PROJECT NAME:
LOCATION:
ITEM NO:
HANDLING & STORAGE EQUIPMENT
HIGH VALUE TRAY CART
AVAILABLE MODELS:
ALC HVTCA-20
ALC HVTCA-24
ALC HVTCSS-20
ALC HVTCSS-24
STANDARD FEATURES:
• Dual, vertical push/pull handles are mounted on rear of
cart
• Full perimeter bumper is attached to cart base
assembly
• 5” ledge spacing
• Non-insulated, non-heated cart
• Cart has 6” diameter cushion casters with zerk fittings
(2 swivel casters - 2 with brake)
• Customization available
QTY:
MODEL NO:
AIA NO:
SIS NO:
CSI SECTION:
ALC HVTC Model shown.
CONSTRUCTION: Stainless steel is nickel-bearing,
200 series minimum.This material is NSF recognized for
corrosion resistance. Body available in .063 aluminum
or 18 gauge premium stainless steel. Base is made from
.125 aluminum or 14 gauge stainless steel.
DOORS: Single door design with full length stainless
steel hinge and heavy duty stainless steel gravity latch.
Doors open a full 270 degrees and lay neatly against
side of cart. Door is made of .090 aluminum or 16
gauge stainless steel.
TRAY SLIDES: Contour seemless tray slides are
easily removable for better cleaning. Available for 13-1/2”
x 23” or 14” x 18” trays. Tray size must be specified with
order. Ledges are 1-3/16” wide. 5” ledge spacing.
ORIGIN OF MANUFACTURE: Designed and
manufactured in the United States.
H&S EQUIPMENT
PP SPECALCHVTC RevA
Revised 12/14
ALC HVTC
Model No.
Height
13-1/2” x 23”
Width
Depth
14” x 18”
Width
Depth
Caster Type
Caster Diameter
Construction
Trays
Ship Wt. (lbs)
Model No.
Height
13-1/2” x 23”
Width
Depth
14” x 18”
Width
Depth
Caster Type
Caster Diameter
Construction
Trays
Ship Wt. (lbs)
ALC HVTCA-20 ALC HVTCA-24
60-1/8” 70-1/8”
30-3/8” 30-3/8”
33-3/8” 33-3/8”
24-3/4” 24-3/4”
32-3/4” 32-3/4”
4 Swivel, 2 w/Brake 4 Swivel, 2 w/Brake
6” 6”
Aluminum Aluminum
20 24
140 155
ALC HVTCSS-20 ALC HVTCSS-24
60-1/8” 70-1/8”
30-3/8” 30-3/8”
33-3/8” 33-3/8”
24-3/4” 24-3/4”
32-3/4” 32-3/4”
4 Swivel, 2 w/Brake 4 Swivel, 2 w/Brake
6” 6”
Stainless Steel Stainless Steel
20 24
220 250
