APZ1-300
Shower drain with an edge for perforated grids
Application
For wheelchair access
For drainage of floor-level showers
For installation into open spaces or near the wall of the shower area
For perforated stainless steel grids
For indoor use
Features
The collar and trap are protected by foil, and the channel itself by a polystyrene
insert
Trap material: polypropylene
Material of shower drain: stainless steel 2 mm, AISI 304, DIN 1.4301, EN1253-1
Mechanically cleanable trap up to the waste pipe
Possibility to buy a combined odour trap
Linear drain from stainless steel (hardened by pickling, passivation and
electrochemical polishing)
Self-adhesive waterproofing tape for quality waterproofing
The trap is firmly connected to the drain channel - 100% waterproofing
Installation height from 85 mm
Adjustable height
The high flow rate is achieved due to the double compartment trap system
25 years guarantee
Scope of supply
Anchoring set for fixing the adjustable legs: screw M6×12 - 2 pcs
Installation channel cover
Anchoring set: screw Ø6×50 - 2 pcs, dowel Ø10 - 2 pcs
The collar and the odour trap inlet are covered by the protective foil
Self-adhesive waterproofing tape
The shower drain is assembled with the odour trap
Order number, Logistic information
Code EAN (piece | packing)(kus | packing | palett) (packing | palett)
APZ1-300 8594045939194 300 mm 1,8560 | 17,5932 | 301,4912 kg 385×130×175 | mm 9 | 144 pcs
Guarantee
2/25 years
Technical specifications
Total installation height 100-158 mm
Minimum thickness of concrete 85 mm
Resistance of odour trap against the pressure 982 Pa
Waste pipe diameter 50 mm
Flow rate 60-68,8 l/min
Load class K3 300 kg
Odour trap 50 mm
Customs code
39229000
Norms
EN 1253
Weight Dimensions Quantity
© 2019 Alca plast, s. r. o. Changes in dimensions and design reserved. www.alcaplast.com 1
