Aiwa XR-X7 Service Manual

XR-X7

EZ, K, U

SERVICE MANUAL

COMPACT DISC

STEREO SYSTEM

• Replace this Service manual with “Revision Publishing” when it is issued.

BASIC CD MECHANISM : DA11B3

S/M Code No. 09-015-445-8T1

SIMPLE

DATA

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O ACCESSORY 87-006-225-010 1D ANT,LOOP ANT NC2 EZSM CX-SLX7
O ACCESSORY 87-006-225-010 1D ANT,LOOP ANT NC2 KSM CX-SLX7
O ACCESSORY 87-006-225-010 1D ANT,LOOP ANT NC2 USM CX-SLX7
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM USM CX-SLX7
O ACCESSORY 87-A90-118-010 0E ANT,WIRE FM(Z) EZSM CX-SLX7
O ACCESSORY 87-A90-118-010 0E ANT,WIRE FM(Z) KSM CX-SLX7
O ACCESSORY 8B-CL2-961-010 1H RC UNIT,RC-BAT01(B/S) EZSM CX-SLX7
O ACCESSORY 8B-CL2-961-010 1H RC UNIT,RC-BAT01(B/S) KSM CX-SLX7
O ACCESSORY 8B-CL2-961-010 1H RC UNIT,RC-BAT01(B/S) USM CX-SLX7
X APPEARANCE 8A-CQ0-043-010 0E CUSH,TOP EZSM CX-SLX7

X APPEARANCE 8A-CQ0-043-010 0E CUSH,TOP KSM CX-SLX7
X APPEARANCE 8A-CQ0-043-010 0E CUSH,TOP USM CX-SLX7
O APPEARANCE 8B-CL2-001-010 1C CABI,FR KSM CX-SLX7
O APPEARANCE 8B-CL2-004-010 1C CABI,FR U USM CX-SLX7
O APPEARANCE 8B-CL2-005-010 1E CABI,TOP U USM CX-SLX7
X APPEARANCE 8B-CL2-006-110 1D CABI,BOTTOM U USM CX-SLX7
O APPEARANCE 8B-CL2-008-010 1C CABI,FR EZ EZSM CX-SLX7
O APPEARANCE 8B-CL2-009-010 0E CAP, TOP EZSM CX-SLX7
O APPEARANCE 8B-CL2-009-010 0E CAP, TOP KSM CX-SLX7
O APPEARANCE 8B-CL2-009-010 0E CAP, TOP USM CX-SLX7

O APPEARANCE 8B-CL2-010-010 2M WINDOW,FR EZSM CX-SLX7
O APPEARANCE 8B-CL2-010-010 2M WINDOW,FR KSM CX-SLX7
O APPEARANCE 8B-CL2-010-010 2M WINDOW,FR USM CX-SLX7
O APPEARANCE 8B-CL2-013-110 1A ARM,OPEN R EZSM CX-SLX7
O APPEARANCE 8B-CL2-013-110 1A ARM,OPEN R KSM CX-SLX7
O APPEARANCE 8B-CL2-013-110 1A ARM,OPEN R USM CX-SLX7
O APPEARANCE 8B-CL2-014-110 1A ARM,OPEN L EZSM CX-SLX7
O APPEARANCE 8B-CL2-014-110 1A ARM,OPEN L KSM CX-SLX7
O APPEARANCE 8B-CL2-014-110 1A ARM,OPEN L USM CX-SLX7
O APPEARANCE 8B-CL2-028-010 1 PANEL,REAR USM USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O APPEARANCE 8B-CL2-030-010 1B PANEL,REAR KSM KSM CX-SLX7
O APPEARANCE 8B-CL2-031-010 1B PANEL,REAR EZSM EZSM CX-SLX7
X APPEARANCE 8B-CL2-034-010 1A COVER, HT-SINK EZSM CX-SLX7
X APPEARANCE 8B-CL2-034-010 1A COVER, HT-SINK KSM CX-SLX7
X APPEARANCE 8B-CL2-038-010 1A COVER, HT-SINK U USM CX-SLX7
O APPEARANCE 8B-CL2-040-010 1E CABI,TOP EZSM CX-SLX7
O APPEARANCE 8B-CL2-040-010 1E CABI,TOP KSM CX-SLX7
X APPEARANCE 8B-CL2-041-010 1E CABI,BOTTOM KSM CX-SLX7
O APPEARANCE 8B-CL2-042-110 1E CABI,BOTTOM EZ EZSM CX-SLX7
O APPEARANCE 8B-CL2-043-010 1 FOOT,ARCH USM CX-SLX7

O APPEARANCE 8B-CL2-043-010 1B FOOT,ARCH EZSM CX-SLX7
O APPEARANCE 8B-CL2-043-010 1B FOOT,ARCH KSM CX-SLX7
O APPEARANCE 8B-CL2-045-010 1C RING,TOP EZSM CX-SLX7
O APPEARANCE 8B-CL2-045-010 1C RING,TOP KSM CX-SLX7
O APPEARANCE 8B-CL2-045-010 1C RING,TOP USM CX-SLX7
O APPEARANCE 8B-CL2-046-010 2B WINDOW,TOP KSM CX-SLX7
O APPEARANCE 8B-CL2-046-110 2B WINDOW,TOP EZSM CX-SLX7
O APPEARANCE 8B-CL2-050-110 2 WINDOW,TOP U USM CX-SLX7
! O APPEARANCE 8Z-CDB-169-010 1D PANEL,CD SANYO EZSM CX-SLX7
! O APPEARANCE 8Z-CDB-169-010 1D PANEL,CD SANYO KSM CX-SLX7

! O APPEARANCE 8Z-CDB-169-010 1D PANEL,CD SANYO USM CX-SLX7
X CD 80-XV1-218-010 0E CUSH-S,PWB EZSM CX-SLX7
X CD 80-XV1-218-010 0E CUSH-S,PWB KSM CX-SLX7
X CD 80-XV1-218-010 0E CUSH-S,PWB USM CX-SLX7
X CD 8B-CL2-631-110 -- PWB,CD-FUNC EZSM CX-SLX7
X CD 8B-CL2-631-110 -- PWB,CD-FUNC KSM CX-SLX7
X CD 8B-CL2-631-110 -- PWB,CD-FUNC USM CX-SLX7
X CD 8B-CL2-632-110 -- PWB,JACK EZSM CX-SLX7
X CD 8B-CL2-632-110 -- PWB,JACK KSM CX-SLX7
X CD 8B-CL2-632-110 -- PWB,JACK USM CX-SLX7

X CD M8-AZK-M90-070 2 DA11B3 USM CX-SLX7
X CD M8-AZK-M90-070 2B DA11B3 EZSM CX-SLX7
X CD M8-AZK-M90-070 2B DA11B3 KSM CX-SLX7
X CD * 8B-CL2-630-110 1C PWB,COMBI CD 2M EZSM CX-SLX7
X CD * 8B-CL2-630-110 1C PWB,COMBI CD 2M KSM CX-SLX7
X CD * 8B-CL2-630-110 1C PWB,COMBI CD 2M USM CX-SLX7
O CD C 0001 87-010-418-040 0E CAP,E 3.3-25 M 5L SRE EZSM CX-SLX7
O CD C 0001 87-010-418-040 0E CAP,E 3.3-25 M 5L SRE KSM CX-SLX7
O CD C 0001 87-010-418-040 0E CAP,E 3.3-25 M 5L SRE USM CX-SLX7
O CD C 0002 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7

 2 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O CD C 0002 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0002 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0003 87-010-263-040 0E CAP,E 100-10 M 11L SME EZSM CX-SLX7
O CD C 0003 87-010-263-040 0E CAP,E 100-10 M 11L SME KSM CX-SLX7
O CD C 0003 87-010-263-040 0E CAP,E 100-10 M 11L SME USM CX-SLX7
O CD C 0004 87-A12-063-040 0E CAP,E 220-10 SMG EZSM CX-SLX7
O CD C 0004 87-A12-063-040 0E CAP,E 220-10 SMG KSM CX-SLX7
O CD C 0004 87-A12-063-040 0E CAP,E 220-10 SMG USM CX-SLX7
O CD C 0005 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0005 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O CD C 0005 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0006 87-010-234-040 0E CAP,E 47-16 M 5L SRE EZSM CX-SLX7
O CD C 0006 87-010-234-040 0E CAP,E 47-16 M 5L SRE KSM CX-SLX7
O CD C 0006 87-010-234-040 0E CAP,E 47-16 M 5L SRE USM CX-SLX7
O CD C 0007 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O CD C 0007 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O CD C 0007 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O CD C 0008 87-010-787-080 0E C-CAP,U 0.022-25 K B EZSM CX-SLX7
O CD C 0008 87-010-787-080 0E C-CAP,U 0.022-25 K B KSM CX-SLX7
O CD C 0008 87-010-787-080 0E C-CAP,U 0.022-25 K B USM CX-SLX7

O CD C 0009 87-A12-063-040 0E CAP,E 220-10 SMG EZSM CX-SLX7
O CD C 0009 87-A12-063-040 0E CAP,E 220-10 SMG KSM CX-SLX7
O CD C 0009 87-A12-063-040 0E CAP,E 220-10 SMG USM CX-SLX7
O CD C 0010 87-010-263-040 0E CAP,E 100-10 M 11L SME EZSM CX-SLX7
O CD C 0010 87-010-263-040 0E CAP,E 100-10 M 11L SME KSM CX-SLX7
O CD C 0010 87-010-263-040 0E CAP,E 100-10 M 11L SME USM CX-SLX7
O CD C 0011 87-A10-794-080 0E C-CAP,U 0.15-16 Z F EZSM CX-SLX7
O CD C 0011 87-A10-794-080 0E C-CAP,U 0.15-16 Z F KSM CX-SLX7
O CD C 0011 87-A10-794-080 0E C-CAP,U 0.15-16 Z F USM CX-SLX7
O CD C 0012 87-010-071-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O CD C 0012 87-010-071-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7
O CD C 0012 87-010-071-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
O CD C 0013 87-010-788-080 0E C-CAP,U 0.033-25 Z F EZSM CX-SLX7
O CD C 0013 87-010-788-080 0E C-CAP,U 0.033-25 Z F KSM CX-SLX7
O CD C 0013 87-010-788-080 0E C-CAP,U 0.033-25 Z F USM CX-SLX7
O CD C 0014 87-010-405-040 0E CAP,E 10-50 M 11L SME EZSM CX-SLX7
O CD C 0014 87-010-405-040 0E CAP,E 10-50 M 11L SME KSM CX-SLX7
O CD C 0014 87-010-405-040 0E CAP,E 10-50 M 11L SME USM CX-SLX7
O CD C 0016 87-015-962-040 0E CAP,E 0.22-50 M 5L SRE EZSM CX-SLX7
O CD C 0016 87-015-962-040 0E CAP,E 0.22-50 M 5L SRE KSM CX-SLX7

O CD C 0016 87-015-962-040 0E CAP,E 0.22-50 M 5L SRE USM CX-SLX7
O CD C 0017 87-012-268-080 0E C-CAP,U 330P-50 K B GRM EZSM CX-SLX7
O CD C 0017 87-012-268-080 0E C-CAP,U 330P-50 K B GRM KSM CX-SLX7
O CD C 0017 87-012-268-080 0E C-CAP,U 330P-50 K B GRM USM CX-SLX7
O CD C 0018 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM EZSM CX-SLX7
O CD C 0018 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM KSM CX-SLX7
O CD C 0018 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM USM CX-SLX7
O CD C 0019 87-A10-706-080 0E C-CAP,U 0.33-16 Z F EZSM CX-SLX7
O CD C 0019 87-A10-706-080 0E C-CAP,U 0.33-16 Z F KSM CX-SLX7
O CD C 0019 87-A10-706-080 0E C-CAP,U 0.33-16 Z F USM CX-SLX7

O CD C 0020 87-010-788-080 0E C-CAP,U 0.033-25 Z F EZSM CX-SLX7
O CD C 0020 87-010-788-080 0E C-CAP,U 0.033-25 Z F KSM CX-SLX7
O CD C 0020 87-010-788-080 0E C-CAP,U 0.033-25 Z F USM CX-SLX7
O CD C 0021 87-A10-794-080 0E C-CAP,U 0.15-16 Z F EZSM CX-SLX7
O CD C 0021 87-A10-794-080 0E C-CAP,U 0.15-16 Z F KSM CX-SLX7
O CD C 0021 87-A10-794-080 0E C-CAP,U 0.15-16 Z F USM CX-SLX7
O CD C 0022 87-012-280-080 0E C-CAP,U 3300P-50 K B EZSM CX-SLX7
O CD C 0022 87-012-280-080 0E C-CAP,U 3300P-50 K B KSM CX-SLX7
O CD C 0022 87-012-280-080 0E C-CAP,U 3300P-50 K B USM CX-SLX7
O CD C 0023 87-A10-504-080 0E C-CAP,U 0.047-16 K B EZSM CX-SLX7

O CD C 0023 87-A10-504-080 0E C-CAP,U 0.047-16 K B KSM CX-SLX7
O CD C 0023 87-A10-504-080 0E C-CAP,U 0.047-16 K B USM CX-SLX7
O CD C 0024 87-A10-025-080 0E C-CAP,U 0.22-16 Z F EZSM CX-SLX7
O CD C 0024 87-A10-025-080 0E C-CAP,U 0.22-16 Z F KSM CX-SLX7
O CD C 0024 87-A10-025-080 0E C-CAP,U 0.22-16 Z F USM CX-SLX7
O CD C 0025 87-012-272-080 0E C-CAP,U 680P-50 K B GRM EZSM CX-SLX7
O CD C 0025 87-012-272-080 0E C-CAP,U 680P-50 K B GRM KSM CX-SLX7
O CD C 0025 87-012-272-080 0E C-CAP,U 680P-50 K B GRM USM CX-SLX7
O CD C 0026 87-A10-706-080 0E C-CAP,U 0.33-16 Z F EZSM CX-SLX7
O CD C 0026 87-A10-706-080 0E C-CAP,U 0.33-16 Z F KSM CX-SLX7

 3 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O CD C 0026 87-A10-706-080 0E C-CAP,U 0.33-16 Z F USM CX-SLX7
O CD C 0028 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0028 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0028 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0029 87-012-282-080 0E C-CAP,U 4700P-50 K B EZSM CX-SLX7
O CD C 0029 87-012-282-080 0E C-CAP,U 4700P-50 K B KSM CX-SLX7
O CD C 0029 87-012-282-080 0E C-CAP,U 4700P-50 K B USM CX-SLX7
O CD C 0030 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O CD C 0030 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7
O CD C 0030 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7

O CD C 0031 87-010-068-040 0E CAP,E 0.22-50 M 5L SRE EZSM CX-SLX7
O CD C 0031 87-010-068-040 0E CAP,E 0.22-50 M 5L SRE KSM CX-SLX7
O CD C 0031 87-010-068-040 0E CAP,E 0.22-50 M 5L SRE USM CX-SLX7
O CD C 0032 87-015-680-040 0E CAP,E 47-10 M 7L SRA EZSM CX-SLX7
O CD C 0032 87-015-680-040 0E CAP,E 47-10 M 7L SRA KSM CX-SLX7
O CD C 0032 87-015-680-040 0E CAP,E 47-10 M 7L SRA USM CX-SLX7
O CD C 0033 87-010-071-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7
O CD C 0033 87-010-071-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7
O CD C 0033 87-010-071-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
O CD C 0034 87-012-280-080 0E C-CAP,U 3300P-50 K B EZSM CX-SLX7

O CD C 0034 87-012-280-080 0E C-CAP,U 3300P-50 K B KSM CX-SLX7
O CD C 0034 87-012-280-080 0E C-CAP,U 3300P-50 K B USM CX-SLX7
O CD C 0035 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0035 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0035 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0036 87-010-374-040 0E CAP,E 47-10 M 11L SME EZSM CX-SLX7
O CD C 0036 87-010-374-040 0E CAP,E 47-10 M 11L SME KSM CX-SLX7
O CD C 0036 87-010-374-040 0E CAP,E 47-10 M 11L SME USM CX-SLX7
O CD C 0037 87-010-404-040 0E CAP,E 4.7-50 M 11L SME EZSM CX-SLX7
O CD C 0037 87-010-404-040 0E CAP,E 4.7-50 M 11L SME KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O CD C 0037 87-010-404-040 0E CAP,E 4.7-50 M 11L SME USM CX-SLX7
O CD C 0038 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0038 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0038 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0039 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O CD C 0039 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O CD C 0039 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O CD C 0040 87-012-162-080 0E C-CAP,U 1P-50 C CH EZSM CX-SLX7
O CD C 0040 87-012-162-080 0E C-CAP,U 1P-50 C CH KSM CX-SLX7
O CD C 0040 87-012-162-080 0E C-CAP,U 1P-50 C CH USM CX-SLX7

O CD C 0041 87-012-280-080 0E C-CAP,U 3300P-50 K B EZSM CX-SLX7
O CD C 0041 87-012-280-080 0E C-CAP,U 3300P-50 K B KSM CX-SLX7
O CD C 0041 87-012-280-080 0E C-CAP,U 3300P-50 K B USM CX-SLX7
O CD C 0042 87-012-176-080 0E C-CAP,U 15P-50 J CH EZSM CX-SLX7
O CD C 0042 87-012-176-080 0E C-CAP,U 15P-50 J CH KSM CX-SLX7
O CD C 0042 87-012-176-080 0E C-CAP,U 15P-50 J CH USM CX-SLX7
O CD C 0045 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0045 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0045 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0046 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7

O CD C 0046 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0046 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0047 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0047 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0047 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0048 87-012-182-080 0E C-CAP,U 27P-50 J CH EZSM CX-SLX7
O CD C 0048 87-012-182-080 0E C-CAP,U 27P-50 J CH KSM CX-SLX7
O CD C 0048 87-012-182-080 0E C-CAP,U 27P-50 J CH USM CX-SLX7
O CD C 0051 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O CD C 0051 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7

O CD C 0051 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7
O CD C 0053 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0053 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0053 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O CD C 0055 87-010-263-040 0E CAP,E 100-10 M 11L SME EZSM CX-SLX7
O CD C 0055 87-010-263-040 0E CAP,E 100-10 M 11L SME KSM CX-SLX7
O CD C 0055 87-010-263-040 0E CAP,E 100-10 M 11L SME USM CX-SLX7
O CD C 0057 87-012-184-080 0E C-CAP,U 33P-50 J CH EZSM CX-SLX7
O CD C 0057 87-012-184-080 0E C-CAP,U 33P-50 J CH KSM CX-SLX7
O CD C 0057 87-012-184-080 0E C-CAP,U 33P-50 J CH USM CX-SLX7

 4 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O CD C 0058 87-012-184-080 0E C-CAP,U 33P-50 J CH EZSM CX-SLX7
O CD C 0058 87-012-184-080 0E C-CAP,U 33P-50 J CH KSM CX-SLX7
O CD C 0058 87-012-184-080 0E C-CAP,U 33P-50 J CH USM CX-SLX7
O CD C 0059 87-010-263-040 0E CAP,E 100-10 M 11L SME EZSM CX-SLX7
O CD C 0059 87-010-263-040 0E CAP,E 100-10 M 11L SME KSM CX-SLX7
O CD C 0059 87-010-263-040 0E CAP,E 100-10 M 11L SME USM CX-SLX7
O CD C 0060 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0060 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0060 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0061 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7

O CD C 0061 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0061 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0062 87-A12-058-040 0E CAP,E 470-6.3 SMG EZSM CX-SLX7
O CD C 0062 87-A12-058-040 0E CAP,E 470-6.3 SMG KSM CX-SLX7
O CD C 0062 87-A12-058-040 0E CAP,E 470-6.3 SMG USM CX-SLX7
O CD C 0065 87-010-404-040 0E CAP,E 4.7-50 M 11L SME EZSM CX-SLX7
O CD C 0065 87-010-404-040 0E CAP,E 4.7-50 M 11L SME KSM CX-SLX7
O CD C 0065 87-010-404-040 0E CAP,E 4.7-50 M 11L SME USM CX-SLX7
O CD C 0066 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0066 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7

O CD C 0066 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0067 87-010-263-040 0E CAP,E 100-10 M 11L SME EZSM CX-SLX7
O CD C 0067 87-010-263-040 0E CAP,E 100-10 M 11L SME KSM CX-SLX7
O CD C 0067 87-010-263-040 0E CAP,E 100-10 M 11L SME USM CX-SLX7
O CD C 0069 87-012-197-080 0E C-CAP,U 150P-50 J CH EZSM CX-SLX7
O CD C 0069 87-012-197-080 0E C-CAP,U 150P-50 J CH KSM CX-SLX7
O CD C 0069 87-012-197-080 0E C-CAP,U 150P-50 J CH USM CX-SLX7
O CD C 0070 87-018-134-080 0E CAP,TC U 0.01-16 N Y UP050 USM CX-SLX7
O CD C 0071 87-018-208-080 0E CAP,TC U 0.047-50 Z F UP050 USM CX-SLX7
O CD C 0072 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O CD C 0073 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0074 87-018-208-080 0E CAP,TC U 0.047-50 Z F UP050 USM CX-SLX7
O CD C 0075 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0081 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE EZSM CX-SLX7
O CD C 0081 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE KSM CX-SLX7
O CD C 0081 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE USM CX-SLX7
O CD C 0082 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE EZSM CX-SLX7
O CD C 0082 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE KSM CX-SLX7
O CD C 0082 87-010-417-040 0E CAP,E 2.2-35 M 5L SRE USM CX-SLX7
O CD C 0083 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM EZSM CX-SLX7

O CD C 0083 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM KSM CX-SLX7
O CD C 0083 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM USM CX-SLX7
O CD C 0084 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM EZSM CX-SLX7
O CD C 0084 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM KSM CX-SLX7
O CD C 0084 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM USM CX-SLX7
O CD C 0093 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O CD C 0093 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O CD C 0093 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O CD C 0094 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O CD C 0094 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7

O CD C 0094 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O CD C 0095 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0095 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0095 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O CD C 0102 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0102 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0102 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7

O CD C 0103 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0103 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0103 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O CD C 0104 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0104 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0104 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O CD C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O CD C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O CD C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O CD C 0106 87-010-494-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7

 5 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O CD C 0106 87-010-494-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7
O CD C 0106 87-010-494-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
O CD C 0110 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0110 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0110 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0120 87-A12-326-080 0E CAP,E 1000-16 RS EZSM CX-SLX7
O CD C 0120 87-A12-326-080 0E CAP,E 1000-16 RS KSM CX-SLX7
O CD C 0120 87-A12-326-080 0E CAP,E 1000-16 RS USM CX-SLX7
O CD C 0121 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0121 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O CD C 0121 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0123 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0123 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0123 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0124 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O CD C 0124 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7
O CD C 0124 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7
O CD C 0125 87-012-270-080 0E C-CAP,U 470P-50 K B EZSM CX-SLX7
O CD C 0125 87-012-270-080 0E C-CAP,U 470P-50 K B KSM CX-SLX7
O CD C 0125 87-012-270-080 0E C-CAP,U 470P-50 K B USM CX-SLX7

O CD C 0126 87-012-270-080 0E C-CAP,U 470P-50 K B EZSM CX-SLX7
O CD C 0126 87-012-270-080 0E C-CAP,U 470P-50 K B KSM CX-SLX7
O CD C 0126 87-012-270-080 0E C-CAP,U 470P-50 K B USM CX-SLX7
O CD C 0127 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O CD C 0127 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7
O CD C 0127 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7
O CD C 0495 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O CD C 0495 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O CD C 0495 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O CD C 0496 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O CD C 0496 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0496 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O CD C 0913 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O CD C 0913 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O CD C 0913 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
X CD CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS EZSM CX-SLX7
X CD CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS KSM CX-SLX7
X CD CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-SLX7
X CD CLP0002 87-A60-884-010 0E PIN,DIA1 COATING-SHS EZSM CX-SLX7
X CD CLP0002 87-A60-884-010 0E PIN,DIA1 COATING-SHS KSM CX-SLX7

X CD CLP0002 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-SLX7
O CD CN 0001 87-A60-429-010 0E CONN,16P H TOC-A EZSM CX-SLX7
O CD CN 0001 87-A60-429-010 0E CONN,16P H TOC-A KSM CX-SLX7
O CD CN 0001 87-A60-429-010 0E CONN,16P H TOC-A USM CX-SLX7
O CD CN 0002 87-A60-623-010 0E CONN,6P V 2MM JMT EZSM CX-SLX7
O CD CN 0002 87-A60-623-010 0E CONN,6P V 2MM JMT KSM CX-SLX7
O CD CN 0002 87-A60-623-010 0E CONN,6P V 2MM JMT USM CX-SLX7
! O CD CN 0004 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK EZSM CX-SLX7
! O CD CN 0004 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK KSM CX-SLX7
! O CD CN 0004 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK USM CX-SLX7

S CD D 0001 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S CD D 0001 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S CD D 0001 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S CD D 0002 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S CD D 0002 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S CD D 0002 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S CD D 0003 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S CD D 0003 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S CD D 0003 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S CD IC 0001 87-A20-446-010 1E C-IC,LA9241ML EZSM CX-SLX7

S CD IC 0001 87-A20-446-010 1E C-IC,LA9241ML KSM CX-SLX7
S CD IC 0001 87-A20-446-010 1E C-IC,LA9241ML USM CX-SLX7
S CD IC 0002 87-A21-319-010 2A C-IC,LC78622NE EZSM CX-SLX7
S CD IC 0002 87-A21-319-010 2A C-IC,LC78622NE KSM CX-SLX7
S CD IC 0002 87-A21-319-010 2A C-IC,LC78622NE USM CX-SLX7
S CD IC 0003 87-017-917-080 1A C-IC,BU4066BCF EZSM CX-SLX7
S CD IC 0003 87-017-917-080 1A C-IC,BU4066BCF KSM CX-SLX7
S CD IC 0003 87-017-917-080 1A C-IC,BU4066BCF USM CX-SLX7
S CD IC 0120 87-A21-985-040 1D C-IC,BA5983FM EZSM CX-SLX7
S CD IC 0120 87-A21-985-040 1D C-IC,BA5983FM KSM CX-SLX7

 6 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S CD IC 0120 87-A21-985-040 1D C-IC,BA5983FM USM CX-SLX7
X CD JR 0001 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0001 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0001 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0002 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0002 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0002 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0003 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0003 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0003 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7

X CD JR 0004 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0004 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0004 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0005 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0005 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0005 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0006 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X CD JR 0006 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X CD JR 0006 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X CD JR 0007 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7

X CD JR 0007 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X CD JR 0007 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X CD JR 0008 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X CD JR 0008 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X CD JR 0008 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X CD JR 0009 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0009 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0009 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0010 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0010 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X CD JR 0010 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0011 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X CD JR 0011 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X CD JR 0011 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X CD JR 0012 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X CD JR 0012 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X CD JR 0012 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X CD JR 0017 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X CD JR 0017 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X CD JR 0017 88-108-000-080 0E C-JUMPER,U USM CX-SLX7

X CD JR 0035 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X CD JR 0035 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X CD JR 0035 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
O CD JR 0058 87-A50-189-080 0E C-COIL,S BLM21B272S EZSM CX-SLX7
O CD JR 0058 87-A50-189-080 0E C-COIL,S BLM21B272S KSM CX-SLX7
O CD JR 0058 87-A50-189-080 0E C-COIL,S BLM21B272S USM CX-SLX7
X CD JR 0131 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X CD JR 0131 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X CD JR 0131 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
O CD L 0001 87-003-102-080 0E COIL,10UH J LAL02 EZSM CX-SLX7

O CD L 0001 87-003-102-080 0E COIL,10UH J LAL02 KSM CX-SLX7
O CD L 0001 87-003-102-080 0E COIL,10UH J LAL02 USM CX-SLX7
O CD L 0002 87-003-146-080 0E COIL,15UH J LAL02 EZSM CX-SLX7
O CD L 0002 87-003-146-080 0E COIL,15UH J LAL02 KSM CX-SLX7
O CD L 0002 87-003-146-080 0E COIL,15UH J LAL02 USM CX-SLX7
O CD L 0003 87-008-372-080 0E FLTR,EMI BL01 RN1 EZSM CX-SLX7
O CD L 0003 87-008-372-080 0E FLTR,EMI BL01 RN1 KSM CX-SLX7
O CD L 0003 87-008-372-080 0E FLTR,EMI BL01 RN1 USM CX-SLX7
O CD L 0004 87-003-102-080 0E COIL,10UH J LAL02 EZSM CX-SLX7
O CD L 0004 87-003-102-080 0E COIL,10UH J LAL02 KSM CX-SLX7

