System II Tray Transport Cart
Model Numbers
20-Tray Transport Cart Model G101099
Description
An enclosed, non-insulated cart used with System II trays. It can be
used to transport trays of plated food sent in a truck prior to retherm,
trays of food after retherm, and soiled trays being returned to a
dishroom.
Specifications
All construction is riveted, welded and finished.
CABINET EXTERIOR: One-piece 18 ga., 304 stainless steel top.
Extruded aluminum channel posts, 7/8 x 2-1/4 x .102 welded to
base. Back panel fitted into posts, riveted to top and reinforced.
Tie rod applied at front. Pan stop channels riveted to inside rear of
cabinet and door. 1” non-marking rubber bumper around perimeter.
Push/pull handles of 1” dia. Aluminum tubing mounted vertically to
rear of cabinet.
CABINET BASE/INTERIOR: One-piece base of 190 aluminum.
Casters: 6” dia. Casters with poly-loc tires, 2” wide, 800 lbs load
capacity each, temperature range: -30˚ to 180˚F, Zerk fittings in hubs.
Two casters are rigid and two are swivel with brakes.
model G101099
PAN SLIDES (20): 18 ga. angles, 304 stainless steel; 1” x 2”; riveted
to side panels on 4-1/2” centers.
DOOR: Formed 20 ga., 304 stainless steel panel. 3/8” x 1-1/2”
extruded reinforcement bars; riveted horizontally to top, center and
bottom. Gravity type latch, stainless steel with staple for a hasp lock.
Door swings 270˚ on stainless steel butt hinges, riveted to posts and
door panel. Card clip.
Capacity
Cart holds 20 System II trays (14” x 18”).
Dimensions (WxLxH)
• 23” x 34-1/4” x 60-1/8”
• Weight: 155 lbs.
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Please reference our website for the most
updated product information and specifications.
A la Cart, Page 6
SYSIITC 157480 Rev. A
Created 11/11
Model G101099
23
34-1/4
1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
© 2011 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of
Dover Corporation.
