radio service.

To listen to a radio programme, touch from the
Home screen, then touch Radio.

6

7

8

9

Touch to open and view the saved channels list.

1

(1)

The quality of the radio depends on the coverage of the

radio station in that particular area.

(2)

Depending on your network operator and market.

1

2

3

4

5

86

Touch to add the current station to favorites.

2

Drag to change current frequency.

3

Touch to increase 0.1MHz. Long press to search and

4

go to the nearest higher frequency channel.

Touch to go to next saved channel.

5

Touch to enable/disable the loudspeaker.

6

Touch to decrease 0.1MHz. Long press to search

7

and go to the nearest lower frequency channel.

Touch to go to previous saved channel.

8

Touch to play/stop.

9

To listen to the radio you must insert headphones.
Headphones act as radio antenna.

Available options:

• Save channels

Touch to add the current station to favorites. It will
disappear if the current channel has been saved.

• Scan channels

Touch to search for channels.

• Edit name

Touch to name the channel.

• Delete

Delete the channel.

87

• Enter frequency

Enter the frequency manually to turn to the channel.

• Station info

Mark the checkbox to display station information.

• Exit

Turn off the radio.

8.3 Other applications

(1)

The previous applications in this section are preinstalled
on your phone. To read a brief introduction of the
preinstalled 3rd party applications, refer to the leaflet
provided with the phone. To download and install
more 3rd party applications, use the Google Play Store
application.

(1)

Application availability depends on country and operator.

88

9

Google apps are preinstalled on your phone to improve
work efficiency and help you enjoy life.

This manual briefly introduces the apps. For detailed
features and user guides, refer to related websites or
the introduction provided in the apps.

You are recommended to register with a Google account
to enjoy all the functions.

Google applications ...........

9.1 Chrome

A web browser with which you can surf the internet.

Your bookmarks, browsing history, and settings
across all devices with the browser installed can be
synchronised with your Google account.

9.2 Gmail

As Google's web-based email service, Gmail is
configured when you first set up your phone. With this
application, you can send and receive emails, manage
emails by labels, archive emails, etc. Emails can be
automatically synchronised with your Gmail account.

89

9.3 Maps

Google Maps offers satellite imagery, street maps, 360°
panoramic views of streets, real-time traffic conditions,
and route planning for traveling by foot, car, or public
transportation. By using this application, you can get
your own location, search for a place, and get suggested
route planning for your trips.

9.4 YouTube

YouTube is an online video-sharing application where
users can upload, view, and share videos. Available
content includes video clips, TV clips, music videos,
and other content such as video blogging, short original
videos, and educational videos. It supports a streaming
function that allows you to start watching videos almost
as soon as they begin downloading from the internet.

9.5 Play Store

Serves as the official app store for the Android operating
system, allowing users to browse and download
applications and games. Applications are either free of
charge or at a cost.

In Play Store, search for the app you need, download it
and then follow the installation guide to install the app.
You can also uninstall, update an app, and manage your
downloads.

90

9.6 Drive

A file storage and synchronisation service created by
Google, which allows users to store files in the cloud,
share and edit files.

Files in Drive are kept secure and can be accessed from
any device by logging in to your Google account. Files
or folders can be shared privately with other Google
account users.

9.7 Play Music

A music streaming service and online music locker
operated by Google.

You can upload and listen to a large number of songs
for free. In addition to offering music streaming for
internet-connected devices, the Google Play Music app
allows music to be stored and listened to offline. Songs
purchased through Play Music are automatically added
to the user's account.

9.8 Duo

A video chat mobile app.

With phone numbers verified, users can easily video
call people from their contact list.

91

9.9 Photos

Google Photos stores and backs up your photos and
videos. It also automatically analyses photos and
organises them into groups, so that you can quickly
find the photos you need.

9.10 Keep

A note taking application developed by Google.

You can insert images, lists, and record voice in your
notes. You can also set time or location-based reminders
for notes. Google Keep allows you to categorise notes
by labels, and notes are searchable based on their
colour, whether they have reminders, audio, images, or
lists.