O CD L 0004 87-003-102-080 0E COIL,10UH J LAL02 USM CX-SLX7
O CD L 0005 87-003-152-080 0E COIL,100UH J LAL02 EZSM CX-SLX7
O CD L 0005 87-003-152-080 0E COIL,100UH J LAL02 KSM CX-SLX7
O CD L 0005 87-003-152-080 0E COIL,100UH J LAL02 USM CX-SLX7
O CD L 0006 87-003-102-080 0E COIL,10UH J LAL02 EZSM CX-SLX7
O CD L 0006 87-003-102-080 0E COIL,10UH J LAL02 KSM CX-SLX7
O CD L 0006 87-003-102-080 0E COIL,10UH J LAL02 USM CX-SLX7
O CD L 0007 87-003-102-080 0E COIL,10UH J LAL02 EZSM CX-SLX7
O CD L 0007 87-003-102-080 0E COIL,10UH J LAL02 KSM CX-SLX7
O CD L 0007 87-003-102-080 0E COIL,10UH J LAL02 USM CX-SLX7

 7 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O CD L 0008 87-003-102-080 0E COIL,10UH J LAL02 EZSM CX-SLX7
O CD L 0008 87-003-102-080 0E COIL,10UH J LAL02 KSM CX-SLX7
O CD L 0008 87-003-102-080 0E COIL,10UH J LAL02 USM CX-SLX7
S CD Q 0001 87-026-463-080 0E TR,2SA933SRS EZSM CX-SLX7
S CD Q 0001 87-026-463-080 0E TR,2SA933SRS KSM CX-SLX7
S CD Q 0001 87-026-463-080 0E TR,2SA933SRS USM CX-SLX7
S CD Q 0403 87-A30-287-040 0E C-TR,DTC114TKA EZSM CX-SLX7
S CD Q 0403 87-A30-287-040 0E C-TR,DTC114TKA KSM CX-SLX7
S CD Q 0403 87-A30-287-040 0E C-TR,DTC114TKA USM CX-SLX7
X CD R 0001 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7

X CD R 0001 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X CD R 0001 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X CD R 0002 88-108-100-080 0E C-RES,U 10-1/16W J EZSM CX-SLX7
X CD R 0002 88-108-100-080 0E C-RES,U 10-1/16W J KSM CX-SLX7
X CD R 0002 88-108-100-080 0E C-RES,U 10-1/16W J USM CX-SLX7
X CD R 0003 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X CD R 0003 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X CD R 0003 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X CD R 0005 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0005 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7

X CD R 0005 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0006 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X CD R 0006 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X CD R 0006 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X CD R 0008 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7
X CD R 0008 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X CD R 0008 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X CD R 0009 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X CD R 0009 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X CD R 0009 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X CD R 0010 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X CD R 0010 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X CD R 0010 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X CD R 0011 88-108-561-080 0E C-RES,U 560-1/16W J EZSM CX-SLX7
X CD R 0011 88-108-561-080 0E C-RES,U 560-1/16W J KSM CX-SLX7
X CD R 0011 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-SLX7
X CD R 0012 88-108-224-080 0E C-RES,U 220K-1/16W J EZSM CX-SLX7
X CD R 0012 88-108-224-080 0E C-RES,U 220K-1/16W J KSM CX-SLX7
X CD R 0012 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-SLX7
X CD R 0013 88-108-153-080 0E C-RES,U 15K-1/16W J EZSM CX-SLX7

X CD R 0013 88-108-153-080 0E C-RES,U 15K-1/16W J KSM CX-SLX7
X CD R 0013 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-SLX7
X CD R 0014 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X CD R 0014 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X CD R 0014 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X CD R 0015 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X CD R 0015 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X CD R 0015 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X CD R 0016 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X CD R 0016 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X CD R 0016 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X CD R 0017 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X CD R 0017 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X CD R 0017 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X CD R 0018 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X CD R 0018 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X CD R 0018 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X CD R 0019 88-108-152-080 0E C-RES,U 1.5K-1/16W J EZSM CX-SLX7
X CD R 0019 88-108-152-080 0E C-RES,U 1.5K-1/16W J KSM CX-SLX7
X CD R 0019 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-SLX7

X CD R 0020 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X CD R 0020 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X CD R 0020 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X CD R 0021 88-108-184-080 0E C-RES,U 180K-1/16W J EZSM CX-SLX7
X CD R 0021 88-108-184-080 0E C-RES,U 180K-1/16W J KSM CX-SLX7
X CD R 0021 88-108-184-080 0E C-RES,U 180K-1/16W J USM CX-SLX7
X CD R 0023 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0023 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X CD R 0023 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0024 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7

 8 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X CD R 0024 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X CD R 0024 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X CD R 0025 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X CD R 0025 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X CD R 0025 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X CD R 0026 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X CD R 0026 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X CD R 0026 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X CD R 0027 88-108-682-080 0E C-RES,U 6.8K-1/16W J EZSM CX-SLX7
X CD R 0027 88-108-682-080 0E C-RES,U 6.8K-1/16W J KSM CX-SLX7

X CD R 0027 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-SLX7
X CD R 0028 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0028 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0028 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0029 88-108-152-080 0E C-RES,U 1.5K-1/16W J EZSM CX-SLX7
X CD R 0029 88-108-152-080 0E C-RES,U 1.5K-1/16W J KSM CX-SLX7
X CD R 0029 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-SLX7
X CD R 0031 88-108-334-080 0E C-RES,U 330K-1/16W J EZSM CX-SLX7
X CD R 0031 88-108-334-080 0E C-RES,U 330K-1/16W J KSM CX-SLX7
X CD R 0031 88-108-334-080 0E C-RES,U 330K-1/16W J USM CX-SLX7

X CD R 0032 88-108-334-080 0E C-RES,U 330K-1/16W J EZSM CX-SLX7
X CD R 0032 88-108-334-080 0E C-RES,U 330K-1/16W J KSM CX-SLX7
X CD R 0032 88-108-334-080 0E C-RES,U 330K-1/16W J USM CX-SLX7
X CD R 0033 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X CD R 0033 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X CD R 0033 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X CD R 0034 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X CD R 0034 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X CD R 0034 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X CD R 0035 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X CD R 0035 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X CD R 0035 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X CD R 0036 88-108-822-080 0E C-RES,U 8.2K-1/16W J EZSM CX-SLX7
X CD R 0036 88-108-822-080 0E C-RES,U 8.2K-1/16W J KSM CX-SLX7
X CD R 0036 88-108-822-080 0E C-RES,U 8.2K-1/16W J USM CX-SLX7
X CD R 0037 88-108-562-080 0E C-RES,U 5.6K-1/16W J EZSM CX-SLX7
X CD R 0037 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X CD R 0037 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-SLX7
X CD R 0038 88-108-681-080 0E C-RES,U 680-1/16W J EZSM CX-SLX7
X CD R 0038 88-108-681-080 0E C-RES,U 680-1/16W J KSM CX-SLX7

X CD R 0038 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-SLX7
X CD R 0039 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X CD R 0039 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X CD R 0039 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X CD R 0040 88-108-331-080 0E C-RES,U 330-1/16W J EZSM CX-SLX7
X CD R 0040 88-108-331-080 0E C-RES,U 330-1/16W J KSM CX-SLX7
X CD R 0040 88-108-331-080 0E C-RES,U 330-1/16W J USM CX-SLX7
X CD R 0041 88-108-681-080 0E C-RES,U 680-1/16W J EZSM CX-SLX7
X CD R 0041 88-108-681-080 0E C-RES,U 680-1/16W J KSM CX-SLX7
X CD R 0041 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-SLX7

X CD R 0042 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X CD R 0042 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X CD R 0042 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X CD R 0043 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X CD R 0043 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X CD R 0043 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X CD R 0044 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X CD R 0044 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X CD R 0044 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7
X CD R 0045 88-108-823-080 0E C-RES,U 82K-1/16W J EZSM CX-SLX7

X CD R 0045 88-108-823-080 0E C-RES,U 82K-1/16W J KSM CX-SLX7
X CD R 0045 88-108-823-080 0E C-RES,U 82K-1/16W J USM CX-SLX7
X CD R 0047 88-121-333-080 0E RES,33K-1/8W J EZSM CX-SLX7
X CD R 0047 88-121-333-080 0E RES,33K-1/8W J KSM CX-SLX7
X CD R 0047 88-121-333-080 0E RES,33K-1/8W J USM CX-SLX7
X CD R 0049 88-108-272-080 0E C-RES,U 2.7K-1/16W J EZSM CX-SLX7
X CD R 0049 88-108-272-080 0E C-RES,U 2.7K-1/16W J KSM CX-SLX7
X CD R 0049 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-SLX7
X CD R 0050 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X CD R 0050 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7

 9 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X CD R 0050 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X CD R 0051 88-121-103-080 0E RES,10K-1/8W J EZSM CX-SLX7
X CD R 0051 88-121-103-080 0E RES,10K-1/8W J KSM CX-SLX7
X CD R 0051 88-121-103-080 0E RES,10K-1/8W J USM CX-SLX7
X CD R 0053 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X CD R 0053 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X CD R 0053 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X CD R 0055 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X CD R 0055 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X CD R 0055 88-108-000-080 0E C-JUMPER,U USM CX-SLX7

X CD R 0056 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0056 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X CD R 0056 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0059 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0059 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X CD R 0059 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0065 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0065 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0065 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0066 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

X CD R 0066 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0066 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0067 88-121-333-080 0E RES,33K-1/8W J EZSM CX-SLX7
X CD R 0067 88-121-333-080 0E RES,33K-1/8W J KSM CX-SLX7
X CD R 0067 88-121-333-080 0E RES,33K-1/8W J USM CX-SLX7
X CD R 0068 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7
X CD R 0068 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X CD R 0068 88-121-471-080 0E RES,470-1/8W J USM CX-SLX7
X CD R 0069 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0069 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X CD R 0069 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0078 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7
X CD R 0078 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7
X CD R 0078 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X CD R 0079 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7
X CD R 0079 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X CD R 0079 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X CD R 0081 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X CD R 0081 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X CD R 0081 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7

X CD R 0082 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X CD R 0082 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X CD R 0082 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X CD R 0083 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X CD R 0083 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X CD R 0083 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X CD R 0084 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X CD R 0084 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X CD R 0084 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X CD R 0085 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7

X CD R 0085 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X CD R 0085 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X CD R 0086 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7
X CD R 0086 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X CD R 0086 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X CD R 0087 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7
X CD R 0087 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X CD R 0087 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X CD R 0088 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7
X CD R 0088 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7

X CD R 0088 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X CD R 0089 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0089 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0089 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0101 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0101 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0101 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0102 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X CD R 0102 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X CD R 0102 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7

 10 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X CD R 0103 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X CD R 0103 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X CD R 0103 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X CD R 0104 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0104 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0104 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0105 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X CD R 0105 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0105 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0106 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

X CD R 0106 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X CD R 0106 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X CD R 0107 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X CD R 0107 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X CD R 0107 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X CD R 0108 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X CD R 0108 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X CD R 0108 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X CD R 0109 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X CD R 0109 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7

X CD R 0109 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X CD R 0123 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X CD R 0123 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X CD R 0123 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X CD R 0124 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X CD R 0124 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X CD R 0124 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X CD R 0125 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X CD R 0125 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X CD R 0125 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X CD R 0126 88-108-153-080 0E C-RES,U 15K-1/16W J EZSM CX-SLX7
X CD R 0126 88-108-153-080 0E C-RES,U 15K-1/16W J KSM CX-SLX7
X CD R 0126 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-SLX7
X CD R 0130 88-121-104-080 0E RES,100K-1/8W J EZSM CX-SLX7
X CD R 0130 88-121-104-080 0E RES,100K-1/8W J KSM CX-SLX7
X CD R 0130 88-121-104-080 0E RES,100K-1/8W J USM CX-SLX7
X CD R 0131 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X CD R 0131 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X CD R 0131 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0132 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7

X CD R 0132 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X CD R 0132 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X CD R 0430 88-128-101-080 0E C-RES, 100-1/8W J EZSM CX-SLX7
X CD R 0430 88-128-101-080 0E C-RES, 100-1/8W J KSM CX-SLX7
X CD R 0430 88-128-101-080 0E C-RES, 100-1/8W J USM CX-SLX7
X CD R 0453 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X CD R 0453 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X CD R 0453 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X CD R 0456 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X CD R 0456 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X CD R 0456 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X CD R 0457 88-108-153-080 0E C-RES,U 15K-1/16W J EZSM CX-SLX7
X CD R 0457 88-108-153-080 0E C-RES,U 15K-1/16W J KSM CX-SLX7
X CD R 0457 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-SLX7
X CD R 0495 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X CD R 0495 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X CD R 0495 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X CD R 0496 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X CD R 0496 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X CD R 0496 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7

X CD R 0497 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X CD R 0497 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X CD R 0497 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X CD R 0498 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X CD R 0498 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X CD R 0498 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X CD R 0531 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7
X CD R 0531 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X CD R 0531 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
X CD R 0532 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7

 11 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X CD R 0532 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X CD R 0532 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
O CD SFR0130 87-024-437-080 0E SFR,100K H RH063MC EZSM CX-SLX7
O CD SFR0130 87-024-437-080 0E SFR,100K H RH063MC KSM CX-SLX7
O CD SFR0130 87-024-437-080 0E SFR,100K H RH063MC USM CX-SLX7
O CD X 0001 87-A70-046-010 1B VIB,XTAL 16.934MHZ EZSM CX-SLX7
O CD X 0001 87-A70-046-010 1B VIB,XTAL 16.934MHZ KSM CX-SLX7
O CD X 0001 87-A70-046-010 1B VIB,XTAL 16.934MHZ USM CX-SLX7
! O ELECTRICAL 86-ZG1-609-010 1D CONN ASSY,6P EZSM CX-SLX7
! O ELECTRICAL 86-ZG1-609-010 1D CONN ASSY,6P KSM CX-SLX7

! O ELECTRICAL 86-ZG1-609-010 1D CONN ASSY,6P USM CX-SLX7
O ELECTRICAL 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 EZSM CX-SLX7
O ELECTRICAL 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 KSM CX-SLX7
X ELECTRICAL 87-098-335-010 0E LBL,REPLACEMENT USM CX-SLX7
! O ELECTRICAL 87-099-811-010 1E PLUG,ADPTR CONV(K) KSM CX-SLX7
! X ELECTRICAL 87-839-302-010 0E TUBE,UL 3-20 EZSM CX-SLX7
! X ELECTRICAL 87-839-302-010 0E TUBE,UL 3-20 KSM CX-SLX7
O ELECTRICAL 87-A90-036-010 1D MOT ASSY,RF-300CA-11440 EZSM CX-SLX7
O ELECTRICAL 87-A90-036-010 1D MOT ASSY,RF-300CA-11440 KSM CX-SLX7
O ELECTRICAL 87-A90-036-010 1D MOT ASSY,RF-300CA-11440 USM CX-SLX7

O ELECTRICAL 87-A90-193-010 0E HLDR,CV100 (B) EZSM CX-SLX7
O ELECTRICAL 87-A90-193-010 0E HLDR,CV100 (B) KSM CX-SLX7
O ELECTRICAL 87-A90-193-010 0E HLDR,CV100 (B) EZSM CX-SLX7
O ELECTRICAL 87-A90-193-010 0E HLDR,CV100 (B) KSM CX-SLX7
O ELECTRICAL 87-A90-193-010 0E HLDR,CV100 (B) USM CX-SLX7
! O ELECTRICAL 87-A90-796-010 2A FAN,F614R-12MC-19-240MM EZSM CX-SLX7
! O ELECTRICAL 87-A90-796-010 2A FAN,F614R-12MC-19-240MM KSM CX-SLX7
! O ELECTRICAL 87-A90-796-010 2A FAN,F614R-12MC-19-240MM USM CX-SLX7
X ELECTRICAL 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
O ELECTRICAL 88-904-081-110 0E FF-CABLE,4P 1.25 80MM EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O ELECTRICAL 88-905-121-110 0E FF-CABLE, 5P 120MM EZSM CX-SLX7
O ELECTRICAL 88-905-121-110 0E FF-CABLE, 5P 120MM KSM CX-SLX7
O ELECTRICAL 88-905-121-110 0E FF-CABLE, 5P 120MM USM CX-SLX7
O ELECTRICAL 88-908-121-110 0E FF-CABLE,8P 1.25 120MM EZSM CX-SLX7
O ELECTRICAL 88-908-121-110 0E FF-CABLE,8P 1.25 120MM KSM CX-SLX7
O ELECTRICAL 88-908-121-110 0E FF-CABLE,8P 1.25 120MM USM CX-SLX7
O ELECTRICAL 88-908-201-110 1A FF-CABLE,8P 1.25 EZSM CX-SLX7
O ELECTRICAL 88-908-201-110 1A FF-CABLE,8P 1.25 KSM CX-SLX7
O ELECTRICAL 88-908-201-110 1A FF-CABLE,8P 1.25 USM CX-SLX7
O ELECTRICAL 88-912-081-110 0E FF-CABLE,12P 1.25 80MM EZSM CX-SLX7

O ELECTRICAL 88-912-081-110 0E FF-CABLE,12P 1.25 80MM KSM CX-SLX7
O ELECTRICAL 88-912-081-110 0E FF-CABLE,12P 1.25 80MM USM CX-SLX7
! O ELECTRICAL 88-NF9-203-010 0E BUSHING,CORD-U USM CX-SLX7
O ELECTRICAL 88-NF9-210-010 0E BUSHING,CORD-E EZSM CX-SLX7
O ELECTRICAL 88-NF9-210-010 0E BUSHING,CORD-E KSM CX-SLX7
X ELECTRICAL 89-920-040-110 0E WIRE,UD0-4-3 EZSM CX-SLX7
X ELECTRICAL 89-920-040-110 0E WIRE,UD0-4-3 KSM CX-SLX7
X ELECTRICAL 89-920-040-110 0E WIRE,UD0-4-3 USM CX-SLX7
X ELECTRICAL 89-990-051-110 0E WIRE,U24X0-5-3 EZSM CX-SLX7
X ELECTRICAL 89-990-051-110 0E WIRE,U24X0-5-3 KSM CX-SLX7

X ELECTRICAL 89-990-051-110 0E WIRE,U24X0-5-3 USM CX-SLX7
! O ELECTRICAL 8B-CL2-650-010 2P PT,BCL-2 U USM CX-SLX7
! O ELECTRICAL 8B-CL2-652-010 -- PT,BCL-2 EZ EZSM CX-SLX7
! O ELECTRICAL 8B-CL2-652-010 -- PT,BCL-2 EZ KSM CX-SLX7
O ELECTRICAL 8B-CL2-660-010 0E FF-CABLE,21P 1.0 EZSM CX-SLX7
O ELECTRICAL 8B-CL2-660-010 0E FF-CABLE,21P 1.0 KSM CX-SLX7
O ELECTRICAL 8B-CL2-660-010 0E FF-CABLE,21P 1.0 USM CX-SLX7
O ELECTRICAL 8B-CL2-661-010 0E FF-CABLE,9P 1.0 EZSM CX-SLX7
O ELECTRICAL 8B-CL2-661-010 0E FF-CABLE,9P 1.0 KSM CX-SLX7
O ELECTRICAL 8B-CL2-661-010 0E FF-CABLE,9P 1.0 USM CX-SLX7

O ELECTRICAL 8B-CL2-662-010 0E FF-CABLE,11P 1.0 EZSM CX-SLX7
O ELECTRICAL 8B-CL2-662-010 0E FF-CABLE,11P 1.0 KSM CX-SLX7
O ELECTRICAL 8B-CL2-662-010 0E FF-CABLE,11P 1.0 USM CX-SLX7
O ELECTRICAL 8B-CL2-663-010 0E FF-CABLE,16P 1.0 EZSM CX-SLX7
O ELECTRICAL 8B-CL2-663-010 0E FF-CABLE,16P 1.0 KSM CX-SLX7
O ELECTRICAL 8B-CL2-663-010 0E FF-CABLE,16P 1.0 USM CX-SLX7
X ELECTRICAL F 0001 87-098-261-010 0E LBL,FUSE 1.25A 125V USM CX-SLX7
! S ELECTRICAL F 0001 87-A91-224-010 0E FUSE,1.25A 125V T 51S USM CX-SLX7
O ELECTRICAL FB 0101 87-003-317-010 1C F-BEAD,15-25-15 E2515MRT EZSM CX-SLX7
O ELECTRICAL FB 0101 87-003-317-010 1C F-BEAD,15-25-15 E2515MRT KSM CX-SLX7

 12 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O ELECTRICAL FB 0101 87-003-317-010 1C F-BEAD,15-25-15 E2515MRT USM CX-SLX7
! O ELECTRICAL W 0001 87-A80-092-010 1C AC CORD ASSY,E BLK SUN FAI EZSM CX-SLX7
! O ELECTRICAL W 0001 87-A80-143-010 1C AC CORD ASSY,E BLK KSM CX-SLX7
! O ELECTRICAL W 0001 87-A80-149-010 1B AC CORD ASSY,U BLK USM CX-SLX7
O FAN CONTROL C 0301 87-010-235-080 0E CAP,E 470-16 M SME EZSM CX-SLX7
O FAN CONTROL C 0301 87-010-235-080 0E CAP,E 470-16 M SME KSM CX-SLX7
O FAN CONTROL C 0301 87-010-235-080 0E CAP,E 470-16 M SME USM CX-SLX7
O FAN CONTROL C 0302 87-010-112-040 0E CAP,E 100-16 M 11L SME EZSM CX-SLX7
O FAN CONTROL C 0302 87-010-112-040 0E CAP,E 100-16 M 11L SME KSM CX-SLX7
O FAN CONTROL C 0302 87-010-112-040 0E CAP,E 100-16 M 11L SME USM CX-SLX7

O FAN CONTROL C 0303 87-010-553-040 0E CAP,E 47-16 M 5L SRE EZSM CX-SLX7
O FAN CONTROL C 0303 87-010-553-040 0E CAP,E 47-16 M 5L SRE KSM CX-SLX7
O FAN CONTROL C 0303 87-010-553-040 0E CAP,E 47-16 M 5L SRE USM CX-SLX7
O FAN CONTROL C 0304 87-010-404-040 0E CAP,E 4.7-50 M 11L SME EZSM CX-SLX7
O FAN CONTROL C 0304 87-010-404-040 0E CAP,E 4.7-50 M 11L SME KSM CX-SLX7
O FAN CONTROL C 0304 87-010-404-040 0E CAP,E 4.7-50 M 11L SME USM CX-SLX7
O FAN CONTROL C 0305 87-010-494-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7
O FAN CONTROL C 0305 87-010-494-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7
O FAN CONTROL C 0305 87-010-494-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
O FAN CONTROL CN 0302 87-A60-619-010 0E CONN,2P V 2MM JMT EZSM CX-SLX7

O FAN CONTROL CN 0302 87-A60-619-010 0E CONN,2P V 2MM JMT KSM CX-SLX7
O FAN CONTROL CN 0302 87-A60-619-010 0E CONN,2P V 2MM JMT USM CX-SLX7
O FAN CONTROL CNA0301 87-099-410-010 0E CONN,10P V WHT EH EZSM CX-SLX7
O FAN CONTROL CNA0301 87-099-410-010 0E CONN,10P V WHT EH KSM CX-SLX7
O FAN CONTROL CNA0301 87-099-410-010 0E CONN,10P V WHT EH USM CX-SLX7
S FAN CONTROL D 0301 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S FAN CONTROL D 0301 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S FAN CONTROL D 0301 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S FAN CONTROL D 0302 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S FAN CONTROL D 0302 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S FAN CONTROL D 0302 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S FAN CONTROL Q 0301 87-A30-234-080 0E TR,CSC4115BC EZSM CX-SLX7
S FAN CONTROL Q 0301 87-A30-234-080 0E TR,CSC4115BC KSM CX-SLX7
S FAN CONTROL Q 0301 87-A30-234-080 0E TR,CSC4115BC USM CX-SLX7
S FAN CONTROL Q 0302 87-026-609-080 0E TR,KTA1266GR EZSM CX-SLX7
S FAN CONTROL Q 0302 87-026-609-080 0E TR,KTA1266GR KSM CX-SLX7
S FAN CONTROL Q 0302 87-026-609-080 0E TR,KTA1266GR USM CX-SLX7
S FAN CONTROL Q 0303 87-A30-075-080 0E C-TR,2SA1235F EZSM CX-SLX7
S FAN CONTROL Q 0303 87-A30-075-080 0E C-TR,2SA1235F KSM CX-SLX7
S FAN CONTROL Q 0303 87-A30-075-080 0E C-TR,2SA1235F USM CX-SLX7

S FAN CONTROL Q 0304 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S FAN CONTROL Q 0304 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S FAN CONTROL Q 0304 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
X FAN CONTROL R 0301 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0301 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X FAN CONTROL R 0301 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X FAN CONTROL R 0302 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0302 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X FAN CONTROL R 0302 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
X FAN CONTROL R 0303 88-128-399-080 0E C-RES, 3.9-1/8W J EZSM CX-SLX7

X FAN CONTROL R 0303 88-128-399-080 0E C-RES, 3.9-1/8W J KSM CX-SLX7
X FAN CONTROL R 0303 88-128-399-080 0E C-RES, 3.9-1/8W J USM CX-SLX7
X FAN CONTROL R 0304 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0304 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X FAN CONTROL R 0304 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X FAN CONTROL R 0306 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0306 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X FAN CONTROL R 0306 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X FAN CONTROL R 0307 88-108-151-080 0E C-RES,U 150-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0307 88-108-151-080 0E C-RES,U 150-1/16W J KSM CX-SLX7

X FAN CONTROL R 0307 88-108-151-080 0E C-RES,U 150-1/16W J USM CX-SLX7
X FAN CONTROL R 0308 88-108-184-080 0E C-RES,U 180K-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0308 88-108-184-080 0E C-RES,U 180K-1/16W J KSM CX-SLX7
X FAN CONTROL R 0308 88-108-184-080 0E C-RES,U 180K-1/16W J USM CX-SLX7
X FAN CONTROL R 0309 88-108-823-080 0E C-RES,U 82K-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0309 88-108-823-080 0E C-RES,U 82K-1/16W J KSM CX-SLX7
X FAN CONTROL R 0309 88-108-823-080 0E C-RES,U 82K-1/16W J USM CX-SLX7
X FAN CONTROL R 0310 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0310 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X FAN CONTROL R 0310 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7

 13 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X FAN CONTROL R 0311 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X FAN CONTROL R 0311 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X FAN CONTROL R 0311 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
O FRCB MECHA 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O FRCB MECHA 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7
O FRCB MECHA 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
X FRCB MECHA 8B-CL2-229-010 0E CUSH,G 6.5-6.5-6 W/ADH EZSM CX-SLX7
X FRCB MECHA 8B-CL2-229-010 0E CUSH,G 6.5-6.5-6 W/ADH KSM CX-SLX7
X FRCB MECHA 8B-CL2-229-010 0E CUSH,G 6.5-6.5-6 W/ADH USM CX-SLX7
X FRCB MECHA * 8B-CL2-017-010 1D SH,DIFFUSION EZSM CX-SLX7

X FRCB MECHA * 8B-CL2-017-010 1D SH,DIFFUSION KSM CX-SLX7
X FRCB MECHA * 8B-CL2-017-010 1D SH,DIFFUSION USM CX-SLX7
X FRCB MECHA * 8B-CL2-018-010 0E SH,LCD EZSM CX-SLX7
X FRCB MECHA * 8B-CL2-018-010 0E SH,LCD KSM CX-SLX7
X FRCB MECHA * 8B-CL2-018-010 0E SH,LCD USM CX-SLX7
O FRCB MECHA * 8B-CL2-029-010 1D REFLECTOR,LCD EZSM CX-SLX7
O FRCB MECHA * 8B-CL2-029-010 1D REFLECTOR,LCD KSM CX-SLX7
O FRCB MECHA * 8B-CL2-029-010 1D REFLECTOR,LCD USM CX-SLX7
X FRCB MECHA * 8B-CL2-207-010 1 HT-SINK,TR SUB USM CX-SLX7
X FRCB MECHA * 8B-CL2-207-010 1B HT-SINK,TR SUB EZSM CX-SLX7

