Important Safety Instruction
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrow head within a triangle is intended to tell the user that
parts inside the product are a risk of electric shock to persons.
The exclamation point within a triangle is intended to tell the user that important
operating and servicing instructions are in the papers with the appliance.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
2
Warnings And Cautions
Do not drop or push obje cts into the television cabinet slots
or openings. Never s pill any kind of liquid on the television
receiver.
Do not insert anythi ng in the ventilation holes. If metal or
something flamma ble enters, it may result in fire or electric s hock.
Caution
Caution
Caution
Do not place your tele vision on an unstable cart , stand , shelf or
table. Serious inj ury to an individual, and damage to the television,
may result if it should fall.
Caution
Do not block the ventilation holes in the back cover.
Adequate ventila tion is essential to prevent failure of ele ctrical
component.
Warning
To prevent fire or electrical shock hazard, Do not expose the
television recei ver to rain or moisture.
3
Functional Parts( TV )
Front View of LED Set
1.
Remote Sensor
2. LED indicator lamp
1
To turn the TV power ON
Put the TV set on the correct place, then connect the DC plug of the AC-DC adaptor to the D C 12V socket
at the back of the TV set. Connect the adaptor main cord to the wall outlet ,then the LE D indicator lamp
turns red/blue and the TV set is at Standby/work Mode. At Standby Mode, if Standb y Button is pressed
the power indicato r will change to blue. It will flash a few seconds before the picture appears.
To turn the TV power OFF
Press the Standby Button to make the TV set in Standby Mode, then disconnect the p ower plug from the
wall outlet.
NOTE:
If TV is the selected input without signal received and NO operation is perfor med for about 5 minutes
continuously, the TV set will enter standby mode. For any inputs other than TV, the TV set will not enter
standby mode autom atically without users instruction. I f you are not going to use this TV set for a long
time, switch off the set and disconnect the power plug from the wall outlet.
2
4
Rear View Of TV Set
Back View of LED Set
1. Standby Button
2. SOURCE Button
MENU Button
3. P+ Button
P- Button
4. V+ Button
V- Button
NOTE:
Precautions when connecting to other equipment.
When using external equipment with this TV set, please read the instruction manual of the external
equipment.
Switch off all power supplies to the equipment and TV set before connection.
Always ensure that the input and output terminals are correctly connected.
The UPDATE terminals just use to update the system software.
①
②
③
④