92

10

To go to Settings, touch from the Home screen, then
touch Settings.

Settings ............................

10.1 Network & connection

10.1.1 Wi-Fi

Using Wi-Fi you can access the internet without using
your SIM card whenever you are in range of a wireless
network. The only thing you have to do is to enter the
Wi-Fi screen and configure an access point to connect
your phone to the wireless network.

For detailed instructions on using Wi-Fi, refer to "6.1.2

Wi-Fi".

10.1.2 Bluetooth

Bluetooth allows your phone to exchange data (videos,
images, music, etc.) within a small range with another
Bluetooth supported device (phone, computer, printer,
headset, car kit, etc.).

For more information on Bluetooth, refer to "6.2
Connecting to a Bluetooth device".

93

10.1.3 Mobile network

You can set Data roaming, Preferred networks,
Preferred network type, Access Point Names, and
Network operators in this menu.

10.1.4 Tethering&portable hotspot

This function allows you to share your phone's mobile
data connection via USB or as a portable Wi-Fi access
point (refer to "6.4 Sharing your phone's mobile data

connection").

10.1.5 SIM cards

Touch to choose SIM 1 or SIM 2
the network, making calls and sending SMS messages.

(1)

for connecting to

10.1.6 VPN

For more information on VPN, refer to "6.5 Connecting
to virtual private networks".

10.1.7 Aeroplane mode

Turn on Airplane mode to simultaneously disable
all wireless connections including Wi-Fi, Bluetooth and
more.

(1)

Only for 5052D.

94

10.1.8 Data usage

Data saver

By enabling Data saver, you can reduce data usage by
preventing some apps from sending or receiving data in
the background.

Cellular data

If you do not need to transmit data on mobile networks,
turn off Mobile data to avoid incurring significant
charges for data use on local operator mobile networks,
particularly if you do not have a mobile data agreement.

Data usage is measured by your phone, and your
operator may count differently.

10.2 Apps & notifications

Touch to view details about the applications installed
on your phone, to manage their data usage or force
them to stop.

In the Notifications menu, you can configure whether
to block the notifications from this app, hide sensitive
content, etc.

In the App Permissions menu of an application, you can
grant permissions for the app, such as allowing the app
to access your Camera, Contacts, Location, etc.

95

10.3 Battery

Touch any category in the battery management screen
to view its power consumption.

10.4 Smart Manager

Turn on to restict auto-start of certain apps.

10.5 Display

In this menu, you can adjust your screen brightness,
wallpaper, sleep time, font size, etc.

To rotate screen contents when device is rotated, touch

Auto-rotate screen.

10.6 Sound

Touch to adjust call and notification ringtones, music,
and other audio settings.

10.7 Security & location

Touch to set Screen lock , Fingerprint sensor, lock
screen preferences, Face key, Smart lock , Private
mode, Apps lock , Encrypt phone, SIM card lock,
Device administrators, Storage type, etc.

96

10.8 Advanced Features

10.8.1 Duraspeed

Duraspeed helps boost the foreground app by
restircting background apps; some notifications may be
postponed or not received. Turn on to allow apps
running in the background.

10.8.2 Press power button twice for camera

Turn on , so that you can quickly open camera
without unlocking your screen.

10.8.3 Gestures

Touch to set gestures for screenshot, Camera.

10.8.4 Func shortcuts

Touch to customise the application shortcuts displayed
on your lock screen.

10.9 Users & accounts

Touch to add, remove, and manage your email and
other supported accounts. You can also use these
settings to control how and whether all applications
send, receive, and synchronise data on their own
schedules, and whether all applications can synchronise
user data automatically.

97

Touch Add account to add an account for the selected
app.

10.10 Accessibility

Use the Accessibility settings to configure any
accessibility plug-ins you have installed on your phone.

10.11 Google

Touch to configure your Google account and services
settings.

10.12 System

10.12.1 Language & input

Touch to configure language settings, the on-screen
keyboard, voice input settings, pointer speed, etc.

10.12.2 Date & time

Use Date & time settings to customise your preferences
for how date and time are displayed.

98