X FRCB MECHA * 8B-CL2-207-010 1B HT-SINK,TR SUB KSM CX-SLX7
O FRCB MECHA * 8B-CL2-220-010 0E GUIDE,LCD EZSM CX-SLX7
O FRCB MECHA * 8B-CL2-220-010 0E GUIDE,LCD KSM CX-SLX7
O FRCB MECHA * 8B-CL2-220-010 0E GUIDE,LCD USM CX-SLX7
X KEY/DISP * 8B-CL2-620-110 1D PWB,COMBI FRONT EZSM CX-SLX7
X KEY/DISP * 8B-CL2-620-110 1D PWB,COMBI FRONT KSM CX-SLX7
X KEY/DISP * 8B-CL2-620-110 1D PWB,COMBI FRONT USM CX-SLX7
X KEY/DISP * 8B-CL2-621-110 -- PWB,FRONT EZSM CX-SLX7
X KEY/DISP * 8B-CL2-621-110 -- PWB,FRONT KSM CX-SLX7
X KEY/DISP * 8B-CL2-621-110 -- PWB,FRONT USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X KEY/DISP * 8B-CL2-622-110 -- PWB,SUPPLY EZSM CX-SLX7
X KEY/DISP * 8B-CL2-622-110 -- PWB,SUPPLY KSM CX-SLX7
X KEY/DISP * 8B-CL2-622-110 -- PWB,SUPPLY USM CX-SLX7
X KEY/DISP * 8B-CL2-623-110 -- PWB,MOSW EZSM CX-SLX7
X KEY/DISP * 8B-CL2-623-110 -- PWB,MOSW KSM CX-SLX7
X KEY/DISP * 8B-CL2-623-110 -- PWB,MOSW USM CX-SLX7
X KEY/DISP * 8B-CL2-624-110 -- PWB,KEY EZSM CX-SLX7
X KEY/DISP * 8B-CL2-624-110 -- PWB,KEY KSM CX-SLX7
X KEY/DISP * 8B-CL2-624-110 -- PWB,KEY USM CX-SLX7
X KEY/DISP * 8B-CL2-625-110 -- PWB,HP EZSM CX-SLX7

X KEY/DISP * 8B-CL2-625-110 -- PWB,HP KSM CX-SLX7
X KEY/DISP * 8B-CL2-625-110 -- PWB,HP USM CX-SLX7
O KEY/DISP C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O KEY/DISP C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O KEY/DISP C 0101 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O KEY/DISP C 0102 87-010-560-040 0E CAP,E 10-50 M 5L MA EZSM CX-SLX7
O KEY/DISP C 0102 87-010-560-040 0E CAP,E 10-50 M 5L MA KSM CX-SLX7
O KEY/DISP C 0102 87-010-560-040 0E CAP,E 10-50 M 5L MA USM CX-SLX7
O KEY/DISP C 0103 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O KEY/DISP C 0103 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7

O KEY/DISP C 0103 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7
O KEY/DISP C 0104 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O KEY/DISP C 0104 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7
O KEY/DISP C 0104 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7
O KEY/DISP C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O KEY/DISP C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O KEY/DISP C 0105 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O KEY/DISP C 0106 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O KEY/DISP C 0106 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O KEY/DISP C 0106 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7

O KEY/DISP C 0107 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O KEY/DISP C 0107 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O KEY/DISP C 0107 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O KEY/DISP C 0108 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O KEY/DISP C 0108 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O KEY/DISP C 0108 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O KEY/DISP C 0111 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O KEY/DISP C 0111 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O KEY/DISP C 0111 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O KEY/DISP C 0112 87-010-560-040 0E CAP,E 10-50 M 5L MA EZSM CX-SLX7

 14 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O KEY/DISP C 0112 87-010-560-040 0E CAP,E 10-50 M 5L MA KSM CX-SLX7
O KEY/DISP C 0112 87-010-560-040 0E CAP,E 10-50 M 5L MA USM CX-SLX7
O KEY/DISP C 0113 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O KEY/DISP C 0113 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O KEY/DISP C 0113 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O KEY/DISP C 0114 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O KEY/DISP C 0114 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O KEY/DISP C 0114 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O KEY/DISP C 0142 87-010-553-040 0E CAP,E 47-16 M 5L SRE EZSM CX-SLX7
O KEY/DISP C 0142 87-010-553-040 0E CAP,E 47-16 M 5L SRE KSM CX-SLX7

O KEY/DISP C 0142 87-010-553-040 0E CAP,E 47-16 M 5L SRE USM CX-SLX7
O KEY/DISP CN 0101 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK EZSM CX-SLX7
O KEY/DISP CN 0101 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK KSM CX-SLX7
O KEY/DISP CN 0101 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK USM CX-SLX7
! O KEY/DISP CN 0102 87-099-201-010 0E CONN,8P H BLK 6216 EZSM CX-SLX7
! O KEY/DISP CN 0102 87-099-201-010 0E CONN,8P H BLK 6216 KSM CX-SLX7
! O KEY/DISP CN 0102 87-099-201-010 0E CONN,8P H BLK 6216 USM CX-SLX7
! O KEY/DISP CN 0141 87-A60-079-010 0E CONN,08P H 9604S-08F EZSM CX-SLX7
! O KEY/DISP CN 0141 87-A60-079-010 0E CONN,08P H 9604S-08F KSM CX-SLX7
! O KEY/DISP CN 0141 87-A60-079-010 0E CONN,08P H 9604S-08F USM CX-SLX7

! O KEY/DISP CN 0142 87-A60-082-010 0E CONN,05P H 9604S-05F EZSM CX-SLX7
! O KEY/DISP CN 0142 87-A60-082-010 0E CONN,05P H 9604S-05F KSM CX-SLX7
! O KEY/DISP CN 0142 87-A60-082-010 0E CONN,05P H 9604S-05F USM CX-SLX7
! O KEY/DISP CN 0151 87-A60-082-010 0E CONN,05P H 9604S-05F EZSM CX-SLX7
! O KEY/DISP CN 0151 87-A60-082-010 0E CONN,05P H 9604S-05F KSM CX-SLX7
! O KEY/DISP CN 0151 87-A60-082-010 0E CONN,05P H 9604S-05F USM CX-SLX7
S KEY/DISP D 0101 87-070-136-080 0E ZENER,MTZJ5.1B EZSM CX-SLX7
S KEY/DISP D 0101 87-070-136-080 0E ZENER,MTZJ5.1B KSM CX-SLX7
S KEY/DISP D 0101 87-070-136-080 0E ZENER,MTZJ5.1B USM CX-SLX7
X KEY/DISP D 0104 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X KEY/DISP D 0104 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X KEY/DISP D 0104 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
X KEY/DISP D 0126 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7
X KEY/DISP D 0126 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X KEY/DISP D 0126 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
S KEY/DISP IC 0101 87-A21-968-030 1H C-IC,LC75824E EZSM CX-SLX7
S KEY/DISP IC 0101 87-A21-968-030 1H C-IC,LC75824E KSM CX-SLX7
S KEY/DISP IC 0101 87-A21-968-030 1H C-IC,LC75824E USM CX-SLX7
S KEY/DISP IC 0102 87-A22-043-010 1B IC,SPS-440-1-E1 EZSM CX-SLX7
S KEY/DISP IC 0102 87-A22-043-010 1B IC,SPS-440-1-E1 KSM CX-SLX7

S KEY/DISP IC 0102 87-A22-043-010 1B IC,SPS-440-1-E1 USM CX-SLX7
X KEY/DISP JR 0101 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X KEY/DISP JR 0101 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X KEY/DISP JR 0101 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X KEY/DISP JR 0102 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X KEY/DISP JR 0102 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X KEY/DISP JR 0102 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X KEY/DISP JR 0110 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X KEY/DISP JR 0110 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X KEY/DISP JR 0110 88-108-000-080 0E C-JUMPER,U USM CX-SLX7

X KEY/DISP JR 0111 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X KEY/DISP JR 0111 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X KEY/DISP JR 0111 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
O KEY/DISP LCD0101 8B-CL2-605-010 1H LCD,AIW4277-30PIN BCL-2 EZSM CX-SLX7
O KEY/DISP LCD0101 8B-CL2-605-010 1H LCD,AIW4277-30PIN BCL-2 KSM CX-SLX7
O KEY/DISP LCD0101 8B-CL2-605-010 1H LCD,AIW4277-30PIN BCL-2 USM CX-SLX7
O KEY/DISP LED0101 87-A40-317-080 0E LED,SLR-342VCT31 RED EZSM CX-SLX7
O KEY/DISP LED0101 87-A40-317-080 0E LED,SLR-342VCT31 RED KSM CX-SLX7
O KEY/DISP LED0101 87-A40-317-080 0E LED,SLR-342VCT31 RED USM CX-SLX7
O KEY/DISP LED0102 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB EZSM CX-SLX7

O KEY/DISP LED0102 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB KSM CX-SLX7
O KEY/DISP LED0102 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB USM CX-SLX7
O KEY/DISP LED0103 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB EZSM CX-SLX7
O KEY/DISP LED0103 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB KSM CX-SLX7
O KEY/DISP LED0103 87-A92-077-010 1E LED,SMLU1BE16C-SLF73 BLU/UMB USM CX-SLX7
O KEY/DISP LED0104 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR EZSM CX-SLX7
O KEY/DISP LED0104 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR KSM CX-SLX7
O KEY/DISP LED0104 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR USM CX-SLX7
O KEY/DISP LED0105 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR EZSM CX-SLX7
O KEY/DISP LED0105 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR KSM CX-SLX7

 15 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O KEY/DISP LED0105 87-A92-078-010 1D LED,SELU1D10CXM-SLF38 GR USM CX-SLX7
S KEY/DISP Q 0101 87-026-609-080 0E TR,KTA1266GR EZSM CX-SLX7
S KEY/DISP Q 0101 87-026-609-080 0E TR,KTA1266GR KSM CX-SLX7
S KEY/DISP Q 0101 87-026-609-080 0E TR,KTA1266GR USM CX-SLX7
S KEY/DISP Q 0102 87-026-609-080 0E TR,KTA1266GR EZSM CX-SLX7
S KEY/DISP Q 0102 87-026-609-080 0E TR,KTA1266GR KSM CX-SLX7
S KEY/DISP Q 0102 87-026-609-080 0E TR,KTA1266GR USM CX-SLX7
S KEY/DISP Q 0103 87-026-609-080 0E TR,KTA1266GR EZSM CX-SLX7
S KEY/DISP Q 0103 87-026-609-080 0E TR,KTA1266GR KSM CX-SLX7
S KEY/DISP Q 0103 87-026-609-080 0E TR,KTA1266GR USM CX-SLX7

S KEY/DISP Q 0104 87-A30-427-040 0E C-TR,DTC114EKA EZSM CX-SLX7
S KEY/DISP Q 0104 87-A30-427-040 0E C-TR,DTC114EKA KSM CX-SLX7
S KEY/DISP Q 0104 87-A30-427-040 0E C-TR,DTC114EKA USM CX-SLX7
S KEY/DISP Q 0105 87-A30-427-040 0E C-TR,DTC114EKA EZSM CX-SLX7
S KEY/DISP Q 0105 87-A30-427-040 0E C-TR,DTC114EKA KSM CX-SLX7
S KEY/DISP Q 0105 87-A30-427-040 0E C-TR,DTC114EKA USM CX-SLX7
S KEY/DISP Q 0106 87-A30-427-040 0E C-TR,DTC114EKA EZSM CX-SLX7
S KEY/DISP Q 0106 87-A30-427-040 0E C-TR,DTC114EKA KSM CX-SLX7
S KEY/DISP Q 0106 87-A30-427-040 0E C-TR,DTC114EKA USM CX-SLX7
S KEY/DISP Q 0107 87-A30-447-040 1F C-TR,DTA114EKA EZSM CX-SLX7

S KEY/DISP Q 0107 87-A30-447-040 1F C-TR,DTA114EKA KSM CX-SLX7
S KEY/DISP Q 0107 87-A30-447-040 1F C-TR,DTA114EKA USM CX-SLX7
S KEY/DISP Q 0143 87-A30-520-080 0E TR,2SC5342Y EZSM CX-SLX7
S KEY/DISP Q 0143 87-A30-520-080 0E TR,2SC5342Y KSM CX-SLX7
S KEY/DISP Q 0143 87-A30-520-080 0E TR,2SC5342Y USM CX-SLX7
S KEY/DISP Q 0144 87-A30-515-080 0E TR,2SA1979O/Y EZSM CX-SLX7
S KEY/DISP Q 0144 87-A30-515-080 0E TR,2SA1979O/Y KSM CX-SLX7
S KEY/DISP Q 0144 87-A30-515-080 0E TR,2SA1979O/Y USM CX-SLX7
S KEY/DISP Q 0145 87-A30-520-080 0E TR,2SC5342Y EZSM CX-SLX7
S KEY/DISP Q 0145 87-A30-520-080 0E TR,2SC5342Y KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S KEY/DISP Q 0145 87-A30-520-080 0E TR,2SC5342Y USM CX-SLX7
S KEY/DISP Q 0146 87-A30-515-080 0E TR,2SA1979O/Y EZSM CX-SLX7
S KEY/DISP Q 0146 87-A30-515-080 0E TR,2SA1979O/Y KSM CX-SLX7
S KEY/DISP Q 0146 87-A30-515-080 0E TR,2SA1979O/Y USM CX-SLX7
S KEY/DISP Q 0147 87-A30-427-040 0E C-TR,DTC114EKA EZSM CX-SLX7
S KEY/DISP Q 0147 87-A30-427-040 0E C-TR,DTC114EKA KSM CX-SLX7
S KEY/DISP Q 0147 87-A30-427-040 0E C-TR,DTC114EKA USM CX-SLX7
S KEY/DISP Q 0148 87-A30-427-040 0E C-TR,DTC114EKA EZSM CX-SLX7
S KEY/DISP Q 0148 87-A30-427-040 0E C-TR,DTC114EKA KSM CX-SLX7
S KEY/DISP Q 0148 87-A30-427-040 0E C-TR,DTC114EKA USM CX-SLX7

X KEY/DISP R 0101 88-108-184-080 0E C-RES,U 180K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0101 88-108-184-080 0E C-RES,U 180K-1/16W J KSM CX-SLX7
X KEY/DISP R 0101 88-108-184-080 0E C-RES,U 180K-1/16W J USM CX-SLX7
X KEY/DISP R 0102 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0102 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X KEY/DISP R 0102 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X KEY/DISP R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X KEY/DISP R 0103 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0104 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7

X KEY/DISP R 0104 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X KEY/DISP R 0104 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0105 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0105 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X KEY/DISP R 0105 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0106 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0106 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X KEY/DISP R 0106 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X KEY/DISP R 0107 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0107 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X KEY/DISP R 0107 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0108 88-128-150-080 0E C-RES, 15-1/8W J EZSM CX-SLX7
X KEY/DISP R 0108 88-128-150-080 0E C-RES, 15-1/8W J KSM CX-SLX7
X KEY/DISP R 0108 88-128-150-080 0E C-RES, 15-1/8W J USM CX-SLX7
X KEY/DISP R 0109 88-128-221-080 0E C-RES, 220-1/8W J EZSM CX-SLX7
X KEY/DISP R 0109 88-128-221-080 0E C-RES, 220-1/8W J KSM CX-SLX7
X KEY/DISP R 0109 88-128-221-080 0E C-RES, 220-1/8W J USM CX-SLX7
X KEY/DISP R 0110 88-128-221-080 0E C-RES, 220-1/8W J EZSM CX-SLX7
X KEY/DISP R 0110 88-128-221-080 0E C-RES, 220-1/8W J KSM CX-SLX7
X KEY/DISP R 0110 88-128-221-080 0E C-RES, 220-1/8W J USM CX-SLX7

 16 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X KEY/DISP R 0111 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0111 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X KEY/DISP R 0111 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0112 88-128-151-080 0E C-RES, 150-1/8W J EZSM CX-SLX7
X KEY/DISP R 0112 88-128-151-080 0E C-RES, 150-1/8W J KSM CX-SLX7
X KEY/DISP R 0112 88-128-151-080 0E C-RES, 150-1/8W J USM CX-SLX7
X KEY/DISP R 0113 88-128-151-080 0E C-RES, 150-1/8W J EZSM CX-SLX7
X KEY/DISP R 0113 88-128-151-080 0E C-RES, 150-1/8W J KSM CX-SLX7
X KEY/DISP R 0113 88-128-151-080 0E C-RES, 150-1/8W J USM CX-SLX7
X KEY/DISP R 0114 88-128-150-080 0E C-RES, 15-1/8W J EZSM CX-SLX7

X KEY/DISP R 0114 88-128-150-080 0E C-RES, 15-1/8W J KSM CX-SLX7
X KEY/DISP R 0114 88-128-150-080 0E C-RES, 15-1/8W J USM CX-SLX7
X KEY/DISP R 0115 88-128-150-080 0E C-RES, 15-1/8W J EZSM CX-SLX7
X KEY/DISP R 0115 88-128-150-080 0E C-RES, 15-1/8W J KSM CX-SLX7
X KEY/DISP R 0115 88-128-150-080 0E C-RES, 15-1/8W J USM CX-SLX7
X KEY/DISP R 0116 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0116 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X KEY/DISP R 0116 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X KEY/DISP R 0117 88-128-391-080 0E C-RES, 390-1/8W J EZSM CX-SLX7
X KEY/DISP R 0117 88-128-391-080 0E C-RES, 390-1/8W J KSM CX-SLX7

X KEY/DISP R 0117 88-128-391-080 0E C-RES, 390-1/8W J USM CX-SLX7
X KEY/DISP R 0118 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0118 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X KEY/DISP R 0118 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X KEY/DISP R 0119 88-121-221-080 0E RES,220-1/8W J EZSM CX-SLX7
X KEY/DISP R 0119 88-121-221-080 0E RES,220-1/8W J KSM CX-SLX7
X KEY/DISP R 0119 88-121-221-080 0E RES,220-1/8W J USM CX-SLX7
X KEY/DISP R 0120 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0120 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X KEY/DISP R 0120 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X KEY/DISP R 0121 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0121 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X KEY/DISP R 0121 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X KEY/DISP R 0122 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0122 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X KEY/DISP R 0122 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X KEY/DISP R 0123 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0123 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X KEY/DISP R 0123 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X KEY/DISP R 0124 88-128-391-080 0E C-RES, 390-1/8W J EZSM CX-SLX7

X KEY/DISP R 0124 88-128-391-080 0E C-RES, 390-1/8W J KSM CX-SLX7
X KEY/DISP R 0124 88-128-391-080 0E C-RES, 390-1/8W J USM CX-SLX7
X KEY/DISP R 0125 88-128-101-080 0E C-RES, 100-1/8W J EZSM CX-SLX7
X KEY/DISP R 0125 88-128-101-080 0E C-RES, 100-1/8W J KSM CX-SLX7
X KEY/DISP R 0125 88-128-101-080 0E C-RES, 100-1/8W J USM CX-SLX7
X KEY/DISP R 0131 88-121-122-080 0E RES,1.2K-1/8W J EZSM CX-SLX7
X KEY/DISP R 0131 88-121-122-080 0E RES,1.2K-1/8W J KSM CX-SLX7
X KEY/DISP R 0131 88-121-122-080 0E RES,1.2K-1/8W J USM CX-SLX7
X KEY/DISP R 0132 88-108-182-080 0E C-RES,U 1.8K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0132 88-108-182-080 0E C-RES,U 1.8K-1/16W J KSM CX-SLX7

X KEY/DISP R 0132 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-SLX7
X KEY/DISP R 0133 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0133 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X KEY/DISP R 0133 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X KEY/DISP R 0134 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0134 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X KEY/DISP R 0134 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X KEY/DISP R 0135 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0135 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X KEY/DISP R 0135 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7

X KEY/DISP R 0136 88-108-822-080 0E C-RES,U 8.2K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0136 88-108-822-080 0E C-RES,U 8.2K-1/16W J KSM CX-SLX7
X KEY/DISP R 0136 88-108-822-080 0E C-RES,U 8.2K-1/16W J USM CX-SLX7
X KEY/DISP R 0141 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0141 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X KEY/DISP R 0141 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X KEY/DISP R 0142 88-108-182-080 0E C-RES,U 1.8K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0142 88-108-182-080 0E C-RES,U 1.8K-1/16W J KSM CX-SLX7
X KEY/DISP R 0142 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-SLX7
X KEY/DISP R 0143 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7

 17 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X KEY/DISP R 0143 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X KEY/DISP R 0143 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X KEY/DISP R 0145 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0145 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X KEY/DISP R 0145 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X KEY/DISP R 0146 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0146 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X KEY/DISP R 0146 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X KEY/DISP R 0147 88-108-822-080 0E C-RES,U 8.2K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0147 88-108-822-080 0E C-RES,U 8.2K-1/16W J KSM CX-SLX7

X KEY/DISP R 0147 88-108-822-080 0E C-RES,U 8.2K-1/16W J USM CX-SLX7
X KEY/DISP R 0148 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0148 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X KEY/DISP R 0148 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X KEY/DISP R 0149 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X KEY/DISP R 0149 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X KEY/DISP R 0149 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X KEY/DISP R 0155 88-128-100-080 0E C-RES, 10-1/8W J EZSM CX-SLX7
X KEY/DISP R 0155 88-128-100-080 0E C-RES, 10-1/8W J KSM CX-SLX7
X KEY/DISP R 0155 88-128-100-080 0E C-RES, 10-1/8W J USM CX-SLX7

X KEY/DISP R 0156 88-128-221-080 0E C-RES, 220-1/8W J EZSM CX-SLX7
X KEY/DISP R 0156 88-128-221-080 0E C-RES, 220-1/8W J KSM CX-SLX7
X KEY/DISP R 0156 88-128-221-080 0E C-RES, 220-1/8W J USM CX-SLX7
X KEY/DISP R 0157 88-128-221-080 0E C-RES, 220-1/8W J EZSM CX-SLX7
X KEY/DISP R 0157 88-128-221-080 0E C-RES, 220-1/8W J KSM CX-SLX7
X KEY/DISP R 0157 88-128-221-080 0E C-RES, 220-1/8W J USM CX-SLX7
X KEY/DISP R 0158 88-128-100-080 0E C-RES, 10-1/8W J EZSM CX-SLX7
X KEY/DISP R 0158 88-128-100-080 0E C-RES, 10-1/8W J KSM CX-SLX7
X KEY/DISP R 0158 88-128-100-080 0E C-RES, 10-1/8W J USM CX-SLX7
X KEY/DISP R 0162 88-130-181-080 0E RES,180-1/4W J EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X KEY/DISP R 0162 88-130-181-080 0E RES,180-1/4W J KSM CX-SLX7
X KEY/DISP R 0162 88-130-181-080 0E RES,180-1/4W J USM CX-SLX7
X KEY/DISP R 0163 88-130-181-080 0E RES,180-1/4W J EZSM CX-SLX7
X KEY/DISP R 0163 88-130-181-080 0E RES,180-1/4W J KSM CX-SLX7
X KEY/DISP R 0163 88-130-181-080 0E RES,180-1/4W J USM CX-SLX7
X KEY/DISP R 0164 88-121-472-080 0E RES,4.7K-1/8W J EZSM CX-SLX7
X KEY/DISP R 0164 88-121-472-080 0E RES,4.7K-1/8W J KSM CX-SLX7
X KEY/DISP R 0164 88-121-472-080 0E RES,4.7K-1/8W J USM CX-SLX7
O KEY/DISP S 0101 87-A91-633-010 1A SW,RTRY XRE012103PVB25FINA 1-2 EZSM CX-SLX7
O KEY/DISP S 0101 87-A91-633-010 1A SW,RTRY XRE012103PVB25FINA 1-2 KSM CX-SLX7

O KEY/DISP S 0101 87-A91-633-010 1A SW,RTRY XRE012103PVB25FINA 1-2 USM CX-SLX7
O KEY/DISP S 0111 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0111 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0111 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0112 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0112 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0112 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0113 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0113 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0113 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7

O KEY/DISP S 0114 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0114 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0114 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0115 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0115 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0115 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0116 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0116 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0116 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0117 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7

O KEY/DISP S 0117 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0117 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0141 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0141 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0141 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0142 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0142 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0142 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0143 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0143 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7

 18 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O KEY/DISP S 0143 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0144 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0144 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0144 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0145 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0145 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0145 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0146 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0146 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0146 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7

O KEY/DISP S 0147 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0147 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0147 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0148 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0148 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0148 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0149 87-A90-095-080 0E SW,TACT EVQ11G04M EZSM CX-SLX7
O KEY/DISP S 0149 87-A90-095-080 0E SW,TACT EVQ11G04M KSM CX-SLX7
O KEY/DISP S 0149 87-A90-095-080 0E SW,TACT EVQ11G04M USM CX-SLX7
O KEY/DISP S 0151 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC EZSM CX-SLX7

O KEY/DISP S 0151 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC KSM CX-SLX7
O KEY/DISP S 0151 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC USM CX-SLX7
O KEY/DISP S 0152 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC EZSM CX-SLX7
O KEY/DISP S 0152 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC KSM CX-SLX7
O KEY/DISP S 0152 87-A90-117-010 1A SW,PUSH 1-1-1 MPU10371MLB0 MIC USM CX-SLX7
O KNOB 8B-CL2-025-010 1 KNOB,RTRY VOL USM CX-SLX7
O KNOB 8B-CL2-025-010 1B KNOB,RTRY VOL EZSM CX-SLX7
O KNOB 8B-CL2-025-010 1B KNOB,RTRY VOL KSM CX-SLX7
O KNOB 8B-CL2-044-010 1C KEY,FUN EZSM CX-SLX7
O KNOB 8B-CL2-044-010 1C KEY,FUN KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O KNOB 8B-CL2-044-010 1C KEY,FUN USM CX-SLX7
O KNOB 8B-CL2-047-010 1C KEY,PLAY EZSM CX-SLX7
O KNOB 8B-CL2-047-010 1C KEY,PLAY KSM CX-SLX7
O KNOB 8B-CL2-047-010 1C KEY,PLAY USM CX-SLX7
O KNOB 8B-CL2-048-010 1C KEY,POWER EZSM CX-SLX7
O KNOB 8B-CL2-048-010 1C KEY,POWER KSM CX-SLX7
O KNOB 8B-CL2-048-010 1C KEY,POWER USM CX-SLX7
O KNOB 8B-CL2-049-010 1 KEY,JOG USM CX-SLX7
O KNOB 8B-CL2-049-010 1B KEY,JOG EZSM CX-SLX7
O KNOB 8B-CL2-049-010 1B KEY,JOG KSM CX-SLX7

X LBL,POP 87-B40-034-010 1 LBL,USA 1-800 USM CX-SLX7
X LBL,POP 8A-NF8-972-010 0E LBL,POP ENG USM CX-SLX7
X MACB MECHA 8B-CL2-206-010 1 HT-SINK,TR MAIN USM CX-SLX7
X MACB MECHA 8B-CL2-206-010 1B HT-SINK,TR MAIN EZSM CX-SLX7
X MACB MECHA 8B-CL2-206-010 1B HT-SINK,TR MAIN KSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7

O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
O MACB MECHA * 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
X MICON * 8B-CL2-610-010 1C PWB,AMP-MICON 2M KSM CX-SLX7
X MICON * 8B-CL2-610-110 1C PWB,AMP-MICON 2M EZSM CX-SLX7
X MICON * 8B-CL2-610-110 1C PWB,AMP-MICON 2M USM CX-SLX7

O MICON C 0114 87-016-044-040 0E CAP,E 100-16 M 5L MA EZSM CX-SLX7
O MICON C 0114 87-016-044-040 0E CAP,E 100-16 M 5L MA KSM CX-SLX7
O MICON C 0114 87-016-044-040 0E CAP,E 100-16 M 5L MA USM CX-SLX7
O MICON C 0115 87-016-044-040 0E CAP,E 100-16 M 5L MA EZSM CX-SLX7
O MICON C 0115 87-016-044-040 0E CAP,E 100-16 M 5L MA KSM CX-SLX7
O MICON C 0115 87-016-044-040 0E CAP,E 100-16 M 5L MA USM CX-SLX7
O MICON C 0116 87-016-044-040 0E CAP,E 100-16 M 5L MA EZSM CX-SLX7
O MICON C 0116 87-016-044-040 0E CAP,E 100-16 M 5L MA KSM CX-SLX7
O MICON C 0116 87-016-044-040 0E CAP,E 100-16 M 5L MA USM CX-SLX7
O MICON C 0161 87-010-553-040 0E CAP,E 47-16 M 5L SRE EZSM CX-SLX7

 19 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O MICON C 0161 87-010-553-040 0E CAP,E 47-16 M 5L SRE KSM CX-SLX7
O MICON C 0161 87-010-553-040 0E CAP,E 47-16 M 5L SRE USM CX-SLX7
O MICON C 0162 87-010-496-040 0E CAP,E 3.3-50 M 5L SRE EZSM CX-SLX7
O MICON C 0162 87-010-496-040 0E CAP,E 3.3-50 M 5L SRE KSM CX-SLX7
O MICON C 0162 87-010-496-040 0E CAP,E 3.3-50 M 5L SRE USM CX-SLX7
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B EZSM CX-SLX7
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B KSM CX-SLX7
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O MICON C 0302 87-A10-781-080 0E C-CAP,U 0.15-10 K B EZSM CX-SLX7
O MICON C 0302 87-A10-781-080 0E C-CAP,U 0.15-10 K B KSM CX-SLX7

O MICON C 0302 87-A10-781-080 0E C-CAP,U 0.15-10 K B USM CX-SLX7
O MICON C 0303 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM EZSM CX-SLX7
O MICON C 0303 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM KSM CX-SLX7
O MICON C 0303 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM USM CX-SLX7
O MICON C 0305 87-A12-063-080 0E CAP,E 220-10 SMG EZSM CX-SLX7
O MICON C 0305 87-A12-063-080 0E CAP,E 220-10 SMG KSM CX-SLX7
O MICON C 0305 87-A12-063-080 0E CAP,E 220-10 SMG USM CX-SLX7
O MICON C 0306 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O MICON C 0306 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O MICON C 0306 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7

O MICON C 0307 87-012-176-080 0E C-CAP,U 15P-50 J CH EZSM CX-SLX7
O MICON C 0307 87-012-176-080 0E C-CAP,U 15P-50 J CH KSM CX-SLX7
O MICON C 0307 87-012-176-080 0E C-CAP,U 15P-50 J CH USM CX-SLX7
O MICON C 0308 87-012-198-080 0E C-CAP,U 180P-50 J CH EZSM CX-SLX7
O MICON C 0308 87-012-198-080 0E C-CAP,U 180P-50 J CH KSM CX-SLX7
O MICON C 0308 87-012-198-080 0E C-CAP,U 180P-50 J CH USM CX-SLX7
O MICON C 0309 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O MICON C 0309 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O MICON C 0309 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O MICON C 0310 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O MICON C 0310 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O MICON C 0310 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O MICON C 0313 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O MICON C 0313 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O MICON C 0313 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O MICON C 0314 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O MICON C 0314 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O MICON C 0314 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O MICON C 0315 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O MICON C 0315 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7

O MICON C 0315 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O MICON C 0471 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O MICON C 0471 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O MICON C 0471 87-A11-132-080 0E CAP,TC U 0.01-50 K B KSM CX-SLX7
O MICON C 0472 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O MICON C 0472 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O MICON C 0472 87-A11-132-080 0E CAP,TC U 0.01-50 K B KSM CX-SLX7
O MICON C 0473 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O MICON C 0473 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O MICON C 0473 87-A11-132-080 0E CAP,TC U 0.01-50 K B KSM CX-SLX7

X MICON CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS EZSM CX-SLX7
X MICON CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS KSM CX-SLX7
X MICON CLP0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-SLX7
X MICON CLP0004 87-A60-884-010 0E PIN,DIA1 COATING-SHS EZSM CX-SLX7
X MICON CLP0004 87-A60-884-010 0E PIN,DIA1 COATING-SHS KSM CX-SLX7
X MICON CLP0004 87-A60-884-010 0E PIN,DIA1 COATING-SHS USM CX-SLX7
O MICON CN 0101 87-099-411-010 0E CONN,11P V WHT EH EZSM CX-SLX7
O MICON CN 0101 87-099-411-010 0E CONN,11P V WHT EH KSM CX-SLX7
O MICON CN 0101 87-099-411-010 0E CONN,11P V WHT EH USM CX-SLX7
O MICON CN 0401 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK EZSM CX-SLX7

O MICON CN 0401 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK KSM CX-SLX7
O MICON CN 0401 87-A61-370-010 1A CONN,21P V BLK FMN-BTRK USM CX-SLX7
! O MICON CN 0403 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK EZSM CX-SLX7
! O MICON CN 0403 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK KSM CX-SLX7
! O MICON CN 0403 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK USM CX-SLX7
! O MICON CN 0404 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK EZSM CX-SLX7
! O MICON CN 0404 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK KSM CX-SLX7
! O MICON CN 0404 87-A60-900-010 0E CONN,9P V BLK FMN-BTRK USM CX-SLX7
! O MICON CN 0405 87-099-014-010 0E CONN,12P V BLK 6216 EZSM CX-SLX7
! O MICON CN 0405 87-099-014-010 0E CONN,12P V BLK 6216 KSM CX-SLX7

 20 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

! O MICON CN 0405 87-099-014-010 0E CONN,12P V BLK 6216 USM CX-SLX7
! O MICON CN 0406 87-099-211-010 0E CONN,4P V BLK 6216 EZSM CX-SLX7
O MICON CNA0101 87-A60-620-010 0E CONN,3P V 2MM JMT EZSM CX-SLX7
O MICON CNA0101 87-A60-620-010 0E CONN,3P V 2MM JMT KSM CX-SLX7
O MICON CNA0101 87-A60-620-010 0E CONN,3P V 2MM JMT USM CX-SLX7
S MICON D 0101 87-070-274-080 0E DIODE,1N4003 SEM EZSM CX-SLX7
S MICON D 0101 87-070-274-080 0E DIODE,1N4003 SEM KSM CX-SLX7
S MICON D 0101 87-070-274-080 0E DIODE,1N4003 SEM USM CX-SLX7
S MICON D 0103 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S MICON D 0103 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7

S MICON D 0103 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S MICON D 0105 87-A40-313-080 0E C-DIODE,MC2840 EZSM CX-SLX7
S MICON D 0105 87-A40-313-080 0E C-DIODE,MC2840 KSM CX-SLX7
S MICON D 0105 87-A40-313-080 0E C-DIODE,MC2840 USM CX-SLX7
S MICON D 0106 87-A40-313-080 0E C-DIODE,MC2840 EZSM CX-SLX7
S MICON D 0106 87-A40-313-080 0E C-DIODE,MC2840 KSM CX-SLX7
S MICON D 0106 87-A40-313-080 0E C-DIODE,MC2840 USM CX-SLX7
S MICON D 0107 87-A40-270-080 0E C-DIODE,MC2838 EZSM CX-SLX7
S MICON D 0107 87-A40-270-080 0E C-DIODE,MC2838 KSM CX-SLX7
S MICON D 0107 87-A40-270-080 0E C-DIODE,MC2838 USM CX-SLX7

S MICON D 0110 87-A40-269-080 0E C-DIODE,MC2836 EZSM CX-SLX7
S MICON D 0110 87-A40-269-080 0E C-DIODE,MC2836 KSM CX-SLX7
S MICON D 0110 87-A40-269-080 0E C-DIODE,MC2836 USM CX-SLX7
S MICON D 0301 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S MICON D 0301 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S MICON D 0301 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S MICON D 0302 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S MICON D 0302 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S MICON D 0302 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S MICON D 0303 87-A40-748-080 0E ZENER,UZ5.6BSA EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S MICON D 0303 87-A40-748-080 0E ZENER,UZ5.6BSA KSM CX-SLX7
S MICON D 0303 87-A40-748-080 0E ZENER,UZ5.6BSA USM CX-SLX7
S MICON D 0304 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S MICON D 0304 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S MICON D 0304 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S MICON D 0305 87-070-274-080 0E DIODE,1N4003 SEM EZSM CX-SLX7
S MICON D 0305 87-070-274-080 0E DIODE,1N4003 SEM KSM CX-SLX7
S MICON D 0305 87-070-274-080 0E DIODE,1N4003 SEM USM CX-SLX7
S MICON D 0413 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S MICON D 0413 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7

S MICON D 0413 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S MICON IC 0301 8B-CL2-601-130 2A C-IC,LC876564V-5V69 EZSM CX-SLX7
S MICON IC 0301 8B-CL2-601-130 2A C-IC,LC876564V-5V69 KSM CX-SLX7
S MICON IC 0301 8B-CL2-601-130 2A C-IC,LC876564V-5V69 USM CX-SLX7
X MICON JR 0201 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0201 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0201 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0203 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0203 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0203 88-118-000-080 0E C-JUMPER,S USM CX-SLX7

X MICON JR 0204 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0204 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0204 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0301 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X MICON JR 0301 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X MICON JR 0301 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X MICON JR 0302 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X MICON JR 0302 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X MICON JR 0302 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X MICON JR 0303 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7

X MICON JR 0303 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0303 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0304 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0304 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0304 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0305 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0305 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0305 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0306 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0306 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7

 21 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON JR 0306 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X MICON JR 0310 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X MICON JR 0310 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X MICON JR 0310 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON JR 0401 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X MICON JR 0401 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X MICON JR 0401 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
O MICON L 0151 87-A50-333-010 0E COIL,OSC 9.43MHZ EZSM CX-SLX7
O MICON L 0151 87-A50-333-010 0E COIL,OSC 9.43MHZ KSM CX-SLX7
O MICON L 0151 87-A50-333-010 0E COIL,OSC 9.43MHZ USM CX-SLX7

X MICON PR 0201 88-100-000-010 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7
X MICON PR 0201 88-100-000-010 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X MICON PR 0201 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
X MICON PR 0202 88-100-000-010 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7
X MICON PR 0202 88-100-000-010 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X MICON PR 0202 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
S MICON Q 0106 87-A30-075-080 0E C-TR,2SA1235F EZSM CX-SLX7
S MICON Q 0106 87-A30-075-080 0E C-TR,2SA1235F KSM CX-SLX7
S MICON Q 0106 87-A30-075-080 0E C-TR,2SA1235F USM CX-SLX7
S MICON Q 0107 87-A30-234-080 0E TR,CSC4115BC EZSM CX-SLX7

S MICON Q 0107 87-A30-234-080 0E TR,CSC4115BC KSM CX-SLX7
S MICON Q 0107 87-A30-234-080 0E TR,CSC4115BC USM CX-SLX7
S MICON Q 0151 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0151 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S MICON Q 0151 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0152 87-A30-075-080 0E C-TR,2SA1235F EZSM CX-SLX7
S MICON Q 0152 87-A30-075-080 0E C-TR,2SA1235F KSM CX-SLX7
S MICON Q 0152 87-A30-075-080 0E C-TR,2SA1235F USM CX-SLX7
S MICON Q 0153 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0153 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S MICON Q 0153 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0154 87-A30-075-080 0E C-TR,2SA1235F EZSM CX-SLX7
S MICON Q 0154 87-A30-075-080 0E C-TR,2SA1235F KSM CX-SLX7
S MICON Q 0154 87-A30-075-080 0E C-TR,2SA1235F USM CX-SLX7
S MICON Q 0155 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0155 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S MICON Q 0155 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G EZSM CX-SLX7
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G KSM CX-SLX7
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G USM CX-SLX7

S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0304 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
S MICON Q 0304 87-A30-076-080 0E C-TR,2SC3052F KSM CX-SLX7
S MICON Q 0304 87-A30-076-080 0E C-TR,2SC3052F USM CX-SLX7
S MICON Q 0305 87-A30-484-080 0E C-TR,KRA102S EZSM CX-SLX7

S MICON Q 0305 87-A30-484-080 0E C-TR,KRA102S KSM CX-SLX7
S MICON Q 0305 87-A30-484-080 0E C-TR,KRA102S USM CX-SLX7
S MICON Q 0306 87-A30-490-080 0E C-TR,KRC107S EZSM CX-SLX7
S MICON Q 0306 87-A30-490-080 0E C-TR,KRC107S KSM CX-SLX7
S MICON Q 0306 87-A30-490-080 0E C-TR,KRC107S USM CX-SLX7
S MICON Q 0307 87-A30-087-080 0E C-FET,2SK2158 EZSM CX-SLX7
S MICON Q 0307 87-A30-087-080 0E C-FET,2SK2158 KSM CX-SLX7
S MICON Q 0307 87-A30-087-080 0E C-FET,2SK2158 USM CX-SLX7
X MICON R 0072 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0072 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7

X MICON R 0072 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0078 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X MICON R 0078 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X MICON R 0078 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X MICON R 0114 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X MICON R 0114 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X MICON R 0114 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7

 22 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0117 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X MICON R 0117 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X MICON R 0117 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
X MICON R 0118 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0118 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0118 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0149 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0149 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0149 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0151 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X MICON R 0151 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0151 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0152 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0152 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0152 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0153 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X MICON R 0153 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X MICON R 0153 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X MICON R 0154 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X MICON R 0154 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7

X MICON R 0154 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X MICON R 0158 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X MICON R 0158 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X MICON R 0158 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X MICON R 0166 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X MICON R 0166 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X MICON R 0166 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7
X MICON R 0167 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X MICON R 0167 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X MICON R 0167 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16W J EZSM CX-SLX7
X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16W J KSM CX-SLX7
X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-SLX7
X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7

X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0305 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X MICON R 0305 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X MICON R 0305 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
X MICON R 0306 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0306 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0306 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0307 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X MICON R 0307 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7

X MICON R 0307 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X MICON R 0308 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X MICON R 0308 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X MICON R 0308 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7
X MICON R 0309 88-121-124-080 0E RES,120K-1/8W J EZSM CX-SLX7
X MICON R 0309 88-121-124-080 0E RES,120K-1/8W J KSM CX-SLX7
X MICON R 0309 88-121-124-080 0E RES,120K-1/8W J USM CX-SLX7
X MICON R 0310 88-108-224-080 0E C-RES,U 220K-1/16W J EZSM CX-SLX7
X MICON R 0310 88-108-224-080 0E C-RES,U 220K-1/16W J KSM CX-SLX7
X MICON R 0310 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-SLX7

X MICON R 0311 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X MICON R 0311 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X MICON R 0311 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X MICON R 0312 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X MICON R 0312 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X MICON R 0312 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X MICON R 0313 88-128-224-080 0E C-RES, 220K-1/8W J EZSM CX-SLX7
X MICON R 0313 88-128-224-080 0E C-RES, 220K-1/8W J KSM CX-SLX7
X MICON R 0313 88-128-224-080 0E C-RES, 220K-1/8W J USM CX-SLX7
X MICON R 0314 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

 23 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0314 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0314 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0315 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X MICON R 0315 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X MICON R 0315 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0316 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X MICON R 0316 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X MICON R 0316 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0317 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X MICON R 0317 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7

X MICON R 0317 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0318 88-128-103-080 0E C-RES, 10K-1/8W J EZSM CX-SLX7
X MICON R 0318 88-128-103-080 0E C-RES, 10K-1/8W J KSM CX-SLX7
X MICON R 0318 88-128-103-080 0E C-RES, 10K-1/8W J USM CX-SLX7
O MICON R 0319 87-022-239-080 0E C-RES,U 10K-1/16W F EZSM CX-SLX7
O MICON R 0319 87-022-239-080 0E C-RES,U 10K-1/16W F KSM CX-SLX7
O MICON R 0319 87-022-239-080 0E C-RES,U 10K-1/16W F USM CX-SLX7
X MICON R 0320 88-128-101-080 0E C-RES, 100-1/8W J EZSM CX-SLX7
X MICON R 0320 88-128-101-080 0E C-RES, 100-1/8W J KSM CX-SLX7
X MICON R 0320 88-128-101-080 0E C-RES, 100-1/8W J USM CX-SLX7

X MICON R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0321 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0322 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0322 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0322 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0323 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0323 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0323 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
O MICON R 0324 87-022-239-080 0E C-RES,U 10K-1/16W F EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O MICON R 0324 87-022-239-080 0E C-RES,U 10K-1/16W F KSM CX-SLX7
O MICON R 0324 87-022-239-080 0E C-RES,U 10K-1/16W F USM CX-SLX7
X MICON R 0325 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0325 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X MICON R 0325 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X MICON R 0326 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0326 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X MICON R 0326 88-108-391-080 0E C-RES,U 390-1/16W J KSM CX-SLX7
X MICON R 0327 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0327 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7

X MICON R 0327 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X MICON R 0328 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X MICON R 0328 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X MICON R 0328 88-108-391-080 0E C-RES,U 390-1/16W J KSM CX-SLX7
X MICON R 0329 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0329 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0329 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0331 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0331 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0331 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7

X MICON R 0401 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0401 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0401 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0402 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0402 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0402 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0404 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7

X MICON R 0404 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0404 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0405 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0405 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0405 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0406 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0406 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0406 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0407 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0407 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7

 24 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0407 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0408 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X MICON R 0408 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X MICON R 0408 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X MICON R 0409 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X MICON R 0409 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X MICON R 0409 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X MICON R 0410 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X MICON R 0410 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X MICON R 0410 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7

X MICON R 0411 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X MICON R 0411 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X MICON R 0411 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X MICON R 0421 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0421 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0421 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0422 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0422 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0422 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0423 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7

X MICON R 0423 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0423 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0424 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X MICON R 0424 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X MICON R 0424 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X MICON R 0425 88-121-101-080 0E RES,100-1/8W J EZSM CX-SLX7
X MICON R 0425 88-121-101-080 0E RES,100-1/8W J KSM CX-SLX7
X MICON R 0425 88-121-101-080 0E RES,100-1/8W J USM CX-SLX7
X MICON R 0426 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0426 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON R 0426 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0427 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0427 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0427 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0428 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X MICON R 0428 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X MICON R 0428 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X MICON R 0429 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X MICON R 0429 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X MICON R 0429 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7

X MICON R 0430 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0430 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0430 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0432 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0432 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0432 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0433 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X MICON R 0433 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X MICON R 0433 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X MICON R 0441 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7

X MICON R 0441 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0441 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0442 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0442 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0442 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0443 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0443 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0443 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0444 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0444 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X MICON R 0444 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0445 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0445 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0445 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0446 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0446 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0446 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0447 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0447 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0447 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7

 25 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0448 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0448 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0448 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0449 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X MICON R 0449 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X MICON R 0449 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X MICON R 0451 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0451 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0451 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0452 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

X MICON R 0452 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0452 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0453 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0453 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0453 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X MICON R 0454 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X MICON R 0454 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X MICON R 0454 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X OTHERS 80-MQ1-209-010 0E CLOTH,20-7 EZSM CX-SLX7
X OTHERS 80-MQ1-209-010 0E CLOTH,20-7 KSM CX-SLX7

X OTHERS 80-MQ1-209-010 0E CLOTH,20-7 USM CX-SLX7
! O OTHERS 81-ZG1-212-010 0E PULLY,LOAD MO(*) EZSM CX-SLX7
! O OTHERS 81-ZG1-212-010 0E PULLY,LOAD MO(*) KSM CX-SLX7
! O OTHERS 81-ZG1-212-010 0E PULLY,LOAD MO(*) USM CX-SLX7
O OTHERS 85-NF7-599-010 0E PV CW 3.2-8-0.3 KSM CX-SLX7
X OTHERS 86-ZG1-598-010 0E SH, PVC 4-4-0.3 W/ADH BLK EZSM CX-SLX7
X OTHERS 86-ZG1-598-010 0E SH, PVC 4-4-0.3 W/ADH BLK KSM CX-SLX7
X OTHERS 86-ZG1-598-010 0E SH, PVC 4-4-0.3 W/ADH BLK USM CX-SLX7
X OTHERS 87-064-080-010 0E BINDER,WIRE USM CX-SLX7
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 KSM CX-SLX7
X OTHERS 87-B40-142-010 0E SH, 12-8.5-2 W/ADH FOOT EEA EZSM CX-SLX7
X OTHERS 87-B40-142-010 0E SH, 12-8.5-2 W/ADH FOOT EEA KSM CX-SLX7
X OTHERS 87-B40-142-010 0E SH, 12-8.5-2 W/ADH FOOT EEA USM CX-SLX7
X OTHERS 88-CH6-220-110 0E CUSHION,CD A EZSM CX-SLX7
X OTHERS 88-CH6-220-110 0E CUSHION,CD A KSM CX-SLX7
X OTHERS 88-CH6-220-110 0E CUSHION,CD A USM CX-SLX7
O OTHERS 8A-NF7-251-010 0E W,3.2-8-0.45 EZSM CX-SLX7
O OTHERS 8A-NF7-251-010 0E W,3.2-8-0.45 KSM CX-SLX7
O OTHERS 8A-NF7-251-010 0E W,3.2-8-0.45 USM CX-SLX7

O OTHERS 8B-CL2-201-010 1A HLDR,PT KSM CX-SLX7
O OTHERS 8B-CL2-201-110 1A HLDR,PT EZSM CX-SLX7
O OTHERS 8B-CL2-201-110 1A HLDR,PT USM CX-SLX7
X OTHERS 8B-CL2-202-010 0E SH,LCD 2 EZSM CX-SLX7
X OTHERS 8B-CL2-202-010 0E SH,LCD 2 KSM CX-SLX7
X OTHERS 8B-CL2-202-010 0E SH,LCD 2 USM CX-SLX7
X OTHERS 8B-CL2-203-010 1A SH, 50-30-2 W/ADH EZSM CX-SLX7
X OTHERS 8B-CL2-203-010 1A SH, 50-30-2 W/ADH KSM CX-SLX7
X OTHERS 8B-CL2-203-010 1A SH, 50-30-2 W/ADH USM CX-SLX7
X OTHERS 8B-CL2-204-010 1A SH,SHLD PWB FR EZSM CX-SLX7

X OTHERS 8B-CL2-204-010 1A SH,SHLD PWB FR KSM CX-SLX7
X OTHERS 8B-CL2-204-010 1A SH,SHLD PWB FR USM CX-SLX7
O OTHERS 8B-CL2-205-010 0E HLDR,FOOT EZSM CX-SLX7
O OTHERS 8B-CL2-205-010 0E HLDR,FOOT KSM CX-SLX7
O OTHERS 8B-CL2-205-010 0E HLDR,FOOT USM CX-SLX7
X OTHERS 8B-CL2-208-010 1 HT-SINK,ASSY MAIN USM CX-SLX7
X OTHERS 8B-CL2-208-010 1B HT-SINK,ASSY MAIN EZSM CX-SLX7
X OTHERS 8B-CL2-208-010 1B HT-SINK,ASSY MAIN KSM CX-SLX7
O OTHERS 8B-CL2-211-010 0E CHAS,GEAR KSM CX-SLX7
O OTHERS 8B-CL2-211-110 0E CHAS,GEAR EZSM CX-SLX7

O OTHERS 8B-CL2-211-110 0E CHAS,GEAR USM CX-SLX7
O OTHERS 8B-CL2-212-010 0E HLDR,GEAR EZSM CX-SLX7
O OTHERS 8B-CL2-212-010 0E HLDR,GEAR KSM CX-SLX7
O OTHERS 8B-CL2-212-010 0E HLDR,GEAR USM CX-SLX7
X OTHERS 8B-CL2-213-010 1 SH,SHLD PWB CD USM CX-SLX7
O OTHERS 8B-CL2-214-010 0E GEAR,PULLY EZSM CX-SLX7
O OTHERS 8B-CL2-214-010 0E GEAR,PULLY KSM CX-SLX7
O OTHERS 8B-CL2-214-010 0E GEAR,PULLY USM CX-SLX7
O OTHERS 8B-CL2-215-010 0E GEAR,MIDDLE EZSM CX-SLX7
O OTHERS 8B-CL2-215-010 0E GEAR,MIDDLE KSM CX-SLX7

 26 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O OTHERS 8B-CL2-215-010 0E GEAR,MIDDLE USM CX-SLX7
O OTHERS 8B-CL2-216-010 0E GEAR,OUT EZSM CX-SLX7
O OTHERS 8B-CL2-216-010 0E GEAR,OUT KSM CX-SLX7
O OTHERS 8B-CL2-216-010 0E GEAR,OUT USM CX-SLX7
X OTHERS 8B-CL2-217-010 0E SH,ADH TOP EZSM CX-SLX7
X OTHERS 8B-CL2-217-010 0E SH,ADH TOP KSM CX-SLX7
X OTHERS 8B-CL2-217-010 0E SH,ADH TOP USM CX-SLX7
O OTHERS 8B-CL2-218-010 0E HLDR,LCD R EZSM CX-SLX7
O OTHERS 8B-CL2-218-010 0E HLDR,LCD R KSM CX-SLX7
O OTHERS 8B-CL2-218-010 0E HLDR,LCD R USM CX-SLX7

O OTHERS 8B-CL2-219-010 0E HLDR,LCD L EZSM CX-SLX7
O OTHERS 8B-CL2-219-010 0E HLDR,LCD L KSM CX-SLX7
O OTHERS 8B-CL2-219-010 0E HLDR,LCD L USM CX-SLX7
O OTHERS 8B-CL2-223-010 0E HLDR,ARM L EZSM CX-SLX7
O OTHERS 8B-CL2-223-010 0E HLDR,ARM L KSM CX-SLX7
O OTHERS 8B-CL2-223-010 0E HLDR,ARM L USM CX-SLX7
O OTHERS 8B-CL2-225-010 0E BELT,SQ1.2-32.2 EZSM CX-SLX7
O OTHERS 8B-CL2-225-010 0E BELT,SQ1.2-32.2 KSM CX-SLX7
O OTHERS 8B-CL2-225-010 0E BELT,SQ1.2-32.2 USM CX-SLX7
O OTHERS 8B-CL2-226-010 0E W-P,6.5-12.8-0.3 B W/O ADH EZSM CX-SLX7

O OTHERS 8B-CL2-226-010 0E W-P,6.5-12.8-0.3 B W/O ADH KSM CX-SLX7
O OTHERS 8B-CL2-226-010 0E W-P,6.5-12.8-0.3 B W/O ADH USM CX-SLX7
X OTHERS 8B-CL2-228-010 0E SH, 3-25-0.1 W/ADH EZSM CX-SLX7
X OTHERS 8B-CL2-228-010 0E SH, 3-25-0.1 W/ADH KSM CX-SLX7
X OTHERS 8B-CL2-228-010 0E SH, 3-25-0.1 W/ADH USM CX-SLX7
X OTHERS 8B-CL2-230-010 0E COVER, WIRE(PT) EZSM CX-SLX7
X OTHERS 8B-CL2-230-010 0E COVER, WIRE(PT) KSM CX-SLX7
X OTHERS 8B-CL2-232-010 1B SH,SHLD PWB (EZ) EZSM CX-SLX7
X OTHERS 8B-CL2-232-010 1B SH,SHLD PWB (EZ) KSM CX-SLX7
X PACKING DU 87-051-136-110 0E BAG,PV 0.03-160-280 KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X PACKING DU 87-B40-090-010 0E BAG,PV 0.04-400-500 PL EZSM CX-SLX7
X PACKING DU 87-B40-090-010 0E BAG,PV 0.04-400-500 PL KSM CX-SLX7
X PACKING DU 87-B40-090-010 0E BAG,PV 0.04-400-500 PL USM CX-SLX7
X PACKING DU 8B-CL2-851-010 1A CUSHION,FRONT M EZSM CX-SLX7
X PACKING DU 8B-CL2-851-010 1A CUSHION,FRONT M KSM CX-SLX7
X PACKING DU 8B-CL2-851-010 1A CUSHION,FRONT M USM CX-SLX7
X PACKING DU 8B-CL2-852-110 1A CUSHION,REAR M EZSM CX-SLX7
X PACKING DU 8B-CL2-852-110 1A CUSHION,REAR M KSM CX-SLX7
X PACKING DU 8B-CL2-852-110 1A CUSHION,REAR M USM CX-SLX7
X PACKING DU 8B-CL2-853-010 1 BOX,ACCESS M USM CX-SLX7

X PACKING DU 8B-CL2-853-010 1B BOX,ACCESS M EZSM CX-SLX7
X PACKING DU 8B-CL2-853-010 1B BOX,ACCESS M KSM CX-SLX7
X PACKING DU 93-324-066-010 0E SH,FOAMED-MAT 0.31-500-300 EZSM CX-SLX7
X PACKING DU 93-324-066-010 0E SH,FOAMED-MAT 0.31-500-300 KSM CX-SLX7
X PACKING DU 93-324-066-010 0E SH,FOAMED-MAT 0.31-500-300 USM CX-SLX7
X PLATE 84-711-909-010 1A LBL DATE CODE USM CX-SLX7
! X PLATE 87-057-961-010 0E LBL,CAUTION TRIANGLE EZSM CX-SLX7
! X PLATE 87-057-961-010 0E LBL,CAUTION TRIANGLE KSM CX-SLX7
! X PLATE 87-057-995-010 0E LBL,CAUTION EFSD EZSM CX-SLX7
! X PLATE 87-057-995-010 0E LBL,CAUTION EFSD KSM CX-SLX7

X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 EZSM CX-SLX7
X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 KSM CX-SLX7
X PLATE 87-B40-282-010 0E LBL,BAR-CODE AU 35X8 USM CX-SLX7
O PLATE 8B-CL2-012-010 0E PLATE,OPE(L2) EZSM CX-SLX7
O PLATE 8B-CL2-012-010 0E PLATE,OPE(L2) KSM CX-SLX7
O PLATE 8B-CL2-012-010 0E PLATE,OPE(L2) USM CX-SLX7
O PLATE 8B-CL2-026-010 0E REFLECTOR,VOL EZSM CX-SLX7
O PLATE 8B-CL2-026-010 0E REFLECTOR,VOL KSM CX-SLX7
O PLATE 8B-CL2-026-010 0E REFLECTOR,VOL USM CX-SLX7
O PLATE 8B-CL2-027-010 0E REFLECTOR,POWER EZSM CX-SLX7

O PLATE 8B-CL2-027-010 0E REFLECTOR,POWER KSM CX-SLX7
O PLATE 8B-CL2-027-010 0E REFLECTOR,POWER USM CX-SLX7
X PLATE 8B-CL2-037-010 0E LBL,SPEC USM USM CX-SLX7
O POWER AMP C 0201 87-012-278-080 0E C-CAP,U 2200P-50 K B EZSM CX-SLX7
O POWER AMP C 0201 87-012-278-080 0E C-CAP,U 2200P-50 K B KSM CX-SLX7
O POWER AMP C 0201 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O POWER AMP C 0202 87-012-278-080 0E C-CAP,U 2200P-50 K B EZSM CX-SLX7
O POWER AMP C 0202 87-012-278-080 0E C-CAP,U 2200P-50 K B KSM CX-SLX7
O POWER AMP C 0202 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O POWER AMP C 0203 87-010-421-080 0E CAP,E 4.7-50 M 5L SRE EZSM CX-SLX7

 27 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O POWER AMP C 0203 87-010-421-080 0E CAP,E 4.7-50 M 5L SRE KSM CX-SLX7
O POWER AMP C 0203 87-010-421-080 0E CAP,E 4.7-50 M 5L SRE USM CX-SLX7
O POWER AMP C 0204 87-A12-090-080 0E CAP,E 4.7-50 SMG EZSM CX-SLX7
O POWER AMP C 0204 87-A12-090-080 0E CAP,E 4.7-50 SMG KSM CX-SLX7
O POWER AMP C 0204 87-A12-090-080 0E CAP,E 4.7-50 SMG USM CX-SLX7
O POWER AMP C 0205 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM EZSM CX-SLX7
O POWER AMP C 0205 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM KSM CX-SLX7
O POWER AMP C 0205 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM USM CX-SLX7
O POWER AMP C 0206 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM EZSM CX-SLX7
O POWER AMP C 0206 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM KSM CX-SLX7

O POWER AMP C 0206 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM USM CX-SLX7
O POWER AMP C 0207 87-A12-090-080 0E CAP,E 4.7-50 SMG EZSM CX-SLX7
O POWER AMP C 0207 87-A12-090-080 0E CAP,E 4.7-50 SMG KSM CX-SLX7
O POWER AMP C 0207 87-A12-090-080 0E CAP,E 4.7-50 SMG USM CX-SLX7
O POWER AMP C 0208 87-A12-090-080 0E CAP,E 4.7-50 SMG EZSM CX-SLX7
O POWER AMP C 0208 87-A12-090-080 0E CAP,E 4.7-50 SMG KSM CX-SLX7
O POWER AMP C 0208 87-A12-090-080 0E CAP,E 4.7-50 SMG USM CX-SLX7
O POWER AMP C 0211 87-A12-070-080 0E CAP,E 33-25 SMG EZSM CX-SLX7
O POWER AMP C 0211 87-A12-070-080 0E CAP,E 33-25 SMG KSM CX-SLX7
O POWER AMP C 0211 87-A12-070-080 0E CAP,E 33-25 SMG USM CX-SLX7

O POWER AMP C 0212 87-A12-070-080 0E CAP,E 33-25 SMG EZSM CX-SLX7
O POWER AMP C 0212 87-A12-070-080 0E CAP,E 33-25 SMG KSM CX-SLX7
O POWER AMP C 0212 87-A12-070-080 0E CAP,E 33-25 SMG USM CX-SLX7
O POWER AMP C 0213 87-012-266-080 0E C-CAP,U 220P-50 K B GRM EZSM CX-SLX7
O POWER AMP C 0213 87-012-266-080 0E C-CAP,U 220P-50 K B GRM KSM CX-SLX7
O POWER AMP C 0213 87-012-266-080 0E C-CAP,U 220P-50 K B GRM USM CX-SLX7
O POWER AMP C 0214 87-012-266-080 0E C-CAP,U 220P-50 K B GRM EZSM CX-SLX7
O POWER AMP C 0214 87-012-266-080 0E C-CAP,U 220P-50 K B GRM KSM CX-SLX7
O POWER AMP C 0214 87-012-266-080 0E C-CAP,U 220P-50 K B GRM USM CX-SLX7
O POWER AMP C 0219 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O POWER AMP C 0219 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O POWER AMP C 0219 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O POWER AMP C 0220 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O POWER AMP C 0220 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O POWER AMP C 0220 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O POWER AMP C 0221 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER AMP C 0221 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER AMP C 0221 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER AMP C 0222 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER AMP C 0222 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7

O POWER AMP C 0222 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER AMP C 0231 87-010-490-040 0E CAP,E 0.1-50 M 5L MA EZSM CX-SLX7
O POWER AMP C 0231 87-010-490-040 0E CAP,E 0.1-50 M 5L MA KSM CX-SLX7
O POWER AMP C 0231 87-010-490-040 0E CAP,E 0.1-50 M 5L MA USM CX-SLX7
O POWER AMP C 0232 87-010-490-040 0E CAP,E 0.1-50 M 5L MA EZSM CX-SLX7
O POWER AMP C 0232 87-010-490-040 0E CAP,E 0.1-50 M 5L MA KSM CX-SLX7
O POWER AMP C 0232 87-010-490-040 0E CAP,E 0.1-50 M 5L MA USM CX-SLX7
O POWER AMP C 0298 87-012-282-080 0E C-CAP,U 4700P-50 K B EZSM CX-SLX7
O POWER AMP C 0298 87-012-282-080 0E C-CAP,U 4700P-50 K B KSM CX-SLX7
O POWER AMP C 0298 87-012-282-080 0E C-CAP,U 4700P-50 K B USM CX-SLX7

O POWER AMP C 0299 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O POWER AMP C 0299 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O POWER AMP C 0299 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
! O POWER AMP CN 0201 87-049-919-010 0E CONN,3P V WHT EH EZSM CX-SLX7
! O POWER AMP CN 0201 87-049-919-010 0E CONN,3P V WHT EH KSM CX-SLX7
! O POWER AMP CN 0201 87-049-919-010 0E CONN,3P V WHT EH USM CX-SLX7
S POWER AMP D 0201 87-A40-505-040 0E C-DIODE,KDS181 EZSM CX-SLX7
S POWER AMP D 0201 87-A40-505-040 0E C-DIODE,KDS181 KSM CX-SLX7
S POWER AMP D 0201 87-A40-505-040 0E C-DIODE,KDS181 USM CX-SLX7
S POWER AMP D 0203 87-017-650-080 0E DIODE,1SS119 EZSM CX-SLX7

S POWER AMP D 0203 87-017-650-080 0E DIODE,1SS119 KSM CX-SLX7
S POWER AMP D 0203 87-017-650-080 0E DIODE,1SS119 USM CX-SLX7
S POWER AMP D 0204 87-017-650-080 0E DIODE,1SS119 EZSM CX-SLX7
S POWER AMP D 0204 87-017-650-080 0E DIODE,1SS119 KSM CX-SLX7
S POWER AMP D 0204 87-017-650-080 0E DIODE,1SS119 USM CX-SLX7
S POWER AMP D 0205 87-A40-505-040 0E C-DIODE,KDS181 EZSM CX-SLX7
S POWER AMP D 0205 87-A40-505-040 0E C-DIODE,KDS181 KSM CX-SLX7
S POWER AMP D 0205 87-A40-505-040 0E C-DIODE,KDS181 USM CX-SLX7
S POWER AMP D 0206 87-A40-505-040 0E C-DIODE,KDS181 EZSM CX-SLX7
S POWER AMP D 0206 87-A40-505-040 0E C-DIODE,KDS181 KSM CX-SLX7

 28 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S POWER AMP D 0206 87-A40-505-040 0E C-DIODE,KDS181 USM CX-SLX7
S POWER AMP D 0215 87-A40-504-040 0E C-DIODE,KDS184 EZSM CX-SLX7
S POWER AMP D 0215 87-A40-504-040 0E C-DIODE,KDS184 KSM CX-SLX7
S POWER AMP D 0215 87-A40-504-040 0E C-DIODE,KDS184 USM CX-SLX7
S POWER AMP D 0250 87-A40-504-040 0E C-DIODE,KDS184 EZSM CX-SLX7
S POWER AMP D 0250 87-A40-504-040 0E C-DIODE,KDS184 KSM CX-SLX7
S POWER AMP D 0250 87-A40-504-040 0E C-DIODE,KDS184 USM CX-SLX7
S POWER AMP D 0299 87-A40-504-040 0E C-DIODE,KDS184 EZSM CX-SLX7
S POWER AMP D 0299 87-A40-504-040 0E C-DIODE,KDS184 KSM CX-SLX7
S POWER AMP D 0299 87-A40-504-040 0E C-DIODE,KDS184 USM CX-SLX7

S POWER AMP Q 0201 89-333-266-080 0E C-TR,2SC3326B EZSM CX-SLX7
S POWER AMP Q 0201 89-333-266-080 0E C-TR,2SC3326B KSM CX-SLX7
S POWER AMP Q 0201 89-333-266-080 0E C-TR,2SC3326B USM CX-SLX7
S POWER AMP Q 0202 89-333-266-080 0E C-TR,2SC3326B EZSM CX-SLX7
S POWER AMP Q 0202 89-333-266-080 0E C-TR,2SC3326B KSM CX-SLX7
S POWER AMP Q 0202 89-333-266-080 0E C-TR,2SC3326B USM CX-SLX7
S POWER AMP Q 0204 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7
S POWER AMP Q 0204 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0204 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0205 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7

S POWER AMP Q 0205 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0205 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0206 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7
S POWER AMP Q 0206 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0206 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0207 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0207 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0207 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0208 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0208 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S POWER AMP Q 0208 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0209 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0209 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0209 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0210 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0210 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0210 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0211 87-A30-190-080 0E TR,CC5551 EZSM CX-SLX7
S POWER AMP Q 0211 87-A30-190-080 0E TR,CC5551 KSM CX-SLX7
S POWER AMP Q 0211 87-A30-190-080 0E TR,CC5551 USM CX-SLX7

S POWER AMP Q 0212 87-A30-190-080 0E TR,CC5551 EZSM CX-SLX7
S POWER AMP Q 0212 87-A30-190-080 0E TR,CC5551 KSM CX-SLX7
S POWER AMP Q 0212 87-A30-190-080 0E TR,CC5551 USM CX-SLX7
S POWER AMP Q 0213 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0213 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0213 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0214 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0214 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0214 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0217 87-A30-306-010 1B TR,2SB1677 EZSM CX-SLX7

S POWER AMP Q 0217 87-A30-306-010 1B TR,2SB1677 KSM CX-SLX7
S POWER AMP Q 0217 87-A30-306-010 1B TR,2SB1677 USM CX-SLX7
S POWER AMP Q 0218 87-A30-306-010 1B TR,2SB1677 EZSM CX-SLX7
S POWER AMP Q 0218 87-A30-306-010 1B TR,2SB1677 KSM CX-SLX7
S POWER AMP Q 0218 87-A30-306-010 1B TR,2SB1677 USM CX-SLX7
S POWER AMP Q 0219 87-A30-307-010 1B TR,2SD2619 EZSM CX-SLX7
S POWER AMP Q 0219 87-A30-307-010 1B TR,2SD2619 KSM CX-SLX7
S POWER AMP Q 0219 87-A30-307-010 1B TR,2SD2619 USM CX-SLX7
S POWER AMP Q 0220 87-A30-307-010 1B TR,2SD2619 EZSM CX-SLX7
S POWER AMP Q 0220 87-A30-307-010 1B TR,2SD2619 KSM CX-SLX7

S POWER AMP Q 0220 87-A30-307-010 1B TR,2SD2619 USM CX-SLX7
S POWER AMP Q 0223 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7
S POWER AMP Q 0223 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0223 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0224 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7
S POWER AMP Q 0224 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0224 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0225 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7
S POWER AMP Q 0225 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0225 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7

 29 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S POWER AMP Q 0227 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0227 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0227 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0228 87-A30-060-080 0E C-TR,KTC3875GR EZSM CX-SLX7
S POWER AMP Q 0228 87-A30-060-080 0E C-TR,KTC3875GR KSM CX-SLX7
S POWER AMP Q 0228 87-A30-060-080 0E C-TR,KTC3875GR USM CX-SLX7
S POWER AMP Q 0263 87-A30-075-080 0E C-TR,2SA1235F EZSM CX-SLX7
S POWER AMP Q 0263 87-A30-075-080 0E C-TR,2SA1235F KSM CX-SLX7
S POWER AMP Q 0263 87-A30-075-080 0E C-TR,2SA1235F USM CX-SLX7
S POWER AMP Q 0296 87-A30-635-040 -- C-TR,SBT5401F EZSM CX-SLX7

S POWER AMP Q 0296 87-A30-635-040 -- C-TR,SBT5401F KSM CX-SLX7
S POWER AMP Q 0296 87-A30-635-040 -- C-TR,SBT5401F USM CX-SLX7
S POWER AMP Q 0297 87-A30-484-080 0E C-TR,KRA102S EZSM CX-SLX7
S POWER AMP Q 0297 87-A30-484-080 0E C-TR,KRA102S KSM CX-SLX7
S POWER AMP Q 0297 87-A30-484-080 0E C-TR,KRA102S USM CX-SLX7
S POWER AMP Q 0298 87-A30-061-080 0E C-TR,KTA1504GR EZSM CX-SLX7
S POWER AMP Q 0298 87-A30-061-080 0E C-TR,KTA1504GR KSM CX-SLX7
S POWER AMP Q 0298 87-A30-061-080 0E C-TR,KTA1504GR USM CX-SLX7
S POWER AMP Q 0299 87-A30-190-080 0E TR,CC5551 EZSM CX-SLX7
S POWER AMP Q 0299 87-A30-190-080 0E TR,CC5551 KSM CX-SLX7

S POWER AMP Q 0299 87-A30-190-080 0E TR,CC5551 USM CX-SLX7
X POWER AMP R 0165 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0165 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X POWER AMP R 0165 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X POWER AMP R 0201 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X POWER AMP R 0201 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X POWER AMP R 0201 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X POWER AMP R 0202 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X POWER AMP R 0202 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X POWER AMP R 0202 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X POWER AMP R 0203 88-108-562-080 0E C-RES,U 5.6K-1/16W J EZSM CX-SLX7
X POWER AMP R 0203 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X POWER AMP R 0203 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-SLX7
X POWER AMP R 0204 88-108-562-080 0E C-RES,U 5.6K-1/16W J EZSM CX-SLX7
X POWER AMP R 0204 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X POWER AMP R 0204 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-SLX7
X POWER AMP R 0205 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0205 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0205 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0206 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X POWER AMP R 0206 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0206 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0207 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0207 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0207 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0208 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0208 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0208 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0209 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0209 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7

X POWER AMP R 0209 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X POWER AMP R 0210 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0210 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X POWER AMP R 0210 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X POWER AMP R 0211 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0211 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X POWER AMP R 0211 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X POWER AMP R 0212 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0212 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X POWER AMP R 0212 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7

X POWER AMP R 0213 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X POWER AMP R 0213 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X POWER AMP R 0213 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X POWER AMP R 0214 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X POWER AMP R 0214 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X POWER AMP R 0214 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X POWER AMP R 0219 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0219 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0219 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0220 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

 30 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP R 0220 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0220 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0221 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0221 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0221 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0222 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0222 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0222 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0223 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0223 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7

X POWER AMP R 0223 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X POWER AMP R 0224 88-128-102-080 0E C-RES, 1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0224 88-128-102-080 0E C-RES, 1K-1/8W J KSM CX-SLX7
X POWER AMP R 0224 88-128-102-080 0E C-RES, 1K-1/8W J USM CX-SLX7
X POWER AMP R 0225 88-128-102-080 0E C-RES, 1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0225 88-128-102-080 0E C-RES, 1K-1/8W J KSM CX-SLX7
X POWER AMP R 0225 88-128-102-080 0E C-RES, 1K-1/8W J USM CX-SLX7
X POWER AMP R 0226 88-128-102-080 0E C-RES, 1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0226 88-128-102-080 0E C-RES, 1K-1/8W J KSM CX-SLX7
X POWER AMP R 0226 88-128-102-080 0E C-RES, 1K-1/8W J USM CX-SLX7

X POWER AMP R 0227 88-108-390-080 0E C-RES,U 39-1/16W J EZSM CX-SLX7
X POWER AMP R 0227 88-108-390-080 0E C-RES,U 39-1/16W J KSM CX-SLX7
X POWER AMP R 0227 88-108-390-080 0E C-RES,U 39-1/16W J USM CX-SLX7
O POWER AMP R 0229 87-A00-258-080 0E RES,M/F 0.22-1W J EZSM CX-SLX7
O POWER AMP R 0229 87-A00-258-080 0E RES,M/F 0.22-1W J KSM CX-SLX7
O POWER AMP R 0229 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-SLX7
O POWER AMP R 0230 87-A00-258-080 0E RES,M/F 0.22-1W J EZSM CX-SLX7
O POWER AMP R 0230 87-A00-258-080 0E RES,M/F 0.22-1W J KSM CX-SLX7
O POWER AMP R 0230 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-SLX7
O POWER AMP R 0231 87-A00-258-080 0E RES,M/F 0.22-1W J EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O POWER AMP R 0231 87-A00-258-080 0E RES,M/F 0.22-1W J KSM CX-SLX7
O POWER AMP R 0231 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-SLX7
O POWER AMP R 0232 87-A00-258-080 0E RES,M/F 0.22-1W J EZSM CX-SLX7
O POWER AMP R 0232 87-A00-258-080 0E RES,M/F 0.22-1W J KSM CX-SLX7
O POWER AMP R 0232 87-A00-258-080 0E RES,M/F 0.22-1W J USM CX-SLX7
X POWER AMP R 0233 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X POWER AMP R 0233 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X POWER AMP R 0233 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X POWER AMP R 0234 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X POWER AMP R 0234 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7

X POWER AMP R 0234 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X POWER AMP R 0235 88-108-152-080 0E C-RES,U 1.5K-1/16W J EZSM CX-SLX7
X POWER AMP R 0235 88-108-152-080 0E C-RES,U 1.5K-1/16W J KSM CX-SLX7
X POWER AMP R 0235 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-SLX7
X POWER AMP R 0236 88-108-152-080 0E C-RES,U 1.5K-1/16W J EZSM CX-SLX7
X POWER AMP R 0236 88-108-152-080 0E C-RES,U 1.5K-1/16W J KSM CX-SLX7
X POWER AMP R 0236 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-SLX7
X POWER AMP R 0237 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0237 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0237 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7

X POWER AMP R 0238 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X POWER AMP R 0238 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X POWER AMP R 0238 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X POWER AMP R 0241 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0241 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X POWER AMP R 0241 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X POWER AMP R 0242 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0242 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X POWER AMP R 0242 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X POWER AMP R 0243 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7

X POWER AMP R 0243 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X POWER AMP R 0243 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X POWER AMP R 0244 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X POWER AMP R 0244 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X POWER AMP R 0244 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X POWER AMP R 0245 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0245 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0245 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0246 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0246 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7

 31 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP R 0246 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0249 88-108-390-080 0E C-RES,U 39-1/16W J EZSM CX-SLX7
X POWER AMP R 0249 88-108-390-080 0E C-RES,U 39-1/16W J KSM CX-SLX7
X POWER AMP R 0249 88-108-390-080 0E C-RES,U 39-1/16W J USM CX-SLX7
X POWER AMP R 0251 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X POWER AMP R 0251 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X POWER AMP R 0251 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X POWER AMP R 0252 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X POWER AMP R 0252 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X POWER AMP R 0252 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7

X POWER AMP R 0255 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X POWER AMP R 0255 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X POWER AMP R 0255 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X POWER AMP R 0256 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X POWER AMP R 0256 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X POWER AMP R 0256 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X POWER AMP R 0257 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X POWER AMP R 0257 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X POWER AMP R 0257 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X POWER AMP R 0269 88-108-221-080 0E C-RES,U 220-1/16W J EZSM CX-SLX7

X POWER AMP R 0269 88-108-221-080 0E C-RES,U 220-1/16W J KSM CX-SLX7
X POWER AMP R 0269 88-108-221-080 0E C-RES,U 220-1/16W J USM CX-SLX7
X POWER AMP R 0270 88-108-221-080 0E C-RES,U 220-1/16W J EZSM CX-SLX7
X POWER AMP R 0270 88-108-221-080 0E C-RES,U 220-1/16W J KSM CX-SLX7
X POWER AMP R 0270 88-108-221-080 0E C-RES,U 220-1/16W J USM CX-SLX7
X POWER AMP R 0271 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0271 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X POWER AMP R 0271 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X POWER AMP R 0272 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0272 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X POWER AMP R 0272 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X POWER AMP R 0273 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0273 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X POWER AMP R 0273 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X POWER AMP R 0274 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X POWER AMP R 0274 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X POWER AMP R 0274 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X POWER AMP R 0275 88-121-331-080 0E RES,330-1/8W J EZSM CX-SLX7
X POWER AMP R 0275 88-121-331-080 0E RES,330-1/8W J KSM CX-SLX7
X POWER AMP R 0275 88-121-331-080 0E RES,330-1/8W J USM CX-SLX7

X POWER AMP R 0276 88-121-331-080 0E RES,330-1/8W J EZSM CX-SLX7
X POWER AMP R 0276 88-121-331-080 0E RES,330-1/8W J KSM CX-SLX7
X POWER AMP R 0276 88-121-331-080 0E RES,330-1/8W J USM CX-SLX7
X POWER AMP R 0277 88-108-683-080 0E C-RES,U 68K-1/16W J EZSM CX-SLX7
X POWER AMP R 0277 88-108-683-080 0E C-RES,U 68K-1/16W J KSM CX-SLX7
X POWER AMP R 0277 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-SLX7
X POWER AMP R 0278 88-108-105-080 0E C-RES,U 1M-1/16W J EZSM CX-SLX7
X POWER AMP R 0278 88-108-105-080 0E C-RES,U 1M-1/16W J KSM CX-SLX7
X POWER AMP R 0278 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-SLX7
X POWER AMP R 0279 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7

X POWER AMP R 0279 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X POWER AMP R 0279 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X POWER AMP R 0280 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0280 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0280 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0281 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X POWER AMP R 0281 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X POWER AMP R 0281 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X POWER AMP R 0282 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X POWER AMP R 0282 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7

X POWER AMP R 0282 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X POWER AMP R 0283 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0283 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0283 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0293 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0293 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0293 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0294 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X POWER AMP R 0294 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X POWER AMP R 0294 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7

 32 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP R 0295 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-SLX7
X POWER AMP R 0295 88-108-682-080 0E C-RES,U 6.8K-1/16W J EZSM CX-SLX7
X POWER AMP R 0295 88-108-682-080 0E C-RES,U 6.8K-1/16W J KSM CX-SLX7
X POWER AMP R 0296 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0296 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0296 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0297 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0297 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0297 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0298 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7

X POWER AMP R 0298 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X POWER AMP R 0298 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X POWER AMP R 0299 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X POWER AMP R 0299 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X POWER AMP R 0299 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X POWER AMP R 0412 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0412 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X POWER AMP R 0412 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X POWER AMP R 0413 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0413 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X POWER AMP R 0413 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X POWER AMP R 0414 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X POWER AMP R 0414 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X POWER AMP R 0414 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X POWER AMP R 0431 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X POWER AMP R 0431 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X POWER AMP R 0431 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
O POWER AMP TH 0201 87-A91-042-080 0E C-THMS,100K 55001 EZSM CX-SLX7
O POWER AMP TH 0201 87-A91-042-080 0E C-THMS,100K 55001 KSM CX-SLX7
O POWER AMP TH 0201 87-A91-042-080 0E C-THMS,100K 55001 USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O POWER AMP TH 0202 87-A91-042-080 0E C-THMS,100K 55001 EZSM CX-SLX7
O POWER AMP TH 0202 87-A91-042-080 0E C-THMS,100K 55001 KSM CX-SLX7
O POWER AMP TH 0202 87-A91-042-080 0E C-THMS,100K 55001 USM CX-SLX7
O POWER SUPPLY C 0201 87-A10-520-000 1B CAP,E 3300-35 M SMG EZSM CX-SLX7
O POWER SUPPLY C 0201 87-A10-520-000 1B CAP,E 3300-35 M SMG KSM CX-SLX7
O POWER SUPPLY C 0201 87-A10-520-000 1B CAP,E 3300-35 M SMG USM CX-SLX7
O POWER SUPPLY C 0202 87-016-051-000 1B CAP,E 2200-35 M SMG EZSM CX-SLX7
O POWER SUPPLY C 0202 87-016-051-000 1B CAP,E 2200-35 M SMG KSM CX-SLX7
O POWER SUPPLY C 0202 87-016-051-000 1B CAP,E 2200-35 M SMG USM CX-SLX7
O POWER SUPPLY C 0203 87-A12-317-080 0E C-CAP,U 0.1-50 Z F EZSM CX-SLX7

O POWER SUPPLY C 0203 87-A12-317-080 0E C-CAP,U 0.1-50 Z F KSM CX-SLX7
O POWER SUPPLY C 0203 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-SLX7
O POWER SUPPLY C 0204 87-A12-317-080 0E C-CAP,U 0.1-50 Z F EZSM CX-SLX7
O POWER SUPPLY C 0204 87-A12-317-080 0E C-CAP,U 0.1-50 Z F KSM CX-SLX7
O POWER SUPPLY C 0204 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-SLX7
O POWER SUPPLY C 0205 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0205 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER SUPPLY C 0205 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0206 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0206 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7

O POWER SUPPLY C 0206 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0207 87-A12-317-080 0E C-CAP,U 0.1-50 Z F EZSM CX-SLX7
O POWER SUPPLY C 0207 87-A12-317-080 0E C-CAP,U 0.1-50 Z F KSM CX-SLX7
O POWER SUPPLY C 0207 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-SLX7
O POWER SUPPLY C 0208 87-A12-317-080 0E C-CAP,U 0.1-50 Z F EZSM CX-SLX7
O POWER SUPPLY C 0208 87-A12-317-080 0E C-CAP,U 0.1-50 Z F KSM CX-SLX7
O POWER SUPPLY C 0208 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-SLX7
O POWER SUPPLY C 0209 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0209 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER SUPPLY C 0209 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7

O POWER SUPPLY C 0210 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0210 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER SUPPLY C 0210 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0211 87-A12-074-080 0E CAP,E 470-25 SMG EZSM CX-SLX7
O POWER SUPPLY C 0211 87-A12-074-080 0E CAP,E 470-25 SMG KSM CX-SLX7
O POWER SUPPLY C 0211 87-A12-074-080 0E CAP,E 470-25 SMG USM CX-SLX7
O POWER SUPPLY C 0212 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0212 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER SUPPLY C 0212 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0213 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7

 33 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O POWER SUPPLY C 0213 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O POWER SUPPLY C 0213 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0214 87-A12-068-080 0E CAP,E 470-16 SMG EZSM CX-SLX7
O POWER SUPPLY C 0214 87-A12-068-080 0E CAP,E 470-16 SMG KSM CX-SLX7
O POWER SUPPLY C 0214 87-A12-068-080 0E CAP,E 470-16 SMG USM CX-SLX7
O POWER SUPPLY C 0215 87-016-521-010 1A CAP,E 2200-16 M SMG EZSM CX-SLX7
O POWER SUPPLY C 0215 87-016-521-010 1A CAP,E 2200-16 M SMG KSM CX-SLX7
O POWER SUPPLY C 0215 87-016-521-010 1A CAP,E 2200-16 M SMG USM CX-SLX7
O POWER SUPPLY C 0216 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O POWER SUPPLY C 0216 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7

O POWER SUPPLY C 0216 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
O POWER SUPPLY C 0217 87-010-380-040 0E CAP,E 47-16 M 11L SME EZSM CX-SLX7
O POWER SUPPLY C 0217 87-010-380-040 0E CAP,E 47-16 M 11L SME KSM CX-SLX7
O POWER SUPPLY C 0217 87-010-380-040 0E CAP,E 47-16 M 11L SME USM CX-SLX7
O POWER SUPPLY C 0301 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O POWER SUPPLY C 0301 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O POWER SUPPLY C 0301 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O POWER SUPPLY C 0302 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O POWER SUPPLY C 0302 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O POWER SUPPLY C 0302 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7

! O POWER SUPPLY CN 0201 87-009-195-010 0E CONN,5P V WHT EH EZSM CX-SLX7
! O POWER SUPPLY CN 0201 87-009-195-010 0E CONN,5P V WHT EH KSM CX-SLX7
! O POWER SUPPLY CN 0201 87-009-195-010 0E CONN,5P V WHT EH USM CX-SLX7
! O POWER SUPPLY CN 0202 87-099-043-010 0E CONN,2P V WHT EH EZSM CX-SLX7
! O POWER SUPPLY CN 0202 87-099-043-010 0E CONN,2P V WHT EH KSM CX-SLX7
! O POWER SUPPLY CN 0202 87-099-043-010 0E CONN,2P V WHT EH USM CX-SLX7
O POWER SUPPLY CNA0201 8B-CL2-671-010 1 CONN ASSY,11P EH USM CX-SLX7
O POWER SUPPLY CNA0201 8B-CL2-671-010 1B CONN ASSY,11P EH EZSM CX-SLX7
O POWER SUPPLY CNA0201 8B-CL2-671-010 1B CONN ASSY,11P EH KSM CX-SLX7
O POWER SUPPLY CNA0203 8B-CL2-668-010 1A CONN ASSY,10P EH EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O POWER SUPPLY CNA0203 8B-CL2-668-010 1A CONN ASSY,10P EH KSM CX-SLX7
O POWER SUPPLY CNA0203 8B-CL2-668-010 1A CONN ASSY,10P EH USM CX-SLX7
O POWER SUPPLY CNA0301 8B-CL2-672-010 1A CONN ASSY,5P EH EZSM CX-SLX7
O POWER SUPPLY CNA0301 8B-CL2-672-010 1A CONN ASSY,5P EH KSM CX-SLX7
O POWER SUPPLY CNA0301 8B-CL2-672-010 1A CONN ASSY,5P EH USM CX-SLX7
S POWER SUPPLY D 0201 87-017-654-060 1C DIODE,GBU6JL6131 EZSM CX-SLX7
S POWER SUPPLY D 0201 87-017-654-060 1C DIODE,GBU6JL6131 KSM CX-SLX7
S POWER SUPPLY D 0201 87-017-654-060 1C DIODE,GBU6JL6131 USM CX-SLX7
S POWER SUPPLY D 0202 87-070-274-080 0E DIODE,1N4003 SEM EZSM CX-SLX7
S POWER SUPPLY D 0202 87-070-274-080 0E DIODE,1N4003 SEM KSM CX-SLX7

S POWER SUPPLY D 0202 87-070-274-080 0E DIODE,1N4003 SEM USM CX-SLX7
S POWER SUPPLY D 0203 87-070-274-080 0E DIODE,1N4003 SEM EZSM CX-SLX7
S POWER SUPPLY D 0203 87-070-274-080 0E DIODE,1N4003 SEM KSM CX-SLX7
S POWER SUPPLY D 0203 87-070-274-080 0E DIODE,1N4003 SEM USM CX-SLX7
S POWER SUPPLY IC 0201 87-001-576-010 1B IC,NJM7812FA EZSM CX-SLX7
S POWER SUPPLY IC 0201 87-001-576-010 1B IC,NJM7812FA KSM CX-SLX7
S POWER SUPPLY IC 0201 87-001-576-010 1B IC,NJM7812FA USM CX-SLX7
S POWER SUPPLY IC 0202 87-002-349-010 1B IC,NJM78M06FA EZSM CX-SLX7
S POWER SUPPLY IC 0202 87-002-349-010 1B IC,NJM78M06FA KSM CX-SLX7
S POWER SUPPLY IC 0202 87-002-349-010 1B IC,NJM78M06FA USM CX-SLX7

S POWER SUPPLY IC 0203 87-A21-298-010 1B IC,SI-3050F EZSM CX-SLX7
S POWER SUPPLY IC 0203 87-A21-298-010 1B IC,SI-3050F KSM CX-SLX7
S POWER SUPPLY IC 0203 87-A21-298-010 1B IC,SI-3050F USM CX-SLX7
O POWER SUPPLY J 0201 87-A60-420-010 1A JACK,3.5 ST (MSC) EZSM CX-SLX7
O POWER SUPPLY J 0201 87-A60-420-010 1A JACK,3.5 ST (MSC) KSM CX-SLX7
O POWER SUPPLY J 0201 87-A60-420-010 1A JACK,3.5 ST (MSC) USM CX-SLX7
S POWER SUPPLY PR 0201 87-A91-935-080 0E PROTECTOR,1A 20P 60V EZSM CX-SLX7
S POWER SUPPLY PR 0201 87-A91-935-080 0E PROTECTOR,1A 20P 60V KSM CX-SLX7
S POWER SUPPLY PR 0201 87-A91-935-080 0E PROTECTOR,1A 20P 60V USM CX-SLX7
X POWER SUPPLY R 0201 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7

X POWER SUPPLY R 0201 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X POWER SUPPLY R 0201 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X POWER SUPPLY R 0203 88-140-121-080 0E RES,120-1/2W J EZSM CX-SLX7
X POWER SUPPLY R 0203 88-140-121-080 0E RES,120-1/2W J KSM CX-SLX7
X POWER SUPPLY R 0203 88-140-121-080 0E RES,120-1/2W J USM CX-SLX7
X POWER SUPPLY R 0204 88-140-121-080 0E RES,120-1/2W J EZSM CX-SLX7
X POWER SUPPLY R 0204 88-140-121-080 0E RES,120-1/2W J KSM CX-SLX7
X POWER SUPPLY R 0204 88-140-121-080 0E RES,120-1/2W J USM CX-SLX7
X POWER SUPPLY R 0205 88-140-121-080 0E RES,120-1/2W J EZSM CX-SLX7
X POWER SUPPLY R 0205 88-140-121-080 0E RES,120-1/2W J KSM CX-SLX7

 34 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER SUPPLY R 0205 88-140-121-080 0E RES,120-1/2W J USM CX-SLX7
X POWER SUPPLY R 0301 88-130-331-080 0E RES,330-1/4W J EZSM CX-SLX7
X POWER SUPPLY R 0301 88-130-331-080 0E RES,330-1/4W J KSM CX-SLX7
X POWER SUPPLY R 0301 88-130-331-080 0E RES,330-1/4W J USM CX-SLX7
X POWER SUPPLY R 0302 88-130-331-080 0E RES,330-1/4W J EZSM CX-SLX7
X POWER SUPPLY R 0302 88-130-331-080 0E RES,330-1/4W J KSM CX-SLX7
X POWER SUPPLY R 0302 88-130-331-080 0E RES,330-1/4W J USM CX-SLX7
X PRINTED DU 87-056-168-010 0E SH,CAUTION INF-WARR(EC) EZSM CX-SLX7
X PRINTED DU 87-056-168-010 0E SH,CAUTION INF-WARR(EC) KSM CX-SLX7
X PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL EZSM CX-SLX7

X PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL KSM CX-SLX7
X PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL USM CX-SLX7
X PRINTED DU 87-B50-053-010 0E WARR-CARD,USA CUST/AV,VISUAL USM CX-SLX7
X PRINTED DU 87-B50-079-010 0E LIST,FACILITY(B)-0007 EZSM CX-SLX7
X PRINTED DU 87-B50-079-010 0E LIST,FACILITY(B)-0007 KSM CX-SLX7
O PRINTED DU 8B-CL2-903-110 -- IB,U(ESF)M USM CX-SLX7
O PRINTED DU 8B-CL2-905-010 0E IB,K(E)M KSM CX-SLX7
O PRINTED DU 8B-CL2-906-010 1C IB,EZ(9L)M EZSM CX-SLX7
X PWB/PT * 8B-CL2-645-010 1 PWB,PT 3M USM CX-SLX7
X PWB/PT * 8B-CL2-645-010 1B PWB,PT 3M EZSM CX-SLX7

X PWB/PT * 8B-CL2-645-010 1B PWB,PT 3M KSM CX-SLX7
! O PWB/PT C 0001 87-A10-479-080 0E CAP,CER 2200P-250 M E KH EZSM CX-SLX7
! O PWB/PT C 0001 87-A10-479-080 0E CAP,CER 2200P-250 M E KH KSM CX-SLX7
! O PWB/PT C 0001 87-A10-479-080 0E CAP,CER 2200P-250 M E KH USM CX-SLX7
O PWB/PT C 0014 87-A10-831-080 1A CAP,E 1000-25 M SMG EZSM CX-SLX7
O PWB/PT C 0014 87-A10-831-080 1A CAP,E 1000-25 M SMG KSM CX-SLX7
O PWB/PT C 0014 87-A10-831-080 1A CAP,E 1000-25 M SMG USM CX-SLX7
O PWB/PT C 0016 87-010-496-080 0E CAP,E 3.3-50 M 5L SRE EZSM CX-SLX7
O PWB/PT C 0016 87-010-496-080 0E CAP,E 3.3-50 M 5L SRE KSM CX-SLX7
O PWB/PT C 0016 87-010-496-080 0E CAP,E 3.3-50 M 5L SRE USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

! O PWB/PT CN 0001 87-A60-645-010 0E CONN,3P V VH EZSM CX-SLX7
! O PWB/PT CN 0001 87-A60-645-010 0E CONN,3P V VH KSM CX-SLX7
! O PWB/PT CN 0001 87-A60-645-010 0E CONN,3P V VH USM CX-SLX7
O PWB/PT CNA0001 8B-CL2-669-010 0E CONN ASSY,3P V STBY EZSM CX-SLX7
O PWB/PT CNA0001 8B-CL2-669-010 0E CONN ASSY,3P V STBY KSM CX-SLX7
O PWB/PT CNA0001 8B-CL2-669-010 0E CONN ASSY,3P V STBY USM CX-SLX7
S PWB/PT D 0001 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0001 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0001 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0002 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7

S PWB/PT D 0002 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0002 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0003 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0003 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0003 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0004 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0004 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0004 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0005 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0005 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7

S PWB/PT D 0005 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0006 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0006 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0006 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S PWB/PT D 0007 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S PWB/PT D 0007 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S PWB/PT D 0007 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
O PWB/PT FC 0001 87-033-213-080 0E FUSE CLAMP,PFC5000 USM CX-SLX7
O PWB/PT FC 0002 87-033-213-080 0E FUSE CLAMP,PFC5000 USM CX-SLX7
X PWB/PT PR 0001 88-100-000-080 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7

X PWB/PT PR 0001 88-100-000-080 0E PLATING-JW, 0.58 SN95 KSM CX-SLX7
X PWB/PT PR 0001 88-100-000-080 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
! O PWB/PT PT 0001 8A-NF8-661-010 1C PT,SUB ANF-8 (U) USM CX-SLX7
! O PWB/PT PT 0001 8A-NF8-662-010 1C PT,SUB ANF-8 (E) EZSM CX-SLX7
! O PWB/PT PT 0001 8A-NF8-662-010 1C PT,SUB ANF-8 (E) KSM CX-SLX7
S PWB/PT Q 0001 87-026-245-080 0E TR,DTC114ES EZSM CX-SLX7
S PWB/PT Q 0001 87-026-245-080 0E TR,DTC114ES KSM CX-SLX7
S PWB/PT Q 0001 87-026-245-080 0E TR,DTC114ES USM CX-SLX7
S PWB/PT Q 0002 87-A30-198-080 0E TR,KTC3199GR EZSM CX-SLX7
S PWB/PT Q 0002 87-A30-198-080 0E TR,KTC3199GR KSM CX-SLX7

 35 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S PWB/PT Q 0002 87-A30-198-080 0E TR,KTC3199GR USM CX-SLX7
X PWB/PT R 0001 88-121-153-080 0E RES,15K-1/8W J EZSM CX-SLX7
X PWB/PT R 0001 88-121-153-080 0E RES,15K-1/8W J KSM CX-SLX7
X PWB/PT R 0001 88-121-153-080 0E RES,15K-1/8W J USM CX-SLX7
X PWB/PT R 0002 88-130-101-080 0E RES,100-1/4W J EZSM CX-SLX7
X PWB/PT R 0002 88-130-101-080 0E RES,100-1/4W J KSM CX-SLX7
X PWB/PT R 0002 88-130-101-080 0E RES,100-1/4W J USM CX-SLX7
X PWB/PT R 0003 88-140-225-080 0E RES,2.2M-1/2W J USM CX-SLX7
! O PWB/PT RY 0001 87-A90-977-010 1C RELAY,AC12V DG12D1-O(M) EZSM CX-SLX7
! O PWB/PT RY 0001 87-A90-977-010 1C RELAY,AC12V DG12D1-O(M) KSM CX-SLX7

! O PWB/PT RY 0001 87-A90-977-010 1C RELAY,AC12V DG12D1-O(M) USM CX-SLX7
O PWB/PT T 0001 87-A60-317-010 0E TERMINAL, 1P MSC EZSM CX-SLX7
O PWB/PT T 0001 87-A60-317-010 0E TERMINAL, 1P MSC KSM CX-SLX7
O PWB/PT T 0001 87-A60-317-010 0E TERMINAL, 1P MSC USM CX-SLX7
O PWB/PT T 0002 87-A60-317-010 0E TERMINAL, 1P MSC EZSM CX-SLX7
O PWB/PT T 0002 87-A60-317-010 0E TERMINAL, 1P MSC KSM CX-SLX7
O PWB/PT T 0002 87-A60-317-010 0E TERMINAL, 1P MSC USM CX-SLX7
O Q SURROUND C 0603 87-010-402-040 0E CAP,E 2.2-50 M 11L SME EZSM CX-SLX7
O Q SURROUND C 0603 87-010-402-040 0E CAP,E 2.2-50 M 11L SME KSM CX-SLX7
O Q SURROUND C 0603 87-010-402-040 0E CAP,E 2.2-50 M 11L SME USM CX-SLX7

O Q SURROUND C 0604 87-010-402-040 0E CAP,E 2.2-50 M 11L SME EZSM CX-SLX7
O Q SURROUND C 0604 87-010-402-040 0E CAP,E 2.2-50 M 11L SME KSM CX-SLX7
O Q SURROUND C 0604 87-010-402-040 0E CAP,E 2.2-50 M 11L SME USM CX-SLX7
O Q SURROUND C 0605 87-010-408-040 0E CAP,E 47-50 M 11L SME EZSM CX-SLX7
O Q SURROUND C 0605 87-010-408-040 0E CAP,E 47-50 M 11L SME KSM CX-SLX7
O Q SURROUND C 0605 87-010-408-040 0E CAP,E 47-50 M 11L SME USM CX-SLX7
O Q SURROUND C 0607 87-010-405-040 0E CAP,E 10-50 M 11L SME EZSM CX-SLX7
O Q SURROUND C 0607 87-010-405-040 0E CAP,E 10-50 M 11L SME KSM CX-SLX7
O Q SURROUND C 0607 87-010-405-040 0E CAP,E 10-50 M 11L SME USM CX-SLX7
O Q SURROUND C 0608 87-010-405-040 0E CAP,E 10-50 M 11L SME EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O Q SURROUND C 0608 87-010-405-040 0E CAP,E 10-50 M 11L SME KSM CX-SLX7
O Q SURROUND C 0608 87-010-405-040 0E CAP,E 10-50 M 11L SME USM CX-SLX7
O Q SURROUND C 0609 87-010-759-080 0E C-CAP,U 0.1-25 Z F EZSM CX-SLX7
O Q SURROUND C 0609 87-010-759-080 0E C-CAP,U 0.1-25 Z F KSM CX-SLX7
O Q SURROUND C 0609 87-010-759-080 0E C-CAP,U 0.1-25 Z F USM CX-SLX7
O Q SURROUND C 0610 87-010-384-040 0E CAP,E 100-25 M 11L SME EZSM CX-SLX7
O Q SURROUND C 0610 87-010-384-040 0E CAP,E 100-25 M 11L SME KSM CX-SLX7
O Q SURROUND C 0610 87-010-384-040 0E CAP,E 100-25 M 11L SME USM CX-SLX7
O Q SURROUND C 0611 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O Q SURROUND C 0611 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O Q SURROUND C 0611 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O Q SURROUND C 0612 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O Q SURROUND C 0612 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O Q SURROUND C 0612 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
S Q SURROUND IC 0601 87-A21-103-040 1E C-IC,MM1454XFBE EZSM CX-SLX7
S Q SURROUND IC 0601 87-A21-103-040 1E C-IC,MM1454XFBE KSM CX-SLX7
S Q SURROUND IC 0601 87-A21-103-040 1E C-IC,MM1454XFBE USM CX-SLX7
X Q SURROUND R 0601 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X Q SURROUND R 0601 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X Q SURROUND R 0601 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7

X Q SURROUND R 0608 88-121-472-080 0E RES,4.7K-1/8W J EZSM CX-SLX7
X Q SURROUND R 0608 88-121-472-080 0E RES,4.7K-1/8W J KSM CX-SLX7
X Q SURROUND R 0608 88-121-472-080 0E RES,4.7K-1/8W J USM CX-SLX7
X Q SURROUND R 0609 88-108-153-080 0E C-RES,U 15K-1/16W J EZSM CX-SLX7
X Q SURROUND R 0609 88-108-153-080 0E C-RES,U 15K-1/16W J KSM CX-SLX7
X Q SURROUND R 0609 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-SLX7
X Q SURROUND R 0611 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X Q SURROUND R 0611 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X Q SURROUND R 0611 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X Q SURROUND R 0612 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X Q SURROUND R 0612 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X Q SURROUND R 0612 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X Q SURROUND R 0614 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X Q SURROUND R 0614 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X Q SURROUND R 0614 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X Q SURROUND R 0615 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X Q SURROUND R 0615 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X Q SURROUND R 0615 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X Q SURROUND R 0617 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X Q SURROUND R 0617 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7

 36 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X Q SURROUND R 0617 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
O SCREW 87-067-579-010 0E BVT2+3-8 W/O SLOT USM CX-SLX7
O SCREW 87-067-579-010 0E BVT2+3-8 W/O SLOT EZSM CX-SLX7
O SCREW 87-067-579-010 0E BVT2+3-8 W/O SLOT KSM CX-SLX7
O SCREW 87-067-584-010 0E BVT2+3-6 W/0 SL0T EZSM CX-SLX7
O SCREW 87-067-584-010 0E BVT2+3-6 W/0 SL0T KSM CX-SLX7
O SCREW 87-067-584-010 0E BVT2+3-6 W/0 SL0T USM CX-SLX7
O SCREW 87-067-585-010 0E BVTT+4-6 EZSM CX-SLX7
O SCREW 87-067-585-010 0E BVTT+4-6 KSM CX-SLX7
O SCREW 87-067-585-010 0E BVTT+4-6 USM CX-SLX7

O SCREW 87-067-703-010 0E BVT2+3-10 W/0 SL0T EZSM CX-SLX7
O SCREW 87-067-703-010 0E BVT2+3-10 W/0 SL0T KSM CX-SLX7
O SCREW 87-067-703-010 0E BVT2+3-10 W/0 SL0T USM CX-SLX7
O SCREW 87-067-761-010 0E BVT2+3-10 BLK EZSM CX-SLX7
O SCREW 87-067-761-010 0E BVT2+3-10 BLK KSM CX-SLX7
O SCREW 87-067-761-010 0E BVT2+3-10 BLK USM CX-SLX7
O SCREW 87-067-767-010 0E BVTT+2.6-6 EZSM CX-SLX7
O SCREW 87-067-767-010 0E BVTT+2.6-6 KSM CX-SLX7
O SCREW 87-067-767-010 0E BVTT+2.6-6 USM CX-SLX7
O SCREW 87-067-822-010 0E BVT2+3-20 W/0 SL0T EZSM CX-SLX7

O SCREW 87-067-822-010 0E BVT2+3-20 W/0 SL0T KSM CX-SLX7
O SCREW 87-067-822-010 0E BVT2+3-20 W/0 SL0T USM CX-SLX7
O SCREW 87-067-868-010 0E V+1.7-4 BLK HL EZSM CX-SLX7
O SCREW 87-067-868-010 0E V+1.7-4 BLK HL KSM CX-SLX7
O SCREW 87-067-868-010 0E V+1.7-4 BLK HL USM CX-SLX7
O SCREW 87-721-095-410 0E QT2+3-8 W/O SL0T EZSM CX-SLX7
O SCREW 87-721-095-410 0E QT2+3-8 W/O SL0T KSM CX-SLX7
O SCREW 87-721-095-410 0E QT2+3-8 W/O SL0T USM CX-SLX7
O SCREW 87-741-096-410 0E UT2+3-10 W/O SLOT EZSM CX-SLX7
O SCREW 87-741-096-410 0E UT2+3-10 W/O SLOT KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O SCREW 87-741-096-410 0E UT2+3-10 W/O SLOT USM CX-SLX7
O SCREW 88-AR1-217-010 0E S-SCREW,BFT2+3-8 EZSM CX-SLX7
O SCREW 88-AR1-217-010 0E S-SCREW,BFT2+3-8 KSM CX-SLX7
O SCREW 88-AR1-217-010 0E S-SCREW,BFT2+3-8 USM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 EZSM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 EZSM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 EZSM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 KSM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 KSM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 KSM CX-SLX7

O SCREW * 87-B10-294-010 0E BVT2+2.6-8 USM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 USM CX-SLX7
O SCREW * 87-B10-294-010 0E BVT2+2.6-8 USM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 EZSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 EZSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 EZSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 EZSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 KSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 KSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 KSM CX-SLX7

O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 KSM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 USM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 USM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 USM CX-SLX7
O SCREW * 8Z-CK5-222-010 0E S-SCREW,CD+2.6-6 F9 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7

O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1 S-SCREW,ZCL1 USM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7

 37 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 EZSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O SCREW * 8Z-CL1-034-010 1B S-SCREW,ZCL1 KSM CX-SLX7
O TUNER(IF) C 0753 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7

O TUNER(IF) C 0753 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O TUNER(IF) C 0755 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0755 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0755 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0756 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0756 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0756 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0757 87-012-188-080 0E C-CAP,U 47P-50 J CH EZSM CX-SLX7
O TUNER(IF) C 0757 87-012-188-080 0E C-CAP,U 47P-50 J CH KSM CX-SLX7
O TUNER(IF) C 0757 87-012-188-080 0E C-CAP,U 47P-50 J CH USM CX-SLX7

O TUNER(IF) C 0758 87-012-167-080 0E C-CAP,U 5P-50 C CH EZSM CX-SLX7
O TUNER(IF) C 0758 87-012-167-080 0E C-CAP,U 5P-50 C CH KSM CX-SLX7
O TUNER(IF) C 0758 87-012-167-080 0E C-CAP,U 5P-50 C CH USM CX-SLX7
O TUNER(IF) C 0761 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(IF) C 0761 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(IF) C 0761 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(IF) C 0762 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0762 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0763 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0763 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TUNER(IF) C 0763 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7
O TUNER(IF) C 0764 87-012-337-080 0E C-CAP,U 56P-50 J CH GRM USM CX-SLX7
O TUNER(IF) C 0765 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0765 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0765 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0766 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0766 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0766 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0768 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0768 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O TUNER(IF) C 0769 87-A12-071-080 0E CAP,E 47-25 SMG EZSM CX-SLX7
O TUNER(IF) C 0769 87-A12-071-080 0E CAP,E 47-25 SMG KSM CX-SLX7
O TUNER(IF) C 0769 87-A12-071-080 0E CAP,E 47-25 SMG USM CX-SLX7
O TUNER(IF) C 0770 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0770 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7
O TUNER(IF) C 0770 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7
O TUNER(IF) C 0771 87-A12-070-080 0E CAP,E 33-25 SMG EZSM CX-SLX7
O TUNER(IF) C 0771 87-A12-070-080 0E CAP,E 33-25 SMG KSM CX-SLX7
O TUNER(IF) C 0771 87-A12-070-080 0E CAP,E 33-25 SMG USM CX-SLX7
O TUNER(IF) C 0772 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7

O TUNER(IF) C 0772 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7
O TUNER(IF) C 0772 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7
O TUNER(IF) C 0773 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(IF) C 0773 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 EZSM CX-SLX7
O TUNER(IF) C 0773 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 KSM CX-SLX7
O TUNER(IF) C 0774 87-A12-062-080 0E CAP,E 100-10 SMG EZSM CX-SLX7
O TUNER(IF) C 0774 87-A12-062-080 0E CAP,E 100-10 SMG KSM CX-SLX7
O TUNER(IF) C 0774 87-A12-062-080 0E CAP,E 100-10 SMG USM CX-SLX7
O TUNER(IF) C 0775 87-A12-090-080 0E CAP,E 4.7-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0775 87-A12-090-080 0E CAP,E 4.7-50 SMG KSM CX-SLX7

O TUNER(IF) C 0775 87-A12-090-080 0E CAP,E 4.7-50 SMG USM CX-SLX7
O TUNER(IF) C 0776 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0776 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0776 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0777 87-A12-086-080 0E CAP,E 0.47-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0777 87-A12-086-080 0E CAP,E 0.47-50 SMG KSM CX-SLX7
O TUNER(IF) C 0777 87-A12-086-080 0E CAP,E 0.47-50 SMG USM CX-SLX7
O TUNER(IF) C 0778 87-A12-087-080 0E CAP,E 1-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0778 87-A12-087-080 0E CAP,E 1-50 SMG KSM CX-SLX7
O TUNER(IF) C 0778 87-A12-087-080 0E CAP,E 1-50 SMG USM CX-SLX7

 38 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O TUNER(IF) C 0779 87-A12-087-080 0E CAP,E 1-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0779 87-A12-087-080 0E CAP,E 1-50 SMG KSM CX-SLX7
O TUNER(IF) C 0779 87-A12-087-080 0E CAP,E 1-50 SMG USM CX-SLX7
O TUNER(IF) C 0780 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(IF) C 0780 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(IF) C 0780 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(IF) C 0781 87-A12-091-080 0E CAP,E 10-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0781 87-A12-091-080 0E CAP,E 10-50 SMG KSM CX-SLX7
O TUNER(IF) C 0781 87-A12-091-080 0E CAP,E 10-50 SMG USM CX-SLX7
O TUNER(IF) C 0782 87-A12-091-080 0E CAP,E 10-50 SMG EZSM CX-SLX7

O TUNER(IF) C 0782 87-A12-091-080 0E CAP,E 10-50 SMG KSM CX-SLX7
O TUNER(IF) C 0782 87-A12-091-080 0E CAP,E 10-50 SMG USM CX-SLX7
O TUNER(IF) C 0783 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0783 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0783 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0784 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(IF) C 0784 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(IF) C 0784 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(IF) C 0785 87-010-805-080 0E C-CAP,S 1-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0785 87-010-805-080 0E C-CAP,S 1-16 Z F KSM CX-SLX7

O TUNER(IF) C 0785 87-010-805-080 0E C-CAP,S 1-16 Z F USM CX-SLX7
O TUNER(IF) C 0786 87-010-805-080 0E C-CAP,S 1-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0786 87-010-805-080 0E C-CAP,S 1-16 Z F KSM CX-SLX7
O TUNER(IF) C 0786 87-010-805-080 0E C-CAP,S 1-16 Z F USM CX-SLX7
O TUNER(IF) C 0787 87-012-280-080 0E C-CAP,U 3300P-50 K B EZSM CX-SLX7
O TUNER(IF) C 0787 87-012-280-080 0E C-CAP,U 3300P-50 K B KSM CX-SLX7
O TUNER(IF) C 0787 87-012-280-080 0E C-CAP,U 3300P-50 K B USM CX-SLX7
O TUNER(IF) C 0788 87-012-280-080 0E C-CAP,U 3300P-50 K B EZSM CX-SLX7
O TUNER(IF) C 0788 87-012-280-080 0E C-CAP,U 3300P-50 K B KSM CX-SLX7
O TUNER(IF) C 0788 87-012-280-080 0E C-CAP,U 3300P-50 K B USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TUNER(IF) C 0789 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM EZSM CX-SLX7
O TUNER(IF) C 0789 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM KSM CX-SLX7
O TUNER(IF) C 0789 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM USM CX-SLX7
O TUNER(IF) C 0790 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM EZSM CX-SLX7
O TUNER(IF) C 0790 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM KSM CX-SLX7
O TUNER(IF) C 0790 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM USM CX-SLX7
O TUNER(IF) C 0791 87-A12-091-080 0E CAP,E 10-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0791 87-A12-091-080 0E CAP,E 10-50 SMG KSM CX-SLX7
O TUNER(IF) C 0791 87-A12-091-080 0E CAP,E 10-50 SMG USM CX-SLX7
O TUNER(IF) C 0793 87-012-273-080 0E C-CAP,U 820P-50 K B USM CX-SLX7

O TUNER(IF) C 0793 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O TUNER(IF) C 0793 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O TUNER(IF) C 0794 87-A12-092-080 0E CAP,E 22-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0794 87-A12-092-080 0E CAP,E 22-50 SMG KSM CX-SLX7
O TUNER(IF) C 0794 87-A12-092-080 0E CAP,E 22-50 SMG USM CX-SLX7
O TUNER(IF) C 0795 87-010-596-080 0E C-CAP,S 0.047-16 K R C2012 USM CX-SLX7
O TUNER(IF) C 0795 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0795 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7
O TUNER(IF) C 0796 87-A12-089-080 0E CAP,E 3.3-50 SMG EZSM CX-SLX7
O TUNER(IF) C 0796 87-A12-089-080 0E CAP,E 3.3-50 SMG KSM CX-SLX7

O TUNER(IF) C 0796 87-A12-089-080 0E CAP,E 3.3-50 SMG USM CX-SLX7
O TUNER(IF) C 0797 87-012-276-080 0E C-CAP,U 1500P-50 K B EZSM CX-SLX7
O TUNER(IF) C 0797 87-012-276-080 0E C-CAP,U 1500P-50 K B KSM CX-SLX7
O TUNER(IF) C 0797 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O TUNER(IF) C 0798 87-012-276-080 0E C-CAP,U 1500P-50 K B EZSM CX-SLX7
O TUNER(IF) C 0798 87-012-276-080 0E C-CAP,U 1500P-50 K B KSM CX-SLX7
O TUNER(IF) C 0798 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O TUNER(IF) C 0799 87-010-829-080 0E C-CAP,U 0.047-16 Z F EZSM CX-SLX7
O TUNER(IF) C 0799 87-010-829-080 0E C-CAP,U 0.047-16 Z F KSM CX-SLX7
O TUNER(IF) C 0799 87-010-829-080 0E C-CAP,U 0.047-16 Z F USM CX-SLX7

! O TUNER(IF) CN 0601 87-099-029-010 0E CONN,12P H BLK 6216 EZSM CX-SLX7
! O TUNER(IF) CN 0601 87-099-029-010 0E CONN,12P H BLK 6216 KSM CX-SLX7
! O TUNER(IF) CN 0601 87-099-029-010 0E CONN,12P H BLK 6216 USM CX-SLX7
X TUNER(IF) D 0746 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
S TUNER(IF) D 0771 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S TUNER(IF) D 0771 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
X TUNER(IF) D 0771 88-100-000-010 0E PLATING-JW, 0.58 SN95 USM CX-SLX7
S TUNER(IF) D 0773 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S TUNER(IF) D 0773 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S TUNER(IF) D 0773 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7

 39 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S TUNER(IF) IC 0771 87-A20-913-010 1D IC,LA1837NL EZSM CX-SLX7
S TUNER(IF) IC 0771 87-A20-913-010 1D IC,LA1837NL KSM CX-SLX7
S TUNER(IF) IC 0771 87-A20-913-010 1D IC,LA1837NL USM CX-SLX7
X TUNER(IF) JR 0701 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(IF) JR 0701 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(IF) JR 0702 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0702 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0702 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(IF) JR 0703 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0703 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7

X TUNER(IF) JR 0703 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0704 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(IF) JR 0704 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(IF) JR 0705 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0705 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(IF) JR 0706 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0706 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(IF) JR 0706 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0707 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0707 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7

X TUNER(IF) JR 0707 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0708 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0708 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(IF) JR 0708 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0709 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0709 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(IF) JR 0709 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(IF) JR 0711 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(IF) JR 0711 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(IF) JR 0712 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(IF) JR 0712 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(IF) JR 0712 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0713 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(IF) JR 0713 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(IF) JR 0713 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0718 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0719 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0720 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(IF) JR 0721 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(IF) JR 0791 88-118-000-080 0E C-JUMPER,S USM CX-SLX7

X TUNER(IF) JR 0792 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
O TUNER(IF) L 0771 87-A50-266-010 1A COIL,FM DET-2N(TOK) EZSM CX-SLX7
O TUNER(IF) L 0771 87-A50-266-010 1A COIL,FM DET-2N(TOK) KSM CX-SLX7
O TUNER(IF) L 0771 87-A50-266-010 1A COIL,FM DET-2N(TOK) USM CX-SLX7
O TUNER(IF) L 0772 87-A90-733-010 1A FLTR,PCFAZH-450 (TOK) EZSM CX-SLX7
O TUNER(IF) L 0772 87-A90-733-010 1A FLTR,PCFAZH-450 (TOK) KSM CX-SLX7
O TUNER(IF) L 0772 87-A90-733-010 1A FLTR,PCFAZH-450 (TOK) USM CX-SLX7
O TUNER(IF) L 0781 87-005-847-080 0E COIL,2.2UH K CECS EZSM CX-SLX7
O TUNER(IF) L 0781 87-005-847-080 0E COIL,2.2UH K CECS KSM CX-SLX7
O TUNER(IF) L 0781 87-005-847-080 0E COIL,2.2UH K CECS USM CX-SLX7

O TUNER(IF) L 0791 87-A50-027-010 1A COIL,1 POLE MPX(TOK) EZSM CX-SLX7
O TUNER(IF) L 0791 87-A50-027-010 1A COIL,1 POLE MPX(TOK) KSM CX-SLX7
O TUNER(IF) L 0792 87-A50-027-010 1A COIL,1 POLE MPX(TOK) EZSM CX-SLX7
O TUNER(IF) L 0792 87-A50-027-010 1A COIL,1 POLE MPX(TOK) KSM CX-SLX7
X TUNER(IF) R 0730 88-121-102-080 0E RES,1K-1/8W J USM CX-SLX7
X TUNER(IF) R 0743 88-108-822-080 0E C-RES,U 8.2K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0743 88-108-822-080 0E C-RES,U 8.2K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0743 88-108-822-080 0E C-RES,U 8.2K-1/16W J USM CX-SLX7
X TUNER(IF) R 0760 88-108-271-080 0E C-RES,U 270-1/16W J USM CX-SLX7
X TUNER(IF) R 0760 88-121-271-080 0E RES,270-1/8W J EZSM CX-SLX7

X TUNER(IF) R 0760 88-121-271-080 0E RES,270-1/8W J KSM CX-SLX7
X TUNER(IF) R 0761 88-121-102-080 0E RES,1K-1/8W J EZSM CX-SLX7
X TUNER(IF) R 0761 88-121-102-080 0E RES,1K-1/8W J KSM CX-SLX7
X TUNER(IF) R 0763 88-108-221-080 0E C-RES,U 220-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0763 88-108-221-080 0E C-RES,U 220-1/16W J KSM CX-SLX7
X TUNER(IF) R 0763 88-108-221-080 0E C-RES,U 220-1/16W J USM CX-SLX7
X TUNER(IF) R 0765 88-108-151-080 0E C-RES,U 150-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0765 88-108-151-080 0E C-RES,U 150-1/16W J KSM CX-SLX7
X TUNER(IF) R 0765 88-108-151-080 0E C-RES,U 150-1/16W J USM CX-SLX7
X TUNER(IF) R 0771 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7

 40 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(IF) R 0771 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0771 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X TUNER(IF) R 0772 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X TUNER(IF) R 0772 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0772 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0773 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0773 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0773 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X TUNER(IF) R 0774 88-108-220-080 0E C-RES,U 22-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0774 88-108-220-080 0E C-RES,U 22-1/16W J KSM CX-SLX7

X TUNER(IF) R 0774 88-108-220-080 0E C-RES,U 22-1/16W J USM CX-SLX7
X TUNER(IF) R 0775 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0775 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0775 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X TUNER(IF) R 0776 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0776 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0776 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X TUNER(IF) R 0779 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0779 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0779 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7

X TUNER(IF) R 0780 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0780 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0780 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(IF) R 0781 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0781 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0781 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X TUNER(IF) R 0782 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0782 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0782 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-SLX7
X TUNER(IF) R 0783 88-108-822-080 0E C-RES,U 8.2K-1/16W J EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(IF) R 0783 88-108-822-080 0E C-RES,U 8.2K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0784 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X TUNER(IF) R 0784 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0784 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0785 88-121-103-080 0E RES,10K-1/8W J EZSM CX-SLX7
X TUNER(IF) R 0785 88-121-103-080 0E RES,10K-1/8W J KSM CX-SLX7
X TUNER(IF) R 0785 88-121-103-080 0E RES,10K-1/8W J USM CX-SLX7
X TUNER(IF) R 0787 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0787 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0787 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7

X TUNER(IF) R 0788 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0788 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0788 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7
X TUNER(IF) R 0790 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(IF) R 0790 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0790 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0791 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0791 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0791 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-SLX7
X TUNER(IF) R 0792 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7

X TUNER(IF) R 0792 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0792 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0793 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0793 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0793 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X TUNER(IF) R 0794 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-SLX7
X TUNER(IF) R 0794 88-108-682-080 0E C-RES,U 6.8K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0794 88-108-682-080 0E C-RES,U 6.8K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0795 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0795 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

X TUNER(IF) R 0795 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(IF) R 0797 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0797 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0797 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X TUNER(IF) R 0798 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X TUNER(IF) R 0798 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X TUNER(IF) R 0798 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X TUNER(PLL) 84-ZG1-264-010 0E SH, 7-7-0.2 W/ADH EZSM CX-SLX7
X TUNER(PLL) 84-ZG1-264-010 0E SH, 7-7-0.2 W/ADH KSM CX-SLX7
X TUNER(PLL) * 8A-ZA8-601-110 1A PWB,TUNER D ULH V 4M USM CX-SLX7

 41 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(PLL) * 8A-ZA8-602-110 1A PWB,TUNER EZK 4M EZSM CX-SLX7
X TUNER(PLL) * 8A-ZA8-602-110 1A PWB,TUNER EZK 4M KSM CX-SLX7
O TUNER(PLL) C 0701 87-A12-071-080 0E CAP,E 47-25 SMG EZSM CX-SLX7
O TUNER(PLL) C 0701 87-A12-071-080 0E CAP,E 47-25 SMG KSM CX-SLX7
O TUNER(PLL) C 0701 87-A12-071-080 0E CAP,E 47-25 SMG USM CX-SLX7
O TUNER(PLL) C 0702 87-A12-090-080 0E CAP,E 4.7-50 SMG EZSM CX-SLX7
O TUNER(PLL) C 0702 87-A12-090-080 0E CAP,E 4.7-50 SMG KSM CX-SLX7
O TUNER(PLL) C 0702 87-A12-090-080 0E CAP,E 4.7-50 SMG USM CX-SLX7
O TUNER(PLL) C 0703 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0703 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O TUNER(PLL) C 0703 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0704 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0704 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(PLL) C 0704 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0709 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O TUNER(PLL) C 0709 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O TUNER(PLL) C 0709 87-012-195-080 0E C-CAP,U 100P-50 J CH USM CX-SLX7
O TUNER(PLL) C 0711 87-A12-062-080 0E CAP,E 100-10 SMG EZSM CX-SLX7
O TUNER(PLL) C 0711 87-A12-062-080 0E CAP,E 100-10 SMG KSM CX-SLX7
O TUNER(PLL) C 0711 87-A12-062-080 0E CAP,E 100-10 SMG USM CX-SLX7

O TUNER(PLL) C 0712 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(PLL) C 0712 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(PLL) C 0712 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(PLL) C 0713 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0713 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(PLL) C 0713 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0714 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0714 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(PLL) C 0714 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0715 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TUNER(PLL) C 0715 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O TUNER(PLL) C 0717 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0717 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(PLL) C 0717 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0719 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(PLL) C 0719 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(PLL) C 0719 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(PLL) C 0720 87-012-195-080 0E C-CAP,U 100P-50 J CH EZSM CX-SLX7
O TUNER(PLL) C 0720 87-012-195-080 0E C-CAP,U 100P-50 J CH KSM CX-SLX7
O TUNER(PLL) C 0721 87-012-176-080 0E C-CAP,U 15P-50 J CH EZSM CX-SLX7

O TUNER(PLL) C 0721 87-012-176-080 0E C-CAP,U 15P-50 J CH KSM CX-SLX7
O TUNER(PLL) C 0721 87-012-176-080 0E C-CAP,U 15P-50 J CH USM CX-SLX7
O TUNER(PLL) C 0722 87-012-176-080 0E C-CAP,U 15P-50 J CH EZSM CX-SLX7
O TUNER(PLL) C 0722 87-012-176-080 0E C-CAP,U 15P-50 J CH KSM CX-SLX7
O TUNER(PLL) C 0722 87-012-176-080 0E C-CAP,U 15P-50 J CH USM CX-SLX7
O TUNER(PLL) C 0723 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O TUNER(PLL) C 0723 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O TUNER(PLL) C 0723 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O TUNER(PLL) C 0725 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O TUNER(PLL) C 0725 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7

O TUNER(PLL) C 0725 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O TUNER(PLL) C 0727 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(PLL) C 0727 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(PLL) C 0727 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(PLL) C 0728 87-A12-063-080 0E CAP,E 220-10 SMG EZSM CX-SLX7
O TUNER(PLL) C 0728 87-A12-063-080 0E CAP,E 220-10 SMG KSM CX-SLX7
O TUNER(PLL) C 0728 87-A12-063-080 0E CAP,E 220-10 SMG USM CX-SLX7
S TUNER(PLL) D 0721 87-017-148-080 0E ZENER,HZS6A1L EZSM CX-SLX7
S TUNER(PLL) D 0721 87-017-148-080 0E ZENER,HZS6A1L KSM CX-SLX7
S TUNER(PLL) D 0721 87-017-148-080 0E ZENER,HZS6A1L USM CX-SLX7

S TUNER(PLL) D 0774 87-A40-269-080 0E C-DIODE,MC2836 EZSM CX-SLX7
S TUNER(PLL) D 0774 87-A40-269-080 0E C-DIODE,MC2836 KSM CX-SLX7
S TUNER(PLL) D 0774 87-A40-270-080 0E C-DIODE,MC2838 USM CX-SLX7
S TUNER(PLL) IC 0721 87-A21-928-010 1C IC,LC72131D-N EZSM CX-SLX7
S TUNER(PLL) IC 0721 87-A21-928-010 1C IC,LC72131D-N KSM CX-SLX7
S TUNER(PLL) IC 0721 87-A21-928-010 1C IC,LC72131D-N USM CX-SLX7
X TUNER(PLL) JR 0704 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(PLL) JR 0705 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(PLL) JR 0710 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(PLL) JR 0710 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7

 42 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(PLL) JR 0722 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(PLL) JR 0725 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(PLL) JR 0730 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(PLL) JR 0730 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(PLL) JR 0730 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(PLL) JR 0731 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X TUNER(PLL) JR 0731 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X TUNER(PLL) JR 0731 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X TUNER(PLL) JR 0801 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(PLL) JR 0801 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7

X TUNER(PLL) JR 0802 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(PLL) JR 0802 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
S TUNER(PLL) Q 0711 87-A30-196-080 0E TR,2SC4115SRS EZSM CX-SLX7
S TUNER(PLL) Q 0711 87-A30-196-080 0E TR,2SC4115SRS KSM CX-SLX7
S TUNER(PLL) Q 0711 87-A30-196-080 0E TR,2SC4115SRS USM CX-SLX7
X TUNER(PLL) R 0703 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0703 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0705 88-108-562-080 0E C-RES,U 5.6K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0705 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0705 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-SLX7

X TUNER(PLL) R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0707 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0707 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0707 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0708 88-108-681-080 0E C-RES,U 680-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0708 88-108-681-080 0E C-RES,U 680-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0708 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-SLX7
X TUNER(PLL) R 0711 88-128-471-080 0E C-RES, 470-1/8W J EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(PLL) R 0711 88-128-471-080 0E C-RES, 470-1/8W J KSM CX-SLX7
X TUNER(PLL) R 0711 88-128-471-080 0E C-RES, 470-1/8W J USM CX-SLX7
X TUNER(PLL) R 0712 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0712 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0712 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0713 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0713 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0713 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X TUNER(PLL) R 0714 88-108-181-080 0E C-RES,U 180-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0714 88-108-181-080 0E C-RES,U 180-1/16W J KSM CX-SLX7

X TUNER(PLL) R 0714 88-108-181-080 0E C-RES,U 180-1/16W J USM CX-SLX7
X TUNER(PLL) R 0715 88-128-471-080 0E C-RES, 470-1/8W J EZSM CX-SLX7
X TUNER(PLL) R 0715 88-128-471-080 0E C-RES, 470-1/8W J KSM CX-SLX7
X TUNER(PLL) R 0715 88-128-471-080 0E C-RES, 470-1/8W J USM CX-SLX7
X TUNER(PLL) R 0717 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0717 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0717 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0718 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0718 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0718 88-121-103-080 0E RES,10K-1/8W J USM CX-SLX7

X TUNER(PLL) R 0719 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0719 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0719 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0720 88-108-563-080 0E C-RES,U 56K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0720 88-108-563-080 0E C-RES,U 56K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0720 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0722 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0722 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0722 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0724 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X TUNER(PLL) R 0724 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0724 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0726 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0726 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0726 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0727 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0727 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0727 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0728 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0728 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7

 43 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(PLL) R 0728 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(PLL) R 0729 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(PLL) R 0729 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(PLL) R 0729 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
O TUNER(PLL) X 0721 87-A70-306-010 1A VIB,XTAL 4.500MHZ CSA-309ST EZSM CX-SLX7
O TUNER(PLL) X 0721 87-A70-306-010 1A VIB,XTAL 4.500MHZ CSA-309ST KSM CX-SLX7
O TUNER(PLL) X 0721 87-A70-306-010 1A VIB,XTAL 4.500MHZ CSA-309ST USM CX-SLX7
O TUNER(RDS) C 0859 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RDS) C 0861 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O TUNER(RDS) C 0862 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7

O TUNER(RDS) C 0863 87-012-270-080 0E C-CAP,U 470P-50 K B EZSM CX-SLX7
O TUNER(RDS) C 0864 87-A12-091-080 0E CAP,E 10-50 SMG EZSM CX-SLX7
O TUNER(RDS) C 0865 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(RDS) C 0866 87-A12-091-080 0E CAP,E 10-50 SMG EZSM CX-SLX7
O TUNER(RDS) C 0867 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RDS) C 0868 87-012-184-080 0E C-CAP,U 33P-50 J CH EZSM CX-SLX7
O TUNER(RDS) C 0869 87-012-180-080 0E C-CAP,U 22P-50 J CH EZSM CX-SLX7
! O TUNER(RDS) CN 0602 87-099-211-010 0E CONN,4P V BLK 6216 EZSM CX-SLX7
S TUNER(RDS) IC 0851 87-A20-440-040 1H C-IC,BU1920FS EZSM CX-SLX7
X TUNER(RDS) L 0851 88-100-000-010 0E PLATING-JW, 0.58 SN95 EZSM CX-SLX7

S TUNER(RDS) Q 0853 87-A30-076-080 0E C-TR,2SC3052F EZSM CX-SLX7
X TUNER(RDS) R 0851 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0852 88-108-272-080 0E C-RES,U 2.7K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0853 88-108-224-080 0E C-RES,U 220K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0854 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0855 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0857 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0860 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(RDS) R 0861 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
O TUNER(RDS) X 0851 87-A70-091-010 1B VIB,XTAL 4.332MHZ CSA-309 EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TUNER(RF) C 0812 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0812 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0812 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(RF) C 0813 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-SLX7
O TUNER(RF) C 0814 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0814 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0814 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(RF) C 0818 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 EZSM CX-SLX7
O TUNER(RF) C 0818 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 KSM CX-SLX7
O TUNER(RF) C 0819 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USM CX-SLX7

O TUNER(RF) C 0820 87-A12-071-080 0E CAP,E 47-25 SMG EZSM CX-SLX7
O TUNER(RF) C 0820 87-A12-071-080 0E CAP,E 47-25 SMG KSM CX-SLX7
O TUNER(RF) C 0820 87-A12-071-080 0E CAP,E 47-25 SMG USM CX-SLX7
O TUNER(RF) C 0821 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0821 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0821 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(RF) C 0822 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0822 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0822 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(RF) C 0823 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7

O TUNER(RF) C 0823 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0823 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O TUNER(RF) C 0828 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(RF) C 0828 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(RF) C 0828 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(RF) C 0829 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(RF) C 0829 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(RF) C 0829 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(RF) C 0940 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0940 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

O TUNER(RF) C 0942 87-012-172-080 0E C-CAP,U 10P-50 D CH EZSM CX-SLX7
O TUNER(RF) C 0942 87-012-172-080 0E C-CAP,U 10P-50 D CH KSM CX-SLX7
O TUNER(RF) C 0947 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0947 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0949 87-A10-039-080 0E C-CAP,U 470P-50 J CH EZSM CX-SLX7
O TUNER(RF) C 0949 87-A10-039-080 0E C-CAP,U 470P-50 J CH KSM CX-SLX7
O TUNER(RF) C 0952 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0952 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O TUNER(RF) C 0958 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O TUNER(RF) C 0958 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7

 44 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O TUNER(RF) C 0959 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(RF) C 0959 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(RF) C 0959 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(RF) C 0960 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 EZSM CX-SLX7
O TUNER(RF) C 0960 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 KSM CX-SLX7
O TUNER(RF) C 0960 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USM CX-SLX7
O TUNER(RF) C 0961 87-012-170-080 0E C-CAP,U 8P-50 D CH USM CX-SLX7
O TUNER(RF) C 0962 87-A12-087-080 0E CAP,E 1-50 SMG EZSM CX-SLX7
O TUNER(RF) C 0962 87-A12-087-080 0E CAP,E 1-50 SMG KSM CX-SLX7
O TUNER(RF) CF 0801 87-008-261-010 1A FLTR,CF SFE10.7MA5 USM CX-SLX7

O TUNER(RF) CF 0801 87-008-423-010 1A FLTR,CF SFE10.7MS3G-A EZSM CX-SLX7
O TUNER(RF) CF 0801 87-008-423-010 1A FLTR,CF SFE10.7MS3G-A KSM CX-SLX7
O TUNER(RF) CF 0802 82-785-747-010 1A CF,MS2 GHY,R EZSM CX-SLX7
O TUNER(RF) CF 0802 82-785-747-010 1A CF,MS2 GHY,R KSM CX-SLX7
O TUNER(RF) CF 0802 87-008-261-010 1A FLTR,CF SFE10.7MA5 USM CX-SLX7
S TUNER(RF) D 0942 87-A40-270-080 0E C-DIODE,MC2838 EZSM CX-SLX7
S TUNER(RF) D 0942 87-A40-270-080 0E C-DIODE,MC2838 KSM CX-SLX7
S TUNER(RF) D 0944 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S TUNER(RF) D 0944 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
O TUNER(RF) FFE0801 A8-6ZA-19H-030 -- 6ZA-1 FEMENM EZSM CX-SLX7

O TUNER(RF) FFE0801 A8-6ZA-19H-030 -- 6ZA-1 FEMENM KSM CX-SLX7
O TUNER(RF) FFE0801 A8-8ZA-194-030 -- 8ZA-1 FEMUNM USM CX-SLX7
O TUNER(RF) J 0801 87-A60-657-010 1A TERMINAL,4P HSP-154V5-02 USM CX-SLX7
O TUNER(RF) J 0802 87-033-241-010 1B TERMINAL,ANT 2P AJ-2040 EZSM CX-SLX7
O TUNER(RF) J 0802 87-033-241-010 1B TERMINAL,ANT 2P AJ-2040 KSM CX-SLX7
X TUNER(RF) JR 0710 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(RF) JR 0711 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(RF) JR 0714 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(RF) JR 0715 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(RF) JR 0716 88-118-000-080 0E C-JUMPER,S USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(RF) JR 0723 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(RF) JR 0724 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
X TUNER(RF) JR 0801 88-129-000-080 0E C-JUMPER, 3216 USM CX-SLX7
X TUNER(RF) JR 0803 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(RF) JR 0803 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0804 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(RF) JR 0804 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0805 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(RF) JR 0805 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0806 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7

X TUNER(RF) JR 0806 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0807 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(RF) JR 0807 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(RF) JR 0808 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(RF) JR 0808 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(RF) JR 0901 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(RF) JR 0901 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0902 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X TUNER(RF) JR 0902 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0903 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7

X TUNER(RF) JR 0903 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X TUNER(RF) JR 0904 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(RF) JR 0904 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
X TUNER(RF) JR 0960 88-129-000-080 0E C-JUMPER, 3216 EZSM CX-SLX7
X TUNER(RF) JR 0960 88-129-000-080 0E C-JUMPER, 3216 KSM CX-SLX7
O TUNER(RF) L 0832 87-005-847-080 0E COIL,2.2UH K CECS EZSM CX-SLX7
O TUNER(RF) L 0832 87-005-847-080 0E COIL,2.2UH K CECS KSM CX-SLX7
O TUNER(RF) L 0832 87-005-847-080 0E COIL,2.2UH K CECS USM CX-SLX7
O TUNER(RF) L 0941 87-A50-020-010 0E COIL,ANT LW (COI) 252KHZ EZSM CX-SLX7
O TUNER(RF) L 0941 87-A50-020-010 0E COIL,ANT LW (COI) 252KHZ KSM CX-SLX7

O TUNER(RF) L 0942 87-A50-019-010 0E COIL,OSC LW (COI) 856KHZ EZSM CX-SLX7
O TUNER(RF) L 0942 87-A50-019-010 0E COIL,OSC LW (COI) 856KHZ KSM CX-SLX7
O TUNER(RF) L 0981 87-NF4-650-010 1D COIL,AM PACK4N(TOK) USM CX-SLX7
O TUNER(RF) L 0981 87-NF4-651-110 1C COIL,AM PACK2N(TOM) EZSM CX-SLX7
O TUNER(RF) L 0981 87-NF4-651-110 1C COIL,AM PACK2N(TOM) KSM CX-SLX7
S TUNER(RF) Q 0805 89-327-143-080 0E C-TR,2SC2714O EZSM CX-SLX7
S TUNER(RF) Q 0805 89-327-143-080 0E C-TR,2SC2714O KSM CX-SLX7
S TUNER(RF) Q 0805 89-327-143-080 0E C-TR,2SC2714O USM CX-SLX7
S TUNER(RF) Q 0806 87-A30-072-080 0E C-TR,RT1P 144C EZSM CX-SLX7
S TUNER(RF) Q 0806 87-A30-072-080 0E C-TR,RT1P 144C KSM CX-SLX7

 45 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S TUNER(RF) Q 0806 87-A30-072-080 0E C-TR,RT1P 144C USM CX-SLX7
S TUNER(RF) Q 0947 89-503-602-080 1A C-FET,2SK360E EZSM CX-SLX7
S TUNER(RF) Q 0947 89-503-602-080 1A C-FET,2SK360E KSM CX-SLX7
S TUNER(RF) Q 0948 87-A30-086-070 0E C-TR,CSD1306E EZSM CX-SLX7
S TUNER(RF) Q 0948 87-A30-086-070 0E C-TR,CSD1306E KSM CX-SLX7
S TUNER(RF) Q 0951 87-A30-074-080 0E C-TR,RT1P 141C EZSM CX-SLX7
S TUNER(RF) Q 0951 87-A30-074-080 0E C-TR,RT1P 141C KSM CX-SLX7
S TUNER(RF) Q 0952 87-A30-086-070 0E C-TR,CSD1306E EZSM CX-SLX7
S TUNER(RF) Q 0952 87-A30-086-070 0E C-TR,CSD1306E KSM CX-SLX7
X TUNER(RF) R 0820 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X TUNER(RF) R 0820 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0820 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(RF) R 0821 88-108-221-080 0E C-RES,U 220-1/16W J USM CX-SLX7
X TUNER(RF) R 0821 88-128-121-080 0E C-RES, 120-1/8W J EZSM CX-SLX7
X TUNER(RF) R 0821 88-128-121-080 0E C-RES, 120-1/8W J KSM CX-SLX7
X TUNER(RF) R 0822 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(RF) R 0823 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0823 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0823 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(RF) R 0824 88-108-331-080 0E C-RES,U 330-1/16W J EZSM CX-SLX7

X TUNER(RF) R 0824 88-108-331-080 0E C-RES,U 330-1/16W J KSM CX-SLX7
X TUNER(RF) R 0824 88-108-331-080 0E C-RES,U 330-1/16W J USM CX-SLX7
X TUNER(RF) R 0825 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0825 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0825 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-SLX7
X TUNER(RF) R 0826 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0826 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0826 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X TUNER(RF) R 0827 88-108-181-080 0E C-RES,U 180-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0827 88-108-181-080 0E C-RES,U 180-1/16W J KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(RF) R 0827 88-108-181-080 0E C-RES,U 180-1/16W J USM CX-SLX7
X TUNER(RF) R 0828 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0828 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X TUNER(RF) R 0828 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-SLX7
X TUNER(RF) R 0830 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0830 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X TUNER(RF) R 0830 88-128-101-080 0E C-RES, 100-1/8W J USM CX-SLX7
X TUNER(RF) R 0832 88-108-391-080 0E C-RES,U 390-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0832 88-108-391-080 0E C-RES,U 390-1/16W J KSM CX-SLX7
X TUNER(RF) R 0832 88-108-391-080 0E C-RES,U 390-1/16W J USM CX-SLX7

X TUNER(RF) R 0836 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0836 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0836 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X TUNER(RF) R 0839 88-108-151-080 0E C-RES,U 150-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0839 88-108-151-080 0E C-RES,U 150-1/16W J KSM CX-SLX7
X TUNER(RF) R 0839 88-108-151-080 0E C-RES,U 150-1/16W J USM CX-SLX7
X TUNER(RF) R 0840 88-108-221-080 0E C-RES,U 220-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0840 88-108-221-080 0E C-RES,U 220-1/16W J KSM CX-SLX7
X TUNER(RF) R 0840 88-108-221-080 0E C-RES,U 220-1/16W J USM CX-SLX7
X TUNER(RF) R 0944 88-108-101-080 0E C-RES,U 100-1/16W J EZSM CX-SLX7

X TUNER(RF) R 0944 88-108-101-080 0E C-RES,U 100-1/16W J KSM CX-SLX7
X TUNER(RF) R 0945 88-108-104-080 0E C-RES,U 100K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0945 88-108-104-080 0E C-RES,U 100K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0945 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-SLX7
X TUNER(RF) R 0947 88-108-183-080 0E C-RES,U 18K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0947 88-108-183-080 0E C-RES,U 18K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0948 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0948 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0952 88-108-562-080 0E C-RES,U 5.6K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0952 88-108-562-080 0E C-RES,U 5.6K-1/16W J KSM CX-SLX7

X TUNER(RF) R 0954 88-108-222-080 0E C-RES,U 2.2K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0954 88-108-222-080 0E C-RES,U 2.2K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0956 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0956 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X TUNER(RF) R 0958 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0958 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0959 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0959 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0962 88-121-221-080 0E RES,220-1/8W J USM CX-SLX7
X TUNER(RF) R 0962 88-128-221-080 0E C-RES, 220-1/8W J EZSM CX-SLX7

 46 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(RF) R 0962 88-128-221-080 0E C-RES, 220-1/8W J KSM CX-SLX7
X TUNER(RF) R 0963 88-108-330-080 0E C-RES,U 33-1/16W J USM CX-SLX7
X TUNER(RF) R 0964 88-108-330-080 0E C-RES,U 33-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0964 88-108-330-080 0E C-RES,U 33-1/16W J KSM CX-SLX7
X TUNER(RF) R 0970 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X TUNER(RF) R 0970 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X TUNER(RF) R 0990 88-118-472-080 0E C-RES,S 4.7K-1/10W J USM CX-SLX7
O TUNER(RF) TC 0942 87-A91-658-010 0E TRIMMER,30P 4.0X4.5 ECRL EZSM CX-SLX7
O TUNER(RF) TC 0942 87-A91-658-010 0E TRIMMER,30P 4.0X4.5 ECRL KSM CX-SLX7
O VOL/FUNC C 0076 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7

O VOL/FUNC C 0201 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O VOL/FUNC C 0201 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7
O VOL/FUNC C 0201 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7
O VOL/FUNC C 0202 87-012-199-080 0E C-CAP,U 220P-50 J CH EZSM CX-SLX7
O VOL/FUNC C 0202 87-012-199-080 0E C-CAP,U 220P-50 J CH KSM CX-SLX7
O VOL/FUNC C 0202 87-012-199-080 0E C-CAP,U 220P-50 J CH USM CX-SLX7
O VOL/FUNC C 0213 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB EZSM CX-SLX7
O VOL/FUNC C 0213 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB KSM CX-SLX7
O VOL/FUNC C 0213 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB USM CX-SLX7
O VOL/FUNC C 0214 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB EZSM CX-SLX7

O VOL/FUNC C 0214 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB KSM CX-SLX7
O VOL/FUNC C 0214 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB USM CX-SLX7
O VOL/FUNC C 0215 87-010-544-040 0E CAP,E 0.1-50 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0215 87-010-544-040 0E CAP,E 0.1-50 M 11L SME KSM CX-SLX7
O VOL/FUNC C 0215 87-010-544-040 0E CAP,E 0.1-50 M 11L SME USM CX-SLX7
O VOL/FUNC C 0216 87-010-544-040 0E CAP,E 0.1-50 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0216 87-010-544-040 0E CAP,E 0.1-50 M 11L SME KSM CX-SLX7
O VOL/FUNC C 0216 87-010-544-040 0E CAP,E 0.1-50 M 11L SME USM CX-SLX7
O VOL/FUNC C 0217 87-012-278-080 0E C-CAP,U 2200P-50 K B EZSM CX-SLX7
O VOL/FUNC C 0217 87-012-278-080 0E C-CAP,U 2200P-50 K B KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O VOL/FUNC C 0217 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O VOL/FUNC C 0218 87-012-278-080 0E C-CAP,U 2200P-50 K B EZSM CX-SLX7
O VOL/FUNC C 0218 87-012-278-080 0E C-CAP,U 2200P-50 K B KSM CX-SLX7
O VOL/FUNC C 0218 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-SLX7
O VOL/FUNC C 0501 87-A12-071-040 0E CAP,E 47-25 SMG EZSM CX-SLX7
O VOL/FUNC C 0501 87-A12-071-040 0E CAP,E 47-25 SMG KSM CX-SLX7
O VOL/FUNC C 0501 87-A12-071-040 0E CAP,E 47-25 SMG USM CX-SLX7
O VOL/FUNC C 0502 87-A12-071-040 0E CAP,E 47-25 SMG EZSM CX-SLX7
O VOL/FUNC C 0502 87-A12-071-040 0E CAP,E 47-25 SMG KSM CX-SLX7
O VOL/FUNC C 0502 87-A12-071-040 0E CAP,E 47-25 SMG USM CX-SLX7

O VOL/FUNC C 0503 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O VOL/FUNC C 0503 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O VOL/FUNC C 0503 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O VOL/FUNC C 0504 87-012-274-080 0E C-CAP,U 1000P-50 K B EZSM CX-SLX7
O VOL/FUNC C 0504 87-012-274-080 0E C-CAP,U 1000P-50 K B KSM CX-SLX7
O VOL/FUNC C 0504 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-SLX7
O VOL/FUNC C 0511 87-012-276-080 0E C-CAP,U 1500P-50 K B EZSM CX-SLX7
O VOL/FUNC C 0511 87-012-276-080 0E C-CAP,U 1500P-50 K B KSM CX-SLX7
O VOL/FUNC C 0511 87-012-276-080 0E C-CAP,U 1500P-50 K B USM CX-SLX7
O VOL/FUNC C 0512 87-012-276-080 0E C-CAP,U 1500P-50 K B EZSM CX-SLX7

O VOL/FUNC C 0512 87-012-276-080 0E C-CAP,U 1500P-50 K B KSM CX-SLX7
O VOL/FUNC C 0512 87-012-276-080 0E C-CAP,U 1500P-50 K B USM CX-SLX7
O VOL/FUNC C 0521 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB EZSM CX-SLX7
O VOL/FUNC C 0521 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB KSM CX-SLX7
O VOL/FUNC C 0521 87-010-758-080 0E C-CAP,U 0.068-25 Z F CM/CB USM CX-SLX7
O VOL/FUNC C 0522 87-A11-070-080 0E C-CAP,U 0.033-16 K B EZSM CX-SLX7
O VOL/FUNC C 0522 87-A11-070-080 0E C-CAP,U 0.033-16 K B KSM CX-SLX7
O VOL/FUNC C 0522 87-A11-070-080 0E C-CAP,U 0.033-16 K B USM CX-SLX7
O VOL/FUNC C 0524 87-010-401-040 0E CAP,E 1-50 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0524 87-010-401-040 0E CAP,E 1-50 M 11L SME KSM CX-SLX7

O VOL/FUNC C 0524 87-010-401-040 0E CAP,E 1-50 M 11L SME USM CX-SLX7
O VOL/FUNC C 0525 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0525 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0525 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0526 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0526 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0526 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0527 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O VOL/FUNC C 0527 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O VOL/FUNC C 0527 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7

 47 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O VOL/FUNC C 0528 87-012-286-080 0E C-CAP,U 0.01-25 K B EZSM CX-SLX7
O VOL/FUNC C 0528 87-012-286-080 0E C-CAP,U 0.01-25 K B KSM CX-SLX7
O VOL/FUNC C 0528 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-SLX7
O VOL/FUNC C 0531 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0531 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE KSM CX-SLX7
O VOL/FUNC C 0531 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-SLX7
O VOL/FUNC C 0532 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0532 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE KSM CX-SLX7
O VOL/FUNC C 0532 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-SLX7
O VOL/FUNC C 0535 87-A10-504-080 0E C-CAP,U 0.047-16 K B EZSM CX-SLX7

O VOL/FUNC C 0535 87-A10-504-080 0E C-CAP,U 0.047-16 K B KSM CX-SLX7
O VOL/FUNC C 0535 87-A10-504-080 0E C-CAP,U 0.047-16 K B USM CX-SLX7
O VOL/FUNC C 0536 87-A10-504-080 0E C-CAP,U 0.047-16 K B EZSM CX-SLX7
O VOL/FUNC C 0536 87-A10-504-080 0E C-CAP,U 0.047-16 K B KSM CX-SLX7
O VOL/FUNC C 0536 87-A10-504-080 0E C-CAP,U 0.047-16 K B USM CX-SLX7
O VOL/FUNC C 0537 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0537 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE KSM CX-SLX7
O VOL/FUNC C 0537 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE USM CX-SLX7
O VOL/FUNC C 0538 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0538 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE KSM CX-SLX7

O VOL/FUNC C 0538 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE USM CX-SLX7
O VOL/FUNC C 0539 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM EZSM CX-SLX7
O VOL/FUNC C 0539 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM KSM CX-SLX7
O VOL/FUNC C 0539 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM USM CX-SLX7
O VOL/FUNC C 0540 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM EZSM CX-SLX7
O VOL/FUNC C 0540 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM KSM CX-SLX7
O VOL/FUNC C 0540 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM USM CX-SLX7
O VOL/FUNC C 0541 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0541 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0541 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O VOL/FUNC C 0542 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0542 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0542 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0543 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0543 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0543 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0544 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7
O VOL/FUNC C 0544 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0544 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0545 87-A10-260-080 0E C-CAP,U 0.1-16 K B EZSM CX-SLX7

O VOL/FUNC C 0545 87-A10-260-080 0E C-CAP,U 0.1-16 K B KSM CX-SLX7
O VOL/FUNC C 0545 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-SLX7
O VOL/FUNC C 0546 87-010-403-040 0E CAP,E 3.3-50 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0546 87-010-403-040 0E CAP,E 3.3-50 M 11L SME KSM CX-SLX7
O VOL/FUNC C 0546 87-010-403-040 0E CAP,E 3.3-50 M 11L SME USM CX-SLX7
O VOL/FUNC C 0547 87-010-401-040 0E CAP,E 1-50 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0547 87-010-401-040 0E CAP,E 1-50 M 11L SME KSM CX-SLX7
O VOL/FUNC C 0547 87-010-401-040 0E CAP,E 1-50 M 11L SME USM CX-SLX7
O VOL/FUNC C 0549 87-010-071-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0549 87-010-071-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7

O VOL/FUNC C 0549 87-010-071-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
O VOL/FUNC C 0550 87-010-071-040 0E CAP,E 1-50 M 5L SRE EZSM CX-SLX7
O VOL/FUNC C 0550 87-010-071-040 0E CAP,E 1-50 M 5L SRE KSM CX-SLX7
O VOL/FUNC C 0550 87-010-071-040 0E CAP,E 1-50 M 5L SRE USM CX-SLX7
X VOL/FUNC C 0595 88-118-000-080 0E C-JUMPER,S EZSM CX-SLX7
X VOL/FUNC C 0595 88-118-000-080 0E C-JUMPER,S KSM CX-SLX7
X VOL/FUNC C 0595 88-118-000-080 0E C-JUMPER,S USM CX-SLX7
O VOL/FUNC C 0702 87-010-374-040 0E CAP,E 47-10 M 11L SME EZSM CX-SLX7
O VOL/FUNC C 0702 87-010-374-040 0E CAP,E 47-10 M 11L SME KSM CX-SLX7
O VOL/FUNC C 0702 87-010-374-040 0E CAP,E 47-10 M 11L SME USM CX-SLX7

O VOL/FUNC C 0703 87-010-831-080 0E C-CAP,U 0.1-16 Z F EZSM CX-SLX7
O VOL/FUNC C 0703 87-010-831-080 0E C-CAP,U 0.1-16 Z F KSM CX-SLX7
O VOL/FUNC C 0703 87-010-831-080 0E C-CAP,U 0.1-16 Z F USM CX-SLX7
! O VOL/FUNC CN 0201 87-A60-059-010 0E CONN,08P V 9604S-08C EZSM CX-SLX7
! O VOL/FUNC CN 0201 87-A60-059-010 0E CONN,08P V 9604S-08C KSM CX-SLX7
! O VOL/FUNC CN 0201 87-A60-059-010 0E CONN,08P V 9604S-08C USM CX-SLX7
! O VOL/FUNC CN 0202 87-A60-059-010 0E CONN,08P V 9604S-08C EZSM CX-SLX7
! O VOL/FUNC CN 0202 87-A60-059-010 0E CONN,08P V 9604S-08C KSM CX-SLX7
! O VOL/FUNC CN 0202 87-A60-059-010 0E CONN,08P V 9604S-08C USM CX-SLX7
! O VOL/FUNC CN 0501 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK EZSM CX-SLX7

 48 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

! O VOL/FUNC CN 0501 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK KSM CX-SLX7
! O VOL/FUNC CN 0501 87-A61-272-010 0E CONN,11P V BLK FMN-BTRK USM CX-SLX7
S VOL/FUNC D 0201 87-070-136-080 0E ZENER,MTZJ5.1B EZSM CX-SLX7
S VOL/FUNC D 0201 87-070-136-080 0E ZENER,MTZJ5.1B KSM CX-SLX7
S VOL/FUNC D 0201 87-070-136-080 0E ZENER,MTZJ5.1B USM CX-SLX7
S VOL/FUNC D 0501 87-A40-437-080 0E ZENER,MTZJ4.3B EZSM CX-SLX7
S VOL/FUNC D 0501 87-A40-437-080 0E ZENER,MTZJ4.3B KSM CX-SLX7
S VOL/FUNC D 0501 87-A40-437-080 0E ZENER,MTZJ4.3B USM CX-SLX7
S VOL/FUNC D 0502 87-A40-437-080 0E ZENER,MTZJ4.3B EZSM CX-SLX7
S VOL/FUNC D 0502 87-A40-437-080 0E ZENER,MTZJ4.3B KSM CX-SLX7

S VOL/FUNC D 0502 87-A40-437-080 0E ZENER,MTZJ4.3B USM CX-SLX7
S VOL/FUNC D 0504 87-020-465-080 0E DIODE,1SS133 EZSM CX-SLX7
S VOL/FUNC D 0504 87-020-465-080 0E DIODE,1SS133 KSM CX-SLX7
S VOL/FUNC D 0504 87-020-465-080 0E DIODE,1SS133 USM CX-SLX7
S VOL/FUNC IC 0501 87-A21-452-130 1H C-IC,BD3876AKS2 EZSM CX-SLX7
S VOL/FUNC IC 0501 87-A21-452-130 1H C-IC,BD3876AKS2 KSM CX-SLX7
S VOL/FUNC IC 0501 87-A21-452-130 1H C-IC,BD3876AKS2 USM CX-SLX7
! S VOL/FUNC IC 0701 87-017-825-010 1E IC,GP1F32T EZSM CX-SLX7
! S VOL/FUNC IC 0701 87-017-825-010 1E IC,GP1F32T KSM CX-SLX7
! S VOL/FUNC IC 0701 87-017-825-010 1E IC,GP1F32T USM CX-SLX7

O VOL/FUNC J 0201 87-A61-595-010 1A JACK,PIN 3P R/W/B EZSM CX-SLX7
O VOL/FUNC J 0201 87-A61-595-010 1A JACK,PIN 3P R/W/B KSM CX-SLX7
O VOL/FUNC J 0201 87-A61-595-010 1A JACK,PIN 3P R/W/B USM CX-SLX7
O VOL/FUNC J 0202 87-YP6-608-010 1B TERMINAL,SPKR 4P EZSM CX-SLX7
O VOL/FUNC J 0202 87-YP6-608-010 1B TERMINAL,SPKR 4P KSM CX-SLX7
O VOL/FUNC J 0202 87-YP6-608-010 1B TERMINAL,SPKR 4P USM CX-SLX7
! O VOL/FUNC J 0501 87-009-610-010 1A JACK,PIN 2P WHT W/O SW EZSM CX-SLX7
! O VOL/FUNC J 0501 87-009-610-010 1A JACK,PIN 2P WHT W/O SW KSM CX-SLX7
! O VOL/FUNC J 0501 87-009-610-010 1A JACK,PIN 2P WHT W/O SW USM CX-SLX7
O VOL/FUNC JR 0101 87-A50-189-080 0E C-COIL,S BLM21B272S EZSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O VOL/FUNC JR 0101 87-A50-189-080 0E C-COIL,S BLM21B272S KSM CX-SLX7
O VOL/FUNC JR 0101 87-A50-189-080 0E C-COIL,S BLM21B272S USM CX-SLX7
X VOL/FUNC JR 0102 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC JR 0102 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC JR 0102 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
O VOL/FUNC L 0201 87-003-383-010 1A COIL,1UH K EZSM CX-SLX7
O VOL/FUNC L 0201 87-003-383-010 1A COIL,1UH K KSM CX-SLX7
O VOL/FUNC L 0201 87-003-383-010 1A COIL,1UH K USM CX-SLX7
O VOL/FUNC L 0202 87-003-383-010 1A COIL,1UH K EZSM CX-SLX7
O VOL/FUNC L 0202 87-003-383-010 1A COIL,1UH K KSM CX-SLX7

O VOL/FUNC L 0202 87-003-383-010 1A COIL,1UH K USM CX-SLX7
S VOL/FUNC Q 0253 87-A30-257-080 0E C-TR,2SD1306E EZSM CX-SLX7
S VOL/FUNC Q 0253 87-A30-257-080 0E C-TR,2SD1306E KSM CX-SLX7
S VOL/FUNC Q 0253 87-A30-257-080 0E C-TR,2SD1306E USM CX-SLX7
S VOL/FUNC Q 0254 87-A30-257-080 0E C-TR,2SD1306E EZSM CX-SLX7
S VOL/FUNC Q 0254 87-A30-257-080 0E C-TR,2SD1306E KSM CX-SLX7
S VOL/FUNC Q 0254 87-A30-257-080 0E C-TR,2SD1306E USM CX-SLX7
X VOL/FUNC R 0201 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0201 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0201 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7

X VOL/FUNC R 0202 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0202 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0202 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X VOL/FUNC R 0203 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0203 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X VOL/FUNC R 0203 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
X VOL/FUNC R 0204 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0204 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X VOL/FUNC R 0204 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-SLX7
X VOL/FUNC R 0205 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7

X VOL/FUNC R 0205 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0205 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0206 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0206 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0206 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0245 88-121-100-080 0E RES,10-1/8W J EZSM CX-SLX7
X VOL/FUNC R 0245 88-121-100-080 0E RES,10-1/8W J KSM CX-SLX7
X VOL/FUNC R 0245 88-121-100-080 0E RES,10-1/8W J USM CX-SLX7
X VOL/FUNC R 0246 88-121-100-080 0E RES,10-1/8W J EZSM CX-SLX7
X VOL/FUNC R 0246 88-121-100-080 0E RES,10-1/8W J KSM CX-SLX7

 49 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X VOL/FUNC R 0246 88-121-100-080 0E RES,10-1/8W J USM CX-SLX7
X VOL/FUNC R 0247 88-121-100-080 0E RES,10-1/8W J EZSM CX-SLX7
X VOL/FUNC R 0247 88-121-100-080 0E RES,10-1/8W J KSM CX-SLX7
X VOL/FUNC R 0247 88-121-100-080 0E RES,10-1/8W J USM CX-SLX7
X VOL/FUNC R 0248 88-121-100-080 0E RES,10-1/8W J EZSM CX-SLX7
X VOL/FUNC R 0248 88-121-100-080 0E RES,10-1/8W J KSM CX-SLX7
X VOL/FUNC R 0248 88-121-100-080 0E RES,10-1/8W J USM CX-SLX7
X VOL/FUNC R 0249 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0249 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0249 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7

X VOL/FUNC R 0250 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0250 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0250 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X VOL/FUNC R 0251 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0251 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0251 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X VOL/FUNC R 0501 88-130-470-080 0E RES,47-1/4W J EZSM CX-SLX7
X VOL/FUNC R 0501 88-130-470-080 0E RES,47-1/4W J KSM CX-SLX7
X VOL/FUNC R 0501 88-130-470-080 0E RES,47-1/4W J USM CX-SLX7
X VOL/FUNC R 0502 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7

X VOL/FUNC R 0502 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0502 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X VOL/FUNC R 0503 88-108-122-080 0E C-RES,U 1.2K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0503 88-108-122-080 0E C-RES,U 1.2K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0503 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-SLX7
X VOL/FUNC R 0508 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0508 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0508 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0509 88-130-470-080 0E RES,47-1/4W J EZSM CX-SLX7
X VOL/FUNC R 0509 88-130-470-080 0E RES,47-1/4W J KSM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X VOL/FUNC R 0509 88-130-470-080 0E RES,47-1/4W J USM CX-SLX7
X VOL/FUNC R 0510 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0510 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0510 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0511 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0511 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0511 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7
X VOL/FUNC R 0512 88-108-332-080 0E C-RES,U 3.3K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0512 88-108-332-080 0E C-RES,U 3.3K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0512 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-SLX7

X VOL/FUNC R 0513 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0513 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0513 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X VOL/FUNC R 0514 88-108-123-080 0E C-RES,U 12K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0514 88-108-123-080 0E C-RES,U 12K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0514 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-SLX7
X VOL/FUNC R 0515 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0515 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0515 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X VOL/FUNC R 0516 88-108-392-080 0E C-RES,U 3.9K-1/16W J EZSM CX-SLX7

X VOL/FUNC R 0516 88-108-392-080 0E C-RES,U 3.9K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0516 88-108-392-080 0E C-RES,U 3.9K-1/16W J USM CX-SLX7
X VOL/FUNC R 0517 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0517 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0517 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0518 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0518 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0518 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0519 88-108-272-080 0E C-RES,U 2.7K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0519 88-108-272-080 0E C-RES,U 2.7K-1/16W J KSM CX-SLX7

X VOL/FUNC R 0519 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-SLX7
X VOL/FUNC R 0520 88-108-272-080 0E C-RES,U 2.7K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0520 88-108-272-080 0E C-RES,U 2.7K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0520 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-SLX7
X VOL/FUNC R 0521 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0521 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0521 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7
X VOL/FUNC R 0522 88-108-473-080 0E C-RES,U 47K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0522 88-108-473-080 0E C-RES,U 47K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0522 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-SLX7

 50 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X VOL/FUNC R 0523 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0523 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0523 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X VOL/FUNC R 0524 88-108-273-080 0E C-RES,U 27K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0524 88-108-273-080 0E C-RES,U 27K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0524 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-SLX7
X VOL/FUNC R 0525 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0525 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0525 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X VOL/FUNC R 0526 88-108-472-080 0E C-RES,U 4.7K-1/16W J EZSM CX-SLX7

X VOL/FUNC R 0526 88-108-472-080 0E C-RES,U 4.7K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0526 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-SLX7
X VOL/FUNC R 0528 88-108-223-080 0E C-RES,U 22K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0528 88-108-223-080 0E C-RES,U 22K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0528 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-SLX7
X VOL/FUNC R 0533 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0533 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0533 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X VOL/FUNC R 0534 88-108-154-080 0E C-RES,U 150K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0534 88-108-154-080 0E C-RES,U 150K-1/16W J KSM CX-SLX7

X VOL/FUNC R 0534 88-108-154-080 0E C-RES,U 150K-1/16W J USM CX-SLX7
X VOL/FUNC R 0535 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0535 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0535 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X VOL/FUNC R 0536 88-108-102-080 0E C-RES,U 1K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0536 88-108-102-080 0E C-RES,U 1K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0536 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-SLX7
X VOL/FUNC R 0537 88-108-474-080 0E C-RES,U 470K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0537 88-108-474-080 0E C-RES,U 470K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0537 88-108-474-080 0E C-RES,U 470K-1/16W J USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X VOL/FUNC R 0538 88-108-333-080 0E C-RES,U 33K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0538 88-108-333-080 0E C-RES,U 33K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0538 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-SLX7
X VOL/FUNC R 0539 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0539 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0539 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0540 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0540 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0540 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0545 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7

X VOL/FUNC R 0545 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0545 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0546 88-108-182-080 0E C-RES,U 1.8K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0546 88-108-182-080 0E C-RES,U 1.8K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0546 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-SLX7
X VOL/FUNC R 0547 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0547 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7
X VOL/FUNC R 0547 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0548 88-108-103-080 0E C-RES,U 10K-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0548 88-108-103-080 0E C-RES,U 10K-1/16W J KSM CX-SLX7

X VOL/FUNC R 0548 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-SLX7
X VOL/FUNC R 0549 88-108-105-080 0E C-RES,U 1M-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0549 88-108-105-080 0E C-RES,U 1M-1/16W J KSM CX-SLX7
X VOL/FUNC R 0549 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-SLX7
X VOL/FUNC R 0550 88-108-105-080 0E C-RES,U 1M-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0550 88-108-105-080 0E C-RES,U 1M-1/16W J KSM CX-SLX7
X VOL/FUNC R 0550 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-SLX7
X VOL/FUNC R 0557 88-121-103-080 0E RES,10K-1/8W J EZSM CX-SLX7
X VOL/FUNC R 0557 88-121-103-080 0E RES,10K-1/8W J KSM CX-SLX7
X VOL/FUNC R 0557 88-121-103-080 0E RES,10K-1/8W J USM CX-SLX7

X VOL/FUNC R 0558 88-108-105-080 0E C-RES,U 1M-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0558 88-108-105-080 0E C-RES,U 1M-1/16W J KSM CX-SLX7
X VOL/FUNC R 0558 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-SLX7
X VOL/FUNC R 0591 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0591 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0591 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0592 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0592 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0592 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0593 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7

 51 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X VOL/FUNC R 0593 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0593 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0594 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0594 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7
X VOL/FUNC R 0594 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0701 88-108-000-080 0E C-JUMPER,U USM CX-SLX7
X VOL/FUNC R 0701 88-108-471-080 0E C-RES,U 470-1/16W J EZSM CX-SLX7
X VOL/FUNC R 0701 88-108-471-080 0E C-RES,U 470-1/16W J KSM CX-SLX7
X VOL/FUNC R 0703 88-108-000-080 0E C-JUMPER,U EZSM CX-SLX7
X VOL/FUNC R 0703 88-108-000-080 0E C-JUMPER,U KSM CX-SLX7

X VOL/FUNC R 0703 88-108-000-080 0E C-JUMPER,U USM CX-SLX7

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

 52 

SCHEMATIC DIAGRAM – 1 (MAIN : AMP)

– 53 –

SCHEMATIC DIAGRAM – 2 (MAIN : FUNCTION 1 / 2)

– 54 –

SCHEMATIC DIAGRAM – 3 (FUNCTION 2 / 2)

– 55 –

SCHEMATIC DIAGRAM – 4 (TUNER)

– 56 –

SCHEMATIC DIAGRAM – 5 (FRONT)

– 57 –

SCHEMATIC DIAGRAM – 6 (POWER SUPPLY)

– 58 –

SCHEMATIC DIAGRAM – 7 (PT)

– 59 –

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]

Printed in Singapore2000058
